Smeg CO300, CO400 User Manual
GB
Climatic Class Amb. T. (°C) Amb. T. (°F)
SN From 10 to 32 From 50 to 90
N From 16 to 32 From 61 to 90
ST From 16 to 38 From 61 to 100
T From 16 to 43 From 61 to 110
1.
Temperature
adjustment thermostat.
2.
Red LED (if provided)
: Indicates that the appliance
temperature is not sufficiently low.
3.
Green LED (if provided):
indicates that the appliance
is on.
4.
Yellow/orange illuminated button (if provided)
:
activates/deactivates the fast freeze function. It lights up
when the fast freeze function is active.
The exact configuration of the controls may vary
according to the model.
INSTRUCTIONS FOR USE
Lid handle.
1.
Lock (if provided).
2.
Seal.
3.
Divider (if provided).
4.
Defrost water drain plug.
5.
Control panel.
6.
Side motor cooling grille.
7.
Upper edge.
8.
Condenser (located at the rear)
9.
INSTALLATION
•
Please refer to the chapter “BEFORE USING THE
APPLIANCE”.
•
Unpack the appliance.
•
Remove the 4 protection pieces inserted between lid
and appliance.
•
Warning: two of the four protection pieces must be
fitted in the seat of the condenser plastic supports,
located at the rear of the product.
This is necessary to ensure the correct distance from
the wall.
Ensure that the defrosting water drainage plug (if provided) is
•
correctly positioned
For best operation of the appliance and in order to avoid
•
damage when the lid is opened, leave a space of at least
7 cm from the rear wall and 7 cm at the sides.
Fit the accessories (if provided).
•
.
(5)
Switching on the appliance
The appliance is factory set for optimum operation at a
•
temperature of -18°C.
Plug in the appliance.
•
The green LED lights up (if provided).
•
Also the red LED (if provided) will switch on because the
•
temperature inside the appliance is not yet sufficiently low for
food storage. The red LED will normally switch off within the
first six hours after the appliance is switched on.
•
After connecting the appliance to the mains supply
and when the optimal temperature has been reached
(this phase takes about 1 hour during which the lid
will not open), ensure that the fast freeze button is
not pressed (the yellow LED, if provided, is off)
Place food inside the product only when the red LED
•
(if provided) has switched off.
Thanks to the efficient lid seal, the appliance lid will not
•
re-open easily immediately after closing.
Wait a few minutes before re-opening the lid of the
appliance.
Temperature Adjustment
Use the thermostat to select the ideal storage temperature.
To adjust the internal temperature, proceed as follows:
Turn the thermostat knobto 1 for a storage temperature that
•
is less cold.
Turn the thermostat knob to 6 / for a colder storage
•
temperature.
When the appliance is only partially full, choose a lower
•
thermostat setting. For average loads, set the thermostat
to “3 Eco/e” to optimize energy consumption.
