USB2227/USB2228
4th Generation USB2.0
Flash Media Controller
with Integrated Card
Power FETs
PRODUCT FEATURES
■ Complete System Solution for interfacing
SmartMedia
Memory Stick
(HSMS), Memory Stick PRO (MSPRO), MS DuoTM,
Secure Digital (SD), Mini-Secure Digital (Mini-SD),
TransFlash (SD), MultiMediaCard
Reduced Size MultiMediaCard (RS-MMC), NAND
Flash, Compact FlashTM (CF) and CF UltraTM I & II,
and CF form-factor ATA hard drives to USB2.0 bus
— Supports USB Bulk Only Mass Storage Compliant
Bootable BIOS
■ Support for simultaneous operation of all above
devices. (only one at a time of each of the following
groups supported: CF or ATA drive, SM or XD or
NAND, SD or MMC)
■ On-Chip 4-Bit High Speed Memory Stick and MS
PRO Hardware Circuitry
■ On-Chip firmware reads and writes High Speed
Memory Stick and MS PRO
■ 1-bit ECC correction performed in hardware for
maximum efficiency
■ Hardware support for SD Security Command
Extensions
■ On-chip power FETs for supplying flash media card
power with minimum board components
■ USB Bus Power Certified
■ 3.3 Volt I/O with 5V input tolerance on VBUS/GPIO3
■ Complete USB Specification 2.0 Compatibility for Bus
Powered Operation
— Includes USB2.0 Transceiver
— A Bi-directional Control and a Bi-directional Bulk
Endpoint are provided.
■ 8051 8 bit microprocessor
— Provides low speed control functions
— 30 Mhz execution speed at 4 cycles per instruction
average
— 12K Bytes of internal SRAM for general purpose
scratchpad
— 768 Bytes of internal SRAM for general purpose
scratchpad or program execution while re-flashing
external ROM
1.xD Picture Card not applicable to USB2227.
TM
(SM) or xD Picture CardTM (xD)1,
TM
(MS), High Speed Memory Stick
TM
(MMC),
Datasheet
■ Double Buffered Bulk Endpoint
— Bi-directional 512 Byte Buffer for Bulk Endpoint
— 64 Byte RX Control Endpoint Buffer
— 64 Byte TX Control Endpoint Buffer
■ Internal or External Program Memory Interface
— 64K Byte Internal Code Space or Optional 64K Byte
External Code Space using Flash, SRAM or EPROM
memory.
■ On Board 24Mhz Crystal Driver Circuit
■ Can be clocked by 48MHz external source
■ On-Chip 1.8V Regulator for Low Power Core
Operation
■ Internal PLL for 480Mhz USB2.0 Sampling,
Configurable MCU clock
■ Supports firmware upgrade via USB bus if “boot
block” Flash program memory is used
■ 15 GPIOs for special function use: LED indicators,
button inputs, power control to memory devices, etc.
— Inputs capable of generating interrupts with either edge
sensitivity
— Attribute bit controlled features:
— Activity LED polarity/operation/blink rate
— Full or Partial Card compliance checking
— Bus or Self Powered
— LUN configuration and assignment
— Write Protect Polarity
— SmartDetach™ Detach from USB when no Card
Inserted for Notebook apps
— Cover Switch operation for xD compliance
— Inquiry Command operation
— SD Write Protect operation
— Older CF card support
— Force USB 1.1 reporting
— Internal or External Power FET operation
■ Compatible with Microsoft WinXP, WinME, Win2K
SP3, Apple OS10, Softconnex, and Linux Multi-LUN
Mass Storage Class Drivers
■ Win2K, Win98/98SE and Apple OS8.6 and OS9
Multi-LUN Mass Storage Class Drivers available from
SMSC
■ 128 Pin VTQFP Package (1.0mm height, 14mm
x14mm footprint); green, lead-free package also
available
SMSC USB2227/USB2228 DATASHEET Revision 1.77 (06-13-05)
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
ORDER NUMBER(S):
USB2227/USB2228-NE-XX FOR 128 PIN, VTQFP PACKAGE
USB2227/USB2228-NU-XX FOR 128 PIN, VTQFP PACKAGE (GREEN, LEAD-FREE)
Datasheet
Hauppauge, NY 11788
(631) 435-6000
FAX (631) 273-3123
80 Arkay Drive
Copyright © 2005 SMSC or its subsidiaries. All rights reserved.
Circuit diagrams and other information relating to SMSC products are included as a means of illustrating typical applications. Consequently,
complete information sufficient for construction purposes is not necessarily given. Although the information has been checked and is believed to be
accurate, no responsibility is assumed for inaccuracies. SMSC reserves the right to make changes to specifications and product descriptions at any
time without notice. Contact your local SMSC sales office to obtain the latest specifications before placing your product order. The provision of this
information does not convey to the purchaser of the described semiconductor devices any licenses under any patent rights or other intellectual
property rights of SMSC or others. All sales are expressly conditional on your agreement to the terms and conditions of the most recently dated
version of SMSC's standard Terms of Sale Agreem ent dated before the date of your order (the "Terms of Sale Agreement"). The product may
contain design defects or errors known as anomalies which may cause the product's functions to deviate from published specifications. Anomaly
sheets are available upon request. SMSC products are not designed, intended, authorized or warranted for use in any life support or other
application where product failure could cause or contribute to personal injury or severe property damage. Any and all such uses without prior written
approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer. Copies of this document or other
SMSC literature, as well as the Terms of Sale Agreement, may be obtained by visiting SMSC’s website at http://www.smsc.com. SMSC is a
registered trademark of Standard Microsystems Corporation (“SMSC”). Product names and company names are the trademarks of their respective
holders.
SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARRANTIES, INCLUDING WITHOUT LIMITATION ANY AND ALL IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND AGAINST INFRINGEMENT AND THE LIKE,
AND ANY AND ALL WARR ANTIES ARISING FROM ANY COURSE OF DEALING OR USAGE OF TRADE.
IN NO EVENT SHALL SMSC BE LIABLE FOR ANY DIRECT, INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR CONSEQUENTIAL
DAMAGES; OR FOR LOST DATA, PROFITS, SAVINGS OR REVENUES OF ANY KIND; REGARDLESS OF THE FORM OF ACTION,
WHETHER BASED ON CONTRACT; TORT; NEGLIGENCE OF SMSC OR OTHERS; STRICT LIABILITY; BREACH OF WARRANTY; OR
OTHERWISE; WHETHER OR NOT ANY REMEDY OF BUYER IS HELD TO HAVE FAILED OF ITS ESSENTIAL PURPOSE, AND WHETHER
OR NOT SMSC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Revision 1.77 (06-13-05) 2 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
Table of Contents
Chapter 1 General Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 2 Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 3 Pin Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 128-Pin Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 128-Pin List Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 4 Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 5 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chapter 6 Pin Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6.1 PIN Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6.2 Buffer Type Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Chapter 7 DC Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.1 Maximum Guaranteed Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.2 DC Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.3 Capacitance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Chapter 8 Package Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Chapter 9 GPIO Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
SMSC USB2227/USB2228 3 Revision 1.77 (06-13-05)
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
List of Figures
Figure 4.1 USB2227/USB2228 128-Pin VTQFP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 8.1 USB2227/USB2228 128-Pin VTQFP Package Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Revision 1.77 (06-13-05) 4 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
List of Tables
Table 3.1 USB2227/USB2228 128-Pin Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 3.2 USB2227/USB2228 128-Pin VTQFP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Table 6.1 USB2227/USB2228 Buffer Type Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 8.1 USB2227/USB2228 128-Pin VTQFP Package Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Table 9.1 GPIO Usage (ROM Rev 0x00) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
SMSC USB2227/USB2228 5 Revision 1.77 (06-13-05)
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Chapter 1 General Description
The USB2227/USB2228 is a USB2.0 Bulk Only Mass Storage Class Peripheral Controller intended for
supporting CompactFlash (CF and CF Ultra I/II) in True IDE Mode only, SmartMedia (SM) and XD
cards, Memory Stick (MS), Memory Stick DUO (MSDUO) and Memory Stick Pro (MSPRO), Secure
Digital (SD), and MultiMediaCard (MMC) flash memory devices. It provides a single chip solution for
the most popular flash memory cards in the market.
The device consists of a USB2.0 PHY and SIE, buffers, Fast 8051 microprocessor with expanded
scratchpad, and program SRAM, and CF, MS, SM and SD controllers. The SD controller supports both
SD and MMC devices. SM controller supports both SM and xD cards.
Provisions for external Flash Memory up to 64K bytes for program storage is provided.
12K bytes of scratchpad SRAM and 768 Bytes of program SRAM are also provided.
Fifteen GPIO pins are provided for indicators, external serial EEPROM for OEM id and system
configuration information, and other special functions.
Internal power FETs are provided to directly supply power to the xD/SM, MMC/SD and MS/MSPro
cards.
The internal ROM program is capable of implementing any combination of single or multi-LUN
CF/SD/MMC/SM/MS reader functions with individual card power control and activity indication. SMSC
also provides licenses** for Win98 and Win2K drivers and setup utilities. Note: Please check with
SMSC for precise features and capabilities for the current ROM code release.
*Note: In order to develop, make, use, or sell readers and/or other products using or incorporating any of the SMSC devices made
the subject of this document or to use related SMSC software programs, technical information and licenses under patent and other
intellectual property rights from or through various persons or entities, including without limitation media standard companies,
forums, and associations, and other patent holders may be required. These media standard companies, forums, and associations
include without limitation the following: Sony Corporation (Memory Stick, Memory Stick Pro); SD3 LLC (Secure Digital); MultiMedia
Card Association (MultiMediaCard); the SSFDC Forum (SmartMedia); the Compact Flash Association (Compact Flash); and Fuji
Photo Film Co., Ltd., Olympus Optical Co., Ltd., and Toshiba Corporation (xD-Picture Card). SMSC does not make such licenses
or technical information available; does not promise or represent that any such licenses or technical information will actually be
obtainable from or through the various persons or entities (including the media standard companies, forums, and associations), or
with respect to the terms under which they may be made available; and is not responsible for the accuracy or sufficiency of, or
otherwise with respect to, any such technical information.
SMSC's obligations (if any) under the Terms of Sale Agreement, or any other agreement with any customer, or otherwise, with
respect to infringement, including without limitation any obligations to defend or settle claims, to reimburse for costs, or to pay
damages, shall not apply to any of the devices made the subject of this document or any software programs related to any of such
devices, or to any combinations involving any of them, with respect to infringement or claimed infringement of any existing or future
patents related to solid state disk or other flash memory technology or applications ("Solid State Disk Patents"). By making any
purchase of any of the devices made the subject of this document, the customer represents, warrants, and agrees that it has
obtained all necessary licenses under then-existing Solid State Disk Patents for the manufacture, use and sale of solid state disk
and other flash memory products and that the customer will timely obtain at no cost or expense to SMSC all necessary licenses
under Solid State Disk Patents; that the manufacture and testing by or for SMSC of the units of any of the devices made the subject
of this document which may be sold to the customer, and any sale by SMSC of such units to the customer, are valid exercises of
the customer's rights and licenses under such Solid State Disk Patents; that SMSC shall have no obligation for royalties or otherwise
under any Solid State Disk Patents by reason of any such manufacture, use, or sale of such units; and that SMSC shall have no
obligation for any costs or expenses related to the customer's obtaining or having obtained rights or licenses under any Solid State
Disk Patents.
SMSC MAKES NO WARRANTIES, EXPRESS, IMPLIED, OR STATUTORY, IN REGARD TO INFRINGEMENT OR OTHER
VIOLATION OF INTELLECTUAL PROPERTY RIGHTS. SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARRANTIES
AGAINST INFRINGEMENT AND THE LIKE.
No license is granted by SMSC expressly, by implication, by estoppel or otherwise, under any patent, trademark, copyright, mask
work right, trade secret, or other intellectual property right.
**To obtain this software program the appropriate SMSC Software License Agreement must be executed and in effect. Forms of
these Software License Agreements may be obtained by contacting SMSC.
Datasheet
Revision 1.77 (06-13-05) 6 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
Chapter 2 Acronyms
SM: SmartMedia
SMC: SmartMedia Controller
FM: Flash Media
FMC: Flash Media Controller
CF: Compact Flash
CFC: CompactFlash Controller
SD: Secure Digital
SDC: Secure Digital Controller
MMC: MultiMediaCard
MS: Memory Stick
MSC: Memory Stick Controller
TPC: Transport Protocol Code.
ECC: Error Checking and Correcting
CRC: Cyclic Redundancy Checking
SMSC USB2227/USB2228 7 Revision 1.77 (06-13-05)
DATASHEET
Chapter 3 Pin Table
3.1 128-Pin Package
Table 3.1 USB2227/USB2228 128-Pin Package
CompactFlashINTERFACE (28 Pins)
CF_D0 CF_D1 CF_D2 CF_D3
CF_D4 CF_D5 CF_D6 CF_D7
CF_D8 CF_D9 CF_D10 CF_D11
CF_D12 CF_D13 CF_D14 CF_D15
CF_nIOR CF_nIOW CF_IRQ CF_nRESET
CF_IORDY CF_nCS0 CF_nCS1 CF_SA0
CF_SA1 CF_SA2 CF_nCD1 CF_nCD2
SmartMedia INTERFACE (17 Pins)
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
SM_D0 SM_D1 SM_D2 SM_D3
SM_D4 SM_D5 SM_D6 SM_D7
SM_ALE SM_CLE SM_nRE SM_nWE
SM_nWP SM_nB/R SM_nCE SM_nCD
SM_nWPS
Memory Stick INTERFACE (7 Pins)
MS_BS MS_SDIO/MS_D0 MS_SCLK MS_INS
MS_D1 MS_D2 MS_D3
SD INTERFACE (7 Pins)
SD_CMD SD_CLK SD_DAT0 SD_DAT1
SD_DAT2 SD_DAT3 SD_nWP
USB INTERFACE (10 Pins)
USBDP USBDM ATEST RBIAS
VDD18PLL VSSPLL VDDA33 VSSA
XTAL1/CLKIN XTAL2
Revision 1.77 (06-13-05) 8 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
Table 3.1 USB2227/USB2228 128-Pin Package (continued)
MEMORY/IO INTERFACE (27 Pins)
MA0/CLK_SEL0 MA1/CLK_SEL1 MA2/SEL_CLKDRV MA3
MA4 MA5 MA6 MA7
MA8 MA9 MA10 MA11
MA12 MA13 MA14 MA15
MD0 MD1 MD2 MD3
MD4 MD5 MD6 MD7
nMRD nMWR nMCE
MISC (18 Pins)
GPIO1 GPIO2 GPIO3 GPIO4
GPIO5 GPIO6/ROMEN GPIO7 GPIO8/
CRP_PWR0
GPIO9 GPIO10/
CRD_PWR1
GPIO13 GPIO14 GPIO15 nTEST0
nTEST1 nRESET
DIGITAL, POWER, GROUND & NC (14 Pins)
(5)VDD33 (2)VDD18 (7)VSS
Tota l 128
GPIO11/
CRD_PWR2
GPIO12
3.2 128-Pin List Table
Table 3.2 USB2227/USB2228 128-Pin VTQFP
PIN #NAME MA PIN
#
1 MA13 8 33 CF_D1 8 65 SM_D0 8 97 VSS -
2 MA14 8 34 CF_D2 8 66 SM_D1 8 98 RBIAS -
3 VDD33 - 35 CF_D3 8 67 SM_D2 8 99 ATEST -
NAME MA PIN
#
NAME MA PIN
#
NAME MA
4 MA15 8 36 CF_D4 8 68 SM_D3 8 100 VDD33 -
5 MD0 8 37 CF_D5 8 69 SM_D4 8 101 VDD18PLL -
6 MD1 8 38 CF_D6 8 70 SM_D5 8 102 XTAL1/
CLKIN
7 MD2 8 39 CF_D7 8 71 SM_D6 8 103 XTAL2 -
8 MD3 8 40 CF_D8 8 72 SM_D7 8 104 VSSPLL -
9 MD4 8 41 CF_D9 8 73 SM_ALE 8 105 GPIO9 8
SMSC USB2227/USB2228 9 Revision 1.77 (06-13-05)
-
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Table 3.2 USB2227/USB2228 128-Pin VTQFP (continued)
Datasheet
PIN #NAME MA PIN
#
10 MD5 8 42 GPIO8/
NAME MA PIN
#
8 74 SM_nWP 8 106 VDD18 -
NAME MA PIN
#
NAME MA
CRD_PWR0
11 MD6 8 43 VDD33 - 75 SM_CLE 8 107 GPIO7 8
12 MD7 8 44 GPIO11/
8 76 SM_nWPS - 108 VDD33 -
CRD_PWR2
13 nMRD 8 45 CF_D10 8 77 SM_nB/R - 109 GPIO6/
ROMEN
14 nMWR 8 46 CF_D11 8 78 SM_nCD - 110 GPIO5 8
15 VSS - 47 VSS - 79 GPIO10/
8111 GPIO4 8
CRD_PWR1
16 VSS - 48 CF_D12 8 80 VDD33 - 112 VSS -
17 nMCE 8 49 VDD18 - 81 SM_nRE 8 113 GPIO2 8
18 MS_INS - 50 CF_D13 8 82 SM_nWE 8 114 GPIO1 8
19 MS_D0/
8 51 CF_D14 8 83 SM_nCE 8 115 nRESET -
MS_SDIO
20 MS_D1 8 52 CF_D15 8 84 VSS - 116 MA0/
CLK_SEL0
8
8
21 MS_D2 8 53 CF_nCD1 - 85 VSS - 117 MA1/
CLK_SEL1
22 MS_D3 8 54 CF_nCD2 - 86 VSSA - 118 MA2/
SEL_
CLKDRV
23 MS_SCLK8 55 CF_IRQ 8 87 USBDM - 119 MA3 8
24 MS_BS 8 56 CF_IORDY 8 88 USBDP - 120 MA4 8
25 SD_nWP - 57 CF_nIOR 8 89 VDDA33 - 121 MA5 8
26 SD_DAT0 8 58 CF_nIOW 8 90 GPIO15 8 122 MA6 8
27 SD_DAT1 8 59 CF_nRESET 8 91 GPIO14 8 123 MA7 8
28 SD_DAT2 8 60 CF_nCS0 8 92 GPIO13 8 124 MA8 8
29 SD_DAT3 8 61 CF_nCS1 8 93 GPIO12 8 125 MA9 8
30 SD_CMD 8 62 CF_SA0 8 94 GPIO3 8 126 MA10 8
31 SD_CLK - 63 CF_SA1 8 95 nTEST1 - 127 MA11 8
32 CF_D0 8 64 CF_SA2 - 96 nTEST0 - 128 MA12 8
Notes:
■ RBIAS is connected to the Analog Ground plane VSSA via a resistor.
■ When the internal 1.8V regulator is enabled, VDD18 (Pin 106) & VDD18PLL (Pin 101), MUST have
a 10uf +/- 20%, (equivalent series resistance (ESR) <0.1ohm) bypass capacitor to VSSA. These
capacitors must be as close to the pins as possible
8
8
Revision 1.77 (06-13-05) 10 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
Chapter 4 Pin Configuration
MA12
MA11
MA10
MA9
MA8
MA7
MA6
MA5
MA4
MA3
MA2
MA1
MA0
nRESET
GPIO1
GPIO2
VSS
GPIO4
GPIO5
GPIO6/ROMEN
VDD33
GPIO7
VDD18
GPIO9
VSSPLL
XTAL2
XTAL1
VDD18PLL
VDD33
ATEST
RBIAS
VSS
MA13
MA14
VDD33
MA15
MD0
MD1
MD2
MD3
MD4
MD5
MD6
MD7
nMRD
nMWR
VSS
VSS
nMCE
MS_INS
MS_D0
MS_D1
MS_D2
MS_D3
MS_SCLK
MS_BS
SD_nWP
SD_DAT0
SD_DAT1
SD_DAT2
SD_DAT3
SD_CMD
SD_CLK
CF_D0
1
USB2227 & USB2228
32
CF_D1
CF_D2
CF_D3
CF_D4
CF_D5
CF_D6
CF_D7
CF_D8
CF_D9
GPIO8
VDD33
GPIO11
CF_D10
CF_D11
VSS
VDD18
CF_D12
CF_D13
CF_D14
CF_D15
CF_nCD1
CF_nCD2
CF_IRQ
CF_nIOR
CF_IORDY
CF_nIOW
96
nTEST0
nTEST1
GPIO3
GPIO12
GPIO13
GPIO14
GPIO15
VDDA33
USBDP
USBDM
VSSA
VSS
VSS
SM_nCE
SM_nWE
SM_nRE
VDD33
GPIO10
SM_nCD
SM_nB/R
SM_nWPS
SM_CLE
SM_nWP
SM_ALE
SM_D7
SM_D6
SM_D5
SM_D4
SM_D3
SM_D2
SM_D1
SM_D0
64
CF_SA0
CF_SA1
CF_SA2
CF_nCS0
CF_nCS1
CF_nRESET
Figure 4.1 USB2227/USB2228 128-Pin VTQFP
SMSC USB2227/USB2228 11 Revision 1.77 (06-13-05)
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
&)
&DUGV
0HPRU\
6066)'&
6'00&
06+60606352
*3,2&5'B3:5
*3,2&5'B3:5
*3,2&5'B3:5
520(1
%XV
3URJUDP0HPRU\,2
65$0
.%
%\WHV(37;5;%XIIHU%
%\WHV(37;5;%XIIHU$
$GGUHVV
&RQWUROOHUV
)ODVK0HGLD
%\WHV(37;
%\WHV(35;
%\WHV(35;
&)
)0&
'$7$
)ODVK0HGLD'0$8QLW
D
W
D
'
%\WHV(37;
&RQWUROOHU
0+]%LW
X
%
V
V
&RQWURO
6WDWXV
60
&RQWUROOHU
(&&
&RQWURO
'$7$
)0&
/DWFKSKDVH
/DWFKSKDVH
6,(
/DWFKSKDVH
$GGUHVV08;
6WDWXV
&RQWURO
6WDWXV
'DWD#ELW
6'
06
&RQWUROOHU
&RQWURO
6WDWXV
&RQWURO
&RQWUROOHU
6WDWXV
.520
&5&
&5&
0(0,2%XVSLQV
'$7$
'$7$
)0 &'DWD 08 ;
0K]
.%\WH
$GGUHVVDQG'DWDEXVVHV
;'$7$6)5
$GGUHVV5HJLVWHU
ELW0+]'DWD%XVV
3:5B)(7
3:5B)(7
65$0
6FUDWFKSDG
*3,2 SLQV
3:5B)(7
6,(&RQWURO5HJV
&RQILJXUDWLRQDQG&RQWURO
6FUDWFKSDG
65$0%\WH
,QWHUUXSW&RQWUROOHU
2VF
&ORFN*HQHUDWLRQ
;
)$67
$
7
#LOCKEDBY0HASE#LOCK
&38&25(
/
0+]
$GGUHVV
$GGUHVV
$GGUHVV
(37;B%&
$XWRDGGUHVVJHQHUDWRUV
Chapter 5 Block Diagram
Revision 1.77 (06-13-05) 12 SMSC USB2227/USB2228
(35;B%&
$GGUHVV
(37;B%&
$GGUHVV
(35;B%&
$GGUHVV
5$0:5B$%
5$05'B$%
DATASHEET
#LOCKEDBY0HASE#LOCK
6,(
6HULDO,QWHUIDFH(QJLQH
86%3+<
7UDQVFLHYHU
SLQV
&/2&.287
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
Chapter 6 Pin Descriptions
This section provides a detailed description of each signal. The signals are arranged in functional
groups according to their associated interface.
The “n” symbol in the signal name indicates that the active, or asserted state occurs when the signal
is at a low voltage level. When “n” is not present before the signal name, the signal is asserted when
at the high voltage level.
The terms assertion and negation are used exclusively. This is done to avoid confusion when working
with a mixture of “active low” and “active high” signal. The term assert, or assertion indicates that a
signal is active, independent of whether that level is represented by a high or low voltage. The term
negate, or negation indicates that a signal is inactive.
6.1 PIN Descriptions
BUFFER
NAME SYMBOL
CompactFlash (In True IDE mode) INTERFACE
TYPE DESCRIPTION
CF Chip Select 1 CF_nCS1 O8PU This pin is the active low chip select 1 signal for the CF
CF Chip Select 0 CF_nCS0 O8PU This pin is the active low chip select 0 signal for the task
CF Register
Address 2
CF Register
Address 1
CF Register
Address 0
CF Interrupt CF_IRQ IPD This is the active high interrupt request signal from the
CF
Data 15-8
CF
Data7-0
CF_SA2 O8 This pin is the register select address bit 2 for the CF
CF_SA1 O8 This pin is the register select address bit 1 for the CF
CF_SA0 O8 This pin is the register select address bit 0 for the CF
CF_D[15:8] I/O8PD The bi-directional data signals CF_D15-CF_D8 in True
CF_D[7:0] I/O8PD The bi-directional data signals CF_D7-CF_D0 in the
ATA device
file registers of CF ATA device in the True IDE mode.
ATA device.
ATA device
ATA device.
CF device.
IDE mode data transfer.
In the True IDE Mode, all of task file register operation
occur on the CF_D[7:0], while the data transfer is on
CF_D[15:0].
The bi-directional data signal has an internal weak pulldown resistor.
True IDE mode data transfer.
In the True IDE Mode, all of task file register operation
occur on the CF_D[7:0], while the data transfer is on
CF_D[15:0].
The bi-directional data signal has an internal weak pulldown resistor.
IO Ready CF_IORDY IPU This pin is active high input signal.
This pin has an internally controlled weak pull-up
resistor.
SMSC USB2227/USB2228 13 Revision 1.77 (06-13-05)
DATASHEET
NAME SYMBOL
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
BUFFER
TYPE DESCRIPTION
CF
Card Detection2
CF
Card Detection1
CF
Hardware Reset
CF
IO Read
CF
IO Write Strobe
SM
Write Protect
SM
Address Strobe
CF_nCD2 IPU This card detection pin is connected to the ground on
the CF device, when the CF device is inserted.
This pin has an internally controlled weak pull-up
resistor.
CF_nCD1 IPU This card detection pin is connected to ground on the
CF device, when the CF device is inserted.
This pin has an internally controlled weak pull-up
resistor.
CF_nRESET O8 This pin is an active low hardware reset signal to CF
device.
CF_nIOR O8 This pin is an active low read strobe signal for CF
device.
CF_nIOW O8 This pin is an active low write strobe signal for CF
device.
SmartMedia INTERFACE
SM_nWP O8PD This pin is an active low write protect signal for the SM
device.
This pin has a weak pull-down resistor that is
permanently enabled
SM_ALE O8PD This pin is an active high Address Latch Enable signal
for the SM device.
SM
Command Strobe
SM
Data7-0
SM
Read Enable
This pin has a weak pull-down resistor that is
permanently enabled
SM_CLE O8PD This pin is an active high Command Latch Enable signal
for the SM device.
This pin has a weak pull-down resistor that is
permanently enabled
SM_D[7:0] I/O8PD These pins are the bi-directional data signal SM_D7-
SM_D0.
The bi-directional data signal has an internal weak pulldown resistor.
SM_nRE 08PU This pin is an active low read strobe signal for SM
device.
When using the internal FET, this pin has an internal
weak pull-up resistor that is tied to the output of the
internal Power FET.
08 If an external FET is used (Internal FET is disabled),
then the internal pull-up is not available (external pullups must be used, and should be connected to the
applicable Card Power Supply).
Revision 1.77 (06-13-05) 14 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
BUFFER
NAME SYMBOL
TYPE DESCRIPTION
SM
Write Enable
SM
Write Protect Switch
SM
Busy or Data Ready
SM
Chip Enable
SM_nWE O8PU This pin is an active low write strobe signal for SM
device.
When using the internal FET, this pin has an internal
weak pull-up resistor that is tied to the output of the
internal Power FET.
08 If an external FET is used (Internal FET is disabled),
then the internal pull-up is not available (external pullups must be used, and should be connected to the
applicable Card Power Supply).
SM_nWPS IPU A write-protect seal is detected, when this pin is low.
This pin has an internally controlled weak pull-up
resistor.
SM_nB/R I This pin is connected to the BSY/RDY pin of the SM
device.
An external pull-up resistor is required on this signal.
The pull-up resistor must be pulled up to the same
power source that powers the SM/NAND flash device.
SM_nCE O8PU This pin is the active low chip enable signal to the SM
device.
When using the internal FET, this pin has an internal
weak pull-up resistor that is tied to the output of the
internal Power FET.
08 If an external FET is used (Internal FET is disabled),
then the internal pull-up is not available (external pullups must be used, and should be connected to the
applicable Card Power Supply).
SM
Card Detection
MS
Bus State
MS
System
Data In/Out
MS
System Data In/Out
MS
System
Data In/Out
SM_nCD IPU This is the card detection signal from SM device to
indicate if the device is inserted.
This pin has an internally controlled weak pull-up
resistor.
MEMORY STICK INTERFACE
MS_BS O8 This pin is connected to the BS pin of the MS device.
It is used to control the Bus States 0, 1, 2 and 3 (BS0,
BS1, BS2 and BS3) of the MS device.
MS_SDIO/MS_
D0
I/O8PD This pin is a bi-directional data signal for the MS device.
Most significant bit (MSB) of each byte is transmitted
first by either MSC or MS device.
The bi-directional data signal has an internal weak pulldown resistor.
MS_D1 I/O8PD This pin is a bi-directional data signal for the MS device.
This pin has internally controlled weak pull-up and pulldown resistors for various operational modes.
MS_D[3:2] I/O8PD This pin is a bi-directional data signal for the MS device.
The bi-directional data signal has an internal weak pulldown resistor.
SMSC USB2227/USB2228 15 Revision 1.77 (06-13-05)
DATASHEET
NAME SYMBOL
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
BUFFER
TYPE DESCRIPTION
MS
Card Insertion
MS_INS IPU This pin is the card detection signal from the MS device
to indicate, if the device is inserted.
This pin has an internally controlled weak pull-up
resistor.
MS
MS_SCLK O8 This pin is an output clock signal to the MS device.
System CLK
The clock frequency is software configurable.
SD INTERFACE
SD
Data3-0
SD_DAT[3:0] I/O8PU These are bi-directional data signals.
These pins have internally controlled weak pull-up
resistors.
SD Clock SD_CLK O8 This is an output clock signal to SD/MMC device.
The clock frequency is software configurable.
SD Command SD_CMD I/O8PU This is a bi-directional signal that connects to the CMD
signal of SD/MMC device.
This pin has an internally controlled weak pull-up
resistor.
SD
Write Protected
SD_nWP IPD This pin is an input signal with an internal weak pull-
down.
This pin has an internally controlled weak pull-down
resistor.
USB INTERFACE
USB Bus Data USBDM
IO-U These pins connect to the USB bus data signals.
USBDP
USB Transceiver
Bias
RBIAS I A 12.0kΩ, ± 1.0% resistor is attached from VSSA to this
pin, in order to set the transceiver’s internal bias
currents.
Analog Test ATEST AIO This signal is used for testing the analog section of the
chip and should be connected to VDDA33 for normal
operation.
1.8v PLL Power VDD18PLL 1.8v Power for the PLL
PLL Ground
VSSPLL Ground Reference for 1.8v PLL power
Reference
3.3v Analog Power VDDA33 3.3v Analog Power
Analog Ground
VSSA Analog Ground Reference for 3.3v Analog Power.
Reference
Crystal
Input/External Clock
Input
XTAL1/
CLKIN
ICLKx 24Mhz Crystal or external clock input.
This pin can be connected to one terminal of the crystal
or can be connected to an external 24Mhz clock when
a crystal is not used.
Note: The ‘MA[2:0] pins will be sampled while
nRESET is asserted, and the value will be
latched upon nRESET negation. This will
determine the clock source and value.
Revision 1.77 (06-13-05) 16 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
BUFFER
NAME SYMBOL
TYPE DESCRIPTION
Crystal Output XTAL2 OCLKx 24Mhz Crystal
This is the other terminal of the crystal, or left open
when an external clock source is used to drive
XTAL1/CLKIN. It may not be used to drive any external
circuitry other than the crystal circuit.
MEMORY/IO INTERFACE
Memory Data Bus MD[7:0] I/O8PU When ROMEN bit of GPIO_IN1 register = 0, these
signals are used to transfer data between the internal
CPU and the external program memory.
These pins have internally controlled weak pull-up
resistors.
Memory Address
Bus
Memory Address
Bus
MA[15:3] O8 These signals address memory locations within the
external memory.
MA2/
SEL_CLKDRV
I/O8PD MA2 Addresses memory locations within the external
memory.
SEL_CLKDRV. During nRESET assertion, this pins will
select the operating clock mode (crystal or externally
driven clock source), and a weak pull-down resistor is
enabled. When nRESET is negated, the value will be
internally latched and this pin will revert to MA2
functionality, the internal pull-down will be disabled.
‘0’ = Crystal operation (24MHz only)
‘1’ = Externally driven clock source (24MHz or 48MHz)
Note: If the latched value is ‘1’, then the MA2 pin is
tri-stated when the following conditions are
true:
1. IDLE bit (PCON.0) is 1.
2. INT2 is negated
3. SLEEP bit of CLOCK_SEL is 1.
If the latched value is ‘0’, then the MA2 pin will function
identically to the MA[15:3] pins at all times (other than
during nRESET assertion).
SMSC USB2227/USB2228 17 Revision 1.77 (06-13-05)
DATASHEET
NAME SYMBOL
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
BUFFER
TYPE DESCRIPTION
Memory Address
Bus
Memory Write
Strobe
Memory Read
Strobe
MA[1:0]/CLK_S
EL[1:0]
I/O8PD MA[1:0], These signals address memory locations
within the external memory.
SEL[1:0]. During nRESET assertion, these pins will
select the operating frequency of the external clock, and
the corresponding weak pull-down resistors are
enabled. When nRESET is negated, the value on these
pins will be internal latched and these pins will revert to
MA[1:0] functionality, the internal pull-downs will be
disabled.
SEL[1:0] = ‘00’. 24MHz
SEL[1:0] = ‘01’. RESERVED
SEL[1:0] = ‘10’. RESERVED
SEL[1:0] = ‘11’. 48MHz
Note: If the latched value is ‘1’, then the
corresponding MA pin is tri-stated when the
following conditions are true:
1. IDLE bit (PCON.0) is 1.
2. INT2 is negated
3. SLEEP bit of CLOCK_SEL is 1.
If the latched value is ‘0’, then the corresponding MA pin
will function identically to the MA[15:3] pins at all times
(other than during nRESET assertion).
nMWR O8 Program Memory Write; active low
nMRD O8 Program Memory Read; active low
Memory Chip
Enable
General Purpose
I/O
General Purpose
I/O
General Purpose
I/O
General Purpose
I/O
General Purpose
I/O
nMCE O8 Program Memory Chip Enable; active low.
This signal is asserted, when any of the following
conditions are no longer met:
1. IDLE bit (PCON.0) is 1.
2. INT2 is negated
3. SLEEP bit of CLOCK_SEL is 1.
Note: This signal is held to a logic ‘high’ while
nRESET is asserted.
MISC
GPIO1 I/O8 This pin may be used either as input, edge sensitive
interrupt input, or output.
GPIO2 I/O8 This pin may be used either as input, edge sensitive
interrupt input, or output.
GPIO3 I/O8 This pin may be used either as input, edge sensitive
interrupt input, or output.
GPIO4 I/O8 This pin may be used either as input, edge sensitive
interrupt input, or output.
GPIO5 I/O8 This pin may be used either as input, edge sensitive
interrupt input, or output.
Revision 1.77 (06-13-05) 18 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
BUFFER
NAME SYMBOL
TYPE DESCRIPTION
GPIO6, ROMEN GPIO6/ROMEN IPU This pin has an internal weak pull-up resistor that is
enabled or disabled by the state of nRESET.
The pull-up is enabled when nRESET is active.
The pull-up is disabled, when the nRESET is inactive
(some clock cycles later, after the rising edge of
nRESET).
The state of this pin is latched internally on the rising
edge of nRESET to determine if internal or external
program memory is used.
The state latched is stored in ROMEN bit of GPIO_IN1
register.
I/O8 After the rising edge of nRESET, this pin may be used
as GPIO6 or RXD.
When pulled low via an external weak pull-down
resistor, an external program memory should be
connected to the memory data bus. The
USB2227/USB2228 uses this external bus for program
execution.
When this pin is left unconnected or pulled high by a
weak pull-up resistor, the USB2227/USB2228 uses the
internal ROM for program execution.
General Purpose
I/O
General Purpose
I/O
Or
Card Power
GPIO7 I/O8 This pin may be used either as input, edge sensitive
interrupt input, or output.
GPIO8/
CRD_PWR0
I/O8 GPIO: This pin may be used either as input, edge
sensitive interrupt input, or output.
CRD_PWR: Card Power drive of 3.3V @ 100mA.
General Purpose
I/O
General Purpose
I/O
Or
Card Power
General Purpose
I/O
Or
Card Power
General Purpose
GPIO9 I/O8 This pin may be used either as input, edge sensitive
interrupt input, or output.
GPIO10/
CRD_PWR1
I/O8 GPIO: These pins may be used either as input, edge
sensitive interrupt input, or output.
CRD_PWR: Card Power drive of 3.3V @ 100mA.
GPIO11/
CRD_PWR2
I/O8 GPIO: This pin may be used either as input, edge
sensitive interrupt input, or output.
CRD_PWR: Card Power drive of 3.3V @ 200mA.
GPIO[15:12] I/O8 These pins may be used either as input, or output.
I/O
RESET input nRESET IS This active low signal is used by the system to reset the
chip. The active low pulse should be at least 1µs wide.
TEST Input nTEST[1:0] I These signals are used for testing the chip. User should
normally tie them high externally, if the test function is
not used.
DIGITAL POWER, GROUNDS, and NO CONNECTS
1.8v Digital Core
VDD18 +1.8V Core power
Power
All VDD18 pins must be connected together on the
circuit board.
SMSC USB2227/USB2228 19 Revision 1.77 (06-13-05)
DATASHEET
NAME SYMBOL
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
BUFFER
TYPE DESCRIPTION
3.3v Power & &
VDD33 3.3V Power & Regulator Input.
Voltage Regulator
Input
pins 100 & 108 supply 3.3V power to the internal 1.8V
regulators.
Ground VSS Ground Reference
Notes:
■ Hot-insertion capable card connectors are required for all flash media. It is required for SD
connector to have Write Protect switch. This allows the chip to detect MMC card.
■ nMCE is normally asserted except when the 8051 is in standby mode.
6.2 Buffer Type Descriptions
Table 6.1 USB2227/USB2228 Buffer Type Descriptions
BUFFER DESCRIPTION
I Input
IPU Input with internal weak pull-up resistor.
IPD Input with internal weak pull-down resistor.
IS Input with Schmitt trigger
I/O8 Input/Output buffer with 8mA sink and 8mA source.
I/O8PU Input/Output buffer with 8mA sink and 8mA source, with an internal weak pull-up resistor.
I/O8PD Input/Output buffer with 8mA sink and 8mA source, with an internal weak pull-down
resistor.
O8 Output buffer with 8mA sink and 8mA source.
O8PU Output buffer with 8mA sink and 8mA source, with an internal weak pull-up resistor.
O8PD Output buffer with 8mA sink and 8mA source, with an internal weak pull-down resistor.
ICLKx XTAL clock input
OCLKx XTAL clock output
I/O-U Analog Input/Output Defined in USB specification
AIO Analog Input/Output
Revision 1.77 (06-13-05) 20 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
Chapter 7 DC Parameters
7.1 Maximum Guaranteed Ratings
Operating Temperature Range ............................................................................................0oC to +70oC
Storage Temperature Range............................................................................................. -55
Lead Temperature Range (soldering, 10 seconds) ...................................................................... +325
Positive Voltage on GPIO3, with respect to Ground......................................................................... 5.5V
Positive Voltage on any signal pin, with respect to Ground ............................................................. 4.6V
Positive Voltage on XTAL1, with respect to Ground ......................................................................... 4.0V
Positive Voltage on XTAL2, with respect to Ground ......................................................................... 2.5V
Negative Voltage on GPIO8, 10 & 11, with respect to Ground (see Note 7.2)...............................-0.5V
Negative Voltage on any pin, with respect to Ground .....................................................................-0.5V
o
to +150oC
o
C
Maximum V
Maximum V
*Stresses above the specified parameters could cause permanent damage to the device. This is a
stress rating only and functional operation of the device at any other condition above those indicated
in the operation sections of this specification is not implied.
Note 7.1 When powering this device from laboratory or system power supplies, it is important that
Note 7.2 When internal power FET operation of these pins is enabled, these pins may be
DD18, VDD18PLL
DD33, VDDA33
the Absolute Maximum Ratings not be exceeded or device failure can result. Some power
supplies exhibit voltage spikes on their outputs when the AC power is switched on or off.
In addition, voltage transients on the AC power line may appear on the DC output. When
this possibility exists, it is suggested that a clamp circuit be used.
simultaneously shorted to ground or any voltage up to 3.63V indefinitely, without damage
to the device as long as V
.............................................................................................................. +2.5V
................................................................................................................. +4.6V
and V
DD33
7.2 DC Electrical Characteristics
(TA = 0°C - 70°C, V
PARAMETER SYMBOL MIN TYP MAX UNITS COMMENTS
I,IPU & IPD Type Input Buffer
Low Input Level
DD33, VDDA33
= +3.3 V ± 0.3 V, V
V
ILI
are less than 3.63V and TA is less than 70°C.
DDA33
DD18, VDD18PLL
0.8 V
= +1.8 V ± 10%,)
TTL Levels
High Input Level
Pull Down
Pull Up
SMSC USB2227/USB2228 21 Revision 1.77 (06-13-05)
V
PD
PU
IHI
2.0
72
58
V
µA
µA
DATASHEET
PARAMETER SYMBOL MIN TYP MAX UNITS COMMENTS
IS Type Input Buffer
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
Low Input Level
High Input Level
Hysteresis
ICLK Input Buffer
Low Input Level
High Input Level
Input Leakage
(All I and IS buffers)
Low Input Leakage
High Input Leakage
O8. O8PU & 08PD Type
Buffer
Low Output Level
High Output Level
V
V
V
V
V
HYSI
ILCK
IHCK
I
I
V
V
ILI
IHI
IL
IH
OL
OH
2.0
2.2
-10
-10
V
DD33
- 0.4
500
0.8 V
0.4 V
+10
+10
0.4
V
mV
V
µA
mA
V
V
TTL Levels
VIN = 0
= V
V
IN
DD33
= 8 mA @
I
OL
V
= 3.3V
DD33
= -8mA @
I
OH
V
= 3.3V
DD33
Output Leakage
Pull Down
Pull Up
I/O8, I/O8PU & I/O8PD Type
Buffer
Low Output Level
High Output Level
Output Leakage
Pull Down
Pull Up
PD
PU
V
V
PD
PU
I
OL
-10
+10
µA
= 0 to V
V
IN
DD33
(Note 7.3)
72
58
OL
OH
I
OL
V
–
-10
DD33
0.4
0.4
+10
µA
µA
V
V
µA
= 8 mA @
I
OL
= 3.3V
V
DD33
= -8 mA @
I
OH
= 3.3V
V
DD33
= 0 to V
V
IN
DD33
(Note 7.3)
72
58
µA
µA
Revision 1.77 (06-13-05) 22 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
PARAMETER SYMBOL MIN TYP MAX UNITS COMMENTS
IO-U
(Note 7.4)
Integrated Power FET for
GPIO8 & GPIO10 (and
GPIO11 when used with
Firmware version -03 or
older)
Output Current
Short Circuit Current Limit
On Resistance
Output Voltage Rise Time
Integrated Power FET for
GPIO11 (only when used
with Firmware version -04 or
later)
Output Current
Short Circuit Current Limit
On Resistance
Output Voltage Rise Time
Supply Current Unconfigured I
Supply Current Active
(Full Speed)
I
OUT
I
SC
R
DSON
t
DSON
I
OUT
I
SC
R
DSON
t
DSON
CCINIT
I
CC
100
200
mA
140
2.1
800
mA
Ω
µs
mA
181
2.1
800
mA
Ω
µs
55 80 mA
75 90 mA
GPIO8 or 10;
Vdrop
= 0.23V
FET
GPIO8 or 10;
FET
= 0V
Vout
GPIO8 or 10;
= 70mA
I
FET
GPIO8 or 10;
= 10µF
C
LOAD
GPIO11;
Vdrop
= 0.46V
FET
GPIO11;
FET
= 0V
Vout
GPIO11;
= 70mA
I
FET
GPIO11;
= 10µF
C
LOAD
Supply Current Active
(High Speed)
Supply Current Standby I
I
CC
CSBY
75 100 mA
305 420 µA
Note 7.3 Output leakage is measured with the current pins in high impedance.
Note 7.4 See Appendix A for USB DC electrical characteristics.
Note 7.5 The Maximum power dissipation parameters of the package should not be exceeded
Note 7.6 The assignment of each Integrated Card Power FET to a designated Card Connector is
controlled by both firmware and the specific board implementation. Firmware will default to
the settings listed in Table 9.1, “GPIO Usage (ROM Rev 0x00),” on page 26.
SMSC USB2227/USB2228 23 Revision 1.77 (06-13-05)
DATASHEET
7.3 Capacitance
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
TA = 25°C; fc = 1MHz; V
PARAMETER SYMBOL MIN TYP MAX UNIT TEST CONDITION
Clock Input Capacitance C
Input Capacitance C
Output Capacitance C
DD18, VDD18PLL
IN
IN
OUT
= 1.8V
LIMITS
20 pF All pins except USB pins
(and pins under test tied to
AC ground)
10 pF
20 pF
Revision 1.77 (06-13-05) 24 SMSC USB2227/USB2228
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Datasheet
Chapter 8 Package Outline
Figure 8.1 USB2227/USB2228 128-Pin VTQFP Package Outline
Table 8.1 USB2227/USB2228 128-Pin VTQFP Package Parameters
MIN NOMINAL MAX REMARKS
A ~ ~ 1.20 Overall Package Height
A1 0.05 ~ 0.15 Standoff
A2 0.95 ~ 1.05 Body Thickness
D 15.80 ~ 16.20 X Span
D1 13.80 ~ 14.20 X body Size
E 15.80 ~ 16.20 Y Span
E1 13.80 ~ 14.20 Y body Size
H 0.09 ~ 0.20 Lead Frame Thickness
L 0.45 0.60 0.75 Lead Foot Length
L1 ~ 1.00 ~ Lead Length
e 0.40 Basic Lead Pitch
q0
W 0.13 0.18 0.23 Lead Width
R1 0.08 ~ ~ Lead Shoulder Radius
R2 0.08 ~ 0.20 Lead Foot Radius
ccc ~ ~ 0.08 Coplanarity
o
Notes:
1. Controlling Unit: millimeter.
2. Tolerance on the true position of the leads is ± 0.035 mm maximum.
Package body dimensions D1 and E1 do not include the mold protrusion.
3. Maximum mold protrusion is 0.25 mm.
4. Dimension for foot length L measured at the gauge plane 0.25 mm above the seating plane.
5. Details of pin 1 identifier are optional but must be located within the zone indicated.
~7
o
Lead Foot Angle
SMSC USB2227/USB2228 25 Revision 1.77 (06-13-05)
DATASHEET
4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs
Chapter 9 GPIO Usage
Table 9.1 GPIO Usage (ROM Rev 0x00)
ACTIVE
NAME
LEVEL SYMBOL DESCRIPTION AND NOTE
Datasheet
GPIO1 H Flash Media Activity LED/
xD_Door
GPIO2 H EE_CS Serial EE PROM chip select
GPIO3 H V_BUS USB V bus detect
GPIO4 H EE_DIN/EE_DOUT/xDID Serial EE PROM input/output and xD
GPIO5 H HS_IND/SD_CD HS Indicator LED or SD Card Detect
GPIO6 H A16/ROMEN A16 address line connect for DFU or
GPIO7 H EE_CLK/
UNCONF_LED
GPIO8 L MS_PWR_CTRL/
CRD_PWR0
GPIO9 L CF_PWR_CTRL CompactFlash Card Power Control
GPIO10 L SM_PWR_CTRL/
CRD_PWR1
GPIO11 L SD/MMC_PWR_CTRL/
CRD_PWR2
Indicates media activity. Media or USB
cable must not be removed with LED lit.
Also may be used for xD Door
functionality
Identify
Switch input
debug LED indicator optional.
Serial EE PROM clock output or
Unconfigured LED.
Memory Stick Card Power Control, or
Internal Power FET0.
SmartMedia Card Power Control, or
Internal Power FET1.
SD/MMC Card Power Control, or
Internal Power FET2.
GPIO12 H MS_ACT_IND/
Media Activity
GPIO13 H CF_ACT_IND CompactFlash Activity Indicator
GPIO14 H SM_ACT_IND SmartMedia Activity Indicator
GPIO15 H SD/MMC_ACT_IND SD/MMC Activity Indicator
Revision 1.77 (06-13-05) 26 SMSC USB2227/USB2228
Memory Stick Activity Indicator, or
Media Activity LED.
DATASHEET
Loading...
