Siemens TE503209RW User Manual

TE 503..

siemens-home.com/welcome

en Instruction manual fr Mode d’emploi pl Instrukcjaobsługi nl Gebruiksaanwijzing cs Návodkpoužití ru Инструкцияпоэксплуатации

Register your product online

e f

a

b

c

E-Nr. ……… FD… …

d

A

5

4

6

9

10

11

12

13

14

15

16

17

1 2 3

8 7

en ��2

fr ��22

pl ��43

nl ��66

cs ��87

ru ��107

Included in delivery (see page 2) Contenu de l’emballage (voir page 22) Zakres dostawy (patrz strona 43) Leveringsomvang (zie pagina 66)

Součást dodávky (viz strana 87) Объем поставки (voir page 107)

A

5

4

6

9

10

11

12

13

14

15

16

17

1 2 3

8 7

B

C D

6a

18

6b

8d

8c

6d6c6e

8b

1920

8e

8a

1.

2.

1.

E

5b

5f

5c

5a

5d

5e

en

Table of Contents

Included in delivery �� 2 Safety instructions ��3 Overview��5 Controls ��5 Display messages ��6 aromaDouble Shot��6

Before using for the rst time��7 Water lter ��8

Menu settings ��9 Adjusting the grinding unit ��10 Preparation using coffee beans ��10 Preparation using ground coffee �� 11 Dispensing hot water �� 11 Preparing milk froth and warm milk �� 11 Maintenance and daily cleaning ��12 Tips on energy saving ��15 Service Programmes ��15 Frost protection��18 Accessories ��18 Disposal ��19 Guarantee��19 Technical data��19 Simple troubleshooting �� 20

Dear Coffee Connoisseur, Congratulations on purchasing this fully automatic espresso machine from Siemens�

Please also note the enclosed quick reference guide� It can be kept in the special storage compartment (5c) until it is needed�

Included in delivery

(see overview image at the start of the instructions)

a Fully automatic espresso machine

TE503

b Quick reference guide c Instruction manual d Milk frother/Rotary selector e Water hardness testing strip f Measuring spoon

2

en

Safety instructions

Please read and follow the operating instructions carefully and keep them for later reference. Enclose these instructions when you give this appliance to someone else. This appliance is designed for the preparation of normal household quantities in the home, or in household-like, non-commercial environments. Household-like environments include staff kitchens in shops,

of ces, agricultural and other small businesses or for use by

guests at bed-and-breakfast establishments, small hotels and similar residential facilities.

¡ Danger of electric shock!

Connect and operate the appliance only according to the type plate

speci cations. To avoid potential hazards, repairs such as replacing

a damaged cable must only be carried out by our customer service personnel�

This appliance may be used by children aged 8 years and older and by persons with reduced physical, sensory or mental capabilities or who lack experience and/or knowledge if they are supervised or have been given instruction in the safe use of the appliance and have understood the dangers involved� Keep children under 8 years of age away from the appliance and connecting cable and do not allow them to use the appliance� Children shall not play with the appliance� Cleaning and user maintenance shall not be made by children unless they are older than 8 years and supervised�

Never immerse the appliance or mains cable in water� Use only if power cord and appliance show no signs of damage� Should a fault occur, pull the plug or disconnect from the mains immediately�

3

en

¡ Risk of suffocation!

Do not allow children to play with packaging material�

¡ Risk of scalding!

The milk frother outlet (6c) gets very hot� Milk froth or warm milk comes out of the milk frother (6) at high pressure� Splashes of milk can scald� Do not touch the outlet (6c) or aim it at anyone� After use,

allow to cool down rst before touching. Use this appliance only

after the milk frother (6) has been fully assembled and installed�

¡ Risk of injury!

Do not reach into the grinding unit�

4

en

Overview

(see overview images A, B, C, D and E at the beginning of this instruction manual)

1 Bean container 2 Aroma cover 3 Selector for grind setting 4 Drawer

(ground coffee / cleaning tablet)

5 Brewing unit (Fig. E)

a) Brewing unit b) Door c) Storage compartment for

quick reference guide

d) Eject lever for brewing unit e) Lock f) Cover

6 Milk frother (Fig. C) removable

a) Steam valve b) Air nozzle c) Outlet d) Rotary selector for

warm milk / milk froth

e) Milk tube 7 Coffee outlet, height-adjustable 8 Drip tray (Fig. D)

a) Drip tray panel

b) Coffee grounds container

c) Drip tray for coffee outlet

d) Grate for coffee outlet

e) Float 9 Power on/off switch O / I 10 start button 11 h button

12 e off / j button

13 “Coffee strength” rotary knob 14 “Drink selection” rotary knob 15 Display 16 Removable water tank 17 Lid for water tank 18 Measuring spoon

(insertion aid for water lter)

19 Storage compartment for

measuring spoon

20 Power cable with storage compartment

Controls

Power on/off switch O / I

The power switch O / I (9) is used to switch the appliance on or to switch it off fully (power supply off)�

Important: Before switching off, run the

cleaning programme or use the e off / j

button (12) to switch off�

e off / j button

When the e off / j button (12) is pressed

briey, the appliance rinses and switches

off� Pressing and holding down the e off / j

button (12) displays the user settings or starts the descaling and cleaning function�

h button

Press the h button (11) to generate steam for preparing milk froth or warm milk�

start button

Press the start button (10) to begin drink preparation or to start a service programme� Press the start button (10) again during drink preparation to cut the dispensing process short�

“Coffee strength” rotary knob

This rotary knob (13) is used to set the coffee strength�

h

to

g

Very mild Mild Normal Strong DoubleShot strong+ DoubleShot strong++

With these coffee strengths the coffee is brewed in 2 stages� See “aromaDouble Shot”�

5

en

“Drink selection” rotary knob

This rotary knob (14) is used to select the required drink and the per-cup quantity� It is also used to change user settings�

a

to

c

b

to

d

e

f

N.B.: If a drink is selected that cannot be prepared, the display� Change the coffee strength or the selected drink�

Milk frother

Pull the milk frother (6) out to open it and push it back in to close it�

Small Espresso Espresso Small Café Crème Café Crème Large Café Crème

2 small Espresso 2 Espresso 2 small Café Crème 2Café Crème 2 large Café Crème

Rinse machine

Rinse milk system

Invalid combination appears in

Rotary selector

To dispense milk froth – for example for a latte macchiato or cappuccino – turn the symbol to the front� To dispense warm milk, turn the to the front� To dispense hot water, set the rotary selector to the horizontal position�

i symbol

j

Display messages

The display (15) shows not only the current operating status, but also various messages that give you status information or let you know when you need to take action� As soon as you have taken the necessary action, the message disappears and the menu for drink selection is displayed again�

aromaDouble Shot

The longer the coffee is brewed, the more bitter substances and undesired aromas are released� This has a negative effect on the taste and makes the coffee less easily digestible� So for extra strong coffee the TE503 has a special aromaDouble Shot function� When half the quantity has been prepared, coffee is ground and brewed again so that only the pleasant, aromatic scents are released� The aromaDouble Shot function is activated with the following settings:

6

en

Before using for

the rst time

General

Fill the appropriate container using only pure, cold, uncarbonated water and only roasted beans (preferably espresso or coffee bean blends for fully automatic coffee machines)� Do not use coffee beans that have been glazed, caramelised or treated with other additives containing sugar, since they will block the brewing unit� The water hardness setting can be adjusted on this appliance� The factory default setting for the water hardness is 4� Check the water hardness with the enclosed test strip� If the check reveals a value other than 4, change the setting on the appliance accordingly after switching on (see “Menu settings”

Water hardness)�

Switching on the appliance

1� Remove the protective lm. 2� Place the fully automatic espresso

machine on a at, water-resistant

surface that can take its weight� Make

sure that the machine’s ventilation slots

remain unobstructured�

Important: Only use the appliance in frost-free rooms� If the appliance has been transported or stored at temperatures below 0 °C, wait at least 3 hours before operation�

3� Pull the power cord out of the storage

compartment (20) and plug in� Adjust

the length of the cable by pushing it

back in or pulling it out� The easiest way

to do this is to place the appliance so

that its back is ush with the edge of the

counter and either pull the cable down-

ward or push it upward�

4� Install the milk frother� Operate the

machine only after the milk frother (6) has been fully assembled and installed�

5� Lift the lid of the water tank (17)� 6� Remove and rinse the water tank (16)

and ll it with fresh cold water. Do not ll above the max mark�

7� Replace the water tank (16) and push it

rmly downward into place.

8� Close the lid of the water tank (17)

again�

9� Fill the bean container (1) with coffee

beans (for preparation using ground coffee, see “Preparation using ground coffee”)�

10� Press the power switch O / I (9)� The

display (15) shows the menu for setting the display language�

11� Select the required display language

with the upper rotary knob (14)� The following languages are available:

English Nederlands Français Italiano Svenska Español Polski Magyar Türkçe Dansk Norsk Suomi Português Čeština ελληνικα български русский

12� Press the start button (10)� The

language you selected is saved� The display shows Pull milk frother�

13� Place a receptacle under outlet (6c)� 14� Carefully pull out the milk frother (6) to

open it� The appliance rinses out the milk frother (6) with water� The display shows Push milk frother�

15� Push the milk frother (6) in to close it�

7

en

The appliance heats up and rinses� Some water will run out of the coffee outlet� When the drink selection menu is shown in the display, the appliance is ready for use�

Switching off the appliance

The factory settings of the fully automatic espresso machine are programmed for optimal performance� The appliance

switches off automatically after a specic

time (time span can be programmed, see “Menu settings” Shut off)�

Exception: The appliance switches off without rinsing if only hot water or steam were dispensed�

To switch the appliance off manually before this, press the appliance rinses and switches off�

N.B.: If the appliance is being used for the

rst time, a service program has been run,

or the appliance has not been operated

for a long period, the rst beverage will

not have the full aroma and should not be consumed�

When using the espresso machine for the

rst time, you will achieve a suitably thick and stable “crema” only after the rst few

cups have been dispensed�

After extended use, water droplets may form on the ventilation slots� This is normal�

e off / j button (12)� The

Water lter

A water lter can prevent scale buildup. Before a new water lter is used, it must be

rinsed� To do this, proceed as follows: 1� Press the water lter rmly into the

water tank with the aid of the measuring spoon (18)�

2� Fill the water tank (16) with water up to

the max mark�

3� Press and hold the

for at least three seconds� The menu opens�

4� Press the

edly until the display shows

e off / j button (12) repeat-

ﬁlter�

5� Select

6� Press the start button (10)� 7� Place a receptacle with a capacity of

8� Press the start button (10)� 9� Pull the milk frother (6) to open it� 10� Water will now ow through the lter to

11� Push the milk frother (6) in to close it� 12� Empty the container� The appliance is ready to use once more�

Activate ﬁlter with the upper

rotary knob (14)�

0�5 litres under the outlet (6c)�

rinse it�

e off / j button (12)

No / Old

Note: Rinsing the lter simultaneously

activates the setting for the display�

8

Change ﬁlter!

en

The lter is no longer effective when the

Change ﬁlter! display appears, or at

the latest after 2 months� It needs to be replaced for reasons of hygiene and so that there is no build-up of limescale (this could damage the appliance)�

Replacement lters can be obtained from

retailers or from customer service (see “Accessories”). If no new lter is used, turn the ﬁlter setting to No / Old�

Note: You can use the lter indicator to

mark the month in which you inserted the

lter. You can also mark the month in which you will need to replace the lter next (at

the latest after two months)�

Note: If the appliance has not been used for a prolonged period (e�g� vacation) the

lter should be rinsed before the appliance

is used again� To do so, dispense a cup of hot water and pour it away�

You can set the following:

Shut off

Here you can set the time span after which the appliance automatically switches off following the last drink preparation� A time between 15 minutes and 4 hours can be set� To save power you can specify a shorter period�

Filter

Here you can set whether a water lter is being used. If a water lter is not being

used, turn the setting to

water lter is being used, turn the setting to

No / Old� If a

Activate ﬁlter. New water lters have to

be rinsed before use (see “Water lter”).

Start Calc‘n‘Clean

The service programmes (Calc‘n‘Clean / descaling / cleaning) can be selected manually here� Press the start button (10) and run the selected programme (see “Service Programmes”)�

Temp.

The brewing temperature (high / middle /

low) can be set here�

Language

The display language can be set here�

Menu settings

You can adapt the appliance to your individual needs in the menu settings�

1� Hold the e off / j button (12) down for

at least 3 seconds�

2� Press the e off / j button (12)

repeatedly until the required menu item

appears in the display� 3� Select the required setting with the

upper rotary knob (14)� 4� Conrm by pressing the

start button (10)� To leave the menu without making any changes, turn the rotary selector to Exit and press the start button (10)�

Water hardness

The water hardness setting can be adjusted on this appliance� It is important to set the water hardness correctly, so that the appliance indicates accurately when the descaling programme should be run� The factory setting for the water hardness is 4� You can check the water hardness using the enclosed test strip or by asking your local water supplier�

9

en

Dip the test strip briey in water, gently

shake off any drips, and check the result after one minute�

Level Water hardness

German (°dH) French (°fH)

1 2 3 4

1-7 8-14 15-21 22-30

1-13 14-25 26-38 39-54

Adjusting the grinding unit

The rotary selector (3) adjusts the grind

settings from coarse to ne.

Warning!

A

Adjust the grinding unit only while it is running! Otherwise the appliance may be damaged� Do not reach into the grinding unit�

● While the grinding unit is running, adjust the rotary selector (3) from ne (a: Turn anticlockwise) to coarse (b: Turn clockwise) as required�

a b

Note: The new setting will not become

apparent until after the second cup of coffee�

Tip: For dark roast coffee beans, choose a

ner grind, for lighter beans a coarser grind.

Preparation using coffee beans

This fully automatic espresso machine grinds beans freshly for each brew�

Tip: If possible, use only beans for fully automatic coffee and espresso machines� For optimal quality, deep-freeze the beans or store in a cool place in sealed containers� Coffee beans can be ground while frozen�

Important: Fill the water tank (16) with fresh water every day� The tank (16) should

always contain sufcient water for operating

the appliance�

Different coffee drinks can be prepared quite simply at the press of a button�

Preparation

The appliance must be ready for use� 1� Place the pre-warmed cup(s) under the

coffee outlet (7)� Tip: For a small espresso, always preheat the cup, e�g� using hot water�

2� Select the required coffee and the

required per-cup quantity by turning the upper rotary knob (14)� The selected coffee and the per-cup quantity are shown in the display�

3� Select the required coffee strength by

turning the lower rotary knob (13)� The selected coffee strength is shown in the

display� 4� Press the start button (10)� Coffee is brewed and then poured into the cup(s)�

N.B.: With some settings the coffee is prepared in two stages (see “ aromaDouble Shot”)� Wait until the procedure is fully completed�

10

Press the start button (10) again to cut the brewing process short�

en

Preparation using ground coffee

This fully automatic espresso machine can also be operated with ground coffee (not instant coffee powder)�

N.B.: The aromaDouble Shot function cannot be used when coffee is prepared using ground coffee�

Important: Fill the water tank (16) with fresh water every day� The tank (16) should

always contain sufcient water for operating

the appliance�

Preparation

1� Open the drawer (4)� 2� Pour in no more than 2 level measuring

spoons of ground coffee� Warning: Do not use whole beans or

instant coffee� 3� Close the drawer (4)� 4� Select the required drink by turning the

upper rotary knob (14) (only one cup

possible)� 5� Press the start button (10)� Coffee is brewed and then poured into the cup�

N.B.: Repeat the procedure for another cup of coffee� If no coffee is taken within 90 seconds, the brewing chamber empties

automatically to avoid overlling. The

appliance rinses�

Dispensing hot water

Risk of burns!

A

The milk frother (6) gets very hot� Hold the milk frother (6) by the plastic part only�

The milk frother must be cleaned before drawing hot water� The appliance must be ready for use� 1� Place the pre-warmed cup or glass

under the outlet of the milk frother (6)�

2� Set the rotary selector (6d) to the

horizontal position�

3� Pull the milk frother (6) to open it� The

appliance heats up� Hot water runs out of the milk frother outlet (6) for about 40 seconds�

4� Stop the process by pushing in the milk

frother (6)�

Preparing milk froth and warm milk

Risk of burns!

A

The milk frother (6) gets very hot� Hold the milk frother (6) by the plastic part only�

Tip: You can foam the milk rst and then

dispense coffee, or foam the milk separately and pour it onto the coffee�

The appliance must be ready for use� 1� Place a pre-warmed cup under

outlet (6c)�

2� Insert the milk tube (6e) into a milk

container�

11

en

3� Turn the rotary selector (6d) to “Warm

milk” i or “Milk froth” j�

4� Press the h button (11)�

The h button (11) ashes and the

appliance now heats up for approx�

20 seconds� The display then shows

Pull milk frother�

5� Pull the milk frother (6) to open it�

Risk of burns!

A

Milk froth or warm milk comes out of the milk frother (6) at high pressure� Splashes of milk can scald� Do not touch the outlet (6a) or aim it at anyone�

6� Close milk frother (6) by pushing it in�

Tip: For optimal milk froth quality, use cold milk with a fat content of at least 1�5 % if possible�

Important: Dried milk residue is difcult

to remove, so the milk frother (6) must be cleaned with lukewarm water immediately after use and rinse using the Rinse milk

system programme�

Maintenance and daily cleaning

Risk of electric shock!

A

Unplug the appliance before cleaning it� Never immerse the appliance in water� Do not use a steam cleaner�

● Wipe the outside of the appliance with a

soft, damp cloth�

● Do not use abrasive cloths or cleaning

agents�

● Always remove any limescale, coffee, milk or descaling uid residue immediately� Such residue can cause corrosion�

● New sponge cloths may contain salts�

Salts can cause rust lm on stainless

steel and must therefore be washed out thoroughly before use�

● Pull the drip tray (8c) with the coffee grounds container (8b) forward and out� Remove the panel (8a) and the grate (8d)� Empty and clean the drip tray and coffee grounds container�

● Remove drawer (4) and clean�

12

en

● Remove the oat (8e) and clean with a

damp cloth�

Do not put the following items in the dishwasher: drip tray panel (8a),

O

oat (8e), drawer (4), brewing unit

(5a)� The following items are dishwashersafe: drip tray for coffee outlet (8c),

N

coffee grounds container (8b), grate for coffee outlet (8d), aroma cover (2) and measuring spoon (18)�

● Wipe out the inside of the appliance

(tray holders and drawer)�

Important: Drip tray for coffee outlet (8c) and coffee grounds container (8b) should be emptied and cleaned daily to prevent mould from developing�

N.B.: If the appliance is cold when switched on with the power switch O / I (9) or if it switches off automatically after coffee has been dispensed, it rinses automatically� In other words the system cleans itself�

Important: If the appliance has not been used for a prolonged period of time (e�g� after a vacation), clean the entire appliance thoroughly, including the milk system and brewing unit�

Cleaning the milk system

If the milk system was not cleaned after milk has been dispensed, after a certain amount of time the message Clean milk

system! will appear on the display�

Clean the milk system immediately after use! To clean, leave the rotary selector (6d) in the same position it was in when last used�

To pre-clean the milk system automatically:

1� Select f by turning the rotary knob (14)�

2� Place a tall, empty container under the

outlet (6c)�

3� Push the outlet as close as possible to

the container�

4� Place the end of the milk tube (6e) into

the container�

5� Press the start button (10)� 6� Pull the milk frother (6) to open it� The machine automatically releases water into the container and vacuums it up again via the milk tube (6e) to rinse the milk system� The rinse procedure stops automatically after about 1 minute� 7� Push the milk frother (6) in to close it� 8� Empty the container and clean the milk

tube (6e)�

In addition to this, clean the milk system thoroughly at regular intervals (by hand or in the dishwasher)�

Dismantling the milk system for cleaning: 1� Detach outlet (6c) from steam valve (6a)

(Fig. C)�

13

en

2� Clean the individual parts with a deter-

gent solution and a soft brush� If necessary, soak in a warm detergent solution�

3� Rinse all parts with clear water and dry

them�

4� Reassemble all the parts and replace

fully in the appliance�

Risk of scalding!

A

Use this appliance only after the milk frother (6) has been fully assembled and installed�

4� Press the eject lever (5d) down fully�

The brewing unit is released�

5� Grasp the brewing unit (5a) by the

recessed grips and remove carefully�

6� Remove the cover (5f) of the brewing

unit and rinse the brewing unit (5a) thoroughly under running water�

7� Thoroughly clean the brewing unit sieve

under the running water�

Cleaning the brewing unit

Clean the brewing unit regularly� To pre-clean the brewing unit automatically:

1� Select e by turning the rotary knob (14)�

2� Place an empty glass under outlet (7)� 3� Press the start button (10)� The appliance rinses�

In addition to the automatic cleaning programme, the brewing unit (5a) should be removed regularly for cleaning� (See gure E at the start of the operating instructions�) 1� Switch the appliance off at the power

on/off switch O / I (9)� No buttons are lit� 2� Open the door (5b) to the brewing unit� 3� Slide the red lock (5e) on the brewing

unit (5a) completely to the left�

14

Important: Do not clean with detergent or

other cleaning agents and do not put it in the dishwasher�

8� Wipe out the inside of the appliance

thoroughly with a damp cloth and remove any coffee residues�

9� Allow the brewing unit (5a) and the

inside of the appliance to dry�

10� Replace the cover (5f) on the brewing

unit and reinsert the brewing unit (5a)

fully into the appliance� 11� Press the eject lever (5d) up fully� 12� Slide the red lock (5e) fully to the right

and close the door (5b)�

Tips on energy saving

● Switch off the fully automatic espresso

machine when not in use� To do this,

press the e off / j (12) button� The

appliance rinses and switches off�

● If possible, do not interrupt coffee or

milk froth dispensing� Cutting the coffee or milk froth dispensing process short results in higher energy consumption and in more residual water collecting in the drip tray�

● Descale the appliance regularly to

avoid a build-up of limescale� Limescale residue results in higher energy consumption�

Service Programmes

Tip: Refer also to the quick reference guide

in the storage compartment (5c)�

Depending on usage, the following messages will appear on the display at certain intervals:

en

Warning!

A

Each time you run the service programme, you should follow the instructions for using the descaling and cleaning agents� Please observe the safety instructions on the packaging of the cleaning agent� Never interrupt the service programme! Do not drink the liquids! Never use vinegar, vinegar-based products, citric acid or citric acid-based products! Never put descaling tablets or other descaling agents in the ground coffee drawer or the drawer for cleaning tablets (4)!

Specially developed descaling and cleaning tablets are available from retailers or customer service (see “Accessories”).

Important: If there is a lter in the water

tank (16), it needs to be removed before the service programme is run�

Descaling

Duration: approx� 25 minutes

Descale required!

or

Clean required!

or

Calc‘n‘Clean required!

The appliance should be cleaned or descaled immediately using the corresponding programme� You also have the option of combining both processes with the Calc‘n‘Clean function (see “Calc‘n‘Clean“)� If the service programme is not run as instructed, the appliance may be damaged�

Important: If there is a lter in the water

tank (16), it needs to be removed before the descaling programme is run�

If the message Descale required! appears

on the display, press the e off / j button

(12) for 3 seconds and then press the start button (10)� The descaling programme will start� To descale the appliance before being

prompted, press the e off / j button (12) for at least 3 seconds� Then press the e off / j

button (12) briey twice. Turn the upper

rotary knob (14) until Start descaling appears in the display� To start the descaling procedure, press the start button (10)� The display will guide you through the programme�

15

en

Empty drip tray Insert drip tray

● Empty drip tray (8) and replace them�

N.B.: If the water lter is activated, the

display will prompt you to remove the

lter and then press the start button (10) again. Remove the lter now if you

have not already done so� Press the start button (10)�

Fill descaler Press start

● Pour lukewarm water into the empty

water tank (16) up to the 0.5 l mark and then dissolve 1 Siemens descaling tablet TZ80002 in it� When using TZ60002, 2 tablets must be dissolved�

● Press the start button (10)�

Descale in progress

The descaling pro gramme will now run for about 10 minutes�

Place container Pull milk frother

● Place a receptacle with a capacity of at

least 0�5 litres under the outlet (6c)�

● Pull the milk frother (6) to open it�

Descale in progress

The descaling pro gramme will now run for about 12 minutes�

Clean / Fill water tank Press start

● Rinse the water tank (16) and rell it

with fresh water up to the max mark�

● Press the start button (10)�

Descale in progress

The descaling pro gramme now runs for about 30 seconds and rinses the appliance�

Push milk frother

● Push the milk frother (6) in to close it�

Descale in progress

The descaling pro gramme now runs for about 1 minute�

Empty drip tray Insert drip tray

● Empty drip tray (8) and replace them�

Replace the lter if one is being used. The

appliance has completed descaling and is ready for use again�

Important: Wipe down the appliance using a soft, damp cloth to immediately remove any descaler residue� Such residue can cause corrosion� New sponge cloths may

contain salts. Salts can cause rust lm

on stainless steel and must therefore be washed out thoroughly before use�

Cleaning

Duration: approx� 10 minutes

Important: Clean the brewing unit before starting the service programme, see chapter “Cleaning the brewing unit”�

If the message Clean required! appears on the display, press the (12) for 3 seconds and then press the start button (10)� The cleaning programme will start� To clean the appliance before being

prompted, press the e off / j button (12) for

at least 3 seconds� Then press the

button (12) briey twice. Turn the upper

rotary knob (14) until Start cleaning appears in the display� To start the cleaning procedure, press the start button (10)� The display will guide you through the programme�

e off / j button

e off / j

Empty drip tray Insert drip tray

● Empty drip tray (8) and replace them�

16

en

Cleaning in progress

The appliance rinses twice�

Open drawer

● Open the drawer (4)�

Fill cleaner

● Drop a Siemens cleaning tablet in the

drawer (4) and close�

Cleaning in progress

The cleaning pro gramme will now run for about 8 minutes�

Empty drip tray Insert drip tray

● Empty drip tray (8) and replace them�

The appliance has nished cleaning is

ready for use again�

Calc‘n‘Clean

Duration: approx� 35 minutes

Calc‘n‘Clean combines the separate functions of descaling and cleaning� If both programmes are due to be run soon, the espresso machine automatically suggests this service programme�

Important: If there is a lter in the water

tank (16), it needs to be removed before the service programme is run� Clean the brewing unit before starting the service programme, see chapter “Cleaning the brewing unit”�

If the message Calc‘n‘Clean required!

appears on the display, press the e off / j

button (12) for 3 seconds and then press the start button (10)� The service programme will start� To run Calc‘n‘Clean before being prompted,

press the e off / j button (12) for at least

3 seconds�

Then press the e off / j button (12) briey

twice� Turn the upper rotary knob (14) until

Start Calc‘n‘Clean appears in the

display� To start Calc‘n‘Clean, press the start button (10)� The display will guide you through the programme�

Empty drip tray Insert drip tray

● Empty drip tray (8) and replace them�

Calc‘n‘Clean in progress

The appliance rinses twice�

Open drawer

● Open the drawer (4)�

Fill cleaner

● Drop a Siemens cleaning tablet in the

drawer (4) and close�

N.B.: If the water lter is activated, the

display will prompt you to remove the

lter and then press the start button (10) again. Remove the lter now if you

have not already done so� Press the start button (10)�

Fill descaler Press start

● Pour lukewarm water into the empty

water tank (16) up to the 0.5 l mark

and then dissolve 1 Siemens descaling

tablet TZ80002 in it� When using

TZ60002, 2 tablets must be dissolved�

● Press the start button (10)�

Calc‘n‘Clean in progress

The descaling pro gramme will now run for about 10 minutes�

Place container Pull milk frother

● Place a receptacle with a capacity of at

least 1 litre under the outlet (6c)�

● Pull the milk frother (6) to open it�

17

en

Calc‘n‘Clean in progress

The descaling pro gramme will now run for about 12 minutes�

Clean / Fill water tank Press start

● Rinse the water tank (16) and rell it

with fresh water up to the max mark�

● Press the start button (10)�

Calc‘n‘Clean in progress

The descaling pro gramme now runs for about 30 seconds and rinses the appliance�

Push milk frother

● Push the milk frother (6) in to close it�

Calc‘n‘Clean in progress

The cleaning pro gramme will now run for about 8 minutes�

Empty drip tray Insert drip tray

● Empty drip tray (8) and replace them� Replace the lter if one is being used. The appliance has nished cleaning is ready for

use again�

Important: Wipe down the appliance using a soft, damp cloth to immediately remove any descaler residue� Such residue can cause corrosion� New sponge cloths may

contain salts. Salts can cause rust lm

on stainless steel and must therefore be washed out thoroughly before use�

Frost protection

To avoid damage from low

A

temperatures during transport and storage, the appliance must be

completely emptied rst.

Note: The appliance must be ready for use

and the water tank (16) lled.

1� Place a large receptacle under outlet

(6c)�

2� Press the h button (11)�

The h button (11) ashes and the appliance now heats up for approx� 20 seconds� The display then shows

Pull milk frother�

3� Open the milk frother (6) by pulling

it out and release steam for about 15 seconds�

4� Switch the appliance off at the power

on/off switch O / I (9)�

5� Empty the water tank (16) and the

drip tray (8)�

Accessories

The following accessories can be obtained from retailers and customer service�

Accessories Ordering number

Retail / Customer service

Cleaning tablets TZ60001

00310575

Descaling tablets TZ80002

00576693

Water lter TZ70003

00575491

Care set TZ80004

00576330

Milk container with “Fresh Lock” lid

TZ80009N 00576166

18

en

Disposal

Dispose of packaging in an environmentally-friendly manner� This appliance is labelled in accordance with European Directive 2012/19/EG concerning used electrical and electronic appliances (waste electrical and electronic equipment – WEEE)� The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU� Please ask your specialist retailer about current disposal facilities�

A

Guarantee

The guarantee conditions for this appliance

are as dened by our representative in the

country in which it is sold� Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased� The bill of sale or receipt must be produced when making any claim under the terms of this guarantee�

Changes reserved�

Technical data

Power connection (voltage – frequency) 220-240 V – 50/60 Hz

Heater wattage 1600 W

Maximum static pump pressure 15 bar Maximum water tank capacity (without lter) 1�7 liters

Maximum capacity of the coffee bean container 300 grams

Length of power cable 100 cm

Dimensions (H x W x D) 385 x 280 x 479 mm

Weight, empty 9�3 kg

Type of grinding unit Ceramic

19

en

Simple troubleshooting

Problem Cause Solution

Display shows

Reﬁll beans!

although the bean container (1) is full, or the grinding unit does not grind the beans�

No hot water dispensed� The milk frother (6) is soiled� Clean the milk frother (6),

Too little or no milk froth or the milk frother (6) does not draw the milk in�

Coffee dispensing slows to a trickle or stops completely�

Coffee has no “crema”� Unsuitable type of coffee� Use a type of coffee with a higher

Coffee is too “acidic”� The grinding setting is too

Coffee is too “bitter”� The grinding setting is

Display shows

Beans are not falling into the grinding unit (beans too oily)�

The milk frother (6) is soiled� Clean the milk frother (6),

Milk unsuitable for frothing� Use low-fat milk (1�5 % fat)� The milk frother (6) is not

correctly assembled� Build-up of limescale in the

appliance�

Coffee is ground too nely.

Pre-ground coffee is too

ne.

Build-up of limescale in the appliance�

The beans are no longer fresh�

The grinding setting is not suitable for the beans�

coarse or the pre-ground coffee is too coarse�

Unsuitable type of coffee Use a darker roast�

too ne or the pre-ground coffee is too ne.

Unsuitable type of coffee� Change type of coffee used� The appliance has a fault� Please call the hotline�

Error Call hotline

If you are unable to solve the problem, always call the hotline!

You will nd the telephone numbers at the back of these instructions.

Gently tap the bean container (1)� Change the type of coffee if necessary� When the bean container (1) is empty, wipe it with a dry cloth�

see “Maintenance and daily cleaning”�

Wet the milk frother parts and

press together rmly.

Descale the appliance as described in the instructions�

Adjust the grinding unit to a coarser setting� Use coarser preground coffee�

Descale the appliance as described in the instructions�

proportion of robusta beans� Use fresh beans�

Adjust grinding setting to ne.

Adjust the grinding unit to a ner setting or use ner pre-ground

coffee�

Adjust the grinding unit to a coarser setting or use coarser pre-ground coffee�

20

Problem Cause Solution

The water lter does not

stay in position in the water tank (16)�

Display shows

Check water tank

The coffee grounds are not compact and are too wet�

Display shows

Clean brewing unit

Coffee or milk froth quality varies considerably�

Water dripped onto the

inner oor of the appliance

when the drip tray (8) was removed�

Display shows

Insert brewing unit

Restore the unit to its original factory settings (“Reset”)�

If you are unable to solve the problem, always call the hotline!

You will nd the telephone numbers at the back of these instructions.

The water lter is not

mounted correctly�

Water tank has been incorrectly inserted or the

new water lter has not

been rinsed according to instructions�

Carbonated water in the water tank�

The grinding setting is too

ne or too coarse, or not

enough ground coffee has been used�

Brewing unit (5) is soiled� Clean brewing unit (5)� Too much pre-ground

coffee in the brewing unit (5)�

The brewing unit’s mechanism is stiff�

Build-up of limescale in the appliance�

Drip tray (8) removed too early�

Brewing unit (5) is missing or was not recognised�

You changed some settings and want to discard them�

Firmly press the water lter

straight down into the tank connection�

Insert the water tank correctly or

rinse the water lter according to

instructions and then switch on�

Fill the water tank with fresh tap water�

Adjust the grinding unit to a

coarser or ner setting, or use

2 level measuring spoons of ground coffee�

Clean brewing unit (5)� Pour in no more than 2 level measuring spoons of ground coffee�

Remove and clean the brewing unit, see “Maintenance and daily cleaning”�

Descale the appliance as described in the instructions�

Wait a few seconds after the last drink was dispensed before removing the drip tray (8)�

Switch off the appliance with the brewing unit (5) in place, wait three seconds and switch on the appliance�

Turn off the unit with the power on/off switch O / I (9)� Press and hold the (11) button and turn the appliance on with the power on/off switch

O / I (9). Conrm by pressing

the start button start (10)� The factory settings are now activated�

e off / j (12) and the h

en

21

fr

Sommaire

Contenu de l’emballage �� 22 Consignes de sécurité �� 23 Présentation �� 25 Eléments de commande �� 25 Messages à l’écran �� 26 aromaDouble Shot �� 26 Avant la première utilisation �� 27 Filtre eau �� 28 Réglages menu �� 29 Régler la nesse de la mouture �� 30 Préparation avec du café en grains �� 31 Préparation à partir de café moulu �� 31 Préparer de l’eau chaude�� 32 Préparer de la mousse de lait et du lait chaud �� 32 Entretien et nettoyage quotidien �� 33 Conseils pour économiser l’énergie �� 35 Programmes de maintenance �� 36 Protection contre le gel �� 39 Accessoires �� 39 Mise au rebut �� 40 Garantie�� 40 Caractéristiques techniques �� 40 Eliminer soi-même les problèmes simples 41

Chère amatrice de café, cher amateur de café�

Félicitation pour avoir choisi la cafetière Siemens�

Veuillez également tenir compte du Mémento fourni� Un logement (5c) a été prévu pour le conserver à portée de main dans la machine�

Contenu de l’emballage

(voir l’illustration gurant au début du

présent Mode d’emploi)

a Machine à café TE503 b Mémento c Mode d’emploi d Mousseur lait/Sélecteur rotatif e Bandelette pour déterminer

la dureté de l’eau

f Cuillère-dose

22

fr

Consignes de sécurité

Lire attentivement ce mode d’emploi, s’y conformer lors de l’utilisation et le conserver ! Veuillez joindre ce mode d’emploi si vous passez l’appareil à quelqu’un d’autre. Cet appareil est conçu pour la préparation de quantités usuelles, dans le cadre d’un foyer ou d’un usage non commercial de type domestique. Citons p. ex. les cuisines du personnel dans les commerces, bureaux, exploitations agricoles et établissements artisanaux ainsi que les clients de pensions, petits hôtels et toute autre résidence de type similaire.

¡ Risque de chocs électriques !

Ne brancher et n’utiliser l’appareil que conformément aux données indiquées sur la plaque signalétique� Les réparations sur l’appareil telles que le remplacement d’un cordon endommagé ne doivent être

effectuées que par notre SAV a n d’éliminer tout danger.

Cet appareil peut être utilisé par des enfants à partir de 8 ans et par des personnes ayant des facultés physiques, sensorielles ou mentales réduites ou manquant d’expérience et/ou de connaissances à condition d’être surveillés ou d’avoir été informés quant à la bonne utilisation de l’appareil et d’avoir compris les dangers qui en découlent� Les enfants de moins de 8 ans doivent être tenus éloignés de l’appareil et du cordon d’alimentation et ne doivent pas utiliser l’appareil� Ne pas laisser les enfants jouer avec l’appareil� Le nettoyage et l’entretien incombant à l’utilisateur ne doivent pas être effectués par des enfants sauf s’ils ont 8 ans ou plus et sont surveillés�

23

fr

Ne jamais plonger l’appareil ou le cordon électrique dans l’eau� N’utiliser la machine que lorsque le cordon électrique et l’appareil ne présentent aucun dommage� En cas de défaut, débrancher

immédiatement la  che secteur ou couper la tension du réseau.

¡ Risque d’étouffement !

Ne pas laisser les enfants jouer avec les emballages�

¡ Risque de brûlure !

L’embout (6c) du mousseur de lait devient brûlant� De la mousse de lait ou du lait chaud s’écoule à haute pression du mousseur de lait (6)� Les éclaboussures de lait peuvent provoquer des brûlures� Ne pas toucher l’embout (6c) et ne pas le diriger vers une personne� Après utilisation, bien laisser refroidir la buse avant de la saisir� N’utilisez la machine que lorsque le mousseur de lait (6) est entièrement monté et installé�

¡ Risque de blessure !

Ne pas glisser les doigts à l’intérieur du broyeur�

24

fr

Présentation

(voir les illustrations de vue d’ensemble

A, B, C, D et E au début de la notice) 1 Bac à café 2 Couvercle préservateur d’arôme 3 Sélecteur de réglage

de nesse de mouture

4 Tiroir à café

(café en poudre/pastille de nettoyage)

5 Unité de percolation (gure E)

a) Unité de percolation b) Volet c) Logement du Mémento d) Levier d’éjection pour

l’unité de percolation

e) Verrouillage f) Couvercle de protection

6 Mousseur de lait amovible (gure C)

a) Buse vapeur b) Buse à air c) Embout d) Sélecteur rotatif

Lait chaud/Mousse de lait

e) Flexible Lait

7 Bec verseur du café,

réglable en hauteur

8 Bac collecteur (gure D)

a) Support des bacs collecteurs b) Récipient pour marc de café c) Bac collecteur du bec verseur du café d) Grille bec verseur du café

e) Flotteur 9 Interrupteur électrique O / I 10 Touche start 11 Touche h

12 Touche e off / j

13 Sélecteur rotatif « Arôme du café » 14 Sélecteur rotatif

« Sélection de la boisson »

15 Ecran 16 Réservoir d’eau amovible 17 Couvercle du réservoir d’eau 18 Cuillère-dose (sert de poignée pour

placer le ltre d’eau)

19 Logement de la cuillère-dose 20 Cordon électrique et logement

Eléments de commande

Interrupteur électrique O / I

L’interrupteur réseau O / I (9) permet de mettre en marche et d’arrêter entièrement la machine (alimentation électrique coupée)�

Important : Avant d’arrêter la machine, lancer un programme de rinçage ou bien

utiliser la touche e off / j (12)�

Touche e off / j

Appuyer brièvement sur la touche e off / j

(12) pour effectuer un rinçage et arrêter la machine� Appuyer de manière prolongée

sur la touche e off / j (12) pour afcher les

réglages utilisateur ou pour lancer un cycle de détartrage et de nettoyage�

Touche h

Appuyer sur la touche h (11) pour produire de la vapeur, nécessaire pour la production de mousse de lait ou de lait chaud�

Touche start

Appuyer sur la touche start (10) pour lancer la préparation d’une boisson ou pour effectuer un programme de Service� Pour réduire la quantité de boisson appuyer de nouveau sur la touche start (10) en cours de préparation�

Sélecteur rotatif « Arôme du café »

Le sélecteur rotatif (13) sert à régler l’arôme du café�

h

à

g

Très d o ux Doux Normal Fort DoubleShot fort + DoubleShot fort ++

Avec ces réglages de l’arôme, le café est préparé en 2 étapes� Voir point « aromaDouble Shot »�

25

fr

Sélecteur rotatif « Sélection de la boisson »

Le sélecteur (14) permet de sélectionner la boisson et la quantité� Il permet aussi

de modier les réglages de

l’utilisateur�

a

à

c

b

à

d

e

f

Remarque : Lorsqu’il est sélectionné une boisson impossible à préparer, l’écran

afche Combinaison non valide� Modi- er l’arôme du café ou la sélection de la

boisson�

Petit espresso Espresso Petit café crème Café crème Grand café crème

2 petits espressos 2 espressos 2 petits cafés crème 2 cafés crème 2 grands cafés crème

Rinçage machine

Rincer syst.de lait

Sélecteur rotatif

Pour prélever de la mousse de lait – par exemple pour préparer du Latte Macchiato ou un Cappuccino – tourner le symbole vers l’avant� Pour prélever du lait chaud, tourner le symbole Pour prélever de l’eau chaude, placer le sélecteur horizontalement�

i vers l’avant�

j

Messages à l’écran

En plus de l’état de fonctionnement actuel,

l’écran (15) afche également différents

messages qui correspondent à des informations d’état ou qui vous demandent d’intervenir� Dès que vous avez effectué l’opération nécessaire, le message disparaît et le menu de sélection des boissons

s’afche de nouveau.

Mousseur lait

Tirer le mousseur lait (6) pour ouvrir, le repousser pour fermer�

26

aromaDouble Shot

Plus la percolation du café dure longtemps, plus les substances amères et les arômes indésirables sont prononcés� Cela a un effet négatif sur le goût et rend le café moins digeste� La TE503 dispose donc d’une fonction spéciale, aromaDouble Shot pour préparer un café très fort� Une fois que la moitié de la quantité a été préparée, la machine moud de nouveau du café et effectue une percolation� Cela permet de ne développer que les arômes parfumés et très digestes du café�

Siemens TE503209RW User Manual [en, ru, fr, cs, pl]

Specifications and Main Features

Frequently Asked Questions

User Manual
