Sony A3880132 User Guide
SO-03D
INSTRUCTION MANUAL
’11.10
Introduction
Thank you for your purchase of "SO-03D".
For proper use of the SO-03D, read this manual carefully before and while you use the SO-03D.
Before using the terminal
●The SO-03D supports W-CDMA, GSM/GPRS and Wireless LAN Systems.
●Because the terminal operates using radio frequencies, it cannot be used inside a tunnel, underground, in
a building or other locations where radio waves do not reach the terminal, in locations with weak radio wave
condition, or outside of the FOMA's service area. The FOMA services may not be available on high upper
floors of high-rise apartments or buildings, even if you can see no obstructions around you. On occasion,
your calls may become disconnected even in areas with strong radio wave condition, even if you are not
moving, or even if there are 4-antenna marks in the terminal's display.
●Note that because the terminal operates on radio frequencies, your calls are at risk of being intercepted by
the third party. However, the W-CDMA, GSM/GPRS system automatically scrambles all calls through a
private call feature. Therefore, even if third party successfully intercepts your call, they will only hear noise.
●The terminal operates on radio frequencies by converting voice into digital signals. If the caller moves into
an area of adverse radio wave condition, the digital signal may not restored accurately, and the voice
received in the call may differ slightly from the actual voice.
●Always keep the information you save in the terminal in a separate note. Even if the data may be lost as a
result of malfunction, repair, change, or other handling of the terminal, under no condition will DOCOMO be
held liable for any lost data saved in the terminal.
●You are recommended to save important data to microSD card.
●As with PCs, some user-installed applications may disrupt the stability of the terminal performance, or
unexpectedly transmit information via the Internet causing improper use of your location information as well
as personal information recorded on the terminal. Therefore, verify the supplier and operating conditions of
the applications to be used before using them.
●This terminal has FOMA Plus-Area and FOMA HIGH-SPEED Area support.
●Descriptions in this manual are for the terminal with a DOCOMO's UIM inserted.
SIM unlock
This terminal supports SIM unlock. If you release SIM lock, you can use SIM by a carrier other than
NTT DOCOMO.
●The SIM unlock service is provided at a docomo Shop.
●A SIM unlock charge is separately required.
●If you use a SIM other than by DOCOMO, available services and functions will be limited. DOCOMO is not
liable to any failures or malfunctions.
●For details of SIM unlock, refer to NTT DOCOMO website.
Accessories
Supplied accessories
･ SO-03D (with warranty and Back Cover
SO17)
･ Quick Start Guide (In Japanese only)
･ Battery Pack SO04
･ AC Adapter Cable SO03 (with warranty)
<AC adapter> <microUSB cable>
･ microSDHC card (16GB)* (Sample)
(with instruction manual)
クイック
スター ト
ガイド
･ Notes on usage
Safety/Handling precautions (In Japanese
only)
* Inserted in the terminal when purchased.
･ Stereo Headset with Microphone (Sample)
(with instruction manual)
For details on optional devices, see "Optional
and related devices" (P.193).
1
About manuals of SO-03D
In addition to this manual, the operations of
SO-03D are described in "Quick Start Guide"
(in Japanese only) and "Instruction Manual"
application of the terminal.
❖Cautions
･ For downloading or updating the application, a
high packet communication charge will be applied
because of a large amount data communication.
For this reason, subscription of packet flat-rate
service is highly recommended.
* If you use Wi-Fi function to download, packet
communication charges are not applied.
"Quick Start Guide"
(Supplied accessories)
The initial operations and settings after
purchasing the terminal, screen view
contents and operations of main function are
explained. (In Japanese only)
"Instruction Manual"
(Application of the terminal)
Similarly to this manual, operations and
settings of each function are explained.
To use "Instruction Manual" application, from
the Home screen, tap X [Instruction
Manual]. For the first time using, download
and install it according to the onscreen
instructions. You can use the application as
an electronic book. You can also shift to
actual operations by tapping the description
in the contents or view reference contents.
"Instruction Manual" (PDF file)
Operations and settings of each function are
explained.
It can be downloaded from NTT DOCOMO
website.
http://www.nttdocomo.co.jp/english/support/
trouble/manual/download/index.html
* The URL and contents are subject to
change without prior notice.
❖Cautions
･ Reproduction or reprint of all or part of this manual
without prior permission is prohibited.
･ Important information for SO-03D is posted in the
following website. Be sure to check before using.
http://www.sonyericsson.co.jp/support/
use_support/product/so-03d/
2
Operation descriptions
In this manual, each key operations are
described with p, x, y, t,
s, m. And selection operations of
the icons or function items on the touch panel
are described as follows.
Description Operation
･ Please note that "SO-03D" is called the "the
terminal" in this manual.
From the Home
screen, press
t and tap
[Settings].
Tap [Settings] X
[Date & time] X
[Set date].
Tap to
zoom out or in.
Touch and hold
an icon.
From the Home screen, press
t (Menu) key and tap
"Settings" on the screen.
Tap "Settings" displayed on the
screen, and then tap "Date &
time" on the next screen and
"Set date" on the following
screen in order.
Tap displayed on the
screen to zoom out or in the
map.
Keep touching an icon on the
screen longer (1-2 seconds).
❖Information
･ In this manual, the instructions are described with
the default Home screen. If you set the other
application to the home screen, the operations
may differ from the descriptions.
･ Display examples and illustrations used in this
manual are just images for explanations and may
be different from actual ones.
･ In this manual, the easier procedure is described
for the functions and settings which have multiple
operating procedures.
3
Contents
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
About manuals of SO-03D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions (Always follow these directions) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Handling precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
･ Part names and functions ......................................................25
･ UIM .........................................................................................27
･ microSD card .........................................................................28
･ Charging ................................................................................ 29
･ Turning power on and off ....................................................... 34
･ Initial settings (Setup guide) .................................................. 35
Before Using the Handset
→P. 2 5
･ Status bar ............................................................................... 36
･ Notification panel ................................................................... 38
･ Notification LED...................................................................... 38
･ Basic operations .................................................................... 39
･ Home screen ..........................................................................42
･ Searching information in the terminal and web pages ..........47
･ Applications screen ............................................................... 48
･ Character entry ......................................................................56
･ Settings of entering characters ..............................................65
･ Settings of Japanese keyboard .............................................66
Calling/Network Services
→P. 7 1
･ Making/Receiving calls ..........................................................71
･ Call log ...................................................................................75
･ Contacts ................................................................................. 76
･ Network Services ................................................................... 85
Contents/Precautions
4
Settings
→P. 9 3
Mail/Internet
→P.122
･ Viewing the setting menu ....................................................... 93
･ Wireless & networks ............................................................... 93
･ Call settings.......................................................................... 102
･ Sound ................................................................................... 103
･ Display ................................................................................. 105
･ Location & security............................................................... 106
･ Applications ......................................................................... 111
･ Accounts & sync ..................................................................114
･ Privacy.................................................................................. 117
･ Storage .................................................................................118
･ Language & keyboard ......................................................... 119
･ Voice input & output .............................................................119
･ Accessibility .........................................................................120
･ Date & time........................................................................... 120
･ About phone......................................................................... 121
･ sp-mode mail ....................................................................... 122
･ Message (SMS) ....................................................................122
･ Email..................................................................................... 124
･ Using Gmail.......................................................................... 131
･ Google Talk (Chat) ...............................................................131
･ Early warning "Area Mail" .....................................................132
･ Using Browser ......................................................................133
File management
→P.138
Games
→P.148
･ Handling a file ......................................................................138
･ Transferring and moving data ..............................................138
･ Using Bluetooth function ...................................................... 143
･ Sharing files with DLNA devices via Connected devices
(Media server) ......................................................................147
･ Use the terminal as a gaming console................................. 148
Contents/Precautions
5
Applications
→P.150
･ Using the camera .................................................................150
･ Shooting screenshot ............................................................ 158
･ Playing multimedia content .................................................. 158
･ Viewing photos/videos with Gallery ..................................... 160
･ Playing video with YouTube.................................................. 163
･ Music player .........................................................................165
･ TrackID .................................................................................168
･ Using Android Market ..........................................................168
･ Using docomo market ..........................................................169
･ Timescape
･ About location services ........................................................174
･ Calendar............................................................................... 179
･ Clock/Alarm.......................................................................... 181
･ OfficeSuite ............................................................................183
･ Other applications ................................................................183
TM
........................................................................170
International roaming
→P.186
Appendix/Index
→P.193
･ Overview of International roaming (WORLD WING) ............186
･ Available Services ................................................................186
･ Before using ......................................................................... 187
･ Making/Receiving calls in the country you stay ...................190
･ Optional and related devices ...............................................193
･ Troubleshooting....................................................................193
･ Warranty and After Sales Services....................................... 198
･ Updating software ................................................................201
･ Main specifications .............................................................. 203
･ Specific Absorption Rate of Mobile Phone, etc. ..................206
･ End User Licence Agreement ..............................................219
･ About Open Source Software............................................... 220
･ Export Controls and Regulations .........................................220
･ Intellectual Property Right .................................................... 220
･ Index .................................................................................... 224
Contents/Precautions
6
Notes on usage
･ The terminal does not support i-mode sites
(programs) or i-Dppli.
･ The terminal automatically performs
communication for synchronizing data,
checking the latest software version,
maintain connection with the server, etc. If
you transmit a large amount of data such
as downloading applications or watching
movie, a packet communication charge
becomes high. Subscription of packet flatrate service is highly recommended.
･ Public mode (Driving mode) is not
supported.
･ Setting the phone to silent mode does not
mute sounds (playback of video or music,
alarm, etc.) other than the ringtone,
operation sound, and notification sounds.
･ The names of the operators are displayed
on the key unlocking screen (P.35).
･ Your phone number (own number) can be
checked as follows:
From the Home screen, press t and
tap [Settings] X [About phone] X [Status].
･ The software version of your terminal can
be checked as follows:
From the Home screen, press t and
tap [Settings] X [About phone].
･ You can perform software update by
downloading an update file with a PC via
Internet and connecting the PC to the
terminal. For details, see "Connecting to a
PC and updating" (P.202).
･ By some software updates, the operating
system (OS) may be version-upgraded for
improving the terminal quality. For this
reason, you always need to use the latest
OS version. And some applications that
used in the previous OS version may not
be available or some unintended bugs
may occur.
･ If you use the terminal with a part of FOMA
cards (green) inserted, voice calls and
packet communication may not be
available with some overseas network
operators or in some overseas networks.
For using overseas, please visit a docomo
Shop near you. DOCOMO exchanges UIM
(FOMA card) (green) free of charge.
･ Set the screen lock to ensure the security
of your terminal for its loss. For details, see
"Screen lock" (P.109).
Contents/Precautions
Continued on next page
7
･ If your terminal is lost, change your each
account password to invalidate
authentication using a PC to prevent other
persons from using Google services such
as Google Talk, Gmail, Android Market,
etc., Facebook, Twitter and mixi.
･ The terminal supports only sp-mode,
mopera U and Business mopera Internet.
Other providers are not supported.
･ To use tethering, subscription of sp-mode
is required.
･ Packet communication charge when using
tethering varies depending on the
charging plan you use. Subscription of
packet flat-rate service is highly
recommended.
･ If you subscribe packet flat-rate service,
packet communication charge is treated
as "communications connected to an
external device such as a PC". If tethering
is enabled, all packet communication
charge is treated as "communications
connected to an external device such as a
PC" even if any external device is not
connected.
Make sure to deactivate tethering as soon
as communication with an external device
is completed.
･ In the initial settings for tethering, security
setting is not made. Make a security
setting as required.
･ For details on usage charge, etc., refer to
http://www.nttdocomo.co.jp/ .
Notice:
This device has been granted a designation
number by the Ministry of Internal Affairs and
Communications according to the Ordinance
concerning the Technical
Regulations
Conformity Certification etc. of Specified
Radio Equipment
(特定無線設備の技術基準適合証明等に関す
る規則 )
R-(W-CDMA)/Article 2-1-11-3:
202XYSM1156964
R-(W-CDMA) /Article 2-1-11-7:
202MWSM1156964
IEEE802.11bgn (2.4GHz)/Article 2-1-19:
202WWSM1156964
BT/Article 2-1-19: 202WWSM11569641
ANT+/Article 2-1-19: 202WWSM11569642
T-(W-CDMA): AD 11-0022 202
This device should not be modified
(otherwise the granted designation number
will become invalid)
Contents/Precautions
8
Safety Precautions (Always
■ The following symbols indicate specific
directions.
follow these directions)
■ For safe and proper use of the terminal, please
read the "Safety Precautions" prior to use.
Keep the Manual in a safe place for future
reference.
■ ALWAYS observe the safety precautions since
they intend to prevent personal injury or
property damage.
■ The following symbols indicate the different
levels of injury or damage that may result if the
guidelines are not observed and the terminal
is used improperly.
Failure to observe
DANGER
WARNING
CAUTION
these guidelines may
immediately result in
death or serious injury.
Failure to observe
these guidelines may
result in death or
serious injury.
Failure to observe
these guidelines may
result in injury and
property damage.
Indicates prohibited actions.
Don’t
Indicates not to disassemble.
No disassembly
Indicates not to handle with wet hands.
No wet hands
Indicates not to use where it could get
No liquids
Unplug
wet.
Indicates compulsory actions in
accordance with instructions.
Do
Indicates to remove the power plug from
the outlet.
■ "Safety Precautions" are described in the
following categories:
1. Handling the terminal, Battery Pack, AC
Adapter cable, and UIM (general)................. 10
2. Handling the terminal....................................11
3. Handling the Battery Pack ............................ 13
4. Handling the AC Adapter cable..................... 14
5. Handling the UIM..........................................16
6. Handling the terminal near electronic medical
equipment..................................................... 16
7. Material list ................................................... 17
Contents/Precautions
9
1. Handling the terminal, Battery
Pack, AC Adapter cable, and UIM
(general)
DANGER
Don’t
WARNING
Do not throw the equipment, put strong force
or give hard shock to it.
Doing so may cause fire, burns, injury or
electric shock.
Do not use, store, or leave the terminal,
battery pack, AC adapter cable, or UIM in a
place subject to high temperature such as
Don’t
Don’t
No disassembly
No liquids
close to fire, under direct sunlight, or in a car
on an extremely hot day.
Doing so may cause fire, burns or injury.
Do not place the terminal, battery pack, AC
adapter cable, or UIM inside cooking
appliance such as a microwave oven or highpressure containers.
Doing so may cause fire, burns, injury or
electric shock.
Do not disassemble or modify the terminal,
battery pack, AC adapter cable, or UIM.
Doing so may cause fire, burns, injury or
electric shock.
Do not let the terminal, battery pack, AC
adapter cable, or UIM get wet with water,
drinking water, urine of pet animals, etc.
Doing so may cause fire, burns, injury or
electric shock.
Use the battery pack and AC adapter cable
for the terminal specified by DOCOMO.
Failure to do so may cause fire, burns, injury
Do
or electric shock.
Don’t
Don’t
Do
Do
Do not allow the microUSB connection jack
or headset connection jack to come in
contact with conducting foreign substances
(a piece of metal, pencil lead, etc.). Never
allow these objects to get into the connection
jack.
Doing so may cause fire, burns, injury or
electric shock.
Do not cover or wrap the terminal, battery
pack, AC adapter cable, or UIM with a cloth
or bedding in use or while charging.
Doing so may cause fire or burns.
Power off the terminal before you step into a
place where flammable gas can leak, such
as gas stations. Do not charge the battery.
Gas may catch fire.
If you notice anything unusual about the
terminal, battery pack, AC adapter cable, or
UIM such as an unusual odor, overheating,
discoloration or deformation during
operation, charging or storage, immediately
perform the following measures.
・Remove the power plug from the power
outlet.
・Power off the terminal.
・Remove the battery pack from the terminal.
Failure to do so may cause fire, burns, injury
or electric shock.
Contents/Precautions
10
CAUTION
2. Handling the terminal
Don’t
Don’t
Do
Do
Do
Do not place on an unstable or inclined
platform.
Doing so may cause the device to fall and
cause injury.
Do not keep in a place that is very humid,
dusty, or subject to high temperature.
Doing so may cause fire, burns or electric
shock.
If children use the terminal, parents or
guardians should give them the proper
instructions for use. Make sure that they use
the terminal as instructed.
Failure to do so may cause injury.
Keep the terminal, battery pack, AC adapter
cable, or UIM out of the reach of babies and
infants.
Failure to do so may cause accidental
swallowing or injury.
Be careful especially when you use the
terminal while it has been continuously
connected to the AC adapter cable for a long
period of time.
If you play a game, etc. for a long time while
charging, the temperature of the terminal,
battery pack and AC adapter cable may
rise.
If you are directly in contact with hot parts
for a long period of time, it may cause your
skin to become red, itchy, or develop a rash
depending on your physical condition and
also it may cause low-temperature burn.
Don’t
Don’t
Don’t
WARNING
Do not turn on the photo light with the
lighting luminescence part close to the eyes.
Especially to shoot infants or young children,
step away from them more than 1 m.
Doing so may cause blurred vision. Or injury
by dazzling eyes or surprising may occur.
Do not allow a foreign substance such as
water and other liquids, metal parts, or
flammables to get in the UIM or microSD
card insertion slot on the terminal.
Doing so may cause fire, burns, injury or
electric shock.
Do not turn on the light toward a driver of a
car etc.
Doing so may disturb driving and cause an
accident.
Contents/Precautions
11
WARNING
WARNING
Power off the terminal in a place where the
use is prohibited such as in airplane or
hospital.
Failure to do so may affect electronic
equipment and electronic medical
equipment. If you set the automatic poweron function, cancel it before powering off the
terminal.
Follow the instructions of each medical
facility for the use of mobile phones on their
premises.
Prohibited acts such as mobile phone usage
Do
on board an airplane may be punished by
law. If usage of mobile phones in an aircraft
is admitted by setting airplane mode, etc.,
use the terminal under the direction of the
airline.
If the microUSB cable is connected into the
microUSB connection jack for charging etc.,
the terminal is automatically powered on. Be
careful not to connect the microUSB cable in
a place where the use is prohibited such as
in airplane or hospital.
Always keep the terminal away from your ear
when you talk setting the hands-free
function.
Also, when you play game, play back music,
etc. connecting the Earphone/Microphone,
etc. to the terminal, adjust the volume
adequately.
Do
If the volume is too loud, it may cause
difficulty in hearing. Moreover, if you barely
hear the surrounding sounds, it may cause
an accident.
If you have a weak heart, set the vibrator or
ringtone volume carefully.
Failure to do so may affect your heart.
Do
If you are wearing any electronic medical
equipment, check with the relevant medical
electronic equipment manufacturer or vendor
whether the operation may be affected by
radio waves.
Do
The radio waves from the terminal may
affect electronic medical equipment.
Power off the terminal near electronic
devices or equipment operating on high
precision control or weak signals.
Failure to do so may interfere with the
operation of electronic devices or
equipment.
* The followings are some electronic devices
or equipment that you should be careful of:
Hearing aids, implantable cardiac
pacemaker, implantable cardioverter
defibrillator, other electronic medical
Do
Do
equipment, fire detector, automatic door,
and other automatically controlled devices
or equipment.
If you use an implantable cardiac
pacemaker, implantable cardioverter
defibrillator, or other electronic medical
equipment, check with the relevant
medical electronic equipment
manufacturer or vendor whether the
operation can be affected by radio waves.
Be careful about broken glasses or exposed
internal from the terminal if the display or the
camera lens is broken.
Shatterproof film-applied hardened glass is
used on the display surface and the acrylic
resin is applied on camera lens so as not to
be shattered when broken. But they may
cause injury if you touch a cut surface or
exposed portion mistakenly.
Contents/Precautions
12
CAUTION
CAUTION
Don’t
Don’t
Don’t
Do
Do
Do not swing the terminal around by holding
the strap, etc.
The terminal may hit you or others and
cause accident such as injury.
Do not use damaged terminal.
Doing so may cause fire, burns, injury or
electric shock.
If the display is mistakenly damaged and
when the liquid crystal runs out, do not get it
on your skin such as face, hands, etc.
Doing so may cause blindness or injury on
your skin.
If the liquid crystal gets in your eye or
mouth, rinse with clean running water, and
get medical treatment immediately.
Also, if it gets on your skin or clothes, use
something such as alcohol to wipe off and
wash it with soap in clear water.
To use the terminal in car, check with
automobile manufacturer or dealer to
determine how the device is affected by radio
waves before using.
In rare cases, using the phone in some
vehicle models can cause the vehicle's
electronic equipment to malfunction. In that
case, stop using the terminal immediately.
The use of the terminal may cause itching,
rashes, eczema, or other symptoms
depending on the user's physical condition.
Immediately stop using and get medical
treatment in such a case.
For material of each part, →P.17 "Material
list".
When opening or closing the terminal, take
care not to have your fingers or strap caught
by the terminal.
Do
Failure to do so may cause injury.
When watching the display, take a certain
distance from the display in a fully bright
place.
Do
Failure to do so may reduce visual acuity.
3. Handling the Battery Pack
■ Check the type of the battery by the label on
the battery pack.
Display Type of Bat te ry
Li-ion 00 Lithium Ion Battery
DANGER
Do not touch the battery pack terminal with a
metal object such as a wire. Also, do not
carry or keep the battery pack together with
Don’t
Don’t
Don’t
metal objects such as a necklace.
Doing so may cause battery pack to ignite,
explode, overheat or leak.
Check the orientation of battery pack to
install it to the terminal, and do not forcibly
attach the battery pack to the terminal if you
are having trouble installing it.
Doing so may cause battery pack to ignite,
explode, overheat or leak.
Do not throw the battery pack into fire.
Doing so may cause battery pack to ignite,
explode, overheat or leak.
Contents/Precautions
13
DANGER
CAUTION
Don’t
Do
Don’t
Do
Do
Do not stick a nail into the battery pack, hit it
with a hammer, or step on it.
Doing so may cause battery pack to ignite,
explode, overheat or leak.
If the battery fluid gets into your eyes, do not
rub, rinse with clean running water, and get
medical treatment immediately.
Failure to do so may cause blindness.
WARNING
If the battery pack seems to have
abnormalities such as deformation or
scratches due to falling, never use it.
Doing so may cause battery pack to ignite,
explode, overheat or leak.
If the battery pack leaks or hears an unusual
odor, immediately stop using and move it
away from fire.
The leaking liquid may ignite fire, catch fire,
or explode.
Be careful about your pet not to bite the
battery pack.
Failure to do so may cause battery pack to
ignite, explode, overheat or leak.
Do not discard the battery pack together with
other garbage.
The battery pack may become the source of
fire or environmental destruction. Take the
used battery pack to our service counter
Don’t
Don’t
(docomo Shop, etc.) after insulating it by
affixing an adhesive tape on the terminal of it
or follow the instructions of the local
authorities in charge of collecting used
battery packs.
Do not use or charge the wet battery pack.
Doing so may cause battery pack to ignite,
explode, overheat or leak.
If fluid etc. leaks out from battery pack, do
not make the fluid contact with your skin of
face or hands.
Doing so may cause blindness or injury on
your skin.
If the fluid etc. put into your eyes or mouth,
or contacts skin or clothes, immediately
Do
flush the contacted area with clean running
water.
If the fluid put into the eyes or mouth,
immediately see a doctor after flushing.
4. Handling the AC Adapter cable
Don’t
WARNING
Do not use the microUSB cable if it is
damaged.
Doing so may cause fire, burns or electric
shock.
Contents/Precautions
14
WARNING
WARNING
Do not use the AC adapter cable in a very
humid or steamy place such as bathroom.
Don’t
Don’t
Don’t
Don’t
Don’t
No wet hands
Doing so may cause fire, burns or electric
shock.
Do not touch the AC adapter cable if you
hear thunder.
Doing so may cause electric shock.
Do not short-circuit the microUSB plug while
it is connected to the power outlet. Do not
touch the microUSB plug with your hands,
fingers, or any part of your body.
Doing so may cause fire, burns or electric
shock.
Do not place any heavy objects on the
microUSB cable.
Doing so may cause fire, burns or electric
shock.
When you insert and remove AC adapter
from power outlet, do not contact a metal
strap or other metal objects with the jack.
Doing so may cause fire, burns or electric
shock.
Do not touch the cord of the AC adapter
cable or the power outlet with wet hands.
Doing so may cause fire, burns or electric
shock.
Do
Do
Do
Do
Unplug
Unplug
Use the adapter only on the specified power
supply and voltage.
Use the AC adapter cable available overseas
when you charge the battery overseas.
Failure to do so may cause fire, burns or
electric shock.
AC adapter cable: AC 100 V to 240 V (Make
sure to connect the adapter to a household
AC power outlet.)
Clean dust from the power plug.
Failure to do so may cause fire, burns or
electric shock.
When you connect the AC adapter to the
power outlet, insert it firmly.
Failure to do so may cause fire, burns or
electric shock.
Hold the AC adapter, not the microUSB
cable, when you remove the power plug from
the power outlet.
Failure to do so may cause fire, burns or
electric shock.
Remove the power plug from the power
outlet when not used for a long period of
time.
Failure to do so may cause fire, burns or
electric shock.
If liquid such as water gets into the adapter,
immediately remove it from the power outlet.
Failure to do so may cause fire, burns or
electric shock.
Contents/Precautions
15
WARNING
WARNING
Before cleaning, remove the power plug from
the power outlet.
Unplug
Failure to do so may cause fire, burns or
electric shock.
5. Handling the UIM
CAUTION
Please be careful not to touch a cut surface
when you remove the UIM.
Failure to do so may cause injury.
Do
6. Handling the terminal near
electronic medical equipment
■ The following instructions observe the
guidelines of the Electromagnetic
Compatibility Conference, Japan to protect
electronic medical equipment from radio
waves from mobile phones.
Please observe the following guidelines in
medical facilities.
・Do not take the terminal into the operating
rooms, ICU (Intensive Care Unit), or CCU
(Coronary Care Unit).
・Power off the terminal inside hospital
wards.
・Power off the terminal in the lobby and
Do
Do
other places if there are any electronic
medical equipment operating in the
vicinity.
・Follow the instructions of each medical
facility when they specify areas forbidding
to use and carrying a mobile phone.
・If you set the automatic power-on function,
cancel it before powering off the terminal.
Power off the terminal in crowded places
such as rush-hour trains. There may be a
person with an implantable cardiac
pacemaker or implantable cardioverter
defibrillator near you.
The radio waves from the terminal may
affect the operation of implantable cardiac
pacemaker or implantable cardioverter
defibrillator.
Wearers of electronic medical equipment
such as implanted pacemakers or
defibrillators must carry and use terminal at
least 22 cm away from the implanted device.
The radio waves from the terminal may
Do
affect the performance of electronic medical
equipment.
Contents/Precautions
16
WARNING
If you need to use electronic medical
equipment other than implantable cardiac
pacemaker or implantable cardioverter
defibrillator outside medical facilities such as
treating at home, check with the relevant
medical electronic equipment manufacturer
whether the operation may be affected by
Do
radio waves.
The radio waves from the terminal may
affect the performance of electronic medical
equipment.
7. Material list
Part Material
Exterior case
(Front)
Hardware key
(Back key,
Home key,
Menu key,
Search key)
Transparent
plate (Display)
Inner
packaging
(panel part
when game
keypad open)
PC resin
(with glass)
PC resin Non-conductive
Hardened
glass+
PET resin
PC resin UV coating
Surface
treatment
Non-conductive
vacuum
metallization (tin)+
UV coating
vacuum
metallization (tin)+
UV coating
Hard coating
Part Material
Inner
packaging
(front and back
part when game
keypad open)
Hardware key
(△/□/○/ ×
keys, Direction
key)
Hardware key
(Game menu
button of the
game keypad,
Select button,
Start button)
Hardware key
(Touch pad)
Inner
packaging
(Slide rail)
Transparent
plate (Camera
lens cover)
Transparent
plate (Photo
light cover)
Surface
treatment
PC resin (with
glass)+SUS+
PET resin
PC resin UV coating
PC resin UV coating
PET resin UV coating
PCM resin None
PMMA resin AR coating+
PMMA resin AR coating+
UV coating
Non-conductive
vacuum
metallization (tin)+
UV coating
Non-conductive
vacuum
metallization (tin)+
UV coating
Contents/Precautions
Continued on next page
17
Part Material
Surface
treatment
Handling precautions
Exterior case
(Lateral side of
body)
Hardware key
(L button,
R button)
Hardware key
(Volume key,
Power key)
Back Cover PC resin
PC resin
(with glass)
PC resin
(with glass)
PC resin UV coating
(with glass)
Non-conductive
vacuum
metallization (tin)+
UV coating
Non-conductive
vacuum
metallization (tin)+
UV coating
UV coating
■Common precautions
･ Do not expose to water.
The terminal, battery pack, AC Adapter cable,
and UIM are not waterproof. Do not use them in
a humid place such as bathroom or in the rain.
If you carry the terminal on your body,
perspiration may corrode the internal parts of
the terminal and cause malfunction. Note that if
a trouble is diagnosed as exposure to water or
other liquid, repairs of the terminal may not be
covered by the Warranty or it may not be
possible to repair such phones. In that case,
even if the terminal can be repaired, it is
repaired at the owner's expense.
･ Clean the terminal with a dry soft cloth
(such as used for cleaning eyeglasses).
- Do not rub it roughly with a dry cloth. The
display may be damaged.
- Drops of water or dirt left on the display may
cause stains.
- Do not use alcohol, thinner, benzene,
cleaning detergent, etc. to clean the
terminal. These chemicals may erase the
printing on the terminal or cause
discoloration.
Contents/Precautions
Continued on next page
18
･ Clean the terminals occasionally with a
dry cotton swab.
If the jack is soiled, connection gets worse and
it may cause power to be turned off or
insufficient battery charge, so clean the jack
with a dry cotton swab etc. When cleaning, be
careful not to damage the terminals.
･ Do not leave the terminal near the air
conditioning vent.
Extreme temperature changes may produce
condensation and corrode the internal parts of
the terminal, causing it to malfunction.
･ Make sure to use the terminal or battery
pack without excessive force.
If you put the terminal in a bag full of items or sit
down with the terminal in the pocket of your
cloth, it may damage the display, and internal
circuit board, and the battery pack and cause
the terminal to malfunction.
Also, while the external device is connected to
the microUSB connection jack or headset
connection jack, it may damage the connector
and cause malfunction.
･ Do not rub or scratch the display with
metal.
The display may get scratched and it may
cause malfunction or damage.
･ Make sure to see the user's manuals
supplied with the battery pack and AC
adapter cable.
■The terminal precautions
･ Do not press touch panel surface
forcibly, or not operate with a sharppointed objects such as nail, ballpoint
pen, pin, etc.
Doing so may cause damage of touch panel.
･ Do not use the terminal in extremely hot
or cold places.
Use the terminal within a temperature range of
5°C to 35°C and a humidity range of 45% to
85%.
･ Using the terminal near ordinary phone,
television or radio may cause
interference in these electric
appliances. Make sure to move far away
from them when using the terminal.
･ Note down the information saved in the
terminal in a separate note and keep it
safely.
Under no condition will DOCOMO be held
liable for any damaged or lost data saved in the
terminal.
･ Do not drop or give a strong impact to
the terminal.
Doing so may cause malfunction or damage.
･ Do not plug the connector of the external
device into the microUSB connection
jack or headset connection jack at the
slant or pull it while connecting.
Doing so may cause malfunction or damage.
Contents/Precautions
Continued on next page
19
･ The terminal could become warm while
in use and charging. This condition is
not abnormal. You can continue
charging the battery.
･ Do not leave the camera under direct
sunlight.
If you do so, some of the elements may melt or
become faded.
･ Do not use the terminal without the back
cover.
Doing so may cause the battery pack fall,
malfunction, and damage.
･ Do not put extreme thick stickers etc. on
the keypad side.
Doing so may cause malfunction, damage or
erroneous operation.
･ Do not put labels or stickers on the back
side of the display.
Label or sticker may be hooked when opening/
closing the terminal and may cause
malfunction or damage.
･ Do not remove the microSD card or
power off the terminal while using the
microSD card.
Doing so may cause data loss or malfunction.
･ Do not let magnetic cards, etc. come
close to the terminal.
The magnetic data in cash cards, credit cards,
telephone cards, floppy disks, etc. may be
erased.
･ Do not bring strong magnetic objects
close to the terminal.
Strong magnetic objects may cause
misoperation.
■Battery pack precautions
･ The battery pack is a consumable
accessory.
Even if the operating time of the terminal varies
depending on the operating conditions and
other factors, when the length of time you can
use the terminal with a fully charged battery
becomes unusually short, it is time to replace
the battery pack. Purchase the battery pack
specified in this manual.
･ Charge the battery pack in an
environment with the proper ambient
temperature (5°C to 35°C).
･ The operating time of the battery pack
varies depending on the operating
environment and the secular
degradation level of the battery pack.
･ Depending on the use condition, the
battery pack may be inflated as it comes
to the end of its life. This is not a
malfunction.
Contents/Precautions
Continued on next page
20
･ Do not store the battery pack in the
following cases:
- The battery is fully charged (immediately
after the charging is complete)
- The battery has run out (the phone cannot
power on)
The performance and life of the battery pack
may deteriorate.
It is recommended that you store the battery
pack with the remaining battery level of about
40 percent as a guide.
■AC adapter cable precautions
･ Charge the battery pack in an
environment with the proper ambient
temperature (5°C to 35°C).
･ Do not charge in the following places.
- Places that are very humid, dusty or exposed
to strong vibrations.
- Near ordinary phone or TV/radio.
･ The AC adapter cable could become
warm while charging. This condition is
not abnormal. You can continue using
the terminal.
･ When you use the power outlet with a
mechanism to prevent the plug from
being removed, follow the instructions
on the outlet's user's manual.
･ Do not give a strong impact to the
adapter. Also, do not bend or deform the
microUSB plug.
Doing so may cause malfunction.
■UIM precautions
･ Do not use unnecessary force to insert/
remove the UIM.
･ Do not insert and use the UIM with
another IC card reader/writer. Please
note that you are wholly liable for any
damage or malfunction as a result of
such action.
･ Always keep the IC portion clean when
you use the card.
･ Clean the terminal with a dry soft cloth
(such as used for cleaning eyeglasses).
･ Note down the information saved in the
UIM in a separate note and keep it
safely.
Under no condition will DOCOMO be held
liable for any damaged or lost data saved in the
terminal.
･ Take an expended UIM to sales outlet
such as docomo Shop for proper
disposal in order to protect the
environment.
･ Do not carelessly damage, contact, or
short-circuit an IC.
Doing so may cause data loss or malfunction.
･ Do not drop a UIM or subject it to
impact.
Doing so may cause malfunction.
･ Do not bend a UIM or place a heavy
object on it.
Doing so may cause malfunction.
Contents/Precautions
Continued on next page
21
･ Do not insert the UIM on which any label
or seal is stuck into the terminal.
Doing so may cause malfunction.
■Bluetooth function precautions
･ To secure the Bluetooth communication
security, the terminal supports the
security function compliant with
Bluetooth standards, but the security
may not be sufficient depending on the
setting.
Concern about the communication
using the Bluetooth function.
･ Please be aware that DOCOMO is not
responsible for data leak when making
data communications using Bluetooth.
･ You can use a headset, handsfree, and
audio profiles on the terminal. The audio/
video remote control may be available
for audio profile. (only compatible
Bluetooth devices)
･ Frequency band
The frequency band used by the terminal's
Bluetooth/wireless LAN function is indicated on
the battery storage section. The following are
the descriptions:
2.4: This radio equipment uses the 2400 MHz
band.
FH/DS/OF: Modulation scheme is the FH-SS,
DS-SS, or OFDM system.
1: The estimated interference distance is 10 m
or less.
4: The estimated interference distance is 40 m
or less.
8: The estimated interference distance is 80 m
or less.
: The full band between 2400 MHz
and 2483.5 MHz is used and the
band of the mobile identification
device can be avoided.
Available channels vary depending on the
country.
For use in an aircraft, contact the airline
beforehand.
･ Bluetooth cautions
The operating frequency band of the terminal is
used by industrial, scientific, consumer and
medical equipment including microwave
ovens, premises radio stations for identifying
mobile units used in the manufacturing lines of
plants (radio stations requiring a license),
specified low power radio stations (radio
stations requiring no license) and amateur
radio stations (hereinafter referred to as
"another station").
1. Before using the terminal, confirm that
"another station" is not being operated
nearby.
2. In the event of the terminal causing harmful
radio wave interference with "another
station", promptly change the operating
frequency or stop radio wave emission by
turning off the power, etc.
3. If you have further questions, contact
"General Inquiries" on the last page of this
manual.
Contents/Precautions
22
■Wireless LAN (WLAN) precautions
･ Wireless LAN (WLAN) exchanges
information using radio waves, and
allows you to freely establish LAN
connection if you are within an area
where radio wave reaches On the other
side, if you communicate without
appropriate security settings,
communications may be intercepted or
hacked by malicious parties. It is
recommended to make necessary
security settings on your responsibility
and expense.
･ Wireless LAN
Do not use wireless LAN near magnetic
devices such as electrical appliances or AV/OA
devices, or in radio waves.
- Magnetism or radio waves may increase
noises or disable communications
(especially when using a microwave oven).
- When used near TV, radio, etc., reception
interference may occur, or channels on the
TV screen may be disturbed.
- If there are multiple wireless LAN access
points nearby and the same channel is used,
search may not work correctly.
･ 2.4 GHz device cautions
The operating frequency band of the WLAN
device is used by industrial, scientific,
consumer and medical equipment including
home electric appliances such as microwave
ovens, premises radio stations for identifying
mobile units used in the manufacturing lines of
plants (radio stations requiring a license),
specified low power radio stations (radio
stations requiring no license) and amateur
radio stations (radio stations requiring a
license).
1. Before using the device, confirm that
premises radio stations for identifying
mobile units, specified low power radio
stations and amateur radio stations are not
being operated nearby.
2. If the device causes harmful radio
interference to premises radio stations for
identifying mobile units, immediately change
the frequency band or stop use, and contact
"General Inquiries" on the last page of this
manual for crosstalk avoidance, etc. (e.g.
partition setup).
3. If the device causes radio interference to
specified low power radio stations or
amateur radio stations, contact "General
Inquiries" on the last page of this manual.
Contents/Precautions
23
■Cautions
･ Do not use an altered terminal. Using an
altered device is a violation of the Radio
Law.
A "Technical Conformity Mark " affixed on
the manufacturer's specification sticker
certifies that the terminal meets technical
regulations for specified radio equipment that
are based on the Radio Law.
If you remove the screws and alter the inside of
the terminal, the technical regulations
conformity certification becomes invalid.
Do not use the terminal with the certification
invalid, as it is a violation of the Radio Law.
･ Be careful when using the terminal while
driving.
Using a handheld mobile phone while driving
will result in a penalty.
However, absolutely necessary cases such as
rescue of a sick person or maintaining public's
safety are exempted.
･ Do not change basic software
maliciously.
Repair may be refused due to modification of
the software.
Contents/Precautions
24
Part names and functions
Before Using the Handset
defghi
r
s
t
j
u
v
w
l nm
k
a microUSB connecting terminal
b Headset connector
c HDMI connector (type D)
d Notification LED
Notifies charging condition, missed call or unread
mail.
e Proximity sensor
Turns on or off the touch screen to prevent
erroneous operation during a call.
f Light sensor
Adjusts screen brightness. Do not cover it with
your fingers etc.
g Ear speaker
Allows you to hear the other party's voice etc.
during a call.
h Infrared port
Sends and receives data via infrared
communication.
o p q
x
y
z
A
B
i Frontcamera lens
j Display (Touch panel)
k x Back key
Returns to the previous screen.
l y Home key
Displays home screen.
m Microphone
Transmits your voice to the other caller.
n t Menu key
Displays menu according to the operating
conditions.
o Speaker
p Camera lens
q Second Microphone
Reduces noise to make easy to listen.
r GPS/Bluetooth
bc
a
C
£
/Wi-Fi antenna*
1
Before Using the Handset
Continued on next page
25
s p Power key/Screen lock key
Turns on/off power. Also, turns off the backlight
and sets key lock.
t Whip antenna
Extend it when watching TV (1Seg). It has no
influence on calls or data communication if you
extend the whip antenna when calling or using
browser.
u m Volume key/Zoom key
v k Camera key
Hold it down for at least one second to activate
Camera. Use it as a shutter to take photos or
movies.
w Built in antenna*
2
x microSD memory card slot
y FeliCa
TM
mark
Hold it over card reader/writer when using Osaifu-
£
Keitai
.
z Flash/Photo light
Lights to brighten an object when taking a
photograph.
A au IC-Card slot
B Charge terminal
C Strap hole
*1 Do not cover the antenna area with your hand
when using Wi-Fi, Bluetooth
£
or retrieve GPS
information.
*2 Do not cover the antenna area with your hand
during a call or when using the browser.
■Game keypad
Slide the game keypad to use the
following game buttons.
a Direction keys (move the cursor up/down/left/
right)
b Menu button
c Touch pad L
d Touch pad R
e Select button
f Start button
g × button
h ○ button
i △ button
j □ button
k R button
l L button
*
cdefijkl are dedicated buttons for
games. For details on how to use each button in
games, see the user's manual of each game.
* Operating, selecting setting items are available by
using the game keypad. Some items cannot be
operated or selected.
Before Using the Handset
26
UIM
Inserting UIM
The UIM is an IC card recorded user
information such as your phone number etc.
When the UIM is not inserted to the terminal,
you cannot use some functions (phone
function, etc.) of the terminal.
･ In this terminal, the UIM (blue) is not
available. If you have the UIM (blue), bring it
to the nearest docomo Shop to replace.
･ When inserting/removing the UIM, make
sure to power off the terminal and remove
the back cover. Do not connect the AC
Adapter cable.
■Security codes of the UIM
The UIM has a Security code, namely
PIN. It is set "0000" at the subscription.
They can be changed by yourself. (P.109)
Put your tips of the third and fourth
1
fingers (nails) into the groove, hold
the back cover up in the direction
of the arrow ( ) to remove.
Insert straight the UIM all the way
2
into the holder with the metal part
(IC) facing down.
･ Insert it with the corner cut back side.
Before Using the Handset
27
Removing UIM
Remove the back cover, press the
1
UIM with your fingertip and remove
it sliding outside.
❖Information
･ Please be careful not to touch or scratch a metal
part (IC) when you handle the UIM. Doing so may
cause malfunction or damage.
microSD card
❖Information
･ Make sure to attach the back cover before using.
The microSD card cannot be recognized if the
back cover is not attached.
･ Do not touch the back cover detect switch. It may
cause malfunction or damage.
Inserting microSD card
Remove the back cover (P.27).
1
Make sure the inserting direction
2
and insert straight the microSD
card all the way into the holder
untill it clicks.
･ Insert the microSD card with metal
contacts side down.
You can use microSD card for any other
compatible devices.
･ When a microSD card is not inserted,
camera functions, playing or downloading
music or videos, communications using the
Bluetooth function, etc. are not available.
･ The terminal supports microSD card of up to
2GB, and microSDHC card of up to 32GB
(As of October, 2011).
Before Using the Handset
28
Loading...
