SURGICAL AND EXAMINATION
LIGHTING SYSTEMS
MODEL IDENTIFICATION
TABLE OF CONTENTS
Surgical & Examination Lighting Systems Model Identification
Description
Nova Series
Argos Series
Infinity IN Series
Infinity IFB Series
Infinity IF54 Series
Infinity Series - 30TV, 30AR
Stellar Series
Millennium Gold Series
Universe Series
Universe II Series
Page
2
3
4
5
6
7
8
9
10
11
Astro HA43 Series
Astro IN19 Series
Camera Systems
Mini Argos Series
EX-100/62/52
Spectra HA18 Series
Spectra IN9 Series
Focus & Positioning Handles
Lit-Lok Handle Adapters
Bulb Identification 18
4/04
12
12
13
14
14
15
15
16
17
1
NOVA SERIES
Features / Options
Surgical Lighting
Side Focus Knob
Lighthead Intensity Control
Snap in Center
Focus Handle
H
I
O
F
F
OFF
MAX. 500W
Model 100
14 bulbs, 40" Diameter
Model 90
12 bulbs, 35" Diameter
Wall Intensity Control
CR - Sealed Beam
A1-010-18
Provides Low Angle Lighting
2
Bulb Types
Halogen 24V / 50w
Elevato
B1-010-28
Model 75
Model 75
8 bulbs, 30" Diameter
8 bulbs, 30" Diameter
5 bulbs, 22" Diameter
5 bulbs, 22" Diameter
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
Model 58
Model 58
MODEL
(CAT NO.)
Surgical Lighting
Model 75AR - Hub Mounted
7 bulbs, 30" Diameter
ARGOS SERIES
Features / Options
Auxilliary
Focus Knob
Wall Intensity Control
Model 76AR- BOM Mounted
7 bulbs, 30" Diameter
Data Label Information
Location: Center Band of Lighthead
OFF
MAX. 500W
Bulb Type
Halogen 24V / 50w
B1-010-28
Remote Control Wand
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
3
INFINITY IN SERIES
Features / Options
Side Focus Knob
Snap in Center Focus Handle
Surgical Lighting
Model 30
8 bulbs, 30" Diameter
Wall Intensity Control
INTENSITY CONTROL
2
3
14
LOW HI
3
2
3
14
LOW HI
Elevato
Provides Low Angle Lighting
4
Bulb Type
Halogen 24V / 50w
B1-010-28
Model 22
5 bulbs, 22" Diameter
Data Label Information
Location: Center Band of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Surgical Lighting
Model 30
8 bulbs, 30" Diameter
INFINITY IFB SERIES
Features / Options
Side Focus Knob
Snap in Center Focus Handle
Model 22
5 bulbs, 22" Diameter
Data Label Information
Location: Center Band of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Wall Intensity Control
INTENSITY CONTROL
3
2
14
LOW HI
3
3
2
14
LOW HI
110˚ Vertical T ra vel
Bulb Type
Halogen 24V / 50w
B1-010-28
20˚
90˚
5
INFINITY IF54 SERIES
I
N
T
E
N
S
I
T
Y
C
O
N
T
R
O
L
OFF
H
I
I
N
T
E
N
S
I
T
Y
C
O
N
T
R
O
L
OFF
H
I
Features / Options
Side Focus Knob
Snap in Center Focus Handle
Surgical Lighting
Model 54
4 bulbs, 22" Diameter
Lighthead
Intensity Control
Provides Low Angle Lighting
6
Elevato
Bulb Type
Halogen 24V / 50w
B1-010-28
Data Label Information
Location: Center Band of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD.
CAT. NO.
MADE IN
JAPAN
MODEL
(CAT NO.)
Surgical Lighting
Model 30TV
8 bulbs, 30" Diameter
INFINITY SERIES
Features / Options
Handle Mount
Lighthead Focus Control
Camera Rotation Control
R
R
DO NOT REMOVE
DO NOT REMOVE
EQUIR
EQUIR
ES STERILE COVER
ES STERILE COVER
Provision for 3-Chip Camera
Model 30AR
8 bulbs, 30" Diameter
Data Label Information
Location: Center Band of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Remote Control Wand
Wall Intensity Control
INTENSITY CONTROL
2
3
14
LOW HI
3
2
3
14
LOW HI
Bulb Type
Halogen 24V / 50w
B1-010-28
7
STELLAR SERIES
Features / Options
Side Focus Knob
Snap in Center Focus Handle
Surgical Lighting
Model 29
7 bulbs, 29" Diameter
Wall Intensity Control
5
6
4
37
28
19
010
5
5
6
4
37
28
19
010
110˚ Vertical T ra vel
8
Bulb Type
Halogen 24V / 50w
B1-010-28
110˚
Model 23
5 bulbs, 23" Diameter
Data Label Information
Location: Lighthead face
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
- GRAND RAPIDS, MI
CAT. NO.
MODEL
(CAT NO.)
Surgical Lighting
Model 24
1 bulb, 24" Diameter
MILLENNIUM GOLD SERIES
Features / Options
Snap in Center Focus Handle
Bulb Type
Halogen 24V / 170w
B1-310-01
Data Label Information
Location: Center Band of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Wall Intensity Control with
Bulb Change Indicator
110˚ Vertical T ra vel
20˚
90˚
9
UNIVERSE SERIES
FOCUS
Features / Options
Surgical Lighting
FOCUSFOCUS
Snap in Center
Focus Handle
Super Halogen 24V / 50w
Side Focus Knob
Bulb Type
A1-510-01
S
S
U
C
CU
FO
FO
Model 63
10 bulbs, 38" Diameter
Wall
Intensity Control
OFF
12345
LOW HI
INTENSITY
NO. 1
OFF
12345
LOW HI
INTENSITY
NO. 2
INTENSITY CONTROL
"FOR USE ONLY WITH 120V SKYTRON EXAM OR SURGERY LIGHTS
WITH WATTAGE NOT EXCEEDING 600 W PERCONTROL"
Provides Low Angle Lighting
10
MAIN POWER
Lighthead
Intensity Control
ON
OFF
Elevato
Model 61
7 bulbs, 32" Diameter
5
4
HI
3
2
Y
T
I
S
N
E
T
N
I
1
F
F
O
LOW
Model 60
4 bulbs, 22" Diameter
FOCUSFOCUS
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Surgical Lighting
UNIVERSE II SERIES
Features / Options
Side Focus Knob
Snap in Center Focus Handle
Model 60
4 bulbs, 22" Diameter
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
Model 61
6 bulbs, 32" Diameter
FOCUSFOCUS
MODEL
CAT. NO.
(CAT NO.)
Bulb Type
Super Halogen
24V / 60w, A1-420-10
Provides Low Angle Lighting
Wall Intensity Control
TO EXTEND BULB LIFE. TURN INTENSITY DOWN
BEFORE TURNING POWER SWITCH ON OR OFF.
INTENSITY
2
1
OFF
OFF
Elevato
1
3A
OFF
SAFETY FUSE
2
3A
POWER
ON
11
ASTRO HA43 SERIES
Features / Options
Surgical Lighting
Bulb Type
Halogen 24V / 50w
B1-010-28
Elevato
Provides Low Angle Lighting
INTENSITY
CONTROL
STERILIZABLE
POSITIONING HANDLE
Model 43
3 bulbs, 19" Diameter
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
ASTRO IN19 SERIES
Features / Options
Bulb Type
Halogen 24V / 50w
B1-010-28
STERILIZABLE
POSITIONING HANDLE
Elevato
Provides Low Angle Lighting
12
INTENSITY
CONTROL
Surgical Lighting
Model 19
3 bulbs, 19" Diameter
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Surgical Lighting
CAMERA SYSTEMS
Features / Options
Handle-Cam Camera System
Model IF22H
Model ML24TV
CAMERA
CAMERA
COVER
HANDLE
TV-1 Camera System
Model ST23TV
CAMERA
CAMERA
COVER
HANDLE
13
MINI ARGOS SERIES
Features / Options
Examination Lighting
Bulb Type
Halogen 24V / 100w
B1-011-32
Remote Control
Wand - Early
Optional Wall
Control (-WC)
LOW HIGH
INTENSITY CONTROL
A
OFF ON
"MINI"-ARGOS
REMOTE CONTROL LIGHTING
B
Remote Control
Wand - Rechargable
Model HA30AR - HA60AR
Recessed Ceiling Fixture
13-1/2" Diameter, Computer positioned
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
EX-100/62/52
Features / Options
Bulb Types
Model EX-52/62
Wall Mounted Controls
INTENSITY
SAFETY FUSE
1 A
CONTROL
H
OPERATION
F
POWERHORIZONTAL
LR
14
EX-52
Krypton-Halogen
24V / 50w
A1-510-01
EX-62
Super Halogen
24V / 60w
A1-420-10
EX-100
Super Halogen
24V / 100w
A1-430-03
Model EX-62/100
Wall Mounted Controls
SAFETY FUSE INTENSITY
1.25A x 2
A
B
B
A
POWERLIGHT POSITION
LIGHT SELECT
Examination Lighting
Model EX-100 9-1/2" Diameter
Model EX-62 9-1/2" Diameter
Model EX-52 8-1/2" Diameter
Recessed Ceiling Fixture
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Examination Lighting
SPECTRA HA18 SERIES
Features / Options
Model 18
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Bulb Type
Halogen 24V / 75w
B1-010-29
Provides Low Angle Lighting
INTENSITY
CONTROL
POSITIONING HANDLES
Elevato
Examination Lighting
Data Label Information
Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
Model 9EL
MODEL
(CAT NO.)
SPECTRA IN9 SERIES
Features / Options
Bulb Type
Halogen 24V / 75w
B1-010-29
Provides Low Angle Lighting
STERILIZABLE
POSITIONING
HANDLE
Elevato
INTENSITY
CONTROL
15
FOCUS & POSITIONING HANDLES
B1-020-74
NOVA SCREW-IN
CF HANDLE
A1-020-97
POST
B1-020-75 NOVA
B1-210-45 INFINITY
SNAP-IN CF HANDLE
ALUMINUM - OBSOLETE
A1-010-29-1
STERILE POSITIONING
HANDLE
B1-210-45 NOVA / INFINITY
SNAP-IN CF HANDLE
PLASTIC - REPLACEMENT
A1-020-71
EXCEL SNAP-IN
CF HANDLE
16
A1-020-98
COVER - UNIVERSE CF
HANDLE ASSEMBLY
A1-610-04
UNIVERSE II SNAP-IN
CF HANDLE
B1-210-50 INFINITY (IF)
STELLAR, MILLENNIUM GOLD
SNAP-IN CF HANDLE
LITE-LOK HANDLE ADAPTERS
B1-020-100
Center Focus with detachment ring
applications: Universe I / Excel snap-in
B1-020-103
Excel / Nova positioning handle, screw-on
applications: Astro 45 & 93 / IN Argos / IN TV
B1-020-101
Nova snap-in center focus
applications: late Nova / "IN" Infinity
B1-020-104
Universe II center-focus
applications: Universe II
B1-020-102
Nova center focus, screw-on
applications: early Nova
B1-020-112
Skytron Infinity "IF" models
applications: IF22 / IF30 / IF54 / ML24
ST23 / ST29
Siemens / Heraeus
applications: 2000 series
B1-020-99-1 Disposable Handle Cover, single pack
B1-020-99-2 Disposable Handle Cover, dual pack
B1-020-109
applications: ALM or ALM/Chick
B1-020-106B1-020-107
applications: Amsco (all models)
17
BULB IDENTIFICATION
FIXTURE SERIES BULB TYPE BULB ID PART NUMBER
Millennium Gold Halogen, 24V, 170W B1-310-01
Stellar Halogen, 24V, 50W H24501 B1-010-28
ST9 Halogen, 24V, 75W H2475X B4-240-04
Infinity "IF" Halogen, 24V, 50W H24501 B1-010-28
Infinity "IN" Halogen, 24V, 50W H24501 B1-010-28
Nova Sealed Beam, HCR-150 HRC-150-35 A1-010-18
Halogen, 24V, 50W H24501 B1-010-28
Astro HA43 & IN19 Halogen, 24V, 50W H24501 B1-010-28
Spectra HA18 & IN9 Halogen, 24V, 75W H2475 B4-010-29
HA30AR & HA30AR-WC Halogen, 24V, 100W H24100 B5-011-32
HA60AR & HA60AR-WC Halogen, 24V, 100W H24100 B5-011-32
Universe II "UN" Krypton/Halogen, 24V, 60W SH-62 A1-420-10
Universe "SH" Krypton/Halogen, 24V, 50W SH-52 A1-510-01
Excel Sealed Beam, HCR-150 HCR-150-3S A1-010-18
Krypton/Halogen, 24V, 40W SH-42 A1-010-28-1
EX-52 Krypton/Halogen, 24V, 50W SH-52 A1-510-01
EX-62 Krypton/Halogen, 24V, 60W SH-62 A1-420-10
EX-100W Krypton/Halogen, 24V, 100W SH-100 A1-430-03
Mini-Star Halogen, 12V, 35W FRB-3L C1-010-32
SKY
HCR-150-3S
DKK
H24501 - 50w
H2475 - 75w
H24100 - 100w
SEALED BEAM - A1-010-18 HALOGEN KRYPTON / HALOGEN
G
18
Data Label Information Location: Front Face of Lighthead
BULB
TYPE
FUSE
TYPE
SERIAL
NUMBER
ELECTRIC RATING
INPUT
BULBS TYPE
SAFETY FUSE
SERIAL NO.
DAI-ICHI SHOMEI CO., LTD. TOKYO, JAPAN
CAT. NO.
MODEL
(CAT NO.)
Loading...
