HISTORY

SMEG has been producing domestic

appliances with the finest Italian designs

for more than 70 years, with a particular

focus on aesthetics, ergonomics, and

functionality.

Today, SMEG, an acronym for “Smalterie

Metallurgiche Emiliane Guastalla”,

indicating the company's foundation in

enamel work and metallurgy, has reached

its third generation family ownership, and

represents an international group with

direct subsidiaries and distributors on five

continents.

the smeg headquarters designed by architect guido canali

exhibited at the 13 shown in the italian pavilion as an architectural example of excellence made in italy, a structure in tune with the culture of the region, the life of the people, and environmental sustainability.

venice architecture biennial in 2012. it was

smeg believes that objects of daily use should not only fill an

environment; they should create an atmosphere. this sensitivity, which has inspired a collaboration with great architects and designers of our time, is the perfect expression of the made in italy philosophy, which combines art and industrial expertise in everyday objects.

SMEG PRODUCTS

SMEG products, the perfect combination

of refined aesthetics and technological

reliability, have transformed simple kitchen

appliances into designer furnishings,

undisputed examples of the finest Italian

design: a range of fully-coordinated

domestic appliances with unmistakably-

refined aesthetics and a well-defined

identity of its own.

RANGES

SMEG's philosophy, "Technology with

Style", fully emerges in its truly versatile

series of pro ranges. SMEG's acclaimed

pro ranges reflect the artistry and

techniques of the passionate cook by

offering a wealth of functions and features.

RANGES

CPF48UGWH

VERSATILITY

an ample range of style and dimensions

SMEG ranges are icons of design, combining classic SMEG style with outstanding performance. Inspired by the ranges favored by the world’s great chefs, SMEG offers products where style and elegance meet versatility for people who genuinely love to cook.

PORTOFINO OPERA PROFESSIONAL STYLE VICTORIA

BUILDING-IN SOLUTION

SMEG ranges can be elegantly slotted in-between kitchen furniture for a distinctive look that is totally safe, thanks to the excellent, insulation and outercooling system that prevents the sides of SMEG pro ranges from overheating.

MULTIPLE CONVECTION

FANS

Many SMEG ranges have two convection fans that ensure uniform heat distribution, and allow you to cook large meals with ease.

AIR COOLING SYSTEM

The forced air recirculation system means that the sides, door and components inside the oven, remain cool, ensuring greater safety, and a longer life for the appliance.

VICTORIA RANGE

powerful traditional style

A passion for cooking deserves an outstanding tool to realize that passion, one that perfectly blends functionality with style.

4.4

cu.ft.

RANGES

EXTRA VOLUME

SMEG produces ovens with a wider cavity. 36" wide ranges have a net volume of

4.4 cu ft, which allows the use of wide baking trays.

TWO FANS

Many ranges with electric ovens have two fans that ensure uniform heat distribution, and allow you to cook large meals.

AIR COOLING SYSTEM

The forced fresh air recirculation system means that the sides, the door, and the components inside the range remain cool, ensuring greater safety, and a longer life for your appliance. The cooling system remains in-operation even when cooking is nished, continuing to function with the oven switched-off, so as to dissipate the heat that has accumulated inside the range.

EVERCLEAN ENAMEL

The specially-coated EverClean enamel prevents grease from adhering to the oven walls, to reduce cleaning time and effort.

FULL-LENGTH STORAGE

DRAWER

Convenient space for kitchen utensils and oven accessories.

PORTOFINO RANGE

a charismatic identity

The kitchen is one of the most extensively-used environments in the house, where people come together to dine and share a space throughout the day. The technological developments introduced by SMEG serve to simplify everyday tasks. The company strives to understand and anticipate the needs of its users, who are demonstrating increasing interest in taking full advantage of the kitchen space.

Available in three different dimensions from 30 inches wide to 48 inches, SMEG Portono ranges satisfy every space requirement. Range ovens have different capacities, from 1.45 cu ft capacity to an ample 4.5 cu ft.

DUAL ULTRARAPID

BURNER

The dual ultrarapid burner consists of a double crown, which combines an ultrarapid burner with an auxiliary burner reaching a maximum of 20,000 BTUs.

FULL-WIDTH GRATE

The gas cooktops are equipped with solid, heavy-duty cast-iron grates, covering the complete surface of the range. This extends the support surface to a maximum, providing an aesthetic, functional solution, which is perfectly aligned with the countertop, as well as sitting ush with other modular units to create a streamlined effect. This linear and ergonomic design helps provide the range with both a professional look, and a professional approach to cooking.

The burners are uniquely designed with different ame arrangements, and offer superior performance. From the smallest to the most powerful ultrarapid burner, the Portono range can be used for a host of applications.

PORTOFINO RANGE

boundless italian style

This colorful range, inspired by the rich tones of the Mediterranean, offers superb performance, and is characterized by the clean lines typical of professional kitchen design. The new PORTOFINO range is available in 8 different colors and 2 different congurations, all-gas and dual-fuel.

TRIPLE-FAN TECHNOLOGY

The oven is equipped with an exclusive three fan system, which, combined with the increased power of the motors, enables excellent cooking performance. The two large side fans distribute the air around the outer perimeter of the cavity while the smaller central fan increases ventilation by creating a vertical vortex of heat. Accordingly, the temperature within the cavity is uniform, allowing food to be cooked evenly on all ve levels, like in professional kitchens.

COOKING ON STONE

Portono ovens can be equipped with a large refractory stone for quick and easy baking, which is ideal for cooking healthy homemade pizza and bread, as well as sh and vegetables. By activating the Turbo function, you can cook two pizzas simultaneously, in just 4 minutes.

ISOTHERMIC-PROOF CAVITY

This new cavity is characterized by its unique shape, with rounded corners and smooth, uniform walls, for maximum thermal insulation and optimal energy performance. The perfect insulation of the cavity also helps reduce preheating time. The multifunction version, for example, reaches a temperature of 392°F in just 6 minutes, a time saving of 50% compared to a standard oven.

5 COOKING LEVELS

The different cooking levels enable maximum exibility of use, and allow different courses to be cooked simultaneously. This enables users to optimize the time spent cooking, preparing multiple courses quicky and efciently while preserving distinctive avors.

The oven door is equipped with

SOFT CLOSE

a Soft Close system which closes the door in a silent, soft motion, with no need to push it.

PRO-STYLE RANGE GAS OVEN SERIES

for foodies who love to bake and roast

Ideal for baking and roasting most types of food, the ame on a gas stovetop lights immediately, giving you instant heat, and you can control the heat level with precision. When you turn the ame off, the food can stay on the range without worry of overcooking because the elements cool rapidly. The C-Series are available in sizes from 24’’ to 36’’.

TRIM VENTILATION

FRESH DOOR

DOUBLE CONVECTION

TRIPLE GLASS

EVERCLEAN ENAMEL

REMOVABLE INNER

GLASS

OPERA

timeless elegance

RANGES

SUPER BURNER

Central double-inset super burner 15,000 BTU.

TRIM for ventilation.

ELLIPTICAL BURNER for

irregular cookware.

ANTI-OVERFLOW

COOKTOP

This feature avoids spills of liquid, thus protecting the kitchen furniture on either side.

CAST-IRON PAN

STANDS

Strong cast-iron grates and matte black burner caps.

STORAGE STEEL DRAWER

Full-width stainless steel drawer ensures that all of your useful cooking accessories are within arm's reach.

ELECTRIC BARBECUE-GRILL

For convenient indoor grilling.

CPF48UGMX

PORTOFINO PRO-STYLE DUAL-FUEL RANGE, STAINLESS STEEL, 48” X 25”

Portofino Style

Stainless steel control knobs

Thermoseal cavity, energy efficiency best-in-class

Soft Close oven door Full-width continuous grates Storage compartment with inner drawer

MULTIFUNCTION ELECTRIC OVEN - MAIN:

10 cooking modes, including Pizza Function

Vapor-Clean function Programmable timer with touch display Adjustable thermostat 120° - 500° F Air-cooled triple-glazed removable door

True European triple convection

Oven capacity: 4.5 cu ft

EverClean enameled interior cavity

5 shelf positions 2 halogen oven lights Bake element 1.7 kW Broil element 2.9 kW Convection element 1.5 kW

MULTIFUNCTION ELECTRIC OVEN - SECONDARY:

4 cooking modes

True European convection Adjustable thermostat 120° - 440° F EverClean enamelled oven interior Air-cooled triple-glazed removable door Removable inner glass for easy cleaning Oven capacity: 1.45 cu ft 5 shelf positions 2 x halogen oven lights Bake element 750 W Broil element 2.05 kW Convection element 1.5 kW

GAS RANGETOP:

5 gas burners with Electric Griddle Center-rear: 12,000 BTUs Center-front: 4,500 BTUs Right-rear: 12,000 BTUs Right-front: 8,000 BTUs

Left double-inset super burner: 20,000 BTUs

Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

CPF48UGMR

Red

CPF48UGMOR

Orange

CPF48UGMX

Stainless Steel

SAFETY:

Gas safety valves Air-cooled door to prevent overheating

Connected load nominal power: 240/120V - 17 Amps Voltage rating: 240/120V 60Hz

ACCESSORIES INCLUDED:

1 wok ring 1 rotisserie kit 1 deep oven tray 1 total-extraction telescopic guide 2 chrome shelves 1 black toe kick

OPTIONS:

BGTR9 Grill plate TPKTR9 Teppanyaki grill plate GT1T-2 1-Level telescopic shelf - total extraction PPR9 Pizza stone BGTR4110 Cast-iron grill plate

CPF48UGMYW

Yellow

CPF48UGMBL

Black

CPF48UGMAN

CPF48UGMWH

White

CPF48UGMOG

Olive Green

Matte Black

For technical drawing in metric, see page 174

RANGES PORTOFINO

CPF48UGMR

CPF36UGMWH

PORTOFINO PRO-STYLE DUAL-FUEL RANGE, WHITE, 36” X 25”

Portofino Style

Stainless steel control knobs

Thermoseal cavity, energy efficiency best-in-class

Soft Close oven door Full-width continuous grates Push-pull stainless steel storage compartment

MULTIFUNCTION ELECTRIC OVEN:

10 cooking modes including Pizza Function

Vapor-Clean function Programmable timer with touch display Adjustable thermostat 120° - 500° F Air-cooled triple-glazed removable door

True European triple convection

Oven capacity: 4.5 cu ft

EverClean enameled interior cavity

5 shelf positions 2 halogen oven lights Bake element 1.7 kW Broil element 2.9 kW Convection element 1.5 kW

GAS RANGETOP:

5 gas burners Center-rear: 4,500 BTUs Center-front: 10,500 BTUs Right-rear: 12,000 BTUs Right-front: 8,000 BTUs

Left double-inset super burner: 20,000 BTUs

Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

CPF36UGMR

Red

CPF36UGMOR

Orange

CPF36UGMX

Stainless Steel

SAFETY:

Gas safety valves Air-cooled door to prevent overheating

Connected load nominal power: 240/120V - 17 Amps Voltage rating: 240/120V 60Hz

ACCESSORIES INCLUDED:

1 wok ring 1 rotisserie kit 1 deep oven tray 1 total-extraction telescopic guide 2 chrome shelves 1 black toe kick

OPTIONS:

BGTR9 Cast-iron grill plate TPKTR9 Teppanyaki grill plate GT1T-2 1-Level telescopic shelf - total extraction PPR9 Pizza stone

CPF36UGMYW

Yellow

CPF36UGMBL

Black

CPF36UGMAN

Matte Black

CPF36UGMWH

White

CPF36UGMOG

Olive Green

For technical drawing in metric, see page 174

RANGES PORTOFINO

KPF36UYW hood with backsplash

and CPF36UGMYW range

CPF36UGGR

PORTOFINO PRO-STYLE ALL-GAS RANGE, RED, 36” X 25”

Portofino Style

Stainless steel control knobs

Triple Convection

Soft Close oven door Full-width continuous grates Push-pull stainless steel storage compartment

GAS OVEN:

4 cooking modes

Programmable timer with touch display Adjustable thermostat 120° - 500° F Air-cooled triple-glazed removable door

Triple Convection

Oven capacity: 4.5 cu ft

EverClean enameled interior cavity

5 shelf positions 2 halogen oven lights

GAS RANGETOP:

5 gas burners Center-rear: 4,500 BTUs Center-front: 10,500 BTUs Right-rear: 12,000 BTUs Right-front: 8,000 BTUs

Left double-inset super burner: 20,000 BTUs

Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

CPF36UGGR

Red

CPF36UGGOR

Orange

CPF36UGGX

Stainless Steel

SAFETY:

Gas safety valves Air-cooled door to prevent overheating

Connected load nominal power: 200W - 2 Amps Voltage rating: 120V 60Hz

ACCESSORIES INCLUDED:

1 wok ring 1 deep oven tray 1 total-extraction telescopic guide 2 chrome shelves 1 black toe kick

OPTIONS:

BGTR9 Grill plate BGTTR9 Cast-iron grill plate

TPKTR9 Teppanyaki grill plate GT1T-2 1-Level telescopic shelf - total extraction

CPF36UGGYW

Yellow

CPF36UGGBL

Black

CPF36UGGAN

Matte Black

CPF36UGGWH

White

CPF36UGGOG

Olive Green

For technical drawing in metric, see page 174

RANGES PORTOFINO

CPF36UGGOG

CPF30UGMBL

PORTOFINO PRO-STYLE DUAL-FUEL RANGE, BLACK, 30” X 25”

Portofino Style

Stainless steel control knobs

Soft Close oven door

Full-width continuous grates Storage compartment

MULTIFUNCTION ELECTRIC OVEN:

10 cooking modes including Pizza Function

Programmable timer with touch display Adjustable thermostat 120° - 500° F Air-cooled triple-glazed removable door

True European triple convection

Oven capacity: 3.6 cu ft

Ever-Clean enameled interior cavity

4 shelf positions 2 halogen oven lights Bake element 1.7 kW Broil element 2.9 kW Convection element 2.7 kW

GAS RANGETOP:

4 gas burners Diamond configuration burner layout Center-rear: 4,500 BTUs Center-front: 8,000 BTUs Right super burner: 20,000 BTUs

Left double-inset super burner: 20,000 BTUs

Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

CPF30UGMR

Red

CPF30UGMOR

Orange

CPF30UGMX

Stainless Steel

SAFETY:

Gas safety valves Air-cooled door to prevent overheating

Connected load nominal power: 240/120V - 17 Amps Voltage rating: 240/120V 60Hz

ACCESSORIES INCLUDED:

1 wok ring 1 deep oven tray 1 partial-extraction telescopic guide 2 chrome shelves 1 black toe kick

OPTIONS:

BGTR9 Grill plate BGCPF30 Cast-iron grill plate TPKCPF30 Teppanyaki grill plate GT91P Level telescopic shelf - partial extraction PPR9 Pizza stone

CPF30UGMYW

Yellow

CPF30UGMBL

Black

CPF30UGMAN

Matte Black

CPF30UGMWH

White

CPF30UGMOG

Olive Green

For technical drawing in metric, see page 174

RANGES PORTOFINO

CPF30UGMX

CPF30UGGOG

PORTOFINO PRO-STYLE ALL-GAS RANGE, OLIVE GREEN, 30” X 25”

Portofino Style

Stainless steel control knobs

Soft Close oven door

Full-width continuous grates Storage compartment

GAS OVEN:

3 cooking modes

Programmable timer with touch display Adjustable thermostat 120° - 500° F Air-cooled triple-glazed removable door

Removable inner glass for easy cleaning

Oven capacity: 3.6 cu ft

EverClean enameled interior cavity

4 shelf positions 2 halogen oven lights

GAS RANGETOP:

4 gas burners Diamond configuration burner layout Center-rear: 4,500 BTUs Center-front: 8,000 BTUs Right super burner: 20,000 BTUs

Left double-inset super burner: 20,000 BTUs

Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

CPF30UGGR

Red

CPF30UGGOR

Orange

CPF30UGGX

Stainless Steel

SAFETY:

Gas safety valves Air-cooled door to prevent overheating

Connected load nominal power: 200W - 2 Amps Voltage rating: 120V 60Hz

ACCESSORIES INCLUDED:

1 wok ring 1 deep oven tray 1 partial-extraction telescopic guide 2 chrome shelves 1 black toe kick

OPTIONS:

BGTR9 Grill plate TPKCPF30 Teppanyaki grill plate GT91P 1-Level telescopic shelf - partial extraction BGCPF30 Cast-iron grill plate

CPF30UGGYW

Yellow

CPF30UGGBL

Black

CPF30UGGAN

Matte Black

CPF30UGGWH

White

CPF30UGGOG

Olive Green

For technical drawing in metric, see page 174

RANGES PORTOFINO

CPF30UGGAN

A3XU7

FREE-STANDING DUAL-FUEL DUAL-CAVITY "OPERA" RANGE, APPROX. 48", STAINLESS STEEL, GAS RANGETOP WITH ELECTRIC GRILL

Professional Style

Stainless steel Programmable timer with touch display Full-width continuous grates Storage drawer beneath the ovens Smart-Black glass 2" stainless steel backsplash

MULTIFUNCTION ELECTRIC OVEN - MAIN:

8 cooking modes

Programmable timer with touch display Adjustable thermostat 120° - 480° F Triple-glazed removable door Oven capacity: 3.2 cu ft EverClean enameled oven interior Roof liner Bake element 2.8 kW Broil element 3.85 kW

Convection element 2.5 kW

MULTIFUNCTION ELECTRIC OVEN - SECONDARY:

4 cooking modes

Programmable timer Adjustable thermostat 120° - 430° F EverClean enameled oven interior Triple-glazed removable door Oven capacity: 1.48 cu ft Bake element 1.4 kW

Broil element 2.05 kW

GAS RANGETOP:

5 gas burners Right-front: 3,500 BTUs Right-rear (fish burner) 6,650 BTUs Non-stick Teflon-coated electric grill: 5,500 BTUs Center-front: 6,500 BTUs Center-rear: 13,650 BTUs

Left double-inset super burner: 15,000 BTUs

Cast-iron grates and matte black burner caps Automatic electronic ignition LP gas conversion kit included Easy access for nozzle replacement Deep rangetop base to contain spillage

SAFETY

Gas safety valves Ventilated door with cooling system to prevent overheating

Connected load nominal power: 120/240V – 6.5 kW/5 kW Amp supply required 240/208V: 27/24 Amps Voltage rating: 240/208V 60Hz

Gas inlet location: back top-right

ACCESSORIES INCLUDED:

2 baking trays 1 wire rack 2 rotisserie kit 1 wok ring

OPTIONS:

KIT1A3-6 Backsplash KIT2A3XU7 Kick plate GTA-6 3-Level telescopic shelf set GO120 Cast-iron open griddle DICAR Simmer plate

For technical drawing in metric, see page 174

RANGES OPERA

A3XU7

TRU36GMWH

TRU36GGWH9

FREE-STANDING DUAL-FUEL CAVITY "VICTORIA" RANGE, 36" X 25", WHITE

Traditional Style Thermoseal cavity, energy efficiency best-in-class Soft Close oven door

Full-width continuous grates Stainless steel storage drawer beneath the oven

MULTIFUNCTION ELECTRIC OVEN:

8 cooking modes

FREE-STANDING ALL-GAS "VICTORIA" RANGE, 36" X 25", WHITE

Traditional Style

Soft Close oven door Full-width continuous grates Stainless steel storage drawer beneath the oven

GAS OVEN:

4 cooking modes

Programmable timer with touch display Adjustable thermostat 120° - 500° F Air-cooled triple-glazed removable door

True European Double Convection

Oven capacity: 4.5 cu ft

EverClean enameled interior cavity

5 shelf positions 2 halogen oven lights Bake element 1.7 kW Broil element 2.9 kW Convection element 1.5 kW

GAS RANGETOP:

5 gas burners Right-rear: 8,000 BTUs Left-rear: 8,000 BTUs

Central double-inset super burner: 20,000 BTUs

Right-front: 4,500 BTUs Left-front: 12,000 BTUs Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

SAFETY:

Gas safety valves Air-cooled door to prevent overheating Connected load nominal power: 240/120V – 15 Amps Voltage rating: 240/120V 60Hz

ACCESSORIES INCLUDED:

1 wok ring 1 deep oven tray 1 total-extraction telescopic guide 2 chrome shelves 1 Island trim

OPTIONS:

BGTR9 Grill plate GT1T-2 1-Level telescopic shelf total extraction PPR9 Pizza stone TPKTR9 Teppanyaki grill plate

Programmable Timer with Touch display Adjustable thermostat 120° - 500° F Air-cooled triple-glazed removable door

Triple Convection

Oven capacity: 4.5 cu ft

EverClean enameled interior cavity

5 shelf positions 2 x halogen oven lights

GAS RANGETOP:

5 gas burners Right-rear: 8,000 BTUs Left-rear: 8,000 BTUs

Central double-inset super burner: 20,000 BTUs

Right-front: 4,500 BTUs Left-front: 12,000 BTUs Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

SAFETY:

Gas safety valves Air-cooled door to prevent overheating Connected load nominal power: 200 W - 2 Amps Voltage rating: 120V 60Hz

ACCESSORIES INCLUDED:

1 wok ring 1 deep oven tray 1 total-extraction telescopic guide 2 chrome shelves 1 Island trim

OPTIONS:

BGTR9 Cast-iron grill plate GT1T-2 1-Level telescopic shelf total extraction PPR9 Pizza stone TPKTR9 Teppanyaki grill plate

TRU36

For technical drawing in metric, see page 174

RANGES VICTORIA

TRU36GGWH with KTU36WH hood

TRU90P

FREE-STANDING DUAL-FUEL CAVITY "VICTORIA" RANGE, 36" X 25", CREAM

Traditional Style

Electronic clock with programmable features Full-width continuous grates Stainless steel storage drawer beneath the oven 5 1/3” stainless steel backsplash

MULTIFUNCTION ELECTRIC OVEN:

8 cooking modes

Programmable timer Adjustable thermostat 120° - 500° F Air-cooled triple-glazed removable door

True European Double Convection

Oven capacity: 4.4 cu ft EverClean enameled interior cavity 4 shelf positions 2 halogen oven lights Bake element 3.0 kW Broil element 2.9 kW Convection element 1.55 kW

GAS RANGETOP:

5 gas burners Right-rear: 6,500 BTUs Left-rear: 6,500 BTUs

Central double-inset super burner: 18,000 BTUs

Right-front: 3,400 BTUs Left-front: 10,000 BTUs Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

TRU90X

Stainless Steel

SAFETY:

TRU90BL

Glossy Black

Gas safety valves Air-cooled door to prevent overheating

Connected load nominal power: 240/120V Voltage rating: 240/120V 60Hz Amp supply required: 240/120V - 15/13.5 Amps Gas inlet location: back top-right

ACCESSORIES INCLUDED:

1 wok ring 1 moka ring 1 rotisserie kit 2 baking trays 2 chrome shelves

OPTIONS:

KITITR90-1 Black island trim KIT1TR9N Black backsplash KIT1TR9X Stainless steel backsplash KITITR90X-1 Stainless steel island trim TPKTR9 Teppanyaki grill plate

For technical drawing in metric, see page 174

RANGES VICTORIA

KTU36X with backsplash and TRU90X range

TRU36GGBL

FREE-STANDING ALL-GAS "VICTORIA" RANGE, 36", GLOSSY BLACK

Traditional Style

Electronic clock with programmable features Full-width continuous grates Stainless steel storage drawer beneath the oven

GAS OVEN:

5 cooking modes

Programmable timer Adjustable thermostat 122° -500° F Air-cooled triple-glazed removable door True European convection Oven capacity: 4.4 cu ft EverClean enameled interior cavity 4 shelf positions 2 halogen oven lights Bake element 1.7 kW Broil element 2.9 kW Convection element 1.55 kW

GAS RANGETOP:

5 gas burners Right-front: 6,500 BTUs Right-rear: 6,500 BTUs

Central double-inset super burner: 18,000 BTUs

Left-front: 3,400 BTUs Left-rear: 10,000 BTUs Heavy-duty cast-iron grates Automatic electric ignition LP gas conversion kit included

TRU36GGX

Stainless Steel

SAFETY:

TRU36GGP

Cream

Gas safety valves Air-cooled door to prevent overheating Connected load nominal power: 240/120V Voltage rating: 240/120V 60Hz Amp supply required: 240/120V - 15/13.5 Amps Gas inlet location: back top-right

ACCESSORIES INCLUDED:

1 wok ring 1 moka ring 1 rotisserie kit 2 baking trays 2 chrome shelves 5 -1/2" backsplash 1 ¼” Island trim

OPTIONS:

KIT1TR9N Black backsplash KIT1TR9X Stainless steel backsplash TPKTR9 Teppanyaki grill plate

For technical drawing in metric, see page 174

RANGES VICTORIA

KTU36P hood with TRU36GGP range

C36GGXU

FREE-STANDING GAS RANGE, 36”, STAINLESS STEEL

Professional Style

AISI 304 stainless steel Sturdy American-style control knobs 4" polished stainless steel backsplash

GAS OVEN:

3 cooking modes

Gas double convection mode Broil mode Defrost mode Fan option for static gas EverClean enameled oven interior 4 shelf positions Air-cooled triple-glazed removable door 2 halogen oven lights Oven capacity: 4.4 cu ft

GAS RANGETOP:

Heavy-duty cast-iron grates Full-width grates Sealed burners Automatic electronic ignition Safety valves LP gas conversion kit included

6 GAS BURNERS:

Front-right: 6,200 BTUs Back-right: 10,000 BTUs Front-center: 3,400 BTUs

Back-right double-inset super burner: 15,000 BTUs

Front-left: 6,200 BTUs Back-left: 3,400 BTUs

C36GGRU

Red

SAFETY:

Gas safety valves Ventilated door with cooling system to prevent overheating Anti-tilting norms satisfied Suitable for built-in applications

Connected load nominal power: 120V Amp supply required: 120V - 1.2 Amps Voltage rating: 120V 60Hz Gas inlet location: back top-right

ACCESSORIES INCLUDED:

1 baking tray 1 chrome shelf 1 wire rack 1 wok ring 1 moka ring

OPTIONAL ACCESSORIES:

KITI36XU Island trim 8MCCU "Classic" control knob kit

C36GGBU

White

C36GGNU

Black

For technical drawing in metric, see page 174

RANGES PRO-STYLE

C36GGXU

C30GGXU1

FREE-STANDING GAS RANGE, 30”, STAINLESS STEEL

Professional Style

AISI 304 stainless steel Sturdy American-style control knobs 4” polished stainless steel backsplash

GAS OVEN:

3 cooking modes

Gas convection mode Broil mode Defrost mode Timer with alarm Air-cooled triple-glazed removable door EverClean enameled oven interior 4 shelf positions 2 halogen oven lights Oven capacity: 3.6 cu ft

GAS RANGETOP:

Heavy-duty cast-iron grates Full-width grates Sealed burners Automatic electronic ignition incorporated in the control knobs LP gas conversion kit included Deep rangetop base to contain spillage

5 GAS BURNERS:

Front-right: 10,100 BTUs Back-right: 10,100 BTUs Center: 17,000 BTUs Front-left: 10,100 BTUs Back-left: 10,100 BTUs 4 burners with True Simmer function

C30GGRU

Red

SAFETY:

Gas safety valves Ventilated door with cooling system to prevent overheating Anti-tilting norms satisfied Suitable for built-in applications

Connected load nominal power: 120V Amp supply required: 120V 1.2Amps Voltage rating: 120V 60Hz Gas inlet location: back top-right

ACCESSORIES INCLUDED:

1 baking tray 1 chrome shelf 1 wok ring 1 moka ring

OPTIONAL ACCESSORIES:

KITI30XU Island trim 8MCCU "Classic" control knob kit

C30GGBU

White

C30GGNU

Black

For technical drawing in metric, see page 174

C24GGXU

FREE-STANDING GAS RANGE, 24”, STAINLESS STEEL

RANGES PRO-STYLE

HIGH PERFORMANCE FOR SMALL SPACES

Professional Style

AISI 304 stainless steel Sturdy American-style control knobs 4” polished stainless steel backsplash

GAS OVEN:

3 cooking modes

Gas convection mode Broil mode Defrost mode Air-cooled triple-glazed removable door EverClean enameled oven interior 5 shelf positions 2 halogen oven lights Oven capacity: 2.8 cu ft

GAS RANGETOP:

Heavy-duty cast-iron grates Full-width grates Sealed burners Automatic electronic ignition Safety valves LP gas conversion kit included

4 GAS BURNERS:

Front-right: 6,200 BTUs

Back-right double-inset super burner: 15,000 BTUs

Back-left: 3,400 BTUs Front-left: 6,200 BTUs

Connected load nominal power: 120V Amp supply required120V 1.2 Amps Voltage rating: 120V 60Hz Gas inlet location: back top-right

SAFETY:

Gas safety valves Ventilated door with cooling system to prevent overheating Anti-tilting norms satisfied Suitable for built-in applications

ACCESSORIES INCLUDED:

1 baking tray 2 chrome shelves 1 wok ring 1 moka ring

OPTIONAL ACCESSORIES:

KITI24XU Island trim GT1T-1 Telescopic guides - full-extension GT1P-1 Telescopic guides - half-extension 8MCCU "Classic" control knob kit

5 cooking positions to cook various dishes at the same time, or to easily accommodate large items

• Largest cavity oven in its class (2.8 cu ft)

For technical drawing in metric, see page 174

S9GMXU9

FREE-STANDING DUAL-FUEL RANGE, APPROX. 36”, STAINLESS STEEL

Professional Style

Stainless steel Sturdy American-style control knobs Island trim backsplash

MULTIFUNCTION ELECTRIC OVEN:

8 cooking modes

Programmable timer with touch display Air-cooled double-glazed removable door True European Double convection EverClean enameled oven interior 5 shelf positions 2 oven lights Oven capacity: 4.5 cu ft Bake element 1.2 kW Broil element 1.8 kW Convection element 2.9 kW

GAS RANGETOP:

Heavy-duty cast-iron grates Full-width grates Sealed burners Automatic electronic ignition Safety valves LP gas conversion kit included

5 GAS BURNERS:

Front-right: 3,400 BTUs Back-right: 6,200 BTUs

Central double-inset super burner: 14,000 BTUs

Front-left: 9,000 BTUs Back-left: 6,200 BTUs

SAFETY:

Gas safety valves Ventilated door with cooling system to prevent overheating Anti-tilting norms satisfied Suitable for built-in applications

Connected load nominal power: 240/120V –

3.7kW Amp supply required 240/120V 15 Amps Voltage rating: 240/120V 60Hz Gas inlet location: back top-right

ACCESSORIES INCLUDED:

1 baking tray 2 chrome shelves 1 moka ring

OPTIONAL ACCESSORIES:

KITI9XU Island trim KITPS9U Stainless steel toe kick

For technical drawing in metric, see page 174

COOKING ACCESSORIES

SMEG offers a variety of accessories for ovens, cooktops, and ranges, which enhance the appliances, and provide added flexibility.

GT1T-2

1-LEVEL TELESCOPIC SHELF - TOTAL-EXTRACTION

Pair of fully-extractable telescopic guides. Also AvAilAble: GT1P-1 Telescopic shelf set with 1 partially-extractable level.

GO120

CAST-IRON OPEN GRIDDLE FOR BARBECUE

DICAR PRTX

SIMMER PLATE

5pc simmer plate pack suitable for use on all SMEG ranges and gas cooktops.

TPKTR9

TEPPANYAKI GRILL PLATE

pizza stone with handles

Refractory pizza stone with handle, suitable for use with SF399XU. With the oven set at 250º, the pizza stone allows you to cook a very Italian pizza in only 4 minutes.

WOKGHU

CAST-IRON WOK SUPPORT

RANGES PRO-STYLE

The GO120 is intended to replace the plate on A3XU7 ranges with the electric griddle, to convert it to a barbecue.

Stainless steel grill plate designed for cooking teppanyaki dishes. Suitable for Portofino 36" and Victoria series.

The WOKGHU offers additional stability when using a wok. Suitable for most ranges and cast-iron gas cooktops, except for all "Classic" front control 24" gas cooktops.

MODEL/DESCRIPTION/COMPATIBLE WITH:

TPKCPF30 Teppanyaki grill plate suitable for Portofino 30" CPF30 BGTR9 Cast-iron grill plate suitable for Victoria and Portofino 36" CPF36 BGTR4110 Cast-iron Grill Plate for Portofino 48" CPF48 BGCPF30 Cast-iron grill plate suitable for Portofino 30" CPF30 TPKX Teppanyaki grill plate A3XU7 KIT3A31-6 Extension kit to rise the appliance by 1" A3XU7 KIT1A3-6 Backsplash A3XU7 KITIA1 Island trim KIT2A1-2 Toe kick in brushed stainless steel KIT3-6 2" height extension KITI36XU Island trim C36GGXU KITI30XU Island trim C30GGXU-1 KITI24XU Island trim C24GGXU KITI9XU Island trim S9GMXU KITDS9U Depth extension kit S9GMXU9 KITPS9U Stainless steel plinth S9GMXU9 KITITR90X-1 Island trim, stainless steel TRU90P, TRU90X, TRU90BL KIT1TR9N Black backspalsh TRU90BL KITITR90-1 Island trim, black TRU90BL, TRU90P, TRU90X KIT1TR9X Stainless steel backsplash TRU90P, TRU90X, TRU90BL PALPZ Pizza shovel with fold away handle PPR9 Refractory pizza stone, square shape GTA-6 3-level telescopic shelf set A1PXU, A3XU7 8MCCU "Classic" control knobs kit C24GGXU, C30GGXU1, C36GGXU

HOODS

Hoods play an important role in the

kitchen, both aesthetic and functional.

Designed to offer the best combination

of styling and functionality, SMEG hoods

reflect the elegance and style of their

matching appliances.

HOODS

KPF36UYW

KPF48UOG

48” PORTOFINO VENTILATION HOOD, OLIVE GREEN

Portofino Design

Wall-mounted ventilation hood Control adjustment knobs 3 speeds and additional intensive speed 4 LED lights Motor power: 455 W 4 stainless steel grease filters 600 CFM max setting Electrical connection rating: 535 W - 5 Amps Voltage: 120V 60Hz

OPTIONS:

FLTK-1 Charcoal filter KITREDCFM CFM reducer

KPF48URD

Red

KPF48UOR

Orange

KPF48UX

Stainless Steel

KPF48UYW

Yellow

KPF48UBL

Black

KPF48UAN

Matte Black

KPF48UWH

White

KPF48UOG

Olive Green

For technical drawing in metric, see page 175

PORTOFINO

HOODS

KPF48UYW hood with backsplash and CPF48UGMYW range

KPF36UOR

36” PORTOFINO VENTILATION HOOD,ORANGE

Portofino Design

Wall-mounted ventilation hood Control adjustment knobs 3 speeds and additional intensive speed 2 LED lights Motor power: 455 W 3 stainless steel grease filters 600 CFM max setting Electrical connection rating: 495 W - 5 Amps Voltage: 120V 60Hz

OPTIONS:

FLTK-1 Charcoal filter KITREDCFM CFM reducer

KPF36URD

Red

KPF36UOR

Orange

KPF36UX

Stainless Steel

KPF36UYW

Yellow

KPF36UBL

Black

KPF36UAN

Matte Black

KPF36UWH

White

KPF36UOG

Olive Green

For technical drawing in metric, see page 175

KPF30UX

30” PORTOFINO VENTILATION HOOD, STAINLESS STEEL

Portofino Design

Wall-mounted ventilation hood Control adjustment knobs 3 speeds and additional intensive speed 2 LED lights Motor power: 455 W 3 aluminium grease filters 600 CFM max setting Electrical connection rating: 485 W - 5 Amps Voltage: 120V 60Hz

OPTIONS:

FLTK-1 Charcoal filter KITREDCFM CFM reducer

KPF30URD

Red

KPF30UOR

Orange

KPF30UX

Stainless Steel

KPF30UYW

Yellow

KPF30UBL

Black

KPF30UAN

Matte Black

KPF30UWH

White

HOODS PORTOFINO

KPF30UOG

Olive Green

For technical drawing in metric, see page 175

KTU36P

36” VICTORIA VENTILATION HOOD, CREAM

Traditional Victoria Design

Wall-mounted ventilation Stylish ergonomic control knobs Front-mounted controls for lights and vent speeds

1 fan motor 4 speeds 2 halogen lights (2x20W) 3 dishwasher-safe aluminium grease filters

Vented or recirculating

600 CFM max setting Vent duct size: 6”

Voltage rating: 120V/60Hz/4.5 Amps Nominal power: 445 W

OPTIONS:

FLTK-1 Charcoal filter KITCMNKPU Cream chimney extension KITCMNKXU Stainless steel chimney extension KITCMNKBU Black chimney extension

KTU36X

Stainless steel

KTU36BL

Glossy Black

KTU36WH

White

VENT OUT RECIRCULATION

SMEG hoods can operate in either a ducted or recirculation mode. Best performance is achieved in the ducted mode, the preferred choice wherever possible.

Extractor hood: extracts the cooking fumes and expels them outside, using a vent kit. The diameter of the ducting hose should match the vent outlet of the hood.

Filter hood: extracts the cooking fumes and passes them through active charcoal ﬁlters, recirculating the cleaned air into the room.

For technical drawing in metric, see page 175

HOODS VICTORIA

KTU36P hood with TRU36GGP range

KD120XU

120 CM (APPROX. 48”) VENTILATION HOOD, STAINLESS STEEL

“Classic” Design

Wall-mounted ventilation Stylish ergonomic control knobs Premium-quality stainless steel Front-mounted controls for lights and vent speeds

1 twin fan motor 240 W 4 speeds 2 halogen bulbs (2x20W) 4 dishwasher-safe stainless steel grease filters

Vented or recirculating

770 CFM max setting Vent duct size: 6"

Voltage rating: 120V/60Hz/4.5 Amps Nominal power: 485 W

OPTIONS:

FLTK1 Charcoal filter KITCMNKD Chimney extension KITREDCFM CFM reducer

For technical drawing in metric, see page 175

KD90XU

KDU30X

90 CM (APPROX. 36”) VENTILATION HOOD, STAINLESS STEEL

“Classic” Design

Wall-mounted ventilation Stylish ergonomic control knobs Premium-quality stainless steel Front-mounted controls for lights and vent speeds

1 fan motor 4 speeds 2 halogen bulbs (2x20W) 3 dishwasher-safe stainless steel grease filters

30'' VENTILATION HOOD, STAINLESS STEEL

HOODS PRO-STYLE

“Classic” Design

Wall-mounted ventilation Stylish ergonomic control knobs Premium-quality stainless steel Front-mounted controls for lights and vent speeds

1 fan motor 4 speeds 2 halogen bulbs (2x20W) 3 dishwasher-safe stainless steel grease filters

Vented or recirculating

600 CFM max setting Vent duct size: 6”

Voltage rating: 120V/60Hz/4.5 Amps Nominal power: 485 W

OPTIONS:

FLTK1 Charcoal filter KITCMNKD Chimney extension KITREDCFM CFM reducer

Vented or recirculating

600 CFM max setting Vent duct size: 6”

Voltage rating: 120V/60Hz/4.5 Amps Nominal power: 485 W

OPTIONS:

FLTK1 Charcoal filter KITCMNKD Chimney extension KITREDCFM CFM reducer

For technical drawing in metric, see page 175 For technical drawing in metric, see page 175

KSM36XU

90 CM (APPROX. 36”), VENTILATION HOOD, STAINLESS STEEL

Flat Design

Wall-mounted ventilation hood High-quality stainless steel Front-mounted controls for lights and vent speeds

1 motor Vented or recirculating 4 speeds 3 halogen lights (3x20W) 3 dishwasher-safe grease filters

FEATURES AT A GLANCE

To assist in the selection of the right hood, a number of symbols appear beneath each model, and help to check and compare the products on offer. Some examples are shown here, but details of the full range of symbols can be found at the back of the catalogue.

Electronic display to give a visual reminder of the options selected

Touch control panel, all options selected at the touch of a ﬁngertip

Intensive/turb setting, when extrafast extraction is required

Warning light(s), to advise when ﬁlters need changing

600 CFM max. setting Vent duct size: 6” Voltage rating: 120V/60Hz/4.5 Amps

OPTIONS:

KITFC161 Charcoal filter KITSMNKSM Chimney extension

For technical drawing in metric, see page 175

KSM30XU

KSM24XU

30" VENTILATION HOOD, STAINLESS STEEL

Flat Design

Wall-mounted ventilation hood High-quality stainless steel Front-mounted controls for lights and vent speeds

1 motor Vented or recirculating 3 speeds 2 halogen lights (2x20W) 2 dishwasher-safe grease filters

60 CM (APPROX. 24”), VENTILATION HOOD, STAINLESS STEEL

HOODS PRO-STYLE

Flat Design

Wall-mounted ventilation hood High-quality stainless steel Front-mounted controls for lights and vent speeds

1 motor Vented or recirculating 4 speeds 2 halogen lights (2x20W) 3 dishwasher-safe grease filters

600 CFM max. setting Vent duct size: 6” Voltage rating: 120V/60Hz/4.5 Amps

OPTIONS:

KITFC161 Charcoal filter KITSMNKSM Chimney extension KITREDCFM CFM reducer

600 CFM max. setting Vent duct size: 6” Voltage rating: 120V/60Hz/4.5 Amps

OPTIONS:

KITFC161 Charcoal filter KITSMNKSM Chimney extension KITREDCFM CFM reducer

For technical drawing in metric, see page 175 For technical drawing in metric, see page 176

KUC48X

KUC36X

48" PRO-STYLE, UNDER- CABINET HOOD, STAINLESS STEEL

Pro-Style

Under-cabinet hood High-quality stainless steel Pro-Style and Portofino knobs

1 motor Vented or recirculating 4 speeds 2 halogen lights (2x20W) 3 dishwasher-safe grease filters

36" PRO-STYLE, UNDER-CABINET HOOD, STAINLESS STEEL

Pro-Style

Under-cabinet hood High-quality stainless steel Pro-Style and Portofino knobs

1 motor Vented or recirculating 4 speeds 2 halogen lights (2x20W) 3 dishwasher-safe grease filters

600 CFM max. setting Vent duct size: 6” Voltage rating: 120V/60Hz/4.5 Amps Nominal power: 455 W

OPTIONS:

FLTK-1 Charcoal filter

600 CFM max. setting Vent duct size: 6” Voltage rating: 120V/60Hz/4.5 Amps Nominal power: 455 W

OPTIONS:

FLTK-1 Charcoal filter

For technical drawing in metric, see page 176

KUC30X

KUC24X

30" PRO-STYLE, UNDER-CABINET HOOD, STAINLESS STEEL

Pro-Style

Under-cabinet hood High-quality stainless steel Pro-Style and Portofino knobs

1 motor Vented or recirculating 4 speeds 2 halogen lights (2x20W) 2 dishwasher-safe grease filters

24" PRO-STYLE, UNDER-CABINET HOOD, STAINLESS STEEL

HOODS PRO-STYLE

Pro-Style

Under-cabinet hood High-quality stainless steel Pro-Style and Portofino knobs

1 motor Vented or recirculating 4 speeds 2 halogen lights (2x20W) 2 dishwasher-safe grease filters

600 CFM max. setting Vent duct size: 6” Voltage rating: 120V/60Hz/4.5 Amps Nominal power: 455 W

OPTIONS:

FLTK-1 Charcoal filter

600 CFM max. setting Vent duct size: 6” Voltage rating: 120V/60Hz/4.5 Amps Nominal power: 455 W

OPTIONS:

FLTK-1 Charcoal filter

For technical drawing in metric, see page 176

OVENS

Exceptional materials, state-of-the-art

technology, and an uncompromising

approach to aesthetics are the guiding

principles behind SMEG’s acclaimed built-

in ovens.

OVENS

SFU7302TVX

CLEANING MADE SIMPLE

maximum attention to hygiene

VAPOR-CLEAN

The eco-friendly Vapor-Clean function facilitates cleaning through the use of steam. This steam is generated by inserting a small amount of water into the groove in the cavity, with no need for chemical additives. This process also uses less energy.

TILTING GRILL

The grill can be easily unhooked to move the heating element away, and clean the roof of the appliance in one simple step.

EVERCLEAN ENAMEL

The enamel nish of the oven cavities have a special lining that helps to reduce the amount of dirt and grime that adheres to the surface.

SELF-CLEANING

This automatic cleaning function works by heating the inside of the oven to 930°F to burn off any grease and dirt. For a safer environment, all self-clean ovens feature quadrupleglazed door, and Fresh Touch door.

EUROPEAN CONVECTION

Many SMEG ovens feature true European convection, where an additional heating element heats the air as it comes through the convection fans, allowing for more-even and more-efcient heating.

FRESH TOUCH DOOR

All pyrolytic ovens feature a Fresh Touch door, which means that during the pyrolytic cleaning cycle, the outer glass will become no hotter than 130°F. A special device also locks the door for the duration of the process, which along with quadruple-glazed doors, provides total safety.

REMOVABLE INNER

DOOR

The single at surface of the inner glass door is totally removable, to make cleaning an easy task.

SPECIAL FUNCTIONS

a truly Italian pizza in 4 minutes

REFRACTORY STONE

A pizza stone accessory placed at the base of the oven cavity above the lower heating element allows for a perfect pizza to be cooked in just 3 to 5 minutes.

OVENS

Some SMEG wall ovens are equipped with a special system which places the heating element in direct contact with a pizza stone accessory, allowing you to create perfect, delicious, evenly-cooked pizzas in just 3 to 4 minutes, or 5 minutes with toppings. They can also provide excellent results when cooking breads, pies, and more, even vegetables, and sh in foil without having to dry them out.

SFU6104TVS

60 CM (APPROX. 24”) LINEA DESIGN MULTIFUNCTION OVEN, MYSTIC GRAY GLASS

Linea Design

Multifunction oven with 10 cooking modes

Touch screen controls

Mystic Gray glass finish

Color TFT touch screen display

SmartCook System

50 automatic cooking program 10 customizable recipes

Electronic temperature control

True European convection

Adjustable temperature: 87 - 536˚ F Rapid preheat

Vapor-Clean system

EverClean enamel cavity for quick and easy cleaning Automated oven switch-off when door is open 5 rack positions

Soft Close door

Double-insulated cavity Air-cooled door Ceramic catalyst fume control Child-safe control lock Safe-touch cooling Quadruple-glazed removable door Quickly removable, easy-to-clean inner door glass 2 Halogen lights (2 x 40 W)

Oven capacity: 2.8 cu ft Bake element: 1,700W @ 240V Broil element: 2,700W @ 240V Convection element: 2,000W @ 240V

Voltage rating: 120/240V 60Hz Connected load (nominal power): 3 kW Amps: 14 Amps

ACCESSORIES INCLUDED:

1 telescopic guide rail (total extraction) 1 wire rack with tray insert 1 wire rack 1 deep enamel tray 2 enamel trays

For technical drawing in metric, see page 177

OVENS LINEA

SFU6104TVS

SOU130S1 SELF-CLEANING

76 CM (APPROX. 30”) LINEA DESIGN MULTIFUNCTION OVEN, MYSTIC GRAY GLASS

Linea Design

Multifunction oven with 6 cooking modes

Touch screen controls

Mystic Gray glass finish

Color TFT touch screen display 70 automatic cooking program

Defrost by time, defrost by weight, rising, dehydrate, and self-cleaning cycle True European double convection Fast preheat cycle (8 - to - 12 minutes) Adjustable temperature: 80° - 590°F Automated oven switch-off when door is open Self-cleaning Sabbath mode Child safety locks 6 rack positions Air-cooled door Triple-glazed removable door

Oven capacity: 4.34 cu ft Interior dimensions: W 24” x H 16 - 1/8” x D 16 - 5/16“ Concealed bake element Broil element 3.5 kW Voltage rating: 240/208V 60Hz Connected load (nominal power): 240/208V:

16.9/17.5 Amps Power supply location: center-top

ACCESSORIES INCLUDED:

1 grid insert for tray 2 grid tops 1 telescopic guide 1 enameled tray 1 meat probe

For technical drawing in metric, see page 177

OVENS LINEA

SOU130S1

SC712U

70 CM (APPROX. 27”) LINEA DESIGN MULTIFUNCTION OVEN, STAINLESS STEEL AND SUPERSILVER GLASS

SF112U

60 CM (APPROX. 24”) LINEA DESIGN MULTIFUNCTION OVEN, STAINLESS STEEL AND SUPERSILVER GLASS

Linea Design

Multifunction oven with 12 cooking modes

Stainless steel Supersilver glass finish Ergonomic backlit transparent controls Digital electronic program feature with multi-display Automated oven switch-off when door is open Electronic temperature control Stay-clean liners Air-cooled door Triple-glazed removable door Quickly removable, easy-to-clean inner door glass

Oven capacity: 3.2 cu ft Interior dimensions: W 22 Adjustable temperature: 86° - 536° F

” x H 12

” x D 16”

Voltage rating: 240/208V 60 Hz Connected load (nominal power): 240/208V

3.7/2.76kW Amps @ 240/208V: 15.4/13.2 Amps Power supply location: Back-right bottom

ACCESSORIES INCLUDED:

1 baking tray 1 broil pan with broiler rack 2 wire racks 1 rotisserie kit

OPTIONS:

GT90X - 3-level telescopic rack set

Linea Design

Multifunction oven with 12 cooking modes

Stainless steel Supersilver glass finish Ergonomic backlit transparent controls Silver glass & stainless finish Digital electronic program feature with multi-display Dual digital displays for cooking readouts Electronic temperature control Adjustable temperature 105 - 480˚ F Rapid preheat Double-insulated cavity Ceramic catalyst fume control Multi-glazed removable door Safe-touch cooling

Oven capacity: 2.8 cu ft Bake element: 2,200W @ 240V Broil element: 2,700W @ 240V Convection element: 2,000W @ 240V

Voltage rating: 240/120V 60 Hz Connected load (nominal power): 3.5 kW Amps: 14 Amps

ACCESSORIES INCLUDED:

1 wire rack with tray insert 1 wire rack 1 deep enamel tray

SC712U

SF112U

For technical drawing in metric, see page 177

SOU130S SELF-CLEANING

76 CM (APPROX. 30”) LINEA DESIGN ELECTRIC MULTIFUNCTION OVEN, STAINLESS STEEL AND SUPER SI LVER GLASS

Linea Design

Multifunction oven with 6 cooking modes

Stainless steel Supersilver glass finish Defrost by time, defrost by weight, rising, dehydrate, and self-cleaning cycle Digital display True European double convection Fast preheat cycle (8 to 12 minutes) Adjustable temperature: 86° - 554° F Automated oven switch-off when door is open Self-cleaning Sabbath mode Child safety locks 6 rack positions Air-cooled door Triple-glazed removable door

Oven capacity: 4.34 cu ft Interior dimensions: W 24” x H 16 - 1/8” x D 16 5/16“ Concealed bake element Broil element 3.5 kW Voltage rating: 240/208V 60 Hz Connected load (nominal power): 240/208V:

16.9/17.5 Amps Power supply location: center-top

ACCESSORIES INCLUDED:

1 grid insert for tray 2 grid tops 1 telescopic guide 1 enameled tray 1 meat probe

OVENS LINEA

For technical drawing in metric, see page 177

SFU7302TVX

70 CM (APPROX. 27”) “CLASSIC” DESIGN

MULTIFUNCTION OVEN, STAINLESS STEEL AND SMART-BL ACK GLASS

SFU6302TVX

60 CM (APPROX. 24”) “CLASSIC” DESIGN

MULTIFUNCTION OVEN, STAINLESS STEEL AND SMART-BL ACK GLASS

“Classic” Design

Multifunction oven with 9 cooking modes

Stainless steel and Smart-black glass finish Fingerprint-proof stainless steel Ergonomic control knobs

Large LCD display 20 automatic cooking program

Automated oven switch-off when door is open Electronic temperature control

True European convection

Adjustable temperature 87 - 536˚ F Rapid preheat

Vapor-Clean system

EverClean enamel cavity for quick and easy cleaning 4 rack positions Double-insulated cavity Air-cooled door Ceramic catalyst fume control Child-safe control lock Safe-touch cooling Triple-glazed removable door Quickly-removable, easy-to-clean inner door glass 2 Halogen lights (2 x 40 W)

Oven capacity: 3.2 cu ft Interior dimensions: W 24” x H 16

” x 16

”

Voltage rating: 240/208V 60 Hz Connected load (nominal power): 240/208V - 3.7/2.76 kW Amps @ 240/208V: 17.5 Amps Power supply location: Back-right bottom

ACCESSORIES INCLUDED:

1 grid with backstop 1 insert gird 2 enamelled trays (20mm)

“Classic” Design

Multifunction oven with 12 cooking modes

Stainless steel and Smart-black glass finish Fingerprint-proof stainless steel Ergonomic control knobs

Large LCD display 20 automatic cooking program

Automated oven switch-off when door is open Electronic temperature control

True European convection

Adjustable temperature 87 - 536˚ F Rapid preheat

Vapor-Clean system Soft Close door

EverClean enamel cavity for quick and easy cleaning 5 rack positions Double-insulated cavity Air-cooled door Ceramic catalyst fume control Child-safe control lock Safe-touch cooling Triple-glazed removable door Quickly-removable, easy-to-clean inner door glass 2 Halogen lights (2 x 40 W)

Oven capacity: 2.8 cu ft Interior dimensions: W 18,11” x H 14,17” x 16,73”

Voltage rating: 240/120V 60 Hz Connected load (nominal power): 3 kW Amps: 14 Amps

ACCESSORIES INCLUDED:

1 telescopic guide rail (total extraction) 1 grid with backstop 1 insert gird 1 enamelled tray (20mm) 1 enamelled tray (40mm)

SFU7302TVX

SFU6302TVX

For technical drawing in metric, see page 177

OVENS CLASSIC

SFU6302TVX

SOU330X1 SELF-CLEANING

76 CM (30”) "CLASSIC" ELECTRIC MULTIFUNCTION OVEN STAINLESS STEEL AND SMART-BLACK GLASS

“Classic” Design

Multifunction oven with 11 cooking modes

Stainless steel and Smart-black glass finish Fingerprint-proof stainless steel Ergonomic control knobs

Electronic display

Electronic temperature control

True European Double convection

Adjustable temperature 87 - 554˚ F Fast preheat cycle (8 to 12 minutes)

Self-Cleaning

Door lock during self cleaning Automated oven switch-off when door is open 6 rack positions Double-insulated cavity Air-cooled door Safe-touch cooling Triple-glazed removable door 2 Halogen lights (3 x 20 W)

Oven capacity: 4.34 cu ft Interior dimensions: W 24” x H 16,15” x D 16,34“ Voltage rating: 240/208V 60 Hz Connected load (nominal power): 240/208V 3,535 W Amps @ 240/208V: 15.6 Amps

ACCESSORIES INCLUDED:

2 grids with back and side stops 1 insert grid 1 enamel tray 1 telescopic guide 1 meat probe

For technical drawing in metric, see page 177

OVENS CLASSIC

SOU330X1

DOUBLE OVEN WITH SMART-BLACK GLASS FINISH

DOU330X1 SELF-CLEANING

76 CM (30”) "CLASSIC" ELECTRIC MULTIFUNCTION DOUBLE OVEN, STAINLESS STEEL AND SMART-BLACK GLASS

The “Smart-Black” glass is an elegant glass type that appears completely opaque when the oven is off, and becomes transparent when the oven is on.

For technical drawing in metric, see page 177

MAIN AND SECONDARY OVEN

“Classic” Design

Two multifunction ovens, each with 10 cooking modes (including warming and dehydrate) + self-cleaning cycle

Fingerprint-proof stainless steel Ergonomic control knobs Touch control panel to access secondary menu Electronic display True European double convection Fast preheat cycle (8 to 12 minutes) Adjustable temperature: 86° - 554° F Automated oven switch-off when door is open Self-cleaning Sabbath mode Child safety locks 6 rack positions 1 telescopic guide

Oven capacity: 4.34 cu ft Interior dimensions: W 24” x H 16 Concealed bake element

” x 16

”

Voltage rating: 240/208V 60Hz Connected load (nominal power): 240/208V: 32.4/33.8 Amps

Power supply location: center-top

ACCESSORIES INCLUDED (MAIN AND SECONDARY OVEN):

1 grid insert for tray 3 grid tops 1 telescopic guide 1 enameled tray 1 meat probe

SF399XU

60 CM (APPROX. 24”) "CLASSIC" ELECTRIC MULTIFUNCTION OVEN, STAINLESS STEEL AND SMART-BLACK GLASS

“Classic” Design

Multifunction oven with 10 cooking modes

Fingerprint-proof stainless steel Ergonomic control knobs Digital analog LED electronic clock/timer EverClean enamel cavity for quick and easy cleaning Automated oven switch-off when door is open 5 rack positions

True European convection

Adjustable temperature: 122° - 490° F

Vapor-Clean system

Air-cooled door Triple-glazed removable door Quickly removable, easy-to-clean inner door glass 2 Halogen lights (2 x 20 W) Roof liner

Oven capacity: 2.8 cu ft Inner dimensions: W 17½” x H 1411/64” x D 16¾” Bake element 2.2 kW Broil element 2.7 kW Convection element 2.0 kW Voltage Rating: 240/120V 60Hz Connected load (nominal power) 3.5 kW Amps 240/120V: 14 Amps Power supply location: back right bottom

ACCESSORIES INCLUDED:

1 baking tray 1 wire rack with tray insert

1 wire rack with backstop

OPTIONS:

PRTX Pizza stone with handles PALPZ Pizza shovel with fold away handle

A truly Italian pizza cooked in only 4-5 minutes! With the oven set at 490ºF, the pizza stone allows you to cook the pizza rapidly.

PRTX

PALPZ

OVENS CLASSIC

For technical drawing in metric, see page 177

COMPACT OVENS AND

COFFEE MACHINES

Small space appliance engineering meets

multi-tasking cooking technologies to

create state-of-the-art kitchen appliances

that truly deliver fine cuisine and delightful

beverages right at home.

COMPACT OVENS

COFFEE MACHINES

SU45VCX1 atop CMSU6451X

COMPACT APPLIANCES

personality and style

SMEG offers design-coordinated compact appliances with multiple functions for your kitchen, allowing for the creation of a small, efcient work area for the cook that has an eye for personality and style.

COMBINATION STEAM OVEN, A HEALTHY LIFESTYLE

The combination steam oven offers a variety of cooking solutions in one appliance for maximum user exibility. It can be used either as a steam oven, or as a traditional oven, or alternatively the two methods can be combined allowing the user to cook the tastiest dishes in the healthiest way possible.

The oven is also equipped with a broiler to brown food at the end of the cooking time and give it a delicious crispy nish. Steaming is also ideal for cooking different foods simultaneously that require different cooking times, because the natural ingredients absorb only enough water as is necessary.

SMEG offers a warming drawer which circulates warm air in order to heat up plates quickly and evenly. The base of the drawer is tted with a non-slip mat to prevent plates and dishes from sliding when the drawer is opened or closed.

INNOVATIVE WATER

FILLING SYSTEM

The water is drawn in through a flexible tube which disappears into the cavity when it is not used. This discrete system has no impact on the volume of the cavity or the oven’s interior or exterior aesthetics, meaning that the SMEG combi-steam oven has one of the largest compact cavities and is one of the best looking ovens on the market.

COFFEE MACHINES

a perfect beginning

SMEG offers built-in machines to complete your kitchen, to make professional espresso and cappuccino in the comfort of your home. The built-in coffee machine utilizes a 15 bar pressure pump. This maximizes the avor extraction from the coffee beans, optimizing the pour, resulting in a delightful crema for a perfect cup of coffee every time.

LCD

DISPLAY

You can use either readyground coffee or beans

(with an adjustable grinding function at 13 levels) and prepare one or two cups at the same time.

All coffee machines featured in our current range have

clear and easy-to-use displays. Some models

feature touch control displays with large, clear, intuitive menus.

5 adjustable coffee lengths, 5 levels of coffee strength

(Extra-Light, Light, Medium, Strong & Extra Strong) and 3 adjustable coffee temperatures.

COFFEE MACHINE

COMPACT OVENS

An accurate cleaning process starts every time

the machine switches on or switches off to guarantee maximum performance.

All SMEG coffee machines have an automatic cappuccino-maker that will whisk milk into a delicate foam directly into the cup.

SFU4104VCS COMBI STEAM

SFU4104MCS SPEED OVEN

A trim kit for installation in wider wall cabinets above a 30" oven is available. The kit consists of two Mystic Gray glass bars that allow the speed oven to reach 30 inch width.

60 CM (APPROX. 24”) LINEA DESIGN BUILT-IN STEAM COMBINATION OVEN, MYSTIC GRAY GLASS

Linea Design

Steam combination oven with 14 cooking modes

Touch screen controls

Mystic Gray glass finish

Color TFT touch screen display 50 automatic cooking programs 10 customizable recipes

Electronic temperature control True European convection (combinable with steam oven) Adjustable temperature: 87° - 482° F Steam cooking (combinable with convection oven) Steam stops when door is open Rapid preheat

Vapor-Clean system

EverClean enamel cavity for quick and easy cleaning Automated oven switch-off when door is open 3 rack positions

Soft Close door

Oven capacity: 1.77 cu ft Water tank capacity: 0.32 gal.

Voltage rating: 120/240V 60 Hz Connected load (nominal power): 3.0 kW Amps 240 V: 15 Amps

ACCESSORIES INCLUDED:

1 telescopic guide rail (partial extraction) 1 grid with back and side stop 1 insert gird 1 enamelled deep tray (40mm) 1 stainless steel tray (20mm) 1 stainless steel perforated deep tray (40mm) 1 beaker 1 sponge/descaler

60 CM (APPROX. 24”) LINEA DESIGN BUILT-IN SPEED OVEN WITH 1000W MICROWAVE, MYSTIC GRAY GLASS

Linea Design

Microwave combination oven with 13 cooking modes

Touch screen controls

Mystic Gray glass finish

Color TFT touch screen display 50 automatic cooking programs 10 customizable recipes

Electronic temperature control True European convection (combinable with microwave) Adjustable temperature: 87° - 482° F End-of-cooking acoustic alarm Time-setting options: Start & Stop Delay start and automatic end cooking Minute minder Rapid preheat EverClean enamel cavity for quick and easy cleaning Automatic oven/microwave switch-off when door is open 3 rack positions 12 5/8" size glass turntable Cooling fan Defrost programmed by weight or by time Child-safe control lock Microwave screen protection 1 Halogen light (illuminates when door is opened) (1x 20 W)

Oven capacity: 1.77 cu ft Microwave power: 2,000 W Microwave effective power: 1,000 W

Voltage rating: 120/240V 60 Hz Connected load (nominal power): 3.00 kW Amps 240 V: 16 Amps

ACCESSORIES INCLUDED:

1 telescopic guide rail (partial extraction) 1 grid with back and side stop 1 insert gird 1 glass tray

For technical drawing in metric, see page177

COMPACT OVENS LINEA

SFU6104TVS (left)

with SFU4104MCS

atop CPRU115S (right)

CPRU115S

CPRU130S

24” (60 CM), LINEA DESIGN WARMING DRAWER, MYSTIC GRAY GLASS

Linea Design

Mystic Gray glass finish Push opening Anti-slip mat Inner control knob Adjustable temperature: 86° - 176° F On/off pilot lamp Maximum weight allowed above the drawer: 187 lbs. Maximum weight allowed inside the drawer: 33 lbs. Power heating element: 400 W Dimensions: W 23 27/64” x H 5 23/64” x D 21 59/64” Voltage rating: 120V/50-60 Hz

COORDINATES WITH:

Compact oven, Linea Design aesthetic

30” (76 CM), LINEA DESIGN WARMING DRAWER, MYSTIC GRAY GLASS

Linea Design

Mystic Gray glass finish Handle opening Anti-slip mat Inner control knob Adjustable temperature: 86° - 167° F Adjustable timer from 0 to 240 minutes with automatic switch-off Delay timer up to 10 h On/off pilot lamp Maximum weight allowed above the drawer: 187 lbs. Maximum weight allowed inside the drawer: 33 lbs. Power heating element: 800 W Dimensions: W 28,15” x H 10,04” x D 24,4” Voltage rating: 120V/50-60 Hz

COORDINATES WITH:

30'' oven, Linea Design aesthetic

For technical drawing in metric, see page178 For technical drawing in metric, see page178

CMSU4104S

60 CM (APPROX. 24’’), FULLY-AUTOMATIC COFFEE MACHINE WITH MILK FROTHER, MYSTIC GRAY GLASS

Linea Design Touch screen controls

Mystic Gray glass finish

Colour TFT soft touch screen display

Coffee function: regular or double coffee (1 or 2 cups at the same time) Automatic cappuccino maker with separate tank for milk Hot water function for tea or other hot drinks Rinsing function and descaling function Coffee intensity adjustable (5 levels): Extra-Light, Light, Medium, Strong, Extra-Strong Coffee length adjustable (5 levels) Adjustable coffee temperature (3 levels) Adjustable coffee grinder (13 levels) Programmable automatic switch-on Automatic energy saving stand-by Programmable multi-language display Coffee bean container Separate container for ground coffee Removable water tank Removable container for coffee grounds

Frothing nozzle for cappuccino

Adjustable coffee dispenser (for tall or short cups) Drip tray 4 lights Telescopic guides with Soft Close Semi-pro stainless steel conical grinder

Stainless steel 0,5 L thermal carafe with autoclean system

Capacity of water tank: 81 oz Capacity of coffee bean container: 0.77 lbs Pump pressure: 217 psi Connected rating (nominal power): 1,350 W 11 Amps Tension/frequency: 120V 60 Hz Pump pressure: tension/frequency: 120V 60 Hz

COFFEE MACHINES LINEA

For technical drawing in metric, see page178

SCU45VCS1 COMBI STEAM

SCU45MCS1 SPEED OVEN

60 CM (APPROX. 24”) LINEA DESIGN BUILT-IN STEAM COMBINATION OVEN, SUPERSILVER GLASS

Linea Design

10 cooking modes

Supersilver glass finish Ergonomic control knobs Stainless steel cavity Digital LED display True European convection (combinable with steam oven) Pizza cooking function Steam cooking (combinable with convection oven) Steam stops when door is open Adjustable temperature: 105° - 430° F Child-safe control lock 1Halogen bulb (1x 25 W)

Oven capacity: 1.34 cu ft Water tank capacity: 0.32 gal

Voltage rating: 220V 60 Hz Connected load (nominal power): 2.7 kW Amps 240V: 12.3 Amps

ACCESSORIES INCLUDED:

1 steel tray 1 large grid 1 deep perforated steel tray 1 beaker 1 sponge/descaler

OPTIONS:

Please note that this oven may be installed in a wall cabinet that is a minimum of 22'' wide. A trim kit for an installation in a wider cabinet above a 30'' oven is available (product code KIT4570S).

60 CM (APPROX. 24”) LINEA DESIGN BUILT-IN SPEED OVEN WITH 1000W MICROWAVE, SUPERSILVER GLASS

Linea Design

10 cooking modes

Supersilver glass finish Ergonomic control knobs Stainless steel cavity Digital LED display Time-setting options: Start & Stop End-of-cooking acoustic alarm Automatic oven/microwave switch-off when door is open True European convection cooking (combinable with microwave) 12 5/8" size glass turntable Adjustable temperature: 122° - 428°F Cooling fan Defrost programmed by weight or by time Microwave pizza cooking function Child-safe control lock Microwave screen protection 1 Halogen light (illuminates when door is opened) (1x 20 W)

Oven capacity: 1.34 cu ft Microwave power: 1,850W Microwave effective power: 1,000W

Voltage rating: 220V 60Hz Connected load (nominal power): 3.40 kW Amps 240V: 16 Amps

ACCESSORIES INCLUDED:

1 large grid 1 glass tray 1 special crisp plate

OPTIONS:

Please note that this oven may be installed in a wall cabinet that is a minimum of 22'' wide. A trim kit for an installation in a wider cabinet above a 30'' oven is available (product code KIT4570S).

SCU45VCS1

SCU45MCS1

For technical drawing in metric, see page177

CTU15S

OTR111SU

FOOD AND DISH WARMING DRAWER FOR COMPACT OVENS, 24” (60 CM), SUPERSILVER GLASS

Linea Design

Supersilver Glass finish Handle opening Anti-slip mat Electronic touch controls Adjustable temperature: 86° - 176° F Adjustable timer from 0 to 240 minutes with automatic switch-off Delay timer up to 9 h, 50 min On/off pilot lamp Maximum weight allowed above the drawer: 187 lbs Maximum weight allowed inside the drawer: 33 lbs Power heating element: 400 W Dimensions: W 23 27/64” x H 5 23/64” x D 21 59/64” Voltage rating: 120V/50-60 Hz

COORDINATES WITH:

Compact oven, Linea Design aesthetic

OVER-THE-RANGE MICROWAVE, 30’’ SUPERSILVER GLASS

Linea Design

Supersilver Glass finish Simple and multi-stage microwave cooking Speedy cooking Defrost functions: by weight, by time Timer function Functions: popcorn, baked potato, beverage, and reheat Child-safe control lock Hood function 2 halogen hood lights Touchpad control with white LED display Microwave power: 1,000 W Cavity capacity: 1.1 cu ft Glass turntable (diameter in.) 13 5/8"

COMPACT OVENS LINEA

Max setting 300 CFM Noise level: 49 dB(A) Multi-speed vent 3 venting options: roof, wall, room 2 ventilation filters

Connected load (nominal power): 1,550 W Circuit breaker (A): 15 Amps Voltage rating: 120V 60Hz Overall appliance dimensions (HxWxD) (in): 16 1/2" (41,9 cm) x 29 7/8" (76 cm) x 15 3/8" (39 cm)

For technical drawing in metric, see page177 For technical drawing in metric, see page178

CMSCU451S

60 CM (APPROX. 24’’), FULLY-AUTOMATIC COFFEE MACHINE WITH MILK FROTHER, SUPERSILVER GLASS

Linea Design

Supersilver glass Multilanguage LCD display Coffee function: regular or double coffee (1 or 2 cups at the same time) Automatic cappuccino maker with separate tank for milk Hot water function for tea or other hot drinks Rinsing function and descaling function Coffee intensity adjustable (5 levels): Extra-Light, Light, Medium, Strong, Extra-Strong Coffee length adjustable (3 levels): Espresso (Short), Espresso, Medium, Long Adjustable coffee temperature (3 levels) Adjustable coffee grinder Programmable automatic switch-on Automatic energy saving stand-by Programmable multi-language display Coffee bean container Separate container for ground coffee Removable water tank Removable container for coffee grounds

Frothing nozzle for cappuccino

Adjustable coffee dispenser (for tall or short cup) Drip tray 2 lights Telescopic guides

Capacity of water tank: 60 oz Capacity of coffee bean container: 7 3/4” Pump pressure: 217 psi Connected rating (nominal power): 1,350 W 11 Amps Tension/frequency: 120V 60 Hz Pump pressure, tension/frequency: 120V 60 Hz

For technical drawing in metric, see page178

COMPACT OVENS CLASSIC

SF112U (left)

with CMSCU451S

atop CTU15S (left)

SFU4302VCX COMBI STEAM

SFU4302MCX SPEED OVEN

A trim kit for installation in wider wall cabinets above a 30" oven is available. (product code KIT330X) The kit consists of two stainless steel bars that allow the speed oven to reach 30inch width.

SMEG offers a warming drawer which circulates warm air in order to heat up plates quickly and evenly. The base of the drawer is ﬁtted with a non-slip mat to prevent plates and dishes from sliding when the drawer is opened or closed.

COFFEE MACHINE

60 CM (APPROX. 24”) BUILT-IN COMBINATION STEAM OVEN, FINGERPRINT-PROOF STAINLESS STEEL

“Classic” Design

Steam combination oven with 14 cooking modes

Fingerprint-proof stainless steel finish Ergonomic control knobs

Compact LCD display 20 automatic cooking program

Vapor-Clean system

EverClean enamel cavity for quick and easy cleaning Automated oven switch-off when door is open 3 rack positions

Soft Close door

Oven capacity: 1.77 cu ft Water tank capacity: 0.32 gal

Voltage rating: 120/240V 60 Hz Connected load (nominal power): 3.0 kW Amps 240V: 15 Amps

ACCESSORIES INCLUDED:

OPTIONS:

Kit 330X - Trim kit to reach 30'' width.

60 CM (APPROX. 24”) "CLASSIC" BUILT-IN SPEED OVEN WITH 1000W MICROWAVE, FINGERPRINT-PROOF STAINLESS STEEL

“Classic” Design

Microwave combination oven with 13 cooking modes

Fingerprint-proof stainless steel finish Ergonomic control knobs

Compact LCD display 20 automatic cooking program

Electronic temperature control True European convection (combinable with microwave) Adjustable temperature: 87° - 482° F End-of-cooking acoustic alarm Time-setting options: Start & Stop Delay start and automatic end cooking Minute reminder Rapid preheat EverClean enamel cavity for quick and easy cleaning Automatic oven/microwave switch-off when door is open 3 rack positions 12 5/8" size glass turntable Cooling fan Defrost programmed by weight or by time Child-safe control lock Microwave screen protection 1 Halogen light (illuminates when door is opened) (1x 20 W)

Oven capacity: 1.77 cu ft Microwave power: 2,000 W Microwave effective power: 1,000 W

Voltage rating: 120/240V 60 Hz Connected load (nominal power): 3.0 kW Amps 240 V: 16 Amps

ACCESSORIES INCLUDED:

1 telescopic guide rail (partial extraction) 1 grid with back and side stop 1 insert gird 1 glass tray

OPTIONS:

Kit 330X - Trim kit to reach 30'' width.

For technical drawing in metric, see page177

OVENS CLASSIC

SFU4302VCX

KIT330X

SOU330X1

SU45VCX1 COMBI STEAM

SU45MCX1 SPEED OVEN

60 CM (APPROX. 24”) "CLASSIC" DESIGN BUILT-IN STEAM COMBINATION OVEN, FINGERPRINT- PROOF STAINLESS STEEL

"Classic" Design

10 cooking modes

Fingerprint-proof stainless steel finish Ergonomic control knobs Stainless steel cavity Digital LED display True European convection (combinable with steam oven) Pizza cooking function Steam cooking (combinable with convection oven) Steam stops when door is open Adjustable temperature: 105° - 430° F Child-safe control lock 1Halogen bulb (1x 25 W)

Oven capacity: 1.34 cu ft Water tank capacity: 0.32 gal

Voltage rating: 220V 60 Hz Connected load (nominal power): 2.7 kW Amps 240V: 12.3 Amps

ACCESSORIES INCLUDED:

1 steel tray 1 large grid 1 deep perforated steel tray 1 beaker 1 sponge/descaler

OPTIONS:

Please note that this oven may be installed in a wall cabinet that is a minimum of 22'' wide. A trim kit for an installation in a wider cabinet above a 30'' oven is available (product code KIT4570X).

60 CM (APPROX. 24”) "CLASSIC" DESIGN BUILT-IN SPEED OVEN WITH 1000W MICROWAVE, FINGERPRINT-PROOF STAINLESS STEEL

"Classic" Design

10 cooking modes

Fingerprint-proof stainless steel finish Ergonomic control knobs Stainless steel cavity Digital LED display Time-setting options: Start & Stop End-of-cooking acoustic alarm Automatic oven/microwave switch-off when door is open True European convection cooking (combinable with microwave) 12 5/8" size glass turntable Adjustable temperature: 122° - 428°F Cooling fan Defrost programmed by weight or by time Microwave pizza cooking function Child-safe control lock Microwave screen protection 1 Halogen light (illuminates when door is opened) (1x 20 W)

Oven capacity: 1.34 cu ft Microwave power: 1,850W Microwave effective power: 1,000W

Voltage rating: 220V 60Hz Connected load (nominal power): 3.40 kW Amps 240V: 16 Amps

ACCESSORIES INCLUDED:

1 large grid 1 glass tray 1 special crisp plate

OPTIONS:

Please note that this oven may be installed in a wall cabinet that is a minimum of 22'' wide. A trim kit for an installation in a wider cabinet above a 30'' oven is available (product code KIT4570X).

SU45VCX1

SU45MCX1

For technical drawing in metric, see page177

CPRU315X

CPRU330X

CTPU15X

FOOD AND DISH WARMING DRAWER FOR COMPACT OVENS, 24” (60 CM), FINGERPRINT-PROOF STAINLESS STEEL

“Classic” Design

Push opening Anti-slip mat Inner control knob Adjustable temperature: 86° - 176° F On/off pilot lamp Maximum weight allowed above the drawer: 187 lbs. Maximum weight allowed inside the drawer: 33 lbs. Power heating element: 400 W Dimensions: W 23 27/64” x H 5 23/64” x D 21 59/64” Voltage rating: 120V 50-60 Hz

COORDINATES WITH:

Compact oven, “Classic” aesthetic

FOOD AND DISH WARMING DRAWER FOR OVENS, 30” (76 CM), FINGERPRINT-PROOF STAINLESS STEEL

“Classic” Design

Handle opening Anti-slip mat Inner control knob Adjustable temperature: 86° - 176° F Adjustable timer from 0 to 240 minutes with automatic switch-off Delay timer up to 10 h On/off pilot lamp Maximum weight allowed above the drawer: 187 lbs. Maximum weight allowed inside the drawer: 33 lbs. Power heating element: 800 W Dimensions: W 28.15” x H 10.04” x D 24.4” Voltage rating: 120V 50-60 Hz

COORDINATES WITH:

30'' oven, “Classic” aesthetic

FOOD AND DISH WARMING DRAWER FOR COMPACT OVENS, 24” (60 CM), FINGERPRINT-PROOF STAINLESS STEEL

“Classic” Design

Push opening Anti-slip mat Electronic touch controls Adjustable temperature: 86° - 176° F Adjustable timer from 0 to 240 minutes with automatic switch-off Delay timer up to 9 h, 50 min On/off pilot lamp Maximum weight allowed above the drawer: 187 lbs. Maximum weight allowed inside the drawer: 33 lbs. Power heating element: 400 W Dimensions: W 23 27/64” x H 5 23/64” x D 21 59/64” Voltage rating: 120V 50-60 Hz

COORDINATES WITH:

Compact oven, “Classic” aesthetic

OVENS CLASSIC

For technical drawing in metric, see page178

FMIU020X MICROWAVE

OTR316XU

60 CM (APPROX. 24’’) BUILT-IN MICROWAVE, FINGERPRINT- PROOF STAINLESS STEEL

“Classic” Design

Microwave with grill, multiple programs

Fingerprint-proof stainless steel finish

8 automatic programs

Automatic defrosting by time or weight Stainless steel interior cavity Lateral opening door Single LED display Quick start option Child-safe control lock 9 ¾” turntable Microwave power: 800 W Broil element: 1000 W 20 W internal light

Dimensions: W 23.4” x H 13.5” x D 15” Voltage rating 120V 60Hz Connected load (nominal power): 1,350 W Amps 120 V - 11 Amps

ACCESSORIES INCLUDED:

Frame kit for built-in installation 1 grid

30” OVER-THE-RANGE MICROWAVE, MICROWAVE/VENT HOOD FINGERPRINT- PROOF STAINLESS STEEL

“Classic” Design

Fringerprint-proof stainless steel finish Simple and multi-stage microwave cooking Speedy cooking Defrost functions: by weight, by time Timer function Functions: popcorn, baked potato, beverage and reheat Child-safe control lock Hood function 2 halogen hood lights Touchpad control with white LED display Microwave power: 1,000 W Cavity capacity: 1.6 cu ft 13 5/8" turntable Max setting 300 CFM Noise level: 49dB(A) Multi-speed vent 3 venting options: roof, wall, room 2 ventilation filters

Connected load (nominal power): 1,550 W - 15 Amps Voltage rating: 120V 60Hz Overall appliance dimensions (HxWxD) (in): 16 1/2" (41,9cm) x 29 7/8" (76cm) x 15 3/8" (39cm)

For technical drawing in metric, see page178

OVENS CLASSIC

FMIU020X atop SF399XU

CMSU4303X

CMSU6451X

60 CM (APPROX. 24’’), FULLY-AUTOMATIC COFFEE MACHINE WITH MILK FROTHER, FINGERPRINT- PROOF STAINLESS STEEL

“Classic” Design

Fingerprint-proof stainless steel finish

Colour TFT soft touch-screen display

Frothing nozzle for cappuccino

Adjustable coffee dispenser (for tall or short cup) Drip tray 4 lights Telescopic guides with Soft Closing Semiprofessional stainless steel conical grinder

Stainless steel 0,5 L thermal carafe with autoclean system

60 CM (APPROX. 24’’), FULLY-AUTOMATIC COFFEE MACHINE WITH MILK FROTHER, FINGERPRINT- PROOF STAINLESS STEEL

“Classic” Design

Fingerprint-proof stainless steel finish Multilanguage LCD display Coffee function: regular or double coffee (1 or 2 cups at the same time) Automatic cappuccino maker with separate tank for milk Hot water function for tea or other hot drinks Rinsing function and descaling function Coffee intensity adjustable (5 levels): Extra-Light, Light, Medium, Strong, Extra-Strong Coffee length adjustable (3 levels): Espresso (Short), Espresso, Medium, Long Adjustable coffee temperature (3 levels) Adjustable coffee grinder Programmable automatic switch-on Automatic energy saving stand-by Programmable multi-language display Coffee bean container Separate container for ground coffee Removable water tank Removable container for coffee grounds

Frothing nozzle for cappuccino

Adjustable coffee dispenser (for tall or short cup) Drip tray 2 lights Telescopic guides

For technical drawing in metric, see page178

COFFEE MACHINES CLASSIC

CMSU4303X atop

CPRU315X (left)

with SFU4302MCX

atop CPRU315X (right)

WINE COOLERS

Italy has the largest and most diversified

wine production in the world.

The charm of the wine world and the

importance of its preservation have

inspired SMEG to develop this range of

wine coolers.

Designed for those who love to entertain

or have a real passion for wine, these are

must-have kitchen appliances.

Wine is stored at optimum temperatures

and ideal humidity conditions to ensure it

matures properly, so you can enjoy your

favorite bottle to its fullest.

WINE COOLERS

CVIU318RX

atop CPS315X

WINE COOLERS

wines stored with the utmost care

SMEG presents wine coolers developed for conserving ne wines and impressing guests. Equipped with spacious shelves nished in untreated wood, they store different shapes and sizes of bottles, from classic Bordeaux blends to Magnums.

PERFECT PRESERVATION

Finished with UV-ray resistant glass, protecting

against harmful UV rays which can damage the quality of the wine, and a

motor/ compressor designed with particular care, the wine cooler protects bottles from harmful vibrations.

WINE CELLARS

SH ELV ES

Made from Slavonian Oak, used traditionally by Italian winemakers to make barrels as it is known for its tight grain, low aromatics and medium-level tannins. Some shelves are telescopic, so wines can be removed with ease, safely and conveniently.

CONTROLS ON THE EXTERIOR

The touch control display on the glass door allows you to set temperature and humidity parameters without the door opening. It is possible to independently adjust the humidity level, as well as the temperature in order to ensure the appropriate environment for different bottles. The temperature can be set between 41° and 68°F, guaranteeing optimal conditions for each bottle of wine.

Under-counter models can hold up to 38 wine bottles.

TAILOR-MADE PROFESSIONAL CONSERVATION

a wine enthusiast’s dream

The new SMEG wine coolers use the latest technology to correctly store and age wine. The materials used have been carefully selected, in cooperation with expert sommeliers, who have helped create a range of excellent technical and high-quality products. SMEG wine coolers are entirely made in Italy, as the result of the know-how and attention to detail that only an Italian company with a long and consolidated experience can guarantee.

HUMIDITY CONTROL

In order to preserve wine for a long time, it’s essential to maintain the correct level of humidity within the wine cooler. If the level of humidity is lower than 50%, the wine cooler is too dry, and this can cause the corks to become brittle, and trigger wine oxidation. On the other hand, a level of humidity higher than 85% can cause the formation of mold on the labels, which can spread to the corks, and the wine cooler itself. With a level of humidity between 60% and 80%, SMEG wine coolers guarantee optimal preservation of wine.

LIGHT

Solar light, and UV rays in-particular, can alter the wines (organoleptic structure), ruining its balance and attening its scent; red wine loses its tone, while white wine takes on a yellowish color. Thanks to the SMEG wine coolers "Eclipse" black-glass technology, the wine is perfectly shielded. The layered glass is a result of careful stylistic and qualitative research, and it enhances the wine coolers function: from a technological point of view, it protects from damaging light, and from an aesthetical point of view, it has a great visual impact, and gives maximum transparency when the light is on, and complete darkness when the light is off. The choice of using cold LED lighting, which can be turned on from the outside without opening the door, maintains a constant temperature, and provides perfect visibility on the racks.

WINE COOLERS

CVIU338RX

60 CM (APPROX. 24”) BUILT-IN UNDER-COUNTER WINE COOLER

“Classic” Design

Right-hand hinged Fingerprint-proof stainless steel and black glass finish

Compact LCD display

Maximum storage capacity: 38 bottles 2 fixed wooden shelves 3 removable wooden shelves with telescopic guides Active charcoal filter External touch control display Electronic temperature controls 2 independent temperature zones Adjustable temperature range: 41 - 68° F (both zones) Door open alarm Automatic defrost Anti-UV door glass LED lights Gross capacity: 4 cu ft Voltage rating: 120V 60Hz Connected load (nominal power): 0.40 kW - 0.5 Amps Dimensions: W 23

ALSO AVAILABLE:

/64” x H 32 9/32” x D 24 13/32”

CVIU338LX

Left-hand hinged

For technical drawing in metric, see page179

CVIU318RX

CPS315X

CP315X

60 CM (APPROX. 24”) BUILT-IN WINE COOLER

“Classic” Design

Fingerprint-proof stainless steel and black glass finish 17 3/4'' reduced height wine cooler

Push-pull door opening

Compact LCD display

Maximum storage capacity: 18 bottles 1 fixed wooden shelf 2 removable wooden shelves with telescopic guides Active charcoal filter External touch control display Electronic temperature controls Adjustable temperature range: 41 - 68° F Door open alarm Automatic defrost Anti UV door glass LED lights Gross capacity: 1.84 cu ft Voltage rating: 120V 60Hz Connected load (nominal power): 0.40 kW - 0.5 Amps Dimensions: W 23 7/16” x H 5 3/8” x D 21 15/16”

ALSO AVAILABLE:

CVIU318LX

Left-hand hinged

60 CM (APPROX. 24”) SOMMELIER DRAWER

“Classic” Design

Fingerprint-proof stainless steel finish Push opening Slavonia durmast wooden shelf Wine pump + 2 corks Sparkling wine cork Cork to pour wine Anti-drip cork Solid steel cork for sparkling wines Champagne/sparkling wine pliers Corkscrew sommelier Red wine cork Wine thermometer with slipcase Wine funnel with wooden handle Maximum weight allowed above the drawer: 187 lbs Maximum weight allowed inside the drawer: 33 lbs Dimensions: W 23 7/16” x H 5 3/8” x D 21 15/16”

Suitable for fitting directly beneath a 17 3/4'' height wine cooler. It fits in a standard 24'' gap

COORDINATES WITH:

"Classic" aesthetic

60 CM (APPROX. 24”) STORAGE DRAWER

“Classic” Design

Fingerprint-proof stainless steel finish Push opening Non-slip drawer liner Maximum weight allowed above the drawer: 187 lbs Maximum weight allowed inside the drawer: 33 lbs Dimensions: W 23 7/16” x H 5 3/8” x D 21 15/16” Gross capacity: 0.78 cu ft

Suitable for fitting directly beneath a 17 3/4'' height wine cooler. It fits in a standard 24'' gap

COORDINATES WITH:

"Classic" aesthetic

CLASSIC

WINE C00LERS

For technical drawing in metric, see page179

COOKTOPS

High-quality materials and uniquely-

designed grates and burners distinguish

SMEG cooktops.

COOKTOPS

PGFU30X

Smeg SFU4302MCX, SFU4104MCS, SFU4302VCX, CMSU4303X, CMSU4104S User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
