Silverline Reciprocating Saw 115mm User Manual [en, de, es, fr, it]

3 Year Guarantee

*Register online within 30 days. Terms & Conditions apply

Garantie de 3 ans

*Enregistrez votre produit en ligne dans les 30 jours. Sous réserve des termes et conditions appliquées

3 Jahre Garantie *Innerhalb von 30 Tagen online registrieren. Es gelten die Allgemeinen Geschäftsbedingungen

3 años de garantía

*Registre su producto online durante los primeros 30 días. Se aplican términos y condiciones

3 anni di garanzia *Registrare il vostro prodotto on-line entro 30 giorni. Termini e condizioni si applicano

3 jaar garantie *Registreer uw product binnen 30 dagen online. Algemene voorwaarden zijn van toepassing

www.silverlinetools.com

304583_Z1MANPRO1.indd 2 30/01/2014 09:51

115mm

304583

800W Reciprocating Saw

800W Reciprocating Saw Scie sabre 800 W

Sierra sable 800 W 800 W Sega a sciabola

800-W-Säbelsäge

800 W reciprozaag

www.silverlinetools.com

304583_Z1MANPRO1.indd 3 30/01/2014 09:51

304583_Z1MANPRO1.indd 2 30/01/2014 09:51

115mm

800W Reciprocating Saw

English .................. 4

Français ................ 10

Deutsch ................. 16

Español ................. 22

Italiano .................. 28

Nederlands ............ 34

www.silverlinetools.com

304583_Z1MANPRO1.indd 3 30/01/2014 09:51

Description of Symbols

The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use

Wear hearing protection Wear eye protection Wear breathing protection Wear head protection

Wear hand protection

Read instruction manual

Class II construction (double insulated for additional protection)

Conforms to relevant legislation and safety standards

Environmental Protection

Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice

Input voltage: ................................................ 230-240V~ 50Hz

Power: ...........................................................800W

No load speed: ...............................................0 - 2600min

Stroke length: ................................................20mm

Cutting capacity: .......................................... Wood: 115mm

Steel: 5mm

Protection class: ............................................

Ingress protection: .........................................IP20

Length of power cord: .................................... 2m

Weight: ..........................................................2.8kg

Sound and vibration information:

Sound pressure LPA: .......................................76dB(A)

Sound power LWA: ..........................................87dB(A)

Uncertainty K: ................................................3dB

Weighted vibration ah,B: ..................................4.13m/s

Weighted vibration ah,WB: ................................3.11m/s

Uncertainty K: ................................................1.5m/s

The sound intensity level for the operator may exceed 85dB(A) and sound

As part of our ongoing product development, speciﬁcations of Silverline products

Speciﬁcation

-1

protection measures are necessary.

may alter without notice.

WARNING: Always wear ear protection where the sound level exceeds 85dB(A) and limit the time of exposure if necessary. If sound levels are uncomfortable, even with ear protection, stop using the tool immediately and check the ear protection is correctly ﬁtted and provides the correct level of sound attenuation for the level of sound produced by your tool.

WARNING: User exposure to tool vibration can result in loss of sense of touch, numbness, tingling and reduced ability to grip. Long term exposure can lead to a chronic condition. If necessary, limit the length of time exposed to vibration and use anti-vibration gloves. Do not operate the tool with hands below a normal comfortable temperature, as vibration will have a greater effect. Use the ﬁgures provided in the speciﬁcation relating to vibration to calculate the duration and frequency of operating the tool.

Sound and vibration levels in the speciﬁcation are determined according to EN60745 or similar international standards. The ﬁgures represent normal use for the tool in normal working conditions. A poorly maintained, incorrectly assembled, or misused tool, may produce increased levels of noise and vibration. www.osha. europa.eu provides information on sound and vibration levels in the workplace that may be useful to domestic users who use tools for long periods of time.

General Power Tool Safety Warnings

WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, ﬁre and/or serious injury.

WARNING: This appliance is not intended for use by persons (including children) with reduced, physical or mental capabilities or lack of experience or knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

Children must be supervised to ensure that they do not play with the appliance.

Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

Work Area Safety

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents b) Do not operate power tools in explosive atmospheres, such as in the

presence of ﬂammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes

c) Keep children and bystanders away while operating a power tool.

Distractions can cause you to lose control

Electrical Safety

a) Power tool plugs must match the outlet. Never modify the plug in any

way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodiﬁed plugs and matching outlets will reduce risk of electric

shock

b) Avoid body contact with earthed or grounded surfaces, such as pipes,

radiators, ranges and refrigerators. There is an increased risk of electric

shock if your body is earthed or grounded

c) Do not expose power tools to rain or wet conditions. Water entering a

power tool will increase the risk of electric shock

d) Do not abuse the cord. Never use the cord for carrying, pulling or

unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric

shock

e) When operating a power tool outdoors, use an extension cord suitable

for outdoor use. Use of a cord suitable for outdoor use reduces the risk of

electric shock

f) If operating a power tool in a damp location is unavoidable, use a

residual current device (RCD) protected supply. Use of an RCD reduces

the risk of electric shock

WARNING: When used in Australia or New Zealand, it is recommended that this tool is ALWAYS supplied via Residual Current Device (RCD) with a rated residual current of 30mA or less.

Personal Safety

a) Stay alert, watch what you are doing and use common sense when

operating a power tool. Do not use a power tool while you are tired or under the inﬂuence of drugs, alcohol or medication. A moment of

inattention while operating power tools may result in serious personal injury

b) Use personal protective equipment. Always wear eye protection.

Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries

304583_Z1MANPRO1.indd 4 30/01/2014 09:51

800W Reciprocating Saw 304583

c) Prevent unintentional starting. Ensure the switch is in the off-position

before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your ﬁnger on the switch or

energising power tools that have the switch on invites accidents

d) Remove any adjusting key or wrench before turning the power tool on.

A wrench or a key left attached to a rotating part of the power tool may result in personal injury

e) Do not overreach. Keep proper footing and balance at all times. This

enables better control of the power tool in unexpected situations

f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,

clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts

g) If devices are provided for the connection of dust extraction and

collection facilities, ensure these are connected and properly used. Use

of dust collection can reduce dust-related hazards

Power Tool Use & Care

a) Do not force the power tool. Use the correct power tool for your

application. The correct power tool will do the job better and safer at the

rate for which it was designed

b) Do not use the power tool if the switch does not turn it on and off. Any

power tool that cannot be controlled with the switch is dangerous and must be repaired

c) Disconnect the plug from the power source and/or the battery pack

from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures

reduce the risk of starting the power tool accidentally

d) Store idle power tools out of the reach of children and do not allow

persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users

e) Maintain power tools. Check for misalignment or binding of moving

parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools

f) Keep cutting tools sharp and clean. Properly maintained cutting tools with

sharp cutting edges are less likely to bind and are easier to control

g) Use the power tool, accessories and tool bits etc. in accordance with

these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from

those intended could result in a hazardous situation

Service

a) Have your power tool serviced by a qualiﬁed repair person using only

identical replacement parts. This will ensure that the safety of the power

tool is maintained

WARNING: Before connecting a tool to a power source (mains switch power point receptacle, outlet, etc.) be sure that the voltage supply is the same as that speciﬁed on the nameplate of the tool. A power source with a voltage greater than that speciﬁed for the tool can result in serious injury to the user, and damage to the tool. If in doubt, do not plug in the tool. Using a power source with a voltage less than the nameplate rating is harmful to the motor.

Reciprocating Saw Safety

• Ensure that lighting is adequate

• Keep the area free of tripping hazards

• Wear appropriate safety equipment including eye protection and gloves to protect against vibration

• Never saw near combustible liquids or gases

• Check for hidden wiring and pipes before sawing

• Use recommended blades only

• Blades must be sharp and not cracked or distorted

• Before starting work, inspect the workpiece and remove all embedded objects such as nails, screws etc

• Support and secure the workpiece correctly

• When cutting cylindrical wood, use clamps that prevent the workpiece from turning

• Use the insulated handles when operating power tools. This protects the operator if the tool accidentally cuts through hidden electrical wiring, causing the tool to become ‘live’

• Always stand to one side when operating the saw

• Do not use your hands to remove sawdust, chips or waste close to the blade

• Never reach over the blade to remove waste or off-cuts

• Do not attempt to free a jammed blade until the machine has been disconnected from the power

• Do not attempt to slow or stop a blade with any object. Let the blade come to rest naturally

• If you are interrupted when operating the saw, complete the process and switch off before looking up

• Periodically check the tool for loose nuts, bolts and tighten as necessary

Product Familiarisation

1 Wood Blade

2 Pivoting Shoe 3 Chuck Collar 4 Secondary Grip 5 Rotating Barrel 6 Barrel Locking Switch 7 Lock-On Button 8 Handle

9 Variable Speed Trigger Switch 10 Barrel Grip 11 Shoe Adjustment Screws

Included Accessories:

• 1 x hex key

Intended Use

Reciprocating power saw for light to medium duty cutting of wood, plasterboard, plastic, mild steel, and also non-ferrous metals (requiring the purchase of additional, material-speciﬁc saw blades).

Unpacking Your Tool

• Carefully unpack and inspect your tool. Familiarise yourself with all its features and functions

• Ensure that all parts of the tool are present and in good condition. If any parts are missing or damaged, have such parts replaced before attempting to use this tool

www.silverlinetools.com

304583_Z1MANPRO1.indd 5 30/01/2014 09:51

Before Use

Fitting a saw blade

WARNING: ALWAYS ensure that the tool is switched off and disconnected from the

power supply, before ﬁtting or removing saw blades.

WARNING: ALWAYS wear suitable cut-proof gloves when handling saw blades. WARNING: DO NOT continue to use blunt, warped or otherwise damaged saw

blades. Note: ALWAYS ﬁt a saw blade speciﬁc to the material you are cutting.

1. Rotate the Chuck Collar (3) fully anticlockwise, and insert the blade shank as far as it will go into the chuck

2. Release the chuck collar

3. Pull the blade to ensure that it is secure. If it is not locked ﬁrmly in place repeat the above procedure

4. To remove a blade from the chuck, rotate the chuck collar fully anticlockwise, and pull the blade forward, out of the chuck

Adjusting the handle

Note: The Handle (8) orientation of this reciprocating saw can be adjusted to adapt

to working conditions and to best suit operator preference.

1. Push the Barrel Locking Switch (6) back to release the Rotating Barrel (5)

2. Rotate the Handle (8) to the position required

3. Release the Barrel Locking Switch. The barrel should lock in position with a click

Note: Rotate the barrel back and forth to check that it cannot move, or that it clicks into the adjacent lock position.

WARNING: DO NOT operate the tool unless the handle is securely locked in one of the 5 pre-set positions.

Adjusting the shoe

WARNING: ALWAYS ensure that the tool is switched off and disconnected from the

power supply, before attempting to adjust the shoe.

1. Loosen the two Shoe Adjustment Screws (11) with the supplied hex key

2. Reposition the shoe to shield the length of the blade as required

3. Retighten the Shoe Adjustment Screws

WARNING: Take care not to over-tighten the screws, or you may damage the thread.

Note: Where possible, rest the shoe on the material being cut. Pivot the angle of the shoe to suit the shape of the material.

WARNING: DO NOT operate the reciprocating saw if the adjustable shoe is damaged or not installed.

Operation

WARNING: Always use adequate protective equipment, including eye protection, respiratory and hearing protection, as well as suitable gloves, when working with this tool.

WARNING: When cutting wood, ensure foreign objects, such as nails and screws, are removed from the workpiece before starting to cut.

WARNING: NEVER attempt to cut with a saw blade ﬁtted that is not suitable for the material. NEVER use blunt or otherwise damaged saw blades.

Note: ALWAYS use clamps to secure your workpiece to the workbench wherever possible.

Switching on and off

1. Connect the plug to the power supply

2. Hold the tool securely with both hands by the Handle (8) and Barrel Grip (10), and make sure that you have full control at all times

3. Ensure the tool is not in contact with the workpiece before commencing with switching on

4. Press the Variable Speed Trigger Switch (9) to start the machine

Note: The speed of the blade is controlled by increasing/decreasing pressure on the Variable Speed Trigger Switch (also see ‘Adjusting Tool Speed’).

5. Release the Variable Speed Trigger Switch to stop the machine

WARNING: ALWAYS remove the saw blade from the cut before switching off. WARNING: Always wait until the saw blade has stopped moving completely, before

putting the machine down. Always disconnect from the power supply after use. Note: This saw features a Lock-On Button (7), which locks the Variable Speed

Trigger Switch (9) in the ‘On’ position. Press the Variable Speed Trigger Switch fully, and then engage the Lock-On Button for continuous operation. The tool will run on maximum speed. Press the Variable Speed Trigger Switch again, to release the Lock-On Button, and switch the machine off.

WARNING: DO NOT use the lock-on feature when the material requires cutting at reduced speeds (e.g. when cutting metal objects).

Adjusting tool speed

Note: This Silverline reciprocating saw features variable speed control, adjusted by

the Variable Speed Trigger Switch (9), which enables it to be used with a variety of different materials, workpieces and objects.

WARNING: ALWAYS adjust the speed according to material requirements. Use appropriate cutting ﬂuid or cooling agent when cutting metals.

• The Variable Speed Trigger Switch (9) is pressure sensitive. The further the Variable Speed Trigger Switch is depressed, the faster the tool speed

Note: If in doubt about the correct cutting speed, refer to the blade manufacturer’s instructions, and follow recommendations speciﬁc to the material being cut.

Making general cuts

1. Mark out the cutting line

2. Ensure that the material to be cut is secure. Small workpieces should be held

in a vice or clamped to the workbench

3. Hold the saw ﬁrmly using both hands, one on the Handle (8), one on the

Barrel Grip (10)

4. Make sure that the blade is clear of any obstruction and that the power cord

or any extension cord is out of the path of the blade

5. Squeeze the trigger and allow the blade to reach full speed

6. Place the shoe on the workpiece and begin sawing

WARNING: Use ONLY enough pressure to keep the saw cutting. NEVER force the saw blade; allow the blade and the saw to do the work. Use of excessive pressure that causes bending or twisting of the blade may cause the blade to break.

Making plunge cuts

WARNING: Plunge cutting is an advanced technique with higher risk. Only attempt

plunge cuts when you are competent and experienced with this technique. WARNING: ONLY attempt the plunge cutting procedure in soft materials such as

wood, plasterboard and similar materials. DO NOT attempt plunge cuts in metal or hard materials. ONLY use blades speciﬁcally designed for plunge cutting. If in doubt, refer to the blade manufacturer’s instructions.

WARNING: Inspect both sides of the surface you are planning on plunge cutting into. Ensure there are no foreign objects on the underneath, or objects which could be damaged. Be aware of hidden pipe work and cables, when plunge cutting into drywalls, ceilings or ﬂoor boards. If pipes or cables may be present, switch off all electrical circuit breakers and shut off water and gas supplies at the relevant mains valves.

WARNING: Blindly plunge cutting into walls, ﬂoors and ceilings may lead to serious injury and substantial property damage.

1. Mark the line of the cut

2. Choose a point inside the area to be cut out and place the tip of the blade

over that point

3. Rest the front edge of the shoe on the workpiece, so the blade does not

make contact with the workpiece surface

4. Hold the tool securely with both hands by the Handle (8) and Barrel Grip (10),

and make sure that you have full control at all times

5. Squeeze the Variable Speed Trigger Switch (9) trigger fully, for maximum

speed, and allow the blade to reach full speed

6. Slowly lower the blade until it makes contact with the workpiece

7. Continue to cut slowly, until the blade has fully penetrated the thickness of

the workpiece

8. Commence with cutting as normal

Metal cutting tips

Note: This saw is capable of cutting metals, such as sheet steel, pipe, steel rods,

aluminium, brass and copper.

• ALWAYS use a blade speciﬁed for cutting metal

• Be careful not to bend or twist the blade and do not force the cutting action

• ALWAYS use a suitable cutting ﬂuid when sawing soft metals and steel. This keeps the blade cooler, prolongs blade life and makes cutting more efﬁcient

• Clamp the work ﬁrmly and cut close to the clamping point to minimise vibration

• When cutting conduit pipe or angle iron, clamp the work in a vice if possible and cut close to the vice

• To cut thin sheet metal, sandwich the sheet between hardboard or plywood and clamp the layers to prevent vibration and tearing of the metal

304583_Z1MANPRO1.indd 6 30/01/2014 09:51

Accessories

• A full range of material speciﬁc saw blades, plunge cutting blades and other accessories is available from your Silverline stockist

Maintenance

WARNING: ALWAYS ensure that the tool is disconnected from the power supply, before cleaning, changing accessories, or carrying out maintenance.

General inspection

• Regularly check that all the ﬁxing screws are tight. They may vibrate loose over time

• Inspect the supply cord of the tool, prior to each use, for damage or wear. Repairs should be carried out by an authorised Silverline service centre. This advice also applies to extension cords used with this tool

Cleaning

WARNING: ALWAYS wear protective equipment including eye protection and gloves

when cleaning this tool.

• Keep your tool clean at all times. Dirt and dust will cause internal parts to wear quickly, and shorten the device’s service life

• Clean the body of your machine with a soft brush, or dry cloth

• Never use caustic agents to clean plastic parts. If dry cleaning is not sufﬁcient, a mild detergent on a damp cloth is recommended

• Water must never come into contact with the tool

• Ensure the tool is thoroughly dry before using it

• If available, use clean, dry, compressed air to blow through the ventilation holes (where applicable)

Brushes

• Over time the carbon brushes inside the motor may become worn

• Excessively worn brushes may cause loss of power, intermittent failure, or visible sparking

• To replace the brushes, remove the brush access plugs from both sides of the machine. Remove the worn brushes and replaced with new. Replace brush access plugs. Alternatively, have the machine serviced at an authorised Silverline service centre

Note: The brush access caps are located on the Rotating Barrel (5). The Handle (8) must be adjusted to the most outward positions to gain brush access (see ‘Adjusting handle position’).

Storage

• Store this tool carefully in a secure, dry place out of the reach of children

Disposal

Always adhere to national regulations when disposing of power tools that are no longer functional and are not viable for repair.

• Do not dispose of power tools, or other waste electrical and electronic equipment (WEEE), with household waste

• Contact your local waste disposal authority for information on the correct way to dispose of power tools

800W Reciprocating Saw 304583

www.silverlinetools.com

304583_Z1MANPRO1.indd 7 30/01/2014 09:51

Troubleshooting

No function when Variable Speed

Trigger Switch (9) is operated

Slow cutting performance

Saw blade blunts quickly

Problem Possible cause Solution

No power Check power supply

Defective Variable Speed Trigger Switch

Carbon brushes worn

Saw blade not suitable for the material being cut Fit compatible saw blade

Saw blade blunt Fit new saw blade

Incorrect cutting speed Adjust cutting speed to match material requirements

Saw blade not suitable for the material being cut Fit compatible saw blade

Too much pressure exerted on to the tool Use less pressure whilst moving the machine

Cutting speed too fast Reduce cutting speeds to material requirements

No cutting ﬂuid/cooling agent used when cutting metal Use a suitable cutting ﬂuid when cutting metal

Have the Variable Speed Trigger Switch replaced by an authorised Silverline

Replace carbon brushes, or have the carbon brushes replaced by an

service centre

authorised Silverline service centre

304583_Z1MANPRO1.indd 8 30/01/2014 09:51

www.silverlinetools.com

800W Reciprocating Saw 304583

Silverline Tools Guarantee

This Silverline product comes with a 3 year guarantee

Register this product at www.silverlinetools.com within 30 days of purchase in order to qualify for the 3 year guarantee. Guarantee period begins according to the date of purchase on your sales receipt.

Terms & Conditions

Guarantee period becomes effective from the date of retail purchase as detailed on your sales receipt.

PLEASE KEEP YOUR SALES RECEIPT

If this product develops a fault within 30 days of purchase, return it to the stockist where it was purchased, with your receipt, stating details of the fault. You will receive a replacement or refund.

If this product develops a fault after the 30 day period, return it to:

Silverline Tools Service Centre PO Box 2988 Yeovil BA21 1WU, UK

The guarantee claim must be submitted during the guarantee period. You must provide the original sales receipt indicating the purchase date, your

name, address and place of purchase before any work can be carried out.

You must provide precise details of the fault requiring correction. Claims made within the guarantee period will be veriﬁed by Silverline Tools

to establish if the deﬁciencies are related to material or manufacturing of the product.

Carriage will not be refunded. Items for return must be in a suitably clean and safe state for repair, and should be packaged carefully to prevent damage or injury during transportation. We may reject unsuitable or unsafe deliveries.

All work will be carried out by Silverline Tools or its authorized repair agents.

The repair or replacement of the product will not extend the period of guarantee

Defects recognised by us as being covered by the guarantee shall be corrected by means of repair of the tool, free of charge (excluding carriage charges) or by replacement with a tool in perfect working order.

Retained tools, or parts, for which a replacement has been issued, will become the property of Silverline Tools.

Registering your purchase

Registration is made at silverlinetools.com by selecting the Guarantee Registration button. You will need to enter:-

• Your personal details

• Details of the product and purchase information Once this information is entered your guarantee certiﬁcate will be created in

PDF format for you to print out and keep with your purchase.

The repair or replacement of your product under guarantee provides beneﬁts which are additional to and do not affect your statutory rights as a consumer.

What is covered:

The repair of the product, if it can be veriﬁed to the satisfaction of Silverline Tools that the deﬁciencies were due to faulty materials or workmanship within the guarantee period.

If any part is no longer available or out of manufacture, Silverline Tools will replace it with a functional replacement part.

Use of this product in the EU.

What is not covered:

Silverline Tools does not guarantee repairs required as a result of: Normal wear and tear caused by use in accordance with the operating

instructions eg blades, brushes, belts, bulbs, batteries etc. The replacement of any provided accessories drill bits, blades, sanding

sheets, cutting discs and other related items. Accidental damage, faults caused by negligent use or care, misuse, neglect,

careless operation or handling of the product. Use of the product for anything other than normal domestic purposes. Change or modiﬁcation of the product in any way. Use of parts and accessories which are not genuine Silverline Tools

components. Faulty installation (except installed by Silverline Tools). Repairs or alterations carried out by parties other than Silverline Tools or its

authorized repair agents. Claims other than the right to correction of faults on the tool named in these

guarantee conditions are not covered by the guarantee.

CE Declaration of Conformity

The undersigned: Mr Darrell Morris as authorised by: Silverline Tools

Declares that the

Identiﬁcation code: 304583 Description: 800W Reciprocating Saw

Conforms to the following Directives:

• Machinery Directive 2006/42/EC

• EMC Directive 2004/108/EC

• RoHS Directive 2011/65/EU

• EN 60745-1:2009+A11:2010

• EN 60745-2-11:2010

• EN 55014-1:2006+A1:2009+A2:2011

• EN 55014-2:1997+A1:2001+A2:2008

• EN 61000-3-2:2008+A1:2009+A2:2009

• EN 61000-3-3:2008

Notiﬁed body: Intertek Testing Services, Shanghai, China

The technical documentation is kept by: Silverline Tools

Date: 20/01/14

Signed by:

Director

Name and address of the manufacturer:

Powerbox Ltd., Boundary Way, Lufton Trading Estate, Yeovil, Somerset,

BA22 8HZ, United Kingdom

304583_Z1MANPRO1.indd 9 30/01/2014 09:51

Description des symboles

La plaque signalétique ﬁgurant sur votre outil peut présenter des symboles. Ces symboles constituent des informations importantes relatives au produit ou des instructions concernant son utilisation.

Port de protection auditive Port de lunettes de sécurité Port du masque respiratoire Port du casque

Port de gants

Lire le manuel d’instructions

Double isolation pour une protection supplémentaire

Conforme à la réglementation et aux normes de sécurité pertinentes

Protection de l’environnement

Les produits électriques usagés ne doivent pas être jetés avec les ordures ménagères. Veuillez les recycler dans les centres prévus à cet effet. Pour de plus amples informations, veuillez contacter votre municipalité ou point de vente.

Caractéristiques techniques

Tension : ........................................................230 – 240 V~ 50 Hz

Puissance : ....................................................800 W

Vitesse à vide : ...............................................0 – 2600 tr/min

Longueur de course : .....................................20 mm

Capacité maximale de coupe : Bois ............... 115 mm

Acier...............................................................5 mm

Classe de protection : ....................................

Indice de protection : .....................................IP20

Longueur du câble d’alimentation : ................ 2 m

Poids : ............................................................2.8 kg

Informations sur le niveau d’intensité sonore et vibratoire

Pression acoustique LPA :................................76 dB(A)

Puissance acoustique LWA : ............................87 dB(A)

Incertitude K : ................................................3 dB

Vibration pondérée ah,B : ................................4.13 m/s

Vibration pondérée ah,WB :...............................3.11 m/s

Incertitude K : ................................................1.5 m/s

L’intensité sonore peut dépasser 85 dB(A) et il est nécessaire que l’utilisateur

Du fait de l’évolution constante de nos produits, les caractéristiques des produits

porte des protections auditives.

Silverline peuvent changer sans notiﬁcation préalable.

Attention : Toujours porter des protections sonores lorsque le niveau d’intensité est supérieur à 85 dB(A) et limiter le temps d’exposition si nécessaire. Si l’intensité sonore devient inconfortable, même avec les protections, arrêter immédiatement d’utiliser l’appareil, vériﬁer que les protections soient bien mises et qu’elles soient adéquates avec le niveau sonore produit par l’appareil.

Attention : L’exposition de l’utilisateur aux vibrations peut engendrer une perte du toucher, des engourdissements, des picotements et ainsi réduire la capacité de préhension. De longues expositions peuvent également provoquer ces symptômes de façon chronique. Si nécessaire, limiter le temps d’exposition aux vibrations, et porter des gants anti-vibrations. Ne pas utilisez cet appareil avec vos mains sous des conditions en dessous de températures normales, car l’effet vibratoire en est accentué. Se référer au cas de ﬁgures des caractéristiques relatives aux vibrations pour calculer le temps et fréquence d’utilisation de l’appareil.

Les niveaux sonores et vibratoires des caractéristiques techniques sont déterminés en fonction de la norme EN60745 ou autres normes internationales. . Ces données correspondent à un usage normale de l’appareil, et ce dans des conditions de travail normales. Un appareil mal entretenu, mal assemblé ou mal utilisé peut augmenter les niveaux sonores et vibratoires. Pour plus d’informations sur la directive des émissions sonores et vibratoires, visitez le site http://osha.

europa.eu/fr.

Consignes générales de sécurité

AVERTISSEMENT Veuillez lire l’intégralité des consignes de sécurité et des instructions. Le non-respect de ces consignes et instructions peut entraîner un

risque de choc électrique, d’incendie et/ou se traduire par des blessures graves

Attention : Cet appareil n’est pas conçu pour être utilisé par des personnes (enfants compris) ayant des capacités physiques ou mentales réduites, ou n’ayant pas la connaissance ou l’expérience requise, à moins d’être sous la supervision d’une personne responsable de leur sécurité ou d’avoir reçu les instructions nécessaires. Les enfants ne doivent pas s’approcher et jouer avec cet appareil.

Veuillez conserver ces instructions et consignes de sécurité pour référence ultérieure.

L’expression « appareil électrique » employée dans les présentes consignes recouvre aussi bien les appareils ﬁlaires à brancher sur le secteur que les appareils sans ﬁls fonctionnant sous batterie.

Sécurité sur la zone de travail

a) Maintenir une zone de travail propre et bien éclairée. Des zones

encombrées et mal éclairées sont sources d’accidents.

b) Ne pas utiliser d’outils électriques dans des environnements explosifs,

tels qu’à proximité de liquides, de gaz ou de poussières inﬂammables.

Les appareils électriques produisent des étincelles susceptibles d’enﬂammer la poussière ou les vapeurs présentes.

c) Eloigner les enfants et les passants pendant l’utilisation d’un appareil

électrique. Ceux-ci peuvent provoquer une perte d’attention et faire perdre

la maîtrise de l’appareil.

Sécurité électrique

a) La prise d’un appareil électrique doit être adaptée à la prise du secteur.

Ne jamais modiﬁer la prise en aucune façon. Ne jamais utiliser d’adaptateur sur la prise électrique d’appareil mis à la terre. Des prises

non modiﬁées, adaptées aux boîtiers de prise de courant, réduiront le risque de décharge électrique.

b) Eviter le contact corporel avec les surfaces mises à la terre telles que

tuyaux, radiateurs, cuisinières et réfrigérateurs. Le risque de décharge

électrique est plus important si le corps est mis à la terre.

c) Ne pas exposer l’appareil électrique à la pluie ou à l’humidité.

L’inﬁltration d’eau dans un appareil électrique accroît le risque de décharge électrique.

d) Ne pas maltraiter le cordon électrique. Ne jamais utiliser le cordon

électrique pour porter, tirer ou débrancher l’appareil. Protéger le cordon électrique de la chaleur, du contact avec l’essence, des bords tranchants et pièces rotatives. Un cordon électrique endommagé ou entortillé accroît le

risque de décharge électrique.

e) Lors d’une utilisation de l’appareil électrique en extérieur, se servir

d’une rallonge appropriée à une utilisation en extérieur. Cela réduit le

risque de décharge électrique.

f) Si une utilisation de l’appareil électrique dans un environnement

humide ne peut être évitée, utiliser une alimentation protégée par un disjoncteur différentiel. L’utilisation d’un disjoncteur différentiel réduit le

risque de décharge électrique.

ATTENTION : Lorsque utilisé en Australie ou en Nouvelle Zélande, il est

recommandé que cet appareil soit toujours alimenté via un disjoncteur différentiel ayant un courant résiduel de 30 mA ou moins.

304583_Z1MANPRO1.indd 10 30/01/2014 09:51

Scie sabre 800 W 304583

Sécurité des personnes

a) Rester vigilent et faire preuve de bon sens lors de la manipulation de

l’appareil. Ne pas utiliser un appareil électrique lorsque l’on se trouve dans un état de fatigue, ou sous l’inﬂuence de drogues, d’alcool ou de médicaments. Un moment d’inattention pendant l’utilisation d’un outil

électrique peut se traduire par des blessures graves.

b) Porter un équipement de protection approprié. Toujours porter une

protection oculaire. Le port de masque à poussières, chaussures de

sécurité antidérapantes, casque de sécurité et protections antibruit adaptés aux différentes conditions de travail réduit le risque de blessures corporelles.

c) Eviter tout démarrage accidentel. S’assurer que l’interrupteur

marche-arrêt soit en position d’arrêt avant de brancher l’appareil sur l’alimentation secteur ou d’installer la batterie, de prendre l’appareil ou de le transporter. Porter un appareil électrique tout en maintenant le doigt

posé sur l’interrupteur ou brancher un appareil électrique dont l’interrupteur est sur la position de marche est source d’accidents.

d) Enlever toute clé et tout instrument de réglage avant de mettre

l’appareil électrique en marche. Une clé ou un instrument de réglage

laissé ﬁxé à un élément en rotation de l’appareil électrique peut entraîner des blessures physiques.

e) Ne pas essayer d’atteindre une zone hors de portée. Se tenir toujours

en position stable permettant de conserver l’équilibre. Cela permet de

mieux contrôler l’appareil électrique dans des situations inattendues.

f) Porter des vêtements appropriés. Ne pas porter de vêtements amples

ou des bijoux pendants. Eloigner cheveux, vêtements et gants des pièces en mouvement. Les vêtements amples, les bijoux pendants et

cheveux longs peuvent être happés par les pièces en rotation.

g) Si l’appareil est pourvu de dispositifs destinés au raccord d’équipements

d’extraction et de récupération de la poussière/sciure, s’assurer qu’ils soient bien ﬁxés et utilisés correctement L’utilisation de ces dispositifs peut

réduire les risques dus à la poussière.

Utilisation et entretien des appareils électriques

a) Ne pas forcer sur l’appareil électrique. Utiliser l’appareil électrique

approprié au travail à effectuer. Un appareil électrique adapté et employé

au rythme pour lequel il a été conçu permettra de réaliser un travail de meilleure qualité et dans de meilleures conditions de sécurité.

b) Ne pas utiliser un appareil électrique dont l’interrupteur marche-arrêt

est hors service. Tout appareil électrique dont la commande ne s’effectue

plus par l’interrupteur marche-arrêt est dangereux et doit être réparé.

c) Débrancher l’appareil électrique ou démonter sa batterie avant

d’effectuer tout réglage ou changement d’accessoire et avant de le ranger. De telles mesures préventives réduiront les risques de démarrage

accidentel.

d) Ranger les appareils électriques inutilisés hors de portée des enfants

et ne pas permettre l’utilisation de cet appareil aux personnes non habituées à son maniement ou n’ayant pas lu les présentes instructions. Les appareils électriques sont dangereux dans les mains

d’utilisateurs inexpérimentés.

e) Veiller à l’entretien des appareils électriques. Vériﬁer que les éléments

rotatifs soient bien alignés et non grippés. S’assurer de l’absence de pièces cassées ou endommagées susceptibles de nuire au bon fonctionnement de l'appareil. Si l’appareil électrique est endommagé, le faire réparer avant toute utilisation. De nombreux accidents sont dus à

l’utilisation d’appareils électriques mal entretenus.

f) Veiller à ce que les outils de coupe soient tenus affûtés et propres. Des

outils de coupe bien entretenus, aux tranchants bien affûtés, sont moins susceptibles de se gripper et sont plus faciles à contrôler.

g) Utiliser l’appareil électrique, les accessoires et outils à monter

conformément à ces instructions, en tenant compte des conditions de travail et de la tâche à réaliser. Toute utilisation d’un appareil électrique

autre que celle pour laquelle il a été conçu peut entraîner des situations à risque.

Révision

a) Ne faire réparer votre appareil électrique que par un réparateur qualiﬁé

utilisant uniquement des pièces de rechange identiques. Cela permet de

maintenir la sécurité d’utilisation de l’appareil électrique.

ATTENTION : Avant de brancher un appareil sur une source d’alimentation (prise secteur, groupe électrogène, etc.) assurez-vous que la tension fournie soit la même que celle spéciﬁée sur la plaque de l’appareil. Une source d’alimentation avec une tension supérieure à celle indiquée sur l’appareil peut engendrer de sérieuses blessures pour l’utilisateur, et endommager l’appareil. En cas de doute, ne branchez pas l’appareil. Une source d’alimentation avec une tension inférieure à celle indiquée sur l’appareil est néfaste pour le moteur.

Consignes générales de sécurité relatives aux scies sabre

• Veillez à ce que l’éclairage soit d’un niveau sufﬁsant.

• Gardez la zone de travail dégagée de tout objet susceptible de provoquer un trébuchement.

• Portez un équipement de sécurité approprié, tels que des protections oculaires et des gants qui favorisent la protection contre les vibrations.

• Ne procédez pas à proximité de liquides ou de gaz inﬂammables.

• Avant de commencer, vériﬁez qu’il n’y a pas câbles ou de conduites cachés

• Utilisez seulement des lames du type recommandé

• Utilisez toujours une lame bien affûtée. N’employez jamais de lame ﬁssurée ou déformée.

• Avant de commencer, examinez la pièce à scier et éliminez tout objet étranger tel que clou, vis, etc.

• Prévoyez un support et une immobilisation appropriés de la pièce à scier.

• Lors de la coupe de bois de forme cylindrique, immobilisez la pièce à l’aide de dispositifs de serrage pour l’empêcher de tourner.

• Servez-vous toujours des poignées isolées de l’appareil pour le manier. Ceci vous protégera du choc électrique si l’outil devait accidentellement couper un ﬁl électrique sous tension.

• Tenez-vous toujours sur un côté lors du sciage.

• Ne vous servez jamais des mains pour enlever la sciure, les copeaux et déchets de coupe à proximité de la lame.

• N’étendez jamais la main au-dessus de la lame pour ôter les déchets et les chutes.

• N’essayez pas de dégager une lame coincée sans avoir débranché la machine au préalable.

• Ne faites jamais ralentir ni n’arrêtez jamais la lame à l’aide d’un quelconque objet ou surface. Laissez-la s’arrêter d’elle-même.

• Si l’on vous interrompt lors de la coupe. Terminez le processus et débranchez l’appareil avant de relever la tête.

• Vériﬁez de temps en temps que tous les écrous, boulons et autres vis de ﬁxation soient bien serrés.

Se familiariser avec le produit

1 Lame à bois

2 Semelle réglable 3 Collier du mandrin 4 Poignée secondaire 5 Corps rotatif 6 Loquet de rotation 7 Bouton de marche continue 8 Poignée

9 Gâchette marche-arrêt 10 Partie de préhension 11 Vis de réglage de la semelle

Accessoire inclus :

• 1 x clé hexagonale

Usage conforme

Scie sabre pour les coupes légères et moyennes sur le bois, les plaques de plâtre, le plastique, l’acier doux et également les métaux non-ferreux (nécessitant l’achat de lames de scies additionnelles spéciﬁques aux matériaux).

www.silverlinetools.com

304583_Z1MANPRO1.indd 11 30/01/2014 09:51

+ 28 hidden pages

Silverline Reciprocating Saw 115mm User Manual [en, de, es, fr, it]

Specifications and Main Features

Frequently Asked Questions

User Manual
