Smeg SCA45M2 User Manual
SCA45M2
microwave oven
operating and installation instructions
: these provide recommendations for
n of the controls and the correct procedures for cleaning
: these are intended for the
PRECAUTIONS FOR USE................................................................................ 2
1
2 DISPOSAL INSTRUCTIONS - OUR ENVIRONMENT POLICY ........................ 4
3 SAFETY PRECAUTIONS.................................................................................. 5
4 GET TO KNOW YOUR OVEN...........................................................................8
5 BEFORE INSTALLATION ................................................................................. 8
6 DESCRIPTION OF FRONT PANEL CONTROLS ............................................. 9
7 USING THE OVEN..........................................................................................11
8 ACCESSORIES AVAILABLE ..........................................................................17
9 RECOMMENDED COOKING TABLES ........................................................... 18
10 CLEANING AND MAINTENANCE ............................................................... 30
11 EXTRAORDINARY MAINTENANCE ........................................................... 32
12 INSTALLING THE APPLIANCE................................................................... 34
Table of Contents
GB-IE
INSTRUCTIONS FOR THE USER
use, a descriptio
and maintaining the appliance
INSTRUCTIONS FOR THE INSTALLER
qualified engineer who is to install, commission and test the appliance
1
GB-IE
Precautions for Use
1 PRECAUTIONS FOR USE
THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. TAKE GOOD
CARE OF IT AND KEEP IT TO HAND THROUGHOUT THE OVEN'S LIFE CYCLE.
WE URGE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT
CONTAINS CAREFULLY BEFORE USING THE APPLIANCE. INSTALLATION
MUST BE CARRIED OUT BY QUALIFIED STAFF IN COMPLIANCE WITH THE
RELEVANT REGULATIONS. THIS APPLIANCE IS INTENDED FOR HOUSEHOLD
USE AND COMPLIES WITH THE EEC DIRECTIVES CURRENTLY IN FORCE.
THE APPLIANCE IS BUILT TO PROVIDE THE FOLLOWING FUNCTION:
COOKING AND HEATING FOODS; ALL OTHER USES ARE TO BE
CONSIDERED IMPROPER.
THE MANUFACTURER DECLINES ALL LIABILITY FOR USES OTHER THAN
THOSE STATED ABOVE.
KEEP THE DOCUMENTATION OF THIS PRODUCT FOR FUTURE REFERENCE.
ALWAYS KEEP THE INSTRUCTION MANUAL HANDY. IF YOU LEND THE
MICROWAVE OVEN TO SOMEONE ELSE GIVE THEM THE MANUAL AS WELL!
THIS APPLIANCE IS DESIGNED FOR COOKING FOOD AND IT SHALL NOT
BE USED AS A SPACE HEATER.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT
IS IN OPERATION.
NEVER LEAVE PACKAGING RESIDUES UNATTENDED IN THE HOME.
SEPARATE THE VARIOUS PACKAGING MATERIALS BY TYPE AND CONSIGN
THEM TO THE NEAREST SEPARATE DISPOSAL CENTRE.
THIS APPLIANCE IS TAGGED UNDER EUROPEAN DIRECTIVE 2002/96/EC ON
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).
THIS DIRECTIVE CONTAINS THE REGULATIONS GOVERNING THE
COLLECTION AND RECYCLING OF DECOMMISSIONED APPLIANCES
THROUGHOUT THE EUROPEAN UNION.
REPLACED APPLIANCES MUST BE TAKEN TO A SPECIAL GARBAGE
COLLECTION CENTRE.
NEVER OBSTRUCT THE OPENINGS AND SLITS PROVIDED FOR
VENTILATION AND HEAT DISPERSAL.
THE I.D. PLATE WITH TECHNICAL DATA, REGISTRATION NUMBER AND
BRAND NAME IS POSITIONED VISIBLY ON THE OVEN DOOR FRAME.
THE PLATE MUST NOT BE REMOVED.
2
NEVER USE METAL SCOURING PADS OR SHARP SCRAPERS
WHICH WILL DAMAGE THE SURFACE.
USE ORDINARY NON-ABRASIVE PRODUCTS WITH THE AID OF
WOODEN OR PLASTIC UTENSILS IF NECESSARY. RINSE
THOROUGHLY AND DRY WITH A SOFT CLOTH OR CHAMOIS
LEATHER.
DO NOT ALLOW SPILLS OF FOODS WITH HIGH SUGAR CONTENT
(E.G. JAM) TO DRY INSIDE THE OVEN. IF THEY DRY FOR TOO
LONG, THEY MIGHT DAMAGE THE ENAMEL COATING OF THE
INSIDE OF THE OVEN.
Precautions for Use
GB-IE
3
GB-IE
Disposal Instructions
2 DISPOSAL INSTRUCTIONS -
OUR ENVIRONMENT POLICY
Our products are only packaged using non-pollutant, environment-friendly,
recyclable materials. We urge you to cooperate by disposing of the
packaging properly. Contact your local dealer or the competent local
organisations for the addresses of collection, recycling and disposal
facilities.
Never leave all or part of the packaging lying around. Packaging parts,
and especially plastic bags, may represent a suffocation hazard for
children.
Your old appliance must also be disposed of properly.
Important: deliver the appliance to your local organisation authorised to
collect scrapped appliances. Proper disposal allows the intelligent
recovery of valuable materials.
Before scrapping your appliance it is important to remove doors and leave
shelves in position as for use, to ensure that children cannot accidentally
become trapped inside the oven during play. Also, cut the power supply
lead and remove it and the plug.
4
Safety Precautions
GB-IE
3 SAFETY PRECAUTIONS
REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY
REGULATIONS FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION
FUNCTIONS.
IN YOUR INTEREST AND TO ENSURE YOUR SAFETY, BY LAW ALL ELECTRIC
APPLIANCES MUST ONLY BE INSTALLED AND SERVICED BY QUALIFIED
STAFF, IN ACCORDANCE WITH THE RELEVANT REGULATIONS.
OUR APPROVED INSTALLATION ENGINEERS GUARANTEE YOU A JOB WELL
DONE.
GAS OR ELECTRIC APPLIANCES MUST ALWAYS BE DISCONNECTED BY
SUITABLY SKILLED PEOPLE.
THE PLUG TO BE CONNECTED TO THE POWER SUPPLY LEAD AND THE
RELATIVE SOCKET MUST BE OF THE SAME TYPE AND COMPLY WITH THE
RELEVANT REGULATIONS.
THE POWER SUPPLY SOCKET MUST BE ACCESSIBLE EVEN AFTER THE
APPLIANCE HAS BEEN BUILT-IN.
NEVER DISCONNECT THE PLUG BY PULLING ON THE POWER SUPPLY LEAD
THE APPLIANCE MUST BE CONNECTED TO EARTH IN COMPLIANCE WITH
ELECTRICAL SYSTEM SAFETY REGULATIONS.
IMMEDIATELY AFTER INSTALLATION, CARRY OUT A QUICK TEST ON THE
OVEN FOLLOWING THE INSTRUCTIONS PROVIDED LATER IN THIS MANUAL.
DURING THE TESTS PUT A GLASS OF WATER INSIDE THE OVEN AS IT WILL
ABSORB THE MICROWAVES AND THE OVEN WILL NOT BE DAMAGED. IF THE
APPLIANCE FAILS TO OPERATE, DISCONNECT IT FROM THE ELECTRICAL
MAINS AND CONTACT YOUR NEAREST SERVICE CENTRE. NEVER ATTEMPT
TO REPAIR THE APPLIANCE.
WARNING! NEVER LEAVE THE OVEN UNWATCHED, ESPECIALLY WHEN
USING PAPER, PLASTIC OR OTHER COMBUSTIBLE MATERIALS. THESE
MATERIALS CAN CHAR AND MAY FIRE. FIRE RISK!
WARNING! IF YOU SEE SMOKE OR FIRE, KEEP THE DOOR CLOSED IN
ORDER TO SMOTHER THE FLAMES. SWITCH OFF THE OVEN AND TAKE THE
PLUG OUT OF THE SOCKET OR CUT OFF THE OVEN POWER SUPPLY.
WARNING! DO NOT HEAT PURE ALCOHOL OR ALCOHOLIC DRINKS IN THE
MICROWAVE. FIRE RISK!
WARNING! DO NOT HEAT LIQUIDS OR OTHER FOODS IN CLOSED
CONTAINERS SINCE THESE MAY EXPLODE READILY.
WARNING! NEVER PUT INFLAMMABLE OBJECTS IN THE OVEN: THEY COULD
BE ACCIDENTALLY CATCH LIGHT AND CAUSE FIRES.
THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING
CHILDREN) WITH REDUCED PHYSICAL, SENSORY OR MENTAL
CAPABILITIES, OR LACK OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY
HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF
THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY
WITH THE APPLIANCE.
5
GB-IE
Safety Precautions
WARNING: ACCESSIBLE PARTS MAY BECOME HOT DURING USE. YOUNG
CHILDREN SHOULD BE KEPT AWAY.
WARNING: DURING USE THE APPLIANCE BECOMES HOT. CARE SHOULD BE
TAKEN TO AVOID TOUCHING HEATING ELEMENTS INSIDE THE OVEN. TO
AVOID BURNS AND SCALDS CHILDREN SHOULD BE KEPT AWAY.
WARNING! THE OVEN CANNOT BE USED IF:
THE DOOR IS NOT CLOSED CORRECTLY;
THE DOOR HINGES ARE DAMAGED;
THE SURFACES OF THE CONTACT BETWEEN THE DOOR AND THE OVEN
FRONT ARE DAMAGED;
THE DOOR WINDOW GLASS IS DAMAGED;
THERE IS FREQUENT ELECTRICAL ARCING INSIDE THE OVEN EVEN
THOUGH THERE IS NO METAL OBJECT INSIDE.
THE OVEN CAN ONLY BE USED AGAIN AFTER IT HAS BEEN REPAIRED BY A
TECHNICAL ASSISTANCE SERVICE TECHNICIAN.
BEWARE!
NEVER HEAT BABY FOODS OR DRINKS IN BOTTLES OR JARS WITH THE
TEATS OR LIDS ON THEM. AFTER HEATING THE FOOD MIX OR SHAKE
WELL SO THAT THE HEAT IS SPREAD EVENLY. CHECK THE FOOD
TEMPERATURE BEFORE FEEDING THIS TO THE CHILD. DANGER OF
BURNING!
TAKE CARE WHEN HEATING LIQUIDS!
WHEN LIQUIDS (WATER, COFFEE, TEA, MILK, ETC.) ARE NEARLY AT
BOILING POINT INSIDE THE OVEN AND ARE TAKEN OUT SUDDENLY, THEY
MAY SPURT OUT OF THEIR CONTAINERS. DANGER OF INJURIES AND
BURNS!
TO AVOID THAT TYPE OF SITUATION WHEN HEATING LIQUIDS, PUT A
TEASPOON OR GLASS ROD INSIDE THE CONTAINER.
TO AVOID FOOD OVERHEATING OR BURNING IT IS VERY IMPORTANT NOT
TO SELECT LONG TIME PERIODS OR POWER LEVELS THAT ARE TOO HIGH
WHEN HEATING SMALL QUANTITIES OF FOOD. FOR EXAMPLE, A BREAD
ROLL CAN BURN AFTER 3 MINUTES IF THE POWER SELECTED IS TOO HIGH.
FOR TOASTING, USE JUST THE GRILLING FUNCTION AND WATCH THE
OVEN ALL THE TIME. IT YOU USE A COMBINED FUNCTION TO TOAST BREAD
IT WILL CATCH FIRE IN A VERY SHORT TIME.
THIS OVEN IS EXCLUSIVELY FOR DOMESTIC USE!
USE THE OVEN ONLY FOR PREPARING MEALS.
AVOID DAMAGING THE OVEN OR OTHER DANGEROUS SITUATIONS BY
FOLLOWING THESE INSTRUCTIONS:
Do not switch on the oven without the turntable support, the turntable
ring and the respective plate being in place.
Never switch on the microwave when it is empty. If there is no food
inside there may be an electrical overcharge and the oven could be
damaged. RISK OF DAMAGE!
Do not cover or obstruct the ventilation openings.
6
Safety Precautions
GB-IE
Use only dishes suitable for microwaves. Before using dishes and
containers in the microwave, check that these are suitable (see the
section on types of dishes).
Never remove the mica cover on the ceiling of the oven interior!
This cover stops fat and pieces of food damaging the microwave
generator.
Do not keep any inflammable object inside the oven as it may burn if
the oven is switched on.
Do not use the oven as a pantry.
Eggs with their shells and whole boiled eggs must not be heated in
microwave ovens because they may explode.
Do not use the oven for frying as it is impossible to control the
temperature of oil heated by microwaves.
To avoid being burnt, always use oven gloves for handling dishes
and containers and touching the oven.
Do not lean or sit on the open oven door. This may damage the
oven, especially in the hinge zone. The door can bear a maximum
weight of 8 kg.
The turntable and the grills can bear a maximum load of 8 kg. To
avoid damaging the oven, do not exceed this load.
CLEANING:
Warning! Your microwave oven must be cleaned regularly. All food
remains must be removed (see section on Oven Cleaning). If the
microwave oven is not kept clean its surface may deteriorate and this
may shorten the oven’s working life and could even result in a
dangerous situation.
The door contact surfaces (the front of the cavity and the inside part of
the doors) must be kept very clean in order to ensure the oven
functions correctly.
DO NOT USE HARSH ABRASIVE CLEANERS OR SHARP METAL
SCRAPERS TO CLEAN THE OVEN DOOR GLASS SINCE THEY
CAN SCRATCH THE SURFACE, WHICH MAY RESULT IN
SHATTERING OF THE GLASS.
Please follow the instructions regarding cleaning in the section “Oven
Cleaning and Maintenance”.
REPAIRS:
Warning – Microwaves! The outer protection of the oven must not
be removed. It is dangerous for anyone not authorised by the
manufacturer to carry out any kind of repair or maintenance work.
If the power cable is damaged it should be substituted by the
manufacturer, aut horised agents or technicians qualified for this task
in order to avoid dangerous situations. Furthermore, special tools are
required for this task.
Repair and maintenance work, especially of current carrying parts, can
only be carried out by technicians authorised by the manufacturer.
The manufacturer declines all responsibility for injury or damage caused by failure
to comply with the above regulations or deriving from tampering with even just one
part of the appliance and the use of non-original spare parts.
7
GB-IE
Instructions for the User
4 GET TO KNOW YOUR OVEN
1. – Door window glass 8. – Lamp
2. – Catches 9. – Control panel
3. – Turntable support 10. – Glass tray
4. – Turntable ring 11. – Shelf (DO NOT USE WITH
5. – Turntable plate MICROWAVES)
6. – Grill Element 12. – Browning plate
7. – Mica cover 13. – Lateral supports
5 BEFORE INSTALLATION
Never leave packaging residues unattended in the home. Separate waste
packaging materials by type and consign them to the nearest separate
disposal centre.
The inside of the appliance should be cleaned to remove all manufacturing
residues. For further information about cleaning, see point "10. CLEANING
AND MAINTENANCE".
8
Instructions for the User
GB-IE
6 DESCRIPTION OF FRONT PANEL CONTROLS
All the appliance's control and monitoring devices are placed together on
the front panel. The table below provides the key to the symbols used.
FUNCTION’S PARAMETERS KNOB
This knob allows you to set the time, select the
cooking temperature and duration and program
the cooking start and end times. From now on,
for convenience it will be referred to as PT1.
For instructions on how to use it correctly, see
the next chapters.
CURRENT TIME / DURATION DISPLAY
This display shows the current time or the cooking duration.
Also visible are the function cut-out light (see point “7.6.3 Child safety lockout function”)
From now on, for convenience it will be referred to as DSP1.
TEMPERATURE / MICROWAVES POWER / WEIGHT DISPLAY
This display shows the Parameters set for the function required, or the
Parameters set by the user.
From now on, for convenience it will be referred to as DSP2.
FUNCTION DISPLAY
This display shows (illuminated) all the cooking functions available for
selection. For instructions on how to select a cooking function, see
point“7.2 Operating settings”.
From now on, for convenience it will be referred to as DSP3.
9
GB-IE
Instructions for the User
FUNCTION-SWITCH ON KNOB
This knob allows access to the oven's three
operating settings, and is also used to select a
cooking function (see point “7.2 Operating
settings”).
From now on, for convenience it will be
referred to as PT2.
The table below provides a short description of
the functions available.
MICROWAVES
MICROWAVES + GRILL ELEMENT
MICROWAVES + ROUND HEATING
ELEMENT + FAN
GRILL ELEMENT
GRILL ELEMENT + FAN
ROUND HEATING ELEMENT + FAN
GRILL ELEMENT + ROUND
HEATING ELEMENT + FAN
DEFROST BY TIME
DEFROST BY WEIGHT
PIZZA FUNCTION
10
Loading...
