SMSC LAN9512 User Manual

Download

LAN9512

USB Hub with Integrated 10/100 Ethernet Controller

PRODUCT FEATURES

Highlights

 Two downstream ports, one upstream port

— Two integrated downstream USB 2.0 PHYs — One integrated upstream USB 2.0 PHY

 Integrated 10/100 Ethernet MAC with full-duplex

support

 Integrated 10/100 Ethernet PHY with HP Auto-MDIX  Implements Reduced Power Operating Modes  Minimized BOM Cost

— Single 25 MHz crystal (Eliminates cost of separate

crystals for USB and Ethernet)

— Built-in Power-On-Reset (POR) circuit (Eliminates

requirement for external passive or active reset)

Target Applications

 Desktop PCs  Notebook PCs  Printers  Game Consoles  Embedded Systems  Docking Stations

Key Benefits

 USB Hub

— Fully compliant with Universal Serial Bus Specification

Revision 2.0

— HS (480 Mbps), FS (12 Mbps), and LS (1.5 Mbps)

compatible — Two downstream ports, one upstream port — Port mapping and disable support — Port Swap: Programmable USB diff-pair pin location — PHY Boost: Programmable USB signal drive strength — Select presence of a permanently hardwired USB

peripheral device on a port by port basis — Advanced power saving features — Downstream PHY goes into low power mode when port

power to the port is disabled — Full Power Management with individual or ganged

power control of each downstream port. — Integrated USB termination Pull-up/Pull-down resistors — Internal short circuit protection of USB differential signal

pins

SMSC LAN9512 Revision 1.0 (04-20-09)

 High-Performance 10/100 Ethernet Controller

— Fully compliant with IEEE802.3/802.3u — Integrated Ethernet MAC and PHY — 10BASE-T and 100BASE-TX support — Full- and half-duplex support with flow control — Preamble generation and removal — Automatic 32-bit CRC generation and checking — Automatic payload padding and pad removal — Loop-back modes — TCP/UDP checksum offload support — Flexible address filtering modes

– One 48-bit perfect address – 64 hash-filtered multicast addresses – Pass all multicast – Promiscuous mode – Inverse filtering

– Pass all incoming with status report — Wakeup packet support — Integrated Ethernet PHY

– Auto-negotiation

– Automatic polarity detection and correction

– HP Auto-MDIX

– Energy Detect

 Power and I/Os

— Three PHY LEDs — Eight GPIOs — Supports bus-powered and self-powered operation — Internal 1.8v core supply regulator — External 3.3v I/O supply

 Miscellaneous features

— Optional EEPROM — Optional 24MHz reference clock output for partner hub — IEEE 1149.1 (JTAG) Boundary Scan

 Software

— Windows 2000/XP/Vista Driver — Linux Driver — Win CE Driver —MAC OS Driver — EEPROM Utility

 Packaging

— 64-pin QFN, lead-free RoHS compliant

 Environmental

— Commercial Temperature Range (0°C to +70°C) — ±8kV HBM without External Protection Devices — ±8kV contact mode (IEC61000-4-2) — ±15kV air-gap discharge mode (IEC61000-4-2)

Datasheet

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

ORDER NUMBERS:

LAN9512-JZX FOR 64-PIN, QFN LEAD-FREE ROHS COMPLIANT PACKAGE (0 TO +70°C TEMP RANGE)

80 ARKAY DRIVE, HAUPPAUGE, NY 11788 (631) 435-6000, FAX (631) 273-3123

Circuit diagrams and other information relating to SMSC products are included as a means of illustrating typical applications. Consequently, complete information sufficient for construction purposes is not necessarily given. Although the information has been checked and is believed to be accurate, no responsibility is assumed for inaccuracies. SMSC reserves the right to make changes to specifications and product descriptions at any time without notice. Contact your local SMSC sales office to obtain the latest specifications before placing your product order. The provision of this information does not convey to the purchaser of the described semiconductor devices any licenses under any patent rights or other intellectual property rights of SMSC or others. All sales are expressly conditional on your agreement to the terms and conditions of the most recently dated version of SMSC's standard Terms of Sale Agreement dated before the date of your order (the "Terms of Sale Agreement"). The product may contain design defects or errors known as anomalies which may cause the product's functions to deviate from published specifications. Anomaly sheets are available upon request. SMSC products are not designed, intended, authorized or warranted for use in any life support or other application where product failure could cause or contribute to personal injury or severe property damage. Any and all such uses without prior written approval of an Officer of SMSC and further testing and/or modification will be fully at the risk of the customer. Copies of this document or other SMSC literature, as well as the Terms of Sale Agreement, may be obtained by visiting SMSC’s website at http://www.smsc.com. SMSC is a registered trademark of Standard Microsystems Corporation (“SMSC”). Product names and company names are the trademarks of their respective holders.

SMSC DISCLAIMS AND EXCLUDES ANY AND ALL WARRANTIES, INCLUDING WITHOUT LIMITATION ANY AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND AGAINST INFRINGEMENT AND THE LIKE, AND ANY AND ALL WARRANTIES ARISING FROM ANY COURSE OF DEALING OR USAGE OF TRADE. IN NO EVENT SHALL SMSC BE LIABLE FOR ANY DIRECT, INCIDENTAL, INDIRECT, SPECIAL, PUNITIVE, OR CONSEQUENTIAL DAMAGES; OR FOR LOST DATA, PROFITS, SAVINGS OR REVENUES OF ANY KIND; REGARDLESS OF THE FORM OF ACTION, WHETHER BASED ON CONTRACT; TORT; NEGLIGENCE OF SMSC OR OTHERS; STRICT LIABILITY; BREACH OF WARRANTY; OR OTHERWISE; WHETHER OR NOT ANY REMEDY OF BUYER IS HELD TO HAVE FAILED OF ITS ESSENTIAL PURPOSE, AND WHETHER OR NOT SMSC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Revision 1.0 (04-20-09) 2 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table of Contents

Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1.2 USB Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1.3 Ethernet Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1.4 EEPROM Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1.5 Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1.6 Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Chapter 2 Pin Description and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.1 Port Power Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.1.1 Port Power Control Using a USB Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.1.2 Port Power Control Using a Poly Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.2 Buffer Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Chapter 3 EEPROM Controller (EPC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.1 EEPROM Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.1.1 Hub Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3.2 EEPROM Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

3.3 EEPROM Auto-Load. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

3.4 An Example of EEPROM Format Interpretation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Chapter 4 Operational Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.1 Absolute Maximum Ratings*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.2 Operating Conditions** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.3 Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.3.1 Operational Current Consumption & Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.4 DC Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4.5 AC Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4.5.1 Equivalent Test Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4.5.2 Reset Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4.5.3 EEPROM Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

4.6 Clock Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Chapter 5 Package Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

5.1 64-QFN Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

SMSC LAN9512 3 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

List of Figures

Figure 1.1 Internal Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Figure 2.1 LAN9512 64-QFN Pin Assignments (TOP VIEW) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Figure 2.2 Port Power Control with USB Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Figure 2.3 Port Power Control with Poly Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 2.4 Port Power with Ganged Control with Poly Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Figure 4.1 Output Equivalent Test Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Figure 4.1 EEPROM Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Figure 5.1 LAN9512 64-QFN Package Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Figure 5.2 LAN9512 Recommended PCB Land Pattern. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Revision 1.0 (04-20-09) 4 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

List of Tables

Table 2.1 EEPROM Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 2.2 JTAG Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 2.3 Miscellaneous Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 2.4 USB Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Table 2.5 Ethernet PHY Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 2.6 I/O Power Pins, Core Power Pins, and Ground Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Table 2.7 No-Connect Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Table 2.8 64-QFN Package Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Table 2.9 Buffer Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Table 3.1 EEPROM Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Table 3.2 Configuration Flags Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Table 3.3 Hub Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Table 3.4 Config Data Byte 1 Register (CFG1) Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Table 3.5 Config Data Byte 2 Register (CFG2) Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Table 3.6 Config Data Byte 3 Register (CFG3) Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Table 3.7 Boost_Up Register (BOOSTUP) Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Table 3.8 Boost_3:2 Register (BOOST32) Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Table 3.9 Status/Command Register (STCD) Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Table 3.10 EEPROM Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Table 3.11 Dump of EEPROM Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Table 3.12 EEPROM Example - 256 Byte EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Table 4.1 Operational Current Consumption & Power Dissipation (VDD33IO = VDD33A = 3.3V) . . . . . 39

Table 4.2 I/O Buffer Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Table 4.3 100BASE-TX Transceiver Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Table 4.4 10BASE-T Transceiver Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Table 4.5 EEPROM Timing Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Table 4.6 LAN9512 Crystal Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Table 5.1 LAN9512 64-QFN Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

SMSC LAN9512 5 Revision 1.0 (04-20-09)

DATASHEET

Chapter 1 Introduction

TAP

Controller

EEPROM

Controller

10/100

Ethernet

Controller

USB 2.0

Hub

LAN9512

Ethernet

EEPROM

JTAG

USB

DP/DM

Downstream

USB PHY

Ethernet

PHY

Upstream

USB PHY

Downstream

USB PHY

USB

DP/DM

USB

DP/DM

1.1 Block Diagram

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

1.1.1 Overview

Figure 1.1 Internal Block Diagram

The LAN9512 is a high performance Hi-Speed USB 2.0 hub with a 10/100 Ethernet controller. With applications ranging from embedded systems, desktop PCs, notebook PCs, printers, game consoles, and docking stations, the LAN9512 is targeted as a high performance, low cost USB/Ethernet and USB/USB connectivity solution.

The LAN9512 contains an integrated USB 2.0 hub, two integrated downstream USB 2.0 PHYs, an integrated upstream USB 2.0 PHY, a 10/100 Ethernet PHY, a 10/100 Ethernet Controller, a TAP controller, and a EEPROM controller. A block diagram of the LAN9512 is provided in Figure 1.1.

The LAN9512 hub provides over 30 programmable features, including:

PortMap (also referred to as port remap) which provides flexible port mapping and disabling sequences. The downstream ports of the LAN9512 hub can be reordered or disabled in any sequence to support multiple platform designs’ with minimum effort. For any port that is disabled, the LAN9512 automatically reorders the remaining ports to match the USB host controller’s port numbering scheme.

PortSwap which adds per-port programmability to USB differential-pair pin locations. PortSwap allows direct alignment of USB signals (D+/D-) to connectors avoiding uneven trace length or crossing of the USB differential signals on the PCB.

PHYBoost which enables four programmable levels of USB signal drive strength in USB port transceivers. PHYBoost attempts to restore USB signal integrity that has been compromised by system level variables such as poor PCB layout, long cables, etc..

Revision 1.0 (04-20-09) 6 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

1.1.2 USB Hub

The integrated USB hub is fully compliant with the USB 2.0 Specification and will attach to a USB host as a Full-Speed Hub or as a Full-/High-Speed Hub. The hub supports Low-Speed, Full-Speed, and High-Speed (if operating as a High-Speed hub) downstream devices on all of the enabled downstream ports.

A dedicated Transaction Translator (TT) is available for each downstream facing port. This architecture ensures maximum USB throughput for each connected device when operating with mixed-speed peripherals.

The hub works with an external USB power distributed switch device to control V downstream ports, and to limit current and sense over-current conditions.

All required resistors on the USB ports are integrated into the hub. This includes all series termination resistors on D+ and D- pins and all required pull-down and pull-up resistors on D+ and D- pins. The over-current sense inputs for the downstream facing ports have internal pull-up resistors.

Two external ports are available for general USB device connectivity.

1.1.3 Ethernet Controller

The 10/100 Ethernet controller provides an integrated Ethernet MAC and PHY which are fully IEEE

802.3 10BASE-T and 802.3u 100BASE-TX compliant. The 10/100 Ethernet controller also supports numerous power management wakeup features, including “Magic Packet”, “Wake on LAN” and “Link Status Change”. These wakeup events can be programmed to initiate a USB remote wakeup.

The 10/100 Ethernet PHY integrates an IEEE 802.3 physical layer for twisted pair Ethernet applications. The PHY block includes support for auto-negotiation, full or half-duplex configuration, auto-polarity correction and Auto-MDIX. Minimal external components are required for the utilization of the integrated PHY.

The Ethernet controller implements four USB endpoints: Control, Interrupt, Bulk-in, and Bulk-out. The Bulk-in and Bulk-out Endpoints allow for Ethernet reception and transmission respectively. Implementation of vendor-specific commands allows for efficient statistics gathering and access to the Ethernet controller’s system control and status registers.

1.1.4 EEPROM Controller

switching to

BUS

The LAN9512 contains an EEPROM controller for connection to an external EEPROM. This allows for the automatic loading of static configuration data upon power-on reset, pin reset, or software reset. The EEPROM can be configured to load USB descriptors, USB device configuration, and the MAC address.

1.1.5 Peripherals

The LAN9512 also contains a TAP controller, and provides three PHY LED indicators, as well as eight general purpose I/O pins. All GPIOs can serve as remote wakeup events when LAN9512 is in a suspended state.

The integrated IEEE 1149.1 compliant TAP controller provides boundary scan via JTAG.

1.1.6 Power Management

The LAN9512 features three variations of USB suspend: SUSPEND0, SUSPEND1, and SUSPEND2. These modes allow the application to select the ideal balance of remote wakeup functionality and power consumption.

 SUSPEND0: Supports GPIO, “Wake On LAN”, and “Magic Packet” remote wakeup events. This

suspend state reduces power by stopping the clocks of the MAC and other internal modules.

SMSC LAN9512 7 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

 SUSPEND1: Supports GPIO and “Link Status Change” for remote wakeup events. This suspend

state consumes less power than SUSPEND0.

 SUSPEND2: Supports only GPIO assertion for a remote wakeup event. This is the default suspend

mode for the LAN9512.

Revision 1.0 (04-20-09) 8 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

NOTE: Exposed pad (VSS) on bottom of package must be connected to ground

NOTE: When HP Auto-MDIX is activated, the TXN/TXP pins can function as RXN/RXP and vice-versa

EXRES

TEST4

TDO

PRTCTL2

TEST1

nRESET

VBUS_DET

VDD33A

USBDP3

USBDM3

USBDP2

USBDM2

VDD33IO

CLK24_OUT

CLK24_EN

GPIO7

GPIO6

AUTOMDIX_EN

TEST3

VDD33IO

VDD18CORE

GPIO5

GPIO4

GPIO3

TEST2

VDD33A

RXP

RXN

VDD33A

TXP

TXN

VDD33A

USBDM0

USBDP0

VDD18USBPLL

USBRBIAS

TDI

TMS

nTRST

VDD33IO

EEDI

EEDO

EECS

EECLK

nSPD_LED/GPIO2

nLNKA_LED/GPIO1

nFDX_LED/GPIO0

VDD33IO

VDD33A

VDD33IO

VDD18ETHPLL

TCK

VDD18CORE

PRTCTL3

VSS

SMSC

LAN9512

64 PIN QFN

(TOP VIEW)

Datasheet

Chapter 2 Pin Description and Configuration

Figure 2.1 LAN9512 64-QFN Pin Assignments (TOP VIEW)

SMSC LAN9512 9 Revision 1.0 (04-20-09)

DATASHEET

Table 2.1 EEPROM Pins

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

NUM PINS NAME SYMBOL

EEPROM Data

NUM PINS NAME SYMBOL

EEPROM Data

Out

EEPROM Chip

Select

EEPROM Clock EECLK O8 This pin drives the EEPROM clock of the external

JTAG Test Port

Reset

JTAG Test

Mode Select

EEDI IS

EEDO O8 This pin drives the EEDI input of the external

EECS O8 This pin drives the chip select output of the external

nTRST IS This active low pin functions as the JTAG test port

TMS IS This pin functions as the JTAG test mode select.

BUFFER

TYPE DESCRIPTION

This pin is driven by the EEDO output of the

(PD)

Table 2.2 JTAG Pins

BUFFER

TYPE DESCRIPTION

external EEPROM.

EEPROM.

reset input.

Note: This pin should be tied high if it is not

used.

JTAG Test Data

NUM PINS NAME SYMBOL

Input

JTAG Test Data

Out

JTAG Test

Clock

System Reset nRESET IS This active low pin allows external hardware to

Ethernet

Full-Duplex

Indicator LED

General

Purpose I/O 0

TDI IS This pin functions as the JTAG data input.

TDO O12 This pin functions as the JTAG data output.

TCK IS This pin functions as the JTAG test clock. The

nFDX_LED OD12

GPIO0 IS/O12/

maximum operating frequency of this clock is 25MHz.

Table 2.3 Miscellaneous Pins

BUFFER

TYPE DESCRIPTION

reset the device.

Note: This pin should be tied high if it is not

This pin is driven low (LED on) when the Ethernet

(PU)

OD12

(PU)

link is operating in full-duplex mode.

This General Purpose I/O pin is fully programmable as either a push-pull output, an open-drain output, or a Schmitt-triggered input.

used.

Revision 1.0 (04-20-09) 10 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 2.3 Miscellaneous Pins (continued)

NUM PINS NAME SYMBOL

Ethernet Link

Activity Indicator

Purpose I/O 1

Ethernet Speed

Indicator LED

Purpose I/O 2

Purpose I/O 3

LED

General

nLNKA_LED OD12

GPIO1 IS/O12/

nSPD_LED OD12

GPIO2 IS/O12/

GPIO3 IS/O8/

BUFFER

TYPE DESCRIPTION

This pin is driven low (LED on) when a valid link is

(PU)

OD12

(PU)

OD12

(PU)

OD8 (PU)

detected. This pin is pulsed high (LED off) for 80mS whenever transmit or receive activity is detected. This pin is then driven low again for a minimum of 80mS, after which time it will repeat the process if TX or RX activity is detected. Effectively, LED2 is activated solid for a link. When transmit or receive activity is sensed, LED2 will function as an activity indicator.

This General Purpose I/O pin is fully programmable as either a push-pull output, an open-drain output, or a Schmitt-triggered input.

This pin is driven low (LED on) when the Ethernet operating speed is 100Mbs, or during autonegotiation. This pin is driven high during 10Mbs operation, or during line isolation.

This General Purpose I/O pin is fully programmable as either a push-pull output, an open-drain output, or a Schmitt-triggered input.

General

Purpose I/O 4

General

Purpose I/O 5

General

Purpose I/O 6

General

Purpose I/O 7

Detect

Upstream

VBUS Power

Auto-MDIX

Enable

GPIO4 IS/O8/

OD8 (PU)

GPIO5 IS/O8/

OD8 (PU)

GPIO6 IS/O8/

OD8 (PU)

GPIO7 IS/O8/

OD8 (PU)

VBUS_DET IS_5V This pin detects the state of the upstream bus

AUTOMDIX_EN IS Determines the default Auto-MDIX setting.

This General Purpose I/O pin is fully programmable as either a push-pull output, an open-drain output, or a Schmitt-triggered input.

power. The Hub monitors VBUS_DET to determine when to assert the USBDP0 pin's internal pull-up resistor (signaling a connect event).

For bus powered hubs, this pin must be tied to VDD33IO.

For self powered hubs, refer to the LAN9512 reference schematics.

0 = Auto-MDIX is disabled. 1 = Auto-MDIX is enabled.

SMSC LAN9512 11 Revision 1.0 (04-20-09)

Test 1 TEST1 - Used for factory testing, this pin must always be left

unconnected.

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Table 2.3 Miscellaneous Pins (continued)

Datasheet

NUM PINS NAME SYMBOL

Test 2 TEST2 - Used for factory testing, this pin must always be

Test 3 TEST3 - Used for factory testing, this pin must always be

24 MHz Clock

Enable

24 MHz Clock CLK24_OUT 08 This pin outputs a 24 MHz clock that can be used

Test 4 TEST4 - Used for factory testing, this pin must always be left

Upstream

USB DMINUS 0

CLK24_EN IS This pin enables the generation of the 24 MHz

USBDM0 AIO Upstream USB DMINUS signal.

BUFFER

TYPE DESCRIPTION

connected to VSS for proper operation.

connected to VDD33IO for proper operation.

clock on the CLK_24_OUT pin.

a reference clock for a partner hub.

unconnected.

Table 2.4 USB Pins

BUFFER

TYPE DESCRIPTION

USB DMINUS 2

USB DPLUS 2

USB DMINUS 3

USB DPLUS 3

USB Port Power

Upstream

USB

DPLUS 0

Downstream

Control 2

Control 3

USBDP0 AIO Upstream USB DPLUS signal.

USBDM2 AIO Downstream USB peripheral 2 DMINUS signal.

USBDP2 AIO Downstream USB peripheral 2 DPLUS signal.

USBDM3 AIO Downstream USB peripheral 3 DMINUS signal.

USBDP3 AIO Downstream USB peripheral 3 DPLUS signal.

PRTCTL2 IS/OD12

(PU)

PRTCTL3 IS/OD12

(PU)

When used as an output, this pin enables power to downstream USB peripheral 2.

When used as an input, this pin is used to sample the output signal from an external current monitor for downstream USB peripheral 2. An overcurrent condition is indicated when the signal is low.

Refer to Section 2.1 for additional information.

When used as an output, this pin enables power to downstream USB peripheral 3.

When used as an input, this pin is used to sample the output signal from an external current monitor for downstream USB peripheral 3. An overcurrent condition is indicated when the signal is low.

Refer to Section 2.1 for additional information.

Revision 1.0 (04-20-09) 12 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 2.4 USB Pins (continued)

NUM PINS NAME SYMBOL

1 Crystal Output XO OCLK External 25 MHz crystal output.

NUM PINS NAME SYMBOL

External USB

Bias Resistor

USB PLL +1.8V

Power Supply

Crystal Input XI ICLK External 25 MHz crystal input.

Ethernet TX

Data Out

Negative

USBRBIAS AI Used for setting HS transmit current level and on-

VDD18USBPLL P Refer to the LAN9512 reference schematics for

Table 2.5 Ethernet PHY Pins

TXN AIO Negative output of the Ethernet transmitter. The

BUFFER

TYPE DESCRIPTION

chip termination impedance. Connect to an external 12K 1.0% resistor to ground.

additional connection information.

Note: This pin can also be driven by a single-

ended clock oscillator. When this method is used, XO should be left unconnected

BUFFER

TYPE DESCRIPTION

transmit data outputs may be swapped internally with receive data inputs when Auto-MDIX is enabled.

Data In Positive

+3.3V Analog

Power Supply

External PHY

Ethernet TX

Data Out

Positive

Ethernet RX

Data In

Negative

Ethernet RX

Bias Resistor

Ethernet PLL +1.8V Power

Supply

TXP AIO Positive output of the Ethernet transmitter. The

transmit data outputs may be swapped internally with receive data inputs when Auto-MDIX is enabled.

RXN AIO Negative input of the Ethernet receiver. The receive

data inputs may be swapped internally with transmit data outputs when Auto-MDIX is enabled.

RXP AIO Positive input of the Ethernet receiver. The receive

data inputs may be swapped internally with transmit data outputs when Auto-MDIX is enabled.

VDD33A P Refer to the LAN9512 reference schematics for

connection information.

EXRES AI Used for the internal bias circuits. Connect to an

external 12.4K 1.0% resistor to ground.

VDD18ETHPLL P Refer to the LAN9512 reference schematics for

additional connection information.

SMSC LAN9512 13 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Table 2.6 I/O Power Pins, Core Power Pins, and Ground Pad

Datasheet

NUM PINS NAME SYMBOL

+3.3V I/O

Power

Digital Core

+1.8V Power

Supply Output

Note

2.1

NUM PINS NAME SYMBOL

Ground VSS P Ground

Note 2.1 Exposed pad on package bottom (Figure 2.1).

VDD33IO P +3.3V Power Supply for I/O Pins.

VDD18CORE P +1.8 V power from the internal core voltage

BUFFER

TYPE DESCRIPTION

Refer to the LAN9512 reference schematics for connection information.

regulator. All VDD18CORE pins must be tied together for proper operation.

Refer to the LAN9512 reference schematics for connection information.

Table 2.7 No-Connect Pins

BUFFER

TYPE DESCRIPTION

No Connect NC - These pins must be left floating for normal device

operation

Revision 1.0 (04-20-09) 14 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 2.8 64-QFN Package Pin Assignments

NUM PIN NAME

1 USBDM2 17 NC 33 VDD33IO 49 VDD33A

2 USBDP2 18 NC 34 TEST2 50 EXRES

3 USBDM3 19 VDD33IO 35 GPIO3 51 VDD33A

4 USBDP3 20 nFDX_LED/

5 VDD33A 21 nLNKA_LED/

6 NC 22 nSPD_LED/

7 NC 23 EECLK 39 VDD33IO 55 TXP

8 NC 24 EECS 40 TEST3 56 TXN

9 NC 25 EEDO 41 AUTOMDIX_EN 57 VDD33A

10 VDD33A 26 EEDI 42 GPIO6 58 USBDM0

11 VBUS_DET 27 VDD33IO 43 GPIO7 59 USBDP0

12 nRESET 28 nTRST 44 CLK24_EN 60 XO

NUM PIN NAME

GPIO0

GPIO1

GPIO2

NUM PIN NAME

36 GPIO4 52 RXP

37 GPIO5 53 RXN

38 VDD18CORE 54 VDD33A

NUM PIN NAME

13 TEST1 29 TMS 45 CLK24_OUT 61 XI

14 PRTCTL2 30 TDI 46 VDD33IO 62 VDD18USBPLL

15 VDD18CORE 31 TDO 47 TEST4 63 USBRBIAS

16 PRTCTL3 32 TCK 48 VDD18ETHPLL 64 VDD33A

MUST BE CONNECTED TO VSS

EXPOSED PAD

SMSC LAN9512 15 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

USB Power

Switch

OCS

USB

Device

LAN9512

PRTCTL3

USB Power

Switch

OCS

USB

Device

PRTCTL2

2.1 Port Power Control

This section details the usage of the port power control pins PRTCTL[3:2].

2.1.1 Port Power Control Using a USB Power Switch

The LAN9512 has a single port power control and over-current sense signal for each downstream port. When disabling port power the driver will actively drive a ‘0’. To avoid unnecessary power dissipation, the internal pull-up resistor will be disabled at that time. When port power is enabled, the output driver is disabled and the pull-up resistor is enabled, creating an open drain output. If there is an over-current situation, the USB Power Switch will assert the open drain OCS signal. The schmitt trigger input will recognize this situation as a low. The open drain output does not interfere. The overcurrent sense filter handles the transient conditions, such as low voltage, while the device is powering up.

Datasheet

Figure 2.2 Port Power Control with USB Power Switch

Revision 1.0 (04-20-09) 16 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

USB

Device

PRTCTL3

Poly Fuse

LAN9512

USB

Device

PRTCTL2

Poly Fuse

Datasheet

2.1.2 Port Power Control Using a Poly Fuse

When using theLAN9512 with a poly fuse, an external diode must be used (See Figure 2.3). When disabling port power, the driver will drive a ‘0’. This procedure will have no effect since the external diode will isolate the pin from the load. When port power is enabled, the output driver is disabled and the pull-up resistor is enabled, which creates an open drain output. This means that the pull-up resistor is providing 3.3 volts to the anode of the diode. If there is an over-current situation, the poly fuse will open. This will cause the cathode of the diode to go to 0 volts. The anode of the diode will be at 0.7 volts, and the Schmidt trigger input will register this as a low, resulting in an overcurrent detection. The open drain output does not interfere.

Figure 2.3 Port Power Control with Poly Fuse

SMSC LAN9512 17 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

USB

Device

Poly Fuse

USB

Device

PRTCTL2

LAN9512

PRTCTL3

Datasheet

Many customers use a single poly fuse to power all their devices. For the ganged situation, all power control pins must be tied together.

Figure 2.4 Port Power with Ganged Control with Poly Fuse

Revision 1.0 (04-20-09) 18 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

2.2 Buffer Types

Table 2.9 Buffer Types

BUFFER TYPE DESCRIPTION

IS Schmitt-triggered Input

IS_5V 5V Tolerant Schmitt-triggered Input

O8 Output with 8mA sink and 8mA source

OD8 Open-drain output with 8mA sink

O12 Output with 12mA sink and 12mA source

OD12 Open-drain output with 12mA sink

PU 50uA (typical) internal pull-up. Unless otherwise noted in the pin description, internal pull-

PD 50uA (typical) internal pull-down. Unless otherwise noted in the pin description, internal

AI Analog input

AIO Analog bi-directional

ICLK Crystal oscillator input pin

OCLK Crystal oscillator output pin

P Power pin

ups are always enabled.

Note: Internal pull-up resistors prevent unconnected inputs from floating. Do not rely on

internal resistors to drive signals external to LAN9512. When connected to a load that must be pulled high, an external resistor must be added.

pull-downs are always enabled.

Note: Internal pull-down resistors prevent unconnected inputs from floating. Do not rely

on internal resistors to drive signals external to LAN9512. When connected to a load that must be pulled low, an external resistor must be added.

SMSC LAN9512 19 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Chapter 3 EEPROM Controller (EPC)

LAN9512 may use an external EEPROM to store the default values for the USB descriptors and the MAC address. The EEPROM controller supports most “93C46” type EEPROMs. A total of nine address bits are used to support 256/512 byte EEPROMs.

Note: A 3-wire style 2K/4K EEPROM that is organized for 256/512 x 8-bit operation must be used.

The MAC address is used as the default Ethernet MAC address and is loaded into the MAC’s ADDRH and ADDRL registers. If a properly configured EEPROM is not detected, it is the responsibility of the Host LAN Driver to set the IEEE addresses.

After a system-level reset occurs, the device will load the default values from a properly configured EEPROM. The device will not accept USB transactions from the Host until this process is completed.

The EEPROM controller also allows the Host system to read, write and erase the contents of the Serial EEPROM.

3.1 EEPROM Format

Table 3.1 illustrates the format in which data is stored inside of the EEPROM.

Datasheet

Note the EEPROM offsets are given in units of 16-bit word offsets. A length field with a value of zero indicates that the field does not exist in the EEPROM. The device will use the field’s HW default value in this case.

Note: For Device Descriptors, the only valid values for the length are 0 and 18.

Note: For Configuration and Interface Descriptors, the only valid values for the length are 0 and 18.

Note: The EEPROM programmer must ensure that if a String Descriptor does not exist in the

EEPROM, the referencing descriptor must contain 00h for the respective string index field.

Note: If no Configuration Descriptor is present in the EEPROM, then the Configuration Flags affect

the values of bmAttributes and bMaxPower in the Ethernet Controller Configuration Descriptor.

Note: If all String Descriptor lengths are zero, then a Language ID will not be supported.

Table 3.1 EEPROM Format

EEPROM ADDRESS EEPROM CONTENTS

00h 0xA5

01h MAC Address [7:0]

02h MAC Address [15:8]

03h MAC Address [23:16]

04h MAC Address [31:24]

05h MAC Address [39:32]

06h MAC Address [47:40]

07h Full-Speed Polling Interval for Interrupt Endpoint

08h Hi-Speed Polling Interval for Interrupt Endpoint

Revision 1.0 (04-20-09) 20 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 3.1 EEPROM Format (continued)

09h Configuration Flags

0Ah Language ID Descriptor [7:0]

0Bh Language ID Descriptor [15:8]

0Ch Manufacturer ID String Descriptor Length (bytes)

0Dh Manufacturer ID String Descriptor EEPROM Word Offset

0Eh Product Name String Descriptor Length (bytes)

0Fh Product Name String Descriptor EEPROM Word Offset

10h Serial Number String Descriptor Length (bytes)

11h Serial Number String Descriptor EEPROM Word Offset

12h Configuration String Descriptor Length (bytes)

13h Configuration String Descriptor Word Offset

14h Interface String Descriptor Length (bytes)

15h Interface String Descriptor Word Offset

16h Hi-Speed Device Descriptor Length (bytes)

17h Hi-Speed Device Descriptor Word Offset

18h Hi-Speed Configuration and Interface Descriptor Length (bytes)

19h Hi-Speed Configuration and Interface Descriptor Word Offset

1Ah Full-Speed Device Descriptor Length (bytes)

1Bh Full-Speed Device Descriptor Word Offset

1Ch Full-Speed Configuration and Interface Descriptor Length (bytes)

1Dh Full-Speed Configuration and Interface Descriptor Word Offset

1Eh-1Fh RESERVED

20h Vendor ID LSB Register (VIDL)

21h Vendor ID MSB Register (VIDM)

22h Product ID LSB Register (PIDL)

23h Product ID MSB Register (PIDM)

24h Device ID LSB Register (DIDL)

25h Device ID MSB Register (DIDM)

26h Config Data Byte 1 Register (CFG1)

27h Config Data Byte 2 Register (CFG2)

28h Config Data Byte 3 Register (CFG3)

29h Non-Removable Devices Register (NRD)

2Ah Port Disable (Self) Register (PDS)

2Bh Port Disable (Bus) Register (PDB)

SMSC LAN9512 21 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Table 3.1 EEPROM Format (continued)

2Ch Max Power (Self) Register (MAXPS)

2Dh Max Power (Bus) Register (MAXPB)

2Eh Hub Controller Max Current (Self) Register (HCMCS)

2Fh Hub Controller Max Current (Bus) Register (HCMCB)

30h Power-on Time Register (PWRT)

31h Boost_Up Register (BOOSTUP)

32h RESERVED

33h Boost_3:2 Register (BOOST32)

34h RESERVED

35h Port Swap Register (PRTSP)

36h Port Remap 12 Register (PRTR12)

37h Port Remap 3 Register (PRTR3)

Datasheet

38h RESERVED

39h Status/Command Register (STCD)

Note: EEPROM byte addresses past 39h can be used to store data for any purpose.

Table 3.2 describes the Configuration Flags

Table 3.2 Configuration Flags Description

BIT NAME DESCRIPTION

7:3 RESERVED 00000b

2 Remote Wakeup Support 0 = The device does not support remote wakeup.

1 RESERVED 0b

0 Power Method 0 = The device Controller is bus powered.

1 = The device supports remote wakeup.

1 = The device Controller is self powered.

Revision 1.0 (04-20-09) 22 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

3.1.1 Hub Configuration

EEPROM offsets 20h through 39h comprise the Hub Configuration parameters. Table 3.3 describes these parameters and their default ROM values (Values assumed if no valid EEPROM present).

Table 3.3 Hub Configuration

EEPROM

OFFSET DESCRIPTION DEFAULT

20h Vendor ID LSB Register (VIDL)

Least Significant Byte of the Vendor ID. This is a 16-bit value that uniquely identifies the Vendor of the user device (assigned by USB-Interface Forum).

21h Vendor ID MSB (VIDM)

Most Significant Byte of the Vendor ID. This is a 16-bit value that uniquely identifies the Vendor of the user device (assigned by USB-Interface Forum).

22h Product ID LSB Register (PIDL)

Least Significant Byte of the Product ID. This is a 16-bit value that the Vendor can assign that uniquely identifies this particular product (assigned by the OEM).

23h Product ID MSB Register (PIDM)

Most Significant Byte of the Product ID. This is a 16-bit value that the Vendor can assign that uniquely identifies this particular product (assigned by the OEM).

24h Device ID LSB Register (DIDL)

Least Significant Byte of the Device ID. This is a 16-bit device release number in BCD format (assigned by the OEM).

25h Device ID MSB Register (DIDM)

Most Significant Byte of the Device ID. This is a 16-bit device release number in BCD format (assigned by the OEM).

26h Config Data Byte 1 Register (CFG1)

Refer to Table 3.4, “Config Data Byte 1 Register (CFG1) Format,” on page 28 for details.

27h Config Data Byte 2 Register (CFG2)

Refer to Table 3.5, “Config Data Byte 2 Register (CFG2) Format,” on page 29 for details.

24h

04h

12h

95h

00h

Note 3.1

9Bh

18h

28h Config Data Byte 3 Register (CFG3)

Refer to Table 3.6, “Config Data Byte 3 Register (CFG3) Format,” on page 30 for details.

29h Non-Removable Devices Register (NRD)

Indicates which port(s) include non-removable devices.

0 = Port is removable 1 = Port is non-removable

Informs the host if one of the active ports has a permanent device that is not detachable from the Hub.

Note: The device must provide its own descriptor data.

Bit 7 = RESERVED Bit 6 = RESERVED Bit 5 = RESERVED Bit 4 = RESERVED Bit 3 = 1; Port 3 non-removable Bit 2 = 1; Port 2 non-removable Bit 1 = 1; Port 1 non-removable Bit 0 is RESERVED, always = 0b

Note: Bit 1 must be set to 1 by firmware for proper identification of the Ethernet

Controller as a non-removable device.

SMSC LAN9512 23 Revision 1.0 (04-20-09)

00h

02h

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 3.3 Hub Configuration (continued)

EEPROM

OFFSET DESCRIPTION DEFAULT

2Ah Port Disable (Self) Register (PDS)

Disables 1 or more ports.

0 = Port is available 1 = Port is disabled

During Self-Powered operation, this selects the ports which will be permanently disabled, and are not available to be enabled or enumerated by a host controller. The ports can be disabled in any order, the internal logic will automatically report the correct number of enabled ports to the USB host, and will reorder the active ports in order to ensure proper function.

Bit 7 = RESERVED Bit 6 = RESERVED Bit 5 = RESERVED Bit 4 = RESERVED Bit 3 = 1; Port 3 disabled Bit 2 = 1; Port 2 disabled Bit 1 = 1; Port 1 disabled Bit 0 is RESERVED, always = 0b

2Bh Port Disable (Bus) Register (PDB)

Disables 1 or more ports.

0 = Port is available 1 = Port is disabled

During Bus-Powered operation, this selects the ports which will be permanently disabled, and are not available to be enabled or enumerated by a host controller. The ports can be disabled in any order, the internal logic will automatically report the correct number of enabled ports to the USB host, and will reorder the active ports in order to ensure proper function.

30h

Bit 7 = RESERVED Bit 6 = RESERVED Bit 5 = RESERVED Bit 4 = RESERVED Bit 3 = 1; Port 3 disabled Bit 2 = 1; Port 2 disabled Bit 1 = 1; Port 1 disabled Bit 0 is RESERVED, always = 0b

2Ch Max Power (Self) Register (MAXPS)

Value in 2mA increments that the Hub consumes from an upstream port (VBUS) when operating as a self-powered hub. This value includes the hub silicon along with the combined power consumption (from VBUS) of all associated circuitry on the board. This value also includes the power consumption of a permanently attached peripheral if the hub is configured as a compound device, and the embedded peripheral reports 0mA in its descriptors.

Note: The USB2.0 Specification does not permit this value to exceed 100mA.

2Dh Max Power (Bus) Register (MAXPB)

Value in 2mA increments that the Hub consumes from an upstream port (VBUS) when operating as a bus-powered hub. This value includes the hub silicon along with the combined power consumption (from VBUS) of all associated circuitry on the board. This value also includes the power consumption of a permanently attached peripheral if the hub is configured as a compound device, and the embedded peripheral reports 0mA in its descriptors.

01h

00h

Revision 1.0 (04-20-09) 24 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 3.3 Hub Configuration (continued)

EEPROM

OFFSET DESCRIPTION DEFAULT

2Eh Hub Controller Max Current (Self) Register (HCMCS)

Value in 2mA increments that the Hub consumes from an upstream port (VBUS) when operating as a self-powered hub. This value includes the hub silicon along with the combined power consumption (from VBUS) of all associated circuitry on the board. This value does NOT include the power consumption of a permanently attached peripheral if the hub is configured as a compound device.

Note: The USB2.0 Specification does not permit this value to exceed 100mA.

2Fh Hub Controller Max Current (Bus) Register (HCMCB)

Value in 2mA increments that the Hub consumes from an upstream port (VBUS) when operating as a bus-powered hub. This value includes the hub silicon along with the combined power consumption (from VBUS) of all associated circuitry on the board. This value does NOT include the power consumption of a permanently attached peripheral if the hub is configured as a compound device.

30h Power-on Time Register (PWRT)

The length of time that it takes (in 2mS intervals) from the time the host initiated power-on sequence begins on a port until power is good on that port. System software uses this value to determine how long to wait before accessing a powered-on port.

31h Boost_Up Register (BOOSTUP)

Refer to Table 3.7, “Boost_Up Register (BOOSTUP) Format,” on page 30 for details.

32h RESERVED 00h

33h Boost_3:2 Register (BOOST32)

Refer to Table 3.8, “Boost_3:2 Register (BOOST32) Format,” on page 30 for details.

34h RESERVED 00h

35h Port Swap Register (PRTSP)

Swaps the Upstream and Downstream USB DP and DM pins for ease of board routing to devices and connectors.

01h

00h

32h

00h

0 = USB D+ functionality is associated with the DP pin and D- functionality is associated with the DM pin.

1 = USB D+ functionality is associated with the DM pin and D- functionality is associated with the DP pin.

Bit 7 = RESERVED Bit 6 = RESERVED Bit 5 = RESERVED Bit 4 = RESERVED Bit 3 = 1; Port 3 DP/DM is swapped Bit 2 = 1; Port 2 DP/DM is swapped Bit 1 = RESERVED Bit 0 = 1; Upstream Port DP/DM is swapped

SMSC LAN9512 25 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Bit [7:4] = 0000 Physical Port 2 is Disabled

0001 Physical Port 2 is mapped to Logical Port 1

0010 Physical Port 2 is mapped to Logical Port 2

0011 Physical Port 2 is mapped to Logical Port 3

All others RESERVED

Bit [3:0] = 0000 Physical Port 1 is Disabled

0001 Physical Port 1 is mapped to Logical Port 1

0010 Physical Port 1 is mapped to Logical Port 2

0011 Physical Port 1 is mapped to Logical Port 3

All others RESERVED

Datasheet

Table 3.3 Hub Configuration (continued)

EEPROM

OFFSET DESCRIPTION DEFAULT

36h Port Remap 12 Register (PRTR12)

When a hub is enumerated by a USB Host Controller, the hub is only permitted to report how many ports it has. The hub is not permitted to select a numerical range or assignment. The Host Controller will number the downstream ports of the hub starting with the number 1, up to the number of ports that the hub reported having.

The host’s port number is referred to as “Logical Port Number” and the physical port on the hub is the “Physical Port Number”. When remapping mode is enabled, (see

Port Re-Mapping Enable (PRTMAP_EN) bit in Config Data Byte 3 Register (CFG3) Format) the hub’s downstream port numbers can be remapped to different logical port

numbers (assigned by the host).

Note: The OEM must ensure that Contiguous Logical Port Numbers are used,

starting from #1 up to the maximum number of enabled ports. This ensures that the hub’s ports are numbered in accordance with the way a Host will communicate with the ports.

21h

Revision 1.0 (04-20-09) 26 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Bit [7:4] = - RESERVED

Bit [3:0] = 0000 Physical Port 3 is Disabled

0001 Physical Port 3 is mapped to Logical Port 1

0010 Physical Port 3 is mapped to Logical Port 2

0011 Physical Port 3 is mapped to Logical Port 3

All others RESERVED

Datasheet

Table 3.3 Hub Configuration (continued)

EEPROM

OFFSET DESCRIPTION DEFAULT

37h Port Remap 3 Register (PRTR3)

The host’s port number is referred to as “Logical Port Number” and the physical port on the hub is the “Physical Port Number”. When remapping mode is enabled (see

Port Re-Mapping Enable (PRTMAP_EN) bit in Config Data Byte 3 Register (CFG3) Format), the hub’s downstream port numbers can be remapped to different logical port

numbers (assigned by the host).

Note: The OEM must ensure that Contiguous Logical Port Numbers are used,

starting from #1 up to the maximum number of enabled ports, this ensures that the hub’s ports are numbered in accordance with the way a Host will communicate with the ports.

03h

38h RESERVED 00h

39h Status/Command Register (STCD)

SMSC LAN9512 27 Revision 1.0 (04-20-09)

Refer to Table 3.9, “Status/Command Register (STCD) Format,” on page 31 for details.

Note 3.1 Default value is dependent on device revision.

01h

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Table 3.4 Config Data Byte 1 Register (CFG1) Format

BITS DESCRIPTION DEFAULT

Datasheet

7 Self or Bus Power (SELF_BUS_PWR)

Selects between Self or Bus-Powered operation.

0 = Bus-Powered 1 = Self-Powered

The Hub is either Self-Powered (draws less than 2mA of upstream bus power) or Bus-Powered (limited to a 100mA maximum of upstream power prior to being configured by the host controller).

When configured as a Bus-Powered device, the SMSC Hub consumes less than 100mA of current prior to being configured. After configuration, the BusPowered SMSC Hub (along with all associated hub circuitry, any embedded devices if part of a compound device, and 100mA per externally available downstream port) must consume no more than 500mA of upstream VBUS current. The current consumption is system dependent, and the OEM must ensure that the USB2.0 specifications are not violated.

When configured as a Self-Powered device, <1mA of upstream VBUS current is consumed and all ports are available, with each port being capable of sourcing 500mA of current.

6 RESERVED 0b

5 High Speed Disable (HS_DISABLE)

Disables the capability to attach as either a High/Full-Speed device, and forces attachment as Full-Speed only (no High-Speed support).

0 = High-/Full-Speed 1 = Full-Speed-Only (High-Speed disabled)

4 Multiple TT Enable (MTT_ENABLE)

Enables one transaction translator per port operation.

Selects between a mode where only one transaction translator is available for all ports (Single-TT), or each port gets a dedicated transaction translator (Multi-TT) {Note: The host may force Single-TT mode only}.

0 = Single TT for all ports. 1 = One TT per port (multiple TT's supported)

3 EOP Disable (EOP_DISABLE)

Disables EOP generation of EOF1 when in Full-Speed mode. During FS operation only, this permits the Hub to send EOP if no downstream traffic is detected at EOF1. See Section 11.3.1 of the USB 2.0 Specification for additional details.

Note: Generation of an EOP at the EOF1 point may prevent a Host

controller (operating in FS mode) from placing the USB bus in suspend.

0 = An EOP is generated at the EOF1 point if no traffic is detected. 1 = EOP generation at EOF1 is disabled (note: this is normal USB operation).

Note: This is a rarely used feature in the PC environment, existing drivers

may not have been thoroughly debugged with this feature enabled. It is included because it is a permitted feature in Chapter 11 of the USB specification.

Revision 1.0 (04-20-09) 28 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 3.4 Config Data Byte 1 Register (CFG1) Format (continued)

BITS DESCRIPTION DEFAULT

2:1 Over Current Sense (CURRENT_SNS)

Selects current sensing on a port-by-port basis, all ports ganged, or none (only for bus-powered hubs) The ability to support current sensing on a port or ganged basis is hardware implementation dependent.

00 = Ganged sensing (all ports together) 01 = Individual port-by-port 1x = Over current sensing not supported (must only be used with BusPowered configurations!)

0 Port Power Switching (PORT_PWR)

Enables power switching on all ports simultaneously (ganged), or port power is individually switched on and off on a port by port basis (individual). The ability to support power enabling on a port or ganged basis is hardware implementation dependent.

0 = Ganged switching (all ports together) 1 = Individual port by port switching

Table 3.5 Config Data Byte 2 Register (CFG2) Format

BITS DESCRIPTION DEFAULT

7:6 RESERVED 00b

5:4 Over Current Timer (OC_TIMER)

Over Current Timer delay

01b

00 = 50ns 01 = 100ns (This is the recommended value) 10 = 200ns 11 = 400ns

3 Compound Device (COMPOUND)

Allows the OEM to indicate that the Hub is part of a compound (see the USB Specification for definition) device. The applicable port(s) must also be defined as having a “Non-Removable Device”.

0 = No 1 = Yes, Hub is part of a compound device

2:0 RESERVED 000b

SMSC LAN9512 29 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Table 3.6 Config Data Byte 3 Register (CFG3) Format

BITS DESCRIPTION DEFAULT

7:4 RESERVED 0h

Datasheet

3 Port Re-Mapping Enable (PRTMAP_EN)

Selects the method used by the Hub to assign port numbers and disable ports.

0 = Standard Mode. The following EEPROM addresses are used to define which ports are enabled. The ports mapped as Port’n’ on the Hub are reported as Port’n’ to the host, unless one of the ports is disabled, then the higher numbered ports are remapped in order to report contiguous port numbers to the host.

EEPROM Address 2Ah: Port Disable for Self-Powered operation EEPROM Address 2Bh: Port Disable for Bus-Powered operation

1 = Port Re-Map mode. The mode enables remapping via the following EEPROM addresses:

EEPROM Address 36h: Port Remap 12 EEPROM Address 37h: Port Remap 3

2:0 RESERVED 000b

Table 3.7 Boost_Up Register (BOOSTUP) Format

BITS DESCRIPTION DEFAULT

7:2 RESERVED 000000b

1:0 Upstream USB Electrical Signaling Drive Strength Boost Bit for

Upstream Port A (BOOST_IOUT_A)

00 = Normal electrical drive strength 01 = Elevated electrical drive strength (+4% boost) 10 = Elevated electrical drive strength (+8% boost) 11 = Elevated electrical drive strength (+12% boost)

Table 3.8 Boost_3:2 Register (BOOST32) Format

BITS DESCRIPTION DEFAULT

7:6 RESERVED 00b

5:4 Upstream USB Electrical Signaling Drive Strength Boost Bit for

Downstream Port 3 (BOOST_IOUT_3)

00 = Normal electrical drive strength 01 = Elevated electrical drive strength (+4% boost) 10 = Elevated electrical drive strength (+8% boost) 11 = Elevated electrical drive strength (+12% boost)

00b

Revision 1.0 (04-20-09) 30 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 3.8 Boost_3:2 Register (BOOST32) Format (continued)

BITS DESCRIPTION DEFAULT

3:2 Upstream USB Electrical Signaling Drive Strength Boost Bit for

Downstream Port 2 (BOOST_IOUT_2)

00 = Normal electrical drive strength 01 = Elevated electrical drive strength (+4% boost) 10 = Elevated electrical drive strength (+8% boost) 11 = Elevated electrical drive strength (+12% boost)

1:0 RESERVED 00b

Table 3.9 Status/Command Register (STCD) Format

BITS DESCRIPTION DEFAULT

7:2 RESERVED 000000b

1 Reset (RESET)

Resets the internal memory back to nRESET assertion default settings.

0 = Normal Run/Idle State 1 = Force a reset of the registers to their default state

Note: During this reset, this bit is automatically cleared to its default value

of 0.

0 USB Attach and Write Protect (USB_ATTACH)

00b

0 = Device is in configuration state 1 = Hub will signal a USB attach event to an upstream device, and the internal memory (address range 00h - FEh) is “write-protected” to prevent unintentional data corruption.

Note: This bit is write once and is only cleared by assertion of the external

nRESET or POR.

SMSC LAN9512 31 Revision 1.0 (04-20-09)

DATASHEET

3.2 EEPROM Defaults

The signature value of 0xA5 is stored at address 0. A different signature value indicates to the EEPROM controller that no EEPROM or an un-programmed EEPROM is attached to the device. In this case, the hardware default values are used, as shown in Ta b le 3 .1 0 .

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 3.10 EEPROM Defaults

FIELD DEFAULT VALUE

Ethernet Controller MAC Address

Ethernet Controller Full-Speed Polling Interval (mS)

Ethernet Controller Hi-Speed Polling Interval (mS)

Ethernet Controller Configuration Flags

Ethernet Controller Maximum Power (mA)

Ethernet Controller Vendor ID

Ethernet Controller Product ID

3.3 EEPROM Auto-Load

Certain system level resets (USB reset, POR, nRESET, and SRST) cause the EEPROM contents to be loaded into the device. After a reset, the EEPROM controller attempts to read the first byte of data from the EEPROM. If the value 0xA5 is read from the first address, then the EEPROM controller will assume that the external Serial EEPROM is configured for auto-loading. If a value other than 0xA5 is read from the first address, the EEPROM auto-load will not commense.

FFFFFFFFFFFFh

01h

04h

05h

01h

0424h

EC00h

Note: The EEPROM contents are loaded for both the Hub and the Ethernet Controller as a result of

a POR or nRESET. The USB reset results only in the loading of the MAC address from the EEPROM. A software reset (SRST) or a EEPROM Reload Command causes the EEPROM contents related solely to the Ethernet Controller to be loaded.

Revision 1.0 (04-20-09) 32 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

3.4 An Example of EEPROM Format Interpretation

Table 3.11 and Table 3.12 provide an example of how the contents of a EEPROM are formatted. Table 3.11 is a dump of the EEPROM memory (256-byte EEPROM), while Table 3.12 illustrates, byte

by byte, how the EEPROM is formatted.

Table 3.11 Dump of EEPROM Memory

OFFSET

BYTE VALUE

0000h A5 12 34 56 78 9A BC 01

0008h 04 05 09 04 0A 1D 00 00

0010h 00 00 00 00 00 00 12 22

0018h 12 2B 12 34 12 3D 00 00

0020h 24 04 12 95 00 01 9B 18

0028h 00 02 30 30 01 00 01 00

0030h 32 00 00 00 00 00 21 03

0038h 00 01 0A 03 53 00 4D 00

0040h 53 00 43 00 12 01 00 02

0048h FF 00 01 40 24 04 00 EC

0050h 00 01 01 00 00 01 09 02

0058h 27 00 01 01 00 E0 01 09

0060h 04 00 00 03 FF 00 FF 00

0068h 12 01 00 02 FF 00 FF 40

0070h 24 04 00 EC 00 01 01 00

0078h 00 01 09 02 27 00 01 01

0080h 00 E0 01 09 04 00 00 03

0088h FF 00 FF 00 ....................

0090h - 00FFh ..........................................

SMSC LAN9512 33 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Table 3.12 EEPROM Example - 256 Byte EEPROM

Datasheet

EEPROM

ADDRESS

00h A5 EEPROM Programmed Indicator

01h-06h 12 34 56 78 9A BC MAC Address 12 34 56 78 9A BC

07h 01 Full-Speed Polling Interval for Interrupt Endpoint (1ms)

08h 04 Hi-Speed Polling Interval for Interrupt Endpoint (4ms)

09h 05 Configuration Flags - The device is self powered and supports remote

0Ah-0Bh 09 04 Language ID Descriptor 0409h, English

0Ch 0A Manufacturer ID String Descriptor Length (10 bytes)

0Dh 1D Manufacturer ID String Descriptor EEPROM Word Offset (1Dh)

0Eh 00 Product Name String Descriptor Length (0 bytes - NA)

0Fh 00 Product Name String Descriptor EEPROM Word Offset (Don’t Care)

10h 00 Serial Number String Descriptor Length (0 bytes - NA)

11h 00 Serial Number String Descriptor EEPROM Word Offset (Don’t Care)

12h 00 Configuration String Descriptor Length (0 bytes - NA)

EEPROM

CONTENTS

(HEX) DESCRIPTION

wakeup.

Corresponds to EEPROM Byte Offset 3Ah

13h 00 Configuration String Descriptor Word Offset (Don’t Care)

14h 00 Interface String Descriptor Length (0 bytes - NA)

15h 00 Interface String Descriptor Word Offset (Don’t Care)

16h 12 Hi-Speed Device Descriptor Length (18 bytes)

17h 22h Hi-Speed Device Descriptor Word Offset (22h)

18h 12 Hi-Speed Configuration and Interface Descriptor Length (18 bytes)

19h 2B Hi-Speed Configuration and Interface Descriptor Word Offset (2Bh)

1Ah 12 Full-Speed Device Descriptor Length (18 bytes)

1Bh 34 Full-Speed Device Descriptor Word Offset (34h)

1Ch 12 Full-Speed Configuration and Interface Descriptor Length (18bytes)

1Dh 3D Full-Speed Configuration and Interface Descriptor Word Offset (3Dh)

1Eh 00 RESERVED

1Fh 00 RESERVED

20h 24 Vendor ID LSB Register (VIDL)

Corresponds to EEPROM Byte Offset 44h

Corresponds to EEPROM Byte Offset 56h

Corresponds to EEPROM Byte Offset 68h

Corresponds to EEPROM Byte Offset 7Ah

Revision 1.0 (04-20-09) 34 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 3.12 EEPROM Example - 256 Byte EEPROM (continued)

EEPROM

ADDRESS

21h 04 Vendor ID MSB Register (VIDM)

22h 12 Product ID LSB Register (PIDL)

23h 95 Product ID MSB Register (PIDM)

24h 00 Device ID LSB Register (DIDL)

25h 01 Device ID MSB Register (DIDM)

26h 9B Config Data Byte 1 Register (CFG1)

27h 18 Config Data Byte 2 Register (CFG2)

28h 00 Config Data Byte 3 Register (CFG3)

29h 02 Non-Removable Devices Register (NRD)

2Ah 30 Port Disable (Self) Register (PDS)

2Bh 30 Port Disable (Bus) Register (PDB)

2Ch 01 Max Power (Self) Register (MAXPS)

2Dh 00 Max Power (Bus) Register (MAXPB)

2Eh 01 Hub Controller Max Current (Self) Register (HCMCS)

EEPROM

CONTENTS

(HEX) DESCRIPTION

2Fh 00 Hub Controller Max Current (Bus) Register (HCMCB)

30h 32 Power-on Time Register (PWRT)

31h 00 Boost_Up Register (BOOSTUP)

32h 00 RESERVED

33h 00 Boost_3:2 Register (BOOST32)

34h 00 RESERVED

35h 00 Port Swap Register (PRTSP)

36h 21 Port Remap 12 Register (PRTR12)

37h 03 Port Remap 3 Register (PRTR3)

38h 00 RESERVED

39h 01 Status/Command Register (STCD)

3A 0A Size of Manufacturer ID String Descriptor (10 bytes)

3Bh 03 Descriptor Type (String Descriptor - 03h)

3Ch-43h 53 00 4D 00 53 00 43 00 Manufacturer ID String (“SMSC” in UNICODE)

44h 12 Size of Hi-Speed Device Descriptor in Bytes (18 bytes)

45h 01 Descriptor Type (Device Descriptor - 01h)

46h-47h 00 02 USB Specification Number that the device complies with (0200h)

SMSC LAN9512 35 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Table 3.12 EEPROM Example - 256 Byte EEPROM (continued)

EEPROM

ADDRESS

48h FF Class Code

49h 00 Subclass Code

4Ah FF Protocol Code

4Bh 40 Maximum Packet Size for Endpoint 0

4Ch-4Dh 24 04 Vendor ID (0424h)

4Eh-4Fh 00 EC Product ID (EC00h)

50h-51h 00 01 Device Release Number (0100h)

52h 01 Index of Manufacturer String Descriptor

53h 00 Index of Product String Descriptor

54h 00 Index of Serial Number String Descriptor

CONTENTS

(HEX) DESCRIPTION

Datasheet

55h 01 Number of Possible Configurations

56h 09 Size of Hi-Speed Configuration Descriptor in bytes (9 bytes)

57h 02 Descriptor Type (Configuration Descriptor - 02h)

58h-59h 27 00 Total length in bytes of data returned (0027h = 39 bytes)

5Ah 01 Number of Interfaces

5Bh 01 Value to use as an argument to select this configuration

5Ch 00 Index of String Descriptor describing this configuration

5Dh E0 Self powered and remote wakeup enabled

5Eh 01 Maximum Power Consumption is 2 mA

5Fh 09 Size of Descriptor in Bytes (9 Bytes)

60h 04 Descriptor Type (Interface Descriptor - 04h)

61h 00 Number identifying this Interface

62h 00 Value used to select alternative setting

63h 03 Number of Endpoints used for this interface (Less endpoint 0)

64h FF Class Code

65h 00 Subclass Code

66h FF Protocol Code

67h 00 Index of String Descriptor Describing this interface

68h 12 Size of Full-Speed Device Descriptor in Bytes (18 Bytes)

69h 01 Descriptor Type (Device Descriptor - 01h)

6Ah-6Bh 00 02 USB Specification Number that the device complies with (0200h)

Revision 1.0 (04-20-09) 36 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Table 3.12 EEPROM Example - 256 Byte EEPROM (continued)

EEPROM

ADDRESS

6Ch FF Class Code

6Dh 00 Subclass Code

6Eh FF Protocol Code

6Fh 40 Maximum Packet Size for Endpoint 0

70h-71h 24 04 Vendor ID (0424h)

72h-73h 00 EC Product ID (EC00h)

74h-75h 00 01 Device Release Number (0100h)

76 01 Index of Manufacturer String Descriptor

77h 00 Index of Product String Descriptor

78h 00 Index of Serial Number String Descriptor

79h 01 Number of Possible Configurations

7Ah 09 Size of Full-Speed Configuration Descriptor in bytes (9 bytes)

7Bh 02 Descriptor Type (Configuration Descriptor - 02h)

7Ch-7Dh 27 00 Total length in bytes of data returned (0027h = 39 bytes)

EEPROM

CONTENTS

(HEX) DESCRIPTION

7Eh 01 Number of Interfaces

7Fh 01 Value to use as an argument to select this configuration

80h 00 Index of String Descriptor describing this configuration

81h E0 Self powered and remote wakeup enabled

82h 01 Maximum Power Consumption is 2 mA

83h 09 Size of Full-Speed Interface Descriptor in Bytes (9 Bytes)

84h 04 Descriptor Type (Interface Descriptor - 04h)

85h 00 Number identifying this Interface

86h 00 Value used to select alternative setting

87h 03 Number of Endpoints used for this interface (Less endpoint 0)

88h FF Class Code

89h 00 Subclass Code

8Ah FF Protocol Code

8Bh 00 Index of String Descriptor describing this interface

8Ch-FFh - Data storage for use by Host as desired

SMSC LAN9512 37 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Chapter 4 Operational Characteristics

4.1 Absolute Maximum Ratings*

Supply Voltage (VDD33IO, VDD33A) (Note 4.1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0V to +3.6V

Positive voltage on signal pins, with respect to ground (Note 4.2) . . . . . . . . . . . . . . . . . . . . . . . . . . +6V

Negative voltage on signal pins, with respect to ground (Note 4.3) . . . . . . . . . . . . . . . . . . . . . . . . -0.5V

Positive voltage on XI, with respect to ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+4.6V

Positive voltage on XO, with respect to ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+2.5V

Datasheet

Ambient Operating Temperature in Still Air (T

Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-55

Lead Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Refer to JEDEC Spec. J-STD-020

HBM ESD Performance per JESD 22-A114-E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+/- 8kV

Contact Discharge ESD Performance per IEC61000-4-2 (Note 4.4) . . . . . . . . . . . . . . . . . . . . . .+/- 8kV

Air-Gap Discharge ESD Performance per IEC61000-4-2 (Note 4.4) . . . . . . . . . . . . . . . . . . . . .+/- 15kV

Latch-up Performance per EIA/JESD 78 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+/- 200mA

Note 4.1 When powering this device from laboratory or system power supplies, it is important that

the absolute maximum ratings not be exceeded or device failure can result. Some power supplies exhibit voltage spikes on their outputs when AC power is switched on or off. In addition, voltage transients on the AC power line may appear on the DC output. If this possibility exists, it is suggested that a clamp circuit be used.

Note 4.2 This rating does not apply to the following pins: XI, XO, EXRES, USBRBIAS.

Note 4.3 This rating does not apply to the following pins: EXRES, USBRBIAS.

Note 4.4 Performed by independant 3rd party test facility.

) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0oC to +70oC

C to +150oC

*Stresses exceeding those listed in this section could cause permanent damage to the device. This is a stress rating only. Exposure to absolute maximum rating conditions for extended periods may affect device reliability. Functional operation of the device at any condition exceeding those indicated in

Section 4.2, "Operating Conditions**", Section 4.4, "DC Specifications", or any other applicable section

of this specification is not implied. Note, device signals are NOT 5 volt tolerant unless specified otherwise.

4.2 Operating Conditions**

Supply Voltage (VDD33A, VDD33BIAS, VDD33IO) . . . . . . . . . . . . . . . . . . . . . . . . . . .+3.3V +/- 300mV

Ambient Operating Temperature in Still Air (T

**Proper operation of LAN9512 is guaranteed only within the ranges specified in this section.

Revision 1.0 (04-20-09) 38 SMSC LAN9512

DATASHEET

) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0oC to +70oC

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

4.3 Power Consumption

This section details the power consumption of the device as measured during various modes of operation. Power dissipation is determined by temperature, supply voltage, and external source/sink requirements.

4.3.1 Operational Current Consumption & Power Dissipation

Table 4.1 Operational Current Consumption & Power Dissipation (VDD33IO = VDD33A = 3.3V)

PARAMETER MIN TYPICAL MAX UNIT

100BASE-TX Full Duplex (USB High-Speed)

Supply current (VDD33IO, VDD33A) 231 mA

Power Dissipation (Device Only) 763 mW

10BASE-T Full Duplex (USB High-Speed)

Supply current (VDD33IO, VDD33A) 188 mA

Power Dissipation (Device Only) 621 mW

10BASE-T Full Duplex (USB Full-Speed)

Supply current (VDD33IO, VDD33A) 152 mA

Power Dissipation (Device Only) 502 mW

Note: All values measured with maximum simultaneous traffic on the Ethernet port and all USB ports.

Note: Magnetic power consumption:

 100BASE-TX: ~42mA

 10BASE-T: ~104mA

SMSC LAN9512 39 Revision 1.0 (04-20-09)

DATASHEET

4.4 DC Specifications

Table 4.2 I/O Buffer Characteristics

PARAMETER SYMBOL MIN TYP MAX UNITS NOTES

IS Type Input Buffer

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Low Input Level

High Input Level

Negative-Going Threshold

Positive-Going Threshold

SchmittTrigger Hysteresis (V

- V

ILT

)

IHT

Input Leakage (VIN = VSS or VDD33IO)

Input Capacitance

IS_5V Type Input Buffer

Low Input Level

High Input Level

Negative-Going Threshold

Positive-Going Threshold

SchmittTrigger Hysteresis

- V

IHT

ILT

)

Input Leakage (VIN = VSS or VDD33IO)

Input Leakage (VIN = 5.5V)

ILI

IHI

ILT

IHT

HYS

ILI

IHI

ILT

IHT

HYS

-0.3

1.01

1.39

345

-10

-0.3

1.01

1.39

345

-10

1.18

1.6

420

1.18

1.6

420

3.6

1.35

1.8

485

2.5

5.5

1.35

1.8

485

120

Schmitt trigger

Note 4.5

Schmitt trigger

Note 4.5

Note 4.5, Note 4.6

Input Capacitance

3.5

O8 Type Buffers

Low Output Level

High Output Level

VDD33IO - 0.4

0.4 V

IOL = 8mA

IOH = -8mA

OD8 Type Buffer

Low Output Level V

0.4 V IOL = 8mA

O12 Type Buffers

Low Output Level

High Output Level

VDD33IO - 0.4

0.4 V

IOL = 12mA

IOH = -12mA

OD12 Type Buffer

Low Output Level V

ICLK Type Buffer (XI Input)

Low Input Level

High Input Level

ILI

IHI

-0.3

1.4

0.4 V IOL = 12mA

Note 4.7

0.5

3.6

Note 4.5 This specification applies to all inputs and tri-stated bi-directional pins. Internal pull-down

and pull-up resistors add +/- 50uA per-pin (typical)

Revision 1.0 (04-20-09) 40 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Note 4.6 This is the total 5.5V input leakage for the entire device.

Note 4.7 XI can optionally be driven from a 25MHz single-ended clock oscillator.

Table 4.3 100BASE-TX Transceiver Characteristics

PARAMETER SYMBOL MIN TYP MAX UNITS NOTES

Peak Differential Output Voltage High V

Peak Differential Output Voltage Low V

Signal Amplitude Symmetry V

Signal Rise and Fall Time T

Rise and Fall Symmetry T

Duty Cycle Distortion D

Overshoot and Undershoot V

PPH

PPL

RFS

950 - 1050 mVpk Note 4.8

-950 - -1050 mVpk Note 4.8

98 - 102 % Note 4.8

3.0 - 5.0 nS Note 4.8

--0.5nSNote 4.8

35 50 65 % Note 4.9

--5%

Jitter 1.4 nS Note 4.10

Note 4.8 Measured at line side of transformer, line replaced by 100Ω (+/- 1%) resistor.

Note 4.9 Offset from 16nS pulse width at 50% of pulse peak.

Note 4.10 Measured differentially.

Table 4.4 10BASE-T Transceiver Characteristics

PARAMETER SYMBOL MIN TYP MAX UNITS NOTES

Transmitter Peak Differential Output Voltage V

Receiver Differential Squelch Threshold V

OUT

2.2 2.5 2.8 V Note 4.11

300 420 585 mV

Note 4.11 Min/max voltages guaranteed as measured with 100Ω resistive load.

SMSC LAN9512 41 Revision 1.0 (04-20-09)

DATASHEET

4.5 AC Specifications

25 pF

OUTPUT

This section details the various AC timing specifications of the LAN9512.

Note: The USBDP and USBDM pin timing adheres to the USB 2.0 specification. Refer to the

Universal Serial Bus Revision 2.0 specification for detailed USB timing information.

4.5.1 Equivalent Test Load

Output timing specifications assume the 25pF equivalent test load illustrated in Figure 4.1 below.

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

4.5.2 Reset Timing

The nRESET pin input assertion time must be a minimum of 1 μS. Assertion of nRESET is not a requirement. However, if used, it must be asserted for the minimum period specified.

Figure 4.1 Output Equivalent Test Load

Revision 1.0 (04-20-09) 42 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

EECLK

EEDO

EEDI

EECS

ckldis

cshckh

EEDI (VERIFY)

ckhtckl

ckcyc

cklcsl

csl

dvckhtckhdis

dsckh

dhckh

dhcsl

cshdv

Datasheet

4.5.3 EEPROM Timing

The following specifies the EEPROM timing requirements for LAN9512:

Figure 4.1 EEPROM Timing

Table 4.5 EEPROM Timing Values

SYMBOL DESCRIPTION MIN TYP MAX UNITS

ckcyc

ckh

ckl

cshckh

cklcsl

dvckh

ckhdis

dsckh

dhckh

ckldis

cshdv

dhcsl

csl

EECLK Cycle time 1110 1130 ns

EECLK High time 550 570 ns

EECLK Low time 550 570 ns

EECS high before rising edge of EECLK 1070 ns

EECLK falling edge to EECS low 30 ns

EEDO valid before rising edge of EECLK 550 ns

EEDO disable after rising edge EECLK 550 ns

EEDI setup to rising edge of EECLK 90 ns

EEDI hold after rising edge of EECLK 0 ns

EECLK low to data disable (OUTPUT) 580 ns

EEDIO valid after EECS high (VERIFY) 600 ns

EEDIO hold after EECS low (VERIFY) 0 ns

EECS low 1070 ns

SMSC LAN9512 43 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

4.6 Clock Circuit

LAN9512 can accept either a 25MHz crystal (preferred) or a 25MHz single-ended clock oscillator (+/50ppm) input. If the single-ended clock oscillator method is implemented, XO should be left unconnected and XI should be driven with a nominal 0-3.3V clock signal. The input clock duty cycle is 40% minimum, 50% typical and 60% maximum.

It is recommended that a crystal utilizing matching parallel load capacitors be used for the crystal input/output signals (XI/XO). See Table 4.6 for the recommended crystal specifications.

Table 4.6 LAN9512 Crystal Specifications

PARAMETER SYMBOL MIN NOM MAX UNITS NOTES

Crystal Cut AT, typ

Crystal Oscillation Mode Fundamental Mode

Crystal Calibration Mode Parallel Resonant Mode

Datasheet

Frequency F

Frequency Tolerance @ 25

Frequency Stability Over Temp F

Frequency Deviation Over Time F

fund

tol

temp

age

- 25.000 - MHz

- - +/-50 PPM Note 4.12

- +/-3 to 5 - PPM Note 4.13

Total Allowable PPM Budget - - +/-50 PPM Note 4.14

Shunt Capacitance C

Load Capacitance C

Drive Level P

Equivalent Series Resistance R

Operating Temperature Range 0 - +70

-7 typ-pF

- 20 typ - pF

300 - - uW

--50Ohm

LAN9512 XI Pin Capacitance - 3 typ - pF Note 4.15

LAN9512 XO Pin Capacitance - 3 typ - pF Note 4.15

Note 4.12 The maximum allowable values for Frequency Tolerance and Frequency Stability are

application dependant. Since any particular application must meet the IEEE +/-50 PPM Total PPM Budget, the combination of these two values must be approximately +/-45 PPM (allowing for aging).

Note 4.13 Frequency Deviation Over Time is also referred to as Aging.

Note 4.14 The total deviation for the Transmitter Clock Frequency is specified by IEEE 802.3u as

+/- 50 PPM.

Note 4.15 This number includes the pad, the bond wire and the lead frame. PCB capacitance is not

included in this value. The XO/XI pin and PCB capacitance values are required to accurately calculate the value of the two external load capacitors. These two external load capacitors determine the accuracy of the 25.000 MHz frequency.

Revision 1.0 (04-20-09) 44 SMSC LAN9512

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Chapter 5 Package Outline

5.1 64-QFN Package

Figure 5.1 LAN9512 64-QFN Package Definition

Table 5.1 LAN9512 64-QFN Dimensions

MIN NOMINAL MAX REMARKS

A 0.80 0.85 1.00 Overall Package Height

A1 0.00 0.02 0.05 Standoff

A2 - 0.65 0.80 Mold Cap Thickness

D/E 8.90 9.00 9.10 X/Y Body Size

D1/E1 8.65 8.75 8.85 X/Y Mold Cap Size

D2/E2 7.20 7.30 7.40 X/Y Exposed Pad Size

L 0.30 0.40 0.50 Terminal Length

b 0.18 0.25 0.30 Terminal Width

e 0.50 BSC Terminal Pitch

K 0.35 - - Pin to Center Pad Clearance

SMSC LAN9512 45 Revision 1.0 (04-20-09)

DATASHEET

USB Hub with Integrated 10/100 Ethernet Controller

Datasheet

Notes:

1. All dimensions are in millimeters unless otherwise noted.

2. Dimension “b” applies to plated terminals and is measured between 0.15 and 0.30 mm from the terminal tip.

3. Details of terminal #1 identifier are optional, but must be located within the area indicated. The terminal #1 identifier may be either a mold or marked feature.

Figure 5.2 LAN9512 Recommended PCB Land Pattern

Revision 1.0 (04-20-09) 46 SMSC LAN9512

DATASHEET

SMSC LAN9512 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Chapter 1 Introduction

1.1 Block Diagram

1.1.1 Overview

Figure 1.1 Internal Block Diagram

1.1.2 USB Hub

1.1.3 Ethernet Controller

1.1.4 EEPROM Controller

1.1.5 Peripherals

1.1.6 Power Management

Chapter 2 Pin Description and Configuration

Figure 2.1 LAN9512 64-QFN Pin Assignments (TOP VIEW)

Table 2.1 EEPROM Pins

Table 2.2 JTAG Pins

Table 2.3 Miscellaneous Pins

Table 2.4 USB Pins

Table 2.5 Ethernet PHY Pins

Table 2.6 I/O Power Pins, Core Power Pins, and Ground Pad

Table 2.7 No-Connect Pins

Table 2.8 64-QFN Package Pin Assignments

2.1 Port Power Control

2.1.1 Port Power Control Using a USB Power Switch

Figure 2.2 Port Power Control with USB Power Switch

2.1.2 Port Power Control Using a Poly Fuse

Figure 2.3 Port Power Control with Poly Fuse

Figure 2.4 Port Power with Ganged Control with Poly Fuse

2.2 Buffer Types

Table 2.9 Buffer Types

Chapter 3 EEPROM Controller (EPC)

3.1 EEPROM Format

Table 3.1 EEPROM Format

Table 3.2 Configuration Flags Description

3.1.1 Hub Configuration

Table 3.3 Hub Configuration

Table 3.4 Config Data Byte 1 Register (CFG1) Format

Table 3.5 Config Data Byte 2 Register (CFG2) Format

Table 3.6 Config Data Byte 3 Register (CFG3) Format

Table 3.7 Boost_Up Register (BOOSTUP) Format

Table 3.8 Boost_3:2 Register (BOOST32) Format

Table 3.9 Status/Command Register (STCD) Format

3.2 EEPROM Defaults

Table 3.10 EEPROM Defaults

3.3 EEPROM Auto-Load

3.4 An Example of EEPROM Format Interpretation

Table 3.11 Dump of EEPROM Memory

Table 3.12 EEPROM Example - 256 Byte EEPROM

Chapter 4 Operational Characteristics

4.1 Absolute Maximum Ratings*

4.2 Operating Conditions**

4.3 Power Consumption

4.3.1 Operational Current Consumption & Power Dissipation

Table 4.1 Operational Current Consumption & Power Dissipation (VDD33IO = VDD33A = 3.3V)

4.4 DC Specifications

Table 4.2 I/O Buffer Characteristics

Table 4.3 100BASE-TX Transceiver Characteristics

Table 4.4 10BASE-T Transceiver Characteristics

4.5 AC Specifications

4.5.1 Equivalent Test Load

4.5.2 Reset Timing

Figure 4.1 Output Equivalent Test Load

4.5.3 EEPROM Timing

Figure 4.1 EEPROM Timing

Table 4.5 EEPROM Timing Values

4.6 Clock Circuit

Table 4.6 LAN9512 Crystal Specifications

Chapter 5 Package Outline

5.1 64-QFN Package

Figure 5.1 LAN9512 64-QFN Package Definition

Table 5.1 LAN9512 64-QFN Dimensions

Figure 5.2 LAN9512 Recommended PCB Land Pattern
