Sinbo SSI-2873 User guide

SSI 2873 ÜTÜ

EN

Children being supervised not to play with the appliance.

This appliance is not intended for use by persons (including children) with reduced physical,sensory or mental capabilities, or lack of experience and knowledge, unless they havebeen given supervision or instruction concerning use of the appliances by a personresponsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

Heat caused by the arrival of the cutter accidentally starting position to avoid a hazard, such as a timer, this device

is fed via an external switching scheme on a regular basis or by means of the utility opened and closed, and a circuit connected to the circuit

Hot or cold iron and cords should be out of reach of children under 8 years.

- 1 -

ENGLISH

SINBO SSI 2873 STEAM IRON

INSTRUCTION MANUAL

Main technical parameters:

Type: SSI 2873

Rated voltage: AC230V

Rated frequency: 50Hz

Rated power: 2200W

Please read these instructions for use and have a good look at the illustration before using the appliance

Characteristics and structure:

The product has in any functions such as temperature regulating, spraying, dry ironing, steam, strong steam, etc, and is with characteristics: luxury shape, high heat efficiency, easy using, good ironing result, work saving and time saving, and so on.

A:Steam regulating knob

B:Strong steam button

C:Spraying button

D:Indicator bulb

E:Movable wire

F:Temperature regulating knob

G:Water tank

H:Soleplate

I:Spraying mouth

J:Cover of water filling mouth

K:Self-clean button

How to fill water:

Pull up the cap of water filling month, fill until full, push the cap back to its original position. How to dry clean:

1.Turn the temperature regulating knob to "MIN" position, turn the steam knob to"—"position, put the plug into the socket.

2.Turn the temperature regulating knob to the temperature scale which the ironed clothes required, the indicator will light on, then put the iron on the smooth and stable place vertically.

3.After the indicator goes out, you can begin to iron.

How to spray:

Press the spraying button repeatedly, steam will be sprayed out from the spraying mouth, at that time, you should keep enough water in the water tank.

How to iron with steam:

1.Fill water in the water tank.

2.Use steam ironing, turn the steam knob to the " * * " or "* " position, the method for regulating temperature is the same with one of dry ironing.

-5 -
