INSTALLATION AND S ET UP FOR HOMEAWARE™ TRANSMITTER
HA360VPT – Remote Phone Transmitter
The HomeAware™ HA360VPT Remote Phone
Transmitter will alert you to a phone call, video relay
service or a fax via the HomeAware™ Main unit.
Setting Up Your Transmitter
The HomeAware™ HA360VPT Remote Phone
Transmitter plugs into an RJ11 telephone jack (i.e. wall
phone jack, pass-through phone jack on a phone or fax
machine, or a phone jack provided by a VoIP or VRS
hardware.)
Install Batteries
The HomeAware™ Remote Phone Transmitter comes
with two #357 silver oxide long lasting batter ies that n eed
to be installed into the bottom of the unit. Once installed
the red light should light when the button is pushed. If the
light does not show, you may have the batteries in
backwards.
Link Button Set Up
This procedure will link the HA360VPT – Remote
Phone Transmitter to your Main unit. The Main unit
will also provide an alert to all HomeAware™ remote
receivers, and to original Sonic Alert receivers when
using an HA360BU bridge unit.
To link a transmitter to your HomeAware™ Main
unit:
1. Press Set Up button and the word LINK will be
shown on the display, press Enter. LINK will
begin blinking. (If LINK mode is entered by
accident, simply press the BACK button to exit
and return to the clock.)
2. Press and hold down the Link button on the
bottom of your transmitter for about 1 second. The
red LED on the transmitter will light up. Release
the button and the words PICK A DECIVE will
begin scrolling across the display. PHONE will
then be shown on the display, press Enter if you
want to be alerted to incoming phone call or press
the up (Tone) button to switch to VRS or FAX,
press Enter when the desired device is shown.
3. The HomeAware™ main unit will briefly show
DONE, and return to the time display. Your
transmitter is now connected and ready to test and
use.
4. Incoming phone calls will now send a signal to the
Main unit. You also can use the button on the front
of the unit to send a test signal to the Main unit.
HA360VPT Phone Remote UG Rev 3.pdf 1 11/10/2015 5:14:32 PM
INSTALLATION AND S ET UP FOR HOMEAWARE™ TRANSMITTER
SONIC ALERT’S 1 YEAR LIMITED WARRANTY
1081 West Innovation Dr. Kearney, MO 64060, USA.
HA360VPT – Remote Phone Transmitter
FCC Requirements
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions; (1)
This device might not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed to
provide responsible protect against harmful interference in
a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions
manual, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not interfere in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning
the equipment on and off, the user is encouraged to try to
correct the interference by one or more of the following
measures:
i. Reorient or relocate the receiving antenna.
ii. Increase the separation between the equipment
and receiver.
iii. Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
iv. Consult the dealer or and experienced radio /TV
technician for help
Modification not expressly approved by the manufacturer
could void the user’s authority to operate the equipment
under FCC rules.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
The normal function of the product may be disturbed
by Strong Electro Magnetic Interference. If so, simply
reset the product to resume normal operation by
following the instruction manual. In case the function
could not resume, please use the product in other
location.
– Attention should be drawn to the environmental
aspects of battery disposal.
– This indicating separate collection for electrical and
electronic equipment.
The HomeAware™ HA360VPT are warranted against
manufacturing defects in materials and workmanship for
one (1) year from the date of purchase. Within this
period Sonic Alert will repair or replace at our option the
HomeAware™ HA360VPT without charge for parts and
labor.
Simply contact our customer service department
to obtain an RA (return authorization number)
and instructions on how to process your product
for return. Call 1-888-864-2446 or e-mail to
RMA@sonicalert.info. You’ll need a copy of your
receipt to process the return authorization.
GENERAL DATA
UL listed Power Adaptor: AC100-240V~, 50/60Hz
Power: Batteries 2 x SR44
CAUTION:
TO REDUCE
THE RISK
OF ELECTRICAL
SHOCK, DO
The Lightening
flash and
arrowhead within
the triangle is a
warning sign
alerting you of
dangerous voltage
inside the product.
HA360VPT Phone Remote UG Rev 3.pdf 2 11/10/2015 5:14:32 PM
NOT
REMOVE THE
COVER
(OR BACK)
FROM THE
PRODUCT. NO
USER
SERVICEABLE
PARTS
INSIDE. REFER
SERVICING TO
YOUR SONIC
ALERT DEALER.
The exclamation
mark within the
triangle is a
warning sign
alerting you of
important
instructions
accompanying
the product.
Sonic Alert Warranty Center
Made in China
Sonic Alert, Troy, MI 48083
www.SonicAlert.com 1-888-864-244
