Siemens SFG75 User Manual

Issued by BenQ Mobile GmbH & Co. OHG Haidenauplatz 1 D-81667 Munich

www.siemens.com/sfg75

Designed for life

SFG75

Safety Information

For your safety, please read the guidelines below carefully before you use your phone:

Exposure to Radio Frequency Signals

Your wireless handheld portable telephone is a low power transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.

European and international agencies have set standards and recommendations for the protection of public exposure to RF electromagnetic energy.

• International Commission on Non-Ionizing Radiation Protection

(ICNIRP) 1996

• Verband Deutscher Elektroingenieure (VDE) DIN- 0848

• Directives of the European Community, Directorate General V in

Matters of Radio Frequency Electromagnetic Energy

• National Radiological Protection Board of the United Kingdom, GS 11,

1988

• American National Standards Institute (ANSI) IEEE. C95.1- 1992

• National Council on Radiation Protection and Measurements (NCRP).

Report 86

• Department of Health and Welfare Canada. Safety Code 6

These standards are based on extensive scientific review. For example, over 120 scientists, engineers and physicians from universities, government health agencies and industry reviewed the available body of research to develop the updated ANSI Standard.

The design of your phone complies with these standards when used normally.

Safety Information i

Specific Operating Restrictions

No metallic component allowed in body-worn accessories.

Antenna Care

Use only the supplied or approved replacement antenna. Unauthorized antennas, modifications or attachments may damage the phone and violate GCF regulations.

Phone Operation

• Normal Position: Hold the phone as you would with any other

telephone.

• To avoid potential RF interference, please do not wear the phone

around your neck or in front your chest for long hours.

Batteries

• For safety concerns, when the temperature of the phone goes over

45°C (113°F) or below 0°C (32°F), charging will halt.

• Do not expose batteries to temperatures below 0°C (32°F) or above

45°C (113°F). Always take your phone with you when you leave your vehicle.

• Use only genuine Benq battery to ensure the phone’s normal operation.

ii Safety Information

All batteries can cause property damage, injury or burns if a conductive material such as jewelry, keys or beaded chains touches exposed terminals. The material may complete electrical circuit and become quite hot. To protect against such unwanted current drain, exercise care in handling any charged battery, particularly when placing it inside your pocket, purse or other container with metal objects. When battery is detached from the phone, your batteries are packed with a protective battery cover; please use this cover for storing your batteries when not in use.

Driving

Check the laws and regulations on the use of wireless telephones in the areas where you drive. Always obey them. Also, if using your phone while driving, please:

• Give full attention to driving--driving safety is your first responsibility.

• Use hands-free operation, if available.

• Pull off the road and park before making or answering a call if driving

conditions so require.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of 20 cm/9 inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

Safety Information iii

Persons with pacemakers:

• Should ALWAYS keep the phone more than six inches from their

pacemaker when the phone is turned ON.

• Should not carry the phone in a breast pocket.

• Should use the ear opposite the pacemaker to minimize the potential

for interference.

If you have any reason to suspect that the interference is taking place, turn your phone OFF immediately.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference you may want to consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

Ve h i c l e s

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

iv Safety Information

Posted Facilities

Turn your phone OFF in any facility where posted notice so requires.

Aircraft

FCC regulations prohibit using your phone while in the air. Switch OFF your phone before boarding an aircraft.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a "blasting area" or in area posted "TURN OFF TWO-WAY RADIO." Obey all signs and instructions.

Potentially Explosive Atmospheres

Turn your phone OFF and do not remove the battery when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks, from your battery, in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always clearly marked. They include fueling areas such as gasoline stations; below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. DO NOT place objects, including both installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Safety Information v

European Union Directives Conformance Statement

This device complies with the OJ-Directive as below:

Electromagnetic Compatibility Directive (89/336/EEC), Low Voltage Directive (73/23/EEC)

And R&TTE Directive (99/05/EEC).

And also complies with the standard:

The declaration of conformity (DoC) concerned has been signed. Please call the company hotline if you require a copy of the original or:

www.siemens.com/mobiledocs

3GPP TS 51.010-1

EN 301 511

EN 50360/ EN 50361

ETSI EN 301 489-1/-7

EN 60950

ETSI EN 301 908-1 & ETSI EN 301 908-2 & ETSI EN 301 489-24 (WCDMA)

ETSI EN 300 328 & ETSI EN 301 489-17 (Bluetooth)

vi Safety Information

Safety precautions

Please read the operating instructions and safety precautions carefully before use. Explain the content and the hazards associated with using the phone to your children.

Remember to comply with legal requirements and local restrictions when using the phone. For example in aeroplanes, petrol stations, hospitals or while driving.

Mobile phones can interfere with the functioning of medical devices such as hearing aids or pacemakers. Keep at least 20 cm/9 inches between phone and pacemaker. When using the mobile phone hold it to the ear which is further away from the pacemaker. For more information consult your doctor.

Small parts such as the SIM card, sealing stop, lens ring and lens cap can be dismantled and swallowed by small children. The phone must therefore be stored out of the reach of small children.

Do not place the phone near to electromagnetic data carriers such as credit cards and floppy disks. Information stored on them could be lost.

Do not look at the LED (e.g. activated infrared port, flash LED) with optical magnifiers because of radiation.

This product complies with IEC/EN 60825-1 "Safety of Laser Products" for LED Class 1M products; such products are safe under reasonably foreseeable operating conditions.

Information for parents

Safety precautions vii

The mains voltage specified on the power supply unit (V) must not be exceeded. Otherwise the charging device may be destroyed.

The power supply must be plugged into an easily accessible AC mains power socket when charging the battery. The only way to turn off the charging device after charging the battery is to unplug it.

The ringtones, info tones and handsfree talking are reproduced through the loudspeaker. Do not hold the phone to your ear when it rings or when you have switched on the handsfree function. Otherwise you risk serious permanent damage to your hearing.

Only use original batteries (100 % mercury-free) and – charging devices. Otherwise you risk serious damage to health and property. The battery could explode, for instance.

You may only open the phone to replace the battery (100 % mercury-free) or SIM card. You must not open the battery under any circumstances. All other changes to this device are strictly prohibited and will invalidate the guarantee.

All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

This crossed-out wheeled bin symbol on the product means the product is covered by the European Directive 2002/96/EC.

The correct disposal and separate collection of your old appliance will help prevent potential negative consequences for the environment and human health. It is a precondition for reuse and recycling of used electrical and electronic equipment.

For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product.

viii Safety precautions

The phone may cause interference in the vicinity of TV sets, radios and PCs.

As mobile devices offer a range of functions, they can be used in positions other than the head, such as on the body. In this case, at

data transfer (GPRS) a separation distance of

1.5 cm is required.

Bluetooth

Your phone has a Bluetooth interface. This makes it possible to establish a wireless connection of your phone with a headset of a car kit, or with other Bluetooth-enabled devices.

In order to establish a secure link between the devices and to prevent a third party from having access to your phone, you should observe the following points:

• The initial connection between two devices, what is called "pairing",

should take place in familiar surroundings.

• Both devices must be able to identify themselves one time by using a

password/PIN. To ensure sufficient security, you should choose a 16digit number combination for a password that would be difficult to guess (if a PIN has not been assigned).

• An automatic connection acceptance ("connection without

confirmation") should only be used in exceptional cases.

• In general, only trustworthy devices should be linked in order to

minimize security risks.

• You should restrict the "visibility" of your phone if possible. This will

make it much more difficult for unknown devices to establish a connection with your phone.

Safety precautions ix

• The name of your phone is transmitted in a Bluetooth connection. The

factory default is the "Bluetooth ID". The first time Bluetooth is activated, or later in the Bluetooth menu, you can change this name.

• If Bluetooth is not needed, this function should be deactivated.

Before using Bluetooth accessories, or a mobile phone inside a vehicle, check the vehicle user guide for any limitations on the use of these products.

To ensure perfect operation of the phone, please only use the

phone with the keypad completely open or completely closed.

x Safety precautions

Table of Contents

Safety Information..............................................................i

Safety precautions............................................................vii

Bluetooth®...............................................................................ix

1. Preparing Your Phone For Use .....................................1

Inserting a SIM Card ...............................................................1

Installing the Battery................................................................3

Charging the Phone .................................................................4

Turning the Phone On ............................................................5

The miniSD Card.....................................................................6

2. Getting to Know Your Phone ........................................ 7

Your Phone at a Glance...........................................................7

Sub Display.............................................................................10

Idle Screen ..............................................................................10

Using the Keys in Idle Mode .................................................13

Menu Navigation ...................................................................15

3. Using Your Phone ........................................................16

Call Functions ........................................................................16

Making a Phone Call .................................................................16

Ending a Phone Call.................................................................. 16

Answering a Phone Call ............................................................16

Rejecting an Incoming Call.......................................................16

Adjusting the Volume ............................................................... 17

Making an International Call ...................................................17

Making an Emergency Call.......................................................17

Table of Contents xi

Dialing an Extension Number..................................................17

Listening to Voicemails.............................................................18

Operations During a Call.......................................................... 18

Making a Video Call.................................................................. 22

Answering a Video Call............................................................. 23

Video Call Settings ....................................................................23

Options During a Video Call....................................................24

Phone Book............................................................................26

Adding Contacts to the Phone Book........................................ 26

Finding Contacts in the Phone Book .......................................28

Last Missed, Dialed, and Received Calls...............................28

Using the Silent Profile..........................................................29

Camera ...................................................................................30

Taking Pictures..........................................................................30

Camera Settings......................................................................... 31

More Camera Settings............................................................... 31

Managing Your Pictures ...........................................................32

Camcorder..............................................................................33

Shooting a Video Clip ...............................................................33

Camcorder Settings ................................................................... 34

More Camcorder Settings.........................................................34

Managing Your Videos .............................................................35

MP3 Player .............................................................................35

Building a play list .....................................................................35

Playing the music ......................................................................36

Uploading music to your phone...............................................36

xii Table of Contents

Messages .................................................................................37

SMS ............................................................................................37

MMS...........................................................................................40

E-Mail ........................................................................................43

Voicemail ...................................................................................44

Broadcast....................................................................................45

Input Modes...........................................................................46

Letter Input Mode (Abc) ..........................................................46

Predictive Input Mode (iTap) ..................................................47

Numeric Input Mode (123)......................................................48

Symbol Input Mode ..................................................................48

Using the Bluetooth...............................................................48

Establishing Connection with Your Bluetooth Headset .........48

Organizing your Devices........................................................... 49

PC Synchronization and Data Transfer................................50

4. Menus............................................................................ 51

Phone Book............................................................................51

List..............................................................................................51

Find ............................................................................................51

Add.............................................................................................51

Copy ...........................................................................................52

Delete .........................................................................................52

Caller Group ..............................................................................52

Own Number.............................................................................52

Memory......................................................................................52

Messages .................................................................................53

Table of Contents xiii

Calls ........................................................................................53

Missed ........................................................................................53

Received .....................................................................................53

Dialed .........................................................................................53

Cleanup All ................................................................................53

Display .......................................................................................54

Duration and Cost..................................................................... 54

Games .....................................................................................54

Settings.......................................................................................55

Entertainment ........................................................................55

Camera.......................................................................................55

Camcorder ................................................................................. 55

MP3 Player.................................................................................55

Media Center..........................................................................56

Images ........................................................................................56

Videos.........................................................................................57

Music.......................................................................................... 58

Others.........................................................................................58

Tools .......................................................................................59

Alarm .........................................................................................59

Clock Options............................................................................ 60

Calendar..................................................................................... 60

Calculator...................................................................................61

Currency Converter ..................................................................61

Stopwatch ..................................................................................62

Countdown Timer.....................................................................62

Connections............................................................................... 62

xiv Table of Contents

Services ...................................................................................63

WAP Browser ............................................................................63

WAP Messages........................................................................... 64

WAP Settings .............................................................................64

STK............................................................................................. 64

Settings ...................................................................................65

Date & Time ..............................................................................65

Profiles .......................................................................................65

Display .......................................................................................67

Call Settings ...............................................................................68

Network .....................................................................................72

Security ......................................................................................73

Power Saving .............................................................................74

Language ....................................................................................74

Power On/Off Sound ................................................................74

Memory......................................................................................74

Restore .......................................................................................74

5. Care and Maintenance ................................................. 75

Battery quality statement.......................................................76

Display quality declaration....................................................76

6. Troubleshooting........................................................... 77

7. Customer Care ............................................................. 81

8. SAR................................................................................ 85

European Union (RTTE) and international (ICNIRP).......85

Table of Contents xv

9. Guarantee certificate (UK) ..........................................87

10. Guarantee certificate (IRL)........................................ 89

11. End User License Agreement (EULA) ....................... 92

xvi Table of Contents

Preparing Your Phone For Use

Inserting a SIM Card

$Please note:

• In this user manual, "SIM card" implies either a SIM or an USIM card,

unless it is specifically specified as "USIM card".

• To use your mobile phone in the UMTS network, you will need to have a

USIM card. See page 72, "3G/GSM Networks" to find out more about selecting the correct network mode for use.

1. Turn the phone over, and release the battery latch. Lift the battery off the phone.

Battery latch

Do not remove the battery when the phone is on. Doing so could cause you to lose personal settings or data stored either on your SIM

card or in the phone's memory.

Preparing Your Phone For Use 1

2. Slide the SIM card into the SIM card slot, with the SIM card's metal contacts facing downwards and the cut corner at the bottom left.

SIM card

A SIM card can be easily damaged if its metal contacts become

scratched. Therefore, take special care when holding or inserting it.

$To remove the SIM card, you must first press down the stay, then push

the SIM card out of the slot.

Stay

SIM card

2 Preparing Your Phone For Use

Installing the Battery

With the battery's metal contacts facing downwards, align the protruding tabs on the end with the holes in the battery bay. Then push the battery toward the end of the bay to insert the battery's tabs into the holes. Press down to click the battery into place.

Do not remove the battery when the phone is on. Doing so could cause you to lose personal settings or data stored either on your

SIM card or in the phone's memory.

Preparing Your Phone For Use 3

Charging the Phone

1. Insert the charger connector deep into the charger socket at the bottom of your phone. Ensure that the connector is plugged in the right direction with the side showing arrow icon or "up" facing upwards.

2. Plug the charger into a power outlet.

Do not remove the battery while the phone is charging.

3. Once the phone is fully charged, remove the charger from both the power outlet and the phone.

$Please note:

• It takes approximately 4 hours to fully charge a battery.

• When the battery is weak, the phone will play an alert sound.

• When the battery is discharged, the charging may not start immediately

when you plug in the connector. Wait 10 to 15 minutes for the phone to begin charging.

4 Preparing Your Phone For Use

Turning the Phone On

1. Press and hold B to turn the phone on. The phone will display the

welcome animation.

2. Enter your PIN code and press

K to confirm.

$The PIN (Personal Identification Number) is the password provided

by your network operator. You need this password in order to use the SIM card.

If you enter the PIN incorrectly three times in a row, the SIM card will be locked. You must now enter the PUK (Personal Unblocking Key)

for that SIM card in order to unlock it. Please contact your network operator to obtain a PUK.

$To activate/disable PIN password authentication, go to Settings >

Security > PIN Code > PIN1 Code > Settings. See page 73.

3. When the PIN code entered has been accepted, the phone will automatically search for the designated network. This search process may take a few seconds.

4. The idle screen will be displayed, as well as network signal strength and the name of the network operator. You can now use the phone.

$If the phone is not able to detect the designated network, or links to a

network that you are not authorized to use, the signal strength meter will show no bars. You will only be able to make emergency calls.

Preparing Your Phone For Use 5

The miniSD Card

Your phone features a miniSD slot designed specifically for use with the miniSD card, a removable flash memory card intended to add greater storage capacity to your phone.

The miniSD card enables you to store multimedia data such as images, photos, MP3 audio files, ring tones, and videos.

Installing the miniSD Card

1. Lift the cover.

2. Insert the miniSD Card into the slot. Ensure that the card's metal contacts face downwards.

3. Close the cover.

$Your phone does not support a miniSD card which is on FAT32 or

NTFS format.

Removing the miniSD Card

1. Lift the cover.

2. Press the miniSD card to release it.

6 Preparing Your Phone For Use

Getting to Know Your Phone

Your Phone at a Glance

Front and side views

To view what is behind the rubber cover, lift the cover and twist it to the left.

sub display

Antenna

Front Camera

Camera flash

Charger socket

Rubber cover

IrDA port

miniSD slot

Hands-free headset /

Data cable jack

Getting to Know Your Phone 7

Side and back views

Battery latch

Battery

Speaker

Camera hot key

Volume ke y

8 Getting to Know Your Phone

Front open view

Earpiece

Near Camera

OK key

Left soft key

Video call hot key

Dial/Answer key

WAP k ey

Main Display

Navigation key

Right soft key

Clear key

Power on/of f ke y

Alphanumeric keys

Microphone

Getting to Know Your Phone 9

Sub Display

When the flip is closed, the sub display's status bar will show icons for network strength, battery power, the current time and the current profile in use. The sub display will also alert you to incoming calls, new messages and missed calls.

Idle Screen

Status bar

• To set the wallpaper of the display, go to Settings > Display >

Wallpaper. Alternatively, you can go to Media Center > Images.

See page 56 and page 67.

• To set the current time and date, as well as the format to be

shown, go to

Settings > Date & Time. See page 65.

Name of network operator

Press > to enter the

indicated function

Press K to enter the main

menu.

Press < to enter the

indicated function.

10 Getting to Know Your Phone

Icons in the Status Bar

Icon Function Description

Signal strength

Battery status

GPRS in use Appears when GPRS has been activated.

3G in use Appears when 3G has been activated.

GPRS

Connection

3G Connection

Bluetooth Appears when Bluetooth is turned on.

SMS Message

MMS Message

WAP message

E-mail

Signal strength of the network. The more bars indicated, the stronger the signal.

Shows the current level of battery power. The more bars indicated, the more power remains.

Appears when the phone is connecting to a GPRS network.

Appears when the phone is connecting to a 3G network.

Appears when you have new or unread SMS messages.

Appears in red when your SMS messages are full.

Appears when you have new or unread MMS messages.

Appears in red when your MMS messages are full.

Appears when you have new or unread WAP messages.

Appears when you have new or unread email messages.

Appears in red when your e-mails are full.

Getting to Know Your Phone 11

Icon Function Description

Appears when you have new voicemail

Voicemail

Alarm Appears when the alarm is turned on.

messages (this icon will only appear if the function is supported by your network operator).

Normal

Flight Mode

Headset

Meeting

Silent

Outdoors

Divert Appears when the call divert is activated.

Roaming

Shows that the

Appears when the

Appears when a headset is connected to the phone.

Shows that the

Shows that the Outdoors profile is

activated.

Roaming is activated (not your regular network).

12 Getting to Know Your Phone

Normal profile is activated.

Flight profile is activated.

Meeting profile is activated.

Silent profile is activated.

Using the Keys in Idle Mode

In this user manual, "long-press" means to press and hold down a key

for about two seconds. "Press" means to press a key and release immediately.

Key Commands and functions

Power On/off key

• Long-press to turn the phone on or off.

• Press this key to end a call, reject an incoming call, or

to cancel a dialing.

Send/Answer key

• Press to send or answer a call.

• Press to access the call record list.

Left soft key

• Press to perform the function indicated on the display.

Right soft key

• Press to perform the function indicated on the display.

• Long-press to turn the silent profile on or off.

OK key

• Press to open up the main menu.

Getting to Know Your Phone 13

+ 84 hidden pages
