1. Description of the controls

1.1 The control panel

A ON/OFF BUTTON

B PROGRAM SELECTION KEY

C DELAYED START KEY (with door open)

D OPTION SELECTION KEY

E OPTION SETTING KEY

F START-PAUSE KEY (with door closed)

G INFORMATION DISPLAY

N.B.: the functions of keys (C) and (F) are the same.

1.2 The information display

The dishwasher is fitted with a convenient sloping display (G) to assure good visibility from both in front and above.

The display uses brief text messages to provide all the information about the programmed functions and any malfunctions.

1.3 Washing programs

The dishwasher has a control panel and an INFORMATION DISPLAY (G) allowing the user to carry out all switch-on, switch-off and

programming procedures.

User instructions

Before starting a washing program make sure that:

x The water supply tap is open. x The correct amount of detergent has been added to the

dispenser.

x The baskets have been correctly loaded. x The spray arms are able to rotate freely and without

obstruction.

x The dishwasher door is securely closed.

When the appliance is used for the first time, set the hardness of the water and also set the buzzer as required (enabled/disabled). For the relative instructions, see "CUSTOMISING YOUR APPLIANCE".

SWITCHING ON

With the door open press the ON/OFF key (A). The dishwasher comes on and the

message shown below appears on the

DISPLAY (G).

PROGRAMMING

On this model of dishwasher, all programming operations are only possible with the door open.

PROGRAM SELECTION

After the initial message, the system offers you the assisted programming function (Wizard), in which you only have to select the level of dirt and the washing strategy.

Shown on the display:

x Press (D) or (E) to select assisted programming (see "Assisted

programming").

x Press (B) to exit assisted programming and choose standard

programming (see "Standard programming").

User instructions

Assisted programming (Wizard)

x Press (D) or (E) in repetition to display

the type of dirt on the dishes, on the top line of the DISPLAY (G).

x Press (B) or (C) to confirm the selection and continue programming.

Choose the type of wash following the procedures described above (D or E to display the selections available, B or C to confirm).

At the end of assisted programming, the DISPLAY (G) shows "Wait please..." and a few seconds later you will be offered the option selection function (button B/C to accept, D/E to reject).

Refer to the "OPTIONS" section to view the possibilities available.

Standard programming

Select "No" (key B) to disable assisted programming and the system will offer the last program performed. To start this program, simply close the door (buzzer sounds, if enabled).

To select another program, press (B) in repetition until the program required is displayed; to start this program close the door (buzzer sounds, if enabled).

See TABLE OF PROGRAMS on following pages.

At the end of the assisted or standard programming procedure, the programmed duration of the washing cycle, in minutes, appears on the bottom line of the DISPLAY (G).

x The temperature which appears before the program's name

indicates its type (e.g. 45° delicate programs, 55° economy, 65° intensive, etc.); the actual temperature is displayed, stage by stage, while washing is in progress.

x Programs' duration, temperature and consumption figures are

guideline, since they depend on various factors, such as type of load, intake water temperature, room temperature, etc.

User instructions

STARTING THE PROGRAM

To start the program close the door.

Whenever the door is opened and closed with a program selected (in progress, or before it starts) the buzzer sounds, if the "Enable buzzer" function is on (see "CUSTOMISING YOUR APPLIANCE").

FOR CERTIFICATION BODIES

Reference standard EN 50242

Reference program BIO Load 14 place-settings Type of detergent B Amount of detergent 35 g Rinse aid setting setting 5

The washing cycle will not take place if the dishwasher door is left open or not properly closed.

If the door is opened with the dishwasher in operation, a long buzzer sounds and "In pause" appears on the bottom line of the DISPLAY (G). Next time the door is closed the program will continue from where it was interrupted.

If the temperature inside the tank exceeds 50°C, the program will restart after about 30 seconds.

User instructions

NUMBER &

PROGRAMME

SOAK

RINSE

SHORT

DELICATE

(*) EN 50242

AUTO 40-50

AUTO 60-70

STRONG

SUPER

ECO

BIO

LOAD CROCKERY

AND CUTLERY

Pans and dishes awaiting

completion of the load

Pans and dishes

for rinsing and drying

Delicate dishes with light dirt, washed immediately after use

Delicate dishes

with normal dirt

Dishes

with normal dirt

Very dirty dishes,

with dried-on residues

Normally or very

dirty dishes washed

immediately after use

Very dirty

dishes

Very dirty

pans and dishes

Very dirty

pans and dishes,

with dried-on residues

PROGRAM

PROGRESS

Cold prewash (**)

Cold rinse Rinse at 68°C Dry

Wash at 38°C Cold rinse Rinse at 58°C

Cold prewash Wash at 45°C Cold rinse Rinse at 68°C Dry

Wash at 55°C Cold rinse Rinse at 68°C Dry

Cold prewash Wash at 50°C Cold rinse Rinse at 62°C Dry

Cold prewash Wash at 40°C Wash at 55°C Cold rinse Rinse at 68°C Dry

Cold prewash Wash at 50°C Wash at 65°C Cold rinse Rinse at 70°C Dry

Wash at 70°C 2 cold rinses Rinse at 70°C Dry

Prewash at 45°C Wash at 70°C 2 cold rinses Rinse at 70°C Dry

DURATION CONSUMPTION

MINUTES WATER

LITRES (1)

POWER KWh (2)

6 0,03

(**)

(***) (***) (***)

(**)

9 0,90

13 0,85

17 1,15

14 1,30

15 1,08

17 1,50

20 1,70

Only run the soak program with half loads. The options are available in all programs except the soak program. (*) Reference program as per EN 50242 standard. (**) See display. (***) When the "AUTO 40-50" or "AUTO 60-70" program is selected, the dishwasher recognises the type

of dirt and automatically adapts the washing parameters and washing stages as appropriate. (1) Average power consumption with the softener set on level 2. (2) The cycle duration, energy consumption and temperatures which appear on the display may vary

depending on water and room temperature and type and quantity of dishes.

User instructions

CONTENTS OF DISPLAY WHEN PROGRAM IS IN PROGRESS

The top line displays the temperature in the tank, alternating (every 4 seconds) with the program being performed and the current program stage. The bottom line will show the program duration "Duration XX min", where XX is the time left before the end of the program, in minutes.

If DELAYED START (C) is set, until the program starts the second line shows the message "Starting in YY hh/mm", where YY are the hours (from 1-12/1-24 depending on model) or minutes (when less than 1 hour) left before the program starts.

Any warning messages (e.g. "No salt") will appear on the DISPLAY (G) during the washing stage, alternating with the time left to the end of the program.

If the 3/1 PRODUCTS function (only available on some models) is set, the no salt and no rinse aid warning messages do not appear.

INTERRUPTING A PROGRAM

To interrupt a program, press the START/PAUSE key (F) and keep it pressed until "In pause" appears on the bottom line of the DISPLAY (G).

To restart the program, repeat this operation until "Duration XX min" reappears on the bottom line of the display.

Opening the door only cuts out the program in progress, but this is not recommended, since water splashes or gusts of steam might escape. When the door is closed the program restarts automatically, even it was interrupted by pressing the START/PAUSE key (F).

User instructions

CHANGING THE PROGRAM

To change a program while it is running, proceed as follows:

x press key (F) to set the program in pause status; x open the door and select the new program using key (B); x close the door; the changes relating to the new program will

appear on the DISPLAY (G).

ANNULLING A PROGRAM

x To annul a program while it is running, it must first be interrupted by

pressing key (F);

x then open the door and press key (B) in repetition until you obtain

"Cancel program";

x close the door. "Draining" will appear on the DISPLAY (G) and the

dishwasher will start to pump out the water. This will be completed in about 1 minute and "Program end" will appear on the top line of the display.

Before the door is closed, a long washing time will appear alongside "Draining". This is not a malfunction but simply a stage in the time update process; the time will be corrected to 1 minute when the door is closed.

END OF PROGRAM

At the end of the program the buzzer sounds (if enabled), after which the temperature and program name will alternate with "Program end" on the top line of the DISPLAY (G); the bottom line continues to show "Duration XX min".

User instructions

OPTIONS (available in all programs except the soak program)

Options must be chosen before closing the door to start the program, or at the end of assisted programming, when the DISPLAY (G) offers the option selection function (button B/C to accept). If DELAYED START (C) has been set, before the program starts the user may open the door and set one of the other options, or modify the DELAYED START.

To select the option press (D); to enable/disable it press (E).

Key (D) Key (E)

Function Enable Disable

EXTRA HYGIENE 1 0

START DELAY 1>12/1>24 0

HALF LOAD upper/lower OFF

DETERGENT 3/1 NORMAL

For an option to be confirmed it needs only to appear on the display. Then close the door to start the program, or move on to select another option.

Depending on the model the dishwasher may feature one, some or all of the options listed below.

All the options are disabled at the end of the program.

DELAYED START (depending on model)

Shown on the DISPLAY (G): "Start delay h 0, 1, .....12/24".

The start of the washing program can be set with a delay from 1 to 12/24 hours. This function allows you to set the dishwasher to work at your preferred time of day and avoid having several appliances (washing machine, oven, etc.) in operation simultaneously.

The start delay can only be set in steps of 1 hour. Press key (C) in repetition until you obtain the delay required, then close the door to start or select another option. When the door is closed the dishwasher performs a prewash, after which the countdown to the starting time begins. The bottom line of the DISPLAY (G) shows "Starting in X h" or "Starting in Y min" (when less than 1 hour is left).

User instructions

The delay selected can be modified during the time between setting of the option and the program start; simply open the door and repeat the

DELAYED START selection procedure.

HALF-LOAD WASH (depending on model)

Shown on the DISPLAY (G): "Half load Off/Upper/Lower".

Press key (D) to display the "Half load" option, then use key (E) to select "Upper" if you wish to wash in the top basket only, or "Lower" to wash in the bottom basket only. Return to "Off" for normal washing with full load in both baskets.

One half of the cutlery basket can be placed in the basket selected for the HALF LOAD program.

WARNING: dishes and cutlery placed in the basket not selected will not be washed.

USE OF 3/1 PRODUCTS OPTION (depending on model)

Shown on the DISPLAY (G): "3/1/Normal detergent".

Press (D) to display the option and press (E) to enable the (3/1) option or return to the use of normal detergent (Normal).

This option has been developed for use with powder or tablet detergents containing substances that substitute for regenerating salt and rinse aid, known on the market as "3 in 1" or "triple action" products. In this case the dishwasher will make the most effective use of the product, not using any salt or rinse aid which the appliance may contain.

User instructions

If the water hardness has been set on a value above H3, and the 3/1 option is activated, the DISPLAY (G) flashes, warning of a setting error,

because these products are not suitable for use with very hard water. This does not prevent the use of the option, but the washing results might not be of the best.

EXTRA SANITISATION RINSE (depending on model)

Shown on the DISPLAY (G): "Extra hygiene 1/0".

Press (D) to display the option and press (E) to enable (1 on display) or disable (0 on display) it.

This function performs an extra sanitising rinse at the end of the washing cycle, assuring a further reduction in the number of bacteria present.

If the temperature falls while the sanitisation rinse is in progress (e.g. due to a power blackout or because the door is opened), the DISPLAY (G) flashes until the dishwasher is switched off or a new program is set, to warn that the option has not been carried out.

TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT

x Always try to run the dishwasher fully loaded. x Do not wash the dishes in running water. x Use the washing program that is most appropriate for each type of

load.

x Do not carry out any preliminary rinsing. x If available, connect the dishwasher to a hot water supply up to

60°C.

TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT THE ENVIRONMENT

The phosphates contained in dishwasher detergents are harmful to the environment. To avoid using excessive amounts of detergent and to save on electricity, observe the following: x separate the more delicate items from dishes that are more

resistant to aggressive detergents and high temperatures;

x do not pour the detergent directly on the dishes.

User instructions

CUSTOMISING YOUR APPLIANCE

The electronic control system allows you to customise your appliance in a number of ways.

The user customisations cannot be accessed if the dishwasher is in “assisted programming” mode (Wizard).

Use key (D) to select the customisation you require, then key (E) to enable (1) / disable (0) or modify the parameters.

To exit the programming function press key (B).

Enable buzzer

With this function enabled (1), a buzzer sounds whenever the door is opened and closed with a program running or selected, at the end of the cycle and during programming procedures. If it is disabled (0), the buzzer never sounds.

Procedure Customisation Settings

long press on key (D)

Enable buzzer Enable (1) / Disable (0)

H2O hardness

Select the water hardness customisation function using key (D).

Press (E) in repetition to select the hardness level required (from H0 to

H5) with reference to the "WATER HARDNESS TABLE".

Procedure Customisation Settings

second press on key (D)

H2O hardness from h0 to h5

User instructions

WATER HARDNESS TABLE

WATER HARDNESS

German Degrees (°dH) French Degrees (°dF)

0 - 4 0 - 7 h 0

5 - 15 8 - 25 h 1 16 - 23 26 - 40 h 2 24 - 31 41 - 60 h 3 32 - 47 61 - 80 h 4 48 - 58 81 - 100 h 5

Contact your local water board for information on the hardness of your

water supply.

Language

Select the language customisation function using key (D).

Press (E) in repetition to select the language required.

Procedure Customisation Settings

third press on key (D) Language selection

SETTING

Language:

Italian

English

French German Spanish

Portuguese

REMOVING THE DISHES

At the end of the washing program, wait at least 20 minutes before removing the dishes, to allow them to cool down. To prevent any water droplets on the upper basket from falling on the dishes in the lower basket, it is advisable to unload the lower basket first, and then the upper basket.

User instructions

2. Troubleshooting

The dishwasher has an autodiagnosis system capable of detecting and

indicating a preset series of possible malfunctions.

If a malfunction occurs, the relative name indicating the possible cause of the malfunction appears on the DISPLAY (G). The following table summarises the main possible malfunctions and provides brief descriptions.

TABLE OF MALFUNCTIONS DETECTED BY THE AUTODIAGNOSIS SYSTEM

FAULT - DESCRIPTION

Fault waterblock

The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks. Contact the after-sales service.

Safety level on

The system which limits the water level inside the dishwasher has been tripped. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle. If the problem persists, contact the after-sales service.

Heating k.o.

The water is not heated or the heating parameters are not correct. Repeat the washing program; if the problem persists, contact the after-sales service.

Temper. feeler k.o.

Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle. If the problem persists, contact the aftersales service.

Watertap closed

The appliance does not take in water or does not do so correctly. Check that the water connections are correct, the water intake tap is turned on and the filter is not fouled. If the problem persists, contact the after-sales service.

Drain obstructed

The appliance does not pump out the water or does not do so correctly. Check that the drain hose is not kinked or crushed and that the siphon and filter are not fouled. If the problem persists, contact the after-sales service.
