Smeg CR324A7, CR324ASX7 User Manual

INSTRUCTIONS FOR USE

BEFORE USING THE APPLIANCE

SAFEGUARDING THE ENVIRONMENT

PRECAUTIONS AND GENERAL RECOMMENDATIONS

HOW TO USE THE REFRIGERATOR COMPARTMENT

HOW TO USE THE FREEZER COMPARTMENT

HOW TO DEFROST THE FREEZER COMPARTMENT

HOW TO CLEAN THE REFRIGERATOR COMPARTMENT

CARE AND MAINTENANCE

TROUBLESHOOTING GUIDE

AFTER-SALES SERVICE

INSTALLATION

ELECTRICAL CONNECTION

BEFORE USING THE APPLIANCE

• Your new appliance is designed exclusively for

domestic use

To get the most out of your new appliance, read the user handbook thoroughly. The handbook contains a description of the appliance and useful tips for storing food.

Keep this handbook for future consultation.

1. After unpacking, make sure that the appliance is

undamaged and that the door closes properly. Any damage must be reported to your dealer within 24 hours after delivery of the appliance.

2. Wait at least two hours before switching the

appliance on in order to ensure the refrigerant circuit is fully efficient.

3. Installation of the appliance and electrical

connections must be carried out by a qualified electrician, in accordance with the manufacturer's instructions and local safety regulations

4. Clean the inside of the appliance before using it.

SAFEGUARDING THE ENVIRONMENT

1. Packing

The packaging material is entirely recyclable, and marked with the recycling symbol. Follow local regulations for scrapping. Keep the packaging materials (plastic bags, polystyrene parts, etc.) out of reach of children, as they are potentially dangerous.

2. Scrapping

The appliance is manufactured using recyclable material. This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

The symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. Before scrapping, make the appliance unusable by cutting off the power cable and removing the doors and shelves so that children cannot easily climb inside the appliance. Disposal must be carried out in accordance with local environmental regulations for waste disposal. Deliver the appliance immediately to an authorized dump; do not leave it unattended even for a few days, since it is potentially dangerous for children. For more detailed information about treatment, recovery and recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

Information:

This appliance does not contain CFCs (replaced with R134a) or HFCs (replaced with R600a). Appliances with Isobutane (R600a): isobutane is a naturally occurring, low environmental impact gas. Caution is required, however, because isobutane is flammable. Therefore, it is essential to ensure that refrigerant pipelines are not damaged.

Declaration of conformity

• This appliance is designed to store food and is

manufactured in conformity with EEC directive No. 89/109/CEE, 90/128/CEE, 02/ 72/CEE.

• This appliance is designed, manufactured, and

retailed in compliance with:

- the safety objectives of the Low Voltage Directive 73/23/EEC;

- the protection requirements of the “EMC” Directive 89/336/EEC, amended by Directive 93/68/EEC;

• The electrical safety of the appliance can only be

guaranteed if the product is connected to an approved earth connection.

PRECAUTIONS AND GENERAL RECOMMENDATIONS

• Use the refrigerator compartment only for

storing fresh food and beverages and use the freezer compartment only for storing frozen food, freezing fresh food and making ice cubes.

• After installation, make sure that the appliance is

not standing on the power supply cable.

• Do not store glass containers with liquids in the

freezer since they may burst.

• Do not eat ice cubes or ice lollies immediately

after taking them out of the freezer since they may cause cold burns.

• Before carrying out any maintenance or cleaning,

always unplug the appliance or disconnect the power supply.

• Make sure that your appliance is not near a heat

source.

• Do not store or use gasoline or other flammable

vapours and liquids in the vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.

• To ensure proper ventilation leave a 1 cm space

on both sides and above the appliance.

• Ensure that the vent outlets on the appliance

casing or housing unit are unobstructed in order to allow correct air circulation.

• All appliances equipped with an ice maker or

water dispenser must be connected to a mains water supply that delivers potable water only (with water pressure between 1.7 and 8.1 bar (25 and 117 PSI)). Ice makers and/ or water dispensers not directly connected to a mains water supply must be filled with potable water only.

• Install and level the appliance on a floor strong

enough to take its weight and in an area suitable for its size and use.

• Install the appliance in a dry and well-ventilated

place The appliance is set for operation at specific ambient temperature ranges, according to the climatic class indicated on the data plate: The appliance may not work properly if it is left for a long period at a temperature above or below the indicated range.

Climatic class Amb. T. (°C) Amb. T. (°F)

SN From 10 to 32 From 50 to 90

N From 16 to 32 From 61 to 90

ST From 18 to 38 From 64 to 100

T From 18 to 43 From 64 to 110

• Be careful not to damage the floors when you

move the appliance (e.g. parquet flooring).

• Do not use mechanical devices or any means

other than those recommended by the manufacturer to speed up the defrosting process.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the

freezer compartments, unless such appliances are specifically recommended by the manufacturer.

• This appliance is not designed for use by young

children or the infirm.

• To avoid the risk of children being trapped and

therefore suffocating, do not allow them to play or hide inside the appliance.

• The power cable may only be replaced by an

authorized person.

• Do not use extension leads or adapters.

• It must be possible to disconnect the appliance

from the mains by unplugging it or by mean s of a two-pole switch fitted upline of the socket.

• Ensure that the voltage indicated on the

appliance data plate corresponds to the domestic supply voltage

• Do not ingest the contents (non-toxic) of the ice

packs (if provided).

HOW TO USE THE REFRIGERATOR COMPARTMENT

This appliance is a refrigerator with a 4 star freezer compartment.

Defrosting of the refrigerator compartment is performed automatically.

The refrigerator can operate in room temperatures between +10° C and +38° C. Optimal performance of the appliance depends on the climatic class, which is indicated on the rating plate.

Switching on the appliance

Plug in the appliance. The thermostat knob in the refrigerator compartment serves to adjust the temperature in both the refrigerator and freezer compartment if your appliance is equipped with a single compressor. Refrigerator compartment and freezer compartment temperature adjustment is independent in the case of appliances with two compressors (see product description sheet).

Temperature adjustment

1. To ensure correct operation and the best possible food storage in both compartments, set the thermostat in accordance with the indications on the enclosed product description sheet.

2. To alter the temperature in the refrigerator and freezer

compartments set the thermostat knob to:

•lower numbers 1-2 (MIN) if you want to INCREASE the

temperature;

•higher numbers 5-7 (MAX) if you want to DECREASE

the temperature.

Thermostat setting z switches off all functions of the appliance including the interior light.

Note:

The room air temperature, the number of times the door is opened and the position of the appliance will affect the temperature in the refrigerator and freezer compartments. Take these factors into consideration when you set the thermostat. For example if the machine is operated in a room with high temperature you may need to set the thermostat to a low number.

Using the refrigerator compartment

Position the food as shown in the figure. A Cooked food BFish, meat C Fruit and vegetables D Bottles E Butter F Dairy products, cheese

Notes:

• The space between the shelves and the rear wall of the refrigerator

compartment must be unobstructed to allow air circulation.

• Do not place the food in direct contact with the rear wall of the

refrigerator compartment.

• Do not place hot food in the refrigerator.

• Store liquids in closed containers.

• Storage of vegetables with high water contents can lead to the

formation of condensation: this will not affect the correct operation of the appliance.
