Siemens MPCIE1V1 User Manual

MPCIE-R1-ABGN-U3 PCIe WLAN Radio Card
Preliminary Data Sheet V0.1
FCC-ID: LYHMPCIE1V1
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 1 von 21
Contents
1 OVERVIEW ............................................................................................................................................... 3
1.1 FEATURE LIST .................................................................................................................................................... 3
2 SPECIFICATIONS..................................................................................................................................... 4
2.1 MECHANICAL SPECIFICATIONS .......................................................................................................................... 6
2.2 ELECTRICAL SPECIFICATIONS ............................................................................................................................ 8
3 LABEL..................................................................................................................................................... 17
4 FCC AND IC NOTES .............................................................................................................................. 18
5 ORDERING INFORMATION................................................................................................................... 21
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 2 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc

1 Overview

The Siemens MPCIE-R1-ABGN-U3 PCI-e Minicard is an Dual-Band (2.4GHz and 5GHz) PCI-e
Minicard, based on the Atheros AR9390 chipset. It supports 3x3 MiMo technology, which pro­vides an maximum data rate up to 450Mbps.

1.1 Feature List

802.11a/b/g/n PCI-e Minicard Featurset
RoHS compliant
FCC-ID FCC-ID: LYHMPCIE1V1
IC-ID IC-ID: 267AA-MPCIE1V1
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 3 von 21

2 Specifications

Datasheet_802_11abgn_PCI-e_Minicard.doc
Standard
802.11a/b/g/n
FCC-ID FCC-ID: LYHMPCIE1V1
IC-ID IC-ID: 267AA-MPCIE1V1
RoHS compliance fullfilled
Chipset
Atheros AR9390
Host Interface
PCI Express, PCI-e Minicard
Radio
Antenna 3 U.FL (Ultra-miniature coaxial) connectors
Operating Frequency 11b/g/n ISM band: 2.392GHz to 2482GHz
11a ISM Band: 5.170GHz to 5835GHz
Modulation 802.11a: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11b: DSSS (BDSK, DQPSK, CCK)
802.11g: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11n: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
Output Power 802.11a: 16dBm – 15dBm @36Mbps
802.11a: 13dBm – 11dBm @54Mbps
802.11b/g: 19dBm @36Mbps
802.11b/g: 17dBm– 16dBm @54Mbps
802.11n: 18dBm @120Mbps (2,4GHz band)
802.11n: 12dBm @450Mbps (2,4GHz band)
Transmit Power tolerance ±1.5dBm
For further details refer to the transmit power in chapter Electrical Specifications.
Receive Sensitivity 802.11a: -81dBm @54Mbps
802.11b: -90dBm @11Mbps
802.11g: -80dBm @54Mbps
802.11n HT20: -93dBm @19,5Mbps (2,4GHz band)
802.11n HT40: -89dBm @45Mbps (2,4GHz band)
Receive Sensitivity tolerance ±2.0dBm
For further details refer to the receiver sesitivity in chapter Electri­cal Specifications.
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 4 von 21
Power consumption
Continuous TX max. 3.0W
Operating voltage
DC 3.3V ± 5% max. 3.0W
Environmental operating conditions
Storage Temperature Range -40°C to 105°C
Datasheet_802_11abgn_PCI-e_Minicard.doc
Operating Temperature Range:
-20°C to 85°C
Storage Humidity
Operating Humidity: 5% to 95%
Physical Specifications
Dimensions 50.8mm x 30.0mm x 3.2mm
Weight 7g ±0.5g
Software
Driver Windows XP/ Vista, Windows 7, Linux
Security 64/128-bit WEP, WPA, WPA2
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 5 von 21

2.1 Mechanical Specifications

Full size PCI-e Minicard
Top Side
Datasheet_802_11abgn_PCI-e_Minicard.doc
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 6 von 21
Bottom Side
Datasheet_802_11abgn_PCI-e_Minicard.doc
Details
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 7 von 21

2.2 Electrical Specifications

Datasheet_802_11abgn_PCI-e_Minicard.doc
Data transfer rates
all modes support auto-fallback function
802.11b 11Mbps
5.5Mbps 2Mbps 1Mbps
802.11g 54Mbps 48Mbps 36Mbps 24Mbps 18Mbps 12Mbps 9Mbps 6Mbps
802.11g
(Turbo mode)
108Mbps 96Mbps 72Mbps 48Mbps 36Mbps 24Mbps 18Mbps 12Mbps
802.11a 54Mbps 48Mbps 36Mbps 24Mbps 18Mbps 12Mbps 9Mbps 6Mbps
802.11a
(Turbo mode)
108Mbps 96Mbps 72Mbps 48Mbps 36Mbps 24Mbps 18Mbps 12Mbps
802.11n 450Mbps – 6.5Mbps
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 8 von 21
Transmit Power (Output Power conducted)
Datasheet_802_11abgn_PCI-e_Minicard.doc
802.11a
5,180GHz to 5,825GHz
transmit frequency data rate
5,18GHz– 5,32GHz
5,50GHz– 5,60GHz
5,70GHz 5,745GHz–
5,825GHz
1MBit/s – 36MBit/s 16dBm 16dBm 16dBm 15dBm
48MBit/s 14dBm 13dBm 12dBm 12dBm
54MBit/s 13dBm 12dBm 11dBm 11dBm
802.11b/g
2.412GHz to 2.484GHz
transmit frequency data rate
2,412GHz 2,442GHz 2,472GHz
1MBit/s – 24MBit/s 19dBm 19dBm 19dBm
36MBit/s 19dBm 19dBm 19dBm
48MBit/s 18dBm 18dBm 17dBm
54MBit/s 17dBm 17dBm 16dBm
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 9 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc
802.11n
(data rate, steams)
MSC0 – MSC6 (6,5MBit/s – 65MBit/s, 1 stream)
MCS7 (65MBit/s – 72,2MBit/s, 1 stream)
MCS8 – MCS11 (13MBit/s – 57,8MBit/s, 2 streams)
MCS12 (78MBit/s – 86,7MBit/s, 2 streams)
MCS13 (104MBit/s – 115,6MBit/s, 2 streams)
20MHz channel width
2.412GHz to 2.472GHz
transmit frequency modulation
2,412GHz 2,442GHz 2,472GHz
18dBm 18dBm 18dBm
17dBm 17dBm 17dBm
18dBm 18dBm 18dBm
17dBm 18dBm 17dBm
16dBm 17dBm 16dBm
MCS14 (117MBit/s – 130MBit/s, 2 streams)
MCS15 (130MBit/s – 144,4MBit/s, 2 streams)
MCS16 – MCS19 (19,5MBit/s – 86,7MBit/s, 3 streams)
MCS20 – MCS21 (117MBit/s – 173,3MBit/s, 3 streams)
MCS22 (175,5MBit/s – 195MBit/s, 3 streams)
MCS23 (195MBit/s – 216,7MBit/s, 3 streams)
15dBm 16dBm 15dBm
14dBm 15dBm 14dBm
18dBm 18dBm 18dBm
14dBm 15dBm 14dBm
14dBm 14dBm 14dBm
13dBm 13dBm 13dBm
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 10 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc
802.11n
(data rate, steams)
MSC0 – MSC5 (6,5MBit/s – 57,8MBit/s, 1 stream)
MCS6 (58,5MBit/s – 65MBit/s, 1 stream)
MCS7 (65MBit/s – 72,2MBit/s, 1 stream)
MCS8 – MSC12 (13MBit/s – 86,7MBit/s, 2 streams)
MCS13 (104MBit/s – 115,6MBit/s, 2 streams)
20MHz channel width 5,180GHz to 5,825GHz
transmit frequency modulation
5,18GHz– 5,32GHz
5,50GHz 5,60GHz 5,70GHz 5,745GHz–
5,825GHz
16dBm 16dBm 16dBm 16dBm 15dBm
14dBm 14dBm 14dBm 14dBm 14dBm
13dBm 13dBm 13dBm 13dBm 13dBm
16dBm 16dBm 16dBm 16dBm 15dBm
14dBm 13dBm 13dBm 12dBm 12dBm
MCS14 (117MBit/s – 130Bit/s, 2 streams)
MCS15 (130MBit/s – 144,4MBit/s, 2 streams)
MCS16 – MCS19 (19,5MBit/s– 86,7MBit/s, 3 streams)
MCS20 (117MBit/s – 130,7MBit/s, 3 streams)
MCS21 (156MBit/s – 173,3MBit/s, 3 streams)
MCS22 – MSC23 (175,5MBit/s– 216,7MBit/s, 3 streams)
13dBm 12dBm 12dBm 10dBm 10dBm
12dBm 11dBm 11dBm 8dBm 8dBm
16dBm 16dBm 16dBm 16dBm 15dBm
12dBm 11dBm 10dBm 9dBm 9dBm
12dBm 11dBm 9dBm 8dBm 8dBm
11dBm 10dBm 8dBm 7dBm 7dBm
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 11 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc
802.11n
(data rate, steams)
MSC0 – MSC5 (13,5MBit/s – 120MBit/s, 1 stream)
MCS6 (121,5MBit/s – 135MBit/s, 1 stream)
MCS7 (135MBit/s – 150MBit/s, 1 stream)
MCS8 – MCS11 (27MBit/s – 120MBit/s, 2 streams)
MCS12 (162MBit/s – 180MBit/s, 2 streams)
40MHz channel width 2,522GHz to 2,462GHz
transmit frequency modulation
2,422GHz 2,447GHz 2,462GHz
18dBm 18dBm 18dBm
17dBm 17dBm 17dBm
16dBm 16dBm 16dBm
18dBm 18dBm 18dBm
16dBm 17dBm 16dBm
MCS13 (216MBit/s – 240MBit/s, 2 streams)
MCS14 (143MBit/s –270MBit/s, 2 streams)
MCS15 (270MBit/s – 300MBit/s, 2 streams)
MCS16 – MCS19 (40,5MBit/s – 180MBit/s, 3 streams)
MCS20 – MCS21 (243MBit/s – 270MBit/s, 3 streams)
MCS22 (364,5MBit/s – 405MBit/s, 3 streams)
15dBm 16dBm 15dBm
14dBm 15dBm 14dBm
13dBm 14dBm 13dBm
18dBm 18dBm 18dBm
13dBm 14dBm 13dBm
13dBm 13dBm 13dBm
MCS23
12dBm 12dBm 12dBm (405MBit/s – 450MBit/s, 3 streams)
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 12 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc
802.11n
(data rate, steams)
MSC0 – MSC4 (13,5MBit/s – 90MBit/s, 1 stream)
MCS5 (108MBit/s – 120MBit/s, 1 stream)
MCS6 (121,5MBit/s – 135MBit/s, 1 stream)
MCS7 (135MBit/s – 150MBit/s, 1 stream)
MCS8 – MSC12 (27MBit/s – 180MBit/s, 2 streams)
40MHz channel width
5,190GHz to 5,795GHz
transmit frequency modulation
5,19GHz–
5,31GHz
5,51GHz 5,59GHz 5,67GHz 5,755GHz–
5,795GHz
16dBm 16dBm 16dBm 16dBm 15dBm
15dBm 15dBm 15dBm 15dBm 15dBm
14dBm 14dBm 14dBm 14dBm 14dBm
13dBm 13dBm 13dBm 13dBm 13dBm
16dBm 16dBm 16dBm 16dBm 15dBm
MCS13
14dBm 13dBm 13dBm 11dBm 11dBm (216MBit/s – 240MBit/s, 2 streams)
MCS14
13dBm 12dBm 12dBm 10dBm 10dBm (243MBit/s – 270Bit/s, 2 streams)
MCS15
12dBm 11dBm 11dBm 8dBm 8dBm (270MBit/s – 300MBit/s, 2 streams)
MCS16 – MCS19
16dBm 16dBm 16dBm 16dBm 15dBm (40,5MBit/s – 180MBit/s, 3 streams)
MCS20
12dBm 11dBm 10dBm 9dBm 9dBm (243MBit/s – 270MBit/s, 3 streams)
MCS21
12dBm 11dBm 9dBm 8dBm 8dBm (324MBit/s – 360MBit/s, 3 streams)
MCS22 – MSC23
11dBm 10dBm 8dBm 7dBm 7dBm (364,5MBit/s – 450MBit/s, 3 streams)
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 13 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc
Receiver Sensitivity
PER (Packet Error Rate) <10% at PSDU length of 1000Bytes
802.11b
data rate 2,4GHz band
(measurement at 2,442GHz)
1Mbps -98dBm
2Mbps -93dBm
5,5Mbps -94dBm
11Mbps -90dBm
802.11a/g 802.11g 802.11a
data rate 2,4GHz band
(measurement at 2,442GHz)
5GHz band (measurement at 5,500GHz)
6Mbps -95dBm -94dBm
9Mbps -95dBm -94dBm
12Mbps -93dBm -95dBm
18Mbps -93dBm -94dBm
24Mbps -89dBm -90dBm
36Mbps -86dBm -87dBm
48Mbps -81dBm -83dBm
54Mbps -80dBm -81dBm
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 14 von 21
802.11n 20MHz channel width
Datasheet_802_11abgn_PCI-e_Minicard.doc
modulation (data rate) 2,4GHz band
(measurement at 2,442GHz)
5GHz band (measurement at 5,500GHz)
MCS0 (6,5MBit/s) -95dBm -94dBm
MCS1 (13MBit/s) -93dBm -94dBm
MCS2 (19,5MBit/s) -91dBm -93dBm
MCS3 (26MBit/s) -87dBm -88dBm
MCS4 (39MBit/s) -85dBm -86dBm
MCS5 (52MBit/s) -80dBm -81dBm
MCS6 (58,5MBit/s) -79dBm -80dBm
MCS7 (65MBit/s) -78dBm -78dBm
MCS8 (13MBit/s) -93dBm -94dBm
MCS9 (26MBit/s) -90dBm -91dBm
MCS10 (39MBit/s) -88dBm -89dBm
MCS11 (52MBit/s) -85dBm -86dBm
MCS12 (78MBit/s) -82dBm -83dBm
MCS13 (104MBit/s) -78dBm -78dBm
MCS14 (117MBit/s) -76dBm -76dBm
MCS15 (130MBit/s) -76dBm -75dBm
MCS16 (19,5MBit/s) -93dBm -93dBm
MCS17 (39MBit/s) -90dBm -90dBm
MCS18 (58,5MBit/s) -87dBm -88dBm
MCS19 (78MBit/s) -83dBm -85dBm
MCS20 (117MBit/s) -82dBm -81dBm
MCS21 (156MBit/s) -77dBm -76dBm
MCS22 (175,5MBit/s) -75dBm -74dBm
MCS23 (195MBit/s) -74dBm -68dBm
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 15 von 21
802.11n 40MHz channel width
Datasheet_802_11abgn_PCI-e_Minicard.doc
modulation (data rate) 2,4GHz band
(measurement at 2,447GHz)
5GHz band (measurement at 5,510GHz)
MCS0 (13,5MBit/s) -89dBm -91dBm
MCS1 (27MBit/s) -90dBm -90dBm
MCS2 (40,5MBit/s) -89dBm -89dBm
MCS3 (54MBit/s) -85dBm -85dBm
MCS4 (81MBit/s) -82dBm -83dBm
MCS5 (108MBit/s) -78dBm -78dBm
MCS6 (121,5MBit/s) -77dBm -76dBm
MCS7 (135MBit/s) -75dBm -74dBm
MCS8 (27MBit/s) -90dBm -90dBm
MCS9 (54MBit/s) -88dBm -88dBm
MCS10 (81MBit/s) -86dBm -86dBm
MCS11 (108MBit/s) -82dBm -83dBm
MCS12 (162MBit/s) -79dBm -79dBm
MCS13 (216MBit/s) -75dBm -74dBm
MCS14 (243MBit/s) -74dBm -72dBm
MCS15 (300MBit/s) -72dBm -69dBm
MCS16 (45MBit/s) -89dBm -90dBm
MCS17 (81MBit/s) -87dBm -88dBm
MCS18 (121,5MBit/s) -84dBm -85dBm
MCS19 (162MBit/s) -81dBm -81dBm
MCS20 (243MBit/s) -76dBm -72dBm
MCS21 (324MBit/s) -74dBm -71dBm
MCS22 (364,5MBit/s) -72dBm -66dBm
MCS23 (405MBit/s) -70dBm -63dBm
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 16 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc

3 Label

The following figure shows the label of the MPCIE-R1-ABGN-U3
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 17 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc

4 FCC and IC Notes

FCC-approval
This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IEEE802.11b or g operation of this product in the USA is firmware-limited to channels 1 through11. ______________________________________________________________________________ Notice Changes or modifications made to this equipment not expressly approved by SIEMENS may void the FCC authorization to operate this equipment. ______________________________________________________________________________
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected. Consult the dealer or an experienced radio/TV technician for help. ______________________________________________________________________________ Notice This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. ______________________________________________________________________________ This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Professional Installation Notice
To comply with FCC part 15 rules in the United States, the system must be professionally installed to ensure compliance with the Part 15 certification. It is the responsibility of the operator and professional installer to ensure that only certified systems are deployed in the United States. The use of the system in any other combination (such as co-located antennas transmitting the same information) is expressly forbidden.
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 18 von 21
Datasheet_802_11abgn_PCI-e_Minicard.doc
RSS-210 of Industry Canada
"Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device." "This device has been designed to operate with the antennas listed below, and having a maximum gain of 14,2 dBi including the antenna cable. Antennas not included in this list or having a gain greater 14,2 dBi (including the antenna cable) are strictly prohibited for use with this device. The required antenna impedance is 50 ohms." "To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication." "That the device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems." "Users should also be cautioned to take note that high power radars are allocated as primary users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz and these radars could cause interference and/or damage to LE-LAN devices."
Antenna List
Type Properties
ANT792-6MN Omni antenna, mast/wall mounting, 6 dBi 2.4 GHz, N-
Connect female
ANT793-6MN Omni antenna, mast/wall mounting, 5 dBi 5 GHz, N-Connect
female
ANT792-8DN Directional antenna, mast/wall mounting, 14 dBi 2.4 GHz, N-
Connect female
ANT793-8DJ Directional antenna, mast/wall mounting, 18 dBi 5 GHz, 2 x
N-Connect female
ANT793-8DK Directional antenna, mast/wall mounting, 23 dBi 5 GHz, 2 x
N-Connect female
ANT793-6DT Wide angle antenna (MIMO), mast/wall mounting, 8 dBi 5
GHz, 3 x QMA connector female
ANT795-6DC Wide angle antenna, mast/ wall mounting, 9 dBi 2.4 GHz
and 5 GHz, N-Connect female
ANT793-6DG Wide angle antenna, mast/ wall mounting, 9 dBi 5 GHz, 2 x
N-Connect female
ANT795-6MN Omni antenna, mounted on roof/vehicle, 6/8 dBi 2.4 GHz
and 5 GHz, N-Connect female
ANT795-6MT Omni antenna (MIMO), mounted on roof/vehicle/ceiling, 5/7
dBi 2.4 GHz and 5 GHz, 3 x QMA connector female
ANT795-4MC Omnidirectional antenna, 3/5 dBi, 2.4 GHz and 5 GHz, IP65,
N-Connect male for direct installation on the device, straight
connector, set of 3 antennas.
ANT795-4MD Omnidirectional antenna, 3/5 dBi, 2.4 GHz and 5 GHz, IP65, 6GK5 795-4MD00-
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 19 von 21
Order number
6GK5 792-6MN00-
0AA6
6GK5 793-6MN00-
0AA6
6GK5 792-8DN00-0AA6
6GK5 793-8DJ00-0AA0
6GK5 793-8DK00-0AA0
6GK5 793-6DT00-0AA0
6GK5 795-6DC00-0AA0
6GK5 793-6DG00-0AA0
6GK5 795-6MN10-
0AA6
6GK5 795-6MT00-0AA0
6GK5 795-4MC00-
0AA3
Datasheet_802_11abgn_PCI-e_Minicard.doc
N-Connect male for direct installation on the device, 90°
connector, set of 3 antennas.
ANT795-4MA Omni antenna, mounted directly on the device, 3/5 dBi 2.4
GHz and 5 GHz, IP30, R-SMA connector male for direct
mounting on the device, connector angle adjustable 0° to
180°, set of 3 antennas.
ANT792-4DN RCoax helical antenna, circular polarization, 4 dBi, 2.4 GHz,
N-connect female.
ANT793-4MN RCoax λ5/8 antenna with vertical polarization, 6 dBi, 5 GHz,
N-connect female.
IWLAN RCoax cable 2.4
GHz PE 1/2"
IWLAN RCoax cable 5
GHz PE
Omni antenna, 0 dBi
2.400 - 2.485 GHz, N-Connect female.
Omni antenna, 0 dBi
5.150 - 5.875 GHz, N-Connect female.
0AA3
6GK5 795-4MA00-0AA3
6GK5 792-4DN00-0AA6
6GK5 793-4MN00-
0AA6
6XV1875-2A
6XV1875-2D
Notes:
The directed antenna 5CH50 with cable loss 4.4 dB at 5.7 GHz.
The directed antenna 5CN10 with cable loss 8.8 dB at 5.7 GHz.
ANT793-8DJ may be used only with minimum 5 m antenna cable, Type 6XV 1875-
ANT793-8DK may be used only with minimum 10 m antenna cable, Type 6XV 1875-
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 20 von 21

5 Ordering Information

MLFB
6GK5795-2MP10-0AA0
Datasheet_802_11abgn_PCI-e_Minicard.doc
Copyright (c) Siemens AG 2012. All Rights reserved. Confidential Seite 21 von 21
Loading...
