WARNING
Engine exhaust from this product contains
chemicals known, in certain quantities, to cause
cancer, birth defects, or other reproductive harm.
Table of Contents
Safety Rules & Information ................................2
Identification Numbers .......................................7
Features & Controls............................................8
Control Functions....................................................8
Safety Interlock System ..........................................9
Operating the Tractor ........................................10
General .................................................................10
Checks Before Starting.........................................10
Starting the Engine ...............................................11
Stopping the Rider ................................................11
Mowing..................................................................11
Pushing the Rider by Hand...................................11
Zero Turn Driving Practice ....................................12
Storage..................................................................14
Starting After Long Term Storage .........................14
Regular Maintenance ........................................15
Maintenance Schedule .........................................15
Checking Tire Pressures.......................................15
Checking/Adding Fuel...........................................16
Fuel Filter ..............................................................16
Oil & Filter Change ...............................................16
Check / Change Air FIlter .....................................16
Check Hydraulic Oil Level.....................................16
Lubrication ............................................................17
Battery Maintenance .............................................17
Checking Battery Fluid ......................................17
Cleaning the Battery and Cables.......................17
Servicing the Mower Blades .................................18
Troubleshooting, Adjustments & Service .......19
Troubleshooting the Tractor ...................................19
Troubleshooting the Mower ...................................20
Seat Adjustment....................................................21
Ground Speed Control Lever Adjustment.............21
Speed Balancing Adjustment................................21
Parking Brake Adjustment ....................................22
Front Suspension Adjustment...............................22
PTO Clutch Adjustment ........................................23
Blade Brake Check ...............................................23
Neutral Adjustment ...............................................24
Neutral Position & Return Spring Adjustment.......24
Cutting Height Adjustment ....................................25
Deck Leveling Adjustment.....................................26
Hydraulic Pump Drive Belt Replacement..............27
Mower Belt Replacement......................................27
Battery Service .....................................................28
Checking the Battery Voltage ............................28
Charging A Completely Discharged Battery......28
Jump Starting with
Auxiliary (Booster) Battery .............................28
Lawn Care & Mowing Information ...............LC-1
International Symbols...................................LC-8
Technical Manuals.........................................LC-8
NOTE: In this manual, “left” and “right” are referred to as
seen from the operating position.
© Copyright 2003 Ferris Industries
All Rights Reserved. Printed in USA.
TP 100-7088-03-CT-D
1
WARNING
You must read, understand and comply with all safety
and operating instructions in this manual before
attempting to set-up and operate your machine.
Failure to comply with all safety and operating
instructions can result in loss of machine control,
serious personal injury to you and / or bystanders,
and risk of equipment and property damage. The
triangle in the text signifies important cautions or
warnings which must be followed.
