Siemens WM16S440AU Instructions

1 2 3 4 5 6
c:c- 90 °C Temp. Select the temperature (:= cold)
cc- 1600* rpm Select the spin speed (* depending on the model) or (Rinse hold = no final spin,
laundry remains in the water after the final rinse,--- appears in the display panel).
1 - 24 h Finish in Programme end after
Status indicators Programme status indicators:
ütüümüücü- ¯- Wash, rinse, spin, programme duration or end (- ¯-)
ür
Open the washing machine door, add laundry apage 4, 5
Programme selector Display panel /
Options buttons
Start/
Reload
Additional
functions
Sorting and loading the laundry
Follow the manufacturer's care information.
According to the information on the care labels.
According to type, colour, soiling and temperature.
Do not exceed the maximum load apage 7.
Observe the important information apage 9.
Insert items of laundry of varying sizes.
Close the washing machine door. Take care not to trap items of laundry between the washing
machine door and the rubber seal.
Adding detergent and care products
Measure accordingly:
The amount of laundry, level of soiling, water hardness (ask your water supply company) and
manufacturer's instructions.
On models without an insert for liquid detergent:
Pour liquid detergent into the appropriate dispenser and place in the drum.
During operation: open the detergent drawer with care.
Individual settings
ʑ
Signal
ʑ
Start/Reload
To start the programme or to subsequently load additional laundry, and to activate/deactivate the childlock.
2. Set the volume
for ...
Set to
1 step, the display panel lights up
Press and hold
+
1 step, release
Set to
skip
Button signals
Information signals
Set the volume*
1 step Set the
volume*
* you may need to select the function several times.
1. Activating the
mode for setting the signal volume
j
j
Insert for liquid detergent (depending on model), page 10
Compartment II: detergent for main wash,
water softener, bleach, stain remover
Your washing machine Intended use
Contents Page
ʔIntended use .......................................................................................................................... 1
ʔProgrammes .......................................................................................................................... 1
ʔSetting and adjusting the programme ............................................................................. 3
ʔWashing ..............................................................................................................................3/4
ʔAfter washing ........................................................................................................................ 4
ʔIndividual settings ............................................................................................................5/6
ʔOverview of programmes ................................................................................................... 7
ʔSafety instructions ................................................................................................................ 8
ʔConsumption values ............................................................................................................8
ʔImportant information .........................................................................................................9
ʔInsert for liquid detergent .................................................................................................10
ʔCare .......................................................................................................................................10
ʔInformation on the display panel ....................................................................................10
ʔInstructions for blockages ................................................................................................11
ʔWhat to do if.................................................................................................................. 12/13
ʔEmergency release .............................................................................................................13
ʔAfter-sales service ...............................................................................................................13
Protection of the environment/Conservation tips
– Always fill the washing machine with a maximum amount of laundry for
the relevant programme.
– Wash normally soiled laundry without a prewash. – Instead of Cottons/Coloureds 90 °C, select the Cottons/Coloureds 60 °C
programme and the additional jeco Perfect function. Comparable cleaning
result with significantly lower energy consumption.
– Measure the detergent according to the manufacturer's instructions and water
hardness.
– If you want to dry the laundry in the tumble dryer afterwards, select a spin speed
suggested by the dryer manufacturer
.
Preparation
Before washing for the first time
Run a wash cycle without any laundry apage 9
Set* and adjust the programme
1
2
Washing
Compartment ~: fabric softener, starch
Compartment I: detergent for prewash
ʔFor domestic use only
ʔFor washing machine-washable fabrics and hand-washable wool in
detergent solution
ʔTo be operated with cold drinking water and commercially available
detergents and care products which are suitable for use in washing machines.
– Do not leave children unattended near the washing machine. – The washing machine is not to be used by children or persons
not familiar with the operating instructions.
– Keep pets away from the washing machine.
Dilute thick fabric softener and conditioner with water. This prevents blockages.
Detergent drawer
with compartments I, II, ~
Control panel
Washing machine door handle
Service flap
Washing machine door
Install correctly, according to the separate installation instructions.
Check the machine
– Never use a damaged machine. – Inform the after-sales service.
Connect the mains plug
– Make sure your hands are dry. – Take hold of the plug only.
Turn the tap on
*If the s symbol is lit in the display
panel, Childlock active
a Deactivate it,
page 5.
Additional functions and options buttons
aIndividual settings, page 5
Press Start/Reload
Washing
End of programme when ...
... the Start/Reload button is off and - ¯- appears in the
display panel.
If the display panel lighting is off, press any button
a Energy-saving mode, page 5.
Cancel the programme
Programmes at high temperatures:
To cool the laundry: select Rinse. – Press Start/Reload.
Programmes at low temperatures:
Select Spin or Drain.Press Start/Reload.
Change the programme if...
... you have selected the wrong programme by mistake: – Reselect the programme. – Press Start/Reload. The new programme starts from the beginning.
Top up laundry, if ... a page 5
... Start/Reload is pressed and then both of the §+ rsymbols are
lit in the display panel. If ǯ is lit, the washing machine
door cannot be opened. Press the Start/Reload button.
Individual settings
ʑ
Options buttons
The spin speed and temperature can be changed before and during the selected programme. The effects depend on the programme progress.
ʑ
Temp. (Temperature)
You can change the displayed washing temperature. The maximum washing temperature that can be selected depends on the programme that has been set.
ʑ
rpm (Spin speed) / c(Rinse hold = no final spin)
You can change the spin speed shown or select c(Rinse hold = no final spin, laundry remains in the water after the
last rinse, --- appears in the display panel). You can change the spin speed shown. The maximum selectable spin
speed depends on the model and on which programme is currently selected.
ʑ
Finish in
When you select the programme, the relevant progr. duration is displayed. You can delay the start of the programme be­fore it begins. The "Finished in" time can be set in increments of one hour up to a max. of 24 hours. Press the Finish in button repeatedly until the desired number of hours is displayed (h = hour). Press Start/Reload.
ʑ
Additional functions a and overview of programmes, page 7
i speed Perfect For washing in a shorter time with a washing result comparable to that of the standard
programme. Maximum load aOverview of programmes, page 7.
jeco Perfect For saving energy with a washing performance comparable to that of the standard programme.
Easy Iron Special spin sequence with subsequent fluffing. Gentle final spin at reduced speed.
Residual moisture in the laundry is increased slightly.
Extra Rinse Additional rinse cycle. For areas with very soft water or for further enhancing the washing result.
ʑ
Childlock
s
in the display panel
You can lock the washing machine to prevent the functions you have set from being changed inadvertently.
ON/OFF: after the start/end of the programme, press and hold Start/Reload for approx. 5 seconds. Note: The childlock can remain activated until you wish to start the next programme, even after switching off the machine. Then you can deactivate the childlock before starting the programme and activate it again as necessary once the programme has started. Note:
The s symbolis lit: Childlock active.
The s symbolflashes: Childlock active and then the programme selector is altered.
To prevent the programme from stopping, move the programme selector back to the original
programme, the s symbol is lit again.
ʑ
Add laundry
§+ or
in the display panel
If you want to add additional items of laundry after the programme has started, press the Start/Reload button. The machine checks whether adding laundry is possible.
§+ r are lit: Adding laundry is possible.
ǯ
flashing: Wait until §+ r are lit.
Note: Only open the washing machine door when both the §+ r symbols are lit.
ǯ: It is not possible to add laundry.
Note: for safety reasons, the washing machine door remains locked when the water level and/or temperature is high, or during spinning.
To continue the programme, press the Start/Reload button.
ʑ
Energy saving mode
If the washing machine is switched on and is not operated for several minutes before the programme starts or at the end of the programme, the display panel light goes out and the Start/Reload button flashes.
Press any button to turn the light back on.
All buttons are sensitive and need only to be touched lightly. If you press and hold the Finish in option button, the appliance automatically runs through the settings options.
3
Programmes
Detailed overview of programmes apage 7.
Temperature and spin speed can be selected individually, depending on the selected programme and programme progress.
Cottons/Coloureds Hard-wearing fabrics
+ Prewash Hard-wearing fabrics, pre-wash at 30 °C Easy-Care Easy-care fabrics
+ Prewash Easy-care fabrics, pre-wash at 30 °C
Mixed Fabrics Different types of laundry Delicates/Silk Delicate washable fabrics
d Wool
Hand/machine-washable wool
Rinse Extra rinse with spin
Spin Extra spin with selectable spin speed
Drain Empty the rinsing water when c
(Rinse hold = no final spin) is activated
Low Spin Extra spin with reduced spin speed
Rapid 15' Super Quick programme Outdoor Fabrics All-weather, sportswear and outdoor wear
apage 9
Shirts/Blouses Non-iron shirts Dark Wash Dark-coloured fabrics
Switch off
Turn the programme selector to Off.
Turn off the tap
Not required for AquaStop models aRefer to Installation
instructions.
Remove the washing
Open the washing machine door and remove the washing.
If (Rinse hold = no final spin) active: turn the programme selector to
Drain or Spin. Select the spin speed if necessary. Press Start/Reload.
– Remove any foreign objects - risk of rusting. – Leave the washing machine door and detergent drawer open
so that any residual water can dry away.
Congratulations ä you have chosen a modern, high-quality domestic appliance
manufactured by Siemens. This washing machine is distinguished by its economical water and energy consumption.
Each machine that leaves our factory has been inspected thoroughly to ensure that it functions properly and is in perfect condition.
For more information on our products, accessories, replacement parts and services, see our website www.siemens-home.com or contact our after-sales service centres.
Programme selector for switching the machine on and off and for selecting the programme. Can be turned in either direction.
Drum interior light (depending on model) comes on when the door is opened or closed, or when a programme is started; goes out automatically.
7
Overview of programmes aCheck the consumption values table on page 8 and the instructions on page 9.
* reduced load when using the additional i speed Perfect function.
As a short programme, Mixed Fabrics 40 °C is ideal, when maximum spin speed is selected.
Programmes without prewash - add detergent to compartment II, programmes with prewash - distribute the detergent between compartments I and II.
Programmes °C max.
Type of laundry
Additional functions; options; information
Cottons/Coloureds
: - 90 °C
8 kg/
5 kg*
Hard-wearing fabrics, heat-resistant fabrics made of
cotton or linen
i speed Perfect*, jeco Perfect, Easy Iron, Extra Rinse;
c(Rinse hold = no final spin)
+ Prewash
Easy-Care
: - 60 °C
3.5 kg
Easy-care fabrics made of cotton, linen, synthetic fibres
or blended fabrics
i speed Perfect, jeco Perfect, Easy Iron, Extra Rinse;
c(Rinse hold = no final spin)
+ Prewash
Mixed Fabrics :c- 40 °C Fabrics made of cotton or easy-care fabrics
i speed Perfect, jeco Perfect, Easy Iron, Extra Rinse;
c(Rinse hold = no final spin);
different types of laundry can be washed together
Dark Wash :c- 40 °C
Dark-coloured fabrics made of cotton and dark easy-
care fabrics
i speed Perfect, jeco Perfect, Easy Iron, Extra Rinse;
c(Rinse hold = no final spin); reduced rinse and final spin
Delicates/Silk :c- 40 °C
2 kg
For delicate, washable fabrics, e.g. made of silk, satin,
synthetic fibres or blended fabrics (e.g. curtains)
i speed Perfect, jeco Perfect, Easy Iron, Extra Rinse;
c(Rinse hold = no final spin); no spin between the rinse cycles
d Wool
:c- 40 °C
Hand or machine-washable fabrics made of wool or
containing wool
c(Rinse hold = no final spin);
Particularly gentle wash programme to prevent shrinkage of laundry.
Longer programme breaks (fabrics rest in the detergent solution)
Rapid 15' :c- 40 °C
Easy-care fabrics made of cotton, linen, synthetic fibres
or blended fabrics
c(Rinse hold = no final spin); Short programme, approx. 15 minutes,
suitable for lightly soiled laundry
Shirts/Blouses :c- 40 °C
Non-iron shirts made of cotton, linen, synthetic fibres or
blended fabrics
i speed Perfect, jeco Perfect, Easy Iron, Extra Rinse;
c(Rinse hold = no final spin);
spin only briefly, then hang up to drip dry
Outdoor Fabrics :c- 40 °C
All-weather, sports and outdoor wear fabrics including
fabrics with weatherproof membrane
i speed Perfect, jeco Perfect, Extra Rinse;
reduced final spin in intervals
Additional programmes Rinse, Spin, Drain, Low Spin
0511 / 9000590152
*590152*
WM16S440AU
Siemens Electrogeräte GmbH
Carl-Wery-Str. 34
81739 München / Deutschland
8
Safety instructions
– Read the Instruction Manual and Installation Instructions and all other information enclosed with the washing
machine and act accordingly.
– Retain the documents for subsequent use.
Risk of electric shock – Never pull on the cable to disconnect the mains plug.
– Only insert/pull out the mains plug with dry hands.
Danger to life For worn-out appliances:
– Disconnect the mains plug. – Sever the mains cable and discard along with the plug. – Destroy the lock on the washing machine door. This will prevent children from
locking themselves in and risking their lives.
Danger of suffocation – Keep packaging, film and packaging parts out of the reach of children.
Risk of poisoning – Keep detergents and care products out of the reach of children.
Risk of explosion – Items of laundry pretreated with cleaning agents containing solvents, e.g. stain
remover/cleaning solvent may cause an explosion after being loaded into the washing machine. Rinse items of laundry thoroughly by hand beforehand.
Risk of injury – The washing machine door can become very hot.
– Be careful when emptying hot detergent solution. – Do not climb onto the washing machine. – Do not lean on the open washing machine door. – Do not reach into the drum if it is still rotating.
Consumption values
Programme Additional function Load Electricity*** Water***
Programme duration
***
Cottons/Coloureds 30 °C** 8 kg 0.35 kWh 76 l 2:20 h
Cottons/Coloureds 40 °C** 8 kg 0.97 kWh 76 l 2:30 h
Cottons/Coloureds 60 °C** 8 kg 1.36 kWh 76 l 2:40 h
Cottons/Coloureds 60 °C jeco Perfect* 8 kg 0.87 kWh 57 l 4:00 h
Cottons/Coloureds 90 °C 8 kg 2.34 kWh 87 l 2:30 h
Mixed Fabrics 40 °C** 3.5 kg 0.47 kWh 49 l 1:01 h
Easy-Care 40 °C** 3.5 kg 0.55 kWh 55 l 1:43 h
Delicates/Silk :c(cold) 2 kg 0.04 kWh 35 l 0:41 h
Delicates/Silk 30 °C 2 kg 0.14 kWh 35 l 0:41 h
dWool :c(cold)
2 kg 0.06 kWh 40 l 0:40 h
dWool 30 °C
2 kg 0.16 kWh 40 l 0:40 h
* Programme setting for testing and energy labelling in accordance with EU directive 92/75/EEC.
The Cottons/Coloureds 60°C + jeco Perfect, 1600 rpm programme is recommended for normal use.
** Programme setting for testing in accordance with applicable standard EN60456.
Note on comparative tests: When using the test programmes, wash the specified load using the maximum spin speed. As a short programme for coloureds, select the Mixed Fabrics 40 °C programme with maximum spin speed.
*** The values may deviate from the specified values depending on water pressure, water hardness, and inlet temperature,
ambient temperature, type, amount and level of laundry soiling, detergent used, fluctuations in the power supply and selection of additional functions.
9
Important information
Before washing for the first time
Do not put any laundry in the machine. Turn the tap on. Pour the following into compartment II: – approx. 1 litre water – detergent (amount to be used according to the manufacturer's instructions for light soiling and according to
water hardness)
Turn the programme selector to Easy-Care 60 °C and press Start/Reload. At the end of the programme, turn the programme selector to Off.
Protecting the laundry and the machine
– When measuring detergent, care products and cleaning agents, follow the manufacturer's instructions. – Empty pockets. – Look out for metal items (paperclips, etc.). – Wash delicates in a laundry bag (tights, curtains, underwired bras). – Fasten zips, do up any buttons. – Brush sand out of pockets and collars. – Remove curtain fittings or place in the laundry bag.
Loading laundry
Insert items of laundry of varying sizes. Take care not to trap items of laundry between the washing machine door and the rubber seal.
Laundry with varying degrees of soiling
Wash new items of clothing separately.
light Do not pre-wash. If required, select the additional ispeed Perfect function.
Pretreat any stains as necessary.
heavy Do not load as much laundry. Select the programme with Prewash.
Soaking Load laundry of the same colour.
Pour soaking agent/detergent into compartment II in accordance with the manufacturer's instructions. Turn the programme selector to Cottons/Coloureds 30 °C and press Start/Reload. After approx. 10 minutes, press Start/Reload to stop the programme. After the required soaking time, press Start/Reload again to continue the programme, or change the programme.
Starching Laundry must not be treated with fabric softener
Starching is possible in all wash programmes if liquid starch is used. Pour starch into the ~ fabric softener com-
partment in accordance with the manufacturer's instructions (rinse first if necessary).
Dyeing / bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel. Always follow the dye manufacturer's instructions. Do not use the washing machine for bleaching clothes.
Outdoor Fabrics Laundry must not be treated with fabric softener.
Special detergent suitable for machine washing is available particularly in sports shops. For dosage information, see the manufacturer's instructions. Special detergent for outdoor clothing in compartment II.
Turn the programme selector to Outdoor Fabrics. Select the temperature and Start/Reload.
10
Insert for liquid detergent model-dependent
Position the insert for dispensing liquid detergent: – Remove the detergent drawer completely
a
page 10.
– Slide the insert forwards. Do not use the insert (slide upwards): – For gel-type detergents and washing powder, – For programmes with + Prewash or Finish in option
Care
ʑ
Machine housing, control panel
– Remove detergent residue immediately. – Wipe with a soft, damp cloth. – Do not clean with a jet of water.
Cleaning the detergent drawer ...
... if it contains detergent or fabric softener residues.
1. Pull out, press insert down, remove drawer completely.
2. To remove the insert: press the insert upwards from below with your finger.
3. Clean the detergent dispenser tray and insert with water and a brush and dry it.
4. Fit the insert and engage (connect the cylinder to the guide pin).
5. Push in the detergent drawer.
Leave the detergent drawer open so that any residual water can evaporate.
ʑ
Drum
Leave the washing machine door open so that the drum can dry out. Use chlorine-free cleaning agent, not steel wool.
ʑ
Descaling Ensure there is no laundry in the machine
This should not be necessary if the correct detergent dosage has been used. If it is necessary, however, proceed according to the descaling agent manufacturer's instructions. Suitable descalers can be obtained via our website or from our after-sales service (
a
page 13).
Instructions in the display panel depending on model
rflashing Close the washing machine door properly; laundry may be caught.
§:³Å, ÉOpen the tap completely, supply hose kinked or trapped; Clean the filter
a
page 11,
water pressure too low.
§:³µDetergent solution pump blocked; Clean the detergent solution pump
a
page 11.
Drain hose/waste pipe blocked; Clean the drain hose at the siphon
a
page 11.
§: ´Water in the base tub, appliance leaking. Call the after-sales service.
Other displays Switch off the appliance, wait for 5 seconds and switch it back on. If the display appears again,
call the after-sales service
a
page 13.
Risk of electric shock. Disconnect the mains plug.Risk of explosion. No solvents.
11
Information about blockages
Detergent solution pump
Turn the programme selector to Off and disconnect the mains plug.
1. Open and remove the service flap.
2. Take the drain hose out of the retainer.
Remove the sealing cap, allow the detergent solution to flow out. Push the sealing cap back on.
3. Unscrew the pump cover carefully (residual water).
4. Clean the interior, pump cover thread and pump housing (the impeller in the detergent
solution pump must be able to rotate).
5. Replace the pump cover and screw it on tightly. The handle points upright. Replace the
drain hose in the holder.
6. Refit the service flap and close it.
To prevent unused detergent from flowing straight into the drain during the next wash: Pour 1 litre of water into compartment II and start the Drain programme.
Drain hose on the siphon
Turn the programme selector to Off and disconnect the mains plug.
1. Loosen the hose clamp, remove the drain hose carefully (residual water).
2. Clean the drain hose and siphon connecting piece.
3. Reattach the drain hose and secure the connection with the hose clamp.
Filter in the water supply
Risk of electric shock
Do not immerse the AquaStop safety device in water (contains electric valve).
Reduce the water pressure in the supply hose:
1. Turn off the tap.
2. Select any programme (except Spin / Drain).
3. Press Start/Reload. Let the programme run for approximately 40 seconds.
4. Turn the programme selector to Off. Disconnect the mains plug.
Clean the filter:
5. Disconnect the hose from the tap.
Clean the filter with a small brush.
and/or on standard and Aquasecure models: Remove the hose from the back of the appliance, Remove the filter using pliers and clean the filter.
6. Connect the hose and check for leaks.
Risk of scalding!
– Allow the detergent solution to cool down. – Turn off the tap.
12
What to do if...
ʑ
Water is leaking out. – Attach/replace the drain hose correctly.
– Tighten the screw connection of the supply hose.
ʑ
No water supply. Detergent not flushed into machine.
Start/Reload not pressed? – Tap not turned on? – Filter blocked? Clean the filter
a
page 11.
– Supply hose kinked or trapped?
ʑ
Washing machine door cannot be opened.
Safety function active. Programme stopped? apage 4.
(Rinse hold = no final spin) selected?
a
page 3, 4.
Can be opened by emergency release only?
a
page 13.
ʑ
Programme does not start. Start/Reload pressed or Finish in time selected?
– Washing machine door closed? – Childlock active? Deactivate
a
page 5.
ʑ
Detergent solution does not empty.
 (Rinse hold = no final spin) selected?
a
page 3, 4.
Clean the detergent solution pump
a
page 11.
– Clean the waste pipe and/or drain hose.
ʑ
Water not visible in the drum. – Not a fault - water below the visible area.
ʑ
Spin result not satisfactory. Laundry wet/too damp.
– Not a fault - the unbalanced-load detection system has interrupted the spin
because the laundry is unevenly distributed. Distribute large and small items of laundry evenly in the drum.
Easy Iron selected?
a
page 5.
Speed selected too low?
a
page 5.
ʑ
The programme duration changes during the washing cycle.
– Not a fault - the programme sequence is optimised for the relevant washing pro-
cess. This can cause changes in the programme duration in the display panel.
ʑ
Repeated spin start-up. – Not a fault - unbalanced-load detection system is adjusting the imbalance.
ʑ
Residual water in the ~ com-
partment for care products.
– Not a fault - the action of the care product is not affected. – Clean the insert if necessary
a
page 10.
ʑ
Odour formation in the washing machine.
– Run the Cottons/Coloureds 90 °C programme on the empty washing machine.
Use standard detergent.
ʑ
Status indicator³tflashing.
Detergent may escape from the detergent drawer.
– Too much detergent used?
Mix 1 tablespoon of fabric softener with ½ litre water and pour the mixture into compartment II. (Not for outdoor textiles or those made with down.)
– Reduce the detergent dosage for the next wash cycle.
ʑ
Pronounced generation of noise , vibration and “wandering” during the spin cycle.
– Are the appliance feet fixed?
Secure appliance feet
a
Installation instructions.
– Transportation safety devices removed?
Remove transportation safety devices
a
Installation instructions.
ʑ
Noises during spinning and emptying.
– Clean the detergent solution pump apage 11.
ʑ
Display panel/indicator lamps do not function during operation.
– Power cut? – Circuit breakers tripped? Switch the circuit breakers back on or replace. – Energy saving mode active? – If a fault occurs repeatedly, call the after-sales service.
ʑ
Programme sequence longer than usual.
– Not a fault - unbalanced-load detection system is adjusting the imbalance by
repeatedly redistributing the laundry.
– Not a fault - foam detection system active - adds an additional rinse cycle.
ʑ
There are detergent residues on the laundry.
– In isolated cases, phosphate-free detergents contain water-insoluble residues.
Select Rinse or brush down the laundry after washing.
13
What to do if...
ʑ
In Add laundry mode, Start/Relolad flashes very quickly and a signal sounds.
– Water level too high. Not possible to add more laundry. Close the washing
machine door immediately if necessary.
– Press Start/Reload to continue the programme.
If you cannot correct a fault yourself (switching on/off) or a repair is required:
Turn the programme selector to Off and pull the mains plug out of the socket.
Turn off the tap and call the after-sales service apage 13.
Emergency release e.g. in the event of a power cut
The programme continues when the power supply is restored. However, if the laundry has to be removed, the washing machine door can be opened as follows:
Risk of scalding
The detergent solution and laundry may be hot. If possible, leave to cool down. Do not reach into the drum if it is still rotating. Do not open the washing machine door if water can be seen through the glass.
1. Turn the programme selector to Off and pull out the mains plug.
2. Empty the detergent solution apage 11.
3. Pull the emergency release downwards with a tool and release.
Washing machine door can then be opened.
After-sales service
ʑ
If you cannot remedy the fault yourself (What to do if ..., apage 12, 13), contact our after-sales service. We will
always find a suitable solution to avoid unnecessary visits by repair personnel.
ʑ
The contact details of your nearest after-sales service can be found here or in the after-sales service directory (model-dependent).
ʑ
Please give the after-sales service the product number (E-Nr.) and the production number (FD) of the appliance.
Product number Production number
This information can be found: on the inside of the washing machine door* /
open service flap* and on the rear of the appliance. *depending on the model
ʑ
Trust the manufacturer's competence. Turn to us. By doing so, you will ensure that the repair is carried out by trained service technicians equipped with original spare parts
Instruction manual
Washing machine
Observe the safety instructions on page 8.
Do not operate this washing machine until you have read these instructions and the separate installation instructions.
en
1 2
c:c- 90 °C Temp. Select the temperature (:
cc- 1600* rpm Select the spin speed (* depending on the model) or
laundry remains in the water after the final rinse,
1 - 24 h Finish in Programme end after
Status indicators Programme status indicators:
ütüümüücü- ¯- Wash, rinse, spin, programme duration or end ( ¯
üsChildlock a
ür
Open the washing machine door, add laundry a
Programme selector Display panel /
Options buttons
Additional
functions
Close the washing machine door. Take care not to tr
Insert for liquid detergent (depending on model), page 10
Compartment II: detergent for main wash,
water softener, bleach, stain remover
Your washing machine Intended use
Contents Page
ʔIntended use .......................................................................................................................... 1
ʔProgrammes .......................................................................................................................... 1
ʔSetting and adjusting the programme ............................................................................. 3
ʔWashing ..............................................................................................................................3/4
ʔAfter washing ........................................................................................................................ 4
ʔIndividual settings ............................................................................................................5/6
ʔOverview of programmes ................................................................................................... 7
ʔSafety instructions ................................................................................................................ 8
ʔConsumption values ............................................................................................................ 8
ʔImportant information .........................................................................................................9
ʔInsert for liquid detergent .................................................................................................10
ʔCare .......................................................................................................................................10
ʔInformation on the display panel ....................................................................................10
ʔInstructions for blockages ................................................................................................11
ʔWhat to do if.................................................................................................................. 12/13
ʔEmergency release .............................................................................................................13
ʔAfter-sales service ...............................................................................................................13
Protection of the environment/Conservation tips
– Always fill the washing machine with a maximum amount of laundry for
the relevant programme.
– Wash normally soiled laundry without a prewash. – Instead of Cottons/Coloureds 90 °C, select the Cottons/Coloureds 60 °C
programme and the additional jeco Perfect function. Comparable cleaning
result with significantly lower energy consumption.
– Measure the detergent according to the manufacturer's instructions and water
hardness.
– If you want to dry the laundry in the tumble dryer afterwards, select a spin speed
suggested by the dryer manufacturer
.
Preparation
Compartment ~: fabric softener, starch
Compartment I: detergent for prewash
ʔFor domestic use only
ʔFor washing machine-washable fabrics and hand-washable wool in
detergent solution
ʔTo be operated with cold drinking water and commercially available
detergents and care products which are suitable for use in washing machines.
– Do not leave children unattended near the washing machine. – The washing machine is not to be used by children or persons
not familiar with the operating instructions.
– Keep pets away from the washing machine.
Install correctly, according to the separate installation instructions.
Check the machine
– Never use a damaged machine. – Inform the after-sales service.
Connect the mains plug
– Make sure your hands are dry. – Take hold of the plug only.
Turn the tap on
Programmes
Detailed overview of programmes apage 7.
Temperature and spin speed can be selected individually, depending on the selected programme and programme progress.
Cottons/Coloureds Hard-wearing fabrics
+ Prewash Hard-wearing fabrics, pre-wash at 30 °C Easy-Care Easy-care fabrics
+ Prewash Easy-care fabrics, pre-wash at 30 °C
Mixed Fabrics Different types of laundry Delicates/Silk Delicate washable fabrics
d Wool
Hand/machine-washable wool
Rinse Extra rinse with spin
Spin Extra spin with selectable spin speed
Drain Empty the rinsing water when c
(Rinse hold = no final spin) is activated
Low Spin Extra spin with reduced spin speed
Rapid 15' Super Quick programme Outdoor Fabrics All-weather, sportswear and outdoor wear
apage 9
Shirts/Blouses Non-iron shirts Dark Wash Dark-coloured fabrics
Congratulations ä you have chosen a modern, high-quality domestic appliance
manufactured by Siemens. This washing machine is distinguished by its economical water and energy consumption.
Each machine that leaves our factory has been inspected thoroughly to ensure that it functions properly and is in perfect condition.
For more information on our products, accessories, replacement parts and services, see our website www.siemens-home.com or contact our after-sales service centres.
Programme selector for switching the machine on and off and for selecting the programme. Can be turned in either direction.
Loading...
+ 7 hidden pages
