Page 1

Safety

Integrated

Operating instructions

Low-voltage motor with encoder for safety-related applications

Edition

Supplement to the motor operating instructions

siemens.com/drives

SIMOTICS

02/2019

Page 2

Page 3

SIMOTICS

Low-voltage motor Functionally safe encoder

Supplement to the operating instructions for the motor

Introduction

Compact Operating Instructions

Safety instructions

Areas of application and ambient conditions

Marking for functional safety

Electrical connection

Commissioning

Service & support

Quality documents

02/2019

A5E44248729A

Page 4

Legal information Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific task in accordance with the relevant documentation, in particular its warning notices and safety instructions. Qualified personnel are those who, based on their training and experience, are capable of identifying risks and avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. The permissible ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this publication is reviewed regularly and any necessary corrections are included in subsequent editions.

Siemens AG Division Process Industries and Drives Postfach 48 48 90026 NÜRNBERG GERMANY

A5E44248729A Ⓟ 02/2019 Subject to change

Page 5

1 Introduction...................................................................................................................................................5

1.1 Additional languages................................................................................................................6

2 Safety instructions ........................................................................................................................................7

3 Areas of application and ambient conditions ................................................................................................9

4 Marking for functional safety.......................................................................................................................11

5 Electrical connection...................................................................................................................................13

5.1 Safety instructions relating to the electrical connection .........................................................13

5.2 Circuit diagram .......................................................................................................................13

6 Commissioning ...........................................................................................................................................15

6.1 Safety instructions for commissioning....................................................................................15

6.2 Checklist for commissioning...................................................................................................15

A Service & support .......................................................................................................................................17

B Quality documents......................................................................................................................................19

B.1 EU Declaration of Conformity for the encoder .......................................................................19

B.2 Quality documents for the SIMOTICS motors........................................................................19

B.2.1 SIMOTICS TN Series N-compact ..........................................................................................19

B.2.2 SIMOTICS FD ........................................................................................................................19

B.2.3 SIMOTICS SD/GP/DP............................................................................................................19

Index...........................................................................................................................................................21

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 3

Page 6

Table of contents

Functionally safe encoder

4 Compact Operating Instructions, 02/2019, A5E44248729A

Page 7

Introduction

These operating instructions apply to the functionally safe encoder (FSE) mounted on the SIMOTICS motor. The functionally safe encoder is also referred to in the operating instructions as an encoder. These operating instructions supplement the operating instructions for the following motor series:

● SIMOTICS FD

● SIMOTICS TN Series N-compact

● SIMOTICS SD/GP/DP

● SIMOTICS VSD10/VSD4000

These operating instructions are part of the motor delivery. Store the operating instructions near the motor. Please read the operating instructions prior to handling the motor and observe the information they contain. This will ensure safe and disturbance-free functioning.

Siemens AG does not accept any liability for damage and failures that result from the nonobservance of these operating instructions.

Functionally safe encoders

The following encoders can be mounted on the motor:

● Sendix SIL Kübler http://www.kuebler.com

● FSI 862 Leine&Linde http://www.leinelinde.com/

● HOGS 100S Baumer http://www.baumer.com

Operating instructions for the encoder

You can find the relevant technical specifications for the encoder and its operating instructions on the website of the respective manufacturer.

The operating instructions for the encoder contain the following:

● General information

● Encoder function

● Functional safety

● Data transfer

● Electrical installation

● Commissioning

● Technical specifications

Read and observe the operating instructions for the encoder.

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 5

Page 8

Introduction

1.1 Additional languages

You can find these instructions in other languages in SIOS (https://

support.industry.siemens.com/cs/ww/en/view/109756319).

Text format features

You can find the following text format features in these instructions:

1. Handling instructions are always formatted as a numbered list. Always perform the steps in the order given.

● Lists are formatted as bulleted lists.

– Lists on the second level are hyphenated.

Note

The note provides you with additional information about the product itself, handling the product

- and the relevant documentation.

Functionally safe encoder

6 Compact Operating Instructions, 02/2019, A5E44248729A

Page 9

Safety instructions

Siemens AG assumes responsibility for ensuring that the directives of functional safety have been observed for the motor with the encoder. The safety-relevant screw connections are sealed with marking paint before delivery. This will then indicate any inadvertent or unauthorized release of the screw connection.

No functional safety for incorrect use

If the information regarding correct use is not observed, the functional safety may be rendered ineffective.

● Carefully comply with the information provided regarding correct use.

● Changes made by users to the motor and/or the encoder negatively impact operational

reliability and are not permitted.

● The motor is intended for installation in a machine. The company operating the machine is

responsible for ensuring functional safety. The company operating the machine is responsible for the necessary safety functions and their attributes.

No functional safety for non-observance of the warning and safety instructions

If the warning and safety instructions are not observed, the functional safety may be rendered ineffective. The safety functions of the system are no longer ensured. This can result in death, serious injury or material damage.

● Please comply with valid regulations and operating instructions.

No functional safety without safety-relevant encoder evaluation

If the safety-relevant encoder evaluation is not implemented, the safety functions of the system are no longer ensured. This can result in death, serious injury or material damage. The encoder is only safety-relevant when used in conjunction with a suitable encoder evaluation unit.

● Use the encoder together with a safety-relevant encoder evaluation unit.

● Observe the operating instructions for the encoder.

No functional safety without conformity assessment

The motor is intended for installation in a machine. The operating company is responsible for defining the safety level and its actual implementation in the machine.

● Evaluate the conformity of the machine before commissioning.

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 7

Page 10

Safety instructions

Qualified personnel

Only Siemens service personnel or personnel trained and authorized by Siemens may carry out work on the encoder and the entire mounted components of the encoder. These include the torque arm, bolts and shaft journal, if present. Qualified personnel require knowledge of the following topics:

● Topics relating to functional safety

● Legislation, safety regulations and standards for functional safety

● Content of the associated operating instructions, manufacturing instructions and check lists for assembly and disassembly

Contact Technical Support for the following topics:

● Maintenance and service

● Faults and how to resolve them

● Disposal

Responsibility and liability

The responsibility and liability regarding the functional safety and its associated traceability is completely transferred over to the operating company:

● If the operating company damages the seal that was applied to safety-relevant screw connections by Siemens AG.

● If the operating company carries out work on the encoder and its mechanical connection.

Resonance effects in operation

Resonance effects can occur on the motor as a result of the frequency converter or comparable power controlling devices. As a result, the safety functions of the system are no longer ensured. This can result in death, serious injury or material damage.

● Optimize, for example, the controller parameters through an appropriate current setpoint filtering.

Damage

To ensure the system comprising the motor and the encoder is not damaged:

● Do not use the motor and the parts mounted onto it as a foothold or step.

● Do not place any objects on the motor.

● Position the motor in such a way that the encoder is not damaged.

Functionally safe encoder

8 Compact Operating Instructions, 02/2019, A5E44248729A

Page 11

Areas of application and ambient conditions

The encoder is suitable for the following areas of application and ambient conditions:

● Safety-relevant systems up to

– SIL2 / SIL3 acc. to EN 61800-5-2

– PLd / PLe acc. to EN ISO 13849-1 and EN ISO 13849-2

● Degrees of protection ≤ IP65

● Maximum ambient temperature of +40 °C, for simultaneous use of the motors according to

temperature class 155 (F) as a maximum.

● The encoder is designed in accordance with the maximum motor speed.

● Areas of application depending on the encoder

Area of application FSI 862 HOGS 100S Sendix SIL Use in hazardous areas No No No

Typical industrial environment, e.g. indoor in‐ stallation for conveyor technology

Conditionally in port installations Yes Yes Yes Harsh industrial environments, e.g. offshore

or the chemical industry Areas with direct exposure to seawater or

spraying seawater

Yes Yes Yes

Yes Yes No

Guidelines

● The encoder complies with the relevant standards listed in the Declaration of Conformity for

safety-related applications.

● Also take into account the applicable national and regional legislation, standards and

regulations.

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 9

Page 12

Areas of application and ambient conditions

Functionally safe encoder

10 Compact Operating Instructions, 02/2019, A5E44248729A

Page 13

Marking for functional safety

The SIMOTICS motor with functionally safe encoder has a signal yellow marking. The marking SI04 for the functionally safe encoder is stamped on the rating plate of the motor. The safety level is marked on the functionally safe encoder.

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 11

Page 14

Marking for functional safety

Functionally safe encoder

12 Compact Operating Instructions, 02/2019, A5E44248729A

Page 15

Electrical connection

5.1 Safety instructions relating to the electrical connection

Danger due to incorrect installation

If the encoder is electrically installed by inadequately qualified personnel, the functional safety may be rendered ineffective. The safety functions of the system are no longer ensured. This can result in death, serious injury or material damage.

● Only qualified personnel are permitted to work on the encoder.

Danger due to pre-existing damage to, or destruction of, the encoder

Electrostatic discharge can cause the encoder to fail. The safety functions of the system are no longer ensured. This can result in death, serious injury or material damage.

● Ensure that the ESD measures are observed.

Operating instructions for the encoder

Observe the operating instructions for the encoder.

5.2 Circuit diagram

● If the encoder is freely accessible, use the pin assignment specified in the operating

instructions for the encoder.

● If the encoder is not freely accessible: You can find the pin assignment for the encoder in the

terminal box or auxiliary terminal box on the circuit diagram provided in the terminal box.

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 13

Page 16

Electrical connection

5.2 Circuit diagram

Functionally safe encoder

14 Compact Operating Instructions, 02/2019, A5E44248729A

Page 17

Commissioning

6.1 Safety instructions for commissioning

Danger due to inadequately qualified personnel

● Only qualified personnel are permitted to mount or remove the encoder.

● Personnel require knowledge of the following topics:

– Topics relating to functional safety

– Legislation, safety regulations and standards for functional safety

– Content of the detailed operating instructions provided

Conformity

The encoder is intended for installation in a machine. Commissioning is prohibited until it has been established that the end product conforms with Directive 2006/42/EC.

Operating instructions for the encoder

Follow the encoder operating instructions when commissioning it.

6.2 Checklist for commissioning

Complete the checklist before commissioning the encoder.

WARNING

Danger to life if the functional safety is not guaranteed

It is possible that the functional safety is disabled if not all of the measures listed in the checklist are answered with "yes". The safety functions of the system are no longer ensured. This can result in death, serious injury or material damage.

● Only commission the motor and the encoder when all of the points have been answered with "Yes".

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 15

Page 18

Commissioning

6.2 Checklist for commissioning

Table 6-1 Checklist for commissioning the encoder

Encoder serial number on the type plate:

..........................................................................................................

Measure Yes No Is the signal yellow "Safety Integrated" marking present on the front cover and the

"SI04" marking on the rating plate? Is the motor free of damage? Are the operating instructions for the encoder available and have the correspond‐

ing specifications and instructions been observed? Has the motor been correctly assembled and designed so that the permissible

vibrations and shocks of the motor are not exceeded? Is the thermal motor protection evaluated, if available? Have qualified personnel connected the encoder to the encoder evaluation? Was a suitable, shielded connecting cable with twisted conductor pairs used? Were the connecting cables attached to the encoder without any strain, the cable

and connector installed and securely attached? Is the connecting cable shield connected at both ends through a large surface area

and grounded? Was it checked and ensured that the supply voltage has the correct level and

polarity? Check the encoder function: Do the direction of rotation and count direction on the

encoder match?

B.1 EU Declaration of Conformity for the encoder

The EU Declaration of Conformity for the encoder is provided with the motor, and is additionally in SIOS (https://support.industry.siemens.com/cs/ww/en/view/109756368), from where it can be downloaded.

Figure B-1 EU Declaration of Conformity in SIOS

B.2 Quality documents for the SIMOTICS motors

B.2.1 SIMOTICS TN Series N-compact

You can find the quality documents here (https://support.industry.siemens.com/cs/ww/en/ps/

13320/cert):

B.2.2 SIMOTICS FD

You can find the quality documents here (https://support.industry.siemens.com/cs/ww/en/ps/

13318/cert):

B.2.3 SIMOTICS SD/GP/DP

You can find the quality documents here (https://support.industry.siemens.com/cs/ww/en/ps/

13310/cert):

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 19

Page 22

Quality documents B.2 Quality documents for the SIMOTICS motors

Functionally safe encoder

20 Compact Operating Instructions, 02/2019, A5E44248729A

Page 23

Index

"Siemens Industry Online Support" App, 17

Ambient conditions, 9 Area of application, 9

Guidelines, 9

More information, 17

On-site service, 17

Safety level, 11 Siemens Industry Online Support

App, 17

Spare parts, 17

Technical Support, 17

Functionally safe encoder Compact Operating Instructions, 02/2019, A5E44248729A 21

Page 24

Index

Functionally safe encoder

22 Compact Operating Instructions, 02/2019, A5E44248729A

Page 25

Page 26

A5E44248729
