Silex Technology SDMAN User Manual

User Manual

Since this module is not sold to general end users directly, there is no user manual of
module.

For the details about this module, please refer to the specification sheet of module.

This module should be installed in the host device according to the interface specification
(installation procedure).

This radio transmitter SX-SDMAN identify the device by certification number or
model number if Category II) has been approved by Industry Canada to operate with
the antenna types listed below with the maximum permissible gain indicated.
Antenna types not included in this list, having a gain greater than the maximum gain
indicated for that type, are strictly prohibited for use with this device.

Antenna Type

Antenna Gain

2.4GHz W52/53/58

Embedded Antenna 2.0dBi 2.5dBi For Bluetooth and Wireless LAN

Slee v e anten na 1.0dBi 1.1dBi

Mini - N anobl a de ant enna(*) 2.5dBi 4.8dBi

Stan d Alo ne ante nna( *) 3.0dBi 4.6dBi

For Wireless LAN

For Mobile use only

For Wireless LAN

For Mobile use only

For Wireless LAN

For Mobile use only

Le présent émetteur radio SX-SDMAN a été approuvé par Industrie Canada pour
fonctionner avec les types d'antenne énumérés ci‑ dessous et ayant un gain
admissible maximal. Les types d'antenne non inclus dans cette liste, et dont le gain
est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation
de l'émetteur.

Type d’ antenne

Embedded Antenna 2.0dBi 2.5dBi For Bluetooth and Wireless LAN

Slee v e anten na 1.0dBi 1.1dBi

Gain

2.4GHz W52/53/58

For Wireless LAN

For Mobile use only

Mini - N anobl a de ant enna(*) 2.5dBi 4.8dBi

Stan d Alo ne ante nna( *) 3.0dBi 4.6dBi

For Wireless LAN

For Mobile use only

For Wireless LAN

For Mobile use only

(*)It has not been confirmed to meet new rules of FCC 14-30 and RSS-247 in a state of attaching
these antennas. Therefore, the additional testing and the class 2 permissive change application
are required before using these antennas.

[for FCC]

Contains Transmitter Module FCC ID: N6C-SDMAN

or

Contains FCC ID: N6C-SDMAN

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.

*If it is difficult to describe this statement on the host product due to the size, please describe in
the User's manual.

[for IC]

Contains Transmitter Module IC: 4908B-SDMAN

or

Contains IC: 4908B-SDMAN
