Siemens W786C Operating Instructions Manual
SCALANCE W786C
___________________
___________________
___________________
___________________
___________________
___________________
___________________
___________________
SIMATIC NET
Industrial Wireless LAN
SCALANCE W786C
Operating Instructions
10/2015
A5E03692138
Information on the Internet
1
Safety notes
2
Introduction
3
Description
4
Mounting
5
Connection
6
Technical data
7
Approvals
8
-07
Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E03692138-07
Ⓟ
Copyright © Siemens AG 2012 - 2015.
All rights reserved
Legal information
Warning notice system
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
Qualified Personnel
personnel qualified
Proper use of Siemens products
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
Disclaimer of Liability
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
The product/system described in this documentation may be operated only by
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Note the following:
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
for the specific
10/2015 Subject to change
Table of contents
1 Information on the Internet ...................................................................................................................... 5
2 Safety notes ............................................................................................................................................ 7
3 Introduction ............................................................................................................................................. 9
4 Description ............................................................................................................................................ 11
5 Mounting ............................................................................................................................................... 15
6 Connection ........................................................................................................................................... 31
7 Technical data ...................................................................................................................................... 55
2.1 General safety instructions for the SCALANCE W786C .......................................................... 7
3.1 Information on the Operating Instructions ................................................................................ 9
3.2 Structure of the type designations .......................................................................................... 10
4.1 Scope of delivery .................................................................................................................... 11
4.2 LED display ............................................................................................................................. 12
4.3 Reset button ............................................................................................................................ 13
5.1 Safety notes relating to installation ......................................................................................... 15
5.2 Removing / fitting the housing cover ....................................................................................... 16
5.3 Laying the cables .................................................................................................................... 18
5.4 Mounting without an adapter (wall mounting only) ................................................................. 20
5.5 Installation with mounting plate ............................................................................................... 22
5.5.1 Fitting the mounting plate to a wall ......................................................................................... 22
5.5.2 Screwing the cover plate for the cable feedthrough to the mounting plate ............................ 24
5.5.3 Fitting the mounting plate to an S7-300 standard rail ............................................................. 25
5.5.4 Fitting the mounting plate to a DIN rail ................................................................................... 26
5.5.5 Fitting the mounting plate to a mast ........................................................................................ 27
5.5.6 Fitting/removing the SCALANCE W786 to/from a mounting plate ......................................... 28
6.1 Lightning protection, power supply and grounding ................................................................. 31
6.2 Suitable cables for power supply and Ethernet ...................................................................... 36
6.3 Connecting the cables ............................................................................................................ 37
6.4 Connecting the power supply ................................................................................................. 40
6.5 Connecting a power supply adapter ....................................................................................... 42
6.6 Connecting to Industrial Ethernet ........................................................................................... 46
6.7 SFP/SFP+ transceiver ............................................................................................................ 47
6.8 Suitable antenna cables and antennas ................................................................................... 49
6.9 Connecting external antennas ................................................................................................ 52
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
3
Table of contents
8 Approvals ............................................................................................................................................. 63
Index .................................................................................................................................................... 65
7.1 Technical specifications (SCALANCE W786C-2) .................................................................. 55
7.2 Dimension drawing SCALANCE W786 ................................................................................. 58
7.3 Radiation patterns diagrams of SCALANCE W786 internal antennas .................................. 59
SCALANCE W786C
4 Operating Instructions, 10/2015, A5E03692138-07
1
Bitte beachten Sie die Warnhinweise und zusätzlichen Informationen in der
Kompaktbetriebsanleitung in Ihrer Sprache im Internet:
http://support.automation.siemens.com/ww/view/at/10806097
http://support.automation.siemens.com/ww/view/ch/10806097
http://support.automation.siemens.com/ww/view/de/10806097
http://support.automation.siemens.com/ww/view/li/10806097
http://support.automation.siemens.com/ww/view/lu/10806097
Please observe the warnings and additional information in the compact operating
instructions in your language in the Internet:
http://support.automation.siemens.com/ww/view/au/10806097
http://support.automation.siemens.com/ww/view/ca/10806097
http://support.automation.siemens.com/ww/view/gb/10806097
http://support.automation.siemens.com/ww/view/ie/10806097
http://support.automation.siemens.com/ww/view/us/10806097
http://support.automation.siemens.com/ww/view/za/10806097
Veuillez tenir compte des avertissements et informations supplémentaires de la notice de
service dans votre langue sur Internet:
http://support.automation.siemens.com/ww/view/be/10806097
http://support.automation.siemens.com/ww/view/ch/10806097
http://support.automation.siemens.com/ww/view/fr/10806097
http://support.automation.siemens.com/ww/view/lu/10806097
Si prega di tenere conto delle avvertenze e ulteriori informazioni nell’istruzione operativa
compatta nella relativa lingua in Internet:
http://support.automation.siemens.com/ww/view/it/10806097
Se ruega tener en cuenta las advertencias y las informaciones complementarias contenidas
en las instrucciones de servicio (resumen) en español en Internet:
http://support.automation.siemens.com/ww/view/cl/10806097
http://support.automation.siemens.com/ww/view/es/10806097
Dbejte prosím na výstražné pokyny a doplňkové informace v kompaktním návodu k obsluze
ve vašem jazyce na internetu:
http://support.automation.siemens.com/ww/view/cz/10806097
Vær venligst opmærksom på de advarselsanvisninger og ekstra informationer der findes på
dit sprog i kompaktdriftsvejledningen på internettet:
http://support.automation.siemens.com/ww/view/dk/10806097
Noudata lyhyen käyttöoppaan sisältämiä varoituksia ja huomio sen muutkin tiedot. Oman
kielisesi käyttöoppaan löydät internetistä osoitteesta:
http://support.automation.siemens.com/ww/view/fi/10806097
Λάβετε υπόψη τις υποδείξεις προειδοποίησης και τις πρόσθετες πληροφορίες των
συνοπτικών οδηγιών χρήσης που παρέχονται στη γλώσσα σας στο Διαδίκτυο:
http://support.automation.siemens.com/ww/view/gr/10806097
请注意互联网上精编版操作说明相应语言版本中的警告提示和附加信息：
http://support.automation.siemens.com/ww/view/cn/10806097
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
5
Information on the Internet
http://support.automation.siemens.com/ww/view/hk/10806097
http://support.automation.siemens.com/ww/view/sg/10806097
Kérjük, vegye figyelembe az interneten található, az Ön anyanyelvén íródott kompakt
használati útmutatóban található figyelmeztetéseket és további információkat:
http://support.automation.siemens.com/ww/view/hu/10806097
Skoðið vel viðvaranir og aðrar upplýsingar í notkunarleiðbeiningunum á ykkar tungumáli á
internetinu:
http://support.automation.siemens.com/ww/view/is/10806097
インターネットサイトにある各言語の注意事項および追加情報を参照してください:
http://support.automation.siemens.com/ww/view/jp/10806097
사이트에 있는 귀하의 언어로 된 콤팩트 사용 설명서에 명시된 경고 지침 및 추가 정보를
준수하십시오:
http://support.automation.siemens.com/ww/view/kr/10806097
http://support.automation.siemens.com/ww/view/kw/10806097
Neem goed nota van de waarschuwingen en extra informatie in de compacte
gebruiksaanwijzing in uw taal op internet:
http://support.automation.siemens.com/ww/view/be/10806097
http://support.automation.siemens.com/ww/view/nl/10806097
Vennligst følg advarslene og annen informasjon i den kompakte bruksanvisningen, som du
finner på ditt språk på internett:
http://support.automation.siemens.com/ww/view/no/10806097
Proszę zwrócić uwagę na ostrzeżenia oraz dodatkowe informacje w kompaktowej instrukcji
obsługi, dostępnej w odpowiednim języku w internecie:
http://support.automation.siemens.com/ww/view/po/10806097
Observera varningshänvisningarna och extrainformationerna i kompaktbruksanvisningen
som finns på ditt språk på internet:
http://support.automation.siemens.com/ww/view/se/10806097
İnternette kendi dilinizdeki kompakt işletim kılavuzunda yer alan uyarı notlarına ve ek
bilgilere lütfen dikkat edin:
http://support.automation.siemens.com/ww/view/tr/10806097
SCALANCE W786C
6 Operating Instructions, 10/2015, A5E03692138-07
2
2.1
General safety instructions for the SCALANCE W786C
WARNING
Danger from line voltage
Once you have removed the housing cover, there is the danger from line voltage in the
area of the connecting terminals on the power supply adapter.
Opening the device and all work performed on the open device (for example connecting
and disconnecting cables, pressing the reset button) must therefore only be performed by
electrical specialists!
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
7
Safety notes
2.1 General safety instructions for the SCALANCE W786C
SCALANCE W786C
8 Operating Instructions, 10/2015, A5E03692138-07
3
3.1
Information on the Operating Instructions
Validity of the Operating Instructions
Article number
SCALANCE W786C-2 RJ-45
6GK5 786-2FC00-1AA0
SCALANCE W786C-2IA RJ-45
6GK5 786-2HC00-1AA0
Operating instructions
Documentation on the accompanying CD
GS_SCALANCE-WLC711_76.pdf
Note
Make sure that you read the explanations and instructions in the README.txt file
These operating instructions cover the following products:
SCALANCE W786C-2 SFP 6GK5 786-2FE00-1AA0
If information relates to all the named products, the term SCALANCE W786 will be used.
These operating instructions apply to the following software version:
● SCALANCE W786C with firmware as of version 8.31
Based on the operating instructions, you will be able to install and connect up the
SCALANCE W786 correctly. Configuring the SCALANCE W786 and integration in a WLAN
are not dealt with in this manual.
You will find introductory information about configuration in the document "Getting Started
SCALANCE WLC711" on the accompanying SIMATIC NET IWLAN CD under the file name:
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
9
Introduction
3.2
Structure of the type designations
3.2 Structure of the type designations
The type designation of a SCALANCE W786 is made up of several parts that have the
following meaning:
SCALANCE W786C
10 Operating Instructions, 10/2015, A5E03692138-07
4
4.1
Scope of delivery
Note
The installation set with the mounting plate for attachment to an S7
rail or a mast does not ship with the product. You can obtain the installation set under the
following order number: 6GK5
The following components are supplied with the SCALANCE W786:
● SCALANCE W786
● 5 caps for the cover screws
● Depending on the version, up to 8 plugs for sealing the housing
● Depending on the version, up to 8 strain relief clamps
● Connector for the 24 VDC power supply
● SIMATIC NET Industrial Wireless LAN CD
-300 rail, a 35 mm DIN
798-8ML00-0AB3.
Please check that the consignment you have received is complete. If the consignment is
incomplete, contact your supplier or your local Siemens office.
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
11
Description
4.2
LED display
Information on operating status and data transfer
4.2 LED display
On the front of the housing, several LEDs provide information on the operating status of the
SCALANCE W786C-2:
Figure 4-1 LED display of the SCALANCE W786C-2. You will find information on the significance of
the individual elements in the documentation for the WLC700.
SCALANCE W786C
12 Operating Instructions, 10/2015, A5E03692138-07
Description
4.3
Reset button
WARNING
Danger from line voltage
Reset button
4.3 Reset button
After removing the housing cover, there is a risk of touching live parts in the area of the
connecting terminals of the power supply adapter.
Opening the device and all work performed on the open device (for example connecting
and disconnecting cables, pressing the reset button) must therefore only be performed by
electrical specialists!
The reset button is located below the housing cover beside on the right-hand side above the
cable feed:
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
Figure 4-2 Position of the reset button with the housing cover removed
13
Description
4.3 Reset button
SCALANCE W786C
14 Operating Instructions, 10/2015, A5E03692138-07
5
5.1
Safety notes relating to installation
CAUTION
Danger of injury by falling objects
CAUTION
Minimum distance to antennas
WARNING
If the SCALANCE W7x8 is subjected to strong vibration (> 10 g), mounting on a 35 mm DIN
rail does not provide adequate support. Under such conditions, the device can come out of
the mounting and may cause injury.
In this case, install the device on an S7-300 standard rail or on a wall.
Fit the device so that there is a minimum clearance of 20 cm between antennas and
persons.
If a device is operated in an ambient temperature of more than 40 °C, the temperature of
the device housing may be higher than 70 °C. The device must therefore be installed so
that it is only accessible to service personnel or users that are aware of the reason for
restricted access and the required safety measures at an ambient temperature higher than
40 °C.
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
15
Mounting
5.2
Removing / fitting the housing cover
When does the housing cover need to be removed?
Removing the housing cover
WARNING
Danger from line voltage
5.2 Removing / fitting the housing cover
You can only perform the following activities when the cover is removed.
● You want to screw the SCALANCE W786 to a wall or onto the optional mounting plate.
● You want to connect cables to the SCALANCE W786 for the power supply, for Ethernet
or for external antennas.
● You want to use the reset button.
After removing the housing cover, there is a risk of touching live parts in the area of the
connecting terminals of the power supply adapter.
Opening the device and all work performed on the open device (for example connecting
and disconnecting cables, pressing the reset button) must therefore only be performed by
electrical specialists!
SCALANCE W786C
16 Operating Instructions, 10/2015, A5E03692138-07
Mounting
A
B
C
Fitting the housing cover
5.2 Removing / fitting the housing cover
Figure 5-1 Removing the cover
Follow the steps below to remove the housing cover:
1. Remove the sealing caps from the housing cover (position
2. Loosen the screws in the cover (position
3. Remove the housing cover (position
Fitting the housing cover is carried out in the reverse order. Tightening torque for the cover
screws 1.8 Nm.
A Sealing cap
B Cover screw
C Housing cover
in the figure above).
in the figure above).
in the figure above)
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
17
Mounting
5.3
Laying the cables
Connecting up cables prior to mounting
5.3 Laying the cables
Before you screw a SCALANCE W786 to a wall or to the optional mounting plate, the cables
for the power supply, for Ethernet, and, when necessary, for the external antennas must be
connected up first. The available options are as follows:
Figure 5-2 Side view of a SCALANCE W786 with cables entering from different directions
● The cables are inserted from above (position A in the previous schematic). The housing
of the SCALANCE W786 has an opening at the top for this purpose.
● The cables are inserted from below (position B in the previous schematic). There is also
an opening at the bottom for this purpose.
● Cables inserted through a wall behind the SCALANCE W786 (position C in the previous
schematic). In this case, you will need to mount the SCALANCE W786 so that the
opening in the wall is located above the lower edge of the device.
SCALANCE W786C
18 Operating Instructions, 10/2015, A5E03692138-07
Mounting
Grounding terminal
WARNING
5.3 Laying the cables
To operate the SCALANCE W786 safely, the chassis ground connector must have a
suitable cable connected. Do not use the SCALANCE W786 without a ground cable
connected.
The chassis ground connector is located on the rear of the device (M4 thread). Connect the
ground cable before you mount the SCALANCE W786 on a wall or on the optional mounting
plate. Once the SCALANCE W786 is mounted, the connector is no longer accessible.
Place the supplied toothed washer directly on the rear of the device before screwing on the
ground cable. Only then can you be sure that there is ideal contact with the screwed-on
cable.
Figure 5-3 Chassis ground connector on the rear of the SCALANCE W786
SCALANCE W786C
Operating Instructions, 10/2015, A5E03692138-07
19
Mounting
5.4
Mounting without an adapter (wall mounting only)
Drilling template
Note
Installation location
The following shoul
•
•
5.4 Mounting without an adapter (wall mounting only)
d be noted with regard to the installation location:
Devices with an internal antenna must be aligned according to the characteristics of the
internal antenna (refer to the technical specifications of the antenna --> Radiation pattern
diagrams). Since the internal antennas are integrated in the housing, the location and
alignment of the housing decides the radiation direction of the antennas.
There are no restrictions relating to devices without internal antennas.
The location of the holes for mounting the SCALANCE W786 on a wall is shown in the
following figure:
SCALANCE W786C
20 Operating Instructions, 10/2015, A5E03692138-07
Figure 5-4 Drilling template for wall mounting of the SCALANCE W786
