Sony 70663E Users Manual

INSTRUCTION MANUAL

17.10

Introduction

Thank you for your purchase of "SO-05K".

For proper use, read this manual carefully before and while you use the SO-05K.

About manuals of SO-05K

●"クイックスタートガイド

(Supplied accessories)

Part names and functions are explained.

●

"Instruction Manual" (Application of the terminal)

Operations and settings of each function are explained. To use "Instruction Manual" application, from the Home screen, When using for the first time, download and install the application according to the onscreen instructions. You can use the application as an electronic book. You can also shift to actual operations by tapping the description in the contents or view reference contents.

If you uninstall "Instruction Manual" application, access Google Play from Play Store for installing it again. From the Home screen, tap [Play Store], search

取扱説明書

(Instruction Manual)" application to

" select, then operate it following the onscreen instructions.

(Quick Start Guide)"

[Instruction Manual].

●

"Instruction Manual" (PDF file)

Operations and settings of each function are exp lain ed. It can b e down load ed fro m NTT DOCOM O website. https://www.nttdocomo.co.jp/support/trouble/ manual/download/so05k/index.html

* The latest information can be downloaded. The

URL and contents are subject to change without prior notice.

❖

Note

･

Reproduction or reprint of all or part of this manual without prior permission is prohibited.

･

Important information for SO-05K is posted in the following website. Be sure to check before using. http://www.sonymobile.co.jp/support/ (In Japanese only)

Operation descriptions

In this manual, keys (P.30) and key icons (P.47) are described with And operations for selecting icons or items in the key operations on the screens are described as follows.

Press and hold

second. From the Home

screen,

[Display].

Touch and hold an icon.

❖

Information

･

Display examples and illustrations used in this manual are just images for explanations and may be different from actual screens or products.

･

In this manual, the easier procedure is described for the functions and settings which have multiple operating procedures.

･

Please note that "SO-05K" is called "the terminal" in this manual.

･

In this manual, explanations for the theme "Xperia™ Loops" are provided.

･

In this manual, explanations for "docomo LIVE UX" as Home application are provided (P.74). If you set the other home application, the operations may differ from the descriptions.

O, k

, , , .

Description Operation

Press and hold Camera key

for at least 1

[Settings]

(

) on the side of the

terminal for at least 1 second. From the Home screen, tap

(Apps button), and then tap

"Settings" on the next screen and "Display" on the following screen.

Keep touching an icon longer (12 seconds).

Supplied accessories

･

SO-05K

･

クイックスタートガイド

(In Japanese only)

(Quick Start Guide)

･

のご利用にあたっての注意事項

SO-05K

安全上／取り扱い上のご注意

(Notes on usage, Safety/Handling precautions) (In Japanese only)

･

TV antenna cable SO01

You can check or purchase optional accessories compatible with the terminal (optional) in the DOCOMO online shop. https://www.mydocomo.com/onlineshop/ options/index.html (In Japanese only)

Contents

■

Supplied accessories. . . . . . . . . . . . . . . . . 2

■

About using the terminal . . . . . . . . . . . . 5

■

Safety Precautions (Always follow these

directions) . . . . . . . . . . . . . . . . . . . . . . . . . . 7

■

Handling precautions. . . . . . . . . . . . . . . 18

■

Waterproofness/Dustproofness . . . . . 24

Before Using the Terminal . . . 30

Part names and functions................................................30

docomo nano UIM card....................................................31

microSD card ........................................................................... 35

CE mark and FCC ID.............................................................38

Charging..................................................................................... 38

Turning power on/off......................................................... 44

Initial settings........................................................................... 45

Basic operations.....................................................................46

Notification LED .....................................................................52

Status bar ................................................................................... 52

Notification panel .................................................................55

Quick settings panel............................................................56

Home screen............................................................................ 57

™

Application screen .......................................... 65

Xperia

Task manager...........................................................................73

Split screen................................................................................73

Switching Home application.........................................74

Searching information in the terminal and web

pages ............................................................................................75

Character entry.......................................................................76

Setting character entry...................................................... 82

docomo LIVE UX . . . . . . . . . . . . .83

Home screen ........................................................................... 83

Managing the Home screen.......................................... 83

Application screen ............................................................... 86

Display all apps....................................................................... 88

Backing up and restoring the Home screen........ 88

Using My Magazine............................................................. 89

Checking Home application information.............. 90

Phone . . . . . . . . . . . . . . . . . . . . . .91

Making/Receiving a call .................................................... 91

Operations during a call ................................................... 96

Call history................................................................................. 97

Call settings ........................................................................... 100

Phonebook ............................................................................ 104

Mail/Web browser . . . . . . . . . .110

docomo mail ........................................................................ 110

Message (SMS)..................................................................... 110

Email........................................................................................... 113

Gmail.......................................................................................... 117

Early Warning "Area Mail".............................................. 118

Chrome .................................................................................... 120

Apps. . . . . . . . . . . . . . . . . . . . . . .123

メニュー

(dmenu) ........................................................... 123

dmarket.................................................................................... 123

Play Store ................................................................................ 124

Osaifu-Keitai .......................................................................... 125

TV ................................................................................................. 130

Camera ..................................................................................... 136

Content s/Precautio ns

Album........................................................................................ 148

Music.......................................................................................... 150

Location services................................................................ 151

Schedule.................................................................................. 154

Clock........................................................................................... 155

docomo Data Copy .......................................................... 157

Settings . . . . . . . . . . . . . . . . . . . 160

Viewing the setting menu............................................ 160

Network & Internet............................................................ 160

Device connection............................................................170

Appearance ........................................................................... 171

Apps & notifications ......................................................... 171

Battery....................................................................................... 174

Display....................................................................................... 175

Sound ........................................................................................ 177

Storage...................................................................................... 180

Lock screen & security..................................................... 181

docomo service/cloud.................................................... 189

Users & accounts ................................................................ 190

Assist .......................................................................................... 192

Accessibility ........................................................................... 193

Google ...................................................................................... 195

System....................................................................................... 195

File management . . . . . . . . . . 199

Storage structure................................................................ 199

File operations...................................................................... 199

Data communication . . . . . . . 201

Bluetooth function............................................................ 201

NFC communication........................................................ 203

External device connection. .206

Connecting to PC .............................................................. 206

Connecting DLNA device............................................. 207

International roaming . . . . . .208

Overview of International roaming (WORLD

WING) ........................................................................................ 208

Available overseas service ............................................ 208

Before using overseas ..................................................... 209

Making/Receiving a call in the country you stay

....................................................................................................... 212

International roaming settings.................................. 214

After returning to Japan ................................................ 216

Appendix/Index . . . . . . . . . . . .217

Troubleshooting................................................................. 217

あんしん遠隔サポート

....................................................................................................... 225

Warranty and After Sales Services ........................... 226

Software Update ................................................................ 230

Connecting to a PC to update................................... 233

Main specification ............................................................. 234

Certificate and compliance ......................................... 239

End User Licence Agreement .................................... 239

Export Controls and Regulations ............................. 240

Intellectual Property Right ........................................... 241

SIM unlock.............................................................................. 244

Index .......................................................................................... 245

(Anshin Enkaku Support)

Content s/Precautio ns

Contents/Precautions

About using the terminal

･

The terminal supports LTE, W-CDMA, GSM/ GPRS and Wireless LAN Systems.

･

Because a terminal operates using radio frequencies, it cannot be used inside a tunnel, underground, in a building or other locations where radio waves do not reach, in locations with weak radio wave condition, or out of LTE/ FOMA service area. The services may not be available on the upper floors of high-rise apartments or buildings, even if there are no obstructions around you. On occasion, your calls may be disconnected even in areas with strong radio wave condition, even if you are not moving, or even if there are 4-signal icon on the terminal's display.

･

Because the terminal uses radio waves to communicate, it is possible that a third party may attempt to tap your calls. However, the LTE, W-CDMA, GSM/GPRS system automatically scrambles all calls through a private call feature. Therefore, even if the third party successfully intercepts your call, they will only hear noise.

･

The terminal operates on radio frequencies by converting voice into digital signals. If the caller moves into an area of adverse radio wave condition, the digital signal may not be restored accurately, and the voice received in the call may differ slightly from the actual voice.

･

The terminal supports function that can be used by users and guests. Therefore some services or applications recognize them as the same user even after the user is switched. DOCOMO shall have no liabilities for any damage or troubles of customer or a third party resulting from using the function (P.190).

･

Note down the information saved in the terminal in a separate note on a regular basis or save to an external recording medium such as a microSD card or PC. Note that DOCOMO assumes no responsibility for any loss of saved contents of data resulting from malfunction, repair, changing of the model or other handling of the terminal.

･

As with PCs, some user-installed applications or accessed websites may disrupt the stability of the terminal performance, or unexpectedly transmit information via the Internet causing improper use of your location information as well as personal information recorded on the terminal. Therefore, verify the supplier and operating conditions of the applications or websites before using them.

･

This terminal has FOMA Plus-Area and FOMA HIGH-SPEED Area support.

Content s/Precautio ns

･

The terminal automatically performs communication for synchronizing data, checking the latest software version, and maintaining a connection with the server, and for other purposes. If you transmit a large amount of data, such as when downloading applications or watching video, a packet communication charge becomes high. Subscription to Packet Pack/packet flat-rate service is highly recommended.

･

Depending on the applications or service you use, packet communication charge may be applied even in Wi-Fi

･

Public mode (Driving mode) is not supported.

･

To check the software version, from the Home screen,

communication.

[Settings]u[System]u[About

phone].

･

If available memory in the microSD card or the terminal is low, running applications may not operate correctly. In that case, delete the saved data.

･

You can update software on the terminal to the latest one (P.230, P.233).

･

The operating system (OS) may be upgraded via software updates to improve the quality of the terminal. For this reason, you always need to use the latest OS version. And some applications that used in the previous OS version may not be available or some unintended bugs may occur.

･

You can use the terminal only with a docomo nano UIM card. If you have a docomo mini UIM card, UIM, or FOMA card, bring it to a docomo Shop to replace it with a docomo nano UIM card.

･

Set password etc. for screen lock to ensure the security of your terminal for its loss (P.185).

･

If your terminal is lost, change your each account password to invalidate authentication using a PC to prevent other persons from using Google services such as Gmail or Google Play, or SNS, etc.

･

For using services and applications provided by the third party's including the applications provided by Google Inc., confirm the terms and conditions specified by Google or the providers. DOCOMO assumes no responsibility for any malfunctions resulting from the services and applications.

･

When a license agreement screen etc. appears, follow the onscreen instructions.

･

Applications and service contents are subject to change without prior notice.

･

The terminal supports only sp-mode, mopera U and Business mopera Internet. Other providers are not supported.

･

If you want to use tethering, subscription to Packet Pack/packet flat-rate service is strongly recommended.

･

For details on usage charge, refer to NTT DOCOMO website.

Content s/Precautio ns

･

Display is manufactured by taking advantage of highly advanced technology but some dots may be always or never lit. Note that, this shows characteristics of the display and not defects in the terminals.

･

DOCOMO is not liable to any failures or malfunctions for commercially available optional equipment.

Safety Precautions (Always follow these directions)

■

For safe and proper use of the terminal, plea se read the "Safety Precautions" prior to use.

■

ALWAYS observe the safety precautions since they intend to prevent personal injury or property damage.

■

The following symbols indicate the different levels of injury or damage that may result if the guidelines are not observed and the terminal is used improperly.

Failu re to observe these guidelines may

DANGER

WARNING

CAUTION

"immediately result in death or serious

(*1)

injury

Failu re to observe these guidelines may "result in death or serious

(*1)

injury

Failu re to observe these guidelines may "result in minor

(*2)

injury

and

property

(*3)

damage

Content s/Precautio ns

*1 Serious injury: This refers to loss of sight, injury,

burns (high- and low- temperature), electric shock, broken bones, injuries with residual aftereffects from poisoning, etc., and injuries requiring hospital admission for treatment or long-term hospital attendance as an outpatient.

*2 Minor injury: This refers to injuries, burns (high- and

low-temperature), electric shock, etc. that do not require hospital admission for treatment or longterm hospital attendance as an outpatient.

*3 Property damage: This refers to extended damage

to buildings, furniture, livestock, pets, etc.

■

The following symbols indicate specific directions.

■

"Safety Precautions" are described in the following categories:

1. Handling the terminal, adapter, docomo nano UIM card, and TV antenna cable (common) . . .8

2. Handling the terminal. . . . . . . . . . . . . . . . . . . . . . 11

3. Handling the adapter . . . . . . . . . . . . . . . . . . . . . . 14

4. Handling the docomo nano UIM card. . . . . . . 15

5. Handling the terminal near electronic medical

equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

6. Material list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

1. Handling the terminal, adapter, docomo nano UIM card, and TV antenna cable (common)

Indicates prohibited actions.

Don’t

Indicates not to disassemble.

No disassembly

Indicates not to use where it could get wet.

No liquids

Indicates not to handle with wet hands.

No wet hands

Indicates compulsory actions in accordance with instructions.

Indicates to remove the power plug from the outlet.

Unplug

DANGER

Do not use, store or leave the equipment in locations subject to high temperature or

Don’t

accumulation of heat (e.g. by the fire, near a heater, under a kotatsu or bedding, in direct sunlight, in a car in the hot sun).

Doing so may cause fire, burns, injury, electric shock, etc.

Do not put the equipment in or place near microwave ovens, cooking appliances such

Don’t

as IH cooking heaters, or high pressure containers such as pressure cookers.

Doing so may cause fire, burns, injury, electric shock, etc.

Content s/Precautio ns

Do not splash sand, soil or mud, or do not directly place the equipment on them. Also,

Don’t

do not touch the equipment with hands with sand etc. adhered.

Doing so may cause fire, burns, injury, electric shock, etc. For waterproofness/dustproofness, see the following.

⇒

P.24 "Waterproofness/Dustproofness"

Do not charge the terminal when it is wet with liquids such as water (drinking water,

Don’t

sweat, seawater, urine of pet animals, etc.).

Doing so may cause fire, burns, injury, electric shock, etc. For waterproofness, see the following.

⇒

P.24 "Waterproofness/Dustproofness"

Do not subject the terminal to strong pressure or break the terminal. Especially

Don’t

when bringing the terminal putting in a pocket of clothes, do not let the terminal hit against surroundings or being put between the objects.

Doing so may cause fire, burns, injury, etc. because of damage of the internal battery. * The following are examples that you should

be careful of:

・

Sitting or squatting with the terminal put in a pocket of trousers or skirt

・

Putting the terminal in a pocket of outer wear and catching them in a door or a door of car

・

Stepping on the terminal on a soft object such as a sofa, bed, or bedding, or on a floor

Do not disassemble or modify the equipment.

No disassembly

Doing so may cause fire, burns, injury, electric shock, etc.

Do not let the equipment get wet with liquids such as water (drinking water, sweat,

No liquids

seawater, urine of pet animals, etc.).

Doing so may cause fire, burns, injury, electric shock, etc. For waterproofness, see the following.

⇒

P.24 "Waterproofness/Dustproofness"

Do not allow liquids such as water (drinking water, sweat, seawater, urine of pet animals,

No liquids

etc.) to get inside of the charging jack or the external connection jack.

Doing so may cause fire, burns, injury, electric shock, etc. For waterproofness, see the following.

⇒

P.24 "Waterproofness/Dustproofness"

Use optional devices specified by NTT DOCOMO.

Using a device other than specified may cause fire, burns, electric shock, etc.

WARNING

Do not subject the equipment to strong force, impacts, or vibration such as letting it

Don’t

fail, stomping or throwing it.

Doing so may cause fire, burns, injury, electric shock, etc.

Do not allow conductive materials (such as metal objects and pencil lead) to come into

Don’t

contact with the charging jack or external connection jack or dust to get inside it.

Doing so may cause fire, burns, injury, electric shock, etc.

Do not cover or wrap the equipment with a cloth or bedding in use or while charging.

Don’t

Doing so may cause fire, burns, etc.

Content s/Precautio ns

If charging does not finish after specified time, stop charging.

Failure to do so may cause fire, burns, injury, etc. due to overcharge etc.

Power off the terminal before you step into a place where flammable gas generates such

as gas stations, or a place where dusts are generated. Stop charging if you charge the battery.

Using the terminal in a place where flammable gas generates may cause explosion, fire, etc. When using Osaifu-Keitai in a place such as a gas station, power off the terminal before using it. (If you set "NFC / Osaifu-Keitai lock", cancel the lock and then power off the terminal.)

If you notice anything unusual about the equipment such as an unusual odor,

abnormal noise, smoke generation, overheating, discoloration or deformation while using or charging, or during storage, perform the following measures.

・

Remove a power plug from a power outlet or accessory socket.

・

Power off the terminal. Failure to do so may cause fire, burns, injury, electric shock, etc. if you do not follow the instructions above.

CAUTION

Do not use damaged equipment.

Doing so may cause fire, burns, injury, etc.

Don’t

Do not place on an unstable or inclined platform. Be careful especially when vibrator

Don’t

is set.

Doing so may cause the device to fall etc. and cause injury.

Do not use or keep in a place that is very humid, dusty, or subject to high

Don’t

temperature.

Doing so may cause fire, burns, electric shock, etc. For waterproofness/dustproofness, see the following.

⇒

P.24 "Waterproofness/Dustproofness"

If children use the terminal, parents or guardians should give them the proper

Don’t

instructions for use and do not allow them to use the terminal in the wrong way.

Failure to do so may cause injury.

Keep the equipment out of the reach of babies and infants.

Don’t

Doing so may cause accidental ingestion, injury, electric shock etc.

Content s/Precautio ns

Be careful when using the terminal continuously for a long time or charging

because temperature of the terminal may become warm. Also, be careful not to touch it unintentionally for a long time when you fall asleep etc.

The terminal or adapter may become warm when using applications, calling, performing data communication, watching TV or video, etc. for a long time or charging. If you are directly in c ontact with warmed part for a long time, it may cause a redness of skin, itch, rash, low-temperature burn etc. depending on your physical condition.

2. Handling the terminal

DANGER

Do not throw the terminal into fire or apply heat.

Don’t

Doing so may cause fire, burns, injury, etc.

Do not put excessive force such as sticking a nail (sharp object) into the terminal, hitting

Don’t

it with a hammer (hard object), or stepping on it.

Doing so may cause fire, burns, injury, etc.

If the internal substance etc. of the terminal contacts your eyes, immediately rinse your

eyes with clean water and see a doctor right away.

Failure to do so may cause blindness, medical problem, etc. due to effects of the internal substance of the terminal etc.

WARNING

Do not turn on the light or flash with the lighting luminescence part close to the

Don’t

other people's eyes. Keep enough distance away especially from babies and infants.

Doing so may cause blurred vision etc. Or it may dazzle his/her eyes or scare him/her causing an accident such as injury.

Do not turn on or flash the light toward a driver of a car etc.

Don’t

Doing so may disturb driving and cause an accident etc.

Do not watch a repeatedly-blinking screen for a long time.

Don’t

Doing so may cause cramp, loss of consciousness, etc.

Do not allow a foreign substance such as water and other liquids (drinking water,

Don’t

sweat, seawaer, urine of pet animals, etc.), metal parts, or flammables to get in the docomo nano UIM card/microSD card slot on the terminal. Do not insert the docomo nano UIM card or a microSD card into wrong slot, or insert it in wrong orientation.

Doing so may cause fire, burns, injury, electric shock, etc.

Do not expose the camera lens to direct sunlight for an extended period.

Don’t

Doing so may cause fire, burns, injury, etc. by the light-collecting mechanism of the lens.

Content s/Precautio ns

Power off the terminal or put it in Airplane mode before boarding an airplane.

Use of mobile phones on board is restricted. Follow the instructions of each airline. The radio wave from the terminal may adversely affect on-board electronic equipment. Prohibited acts related to mobile phone usage on an airplane may be punished by law.

Follow the instructions of each medical facility for the use of mobile phones on their

premises.

Power off the terminal in a place where the use is prohibited. The radio wave from the terminal may affect electronic equipment and electronic medical equipment.

Always keep the terminal away from your ear when you talk with hands-free set, while

the ringtone is loudly sounding, or in standby mode. Also, when you play game, play back videos or music, etc. connecting the earphone/ microphone, etc. to the terminal, adjust the volume adequately.

Loud sound is emitted from the terminal when calling with hands-free set. Even in standby mode, a ringtone or an alarm sound may sound suddenly. Listening to loud sound for long hours continuously may cause a disability of ears such as deafness. Moreover, too loud sound makes you to barely hear the surrounding sounds and may cause an accident.

If you have a weak heart, set the vibrator or ringtone volume carefully.

Sudden vibration or ringtone sounding when incoming call astonishes you and it may affect your heart.

If you are wearing any electronic medical equipment, check with the relevant medical

electronic equipment manufacturer or vendor whether the operation may be affected by radio waves.

The radio waves from the terminal may affect the electronic medical equipment.

Power off the terminal near electronic devices or equipment operating on high

precision control or weak signals.

The radio wave from the terminal may interfere with the operation of electronic devices or equipment. * The following are some electronic devices

or equipment that you should be careful of: Hearing aids, implantable cardiac pacemaker, implantable cardioverter defibrillator, other electronic medical equipment, and other automatically controlled devices or equipment. If you use an implantable cardiac pacemaker, implantable cardioverter defibrillator, or other electronic medical equipment, check with the medical electronic equipment manufacturer or vendor whether the operation can be affected by radio waves.

Be careful about broken glasses or exposed internal part of the terminal if the display or

the camera lens is broken.

Touching damaged or exposed area may cause burns, injury, electric shock, etc.

Content s/Precautio ns

If the internal battery leaks or gives off a strange smell, immediately remove it from

the vicinity of open flames.

The leaking liquid may ignite fire, catch fire, explode etc.

Be careful not to allow a pet etc. to bite the terminal.

Doing so may cause fire, burns, injury, etc. because of damage of the internal battery.

CAUTION

When using the motion sensor, check the safety around you, hold the terminal firmly,

Don’t

and do not shake it unnecessarily.

Failure to do so may cause accident such as injuries.

If the internal substance is leaked due to damage of the display, do not get it on your

Don’t

skin such as face, hands, or cloths etc.

Doing so may cause injury etc. on y our eyes or skin. If the internal substance etc. gets into your eyes or mouth, or contacts skin or clothes, immediately rinse the contacted area with clean water. If the substance gets into the eyes or mouth, immediately see a doctor after rinsing.

Do not dispose of the terminal together with usual trash.

Don’t

Doing so may cause fire, burns, injury, etc. Also, it may cause environmental destruction. Bring the unnecessary terminal into a sales outlet such as docomo Shop. If your local municipality has a battery recycling program, dispose of them as provided for.

If the substance etc. leaks out from the internal battery, do not make it contact with

Don’t

your skin of face or hands, cloths, etc.

Doing so may cause injury etc. on y our eyes or skin. If the internal substance etc. gets into your eyes or mouth, or contacts skin or clothes, immediately rinse the contacted area with clean water. If the substance gets into your eyes or mouth, immediately see a doctor after rinsing.

To use the terminal in car, check with automobile manufacturer or dealer to

determine how the device is affected by radio waves before using.

In rare cases, the radio wave from the terminal may affect the vehicle's electronic equipment in some vehicle models. In that case, stop using the terminal immediately.

If abnormalities on skin are developed by using the terminal, immediately stop using

and take medical treatment. The use of the terminal may cause itching, rashes, eczema, or other symptoms depending on the user's physical condition.

For material of each part, see the following.

⇒

P. 1 7 " Ma te ri a l li st "

Make sure not to get metal objects (blade of cutter, staples, etc.) adhered because

magnetic parts are used on the earpiece/ speaker, or speaker of the terminal.

Such adhered objects may cause injury etc.

Watch the display in an adequately bright place taking a certain distance from it.

Watching in a dark place or closely may reduce visual acuity etc.

Content s/Precautio ns

3. Handling the adapter

WARNING

Do not use the adapter cord if it gets damaged.

Don’t

Doing so may cause fire, burns, electric shock, etc.

Do not use the adapter in a humid place, such as a bathroom.

Don’t

Doing so may cause fire, burns, electric shock, etc.

DC adapter is only for a negative ground vehicle. Do not use DC adapter for a positive

Don’t

ground vehicle.

Doing so may cause fire, burns, electric shock, etc.

Do not touch the adapter if you hear thunder.

Don’t

Doing so may cause electric shock etc.

Do not short-circuit the charging jack while it is connected to a power outlet or

Don’t

accessory socket. Do not touch the charging jack with your hands, fingers, or any part of your body.

Doing so may cause fire, burns, electric shock, etc.

Do not place heavy objects on the adapter cord, or do not apply unnecessary force such

Don’t

as pulling etc.

Doing so may cause fire, burns, electric shock, etc.

When you insert/remove a plug of AC adapter to/from power outlet, do not let it to

Don’t

contact with metal objects.

Doing so may cause fire, burns, electric shock, etc.

Do not connect the voltage converter for overseas travel (travel converter) to the AC

Don’t

adapter.

Doing so may cause ignition, overheating, electric shock etc.

Do not put an excessive force to the connection part with the adapter connected

Don’t

to the terminal.

Doing so may cause fire, burns, injury, electric shock, etc.

Do not touch the adapter cord, charging jack or power plug with wet hands.

No wet hands

Doing so may cause fire, burns, electric shock, etc.

Use the adapter only on the specified power supply and voltage.

When charging the terminal overseas, use AC adapter for global use.

Using the incorrect power supply and voltage may cause fire, burns, electric shock, etc. AC adapter : 100V AC (Make sure to connect the adapter to a household AC power outlet.) AC adapter for global use : 100V to 240V AC (Make sure to connect the adapter to a household AC power outlet.) DC adapter : 12V or 24V DC (only for a negative-ground vehicle)

Content s/Precautio ns

When replacing a fuse in a DC adapter, make sure to use the specified fuse.

Using a fuse other than specified may cause fire, burns, electric shock, etc. For the specified fuse, check a manual that comes with a DC adapter.

Clean dust from the power plug.

Using it with dust adhering may cause fire,

burns or electric shock.

When you connect the adapter or accessory socket to a power outlet, insert it firmly.

Insecure inserting may cause fire, burns, electric shock, etc.

When you disconnect the power plug from an outlet or accessory socket, do not apply

excessive force it such as pulling the cord of the adapter. Instead, hold the adapter to disconnect.

Pulling the cord may damage the cord and it may cause fire, burns, electric shock, etc.

When plugging/unplugging an adapter into/from the terminal, plug/unplug the

adapter straightly toward the jack without applying excessive force such as pulling the cord etc.

Incorrect plugging/unplugging may cause fire, burns, injury, electric shock, etc.

If the charging terminal is deformed such as being bent etc., stop using immediately. Do

not use it with the deformation restored.

Doing so may cause fire, burns, injury, etc. due to short-circuit of charging terminal.

Always remove the power plug of adapter from an outlet or accessory socket when not

Unplug

using it.

Keeping with connected to the power plug may cause fire, burns, electric shock, etc.

Immediately remove the power plug from an outl et or access ory socket if liquid such as

Unplug

water (drinking water, sweat, seawater, uri ne of pet animals, etc.) is adhered.

Failure to do so may cause fire, burns, injury, etc. due to shor t-circuit from the adhered substance.

Before cleaning, remove the power plug from a power outlet or accessory socket.

Unplug

Failure to do so may cause fire, burns, electric shock, etc.

CAUTION

Do not touch the adapter for a long time when it is connected to a power outlet or

Don’t

accessory socket.

Doing so may cause a burn etc.

4. Handling the docomo nano UIM card

CAUTION

Be careful of the cut surface not to hurt your body parts such as fingers when handling

docomo nano UIM card.

The cut surface may be sharp and it may cause injury etc.

Content s/Precautio ns

5. Handling the terminal near electronic medical equipment

WARNING

If you use an implantable cardiac pacemaker or implantable cardioverter defibrillator,

keep the terminal 15 cm or more away from the implant at all times.

The radio waves from the terminal may affect the performance of electronic medical equipment.

If you need to use electronic medical equipment other than implantable cardiac

pacemaker or implantable cardioverter defibrillator outside medical facilities such as treating at home, check with the relevant medical electronic equipment manufacturer whether the operation may be affected by radio waves.

The radio waves from the terminal may affect the performance of electronic medical equipment.

When you get close to other people within 15 cm just like not having enough space to

turn around, set the radio wave of the terminal to OFF beforehand ( Airplane mode, to Power off, etc.).

A person in close proximity may put on implanted a medical electrical equipment such as pacemakers and ICDs. The radio waves from the terminal may affect the performance of electronic medical equipment.

Follow the instructions of each medical facility for the use of the terminal on their

premises.

The radio waves from the terminal may affect the performance of electronic medical equipment.

Content s/Precautio ns

6. Material list

Part Material

Exterior case (Volume key, Camera key, cover of docomo nano UIM card/ microSD card slot)

Exterior case (top part, bottom part)

Exterior case (Antenna slit)

Exterior case (headset jack)

Transparent plate (Display, Camera lens)

Transparent plate (Flash/ Photo light, Laser AF sensor, RGBC-IR sensor,

mark)

Camera ring (back side) Stainless steel PVD Power key IC + Epoxy

Earpiece/speaker (upper) panel, speaker (lower) panel

Waterproof rubber of the cover of docomo nano UIM card/microSD card slot

Aluminum alloy

Polycarbonate resin

PBT resin (with glass fiber)

Nylon resin (with glass fiber)

Hardened glass AFP

Polycarbonate resin + Acrylic resin combined materials

resin Polyester resin Dyei ng

Silicon rubber

Surface

treatment

Alumite treatment

Coating

―

treatment Hard

coating treatment

Coating + Printi ng

―

Part Material

Tray of microSD card, Tray of docomo nano UIM card

TV antenna cable : headset jack (top surface), connector plug (top surface)

TV antenna cable : headset jack (body), connector plug (body), cable

TV antenna cable : connector plug (metal part)

Surface

treatment

Polyacetal resin

Polypropylene resin

Elastomer resin

Brass Gold

―

plating treatment

Content s/Precautio ns

Handling precautions

■

Common precautions

･

SO-05K is waterproof/dustproof; however, do not allow liquids such as water (drinking water, sweat, seawater, urine of pet animals, etc.) or foreign objects such as dust to enter inside of the terminal or adhere to accessories or optional devices.

The adapter, the docomo nano UIM card, and the TV antenna cable are not waterproof/dustproof. Do not use in a bathroom or other highly humid area or do not let rain touch. Or putting them on your body, humidity of sweat may cause internal corrosion and malfunction. Malfunctions which are determined to be caused by water as result of inspections are not covered by the warranty. For repairs, contact "Repairs (Inquiries/Request)" on the last page (in Japanese only) or DOCOMOspecified repair office.

･

Waterproofness/dustproofness may not be maintained if the terminal has abnormity in appearance such as damage or deformation. In this case, contact "Repairs (Inquiries/Request)" on the last page of this manual (in Japanese only).

･

Clean the terminal with a dry soft cloth (such as used for cleaning eyeglasses).

- Rubbing roughly may scratch the display.

- Drops of water or dirt left on the display may cause stains.

- Do not use alcohol, thinner, benzine, cleaning detergent, etc. to clean the terminal. These chemicals may erase the printing on the terminal or cause discoloration.

･

Clean the jacks or the fingerprint sensor occasionally and use the terminal in a clean state.

If the jack etc. is dirt, you may not use the terminal normally. When cleaning, be careful not to damage the jack etc.

･

Do not leave the terminal near the air conditioning vent.

Extreme temperature changes may produce condensation and corrode the internal parts of the terminal, causing the terminal to malfunction.

･

Make sure to use the terminal without excessive force.

Putting the terminal in a bag full of items or sitting down with the terminal in a pocket of clothes may cause malfunction or damage of the display, internal circuit board, internal battery, etc. Also, doing so while the external device is connected to the external connection jack may cause malfunction or damage.

Content s/Precautio ns

･

Use the optional devices specified by NTT DOCOMO.

Failure to do so may cause a malfunction or damage.

･

Read the user's manual supplied with each optional device.

･

Do not drop the terminal or give a strong impact to the terminal.

Doing so may cause a malfunction or damage.

■

The terminal precautions

･

Do not press the display strongly, or not operate with a sharp-pointed objects.

The display may get scratched and it may cause a malfunction or damage.

･

Do not use the terminal in extremely hot or cold places.

Use the terminal where the temperature ranges

℃

between 5 use in a bathroom etc. when temperature is

above 36℃) and humidity ranges between 45% and 85%.

･

Using the terminal near a land-line

and 40℃ (limited to the temporary

phone, television or radio may cause interference in such electric appliance.

･

Back up data that you saved to the terminal to a microSD card, a PC, or cloud, etc., or note down in a separate note and keep it safely.

NTT DOCOMO is not liable for any loss of data saved in the terminal.

･

Do not insert the plug of external device to the external connection jack at a slant when connecting. Or, do not pull the plug when they are connected.

Doing so may cause a malfunction or damage.

･

It is not abnormal if the terminal becomes warm while in use and charging. You can continue using the terminal.

･

Do not expose the camera lens under direct sunlight.

If you do so, some of the elements may melt or become faded.

･

Usually, keep the cover of docomo na no UIM card/microSD card slot closed during use.

Failure to do so may allow liquids such as water (drinking water, sweat, seawater, urine of pet animals, etc.) or foreign objects such as dust to enter inside and cause a malfunction.

･

Do not subject the fingerprint sensor to strong impact or scratch it.

Doing so not only may cause a malfunction of the fingerprint sensor, but authentication may become unavailable.

･

While microSD card is being used, do not take the card out and do not turn off the terminal.

Doing so may cause data loss or malfunction.

Content s/Precautio ns

･

Keep off a magnetic card or a magnetic object from the terminal.

The magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may be erased. Also, strong magnetic objects may cause a malfunction of the terminal.

･

Do not decorate the terminal with a film or stickers.

Doing so may hinder the proper operations for functions using the proximity. For a location of proximity, see the following.

⇒

P.30 "Part names and functions"

･

The internal battery is out of the warranty due to a consumable part.

The internal battery may become swelled toward the end of battery life depending on usage condition of the internal battery. Replace the internal battery if the usable time is extremely shortened even in a full charge or when the internal battery is swollen. For replacing internal battery, contact "Repairs (Inquiries/Request)" on the l ast page (in Japanese only) or DOCOMO-specified repair office.

･

Charge the battery in an environment with the proper ambient temperature

℃

to 35℃).

･

The operating time of the internal battery varies depending on the operating environment and the degradation level of the internal battery.

･

To store the terminal, avoid the following conditions so as not to degrade the performance or the battery life of the internal battery.

- The battery is fully charged (immediately after the charging is complete)

- The battery has run out (the terminal cannot power on)

The appropriate battery level for storing is about 40%.

･

Type of internal battery for the terminal is as follows.

Display Type of Battery

Li-ion 00 Lithium Ion Battery

■

Adapter precautions

･

Charge the battery in an environment with the proper ambient temperature

℃

to 35℃).

･

Do not charge in the following places.

- Places that are very humid, dusty or exposed to strong vibrations

- Near land-line phone or TV/radio

･

The adapter may become hot during charging. This condition is not abnormal. You can continue using the terminal.

･

When using the DC adapter for charging, do not turn off the vehicle engine.

Doing so may cause the exhaustion of vehicle battery.

Content s/Precautio ns

･

When you use the power outlet with a mechanism to prevent the plug from being removed, follow the instructions on the outlet's user's manual.

･

Do not subject the equipment to a strong impact. Do not deform the charging jack.

Doing so may cause malfunction.

■

docomo nano UIM card precautions

･

Do not use unnecessary force to insert/ remove the docomo nano UIM card.

･

Note that DOCOMO assumes no responsibility for any malfunctions resulting from inserting the docomo nano UIM card into another IC card reader/writer and using it.

･

Clean the IC part occasionally and use it in a clean state.

If the IC is dirt, it may not be used properly.

･

Clean the terminal with a dry soft cloth (such as used for cleaning eyeglasses).

･

Back up data that you saved to the docomo nano UIM card to a microSD card, a PC, or cloud, etc., or note down in a separate note and keep it safely.

NTT DOCOMO is not liable for any loss of data saved in the terminal.

･

Take an expended docomo nano UIM card to a sales outlet such as docomo Shop for proper disposal in order to protect the environment.

･

Do not carelessly damage, contact, or short-circuit an IC.

Doing so may cause data loss or malfunction.

･

Do not drop a docomo nano UIM card or subject it to impact.

Doing so may cause malfunction.

･

Do not bend a docomo nano UIM card or place a heavy object on it.

Doing so may cause malfunction.

･

Do not insert a docomo nano UIM card into the terminal if a label or seal is attached to the card.

Doing so may cause malfunction.

■

Bluetooth® function precautions

･

To secure the Bluetooth communication security, the terminal supports the security function compliant with Bluetooth standards, but the security may not be sufficient depending on the setting. Be aware of security risks when using Bluetooth.

･

Please be aware that DOCOMO is not responsible for any data leakage that might occur when communicating data via Bluetooth.

Content s/Precautio ns

･

Frequency band

The frequency band used by the terminals Bluetooth/wireless LAN function is written as follows:

2.4 : This radio equipment uses the 2400 MHz band.

Modulation scheme is the

FH/XX/DS/OF

4 : The estimated interference distance is 40

8 : The estimated interference distance is 80

Available channels vary depending on the country. For use in an aircraft, contact the airline beforehand.

･

Bluetooth cautions

The operating frequency band of the terminal is used by industrial, scientific, consumer and medical equipment including microwave ovens, premises radio stations for identifying mobile units used in the manufacturing lines of plants (radio stations requiring a license), specified low power radio stations (radio stations requiring no license) and amateur radio stations (hereinafter referred to as "another station").

：

FH-SS, other system, DS-SS, or OFDM system.

m or less.

: The full band between 2400 MHz

and 2483.5 MHz is used and the band of the mobile identification device can be avoided.

- Before using this equipment, confirm that "another station" is not being operated nearby.

- In the event of the terminal causing harmful radio wave interference with "another station", promptly change the operating frequency or stop radio wave emission by turning off the power, etc.

- If you have further questions, contact "General Inquiries" on the last page.

■

Wireless LAN (WLAN) precautions

･

Wireless LAN (WLAN) exchanges information using radio waves, and allows you to freely establish LAN connection if you are within an area where radio waves reach. However, without appropriate security settings, communications may be intercepted or hacked by malicious parties. It is recommended to configure necessary security settings on your own judgment and responsibility.

･

Wireless LAN

Do not use wireless LAN near magnetic devices such as electrical appliances or AV/OA devices, or in radio waves.

- Magnetism or radio waves may increase noises or disable communications (especially when using a microwave oven).

- When used near TV, radio, etc., reception interference may occur, or channels on the TV screen may be disturbed.

- If there are multiple wireless LAN access points nearby and the same channel is used, search may not work correctly.

Content s/Precautio ns

･

2.4GHz device cautions

The operating frequency band of the WLAN device is used by industrial, scientific, consumer and medical equipment including home electric appliances such as microwave ovens, premises radio stations for identifying mobile units used in the manufacturing lines of plants (radio stations requiring a license), specified low power radio stations (radio stations requiring no license) and amateur radio stations (radio stations requiring a license).

- Before using the device, confirm that premises radio stations for identifying mobile units, specified low power radio stations and amateur radio stations are not being operated nearby.

- If the device causes harmful radio interference to premises radio stations for identifying mobile units, immediately change the frequency band or stop use, and contact "General Inquiries" on the last page for crosstalk avoidance, etc. (e.g. partition setup).

- If the device causes radio interference to specified low power radio stations or amateur radio stations, contact "General Inquiries" on the last page.

･

5GHz device cautions

The terminal can use 3 frequency bands of

5.2GHz band (W52), 5.3GHz band (W53), 5.6 GHz

band (W56).

- 5.2GHz band (W52/36, 40, 44, 48 ch)

- 5.3GHz band (W53/52, 56, 60, 64 ch)

- 5.6GHz band (W56/100, 104, 108, 1 12, 116, 120, 124, 128, 132, 136, 140 ch)

Using wireless LAN built-into the terminal in 5.2/

5.3 GHz outside is prohibited by the Radio Law.

■

FeliCa® and NFC reader/writer function precautions

･

FeliCa and NFC reader/writer or P2P function of the terminal has the type designation of Inductive Reader/Writer Communication Equipment stipulated in the Radio Law.

They use 13.56 MHz frequency band. When the other FeliCa or NFC reader/writer, P2P function is used in the surroundings, keep the terminal away sufficiently from them. Before using, confirm that there are no radio stations using the same frequency band nearby. For use in an aircraft, contact the airline beforehand. Some countries may restrict the use of the function. Check the regulations of the country/region before using it. The type designation can be checked in the terminal. From the Home screen,

[System]u[About phone]u[Certificates].

■

Available radio frequencies

GSM/GPRS/EDGE 850, 900, 1800, 1900MHz. UMTS 2100 (Band I), 850 (Band V), 800 (Band VI), 800 (Band XIX)MHz. LTE (Bands 1, 3, 4, 5, 7, 12, 13, 17 , 19, 21, 28, 38, 39, 40, 41, 42). WLAN 2.4G/5G, NFC

GSM 850/900 : Power Class 4, DCS (1800)/ PCS (1900) : Power Class 1, UMTS : Power Class 3, LTE : Power Class 3,

[Settings]

Content s/Precautio ns

2.4GHz<100mW, 5.15-5.35GHz<200mW,

5.47-5.725GHz<200mW,

5.735-5.835GHz<25mW, NFC 13.56MHz

■

Note

･

Do not use a remodeled terminal. Using a remodeled terminal violates the Radio Law/Telecommunications Business Act.

The terminal is compliant with rules on the technical standard conformance of specified wireless equipment based on the Radio Law/ Telecommunications Business Act, and as a proof of it, the "Technical Compliance Mark " is depicted on the electronic nameplate of the terminal. To check the electronic name plate, from the Home screen, [System]u[About phone]u[Certificates]. If you remove the screws and alter the inside of the terminal, the technical regulations conformity certification becomes invalid. Do not use the terminal with the certification invalid, as it is a violation of the Radio Law and Telecommunications Business Act.

･

Be careful when using the terminal

[Settings]

while driving.

Use of the terminal holding with your hand while driving will result in a penalty. However, absolutely necessary cases such as rescue of a sick person or maintaining public safety are exempted.

･

The FeliCa and the NFC reader/writer functions are compliant with the wireless standards of Japan. Check the regulations of the country/

region beforehand if you try to use the function overseas.

･

Do not alter the basic software illegally.

It is regarded as the software modification and Repairs may be refused.

Waterproofness/ Dustproofness

SO-05K provides waterproofness property of

, IPX8*2, and dustproofness property of

IPX5

with the cover of docomo nano UIM

IP6X

card/microSD card slot firmly attached.

*1 IPX5 means that a phone keeps functioning

after applying a jet flow of 12.5 L/min. from every direction from a distance of approximately 3 m for at least 3 minutes using water nozzle in 6.3 mm inner diameter.

*2 IPX8 means that a phone keeps functioning

after SO-05K is slowly submerged to depth of 1.5 m in static tap water at room temperature, left there for approximately 30 minutes and then taken out.

*3 IP6X indicates that a phone has the ability

to prevent dust from entering even when it has been shaken for 8 hours in an apparatus

containing dust particles 75

m or less in

diameter.

Content s/Precautio ns

What you can do with waterproofness/dustproofness of SO-05K

･

You can talk without an umbrella in the rain (for rainfall of 20 mm or less per hour).

- Do not open or close the cover of docomo nano UIM card/microSD card slot with wet hands or with water droplets on the terminal.

･

You can wash the terminal when it gets dirt or stained with liquid other than tap water.

- Wash the terminal with tap water at normal

℃

temperature (5 flow (less than 6 L/min.) at distance of

approximately 10 cm away from the tap or shower.

- When washing the terminal, hold the cover of docomo nano UIM card/microSD card slot closed, and wash the terminal with your hands, not using a brush or sponge. After washing, drain the terminal before use (P.28).

･

You can use at a poolside. Do not throw water from the pool on the terminal, or soak it in pool water.

-35℃) by weaker water

･

You can use the terminal in a bathroom.

- Do not immerse the terminal into a bathtub. Also, do not use the terminal in hot water. Doing so may cause malfunction. If you should fall the terminal into the bathtub, immediately pick it up to drain water in specified procedure (P.28).

- Never put the terminal in hot spr ing water or water containing soap, detergent or bath powder. In case the terminal gets wet with water other than tap water, wash it in the procedure above.

- You can use the terminal within 2 hours in a bathroom where the temperature ranges

℃

between 5 and 45

and humidity ranges

between 45 and 99%.

- Rapid temperature change may cause condensation. In case of bringing the terminal from a cold place to warm place such as a bathroom, wait until the terminal reaches the room temperature.

- Do not put hot water from a faucet or shower.

Content s/Precautio ns

To ensure waterproofness/ dustproofness

To avoid water ingress, be sure to observe the following points.

･

Do not throw any liquid other than room temperature tap water on the terminal, or soak it in such liquid.

･

Firmly close the cover of docomo nano UIM card/microSD card slot. Even a fine obstacle (one hair, one grain of sand, tiny fiber, etc.) put between contact surfaces may allow water to enter.

･

Do not poke the earpiece/speaker, microphone, speaker, second microphone, headset jack, or USB Type-C sharp object.

･

Do not let the terminal fall. It may become scratched causing the waterproof/dustproof performance to degrade.

･

The rubber gasket on the inner side of the cover of docomo nano UIM card/microSD card slot plays an important role in keeping waterproof/dustproof performance. Do not remove or damage them. Also, prevent dust from adhering to them.

™

jack with a

■

Opening the cover of docomo nano UIM card/microSD card slot

Put your tip of finger (fingernail) into the groove and draw the cover out in the arrow direction.

Content s/Precautio ns

■

Closing the cover of docomo nano UIM card/microSD card slot

Push the tray all the way in the arrow direction and firmly press parts and make sure that there are no gaps between the terminal and the cover.

Important precautions

Do not perform actions shown in the illustrations below.

It is recommended to replace the parts for maintaining waterproof/dustproof property once every two years regardless of whether any abnormality is present. DOCOMO replaces the parts as a chargeable service. Bring the terminal to a sales outlet such as a DOCOMO-specified repair office.

Using in hot

spring

Machine-

washing

Applying strong

Attaching

sand/mud

water ow

Using Soap/Detergent/

Bath powder

Soaking in

ocean water

Washing with brush/sponge

Observe the following precautions to use the terminal properly.

･

Accessories and optional devices are not waterproof/dustproof.

･

Do not apply water flow stronger than allowed (P.24). SO-05K provides IPX5 waterproofness, but doing so may cause malfunction.

･

If the terminal gets wet with salt water, sea water, refreshing beverage or mud or sand adhered, wash it immediately. If they dry out, it is hard to remove the dirt and it may cause damage or malfunction.

･

Do not put the terminal in hot water, use it in a sauna or apply hot airflow (from a hair dryer etc.) to it.

Content s/Precautio ns

･

Do not move the terminal in water or slam the terminal against the surface of water.

･

If you put the terminal in tap water, be sure to have it within 30 minutes.

･

When you use the terminal in swimming pool, obey rules of the facility.

･

The terminal does not float on water.

･

Do not leave water on the terminal. In cold region, the terminal freezes up and may cause malfunction.

･

Do not leave water droplet on the earpiece/ speaker, microphone, speaker, second microphone, and headset jack. Such water may interfere with talking.

･

If the terminal gets splashed with water or other liquid while the cover of docomo nano UIM card/microSD card slot is open, the liquid may get inside the terminal, causing electric shock or malfunction. Stop using the terminal, turn off the power and contact a DOCOMOspecified repair office.

･

If the rubber gasket on the inner side of the cover of docomo nano UIM card/microSD card slot is damaged or deformed, have it replaced at a DOCOMO-specified repair office.

･

Do not connect TV antenna cable, earphones, etc. when the terminal is wet with water. Doing so may cause malfunction.

DOCOMO does not guarantee actual operations under all states. Malfunctions deemed to be caused by inappropriate operation by the customer are not covered by the warranty.

Draining water from the terminal

When the terminal is wet, water may flow out after wiping it off; drain the water in the following steps.

Hold the terminal firmly and wipe off moisture on the terminal surface and back side with dry, clean cloth etc.

Shake the terminal about 20 times, firmly holding it, until no more drops of water come out (shown left). Do the s ame with the terminal upside down (shown right).

Content s/Precautio ns

+ 226 hidden pages
