Power Team Canister

(The chances are you’re

never going to read me)

Owner’s Manual

www.SimplicityVac.com

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE

USING THIS APPLIANCE

The manufacturer cannot accept responsibility for damage

IMPORTANT:

caused when the appliance is not used according to the instructions, or for uses other than those for which it was intended.

WARNING: To reduce the risk of fire, electric shock or injury:

• Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.

• WARNING: ELECTRIC SHOCK COULD OCCUR IF USED OUTDOORS OR ON WET SURFACES.

• Do not allow to be used as a toy. Close attention is necessary when used by or near children.

• Use only as described in this manual. Use only manufacturer’s recommended attachments.

• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, return it to your Authorized Retailer for service.

• Do not pull or carry by cord, use cord as a handle, close a door on the cord, or pull cord around sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

• Hold plug when retracting the power cord to prevent the cord from whipping.

• Do not handle plug or appliance with wet hands.

• Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair and anything that may reduce air ow.

• Keep hair, loose clothing, ngers and all parts of body away from openings and moving parts.

• Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.

• Do not use without vacuum bag in place.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up ammable or combustible liquids such as gasoline or use in areas where they may be present.

• Do not attempt to service the unit while appliance is plugged in.

• Do not use vacuum to pick up water or any wet materials.

SAVE THESE INSTRUCTIONS.

Contents

Safety Precautions

Replacing the Vacuum Bag and Filters

Description and Operation of the Canister

Description of the Premium & Full Size Power Nozzles

Operation of the Premium & Full Size Power Nozzles 9-10

Maintenance and Care of the Premium & Full Size Power Nozzles

Description of the Compact Power Nozzle

Operation of the Compact Power Nozzle 14

Maintenance and Care of the Compact Power Nozzle 15

Troubleshooting Guide 16

Key Replacement Parts 16

Owner’s Information

Warranty 18

6-7

11-12

Safety Precautions

This vacuum cleaner should be used for normal, dry household dust and dirt. The manufacturer cannot be held responsible for any damage caused by use or operation of the vacuum contrary to these instructions. If the vacuum is wrongly operated for a purpose other than that for which it is intended, no liability can be accepted for any possible damage.

• Do not vacuum areas which contain moisture or water, flammable matter, needles, pins, razor blades, matches, cigarettes, etc., since they may damage the vacuum or vacuum bag.

• When retracting the power cord, hold the plug to prevent the cord from whipping.

• Make sure a vacuum bag and filters are always in place.

• This product is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug fits into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact an electrician to replace the obsolete outlet. Do not defeat the safety purpose of the polarized plug.

State of California Proposition 65 Warnings:

WARNING: This product contains one or more chemicals known to the State of California to

cause cancer.

WARNING: This product contains one or more chemicals known to the State of California to

cause birth defects or other reproductive harm.

Replacing the Vacuum Bag and Filters

Replacing the Vacuum Bag

Change the vacuum bag when the full bag indicator changes from green to red or when the suction power is weak. The bag compartment will not close without a bag in the vacuum or if the bag is not properly installed.

1. Open the bag compartment.

2. Pull the tab on the bag collar, which closes the bag while removing it from the bag holder.

3. Remove and discard the used bag. NOTE: The HEPA media bag cannot be reused.

4. Slide a new bag into the bag holder until it clicks into place.

5. Close the bag compartment.

When to Change the Filters

At a minimum, it’s recommended to replace the HEPA media and secondary filter after using 12 vacuum bags.

If someone in your household is sensitive to airborne allergens, it is recommended to change the filter set after every six vacuum bags.

Replacing the Secondary Filter

1. Open the bag compartment and locate the filter behind the vacuum bag. For better access to the secondary filter, remove the bag.

2. Pull the filter holder up.

3. Remove the used filter and replace it with a new filter.

4. Slide the filter holder back into place and replace the bag.

Replacing the HEPA Media Filter

1. Open the bag compartment and locate the filter behind the vacuum bag. For better access to the HEPA media filter, remove the bag.

2. Grasp the tab with two fingers and pull the filter out towards you. Replace with a new filter by sliding the filter in and pushing down on the top of the tab until it clicks into place.

NOTE: The HEPA media filter cannot be washed

and reused.

Description and Operation of the Canister

Hose Inlet

• To separate the hose from the canister body, press the buttons on the hose inlet and pull it away from the canister.

Storage

• The tab on the neck of the wand or the neck of the floor tool can be inserted into either groove on the canister for easy storage.

Power Cord Management

• Pull the cord out of the vacuum to desired length. Do not pull the cord out past the yellow safety tape.

• Insert the cord into the cord holder to lock into place.

• To retract the cord, remove it from the holder and tug on the cord until it retracts into the vacuum.

Floor It! Tool with Microfiber Pad

• Use to clean and polish tile, hard wood and linoleum floors.

2-n-1 Tool

• This tool converts from a

premium dusting brush to a deluxe upholstery tool by inserting the hose handle or wand end into the indicated openings.

Wand

Insert here for

Deluxe Upholstery Tool

Insert here for

Premium Dusting Brush

Description and Operation of the Canister

Cleaning Tools

2-n-1 Tool

Power Nozzle

On/Off

Control

Handle

Release

Button

Crevice

Tool

Suction Relief Dial

• Turn dial to open air stream and reduce suction for delicate jobs like cleaning sheer curtains.

Power Control

• Slide to increase or decrease the power of the motor.

Wand

Extension

Button

Full Bag Indicator

• If the green indicator changes to red:

- Change the vacuum bag.

- If the vacuum bag is not full, but the full bag indicator is red, check the hose for a clog.

- If you are vacuuming fine dust like flour or drywall dust, the pores of the bag may become clogged reducing suction before the bag is full. If this happens, change the bag and resume vacuuming.

• When cleaning with a tool (2-n-1 tool or crevice tool), the red

indicator may appear. In this case, continue cleaning.

Bag Compartment Latch

• Lift here to access the vacuum bag and filters.

On/Off Switch

POWER

Description of the Premium & Full Size Power Nozzles

Rear View

Handle

Telescopic Wand

Front View

Power Nozzle

Handle

Telescopic Wand

Power Nozzle

Wand Release Collar

Upright Lock Release Pedal

Height Adjustment Pedal

On/Off Control for Power Nozzle

Handle Release Button

Wand Extension Button (to extend wand)

Height Indicator Window

Jammed Brushroll Warning Light Dirt Sensor (Premium Model only)

Wand Release Collar

Xenon Headlamp

Soft Furniture Guard

Operation of the Premium & Full Size Power Nozzles

Turning On the Power Nozzle

The power nozzle can only be turned on if the canister is also turned on. The canister’s On/Off switch is located on the main body (see page 7). The power nozzle On/Off switch is located on the handle (see page 8). Simply press the switch forward to engage the power nozzle.

Using the Power Nozzle

After turning on the canister and the power nozzle, lower the wand by pressing the left pedal on the back side of the power nozzle.

Removing and Inserting the Wand

Removing the wand from the power nozzle allows you to use cleaning tools for baseboard or ceiling cleaning. To do this, first turn the power nozzle and the canister off. Then, press the wand release collar pictured below and pull the wand out.

Carpet Height Adjustment

Your power nozzle has six different settings to clean a variety of carpet types and floor surfaces. To adjust the carpet height setting of the power nozzle, press the right pedal located on the back of the power nozzle. Each press of this pedal will adjust the height to the next carpet height position.

To determine which setting you are currently on, look through the height indicator window on the top of the unit. You will see one of the six settings detailed below.

To reinsert the wand into the power nozzle, simply press the wand back into the neck of the power nozzle. The wand will then click into place.

Setting: Intended Use:

1. XHI Very plush carpet

2. HI Plush carpet

3. Auto General carpet thickness or bare floors

4. MED Medium pile carpet

5. LO Low pile carpet

6. XLO Indoor/Outdoor carpet

Operation of the Premium & Full Size Power Nozzles

Maintenance & Care of the Premium & Full Size Power Nozzles

Carpet Height Adjustment Tips:

When using the power nozzle, start on the “Auto” setting. If pushing the power nozzle feels difficult, then adjust to a higher setting. If the power nozzle feels very easy to push, you may want to lower the power nozzle for more effective cleaning. The “Auto” setting is the recommended setting for hard floor surfaces (i.e. tile, vinyl, wood).

Warning Light

Your power nozzle is equipped with a circuit breaker safety system that protects it from a jammed situation. Common items that cause jammed brushrolls include socks, excessive threads, corners of area rugs, etc. The warning indicator light on top of the unit will change from green to red should this condition occur.

If the circuit breaker trips:

• Turn off the vacuum cleaner and power nozzle then unplug the power cord.

• Remove the object preventing the brushroll from turning.

• Locate the circuit breaker switch on the back of the power nozzle and press it to reset the breaker. When the unit is turned back on, the warning light should be green.

If the breaker trips again, repeat these steps again to correct the problem. If this does not correct the problem, contact your authorized Simplicity Vacuums retailer for further assistance.

Dirt Sensor - Premium Model only

The warning light will change to orange if the dirt sensor detects dirt in the carpet and will change to green when the carpet is clean.

Maintenance & Care of the Premium & Full Size Power Nozzles

Removing the Brushroll

IMPORTANT: Before performing any maintenance on the power nozzle, always unplug the vacuum cleaner and disconnect the wand.

Your brushroll may need to be removed at times, to cut threads that have become tangled around the brushroll or to replace the belt (see “Replacing the Power Nozzle Belt”).

To remove the brushroll, turn the unit over and take off the metal bottom plate by first unscrewing the two bottom plate screws located by the rear wheels.

To reinstall the brushroll, reinsert the brushroll back into the unit (make sure the belt is attached properly). Next, insert the belt cover guard. Then, place the metal bottom plate back onto the unit (insert the front end of the bottom plate first). Re-insert the two bottom plate screws and secure.

Replacing the Power Nozzle Belt

IMPORTANT: Before performing any maintenance work on the power nozzle, always unplug the vacuum cleaner and disconnect the wand.

To replace the power nozzle belt, you must first remove the brushroll (see “Removing the Brushroll”). Then locate and discard the broken belt.

To install the new belt, locate the power nozzle motor pulley and loop the belt around it.

Remove the belt cover guard and pull the brushroll out.

Place the other end of the belt around the brushroll making sure the belt is seated in the “belt groove” of the brushroll.

Maintenance & Care of the Premium & Full Size Power Nozzles

Replacing the Power Nozzle Belt Cont.

Insert the brushroll back into the brushroll tray and place the belt guard back into position.

Spin the brushroll with your hand to make sure it spins freely. Place the metal bottom plate onto the unit (insert the front end of the bottom plate first). Re-insert the two bottom screws and secure.

Replacing the Bulb

IMPORTANT: Before performing any maintenance work on the power nozzle, always unplug the vacuum cleaner and disconnect the wand.

Turn the power nozzle over and remove the bottom plate by first unscrewing the two bottom plate screws located by the rear wheels.

Remove the two top cover screws. Turn the power nozzle back over, push the neck flat, and remove the top cover.

Simply pull the bulb out (no twisting) and reinsert a factory-authorized bulb. Place the top cover back on the unit, turn the machine over and re-insert the two top cover screws. Reinstall the bottom plate.

Rear View:

Compact Power Nozzle

Telescopic Wand

Handle

Reset Button

Description of the Compact Power Nozzle

Handle

Telescopic Wand

Front View:

Compact Power Nozzle

Handle

Telescopic Wand

Compact Power Nozzle

Reset Button

On/Off Switch for Power Nozzle

Handle Release Button

Wand Extension Button

(to extend wand)

Wand Release Button

Headlight

Soft Furniture Guard

Operation of the Compact Power Nozzle

Turning On the Power Nozzle

The power nozzle can only be turned on if the canister is also turned on. The canister On/Off switch is located on the main body (see page 7). The power nozzle On/Off switch is located on the handle (see page 13). Simply press the switch forward to engage the power nozzle.

Using the Power Nozzle

After turning on the canister and the power nozzle, lower the wand by stepping on the top of the power nozzle and pulling the wand toward you.

Removing and Inserting the Wand

Brushroll Jam Protection

If Your Power Nozzle Shuts Off:

• Turn off the vacuum cleaner and power nozzle then unplug the power cord.

• Remove the object preventing the brushroll from turning.

• Locate the circuit breaker button on the back of the power nozzle and press it to reset the breaker.

Removing the wand from the power nozzle allows you to use cleaning tools for baseboard or ceiling cleaning. To do this, first turn the power nozzle and canister off. Then, press the wand release button and pull the wand out.

To reinsert the wand into the power nozzle, simply press the wand back into the neck of the power nozzle. The wand will then click into place.

If the nozzle shuts off again, repeat these steps to correct the problem. If this does not correct the problem, contact your Authorized Simplicity Retailer for further assistance.

Maintenance & Care of the Compact Power Nozzle

Removing the Brushroll

IMPORTANT: Before performing any maintenance on the power nozzle, always unplug the vacuum cleaner and disconnect the wand.

The brushroll may need to be removed at times, to cut threads that have become tangled around it.

To remove the brushroll, turn the nozzle over and turn the two large screws 1/4 turn. Lift off the baseplate. Pull the brushroll out and remove the endcap.

To reinstall the brushroll first loop the belt over the end of the brushroll, then replace the endcap. Reinsert the brushroll into the nozzle making sure the long sides of the endcaps slide into the bottom housing.

To replace the baseplate, insert the tabs on each end of the baseplate into the grooves on the front of the bottom housing.

Tighten the two large screws. Make sure the tabs on the front of the baseplate are snapped securely in place in the bottom housing.

Troubleshooting Guide

Please check each item below if you have trouble with your vacuum. Unplug the vacuum from the power supply before servicing.

Problem Check Point Possible Solution

Suction power is weak. Vacuum bag If vacuum bag is full, replace it.

Wand, power nozzle, tools If clogged or blocked, or hose remove the object.

The vacuum does not work. Is the hose adapter inserted Insert it completely. into the suction opening of the vacuum completely?

When the vacuum bag is full Turn the vacuum off and or any of the accessories are unplug the vacuum. blocked, the over-heating Check the vacuum protection for the motor bag and accessories is activated. and remove any blockages. The vacuum can be turned on again after approximately 20 minutes.

Power cord does not retract. Power cord Tug the power cord a little until it starts to retract.

Power cord won’t pull out of Power cord Do not pull it out by force. the vacuum. Visit an Authorized Simplicity Vacuum Retailer.

Speciﬁcations

Model: WONDERP Rating: 120V/60Hz Amps: 10 (without power nozzle)

Key Replacement Parts

• Genuine HEPA Media Vacuum Bags 6 pack: SCH-6

• Genuine HEPA Media Filter Set: SF19

• Genuine Belt: PVB (Full Size Power Nozzle), PVBCN (Compact Power Nozzle)

• Mircober Pad 3 pack: HFIP-3

Owner’s Information

(keep this for your records)

The model and serial number of this product may be found on the back side of the unit. You should note the model and serial number of your unit in the spaces provided below, and retain this book as a permanent record of your purchase.

Date of purchase ____________________________________________________

Serial number _______________________________________________________

Model number ______________________________________________________

Purchased from:

Store name _______________________________________________________

Address _______________________________________________________

City, State, Zip ______________________________________________________

Telephone _______________________________________________________

For Best Performance:

• Keep your canister clean and in good operating condition.

• Change vacuum bags once a month or when the full bag indicator changes from green to red to maximize cleaning performance.

• Always use genuine vacuum bags and replacement parts. Use of other products may result in poor cleaning performance, potential vacuum cleaner damage and may void vacuum warranty. Genuine products are designed for maximum cleaning performance.

• Have your canister checked periodically by your Authorized Simplicity Vacuum Retailer.

• Use only Authorized Simplicity Vacuum Retailers for parts or service.

• Store your canister carefully in a dry area.

• For optimum cleaning performance and safety, follow your owner’s manual instructions.

www.SimplicityVac.com

Warranty

What is Covered:

This warranty covers any defects in material and workmanship in your new Simplicity vacuum and applies exclusively to the original purchaser.

How Long Coverage Lasts:

Warranty coverage for the Simplicity Wonder canister body and its contents lasts ve years. Warranty coverage for all other components lasts three years. Canister body contents and all other components on household models used commercially are only warranted for 90 days.

What is Not Covered:

• Damage to the vacuum which occurs from neglect, abuse, alterations, accident, misuse or improper maintenance.

• Normal replacement items: belts, lters and disposable bags.

What Simplicity Vacuums Will Do:

This warranty provides, at no cost to you, all labor and parts to place this vacuum in correct operating condition during the warranted period.

How to Get Service:

Warranty service can only be obtained by presenting the vacuum to an Authorized Simplicity Vacuum Retailer. A proof-of-purchase and product serial number will be required before service is rendered. To locate your

nearest Simplicity Vacuum Retailer, please call 1-888-9-SIMPLY or visit the Simplicity Vacuum website at www.SimplicityVac.com.

THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER WARRANTIES WHETHER WRITTEN, ORAL, EXPRESSED OR IMPLIED, (INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE). THIS WARRANTY DISCLAIMS LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.

How State Law Applies:

This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.

www.SimplicityVac.com

Notes

www.SimplicityVac.com

Simplicity Wonder User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
