Page 1

Motion Control Information System

SINUMERIK 840D/840Di/810D/PCU50 on Windows and SINUMERIK 840D sl NC Program Management DNC

Function Manual · 04/2010

SINUMERIK

Page 2

Page 3

Motion Control Information System

SINUMERIK 840D/840Di/810D/PCU50 on Windows and SINUMERIK 840D sl NC Program Management DNC

DNC Plant / DNC Cell

Book 1

DNC IFC SINUMERIK

Book 2

Function Manual

Valid for

Controller SINUMERIK 840D powerline SINUMERIK 840Di SINUMERIK 840D sl SINUMERIK 810D powerline

Software Version

Motion Control Information System DNC 2.3

04/10 Edition

Appendix

Page 4

SINUMERIK® documentation

Printing history

Brief details of this edition and previous editions are listed below.

The status of each edition is shown by the code in the "Remarks" column.

Status codes in the "Remarks" columns:

A .... New documentation.

B .... Unrevised reprint with new order number.

C .... Revised edition with new status.

Release Order No. Remark

03/03 6FC5297-1AE80-0BP0 04/05 6FC5297-2AE80-0BP0 05/07 6FC5297-2AE80-0BP1 04/10 6FC5297-2AE80-0BP2

Registered trademarks

All designations with the trademark symbol ® are registered trademarks of Siemens AG. Other designations in this documentation may be trademarks whose use by third parties for their own purposes may infringe the rights of the owner.

Disclaimer of liability

We have checked that the contents of this document correspond to the hardware and software described. Nonetheless, differences might exist and therefore we cannot guarantee that they are completely identical. Nevertheless, the information contained in this document is reviewed regularly and any necessary changes will be included in subsequent editions.

A C C B

o. 6FC5297-2AE80-0BP2

Siemens AG Subject

2010.

to change without prior notice

Page 5

04/10 Preface

Preface

SINUMERIK documentation

The SINUMERIK documentation is organized in three parts:

 General documentation

 User documentation

 Manufacturer/service documentation

Information on the following topics is available at http://www.siemens.com/motioncontrol/docu

 Ordering documentation Here you can find an up-to-date overview of publications.

 Downloading documentation Links to more information for downloading files from Service & Support.

 Searching documentation online Information on DOConCD and direct access to the publications in DOConWEB.

 Individually compiling documentation on the basis of Siemens contents with the

My Documentation Manager (MDM), refer to http://www.siemens.com/mdm My Documentation Manager provides you with a range of features for generating your own machine documentation.

 Training and FAQs Information on our range of training courses and FAQs (frequently asked questions) is available via the page navigation.

Target group

Project engineers, technologists (of the machine manufacturers), commissioning engineers (for systems/machines), programmers.

Benefits

The Function Manual describes the functions so that the target group is familiar with and can select them. It provides the target group with the information required to implement the functions.
