Siemens KG56NAI25N User Manual [ru]
en Instruction for Use
tr Kullanma kılavuzu
ru Инcтpyкция
пo экcплyaтaции
KG..N..
Fridge-freezer
Soğutucu/Dondurucu kombine cihazı
Холодильно-морозильная комбинация
en Table of Contents
Safety and warning information ............ 4
Information concerning disposal .......... 6
Scope of delivery .................................... 6
Ambient temperature and ventilation .. 7
Connecting the appliance ..................... 7
Getting to know your appliance ........... 8
Switching the appliance on ................... 9
Setting the temperature ...................... 10
Energy saving mode ........................... 10
Alarm function ...................................... 10
Usable capacity .................................... 11
Refrigerator compartment .................. 12
Super cooling ....................................... 13
Freezer compartment .......................... 13
Max. freezing capacity ........................ 14
tr İçindekiler
Güvenlik ve ikaz bilgileri ..................... 23
Giderme bilgileri ................................... 25
Teslimat kapsamı ................................. 26
Mekan sıcaklığına ve havalandırmaya
dikkat edilmelidir .................................. 26
Cihazın elektrik şebekesine
bağlanması ............................................ 27
Cihaz özelliklerinin öğrenilmesi ......... 27
Cihazın devreye sokulması ................ 28
Sıcaklık derecesinin ayarlanması ...... 29
Enerji tasarruf modu ............................ 29
Alarm fonksiyonu ................................. 30
Kullanılabilen hacim ............................. 30
Soğutucu bölmesi ................................ 31
Süper soğutma ..................................... 32
Dondurucu bölmesi ............................. 32
Azami dondurma kapasitesi .............. 33
Freezing and storing food .................. 14
Freezing fresh food ............................. 14
Super freezing ...................................... 15
Thawing frozen food ............................ 16
Interior fittings ....................................... 16
Sticker “OK” .......................................... 17
Switching off and disconnecting
the appliance ........................................ 17
Defrosting .............................................. 17
Cleaning the appliance ....................... 18
Light (LED) ............................................ 19
Tips for saving energy ........................ 19
Operating noises ................................. 20
Eliminating minor faults yourself ....... 21
Customer service ................................. 22
Besinlerin dondurulması
ve depolanması .................................... 33
Taze besinlerin dondurulması ........... 34
Süper dondurma .................................. 35
Dondurulmuş besinlerin buzunun
çözülmesi .............................................. 35
Dolab ...................................................... 36
Çıkartma ”OK” ...................................... 37
Cihazın kapatılması, cihazın tamamen
kapatılması ............................................ 37
Cihazın buzunun çözülmesi ............... 37
Cihazın temizlenmesi .......................... 38
Aydınlatma (LED) ................................. 39
Enerji tasarrufu ..................................... 39
Çalışma sesleri ..................................... 40
Basit hataları kendiniz
giderebilirsiniz ....................................... 41
Yetkili servis .......................................... 42
ru Coдepжaниe
Укaзaния пo бeзoпacнocти
и пpeдyпpeждeния .............................. 43
Укaзaния пo yтилизaции ................... 45
Oбъeм пocтaвки .................................. 46
Teмпepaтypa oкpyжaющeй cpeды
и вeнтиляция ........................................ 46
Подключение бытового прибора ... 47
Знакомство с бытовым прибором . 48
Включение бытового прибора ....... 49
Уcтaнoвкa
Peжим экoнoмии элeктpoэнepгии . 51
Предупредительная функция .......... 51
Пoлeзный oбъeм ................................. 52
Xoлoдильнoe oтдeлeниe ................... 52
Cyпepoxлaждeниe .............................. 54
Mopoзильнoe oтдeлeниe .................. 54
Maкc. пpoизвoдитeльнocть
зaмopaживaния ................................... 54
тeмпepaтypы .................... 50
Зaмopaживaниe и xpaнeни
пpoдyктoв ............................................. 54
Зaмopaживaниe cвeжиx
пpoдyктoв питaния ............................. 55
Cyпepзaмopaживaниe ....................... 56
Paзмopaживaниe пpoдyктoв ............ 57
Cпeциaльнoe ocнaщeниe ................. 57
Haклeйкa «OK» ................................... 59
Bыключeниe прибора и вывoд
eгo из экcплyaтa
Paзмopaживaниe ................................ 59
Чистка прибора .................................. 59
Ocвeщeниe (нa cвeтoдиoдax) .......... 61
Kaк cэкoнoмить элeктpoэнepгию .. 61
Paбoчиe шyмы ..................................... 62
Caмocтoятeльнoe ycтpaнeниe
мeлкиx нeиcпpaвнocтeй ................... 63
Cлyжбa cepвиca ................................. 64
ции .......................... 59
e
en
enTable of Contents
enInstruction for Use
Safety and warning information
Before you switch ON the appliance
Please read the operating and
installation instructions carefully! They
contain important information on how to
install, use and maintain the appliance.
The manufacturer is not liable if you fail
to comply with the instructions and
warnings. Retain all documents for
subsequent use or for the next owner.
If the power cord of this appliance is
damaged, it must be replaced by the
manufacturer, customer service or a
similarly qualified person. Improper
installations and repairs may put the user
at considerable risk.
Repairs may be performed by the
manufacturer, customer service or a
similarly qualified person only.
Only original parts supplied by the
manufacturer may be used. The
manufacturer guarantees that only these
parts satisfy the safety requirements.
A extension cable may be purchased
from customer service only.
Technical safety
This appliance contains a small quantity
of environmentally-friendly but flammable
R600a refrigerant. Ensure that the tubing
of the refrigerant circuit is not damaged
during transportation and installation.
Leaking refrigerant may cause eye
injuries or ignite.
If damage has occurred
■ Keep naked flames and/or ignition
sources away from the appliance,
■ thoroughly ventilate the room for
several minutes,
■ switch off the appliance and pull out
the mains plug,
■ inform customer service.
The more refrigerant an appliance
contains, the larger the room must be in
which the appliance is situated. Leaking
refrigerant can form a flammable gas-air
mixture in rooms which are too small.
The room must be at least 1 m³ per 8 g
of refrigerant. The amount of refrigerant
in your appliance is indicated on the
rating plate inside the appliance.
Important information when using the appliance
■ Never use electrical appliances inside
the appliance (e.g. heater, electric ice
maker, etc.). Risk of explosion!
■ Never use a steam cleaner to defrost
or clean the appliance! The steam
may penetrate electrical parts
and cause a short-circuit. Risk of
electric shock!
■ Do not use pointed or sharp-edged
implements to remove frost or layers
of ice. You could damage
the refrigerant tubing. Leaking
refrigerant may ignite or cause eye
injuries.
■ Do not store products which contain
flammable propellants (e.g. spray
cans) or explosive substances
in the appliance. Risk of explosion!
■ Do not stand or support
yourself on the base, drawers
or doors, etc.
4
en
■ Before defrosting and cleaning
the appliance, pull out the mains plug
or switch off the fuse.
Do not pull out the mains plug
by tugging the cable.
■ Bottles which contain a high
percentage of alcohol must be sealed
and stored in an upright position.
■ Keep plastic parts and the door seal
free of oil and grease. Otherwise,
parts and door seal will become
porous.
■ Never cover or block the ventilation
openings for the appliance.
■ People (childern incl.) who have
limited physical, sensory or mental
abilities or inadequate knowledge
must not use this appliance unless
they are supervised or given
meticulous instructions.
■ Do not store bottled or canned drinks
(especially carbonated drinks)
in the freezer compartment. Bottles
and cans may explode!
■ Never put frozen food straight
from the freezer compartment
into your mouth.
Risk of low-temperature burns!
■ Avoid prolonged touching of frozen
food, ice or the evaporator pipes, etc.
Risk of low-temperature burns!
Children in the household
■ Keep children away from packaging
and its parts.
Danger of suffocation from folding
cartons and plastic film!
■ Do not allow children to play with the
appliance!
■ If the appliance features a lock:
keep the key out of the reach of
children!
General regulations
The appliance is suitable
■ for refrigerating and freezing food,
■ for making ice.
This appliance is intended for use in
the home and the home environment.
The appliance is suppressed according
to EU Directive 2004/108/EC.
The refrigeration circuit has been
checked for leaks.
This product complies with the relevant
safety regulations for electrical
appliances (EN 60335-2-24).
5
en
Information concerning disposal
* Disposal of packaging
The packaging protects your appliance
from damage during transit. All utilised
materials are environmentally safe and
recyclable. Please help us by disposing
of the packaging in an environmentally
friendly manner.
Please ask your dealer or inquire at your
local authority about current means of
disposal.
* Disposal of your old appliance
Old appliances are not worthless
rubbish! Valuable raw materials can be
reclaimed by recycling old appliances.
This appliance is identified
according to the European
guideline 2002/96/EC on waste
electrical and electronic
equipment – WEEE. The directive
specifies the framework for an
EU-wide valid return and re-use
of old appliances.
m Warning
Redundant appliances
1. Pull out the mains plug.
2. Cut off the power cord and discard with the mains plug.
3. Do not take out the trays and receptacles: children are therefore prevented from climbing in!
4. Do not allow children to play with the appliance once it has spent its useful life. Danger of suffocation!
Refrigerators contain refrigerant
and gases in the insulation. Refrigerant
and gases must be disposed
of professionally. Ensure that tubing
of the refrigerant circuit is not damaged
prior to proper disposal.
Scope of delivery
After unpacking all parts, check for any
damage in transit.
If you have any complaints, please
contact the dealer from whom you
purchased the appliance or our
customer service.
The delivery consists of the following parts:
■ Free-standing appliance
■ Interior fittings (depending on model)
■ Bag containing installation materials
■ Operating instructions
■ Installation manual
■ Customer service booklet
■ Warranty enclosure
■ Information on the energy
consumption and noises
6
en
Ambient temperature and ventilation
Ambient temperature
The appliance is designed for a specific
climate class. Depending on the climate
class, the appliance can be operated at
the following temperatures.
The climate class can be found on
the rating plate. Fig. 0
Climate class Permitted ambient
temperature
SN +10 °C to 32 °C
N +16 °C to 32 °C
ST +16 °C to 38 °C
T +16 °C to 43 °C
Note
The appliance is fully functional within
the room temperature limits
of the indicated climatic class. If
an appliance of climatic class SN
is operated at colder room temperatures,
the appliance will not be damaged up to
a temperature of +5 °C.
Ventilation
Fig. #
The air on the rear panel and on the side
panels of the appliance heats up.
Conduction of the heated air must
not be obstructed. Otherwise,
the refrigerating unit must work harder.
This increases power consumption.
Therefore: Never cover or block
the ventilation openings!
Connecting the appliance
After installing the appliance, wait at least
1 hour until the appliance is switched on.
During transportation the oil in
the compressor may have flowed into
the refrigeration system.
Before switching on the appliance for
the first time, clean the interior of
the appliance (see chapter “Cleaning
the appliance”).
Electrical connection
The socket must be near the appliance
and also freely accessible following
installation of the appliance.
The appliance complies with the
protection class I. Connect the appliance
to 220–240 V/50 Hz alternating current
via a correctly installed socket with
protective conductor. The socket must
be fused with a 10 to 16 A fuse.
For appliances operated in nonEuropean countries, check whether the
stated voltage and current type match
the values of your mains supply. This
information can be found on the rating
plate. Fig. 0
m Warning
Never connect the appliance
to electronic energy saver plugs.
Our appliances can be used with mains
and sine-controlled inverters. Mainscontrolled inverters are used
for photovoltaic systems which
are connected directly to the national
grid. Sine-controlled inverters must be
used for isolated applications (e.g. on
ships or in mountain lodges) which are
not connected directly to the national
grid.
7
en
Getting to know your appliance
Please fold out the illustrated last page.
These operating instructions refer
to several models.
The features of the models may vary.
The diagrams may differ.
Fig. !
* Not all models.
A Refrigerator compartment
B Freezer compartment
1 - 9 Controls
10 On/Off button
11 Light switch
12 Light (LED)
13 Air outlet opening
14 Shelf in the refrigerator
compartment
15 Vegetable container
16 Cold storage compartment
17* Ice maker/pizza box
18 Freezer drawer
19 Freezer shelf
20 Height-adjustable feet
21 Egg rack
22* Butter and cheese compartment
23 Active carbon filters
24* Bottle holder
25 Shelf for large bottles
26* Ice block/Frozen-food calendar
8
en
Controls
Fig. "
1 Selection button for refrigerator
compartment
Is used to set the temperature
in the refrigerator compartment.
2 Temperature display refrigerator
compartment
The numbers correspond
to the set refrigerator
compartment temperatures in °C.
3 “Super” button refrigerator
compartment
Switches super cooling on and
off.
4 Selection button for freezer
compartment
Is used to set the temperature
setting for the freezer
compartment.
5 Temperature display freezer
compartment
The numbers correspond
to the set freezer compartment
temperatures in °C.
6 “Super” button (freezer
compartment)
Switches super freezing
on and off.
7 Alarm button
Used to switch off the warning
signal, see chapter “Alarm
function”.
8 Setting buttons +/-
The buttons are used to set the
temperatures of the refrigerator
and freezer compartment.
9 Energy saving mode display
It is lit when the appliance is not
in use.
Note
When the appliance is not used for some
time, the display on the fascia switches
to ECO mode.
Switching the appliance on
1. Press the On/Off button !/10.
Warning signal is emitted.
2. Press the alarm button "/7. Warning
signal stops.
The alarm button "/7 remains lit until the set temperature has been reached.
The factory has recommended
the following temperatures:
■ Refrigerator compartment: +4 °C
■ Freezer compartment: –18 °C
Operating tips
■ When the appliance has been
switched on, it may take several hours
until the set temperatures have been
reached.
■ The fully automatic NoFrost system
ensures that the freezer compartment
remains free of ice. Defrosting is no
longer required.
■ The sides of the housing are
sometimes heated slightly. This
prevents condensation in the area of
the door seal.
■ If the freezer compartment door
cannot be immediately re-opened after
it has been closed, wait until the
resulting low pressure has equalised.
9
en
Setting the temperature
Fig. "
Refrigerator compartment
The temperature can be set from 2 °C
to 8 °C.
1. Use the selection button refrigerator compartment 1 to select refrigerator compartment.
2. Using the temperature setting button 8, to set the required refrigerator compartment temperature.
The value last selected is saved. The set
temperature is indicated on temperature
display 2.
Freezer compartment
The temperature can be set from -16 °C
to -24 °C.
1. Using the selection button freezer compartment 4 to select freezer compartment.
2. Use the temperature setting button 8 to set the required freezer compartment temperature.
The value last selected is saved. The set
temperature is indicated on display 5.
Energy saving mode
When the appliance is not used,
the display on the controls switches
to energy saving mode.
■ Energy saving mode display, Fig. "/
9, illuminates.
■ The luminosity of the temperature
displays is reduced.
■ When the “Super” function is switched
on, the corresponding super display is
lit (Super cooling display, Fig. "/3 or
Super freezing display, Fig. "/6).
As soon as you operate the appliance,
e.g. open door or press any button,
the display switches to normal
illumination.
Alarm function
In the following cases an alarm may be
actuated.
Door alarm
The door alarm (continuous sound)
switches on and the “alarm” display "/7
is lit, if the appliance door is open for
longer than one minute. Close the door
or press any button to switch the door
alarm off again.
10
Temperature alarm
The temperature alarm switches on
if the freezer compartment is too warm
and the frozen food is at risk of thawing.
The temperature display 5 flashes
and the alarm button 7 is lit.
When the alarm button 7 is pressed,
the temperature display 5 indicates for
five seconds the warmest temperature
reached in the freezer compartment.
Then this value is deleted and
the temperature display 5 indicates
the set temperature.
The alarm may switch on without any risk
to the frozen food
■ when the appliance is switched on,
■ when large quantities of fresh food are
placed in the appliance,
■ if the freezer compartment door is
open too long.
Note
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
en
Usable capacity
Information on the usable capacity can
be found inside your appliance on
the rating plate. Fig. 0
Fully utilising the freezer volume
The maximum amount of food can be
placed in the freezer by removing all
fittings. The food can be stacked directly
on the shelves and in the bottom
of the freezer compartment.
Removing the fittings
Pull out the frozen food container all
the way, lift at the front and remove.
Fig. $
Switching off the alarm
Fig. "
Press the alarm button 7 to switch off
the warning signal.
11
en
Refrigerator compartment
The refrigerator compartment is the ideal
storage location for meat, sausage, fish,
dairy products, eggs, ready meals
and pastries.
Storing food
■ Store fresh, undamaged food. The
quality and freshness will then
be retained for longer.
■ In the case of ready-made products
and bottled goods, observe the bestbefore date or use-by date specified
by the manufacturer.
■ To retain aroma, colour
and freshness, pack or cover food
well before placing in the appliance.
This will prevent the transfer
of flavours and the discolouration
of plastic parts in the refrigerator
compartment.
■ Allow warm food and drinks to cool
down before placing in the appliance.
Note the chill zones in the refrigerator compartment
The air circulation in the refrigerator
compartment creates different chill
zones:
■ Coldest zone
is on the rear panel inside
the appliance and on the cold storage
compartment. Fig. !/16
Note
Store perishable food e.g. fish, sausage, meat in the coldest zones.
■ Warmest zone
is at the very top of the door.
Note
Store e.g. hard cheese and butter in the warmest zone. Cheese can then continue to release its flavour and the butter will still be easy to spread.
Note
Do not block air outlet openings with
food, otherwise the air circulation will be
impaired. Food which is stored directly
in front of the air outlet openings may be
frozen by the cold air flowing out.
12
Vegetable container with humidity controller
Fig. %
To create the optimum storage climate
for fruit and vegetables, you can set the
air humidity in the vegetable container
depending on the quantity stored:
■ smaller quantities of fruit and
vegetables – high air humidity
■ large quantities of fruit and vegetables
– low air humidity
Notes
■ Fruit sensitive to cold (e.g. pineapple,
banana, papaya and citrus fruit) and
vegetables sensitive to cold (e.g.
aubergines, cucumbers, zucchini,
peppers, tomatoes and potatoes)
should be stored outside
the refrigerator at temperatures
of approx. +8 °C to +12 °C for
optimum preservation of quality and
flavour.
■ Condensation may form in the
vegetable container depending on the
type and quantity of products stored.
Remove condensation with a dry cloth
and adjust air humidity in the
vegetable container with the humidity
controller.
en
Super cooling
Super cooling sets the refrigerator
temperature to the coldest temperature
setting for approx. 6 hours. Then
the appliance automatically switches
to the temperature set prior to super
cooling mode.
Switch on super cooling mode, e.g.
■ before placing large quantities of food
in the refrigerator compartment.
■ for the fast cooling of drinks.
Switching on and off
Fig. "
Press “super” button 3.
The button is lit when super cooling is
switched on.
Freezer compartment
Use the freezer compartment
■ To store deep-frozen food.
■ To make ice cubes.
■ To freeze food.
Cold storage compartment
Fig. !/16
The cold storage compartment has lower
temperatures than the refrigerator
compartment. Even temperatures below
0 °C may occur.
Ideal for storing fish, meat and sausage.
Not suitable for lettuce and vegetables
and produce sensitive to cold.
Note
Ensure that the freezer compartment
door has been closed properly. If
the door is open, the frozen food will
thaw. The freezer compartment will
become covered in thick ice. Also: waste
of energy due to high power
consumption!
13
en
Max. freezing capacity
Information about the max. freezing
capacity within 24 hours can be found
on the rating plate. Fig. 0
Freezing and storing food
Purchasing frozen food
■ Packaging must not be damaged.
■ Use by the “use by” date.
■ Temperature in the supermarket
freezer must be -18 °C or lower.
■ If possible, transport deep-frozen food
in an insulated bag and place quickly
in the freezer compartment.
Note when loading products
■ Preferably freeze large quantities
of food in the top compartment, where
food freezes particularly quickly
and therefore also gently.
■ Place the food over the whole area
of the compartments or the frozen
food containers.
Note
Food which is already frozen must not come into contact with the food which is to be frozen. If required, move the frozen food to other frozen food containers.
Freezing fresh food
Freeze fresh and undamaged food only.
To retain the best possible nutritional
value, flavour and colour, vegetables
should be blanched before freezing.
Aubergines, peppers, zucchini and
asparagus do not require blanching.
Literature on freezing and blanching
can be found in bookshops.
Note
Keep food which is to be frozen away
from food which is already frozen.
■ The following foods are suitable for
freezing:
Cakes and pastries, fish and seafood,
meat, game, poultry, vegetables, fruit,
herbs, eggs without shells, dairy
products such as cheese, butter and
quark, ready meals and leftovers such
as soups, stews, cooked meat and
fish, potato dishes, soufflés and
desserts.
■ The following foods are not suitable
for freezing:
Types of vegetables, which are usually
consumed raw, such as lettuce or
radishes, eggs in shells, grapes,
whole apples, pears and peaches,
hard-boiled eggs, yoghurt, soured
milk, sour cream, crème fraîche and
mayonnaise.
Storing frozen food
Insert frozen food container all the way to
ensure unrestricted air circulation.
14
Packing frozen food
To prevent food from losing its flavour or drying out, place in airtight containers.
1. Place food in packaging.
2. Remove air.
3. Seal the wrapping.
4. Label packaging with contents and date of freezing.
Suitable packaging:
Plastic film, tubular film
made of polyethylene, aluminium foil,
freezer containers.
These products are available
from specialist outlets.
Unsuitable packaging:
Wrapping paper, greaseproof paper,
cellophane, bin liners and used
shopping bags.
Items suitable for sealing packaged food:
Rubber bands, plastic clips, string, coldresistant adhesive tape, etc.
Bags and tubular film
made of polyethylene can be sealed
with a film heat sealer.
Shelf life of frozen food
Storage duration depends on the type
of food.
At a temperature of -18 °C:
■ Fish, sausage, ready meals and cakes
and pastries:
up to 6 months
■ Cheese, poultry and meat:
up to 8 months
■ Vegetables and fruit:
up to 12 months
en
Super freezing
Food should be frozen solid as quickly
as possible in order to retain vitamins,
nutritional value, appearance and flavour.
Several hours before placing fresh food
in the freezer compartment, switch on
super freezing to prevent an unwanted
temperature rise.
As a rule, 4-6 hours is adequate.
This appliance runs constantly
and the freezer compartment drops to
a very low temperature.
If the max. freezing capacity is to be
used, super freezing must be switched
on for 24 hours before the fresh produce
is placed in the freezer compartment.
Smaller quantities of food (up to 2 kg)
can be frozen without “super freezing”.
Note
When super freezing is switched on,
increased operating noises may occur.
Switching on and off
Fig. "
Press “super” button 6.
If the super freezing has been switched
on the button is lit.
Super freezing automatically switches off
after approx. 2½ days.
15
en
Thawing frozen food
Depending on the type and application,
select one of the following options:
■ at room temperature
■ in the refrigerator
■ in an electric oven, with/without fan
assisted hot-air
■ in the microwave
m Caution
Do not refreeze thawing or thawed food.
Only ready meals (boiled or fried) may
be refrozen.
No longer store the frozen produce for
the max. storage period.
Interior fittings
Shelves and containers
You can reposition the inner shelves
and the containers in the door as
required: pull shelf forwards, lower
and swivel out to the side. Lift
the container and remove.
Special features
(not all models)
Drawer for sausage and cheese
Fig. &
The drawer can be removed for adding
and removing food. Lift the drawer
and pull out. The drawer holder
can be adjusted.
Bottle shelf
Fig. '
Bottles can be stored securely on
the bottle shelf. The holder can be
adjusted.
Ice maker
Fig. (
1. Remove the ice cube tray, fill ¾ full of drinking water and re-insert.
2. When the ice cubes are frozen, rotate the knobs on the ice cube trays several times to the right and release. The ice cubes loosen and fall into the storage container.
3. Remove ice cubes from the storage container.
Ice cube tray
Fig. )
1. Fill the ice cube tray ¾ full of drinking water and place in the freezer compartment.
2. If the ice tray is stuck to the freezer compartment, loosen with a blunt implement only (spoon-handle).
3. To loosen the ice cubes, twist the ice tray slightly or hold briefly under flowing water.
Freezer calendar
Fig. !/26
To prevent the quality of the frozen food
from deteriorating, do not exceed the
storage duration. The storage period
depends on the type of produce.
The figures next to the symbols indicate
the permitted storage period
of the produce in months. In the case
of commercially available frozen food
observe the date of manufacture or useby date.
16
Ice block
Fig. *
If a power failure or malfunction occurs,
the ice blocks can be used to slow down
the thawing process. The longest
storage time is obtained by placing
the ice pack on the food in the top
compartment.
To save space, the ice block
can be stored in the door compartment.
The ice blocks can also be used to cool
food temporarily , e. g. in a cold bag.
Active carbon filters
Fig. !/23
The activated carbon filter ensures that
air is replaced and odours reduced in
the appliance.
Sticker “OK”
(not all models)
The “OK” temperature monitor
can be used to determine temperatures
below +4 °C. Gradually reduce
the temperature if the sticker
does not indicate “OK”.
Note
When the appliance is switched on,
it may take 12 hours until
the temperature is reached.
en
Switching off and disconnecting the appliance
Switching off the appliance
Fig. !
Press the On/Off button 10.
Refrigerating unit and light switch off.
Disconnecting the appliance
If you do not use the appliance for a prolonged period:
1. Switch off the appliance.
2. Pull out mains plug or switch off fuse.
3. Clean the appliance.
4. Leave the appliance door open.
Defrosting
Freezer compartment
The fully automatic NoFrost system
ensures that the freezer compartment
remains free of ice. Defrosting is no
longer required.
Correct setting
17
en
Cleaning the appliance
m Caution
■ Do not use abrasive, chloride or acidic
cleaning agents or solvents.
■ Do not use scouring or abrasive
sponges.
The metallic surfaces could corrode.
■ Never clean shelves and containers
in the dishwasher.
The parts may become deformed!
Water used for cleaning must not drip
into the
■ slots in the front base area in
the freezer compartment,
■ controls,
■ and light.
Proceed as follows:
1. Before cleaning: Switch the appliance off.
2. Pull out mains plug or switch off fuse.
3. Take out the frozen food and store in a cool location. Place the ice pack (if enclosed) on the food.
4. Clean the appliance with a soft cloth, lukewarm water and a little pH neutral washing-up liquid. The rinsing water must not run into the light.
5. Wipe the door seal with clear water only and then wipe dry thoroughly.
6. After cleaning reconnect and switch the appliance back on.
7. Put the frozen food back in the freezer compartment.
Interior fittings
All variable parts of the appliance
can be taken out for cleaning.
Take out glass shelves
Pull the glass shelves forwards and take
out.
Removing the container
Fig. ,
Pull out the container all the way and lift
to detach it.
To insert the container, place on
the telescopic rails and push into
the appliance. Attach the container by
pressing it down.
Taking out glass shelf above vegetable container
Fig. +
The glass shelf can be taken out and
disassembled for cleaning.
Note
Before taking out the glass shelf, pull out
vegetable container.
Glass shelf cold storage compartment
(not all models)
Note
Do not clean glass shelf of the cold
storage compartment under running
water.
Before removing the glass shelf, remove
vegetable container and cold storage
compartment.
Fig. Press the holder upwards and take out
the glass shelf.
18
Cleaning the ice maker
Clean the ice maker regularly. This will
prevent ice cubes, which were made
quite a long time ago, from shrinking,
having a stale taste or sticking together.
1. Take out the ice maker. Fig. .
2. Remove and empty the storage container.
3. Remove cover from the ice maker.
4. Clean all parts of the ice maker with warm water.
5. Leave parts to dry completely.
6. Assemble ice maker and insert.
Taking out the frozen food container
Fig. $
Pull out the frozen food container all
the way, lift at the front and remove.
Light (LED)
Your appliance features a maintenancefree LED light.
These lights may be repaired
by customer service or authorised
technicians only.
en
Tips for saving energy
■ Install the appliance in a dry, well
ventilated room! The appliance should
not be installed in direct sunlight
or near a heat source (e.g. radiator,
cooker).
If required, use an insulating plate.
■ Allow warm food and drinks to cool
down before placing in the appliance.
■ Thaw frozen food in the refrigerator
compartment and use the low
temperature of the frozen food to cool
refrigerated food.
■ Open the appliance as briefly as
possible.
■ Occasionally clean the rear
of the appliance to prevent an
increased power consumption.
■ If available:
Fit wall spacers to obtain the indicated
energy rating of the appliance (see
Installation instructions). A reduced
wall gap will not restrict the function
of the appliance. The energy rating
may then increase slightly. The gap
of 75 mm must not be exceeded.
■ The arrangement of the fittings does
not affect the energy rating of the
appliance.
19
en
Operating noises
Quite normal noises
Droning
Motors are running (e.g. refrigerating
units, fan).
Bubbling, humming or gurgling noises
Refrigerant is flowing through the tubing.
Clicking
Motor, switches or solenoid valves are
switching on/off.
Cracking
Automatic defrosting is running.
Preventing noises
The appliance is not level
Please align the appliance with a spirit
level. Use the height-adjustable feet
or place packing underneath them.
The appliance is not free-standing
Please move the appliance away
from adjacent units or appliances.
Containers or storage areas wobble or stick
Please check the removable parts
and re-insert them correctly if required.
Bottles or receptacles are touching each other
Move the bottles or receptacles slightly
away from each other.
20
Eliminating minor faults yourself
Before you call customer service:
Please check whether you can eliminate the fault yourself based on the following
information.
Customer service will charge you for advice – even if the appliance is still under
guarantee!
Fault Possible cause Remedial action
Temperature differs greatly
from the set value.
The light does not function.
Fig. !/12
Displays do not illuminate. Power failure; the fuse has
The temperature in
the freezer compartment is
too warm.
Light switch is sticking. Check whether the light switch can move. Fig.
The light is defective. See chapter “Light”.
been switched off; the mains
plug has not been inserted
properly.
Appliance opened
frequently.
The ventilation openings
have been covered.
Large quantities of fresh
food are being frozen.
In some cases it is adequate to switch off
the appliance for 5 minutes.
If the temperature is too high wait a few hours
and check whether the temperature has
approached the set value.
If the temperature is too low check
the temperature again the next day.
!/11
Connect mains plug. Check whether the power
is on, check the fuses.
Do not open the appliance unnecessarily.
Remove obstacles.
Do not exceed max. freezing capacity.
en
21
Loading...
