2
Albatros
Boiler controllers
RVS43..
RVS63..
AVS75..
AVS37..
QAA75..
QAA78..
User manual
Edition 2.0
Controller series B
CE1U2354en
11. May 2007
QAA55..
Building Technologies
HVAC Products
2/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products 11. May 2007
Table of contents
1 Summary ......................................................................................................... 9
1.1 Type summary............................................................................................... 10
2 Safety notes................................................................................................... 11
2.1 Product liability ..............................................................................................11
3 Mounting and installation............................................................................... 12
3.1 Regulations.................................................................................................... 12
3.2 Basic units RVS… ......................................................................................... 12
Planning......................................................................................................... 12
Mounting method........................................................................................... 13
Dimensions and drilling plan.......................................................................... 13
3.2.1 Connection terminals of RVS43.143 .............................................................14
3.2.2 Connection terminals of RVS63.243 .............................................................14
3.2.3 Connection terminals of RVS63.283 .............................................................15
Terminal markings ......................................................................................... 16
3.3 Extension module AVS75.390....................................................................... 18
Dimensions and drilling plan.......................................................................... 18
3.3.1 Connection terminals of AVS75.390.............................................................. 18
Terminal markings ......................................................................................... 19
Assignment of terminals ................................................................................ 19
3.4 Operator unit AVS37.294 ..............................................................................20
Mounting method........................................................................................... 20
Connections................................................................................................... 20
Dimensions.................................................................................................... 20
3.5 Operator unit AVS37.390 ..............................................................................21
Connections................................................................................................... 21
Dimensions.................................................................................................... 21
3.6 Room unit QAA55… ...................................................................................... 22
Planning......................................................................................................... 22
Mounting method........................................................................................... 22
Connections................................................................................................... 22
Dimensions and drilling plan.......................................................................... 22
3.7 Room unit QAA75… ...................................................................................... 23
Planning......................................................................................................... 23
Mounting method........................................................................................... 23
Connections................................................................................................... 23
Dimensions and drilling plan.......................................................................... 24
3.8 Wireless components .................................................................................... 25
3.8.1 Radio module AVS71.390 ............................................................................. 25
Planning......................................................................................................... 25
Mounting method........................................................................................... 25
Connection ....................................................................................................25
Radio connection........................................................................................... 25
Dimensions and drilling plan.......................................................................... 25
3.8.2 Room unit QAA78.610................................................................................... 26
3/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Summary 11. May 2007
Planning .........................................................................................................26
Mounting with base........................................................................................26
Connection / power supply.............................................................................27
Radio connection ...........................................................................................27
Dimensions and drilling plan ..........................................................................28
3.8.3 Wireless outside sensor AVS13.399..............................................................29
Mounting method ...........................................................................................29
Radio connection ...........................................................................................30
Dimensions and drilling plan ..........................................................................30
3.8.4 Radio repeater AVS14.390 ............................................................................31
Mounting method ...........................................................................................31
Connections ...................................................................................................31
Radio connection ...........................................................................................31
Dimensions and drilling plan ..........................................................................31
3.8.5 Checking the wireless components ...............................................................32
3.9 Power supply AVS16.290 ..............................................................................32
Mounting notes ..............................................................................................32
Mounting method ...........................................................................................32
Connections ...................................................................................................32
4 Commissioning ..............................................................................................34
4.1 Basic units......................................................................................................34
5 Handling.........................................................................................................35
5.1 QAA75.. / QAA78… / AVS37.. .......................................................................35
5.1.1 Operation .......................................................................................................35
Operating elements........................................................................................35
Display choices ..............................................................................................36
Selecting heating mode .................................................................................36
Selecting DHW heating mode........................................................................37
Adjusting the room temperature setpoint .......................................................37
Occupancy button ..........................................................................................37
Displaying information....................................................................................37
5.1.2 Programming .................................................................................................40
Setting principle .............................................................................................40
Example: “Setting the time of day“.................................................................40
5.1.3 User levels .....................................................................................................41
Setting structure “Enduser“ ............................................................................42
Setting structure ”Heating engineer“ ..............................................................42
5.1.4 Overview of settings.......................................................................................43
5.1.5 AVS37.390Operation .....................................................................................62
Operating elements........................................................................................62
Display choices ..............................................................................................62
Selecting the operating mode ........................................................................62
Adjusting the room temperature setpoint .......................................................63
Adjusting the nominal DHW setpoint .............................................................63
Displaying information....................................................................................63
Setting principle .............................................................................................64
Example: “Setting the time of day“.................................................................64
5.1.6 User levels .....................................................................................................65
5.1.7 Overview of settings.......................................................................................66
4/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Summary 11. May 2007
5.2 QAA55... ........................................................................................................ 67
5.2.1 Operation....................................................................................................... 67
Operating elements ....................................................................................... 67
Display choices.............................................................................................. 67
5.2.2 Programming ................................................................................................. 67
6 The settings in detail...................................................................................... 68
6.1 Time of day and date..................................................................................... 68
6.2 Operator section ............................................................................................ 68
Operation and display.................................................................................... 68
Heating circuit assignment ............................................................................69
Room sensor ................................................................................................. 70
Device data.................................................................................................... 70
6.3 Radio ............................................................................................................. 70
Binding........................................................................................................... 70
Device list radio ............................................................................................. 71
6.4 Time programs ..............................................................................................71
Switching points............................................................................................. 71
Standard program.......................................................................................... 72
6.5 Holidays......................................................................................................... 72
6.6 Heating circuits .............................................................................................. 72
Operating mode............................................................................................. 72
Setpoints........................................................................................................ 72
Heating curve ................................................................................................73
ECO functions ...............................................................................................74
Flow temperature setpoint limitations ............................................................ 75
Room influence.............................................................................................. 75
Room temp limitation..................................................................................... 76
Boost heating................................................................................................. 77
Quick setback ................................................................................................ 77
Optimum start / stop control ..........................................................................78
Increase of Reduced setpoint........................................................................ 79
Overtemperature protection pump heating circuit .........................................79
Mixing valve control ....................................................................................... 79
Floor curing function ...................................................................................... 80
Excess heat draw .......................................................................................... 81
Buffer storage tank / primary controller .........................................................81
Speed-controlled pump .................................................................................81
Remote .......................................................................................................... 82
6.7 DHW .............................................................................................................. 82
Setpoints........................................................................................................ 82
Priority ...........................................................................................................82
Legionella function......................................................................................... 83
Circulating pump............................................................................................ 83
6.8 Pump H1/H2/H3 ............................................................................................84
Pump H1/H2/H3 ............................................................................................84
6.9 Swimming pool ..............................................................................................84
Setpoints........................................................................................................ 84
Priority ...........................................................................................................84
Plant hydraulics ............................................................................................. 85
6.10 Primary controller / system pump .................................................................. 85
5/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Summary 11. May 2007
Primary controller / system pump ..................................................................85
6.11 Boiler..............................................................................................................85
Operating mode .............................................................................................85
Setpoints ........................................................................................................85
Minimum limitation of the return temperature ................................................86
Output data ....................................................................................................86
2 x 1 cascade.................................................................................................86
6.12 Cascade.........................................................................................................87
Control ...........................................................................................................87
Boiler sequence .............................................................................................87
Minimum limitation of the return temperature ................................................88
6.13 Solar...............................................................................................................89
Charging controller (dT) .................................................................................89
Priority............................................................................................................89
Start function..................................................................................................90
Frost protection for the collector ....................................................................91
Overtemperature protection for the collector .................................................91
Medium’s evaporation temperature ...............................................................91
Speed control.................................................................................................92
Yield measurement ........................................................................................92
6.14 Solid fuel boiler ..............................................................................................92
Operating mode .............................................................................................92
Setpoints ........................................................................................................92
Boiler / burner control.....................................................................................92
6.15 Buffer storage tank.........................................................................................93
Automatic locks..............................................................................................93
Overtemperature protection ...........................................................................93
Recooling .......................................................................................................93
Plant hydraulics..............................................................................................94
Return diversion.............................................................................................94
Partial charging ..............................................................................................95
Full charging ..................................................................................................95
6.16 DHW storage tank..........................................................................................96
Charging control.............................................................................................96
Overtemperature protection ...........................................................................96
Recooling .......................................................................................................96
Electric immersion heater ..............................................................................96
Plant hydraulics..............................................................................................98
Speed-controlled pump..................................................................................98
6.17 Instantaneous DHW heater............................................................................98
Setpoints ........................................................................................................98
Mixing valve control .......................................................................................98
6.18 Configuration..................................................................................................99
Heating circuits 1 and 2 .................................................................................99
DHW sensor B3 .............................................................................................99
DHW controlling element Q3 .........................................................................99
Separate circuit ..............................................................................................99
Boiler............................................................................................................100
Solar.............................................................................................................103
Output relay QX ...........................................................................................104
Input sensor BX ...........................................................................................107
Input H1/H3..................................................................................................107
Input EX2 .....................................................................................................110
6/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Summary 11. May 2007
Mixing valve groups basic unit..................................................................... 111
Extension module ........................................................................................ 112
QX extension module .................................................................................. 113
BX extension module................................................................................... 114
H2 extension module................................................................................... 114
10V output UX ............................................................................................. 114
Types of sensors/readjustments.................................................................. 115
Building and room model............................................................................. 115
Frost protection for the plant........................................................................ 115
External requirements .................................................................................116
sensor state ................................................................................................. 116
Parameter reset........................................................................................... 116
Plant diagram ..............................................................................................117
Device data.................................................................................................. 119
6.19 LPB system .................................................................................................120
Address / power supply ............................................................................... 120
Central functions.......................................................................................... 120
Clock............................................................................................................ 121
6.20 Errors........................................................................................................... 122
6.21 Maintenance / service.................................................................................. 122
Maintenance functions................................................................................. 122
Chimney sweep ........................................................................................... 123
Economy mode............................................................................................ 123
Manual operation......................................................................................... 123
Simulations .................................................................................................. 124
Telephone customer service .......................................................................124
6.22 Input / output test......................................................................................... 125
6.23 State ............................................................................................................ 125
Messages .................................................................................................... 125
6.24 Diagnostics of heat source .......................................................................... 128
6.25 Diagnostics consumers ...............................................................................128
6.26 List of displays ............................................................................................. 129
6.26.1 Error code.................................................................................................... 129
6.26.2 Maintenance code .......................................................................................130
6.26.3 Special operation code ................................................................................ 130
7 Plant diagrams............................................................................................. 131
7.1 Basic diagrams ............................................................................................ 131
7.1.1 Basic diagram RVS43.143 ..........................................................................131
7.1.2 Basic diagram RVS63.243 ..........................................................................132
7.1.3 Basic diagram RVS63.283 ..........................................................................132
7.2 Versions of heat sources ............................................................................. 133
7.3 Extra functions in general ............................................................................ 134
Solar ............................................................................................................ 134
Boiler ...........................................................................................................136
Storage tank temperature............................................................................ 137
Heating circuit.............................................................................................. 137
Heat converter ............................................................................................. 138
Swimming pool ............................................................................................138
Pressureless header.................................................................................... 138
7/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Summary 11. May 2007
Extra functions .............................................................................................139
7.4 Extra functions with AVS75.390...................................................................140
Legend mains voltage..................................................................................142
Legend low-voltage......................................................................................143
8 Technical data..............................................................................................144
8.1 Basic units RVS…........................................................................................144
8.2 Extension module AVS75.390 .....................................................................145
8.3 Operator unit and room units AVS37... / QAA7x… / QAA55.. .....................146
8.4 Power supply AVS16.290 ............................................................................147
8.5 Radio module AVS71.390............................................................................147
8.6 Wireless outside sensor AVS13.399............................................................148
8.7 Radio repeater AVS14.390 ..........................................................................149
8.8 Sensor characteristics..................................................................................150
8.8.1 NTC 1 k........................................................................................................150
8.8.2 NTC 10 k......................................................................................................151
8.8.3 PT1000 ........................................................................................................151
9 Revision history............................................................................................155
8/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Summary 11. May 2007
1 Summary
This User manual describes the products listed in the following table and covers
handling and configuration of the controls for readers ranging from endusers to heating
engineers.
Type reference
(ASN)
RVS43.143 A Basic unit boiler
RVS63.243 B Basic unit boiler
RVS63.283 B Basic unit boiler
AVS75.390 B Extension module
AVS37.294 B Operator unit
AVS37.390 A Operator unit basic
QAA75.610 B Room unit, wired
QAA75.611 B Room unit with backlight, wired
QAA78.610 B Room unit, wireless
QAA55.110 A Room unit basic
AVS16.290 A Power section
AVS71.390 A Radio module
AVS14.390 A Radio repeater
AVS13.399 A Wireless outside sensor
The following products are described in separate pieces of documentation:
QAC34 Outside sensor NTC 1 kΩ
QAD36 Strap-on temperature sensor NTC 10 kΩ
QAZ36 Immersion temperature sensor NTC 10 kΩ
Series Name
9/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Summary 11. May 2007
Operation with room
unit
1.1 Type summary
Wired RF
Operation with operator
unit “basic”
(optionally with additional
room unit)
Operation with operator
unit “clear-text”
(optionally with additional room
unit)
B
A
D
T
B
A
E1
EB
C
T
2359Z66
B
A
D
B
A
B
F
E1
E
C
2359Z67
A
A Basic unit RVS…
B Power section AVS16…
C Room unit QAA75… / 78…
D Outside sensor AVS13…
E Operator unit AVS37.294 (clear-text)
E1 Operator unit AVS37.390 (basic)
F Radio module AVS71…
A
10/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Summary 11. May 2007
2 Safety notes
2.1 Product liability
• The products may only be used in building services plant and applications as
described in this document
• When using the products, all requirements specified in chapters "Handling" and
"Technical data" must be satisfied
• The local regulations (for installation, etc.) must be complied with
• Do not open the units. If not observed, warranty becomes void.
11/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Safety notes 11. May 2007
3 Mounting and installation
3.1 Regulations
Electrical installation
Planning
Mounting location
• Prior to installing the units, power must be turned off
• The connections for mains and low-voltage are separated
• For wiring, the requirements of safety class II must be satisfied. Sensor and power
cables must not be run in the same cable duct
3.2 Basic units RVS…
• Air circulation around the controller must be ensured, allowing the unit to emit the
heat produced by it.
A clearance of at least 10 mm must be provided for the unit's cooling slots at the top
and bottom of the housing.
That space should not be accessible and no objects should be placed there. If the
controller is enclosed in another (insulating) casing, a clearance of up to 100 mm
must be observed around the cooling slots
• The controller is designed conforming to the directives for safety class II devices
mounted in compliance with these regulations
• Power to the controller may only be supplied when completely fitted. If this is not
observed, there is a risk of electric shock hazard near the terminals and through the
cooling slots
• The controller must not be exposed to dripping water.
• Permissible ambient temperature when mounted and when ready to operate: 0...50 °C
• Power cables must be clearly segregated from low-voltage cables (sensors)
observing a distance of at least 100 mm
• Boiler
• Control panel
• Housing for wall mounting
12/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Mounting method
Screwed On DIN rail
Dimensions and drilling plan
BL1B1
A2
A1
2359Z09
L
B1
A: Mounting / B: Removal
Note:
To mount the controller on a DIN rail, a mounting clip
is required!
B2
Dimensions in mm
2359Z11
Total height required
RVS63…
RVS43…
2359Z10
x
2358M01
L B H L1 B1
280.7 120.7 51.7 270 110
180.7 120.7 51.7 170 110
Dimension X:
Connectors with tongues minimum 70 mm
Connector without tongues minimum 60 mm
13/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
3.2.1 Connection terminals of RVS43.143
U TSR Q P N L
QX1 N
Y2 N
Y1
Q2 N
Q3 N
SK2
SK1 4 S3
T2
T1
N L1
S3
L1
050110A
000020RVS43.143/109
S05011000002 0
1PRVS13.143/109
N L
2354Z08
M
BX2 M BX1 M B1 M H1 M B9 M B3 - - M B2 - G+
n n p n k h f b b a
b
CL-
CL+
CL-
G+
CL-
CL+
CL+
MB
DB
X50
X60
X30
BSB
LPB
3.2.2 Connection terminals of RVS63.243
QX4
Z U U UTSR Q PN L
QX4
FX4
EX2
QX3 N
QX2 N - - - - - - - QX1 N
061107B
000020RVS63.243/10 9
S061107000020
1PRVS63.243/109
Y2 N
Y1
Q2 N
Q3 N
SK2
SK1 4 S3
T2
T1
N L1
S3
L1
N L
2354Z06
M
UX M BX4 M BX3 M H3 - - M BX2 M BX1 M B1 M H1 M B9 M B3 - - M B2 - G+
n n n n n n p n k h f b b b a
b
CL-
CL+
CL-
CL+
CL-
CL+
MB
DB
X50
X60
X30
BSB
G+
CL-
CL+
14/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
LPB
3.2.3 Connection terminals of RVS63.283
Z U U T SU TS R Q P N L
QX4
QX4
FX4
EX2
QX3 N
QX2 N
Y6 N
Y5
Q6 N
QX1 N
Y2 N
Y1
Q2 N
Q3 N
SK2
SK1 4 S3
T2
061107B
000020RVS63.283/10 9
S061107000020
1PRVS63.283/109
T1
N L1
S3
L1
N L
2354Z07
M
UX M BX4 M BX3 M H2 M B12 M BX2 M BX1 M B1 M H1 M B9 M B3 - - M B2 - G+
n n n n p n n p n k h f b b b a
b
CL-
CL+
CL-
CL+
CL-
CL+
G+
CL-
CL+
MB
DB
X50
X60
X30
BSB
LPB
15/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Terminal markings
Mains voltage
Use Space Connector type
L Live AC 230 V basic unit N L AGP4S.05A/109
Protective earth
N Neutral conductor
L1 Live AC 230 V burner
S3 Output burner fault
L1 Live burner P AGP8S.07A/109
Protective earth
N Neutral conductor
T1 Phase 1st burner stage
T2 1st burner stage on
S3 Input burner fault
4
Input 1st burner stage hours run
SK1 Safety loop Q AGP8S.02E/109
SK2 Safety loop
N Neutral conductor R AGP8S.03A/109
Protective earth
Q3 DHW charging pump / diverting valve
N Neutral conductor S AGP8S.03B/109
Protective earth
Q2 1st heating circuit pump
Y1 1st heating circuit mixing valve opening T AGP8S.04B/109
N Neutral conductor
Protective earth
Y2 1st heating circuit mixing valve closing
N Neutral conductor U AGP8S.03C/109
Protective earth
QX1 1st multifunctional output
N Nullleiter S
Protective earth
Q6 2nd heating circuit pump
AGP8S.03B/109
Y5 2nd heating circuit mixing valve opening T AGP8S.04B/109
N Neutral conductor
Protective earth
Y6 2nd heating circuit mixing valve closing
N Neutral conductor U AGP8S.03C/109
Protective earth
QX2 2nd multifunctional output
N Neutral conductor U AGP8S.03C/109
Protective earth
QX3 3rd multifunctional output
EX2 Multifunctional input Z AGP8S.04C/109
FX4
(T6)
QX4
(T7)
QX4
(T8)
Phase 4th Multifunctional output
(phase 2nd burner stage)
4th Multifunctional output off
(2nd burner stage off)
4th Multifunctional output on
(2nd burner stage on)
16/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Low-voltage
BSB Service tool OCI700
LPB
Use Space Connector type
- -
Local Process Bus
- system
X60 Radio module AVS71.390
X50 Extension module AVS75.390
X30 Operator unit / boiler control panel
DB LPB data
MB LPB ground
CL+ BSB data
- -
-
-
AVS82.490/109
AVS82.491/109
AGP4S.02H/109
AGP4S.02A/109
CL- BSB ground b
CL+ Room unit 2 data
AGP4S.02A/109
CL- Room unit 2 ground b
CL+ Room unit 1 data
AGP4S.02A/109
CL- Room unit 1 ground b AGP4S.03D/109
G+ Room unit power supply 12 V
B2 Boiler sensor
AGP4S.02B/109
M Ground f
B3 DHW sensor top
AGP4S.02C/109
M Ground h
B9 Outside sensor
AGP4S.02D/109
M Ground k
H1 Digital / DC 0...10 V input
AGP4S.02F/109
M Ground n
B1 Flow temperature sensor HK1
AGP4S.02G/109
M Ground p
BX1 Multifunctional sensor input 1
AGP4S.02F/109
M Ground n
BX2 Multifunctional sensor input 2
AGP4S.02F/109
M Ground n
B12 Flow temperature sensor HK2
AGP4S.02G/109
M Ground p
H3 Digital / DC 0...10 V input
AGP4S.02F/109
M Ground n
BX3 Multifunctional sensor input 3
AGP4S.02F/109
M Ground n
BX4 Multifunctional sensor input 4
AGP4S.02F/109
M Ground n
UX DC 0…10 V output n AGP4S.02F/109
M Ground
17/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
3
2
Dimensions and drilling plan
Connections
3.3 Extension module AVS75.390
For planning, mounting location and mounting method, refer to the information given for
the basic modules.
L
Dimensions in mm
BL1B1
2358M01
AVS75.390
The AVS75.390 extension module must be connected to terminal
using the
L B H L1 B1
108.7 120.9 51.7 98 110
X50 of the basic unit
AVS83.490/109 connecting cable. The connectors are coded.
3.3.1 Connection terminals of AVS75.390
S T N L
- - -
QX2
AVS75.390/109
S050110000020
M
H2 M BX22 M BX21 - -X50 - -
n n n
N
1PAVS75.390/109
QX2
N
QX21
N L
050110A
000020
1
2359Z49
2
12
1
2
= Module 1
= Module 2
X30
18/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Terminal markings
Mains voltage
Low-voltage
Assignment of terminals
Use Space Connector type
L Live AC 230 V basic unit N L AGP4S.03E/109
Protective earth
N Neutral conductor
QX21 Assignment according to function T AGP8S.04B/109
N Neutral conductor
Protective earth
QX22 Assignment according to function
N Neutral conductor S AGP8S.03B/109
Protective earth
QX23 Assignment according to function
X30 Operator unit / boiler control panel
X50 Basic unit
BX21 Assignment according to function
M Ground n
BX22 Assignment according to function
M Ground n
H2 Digital / DC 0...10 V input
Use Space Connector type
-
AVS82.491/109
AVS82.490/109
AGP4S.02F/109
AGP4S.02F/109
AGP4S.02F/109
M Ground n
Using the 2 parameters
• Function extension module 1 (operating line 6020)
• Function extension module 2 (operating mode 6021)
usage of the respective module will be defined.
19/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Mounting method
3.4 Operator unit AVS37.294
Installation
2358Z30
2358Z31
Removal
2358Z32
Connections
Dimensions
Panel cutout
The AVS37.294 operator unit must be connected to terminal X30 of the basic unit using
the AVS82.491/109 connecting cable. The connectors are coded.
27
17
2358M03
96
144
90
42.4
(144)
0.5...3.0
0
+0.8
92
(96)
+1
138
0
2358M05
20/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Connections
Dimensions
3.5 Operator unit AVS37.390
The AVS37.390 operator unit must be connected to terminal X30 of the basic unit using
the AVS82.491/109 connecting cable. The connectors are coded.
2354M01
0,5
13
A
A Control panel, front
21/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Planning
Mounting method
3.6 Room unit QAA55…
@
The room unit should be located in the main living room while giving consideration to
the following points:
• The place of installation should be chosen so that the sensor can capture the room
temperature as accurately as possible without getting adversely affected by direct
solar radiation or other heat or refrigeration sources (about 1.5 meters above the
floor)
• In the case of wall mounting, there must be sufficient clearance above the unit,
enabling it to be fitted and removed
When the unit is removed from its base, power is cut off so that the unit is out of
operation.
2284Z33a
2284Z34a
Connections
Dimensions and drilling plan
• The controller must not be exposed to dripping water
34
562
1
Terminal Designation QAA55..
2284Z40
1
2
CL+ BSB data
CL- BSB ground
2282M02
1
6
9
9
96
7
4
4,2
56
12
56
60
2359Z27
60
22/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Planning
Mounting method
3.7 Room unit QAA75…
@
The room unit should be located in the main living room while giving consideration to
the following points:
• The place of installation should be chosen so that the sensor can capture the room
temperature as accurately as possible without getting adversely affected by direct
solar radiation or other heat or refrigeration sources (about 1.5 meters above the
floor)
• In the case of wall mounting, there must be sufficient clearance above the unit,
enabling it to be fitted and removed
When the unit is removed from its base, power is cut off so that the unit is out of
operation.
Connections
2359Z25
2359Z20
2359Z26
2359Z24
Terminal Designation QAA75.610 QAA75.611
1
2
3
CL+ BSB data BSB data
CL- BSB ground BSB ground
G+ Reserved Power supply DC 12 V
2359Z21
23/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Dimensions and drilling plan
4,2
56
60
100
2359Z50
56
60
80
82
42
185
100
2359Z12
24/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Planning
Mounting method
3.8 Wireless components
The wireless components should be located such that transmission will be as
interference-free as possible. The following criteria must be observed:
• Not in the vicinity of electrical cables, strong magnetic fields or equipment like PCs,
TV sets, microwave ovens, etc.
• Not near larger metal structures or constructional elements with fine metal meshes
such as special glass or special concrete
• The distance to the transmitter should not exceed 30 meters or 2 floors
3.8.1 Radio module AVS71.390
The radio module extends the product range by introducing wireless communication.
With this type of device, the system components, such as room units, transmit data with
no need for laying cables.
Do not install the radio module inside metal casings (e.g. inside a boiler).
2359Z23
Connection
Radio connection
Dimensions and drilling plan
LED
A
Button
B
2359Z57
The prefabricated cable is to be connected to terminal X60 of the controller.
Prior to connecting, the basic unit must be disconnected from power!
Establishment of the wireless connection is described in the following sections which
cover the relevant radio-controlled units.
2354Z11
43
25/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Planning
Mounting with base
3.8.2 Room unit QAA78.610
@
The room unit should be located in the main living room while giving consideration to
the following points:
• The place of installation should be chosen so that the sensor can capture the room
temperature as accurately as possible without getting adversely affected by direct
solar radiation or other heat or refrigeration sources (about 1.5 meters above the
floor)
• In the case of wall mounting, there must be sufficient clearance above the unit,
enabling it to be fitted and removed
2359Z26
2359Z20
2359Z25
2359Z21
2359Z22
26/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Connection / power supply
Radio connection
Establishment
Testing
Mounting without base
2359Z61
The room unit is powered by three 1.5 V Alkali batteries type AA (LR06).
Make the radio connection in the vicinity of the radio module prior to mounting so that
all system are within easy reach.
Prerequisite for the radio connection is that all components receive power, which
means that the radio module must be correctly connected to the basic unit and the
batteries must be correctly installed in the room unit.
1. Press the button on the installed radio module for at least 8 seconds until the LED
on the radio module starts flashing at high frequency.
2. Press OK on the room unit to switch to programming.
3. Press the info button for at least 3 seconds and select operating level
“Commissioning“ with the setting knob. Then, press OK.
4. Select operating page “Operator unit“ and press OK.
5. Select operating line “Used as“ (operating line 40) and make the appropriate
selection. Then, press OK.
6. Select operating page “Radio“ and press OK.
7. Select setting line “Binding“ (line 120). Then, press OK.
8. Set the setting knob to “YES“ and press OK. Connection establishment is started.
9. The display shows the progress of connection establishment in %. This process can
take 2 to 120 seconds.
10. The connection is established when “Device ready” appears and the LED on the
radio module extinguishes
The test is made to check the quality of the radio link.
• The test can be aborted by pressing the ESC button.
• While the radio link can be opened on the controller, the test should be made at the
location where the room unit will be installed
On the room unit, as described above (points 2 through 4), select operating page
“Radio“ and activate the test mode on setting line “Test mode“ (line 121).
27/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Dimensions and drilling plan
Example of a display during the test:
The digits on the left shows telegrams that have
been sent, the digits on the right telegrams that
have been received. The test will be ended
Operator section
Testmode
after 24 telegrams. The test is considered
successful when at least 50 % of the telegrams
sent have been received.
If the test was not successful, some other mounting location is to be selected or the
AVS14.390 radio repeater can be used.
9
185
11
39
67
4,2
2359Z140
2359Z50
100
82
42
2359Z12
56
60
80
100
28/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Mounting method
3.8.3 Wireless outside sensor AVS13.399
• The radio transmitter must be installed inside the building.
• The radio transmitter’s mounting location should be chosen such that batteries
can be easily changed.
Radio transmitter Outside sensor
2359Z30
2359Z33
2359Z54
2359Z32
2359Z59
2359Z31
2359Z53
Battery
AAA
AAA
Battery transit
tab
2359Z55
Connections
The outside sensor is to be connected to the radio transmitter via a 2-core cable, the
connections are interchangeable.
The room unit is powered by 2 pieces 1.5 V Alkali batteries type AAA (LR03).
29/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Radio connection
Establishment
Testing
Dimensions and drilling plan
Make the radio connection in the vicinity of the radio module prior to mounting so that
all system are within easy reach.
Prerequisite for the radio connection is that all components receive power, which
means that the radio module must be correctly connected to the basic unit and the
batteries must be correctly installed in the room unit.
1. Press the button on the radio module for at least 8
LED
seconds until the LED on the radio module starts
flashing at high frequency.
2. Press the button on the transmitter of the wireless
AAA
AAA
outside sensor for at least 8 seconds until that LED
also starts flashing at high frequency.
3. The connection is established when the LED on the
radio module extinguishes.
Button
4. Press the button on the transmitter of the wireless outside sensor briefly again until
the LED extinguishes.
The test is made to check the quality of the radio link.
• The test can be aborted by pressing the ESC button.
• While the radio link can be opened on the controller, the test should be made at the
location where the room unit will be installed
1. Press button 3 on the transmitter of the wireless outside sensor for a maximum of 8
seconds until the LED starts flashing at low frequency.
2. When radio communication works, the LED on the radio module flashes briefly at
10-second intervals.
3. After the test, press the button on the transmitter of the wireless outside sensor
again briefly until the LED extinguishes.
2359Z58
2359Z16
100
90
4,2
12
56
60
2359Z27
32
56
60
79,8
5,5
4
49,5
2524,5
Ø 14,1
91,6
49,7
3
6
5,5
1811M02
1811M01
30/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Mounting method
Connections
Radio connection
Establishment
Testing
Dimensions and drilling plan
3.8.4 Radio repeater AVS14.390
• To establish the radio connection, the device must be provisionally connected to
power prior to mounting, enabling the radio connection to be opened and tested.
• The radio repeater must be fitted inside the building.
1
Power is supplied via the enclosed power pack. The wires are interchangeable.
Make the radio connection in the vicinity of the radio module prior to mounting so that
all system are within easy reach.
Prerequisite for the radio connection is that all components receive power, which
means that the radio module must be correctly connected to the basic unit and power
must be correctly supplied to the radio repeater.
1. Press the button on the radio module for at least 8
seconds until the LED on the radio module starts
flashing at high frequency.
2. Press the button on the installed radio repeater until
the LED start flashing at high frequency.
3. The connection is established when the LED on the
radio module extinguishes.
The test is made to check the quality of the radio link.
• The test can be aborted by pressing the ESC button.
• While the radio link can be opened on the controller, the test should be made at the
location where the room unit will be installed
1. Press button 3 on the radio repeater for a maximum of 8 seconds until the LED
starts flashing at low frequency.
2. When radio communication works, the LED on the radio module flashes briefly at
10-second intervals.
3. After the test, press the button on the radio repeater again briefly until the LED
extinguishes.
2359Z30
2
2359Z33
4
LED
Button
4,2
2359Z16
2359Z31
2359Z56
100
12
90
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
32
56
60
2359Z27
56
60
31/156
Mounting notes
Mounting method
3.8.5 Checking the wireless components
To check whether the connections to the required system components are operational,
consult operating lines 130 through 135 on operating page “Wireless“ (operating level
“Commissioning“).
3.9 Power supply AVS16.290
The boiler control panel is designed for installation in floor-standing or wall-hung oil or
gas boilers and may only be used for that purpose. For installation, the following points
must be observed:
• Power to the control panel may be supplied only after the unit is completely fitted in
the cutout Extension modules or dummy covers for which cutouts are provided must
also be fitted beforehand
• Dimensions of cutout 92 x 92 mm,
sheet metal thickness 0.5 to 3.0 mm
• The boiler control panel can be secured with the 4 clips provided on the panel
• Power to the control panel may be supplied only after the unit is completely fitted in
the cutout Extensions or dummy covers for which cutouts are provided must also be
fitted beforehand.
• The control panel wiring to the connection terminals does not feature strain relief and
must therefore be secured inside the boiler
• The local regulations for electrical installation must be complied with
Installation
2358Z27
2358Z28
Removal
2358Z29
Connections
Mains
Terminal Designation
L Live AC 230 V blue
Protective earth green + yellow
N Neutral conductor blue
Connection to basic unit
Terminal Designation
1
2
3
4
5
L Live AC 230 V basic unit brown
N Neutral conductor blue
L1 Live AC 230 V burner black
S3 Input burner fault
Protective earth green + yellow
-
32/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Dimensions
N1L
2358A16
L1 S3
S1
1A
3B
2A
4B
Si
1
2
N
L
STB
C2
PE
1A
3B1
1
H1
12345
Mains supply to RVS… basic unit
Si Fuse 6.3AT
S1 Mains switch with green glow lamp
STB = SLT Safety limit thermostat 110°C
H1 Signal lamp‚ SLT has cut out
80
35
0.5...3.0
2358M04
96
96
(96)
92
90
48
0
+0.8
92
(96)
+0.8
0
2358M02
33/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Mounting and installation 11. May 2007
Prerequisites
Functional check
Operating state
Diagnostics
4 Commissioning
To commission the units, the following working steps must be carried out:
• Prerequisite is the correct mounting and correct electrical installation and, in the case
of wireless solutions, correctly working radio connections to all required auxiliary
units.
• Make all plant-specific settings. Special attention must be paid to operating page
”Configuration“. For that purpose, the relevant operating level is to be selected as
follows:
Press OK on the room unit to switch to programming.
Press the info button for at least 3 seconds and select operating level
“Commissioning“ with the setting knob. Then, press OK.
• Make the functional check as described below.
• Reset the attenuated outside temperature
(operating page “Diagnostics of consumers“, operating line “Outside temp attenuated“
(operating line 8703))
To facilitate commissioning and fault tracing, the controller allows output and input tests
to be made. With these tests, the controller’s inputs and outputs can be checked. To
make the tests, switch to operating page “Input / output test“ and go through all
available setting lines.
The current operating state can be checked on operating page “State“.
For detailed diagnostics of the plant, check operating pages “Diagnostics heat source“
and “Diagnostics consumer”.
Checking the LED
4.1 Basic units
LED off: No power supply
LED on Ready to operate
LED flashes Local fault
LPB
LED
2358Z33
34/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Commissioning 11. May 2007
Operating elements
A
g
A
g
Room unit
5 Handling
5.1 QAA75.. / QAA78… / AVS37..
5.1.1 Operation
Select heating
mode
Select DHW mode
Quit setting
Take over setting
djust room comfort setpoint
Navi
ation and settings
Presence button
Operator unit
Show information
2359Z06
Select DHW mode
Select heating mode
Show information
Take over setting
Chimney sweep function
STB test
2359Z62
Quit setting
Service plug (BSB)
Manual mode
djust room comfort setpoint
ation and settings
Navi
35/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Display choices
Display
Selecting heating mode
Heating to Comfort setpoint
Heating to Reduced setpoint
Heating to frost protection setpoint
Info level activated
Programming activated
Heating temporarily switched
off
ECO function active
Process running – please wait
Change battery
Burner operating (only oil / gas boiler)
Holiday function active
Reference to heating circuit
Maintenance / special
operation
Error messages
Display of all symbols and segments.
Xxxxxxxxxxxxxxxxxxxxxxxxxxx
Xxxxxxxxxxxxxxxxxxxxxxxxxxx
Xxxxxxxxxxxxxxxxxxxxxxxxxxx
2358Z07
This setting is used to switch between the different
operating modes. The selection made is indicated by a
bar which appears below the respective symbol.
Automatic mode
Automatic mode controls the room temperature according to the time program.
Characteristics of automatic mode:
− Heating mode according to the time program
− Temperature setpoints according to heating program “Comfort setpoint“ or
“Reduced setpoint“
− Protective functions active
− Automatic summer / winter changeover (ECO functions)
Continuous operation
or
Continuous operation maintains the room temperature at the selected operating level.
Heating to Comfort setpoint
Heating to Reduced setpoint
Characteristics of continuous operation:
• Heating mode with no time program
• Protective functions active
• Automatic summer / winter changeover (ECO functions) and 24-hour heating limit
inactive in the case of continuous operation with Comfort setpoint
Protection
When using Protection, the heating system is off. But it remains protected against frost
(frost protection temperature) provided there is no power failure.
Characteristics of Protection:
36/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
• Heating off
• Temperature according to frost protection
• Protective functions active
• Automatic summer / winter changeover (ECO functions) and automatic 24-hour
heating limit active
Selecting DHW heating mode
The button is used to switch DHW heating mode on and off. The selection made is
indicated by a bar which appears below the respective symbol.
DHW heating
• On
The DHW is heated according to the selected switching program.
• Off
No DHW heating, the protective function is active.
DHW push
Triggering is effected by keeping the DHW operating mode
button on the operator or room unit depressed for at least 3 seconds.
It can also be started when:
• The operating mode is “Off“
• Operating mode changeover acts via H1 or centrally (LPB)
• All heating circuits use the holiday function
Adjusting the room temperature setpoint
Turn the setting knob to increase or decrease the Comfort setpoint
.
For the Reduced setpoint
− Press OK
− Select operating page “Heating circuit“ and
− adjust the “Reduced setpoint“
After each readjustment, wait at least 2 hours, allowing the room temperature to adapt.
Occupancy button
If you do not use the rooms for a certain period of time, you can
press the occupancy button to reduce the room temperature, thus
saving heating energy.
When the rooms are occupied again, press again the occupancy
button to resume heating operation.
Heating to Comfort setpoint
Heating to Reduced setpoint
• The occupancy button is only active in automatic operation
• The current selection is active until the next switching action according to the heating
program takes place
Displaying information
Various data can be displayed by pressing the info button.
AUTO
Room temperat ure
4 8 12 16 20 24
0
2359Z140
37/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Possible displays
Exception
Depending on the type of unit, configuration and operating state, some of the info lines
listed below may not appear.
Display:
− Possible error messages from the error code list on page 129
− Possible service messages from the maintenance code list on page 130
− Possible special mode messages from page 169
Other displays:
− Room temperature − State of DHW
− Room temperature minimum − State of boiler
− Room temperature maximum − State of solar
− Boiler temperature − State solid fuel boiler
− Outside temperature − State buffer storage tank
− Outside temp min − State swimming pool
− Outside temp max − Date and time of day
− DHW temp 1 − Telephone customer service
− State of heating circuit 1
− State of heating circuit 2
− State heating circuit P
In exceptional cases, the basic display shows one of the following symbols:
Error messages
If this symbol appears, an error in the
plant has occurred. Press the info button
and read further information
AUTO
Maintenance or special operation
If this symbol appears, a maintenance
alarm is delivered or the plant has
changed to special mode. Press the info
button and read further information.
AUTO
Reset function
Manual operation
Setpoint adjustment in
manual control
Error
30:Flow sensor 1
Text3 Text4
4 8 12 16 20 24
0
2359Z140
Error
30:Flow sensor 1
Text3 T ext4
4 8 12 16 20 24
0
2359Z140
A list of possible displays is given on page 128.
The reset function for meters and the resettable parameters appears on the bottom line
of the display, provided a reset is permitted on the current operating line (enduser /
commissioning / heating engineer).
Reset ? yes
4 8 12 16 20 24
0
2359Z140
After activation with the OK button, the display will show a flashing “Yes“.
Reset ?
4 8 12 16 20 24
0
yes
2359Z140
After confirmation with the OK button, the relevant parameter or counter will be reset.
When manual operation is active, the relays are no longer energized and deenergized
according to the control state, but are set to a predefined manual operation state
depending on their function.
The burner relay energized in manual control can be deenergized by the electronic
temperature controller (TR).
After manual control has been activated, a change to the basic display must be made.
There, the maintenance / special mode symbol
appears.
38/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Chimney sweep function
SLT test
Press the info button to switch to info display “Manual mode“, where the setpoint can be
adjusted.
The chimney sweep function is activated by a short press (maximum 3 seconds) on the
chimney sweep button. This function produces the operating state required to make
emission measurements (flue gas).
The SLT test (SLT = safety limit thermostat) is activated by a long press (longer than 3
seconds) on the chimney sweep button. The button must be kept depressed during the
entire test. If released, the test will be aborted. The SLT test is shown on the display.
The test may only be made by qualified staff since the boiler temperature will be raised
above the maximum limitations.
39/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
5.1.2 Programming
Setting principle
Settings that cannot be made directly with the operating elements are made in the form
of programming. For this purpose, the individual settings are structured in the form of
operating pages and operating lines, thus forming practical groups of settings.
The following example shows how to set the time of day and the date.
Example: “Setting the time of day“
• Press ESC to go one step back at a time, readjusted values are not be adopted
• If no setting is made for 8 minutes, the display returns automatically to the basic
display
• Operating lines may be hidden, depending on the type of controller, the configuration
made and the user level
Operation
1
2
Display example Description
AUTO
Room temperat ure
4 8 12 16 20 24
0
Basic display.
If the basic display is not shown, press
the ESC button to return to it.
Press OK.
2359Z140
AUTO
The bottom section of the display
shows a number of operating pages.
Time of day and dat e
Text3
Operator sect ion
0
4 8 12 16 20 24
Turn the setting knob until operating
page Time of day and date appears.
Press OK to confirm.
2359Z140
3
AUTO
In the bottom section of the display, the
first operating line of operating page
Hours / minutes
Time of day and d ate
4 8 12 16 20 24
0
Time of day and date appears.
Turn the setting knob until operating
line Hours / minutes appears.
2359Z140
To confirm, press OK.
4
AUTO
The display shows the hours flashing.
Turn the setting knob until the hours of
Time of day and date
Hours / mi nutes
0
4 8 12 16 20 24
the time of day are correct.
To confirm, press OK.
2359Z140
40/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
5
AUTO
The display shows the minutes
flashing.
Time of day and dat e
Hours / minut es
4 8 12 16 20 24
0
Turn the setting knob until the minutes
of the time of day are correct.
2359Z140
To confirm, press OK.
6
AUTO
The settings are saved and the
displays stops flashing.
Now, you can make further settings or
Time of da y and date
Hours / minut es
4 8 12 16 20 24
0
you press the operating mode button to
return to the basic display.
2359Z140
Example of menu
structure
7
Now, you see the basic display again.
Time of day and date
Operator section
Wireless
Time program heating circuit 1
Time program heating circuit 2
Time program heating circuit P
Holidays heating circuit 1
Diagnostics of consumers
Hours / minutes
Month / day
Year
Start of summer time
End of summer time
Hours 1...24 h
Minutes 0...60 min
5.1.3 User levels
The user levels only allow authorized user groups to make settings. To reach the
required user level, proceed as follows:
1
Operation
Display example Description
AUTO
Basic display.
If the basic display is not shown,
press the ESC button to return to it.
Room temperat ure
Press OK.
2359Z139
2
4 8 12 16 20 24
0
AUTO
2359Z140
You are on the user level Enduser.
Press the info button for 3 seconds.
Time of day and dat e
Text3
Operator sect ion
4 8 12 16 20 24
0
3
AUTO
2359Z140
You are now given a choice of user
levels.
Turn the setting knob until the
required user level is reached.
Enduser
Text3
Commissioning
4 8 12 16 20 24
0
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
2359Z140
Press OK.
41/156
Setting structure “Enduser“
AUTO
You are now on the required user
level.
Time of day and dat e
Text3
Operator sect ion
4 8 12 16 20 24
0
2359Z140
To reach the OEM level, the relevant code must be entered.
The example given here shows that certain user levels do not allow certain settings to
be made. The example shows them highlighted. On the unit, they are hidden.
Enduser
Commissioning
Heating engineer
OEM
Time of day and date
Operator section
Wireless
Time program heating circuit 1
Time program heating circuit 2
Time program heating circuit P
Holidays heating circuit 1
Diagnostics of consumers
Setting structure ”Heating engineer“
Time of day and date
Operator section
Wireless
Time program heating circuit 1
Time program heating circuit 2
Time program heating circuit P
Holidays heating circuit 1
Diagnostics of consumers
Commissioning
Hours / minutes
Month / day
Year
Start of summer time
End of summer time
Heating engineer
OEMEnduser
Hours / minutes
Month / day
Year
Start of summer time
End of summer time
Hours 1...24 h
Minutes 0...60 min
2359Z139
Hours 1...24 h
Minutes 0...60 min
235 9Z139
42/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Legend
5.1.4 Overview of settings
The table shows all available settings up to the heating engineer level. However,
certain operating lines may be hidden, depending on the type of unit.
E = enduser I = commissioning F = heating engineer
OL = operating line
Operating line
user level
Function
Time of day and date
1
2
3
5
6
E Hours / minutes
E Day / month
E Year
F Start of summertime
F End of summertime
Operator section
20
22
26
27
40
42
44
46
48
54
70
E Language
German ¦ …
F Info
Temporarily ¦ Permanently
F Operation lock
Off ¦ On
F Programming lock
Off ¦ On
I Used as
Room unit 1 ¦ Room unit 2 ¦ Room unit P ¦ Operator unit
1 ¦ Operator unit 2 ¦ Operator unit P ¦ Service unit
I Assignment device 1
Heating circuit 1 ¦ Heating circuits 1 and 2 ¦ Heating
circuits 1 and P ¦ All heating circuits
I Operation HC2
Commonly with HC1 ¦ Independently
I Operation HCP
Commonly with HC1 ¦ Independently
I Action occupancy button
None ¦ Heating circuit 1 ¦ Heating circuit 2 ¦ Commonly
F Readjustment room sensor
F Software version
RF
120
121
130
131
132
133
134
I Binding
No ¦ Yes
I Test mode
Off ¦ On
I Room unit 1
Missing ¦ Ready ¦ No recept’n ¦ Change batt
I Room unit 2
Missing ¦ Ready ¦ No recept’n ¦ Change batt
I Room unit P
Missing ¦ Ready ¦ No recept’n ¦ Change batt
I Outside sensor
Missing ¦ Ready ¦ No recept’n ¦ Change batt
I Repeater
Missing ¦ Ready ¦ No recept’n ¦ Change batt
Default value
-
- 01.01
- 2004
25.03 01.01 31.12
25.10 01.01 31.12
German
Temporarily
Off
Off
Room unit 1
Heating circuit 1
Commonly with HC1
Commonly with HC1
Heating circuit 1
0.0 -3 3
Min
max
00:00 23:59
31.12
2099
-
-
-
-
-
-
-
-
-
Unit
hh:mm
dd.MM
yyyy
dd.MM
dd.MM
°C
- 0 99.9 -
No
Off
- -
- -
- -
- -
43/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
135
136
137
138
140
user level
Function
I Operator unit 1
Missing ¦ Ready ¦ No recept’n ¦ Change batt
I Operator unit 2
Missing ¦ Ready ¦ No recept’n ¦ Change batt
I Operator unit P
Missing ¦ Ready ¦ No recept’n ¦ Change batt
I Service unit
Missing ¦ Ready ¦ No recept’n ¦ Change batt
I Delete all devices
No ¦ Yes
Time prog heating circuit 1
500
501
502
503 E
504 E
505 E
506 E
516 E
E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦ Th ¦ Fr ¦ Sa
¦Su
E 1st phase on
E 1st phase off
2nd phase on
2nd phase off
3rd phase on
3rd phase off
Default values
No ¦ Yes
Time prog heating circuit 2
520
521
522
523 E
524 E
525 E
526 E
536 E
E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦ Th ¦ Fr ¦ Sa
¦Su
E 1st phase on
E 1st phase off
2nd phase on
2nd phase off
3rd phase on
3rd phase off
Default values
No ¦ Yes
Time program 3/HCP
540
541
542
543
544 E
545 E
546 E
556 E
E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦ Th ¦ Fr ¦ Sa
¦Su
E 1st phase on
E 1st phase off
E 2nd phase on
2nd phase off
3rd phase on
3rd phase off
Default values
No ¦ Yes
Time program 4/DHW
560
561
562 E
E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦ Th ¦ Fr ¦ Sa
¦Su
E 1st phase on
1st phase off
Default value
Min
max
Unit
- -
- -
No
Mo - Su
6:00 00:00 24:00
-
-
hh:mm
22:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
No
Mo - Su
6:00 00:00 24:00
-
-
hh:mm
22:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
No
Mo - Su
6:00 00:00 24:00
22:00 00:00 24:00
-
-
hh:mm
hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
No
Mo - Su
-
-
6:00 00:00 24:00 hh:mm
22:00 00:00 24:00 hh:mm
44/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
563 E
564 E
565 E
566 E
576 E
user level
Function
2nd phase on
2nd phase off
3rd phase on
3rd phase off
Default values
No ¦ Yes
Time program 5
600
601
602
603
604 E
605 E
606 E
616 E
E Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦ Th ¦ Fr ¦ Sa
¦Su
1st phase on
1st
E 1st phase off
E 2nd phase on
2nd phase off
3rd phase on
3rd phase off
Default values
No ¦ Yes
Holidays heating circuit 1
641
642
643
648
E Preselection
Period 1 ¦ Period 2 ¦ Period 3¦ Period 4¦ Period 5¦ Period
6¦ Period 7¦ Period 8
Start
E
End
E
E Operating level
Frost protection ¦ Reduced
Holidays heating circuit 2
651
652
653
658
E Preselection
Period 1 ¦ Period 2 ¦ Period 3¦ Period 4¦ Period 5¦ Period
6¦ Period 7¦ Period 8
Start
E
End
E
E Operating level
Frost protection ¦ Reduced
Holidays heating circuit P
661
662
663
668
E Preselection
Period 1 ¦ Period 2 ¦ Period 3¦ Period 4¦ Period 5¦ Period
6¦ Period 7¦ Period 8
Start
E
End
E
E Operating level
Frost protection ¦ Reduced
Heating circuit 1
Comfort cooling setpoint
710
712
714
716
720
721
726
730
E
Reduced setpoint
E
Frost protection setpoint
E
F Comfort setpoint maximum
E Heating curve slope
F Heating curve displacement
F Heating curve adaption
Off ¦ On
E Summer/winter heating limit
Default value
Min
max
Unit
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
No
Mo - Su
6:00 00:00 24:00
22:00 00:00 24:00
-
-
hh:mm
hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
24:00 00:00 24:00 hh:mm
No
Period 1
--.-- 01.01
--.-- 01.01
Frost protection
Period 1
--.-- 01.01
--.-- 01.01
Frost protection
Period 1
--.-- 01.01
--.-- 01.01
Frost protection
20.0
16
OL 712 OL 716 °C
OL 714 OL 710 °C
10.0 4
35.0
OL 710
-
-
31.12
31.12
dd.MM
dd.MM
-
-
31.12
31.12
dd.MM
dd.MM
-
-
31.12
31.12
dd.MM
dd.MM
-
OL 712 °C
35
°C
1.50 0.10 4.00 -
0.0 -4.5 4.5
Off
-
18 − − − / 8 30
°C
°C
45/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
732
740
741
750
760
770
780
790
791
800
801
820
830
832
833
834
850
851
861
870
872
882
883
900
user level
Function
F 24-hour heating limit
I Flow temp setpoint min
I Flow temp setpoint max
F Room influence
F Room temp limitation
F Boost heating
F Quick setback
Off¦Down to reduced setpoint¦Down to frost prot setpoint
F Optimum start control max
F Optimum stop control max
F Reduced setp increase start
F Reduced setp increase end
F Overtemp prot pump circuit
Off ¦ On
F Mixing valve boost
F Actuator type
2-position ¦ 3-position
F Switching differential 2-pos
F Actuator running time
I Floor curing function
Off ¦ Functional heating ¦ Curing heating ¦ Functional /
curing heating¦ Curing/functional heating ¦ Manually
I Floor curing setp manually
F Excess heat draw
Off ¦ Heating mode ¦ Always
F With buffer storage tank
No ¦ Yes
F With primary controller / system pump
No ¦ Yes
F Pump speed min
F Pump speed max
F Optg mode changeover
None ¦ Protection ¦ Reduced ¦ Comfort ¦ Automatic
Heating circuit 2
Comfort cooling setpoint
1010
1012
1014
1016
1020
1021
1026
1030
1032
1040
1041
1050
1060
1070
1080
E
Reduced setpoint
E
Frost protection setpoint
E
F Comfort setpoint maximum
Heating curve slope
E
F Heating curve displacement
F Heating curve adaption
Off ¦ On
Summer/winter heating limit
E
F 24-hour heating limit
I Flow temp setpoint min
I Flow temp setpoint max
Room influence
F
F Room temp limitation
F Boost heating
F Quick setback
Off¦Down to reduced setpoint¦Down to frost prot setpoint
Default value
-3 − − − / -10 10
8 8
80
Min
OL 740
max
°C
OL 741 °C
95
°C
Unit
20 − − − / 1 100 %
1 − − − / 0.5 4
5 − − − / 0 20
Down to reduced setpoint
-
0 0 360
0 0 360
− − − − − − / -30 10
-15 -30
On
OL 800
-
5 0 50
3-position
-
2 0 20
120 30 873
Off
-
25 0 95
Always
Yes
Yes
-
°C
°C
min
min
°C
°C
°C
°C
s
°C
100 0 100 %
100 0 100 %
Protection
20.0
16
10.0 4
35.0
OL 1012 OL 1016 °C
OL 1014 OL 1010 °C
OL 1012 °C
OL 1010
35
°C
1.50 0.10 4.00 -
0.0 -4.5 4.5
Off
-
18 − − − / 8 30
-3 − − − / -10 10
8 8
80
20
OL 1040
− − − / 1 100 %
OL 1041 °C
95
1 − − − / 0.5 4
5 − − − / 0 20
Down to reduced setpoint
-
°C
°C
°C
°C
°C
°C
46/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
1090
1091
1100
1101
1120
1130
1132
1133
1134
1150
1151
1161
1170
1172
1182
1183
1200
user level
Function
F Optimum start control max
F Optimum stop control max
F Reduced setp increase start
F Reduced setp increase end
F Overtemp prot pump circuit
Off ¦ On
F Mixing valve boost
F Actuator type
2-position ¦ 3-position
F Switching differential 2-pos
F Actuator running time
F Floor curing function
Off ¦ Functional heating ¦ Curing heating ¦ Functional /
curing heating¦ Curing/functional heating ¦ Manually
Floor curing setp manually
F
F Excess heat draw
Off ¦ Heating mode ¦ Always
F With buffer storage tank
No ¦ Yes
F With primary controller / system pump
No ¦ Yes
F Pump speed min
F Pump speed max
F Optg mode changeover
None ¦ Protection ¦ Reduced ¦ Comfort ¦ Automatic
Heating circuit P
1300
1310
1312
1314
1316
1320
1321
1326
1330
1332
1340
1341
1350
1360
1370
1380
1390
1391
1400
1401
1420
E Operating mode
Protection ¦ Automatic ¦ Reduced ¦ Comfort
Comfort cooling setpoint
E
Reduced setpoint
E
Frost protection setpoint
E
F Comfort setpoint maximum
E Heating curve slope
F Heating curve displacement
F Heating curve adaption
Off ¦ On
E Summer/winter heating limit
F 24-hour heating limit
F Flow temp setpoint min
F Flow temp setpoint max
F Room influence
F Room temp limitation
F Boost heating
F Quick setback
Off¦Down to reduced setpoint¦Down to frost prot setpoint
F Optimum start control max
F Optimum stop control max
F Reduced setp increase start
F Reduced setp increase end
F Overtemp prot pump circuit
Off ¦ On
Default value
0 0 360
0 0 360
− − − − − − / -30 10
-15 -30
On
5 0 50
3-position
2 0 20
120 30 873
Off
25 0 95
Always
Yes
Yes
Min
max
Unit
min
min
°C
OL 1100
°C
-
°C
-
°C
s
-
°C
-
100 0 100 %
100 0 100 %
Protection
Automatically
20.0
16
OL 1312 OL 1016 °C
OL 1314 OL 1310 °C
10.0 4
35.0
OL 1310
-
OL 1312 °C
35
°C
1.50 0.10 4.00 -
0.0 -4.5 4.5
Off
-
18 − − − / 8 30
-3 − − − / -10 10
8 8
80
OL 1340
OL 1341 °C
95
°C
°C
°C
°C
20 − − − / 1 100 %
1 − − − / 0.5 4
5 − − − / 0 20
Down to reduced setpoint
-
0 0 360
0 0 360
− − − − − − / -30 10
-15 -30
On
OL 1400
-
°C
°C
min
min
°C
°C
47/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
1450
1451
1455
1456
1461
1470
1172
user level
I Floor curing function
I Floor curing setp manually
F Floor curing setp current
F Floor curing day current
F Excess heat draw
F With buffer storage tank
F With primary controller / system pump
1482 F
1483
1500
F Pump speed max
F Optg mode changeover
DHW
1610
1612
1620
1630
1640
1641
1642
1644
1645
1646
1647
1660
1661
1663
E
F Reduced setpoint
I Release
I Charging priority
F Legionella function
F Legionella funct periodically
F Legionella funct weekday
F Legionella function time
F Legionella funct setpoint
F Legionella function dwelling time
F Legionella funct circ pump
F Circulating pump release
F Circulating pump cycling
F Circulation setpoint
Pump H1/H2
2010
2012
2014
2035
2037
2039
F H1 Excess heat draw
F H1 with buffer storage tank
F H1 prim contr/system pump
F H2 Excess heat draw
F H2 with buffer storage tank
F H2 prim contr/system pump
Function
Off ¦ Functional heating ¦ Curing heating ¦ Functional /
curing heating¦ Curing/functional heating ¦ Manually
Off ¦ Heating mode ¦ Always
No ¦ Yes
Nein ¦ Ja
Pump speed min
None ¦ Protection ¦ Reduced ¦ Comfort ¦ Automatic
Nominal setpoint
24h/day ¦ Time programs HCs ¦ Time program 4/DHW
Absolute ¦ Shifting ¦ None ¦ MC shifting, PC absolute
Off ¦ Periodically ¦ Fixed weekday
Monday ¦ Tuesday ¦ Wednesday ¦ Thursday ¦ Friday ¦
Saturday ¦ Sunday
Off ¦ On
Time program 3/HCP ¦ DHW release ¦ Time program
4/DHW¦ Time program 5
Off ¦ On
Off ¦ On
No ¦ Yes
No ¦ Yes
Off ¦ On
No ¦ Yes
No ¦ Yes
Default value
Off
25 0 95
0 0 95
0 0 32
Always
Yes
Min
max
Unit
-
°C
°C
°C
-
Ja
100 0 100 %
100 0 100 %
Protection
55
OL 1612 OL 1614 OEM °C
40 8
Time programs HCs
MC shifting, PC absolute
Fixed weekday
3 1 7
Monday
− − − − − − / 00:00 23:50
65 55 95
30
− − − / 10 360
On
DHW release
On
45 8 80
On
Yes
Yes
On
Yes
Yes
OL 1610 °C
-
-
-
Days
hh:mm
°C
min
-
-
-
°C
-
-
-
-
48/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
2046
2048 F
2050
user level
Function
F H3 Excess heat draw
Off ¦ On
H3 with buffer
No ¦ Yes
F H2 prim contr/system pump
No ¦ Yes
Swimming pool
2055
2056
2065
2080
F Setpoint solar heating
F Setpoint source heating
F Charging priority solar
No ¦ Yes
F With solar integration
No ¦ Yes
Primary controller / system pump
2150
I Primary controller / system pump
Before buffer st tank ¦ After buffer st tank
Boiler
2203
2205
2208 F
2210
2212
2270
2330
2331
2340
F Release below outside temp
F In economy mode
Off ¦ Only DHW ¦ On
Full charging buffer
Off ¦ On
F Setpoint min
F Setpoint max
F Return setpoint min
F Output nominal
F Output basic stage
F Auto source seq 2x1 casc
Cascade
3532
3533
3540
3541
3544
3560
F Restart lock
F Switch-on delay
F Auto source seq ch’over
F Auto source seq exclusion
None ¦ First ¦ Last ¦ First and last
F Leading source
Source 1 ¦ Source 2 ¦ … ¦ Source 16
F Return setpoint min
Solar
3810
3811
3812
3815
3818
3822
3825
3826
3827
3828
F Temp diff on
F Temp diff off
F Charg temp min DHW st tank
F Charging temp min buffer
F Charging temp min swi pool
F Charging prio storage tank
None ¦ DHW storage tank ¦ Buffer
F Charging time relative prio
F Waiting time relative prio
F Waiting time parallel op
F Delay secondary pump
Default value
On
Yes
Yes
Min
max
26 8 80
22 8 80
No
Yes
After buffer st tank
-
− − − − − − / -50 50
Off
Off
40
OL 2211 OEM Setpoint manual
operation
80
Setpoint manual
OL 2213 OEM °C
operation
8 8 95
50 0 1000
30 0 1000
500 − − − / 10 990
300 0 1800
5 0 120
500 − − − / 10 990
None
Source 1
8 8 95
8 0 40
4 0 40
− − − − − − / 8 95
− − − − − − / 8 95
− − − − − − / 8 95
DHW storage tank
− − − − − − / 2 60
5 1 40
− − − − − − / 0 40
60 0 600
Unit
°C
°C
°C
°C
°C
kW
kW
h
s
min
h
°C
°C
°C
°C
°C
°C
min
min
min
s
49/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
3830
3831
3840
3850
3860
3870
3871
3880
3881
3884
user level
Function
F Collector start function
F Min run time collector pump
F Collector frost protection
F Collector overtemp prot
F Evaporation heat carrier
F Pump speed min
F Pump speed max
F Antifreeze
None ¦ Ethylene glycol ¦ ¦ Propylene glycol ¦ Ethyl and
propyl glycol
F Antifreeze concentration
F Pump capacity
Solid fuel boiler
4102
4110
4130
4131
4133
F Locking other heat sources
Off ¦ On
F Setpoint min
F Temp diff on
F Temp diff off
F Comparative temp
DHW sensor B3 ¦ DHW sensor B31 ¦ Buff st tank sensor
B4 ¦ Buff st tank sensor B41 ¦ Flow temp setpoint ¦
Setpoint min
Buffer storage tank
4720
4722
4724
4750
4755
4756
4757
4783
4790
4791
4795
4796
4800
4810 F
4811
4813
F Auto generation lock
None ¦ With B4 ¦ With B4 and B42/B41
F Temp diff buffer/HC
F Min st tank temp heat mode
F Charging temperature max
F Recooling temp
F Recooling DHW/HCs
Off ¦ On
F Recooling collector
Off ¦ Summer ¦ Always
F With solar integration
No ¦ Yes
F Temp diff on return div
F Temp diff off return div
F Compar temp return div
B4 ¦ B41 ¦ B42
F Optg action return diversion
Temp decrease ¦ Temp increase
F Partial charging setpoint
Full charging
Off ¦ Heating mode ¦ Always
F Full charging temp min
F Full charging sensor
With B4 ¦ With B42/B41
DHW storage tank
5020
5021
5022
F Flow setpoint boost
F Increase of transfer boost
F Type of charging
With B3 and B31 ¦ With B3, legio B3 and B31
Default value
− − − − − − / 5 60
20 5 120
− − − − − − / -20 5
− − − − − − / 30 350
− − − − − − / 60 350
Min
max
Unit
min
s
°C
°C
°C
40 0 100 %
100 0 100 %
None
30 1 100 %
200 10 1500
Off
40 8 120
8 1 40
4 0 40
Setpoint min
With B4
-
-5 -20 20
− − − − − − / 8 95
80 8 95
60 8 95
Off
Off
No
10 0 40
5 0 40
B42
Temperature increase
l/h
°C
°C
°C
°C
°C
°C
°C
°C
°C
− − − − − − / 8 95 °C
8 8 80
With B42/B41
16 0 30
8 0 30
With B3 and B31
°C
°C
°C
50/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
5050
5055
5056
5057
5060
5061
5062
5085
5090
5092
5093
5101
5102
user level
Function
F Charging temperature max
F Recooling temp
F Recooling heat gen/HCs
Off ¦ On
F Recooling collector
Off ¦ Summer ¦ Always
F Electric immersion heater operating mode
Substitute ¦ Summer ¦ Always
F Electric immersion heater release
24h/day ¦ DHW release¦ Time program4/ DHW
F El immersion heater control
External thermostat ¦ DHW sensor
F Excess heat draw
Off ¦ On
F With buffer storage tank
No ¦ Yes
F With primary controller / system pump
No ¦ Yes
F With solar integration
No ¦ Yes
F Pump speed min
F Pump speed max
Instantaneous DHW heater
5406
5544
F Min setp diff to tank temp
F Actuator running time
Configuration
5710
5715
5730
5731
5736
5770
5840 I
5841
5890
I Heating circuit 1
Off ¦ On
I Heating circuit 2
Off ¦ On
I DHW sensor B3
Sensor ¦ Thermostat
I DHW controlling element Q3
None ¦ Charging pump ¦ Diverting valve
I Separate circuit
Off ¦ On
I Source type
1-stage ¦ 2-stage ¦ Modulating 3-position ¦ Modulating
UX ¦ Without boiler sensor ¦ 2x1 cascade
Solar controlling element
Charging pump ¦ Diverting valve
I External solar exchanger
Common ¦ DHW storage tank ¦ Buffer
I Relay output QX1
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦
Collector pump Q5 ¦ H1 pump Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed
HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump speed
HCP Q23 ¦ Heating circuit pump HCP Q20 ¦ H pump Q18
¦ System pump Q14 ¦ Heat en shutoff valve Y4 ¦ Solid
fuel boiler pump Q10
return valve Y15
elem buffer K8
pump 2 Q16
Assisted firing fan K30 ¦ Cascade pump Q25 ¦ St tank
transfer pump Q11
intern circ pump Q33
¦ Solar pump ext exch K9 ¦ Solar ctrl
¦ Solar ctrl elem swi pool K18 ¦ Collector
¦ H3 pump Q19 ¦ Flue gas relay K17 ¦
¦Time program 5 K13 ¦ Buffer
¦ DHW mixing pump Q35 ¦ DHW
¦ Heat request K27
Default value
80 8
80 8 95
Off
Off
Substitute
DHW release
DHW sensor
On
No
No
Yes
Min
max
Unit
OL 5051 OEM °C
°C
-
-
-
-
-
-
40 0 100 %
100 0 100 %
4 0 20
60 7.5 480
On
On
Sensors
Charging pump
Off
-
-
-
-
-
°C
s
2-stufig -
Charging pump
Common
None
-
51/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
5891
5892
5894
5930
5931
user level
Function
I Relay output QX2
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦
Collector pump Q5 ¦ H1 pump Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed
HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump
speed HCP Q23 ¦ Heating circuit pump HCP Q20 ¦ H
pump Q18 ¦ System pump Q14 ¦ Heat en shutoff valve
Y4 ¦ Solid fuel boiler pump Q10 ¦Time program 5
K13
¦ Buffer return valve Y15 ¦ Solar pump ext exch
K9
¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18
¦ Collector pump 2 Q16 ¦ H3 pump Q19 ¦ Flue
gas relay K17
pump Q25
pump Q35
request K27
¦ Assisted firing fan K30 ¦ Cascade
¦ St tank transfer pump Q11 ¦ DHW mixing
¦ DHW intern circ pump Q33 ¦ Heat
I Relay output QX3
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦
Collector pump Q5 ¦ H1 pump Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed
HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump
speed HCP Q23 ¦ Heating circuit pump HCP Q20 ¦ H
pump Q18 ¦ System pump Q14 ¦ Heat en shutoff valve
Y4 ¦ Solid fuel boiler pump Q10 ¦Time program 5
K13
¦ Buffer return valve Y15 ¦ Solar pump ext exch
K9
¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18
¦ Collector pump 2 Q16 ¦ H3 pump Q19 ¦ Flue
gas relay K17
pump Q25
pump Q35
request K27
¦ Assisted firing fan K30 ¦ Cascade
¦ St tank transfer pump Q11 ¦ DHW mixing
¦ DHW intern circ pump Q33 ¦ Heat
I Relay output QX4
None ¦ Circulating pump Q4 ¦ El imm heater DHW K6 ¦
Collector pump Q5 ¦ H1 pump Q15 ¦ Boiler pump Q1 ¦
Bypass pump Q12 ¦ Alarm output K10 ¦ 2nd pump speed
HC1 Q21 ¦ 2nd pump speed HC2 Q22 ¦ 2nd pump
speed HCP Q23 ¦ Heating circuit pump HCP Q20 ¦ H
pump Q18 ¦ System pump Q14 ¦ Heat en shutoff valve
Solid fuel boiler pump Q10 ¦Time program 5
Y4 ¦
K13
¦ Buffer return valve Y15 ¦ Solar pump ext exch
K9
¦ Solar ctrl elem buffer K8 ¦ Solar ctrl elem swi pool
K18
¦ Collector pump 2 Q16 ¦ H3 pump Q19 ¦ Flue
gas relay K17
pump Q25
pump Q35
request K27
¦ Assisted firing fan K30 ¦ Cascade
¦ St tank transfer pump Q11 ¦ DHW mixing
¦ DHW intern circ pump Q33 ¦ Heat
I Sensor input BX1
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ Return
sensor B7 ¦ DHW circulation sensor B39 ¦ Buffer sensor
B4 ¦ Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦
DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor
B70 ¦ Swimming pool sensor B13 ¦ Collector sensor 2
B61 ¦ Solar flow sensor B63 ¦ Solar return sensor B64
I Sensor input BX2
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ Return
sensor B7 ¦ DHW circulation sensor B39 ¦ Buffer sensor
B4 ¦ Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦
DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor
B70 ¦ Swimming pool sensor B13 ¦ Collector sensor 2
B61 ¦ Solar flow sensor B63 ¦ Solar return sensor B64
Default value
None
None
None
None
None
Min
max
Unit
-
-
-
52/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
5932
5933
5950
5951
5952
5954
5956
5960
5961
5962
5964
5966
5982
5983
6014
user level
Function
I Sensor input BX3
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ Return
sensor B7 ¦ DHW circulation sensor B39 ¦ Buffer sensor
B4 ¦ Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦
DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor
B70 ¦ Swimming pool sensor B13 ¦ Collector sensor 2
B61 ¦ Solar flow sensor B63 ¦ Solar return sensor B64
I Sensor input BX4
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ Return
sensor B7 ¦ DHW circulation sensor B39 ¦ Buffer sensor
B4 ¦ Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦
DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor
B70 ¦ Swimming pool sensor B13 ¦ Collector sensor 2
B61 ¦ Solar flow sensor B63 ¦ Solar return sensor B64
I Function input H1
Optg mode changeover HCs+DHW ¦ Optg mode
changeover HCs ¦ Optg mode changeover HC1 ¦ Optg
mode changeover HC2 ¦ Optg mode changeover HCP ¦
Heat generation lock ¦ Error/alarm message ¦ Min flow
emp setpoint ¦ Excess heat discharge ¦ Release
swimming pool ¦ Heat request 10V ¦ Pressure
measurement 10V
I Contact type H1
NC ¦ NO
I Min flow temp setpoint H1
I Temp value 10V H1
I Pressure value 3.5V H1
I Function input H3
Optg mode changeover HCs+DHW ¦ Optg mode
changeover HCs ¦ Optg mode changeover HC1 ¦ Optg
mode changeover HC2 ¦ Optg mode changeover HCP ¦
Heat generation lock ¦ Error/alarm message ¦ Min flow
emp setpoint ¦ Excess heat discharge ¦ Release
swimming pool ¦ Heat request 10V ¦ Pressure
measurement 10V
I Contact type H3
NC ¦ NO
I Min flow temp setpoint H3
I Temp value 10V H3
I Pressure value 3.5V H3
I Function input EX2
Counter 2nd burner stage ¦ Heat generation lock ¦
Error/alarm message ¦ SLT error message ¦ Excess heat
discharge
I Cont type input EX2
NC ¦ NO
I Function mixing group 1
Heating circuit 1 ¦ Return temp controller ¦ Prim
contr/system pump ¦ DHW primary controller ¦
Instantaneous DHW heater ¦ Return controller cascade
Default value
None
None
Optg mode changeover
Min
max
-
HCs+DHW
NO
70 8 120
100 5 130
5.0 0.0 10.0
Optg mode changeover
-
HCs+DHW
NO
70 8 120
100 5 130
5.0 0.0 10.0
Counter for second burner
-
stage
NO
Heating circuit
-
-
Unit
-
°C
°C
bar
-
°C
°C
bar
53/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
6015
6020
6021
6030
6031
6032
6040
user level
Function
I Function mixing group 2
Heating circuit 2 ¦ Return temp controller ¦ Prim
contr/system pump ¦ DHW primary controller ¦
Instantaneous DHW heater ¦ Return controller cascade
I Function extension module 1
None ¦ Multifunctional ¦ Heating circuit 2 ¦ Return temp
controller ¦ Solar DHW ¦ Prim contr/system pump ¦ DHW
primary controller ¦ Instantaneous DHW heater ¦ Return
controller cascade
I Function extension module 2
None ¦ Multifunctional ¦ Heating circuit 2 ¦ Return temp
controller ¦ Solar DHW ¦ Prim contr/system pump ¦ DHW
primary controller ¦ Instantaneous DHW heater ¦ Return
controller cascade
I Relay output QX21
None ¦ Circulating pump Q4 ¦
El imm heater DHW K6 ¦ Collector pump Q5 ¦ H1 pump
Q15 ¦ Boiler pump Q1 ¦ Bypass pump Q12 ¦ Alarm
output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
speed HC2 Q22 ¦ 2nd pump speed HCP Q23 ¦ Heat
circuit pump HCP Q20 ¦ H2 pump Q18 ¦ System pump
Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦
Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦
Solar ctrl elem swi pool K18 ¦ Collector pump 2 Q16 ¦ H3
pump Q19 ¦ Flue gas relay K17 ¦ Assisted firing fan K30
¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦
DHW mixing pump Q35 ¦ DHW inerm circ pump Q33 ¦
Heat request K27
I Relay output QX22
None ¦ Circulating pump Q4 ¦
El imm heater DHW K6 ¦ Collector pump Q5 ¦ H1 pump
Q15 ¦ Boiler pump Q1 ¦ Bypass pump Q12 ¦ Alarm
output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
speed HC2 Q22 ¦ 2nd pump speed HCP Q23 ¦ Heat
circuit pump HCP Q20 ¦ H2 pump Q18 ¦ System pump
Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦
Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦
Solar ctrl elem swi pool K18 ¦ Collector pump 2 Q16 ¦ H3
pump Q19 ¦ Flue gas relay K17 ¦ Assisted firing fan K30
¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦
DHW mixing pump Q35 ¦ DHW interm circ pump Q33 ¦
Heat request K27
I Relay output QX23
None ¦ Circulating pump Q4 ¦
El imm heater DHW K6 ¦ Collector pump Q5 ¦ H1 pump
Q15 ¦ Boiler pump Q1 ¦ Bypass pump Q12 ¦ Alarm
output K10 ¦ 2nd pump speed HC1 Q21 ¦ 2nd pump
speed HC2 Q22 ¦ 2nd pump speed HCP Q23 ¦ Heat
circuit pump HCP Q20 ¦ H2 pump Q18 ¦ System pump
Q14 ¦ Heat gen shutoff valve Y4 ¦ Solid fuel boiler pump
Q10 ¦ Time program 5 K13 ¦ Buffer return valve Y15 ¦
Solar pump ext exch K9 ¦ Solar ctrl elem buffer K8 ¦
Solar ctrl elem swi pool K18 ¦ Collector pump 2 Q16 ¦ H3
pump Q19 ¦ Flue gas relay K17 ¦ Assisted firing fan K30
¦ Cascade pump Q25 ¦ St tank transfer pump Q11 ¦
DHW mixing pump Q35 ¦ DHW interm circ pump Q33 ¦
Heat request K27
I Sensor input BX21
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ Return
sensor B7 ¦ DHW circulation sensor B39 ¦ Buffer sensor
Default value
Min
max
Unit
None
None
None
None
None
-
-
Kein
54/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
6041 I
6046
6047
6048
6050
6052
6070
6071
6075
6097
6098
6099
6100
6101
6102
6110
6120
6128
6129
6131
6200
I Function input H2
I Contact type H2
I Min flow temp setpoint H2
I Temp value 10V H2
I Pressure value 3.5V H2
I Function output UX
I Signal logic output UX
I Temp value 10V UX
F Sensor type collector
F Readjustm collector sensor
F Readjustm coll sensor 2
F Readjustm outside sensor
F Sensor type flue gas temp
F Readjustm flue gas sensor
F Time constant building
F Frost protection for the plant
F Heat request below OT
F Heat request above OT
F Heat req in economy mode
I Sensors saving
user level
Function
B4 ¦ Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦
DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor
B70 ¦ Swimming pool sensor B13 ¦ Collector sensor 2
B61 ¦ Solar flow sensor B63 ¦ Solar return sensor B64
Sensor input BX22
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦ Return
sensor B7 ¦ DHW circulation sensor B39 ¦ Buffer sensor
B4 ¦ Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor B22 ¦
DHW charging sensor B36 ¦ Buffer sensor B42 ¦
Common return sensor B73 ¦ Cascade return sensor
B70 ¦ Swimming pool sensor B13 ¦ Collector sensor 2
B61 ¦ Solar flow sensor B63 ¦ Solar return sensor B64
Optg mode change HCs+DHW ¦ Optg mode changeover
HCs ¦ Optg mode changeover HC1 ¦ Optg mode
changeover HC2 ¦ Optg mode changeover HCP ¦ Heat
generation lock ¦ Error/alarm message ¦ Min flow temp
setpoint ¦ Excess heat discharge ¦ Release swimming
pool ¦ Heat request 10V ¦ Pressure measurement 10V
NC ¦ NO
None ¦ Boiler pump Q1 ¦ DHW pump Q3 ¦ DHW interm
circ pump Q33 ¦ Heat circ pump HC1 Q2 ¦ Heat circ
pump HC2 Q6 ¦ Heat circ pump HCP Q20 ¦ Collector
pump Q5 ¦ Solar pump ext exch K9 ¦ Solar pump buffer
K8 ¦ Solar pump swi pool K18 ¦ Collector pump 2 Q16 ¦
Boiler setpoint ¦ Output setpoint ¦ Heat request
Standard ¦ Inverted
NTC 10k ¦ Platinum 1000
NTC 10k ¦ Platinum 1000
Off ¦ On
Off ¦ Only DHW ¦ On
No ¦ Yes
Default value
None
Optg mode changeover
Min
max
HCs+DHW
NO
-
70 8 120
100 5 130
5.0 0.0 10.0
None
Standard
100 5 130
NTC 10k
0 -20 20
0 -20 20
0.0 -3.0 3.0
NTC 10k
0 -20 20
15 0 50
Off
-
− − − − − − / -50 50
− − − − − − / -50 50
Off
No
-
Unit
°C
°C
bar
°C
°C
°C
°C
°C
h
°C
°C
55/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
6205
6212
6213
6215
6217
6220
user level
F Reset to default parameters
I Check no. heat source 1
I Check no. heat source 2
I Check no. storage tank
I Check no. heating circuits
F Software version
LPB system
6600
6601
6604
6605
6620
6621
6623
6624
6625
6631
6640
6650
I Device address
F Segment address
F Bus power supply function
F Bus power supply state
F Action changeover functions
F Summer changeover
F Optg mode changeover
F Manual source lock
F Assignment of DHW heating
F Ext source with eco mode
I Clock mode
F Outside temp source
Errors
6710
6740
6741
6743
6800
6802
6804
6806
6808
6810
6812
I
F Flow temp 1 alarm
F Flow temp 2 alarm
F Boiler temp alarm
F History 1
F Error code 1
F History 2
F Error code 2
F History 3
F Error code 3
F History 4
F Error code 4
F History 5
F Error code 5
F History 6
F Error code 6
F History 7
F Error code 7
Function
No ¦ Yes
Off ¦ Automatically
Off ¦ On
Segment ¦ System
Locally¦ Centrally
Locally¦ Centrally
Locally ¦ Segment
Local HCs ¦ All HCs in segment ¦ All HCs in system
Off ¦ On DHW ¦ On
Autonomously ¦ Slave without remote ¦ Slave with
remote setting ¦ Master
Reset alarm relay
No ¦ Yes
Default value
No
Min
max
-
Unit
- 0 199999 -
- 0 199999 -
- 0 199999 -
- 0 199999 -
- 0 99.9 -
1 0 16 0 0 14 Automatically
On
System
Locally
Centrally
Locally
All HCs in system
Off
Autonomously
-
-
-
-
-
-
0 0 239 -
No
− − − − − − / 10 240
− − − − − − / 10 240
− − − − − − / 10 240
-
min
min
min
-
- 0 255 -
-
- 0 255 -
-
- 0 255 -
-
- 0 255 -
-
- 0 255 -
-
- 0 255 -
-
- 0 255 -
56/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
6814
6816
6818
user level
Function
F History 8
F Error code 8
F History 9
F Error code 9
F History 10
F Error code 10
Maintenance / special operation
7040
7041
7042
7043
7044
7045
7053
7054
7130
7139
7140
7150
7170
F Burner hours interval
F Burner hrs since maintenance
F Burner start interval
F Burn starts since maint
F Maintenance interval
F Time since maintenance
F Flue gas temp limit
F Delay flue gas message
Chimney sweep function
E
Off ¦ On
Economy mode
E
Off ¦ On
Manual operation
E
Off ¦ On
I Simulation outside temperature
I Telephone customer service
Input / output test
7700
7710
7711
7730
7732
7734
7750
7760
7820
7821
7822
7823
7830
7831
7832
7833
7840
I Relay test
No test ¦ Everything off ¦ 1st burner stage T2 ¦ 1st + 2nd
burn stage T2/QX4 ¦ DHW pump Q3 ¦ Heating circuit
pump Q2 ¦ Heat circ mix valve op Y1 ¦ Heat circ mix
valve cl Y2 ¦ Heating circuit pump Q6 ¦ Heat circ mix
valve op Y5 ¦ Heat circ mix valve cl Y6 ¦ Relay output
QX1 ¦ Relay output QX2 ¦ Relay output QX3 ¦ Relay
output QX4 ¦ Relay output QX21 module 1 ¦ Relay
output QX22 module 1 ¦ Relay output QX23 module 1 ¦
Relay output QX21 module 2 ¦ Relay output QX22
module 2 ¦ Relay output QX23 module 2
I Output test UX
I Voltage signal UX
I Outside temp B9
I Flow temp B1
I Flow temp B12
I DHW temp B3
I Boiler temp B2
Sensor temp BX1
I
Sensor temp BX2
I
I Sensor temp BX3
I Sensor temp BX4
I Sensor temp BX21 module 1
I Sensor temp BX22 module 1
I Sensor temp BX21 module 2
I Sensor temp BX22 module 2
I Voltage signal H1
Default value
Min
max
Unit
-
- 0 255 -
-
- 0 255 -
-
- 0 255 -
− − − − − − / 10 10000
0 0 10000
h
h
− − − − − − / 60 65535 -
0 0 65535 -
− − − − − − / 1 240
0 0 240
− − − − − − / 0 350
0 0 120
Off
Off
Off
-
-
- -50.0 50
Months
Months
°C
min
°C
-
No test
-
- 0 100 %
0 0 10
- -50.0 50
- 0.0 140
- 0.0 140
- 0.0 140
- 0.0 140
- -28 350
- -28 350
- -28 350
- -28 350
- -28 350
- -28 350
- -28 350
- -28 350
- 0 10
Volt
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
Volt
57/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
7841
7845
7846
7854
7855
7870
7881
7912
user level
Function
I Contact state H1
Open ¦ Closed
I Voltage signal H2
I Contact state H2
Open ¦ Closed
I Voltage signal H3
I Contact state H3
Open ¦ Closed
I Burner fault S3
0V ¦ 230V
I 1st burner stage E1
0V ¦ 230V
I Input EX2
0V ¦ 230V
State
8000
8001
8002
8003
8005
8007
8008
8010
8011
I State of heating circuit 1
I State of heating circuit 2
I State heating circuit P
I State of DHW
I State of boiler
I State of solar
I State solid fuel boiler
I State buffer storage tank
I State swimming pool
Diagnostics cascade
8100
I Priority source 1…16
to
8130
8101
to
8131
8138
8139
8140
8141
8150
I State source 1...16
Missing ¦ Faulty ¦ Manual control active ¦ Heat
generation lock active ¦ Chimney sweep funct active ¦
Separate DHW circuit active ¦ Outside temp limit active ¦
Not released ¦ Released
I Cascade flow temp
I Cascade flow temp setpoint
I Cascade return temp
I Cascade return temp setp
I Source seq ch’over current
Diagnostics of heat source
8300
8301
8308
8310
8311
8312
8314
8316
8315
8316
I 1st burner stage T2
Off ¦ On
I 2nd burner stage
Off ¦ On
F Boiler pump speed
I Boiler temperature
I Boiler setpoint
I Boiler switching point
I Boiler return temp
I Flue gas temp
I Boiler return temp setpoint
I Flue gas temp
Default value
Min
max
Unit
- -
0 0 10
°C
- -
0 0 10
Volt
-
- -
-
-
- -
- -
- -
- -
- -
- -
-
-
-
0 0 140
0 0 140
0 0 140
0 0 140
0 0 990
°C
°C
°C
°C
h
- -
- -
0 0 100 %
- 0.0 140.0
- 0.0 140.0
0 0 140
- 0.0 140.0
0 0 350
0 0 140
0 0 350
°C
°C
°C
°C
°C
°C
°C
58/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
8318
8326
8330
8331
8332
8333
8505
8506
8507
8508
8510
8511
8512
8513
8514
8515
8519 I
8520
8526
8527
8530
8531
8543
8547
8548
8549
8550
8551
8552
8560
8570
user level
Function
I Flue gas temp max
I Burner modulation
F Hours run 1st stage
F Start counter 1st stage
F Hours run 2nd stage
F Start counter 2nd stage
F Speed collector pump 1
F Speed solar pump ext exch
F Speed solar pump buffer
F Speed solar pump swi pool
I Collector temp 1
I Collector temp 1 max
I Collector temp 1 min
I dT collector 1/DHW
I dT collector 1/buffer
I dt collector 1/swimming pool
Solar flow temp
I Solar return temp
E 24-hour yield solar energy
E Total yield solar energy
F Hours run solar yield
F Hours run collect overtemp
F Speed collector pump 2
I Collector temp 2
I Collector temp 2 max
I Collector temp 2 min
I dT collector 2/DHW
I dT collector 2/buffer
I dt collector 2/swimming pool
Solid fuel boiler temp
E Hours run solid fuel boiler
Default value
0 0 350
Min
max
°C
0 0 100 %
0 0 65535
h
- 0 199'999 0 0 65535
h
0 0 199999 0 0 100 %
0 0 100 %
0 0 100 %
0 0 100 %
- -28.0 350
0 -28.0 350
0 -28.0 350
- -168.0 350
- -168.0 350
°C
°C
°C
°C
°C
0 -168.0 350 °C
0 -28.0 350
0 -28.0 350
0 0 999.9
0 0 9999999.9
- 00:00 15:00
- 00:00 15:00
°C
°C
kWh
kWh
h
h
0 0 100 %
0 -28 350
-28 -28 350
3500 -28 350
0 -168 350
0 -168 350
0 -168 350
0 0 140
0 00:00 15:00
°C
°C
°C
°C
°C
°C
°C
h
Diagnostics consumers
8700
8703
8704
8730
8731
8732
8735
8740
I Outside temperature
I Outside temp attenuated
I Outside temperature composite
I Heating circuit pump Q2
Off ¦ On
I Heating circ mix valve op Y1
Off ¦ On
I Heat circ mix valve cl Y2
Off ¦ On
F Speed heating circuit pump 1
Raumtemperatur 1
I
- -50.0 50.0
- -50.0 50.0
- -50.0 50.0
- -
- -
- -
0 0 100 %
- 0.0 50.0 °C
°C
°C
°C
8741 I Raumsollwert 1 - 4.0 35.0 °C
8743 I Vorlauftemperatur 1 - 0.0 140.0 °C
8744 I Vorlaufsollwert 1 - 0.0 140.0 °C
8760 I
Heating circuit pump 2
Off ¦ On
- -
Unit
59/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
8761 I
8762 I
8765 F
8770 I
8771
8773
8774
8795
8800
8801
8803
8820
8825
8826
8830
8831
8832
8835
8836
8850
8851
8852
8853
8900
8901
8930
8931
8950
8951
8952
8962
8980
8981
8982
8983
9000
9001
9004
9005
9006
9009
9031
9032
I Room setpoint 2
I Flow temperature 2
I Flow temp setpoint 2
F Speed heating circuit pump B
I
I Room setpoint P
I Flow temp setpoint P
I DHW pump Q3
F Speed DHW pump
F Speed DHW interm circ pump
I DHW temp 1
I DHW temp setpoint
I DHW temp 2
I DHW circulation temp
I DHW charging temp
I DHW primary controller temp
I DHW primary controller setp
I Instant DHW heater temp
I Instant DHW heater setpoint
I Swimming pool temp
I Swimming pool setpoint
I Primary controller temp
I Primary controller setpoint
I Common flow temp
I Common flow temp setpoint
I Common return temp
I Common output setpoint
I Buffer temp 1
I Buffer setpoint
I Buffer temp 2
I Buffer temp 3
I Flow temperature setpoint H1
I Flow temp setpoint H2
I Flow temp setpoint H3
I Water pressure H1
I Water pressure H2
I Water pressure H3
I Relay output QX1
I Relay output QX2
user level
Function
Heat circ mix valve 2 open
Off ¦ On
Heat circ mix valve 2 close
Off ¦ On
Speed heating circuit pump 2
Room temp 2
Room temp P
Off ¦ On
Off ¦ On
Off ¦ On
Default value
Min
max
Unit
- -
- -
0 0 100 %
- 0.0 50
- 4.0 35
- 0.0 140
- 0.0 140
°C
°C
°C
°C
0 0 100 %
- 0.0 50
- 4.0 35
- 0.0 140
°C
°C
°C
- -
0 0 100 %
0 0 100 %
- 0.0 140
- 8.0 80
- 0.0 140
- 0.0 140
0 0 140
0 0 140
0 0 140
0 0 140
0 0 140
0 0 140
24 8 80
- 0.0 140.0
- 0.0 140.0
- 0.0 140.0
- 0.0 140.0
0 0 140
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
0 0 100 %
- 0.0 140.0
0 0 140
- 0.0 140.0
0 0 140
- 5.0 130.0
- 5.0 130.0
8 8 120
- 0.0 10.0
- 0.0 10.0
0 0 10
°C
°C
°C
°C
°C
°C
°C
bar
bar
bar
- -
- -
60/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating line
9033
I Relay output QX3
9034
9050
9051
9052
9053
9054
9055
I Relay output QX21 module 1
I Relay output QX22 module 1
I Relay output QX23 module 1
I Relay output QX21 module 2
I Relay output QX22 module 2
I Relay output QX23 module 2
user level
Function
Off ¦ On
Relay output QX4
Off ¦ On
Off ¦ On
Off ¦ On
Off ¦ On
Off ¦ On
Off ¦ On
Off ¦ On
Default value
Min
max
Unit
- -
- -
- -
- -
- -
- -
- -
61/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating elements
A
5.1.5 AVS37.390Operation
Select operating mode
Show information
Chimney sweep function
STB test
Display choices
Display
+
-
OK
+
ESC
-
2354Z12
Set DHW nominal setpoint
Navigation and settings
jdust room comfort setpoint
Navigation and settings
The above illustration shows an example of the front of an operator unit (not supplied
as standard).
Heating to Comfort setpoint
Heating to Reduced setpoint
Boiler operation, heating active
Boiler operation, DHW heating active
1 2
Burner in operation
Error messages
Maintenance / special
operation
Display of all symbols and segments.
21
2354Z13
Selecting the operating mode
Press the button to switch from heating mode on / off to
DHW heating, and vice versa.
The selection made is indicated by a bar which appears
below the respective symbol.
62/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Adjusting the room temperature setpoint
Press the + / - buttons to increase or decrease the Comfort setpoint
.
For the
− Press OK
− Select the operating line for the “Reduced setpoint”
Reduced setpoint
After each readjustment, wait at least 2 hours, allowing the room temperature to adapt.
Adjusting the nominal DHW setpoint
Press the + / - buttons to increase or decrease the nominal DHW
setpoint.
Displaying information
Various data can be displayed by pressing the info button.
The display alternates, showing the value and the info no.
+
+
OK
Exception
Chimney sweep function
2354Z13
↔
2354Z13
- No. 1 Boiler temperature
- No. 2 Outside temperature
- No. 3 DHW temperature
- No. 4 Flow temperature 1
- No. 5 Flow temperature 2
- No. 10 State of heating circuit 1
- No. 11 State of heating circuit 2
- No. 12 State of DHW
- No. 13 State of boiler
- No. 14 State of solar
In exceptional cases, the basic display shows one of the following symbols:
Error messages
If this symbol appears, an error in the
plant has occurred. The display shows
letter “c”, followed by the error no.
Maintenance or special operation
If this symbol appears, a maintenance
alarm is delivered or the plant has
changed to special mode. The display
shows letter “c”, followed by the message
1
2354Z13
no.
1
2354Z13
To start the chimney sweep function , press the button for a moment (< 3 seconds).
This function produces the operating state required to make emission measurements
(flue gas).
63/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Setting principle
3.1.2 Programming
Settings that cannot be made directly with the operating elements require
programming. For that, the respective setting buttons are used as follows:
• Press ESC to go one step back at a time, readjusted values are not be adopted
• If no setting is made for 8 minutes, the display returns automatically to the basic
display
• Operating lines may be hidden, depending on the type of controller, the configuration
made and the user level
Example: “Setting the time of day“
The following example shows how to set the time of day and the date.
Operation
1
+
+
OK
Display example Description
Basic display.
If the basic display does not appear,
press the operating mode button.
2354Z13
Press OK.
2
1
+
The display shows the first operating
line, alternating with the value.
Press the arrow button until you
reach operating line “Hours /
2354Z13
minutes” (e.g. 50).
1
Press OK to confirm.
2354Z13
3
1
+
The display shows the hours
flashing.
Press the "+/-" button until the hours
of the time of day are correct.
2354Z13
Press OK to confirm.
64/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
4
1
+
The display shows the minutes
flashing.
Press the "+/-" button until the
minutes of the time of day are
2354Z13
correct.
Press OK to confirm.
5
1
The settings are saved and the
displays stops flashing.
Now, you can make further settings
or
2354Z13
You can press the operating mode
6
1
button to return to the basic display.
2354Z13
Now, you see the basic display
again.
5.1.6 User levels
The user levels only allow authorized user groups to make settings. To reach the
required user level, proceed as follows:
1
Operation
Display example Description
You see the basic display.
Press OK for 3 seconds.
2
1
2354Z13
Now, you are on the user level
“Enduser”.
Press the info button for 3 seconds.
2354Z13
3
1
You are on the user level “Heating
engineer”.
If the change to the “Heating
engineer” level was successful, the
2354Z13
display shows “ON” as a
confirmation.
65/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Legend
Operating line
Operating line
clear-text units
user level
Function
Time of day and date
50 1
51 2
52 3
53 4
54 5
59 6220
E Hours / minutes
E Day / month
E Year
F Start of summertime
F End of summertime
F Software version
Time prog heating circuit 1
61 500
62 501
63 502
64 503
65 504
66 505
67 506
E Preselection Mo-Su
E
1st phase on
E 1st phase off
E 2nd phase on
E 2nd phase off
E 3rd phase on
E 3rd phase off
Time prog heating circuit 2
Preselection Mo-Su
71 520
72 521
73 522
74 523
75 524
76 525
77 526
E
1st phase on
E
1st phase off
E
2nd phase on
E
2nd phase off
E
3rd phase on
E
3rd phase off
E
Heating circuit 1
81 712
82 720
83 721
84 730
85 741
E Reduced setpoint
E Heating curve slope
F Heating curve displacement
E Summer/winter heating limit
F Flow temp setpoint max
Heating circuit 2
86 1012
87 1020
88 1021
89 1030
90 1041
E Reduced setpoint
E Heating curve slope
F Heating curve displacement
E Summer/winter heating limit
F Flow temp setpoint max
5.1.7 Overview of settings
The table shows all available settings up to the heating engineer level.
E = enduser F = heating engineer
OL = operating line
Default value
01:00
1.01 01.01
2004 2004
25.03 01.01
25.10 01.01
- 0 99.9 -
-{}-6:00 00:00 24:00
22:00 00:00 24:00
--:-- 00:00 24:00
--:-- 00:00 24:00
--:-- 00:00 24:00
--:-- 00:00 24:00
6:00 00:00 24:00
22:00 00:00 24:00
--:-- 00:00 24:00
--:-- 00:00 24:00
--:-- 00:00 24:00
--:-- 00:00 24:00
16 4 35
1.5 0.10 4.00
0 -4.5 4.5
18 - - - / 8 30
80 8 95
16 4 35
1.5 0.10 4.00
0 -4.5 4.5
18 - - - / 8 30
80 80 95
Min
max
00:00 23:59
31.12
2099
31.12
31.12
-
Unit
hh:mm
dd.mm
yyyy
dd.mm
dd.mm
hh:mm
hh:mm
hh:mm
hh:mm
hh:mm
hh:mm
hh:mm
hh:mm
hh:mm
hh:mm
hh:mm
hh:mm
°C
°C
°C
°C
°C
°C
°C
°C
°C
°C
66/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Operating elements
A
g
Display choices
Display
5.2 QAA55...
5.2.1 Operation
Heating to Comfort setpoint
Heating to Reduced setpoint
Display of all symbols and segments.
2358Z34
Select heating mode
djust room comfort setpoint
ation and settings
Navi
Presence button
Burner operating (only oil / gas boiler)
Error messages
Configuration
Settings
Used as
Direct adjustment
2354Z09
5.2.2 Programming
A long press on the occupancy button enables the service level to be accessed.
ru = 1 (factory setting) The room unit is addressed as room unit 1
ru = 2 The room unit is addressed as room unit 2
P1 = 1 (factory setting) Automatic storage:
A setpoint readjustment with the knob is
adopted either by pressing the operating mode
button or without any further confirmation
(timeout).
P1 = 2 Storage with confirmation:
A setpoint readjustment with the knob is
adopted only after pressing the operating mode
button.
67/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products Handling 11. May 2007
Summer- / wintertime
changeover
Operation and display
Info
6 The settings in detail
6.1 Time of day and date
The controller has a yearly clock with time of day, weekday and date. To ensure the
controller’s functionality, both the time of day and the date must be correctly set.
Line no. Operating line
1 Hours / minutes
2 Day / month
3 Year
5 Start of summertime
6 End of summertime
The dates set for the change from wintertime to summertime, and from summertime to
wintertime, ensure that on the first Sunday after that date the time of day will change
from 02:00 (wintertime) to 03:00 (summertime), and from 03:00 (summertime) to 02:00
(wintertime).
6.2 Operator section
Line no. Operating line
20 Language
22 Info
Temporarily
Permanently
26 Operation lock
27 Programming lock
Temporarily: After pressing the info button, a change to the “predefined“ basic display
is made after a maximum of 8 minutes or by pressing the operating
mode button (with the QAA78… only 2 minutes) .
Operation lock
Programming lock
Continuously: After pressing the info button, a change back to the “new“ basic display
is made after a maximum of 8 minutes. The info value selected last will
be adopted by the new basic display.
This setting is not possible with the QAA78…
When the operation lock is activated, the following operating elements can no longer be
adjusted:
Heating circuit operating mode, DHW operating mode, room Comfort setpoint (setting
knob), and occupancy button.
When the programming lock is activated, parameter values can still be displayed, but
can no longer be changed.
• Temporary deactivation of the programming lock.
Within the programming level, the programming lock can temporarily be overridden.
To do this, press the OK and ESC buttons simultaneously for 3 seconds. Temporary
deactivation of the programming lock is maintained until programming is quit.
• Constant deactivation of programming lock.
First, make the temporary deactivation, then go to operating line “Programming lock“
(operating line 27) and deactivate the programming lock
68/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Used as
Heating circuit assignment
Line no. Operating line
40 Used as
Room unit 1
Room unit 2
Room unit P
Operator unit 1
Operator unit 2
Operator unit P
Service unit
This operating line is used to select the use of the operator unit. Depending on use,
additional settings will then be required under “Heating circuit assignment“. When using
several operator units, it is thus possible to match individual units to specific
requirements.
• In the case several operator units are used, each application may only be used once.
• The AVS37.294 operator unit is supplied as operator unit 1 (operating line 40)
acting on all heating circuits (operating line 42) and can only be readjusted on
operating lines 44, 46 and 48
Depending on the selected use of the unit (operating line 40), the following settings
(marked with X) can be made when assigning the heating circuit.
Operating line
40 42 44 46 48 54
Room unit 1 Heating circuit 1
Room unit 2
Room unit P
Heating circuits 1 and 2 X
Heating circuits 1 and P
All heating circuits X X X X
Operator unit 1 Heating circuit 1
Operator unit 2
Operator unit P
Service unit
Heating circuits 1 and 2 X
Heating circuits 1 and P
All heating circuits X X X
X X X
X X
X
X X
X
X
X
Room unit 1
The operator unit supports the heating circuits released on operating line 42
“Assignment room unit 1” and activated in the basic unit.
Room unit 2
The operator unit only supports heating circuit 2.
Operator unit / service unit
The operator unit supports the heating circuits activated in the basic unit.
When using this setting, the operator unit does not acquire and deliver the room
temperature.
Line no. Operating line
42 Assignment device 1
Heating circuit 1
Heating circuits 1 and 2
Heating circuits 1 and P
All heating circuits
44 Operation HC2
Commonly with HC1
Independently
69/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
A
ssignment room unit 1
A
Operation HC2
Operation HCP
ction occupancy button
Room sensor
Device data
46 Operation HCP
Commonly with HC1
Independently
48 Action occupancy button
None
Heating circuit 1
Heating circuit 2
Jointly
As room unit 1 (setting 40), the action of the relevant operator unit on heating circuit 1
or on both heating circuits can be assigned. The latter is required especially when using
2 heating circuits and only 1 room unit.
Depending on operating line 40, the action of operation (operating mode button or
setting knob) on room unit 1, on the operator unit or service unit can be defined for
heating circuit 2.
Commonly with HC1
Operation acts commonly on heating circuits 1 and 2.
Independently
The action of operation is queried on the display as soon as the operating mode button
is pressed or the setting knob is operated.
Depending on operating line 40, the action of operation (operating mode button or
setting knob) on room unit 1, on the operator unit or service unit can be defined for
heating circuit P.
Commonly with HC1
Operation acts commonly on heating circuits 1 and 2.
Independently
Operating mode changes or readjustments of the Comfort setpoints are to be made in
programming mode.
The action of the occupancy button on the operator unit can be assigned to the relevant
heating circuits.
If only 1 heating circuit is assigned, the occupancy button always acts on that heating
circuit.
Line no. Operating line
54 Readjustment room sensor
The temperature display can be readjusted.
Line no. Operating line
70 Software version
The display shows the current version of the room unit.
6.3 Radio
Binding
Line no. Operating line
120 Binding
121 Test mode
For more detailed information, refer to the descriptions of the wireless components in
section 3.8.
Binding
Test mode
70/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
When commissioning the system, the wireless peripheral devices (room unit) are
assigned to the basic unit.
The test mode is used for checking the wireless communication. The test should be
made when the installation is fully completed.
Device list radio
Delete all devices
Line no. Operating line
130 Room unit 1
Missing
Ready
No recept’n
Change batt
131 Room unit 2
Same as on operating line 130
132 Room unit P
Same as on operating line 130
133 Outside sensor
Same as on operating line 130
134 Repeater
Same as on operating line 130
135 Operator unit 1
Same as on operating line 130
136 Operator unit 2
Same as on operating line 130
137 Operator unit P
Same as on operating line 130
138 Service unit
Same as on operating line 130
140 Delete all devices
The wireless connection to all devices will be canceled. If radio communication is
required again, a new binding must be established.
Entering the switching
times
Switching points
6.4 Time programs
For the heating circuits and DHW heating, a number of switching programs are
available. They are activated in "Automatic" operation and control the change of the
temperature levels (and the associated setpoints) via the selected switching times.
The switching times can be set in a combined way, that is, either commonly for several
days or separate times for individual days. When preselecting groups of days like for
instance Mo...Fr and Sa...Su that use the same switching times, setting of the switching
programs is simplified.
Line no. Operating line
HC1 HC2 3/HCP 4/DHW 5
500 520 540 560 600 Preselection
501 521 541 561 601 1st phase on
502 522 542 562 602 1st phase off
503 523 543 563 603 2nd phase on
504 524 544 564 604 2nd phase off
505 525 545 565 605 3rd phase on
506 526 546 566 606 3rd phase off
Mo - Su
Mo - Fr
Sa - Su
Mo - Su
71/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Standard program
Line no. Operating line
516, 536, 556, 576,
Default values
616
All time programs can be reset to the default settings. Each time program has its own
operating line to make this reset.
In that case, individual settings will be lost!
6.5 Holidays
HC1 HC2 HCP
641 651 661 Preselection
642 652 662 Start
643 653 663 End
648 658 668 Operating level
The holiday program is used to switch the heating circuits to a selectable operating
level according to calendar dates.
• The holiday program can only be used in “Automatic“ operation
Line no. Operating line
Frost protection
Reduced
Operating mode
Setpoints
Room temperature
6.6 Heating circuits
For heating circuits, there are various functions available which can be individually set
for each heating circuit.
Line no. Operating line
1300 Operating mode
The operating mode of heating circuits 1 and 2 is selected directly with the operating
mode button while the operating mode of heating circuit P is to be selected in
programming mode (operating line 1300).
This setting is used to switch between the different operating modes. The functionality
corresponds to operating mode selection with the operating mode button. For details,
refer to section ”Operation“.
Line no. Operating line
HC1 HC2 HCP
710 1010 1310 Co mfort setpoint
712 1012 1312 Re duced setpoint
714 1014 1314 Frost p rotection setpoin t
716 1016 1316 Comfort setpoint maximum
The room temperature can be shifted according to different setpoints. These setpoints
become active depending on the selected operating mode, thus producing different
temperature levels in the rooms.
The ranges of adjustable setpoints result from the interdependencies, as this is shown
in the following diagram.
Protection
Automatically
Reduced
Comfort
72/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Frost protection
Comfort setpoint
maximum
Heating curve
Heating curve slope
TRK
TRR
TRF
0 2 4 6 8 10 12 14 16 18 20 22 24 26 °C
TRKmax Comfort setpoint maximum
TRK Comfort cooling setpoint
TRR Reduced setpoint
TRF Frost protection setpoint
TRKmax
2358Z01
In Protection mode, the room temperature is prevented from falling below a certain
level. Thus, the frost protection setpoint of the room temperature is maintained.
The room temperature can be shifted according to different setpoints. These setpoints
become active depending on the selected operating mode, thus producing different
temperature levels in the rooms.
The ranges of adjustable setpoints result from the interdependencies, as this is shown
in the following diagram.
HC1 HC2 HCP
Line no. Operating line
720 1020 1320 Heating curve slope
721 1021 1321 Heating curve displacement
726 1026 1326 Heating curve adaption
The heating curve is used to generate the flow temperature setpoint, which is used to
maintain a certain flow temperature depending on the prevailing weather conditions.
The heating curve can be adjusted with a number of settings, thus matching heat
output and room temperature to individual needs.
As the heating curve slope is raised, the flow temperature increases the quicker the
lower the outside temperature or, in other words, if the room temperature is not correct
at low outside temperatures but correct at higher outside temperatures, the heating
curve slope requires readjustment.
Increase adjustment: Raises the flow temperature, especially when outside
temperatures are low.
Decrease adjustment: Lowers the flow temperature, especially when outside
temperatures are low.
73/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Heating curve
displacement
Heating curve adaption
ECO functions
Summer/winter heating
limit
Parallel displacement of the heating curve is used to change the flow temperature
evenly across the entire outside temperature range or, in other words, if the room
temperature is always too high or too low, a readjustment must be made with the help
of the parallel displacement.
Adaptation of the heating curve is used by the controller to automatically adapt the
heating curve to the prevailing conditions. In that case, a readjustment of heating curve
slope and parallel displacement is not required. It can only be switched on or off.
To assure this function, following must be observed:
• A room sensor must be connected.
• The ”Room influence“ setting must be selected between 1 and 99
• There should be no thermostatic radiator valves in the reference room (mounting
location of room sensor) (If such valves are present, they must be set to their fully
open position).
HC1 HC2 HCP
Line no. Operating line
730 1030 1330 Summer/winter heating limit
732 1032 1332 24-hour heating limit
The summer / winter heating limit is used to switch the heating on and off in the course
of the year, depending on temperature conditions. In Automatic mode, switching on / off
takes place automatically, so there is no need for the user to do this manually. By
changing the setting, the respective periods of time will be shortened or extended.
Increase: Winter operation will start
Summer operation will start
earlier
later
Decrease: Winter operation will start
Summer operation will start
later
earlier
• The function is not active in operating mode ”Continuously Comfort temperature“
• The display shows ECO
• To consider the building’s thermal dynamics, the outside temperature is attenuated
Example:
T
°C
20
19
18
17
16
ON
OFF
501015
SWHG Summer/winter heating limit
TAged Attenuated outside temperature
T Temperature
t Days
TAged
SWHG
SWHG
SWHG
+1 °C
-1 °C
2358Z08
t
74/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
24-hour heating limit
The 24-hour heating limit is used to switch the heating on and off in the course of the
day, depending on the outside temperature. This function is used primarily during
intermediate seasons (spring and fall) to respond to short-time temperature variations.
Example:
Setting line e.g.
Comfort setpoint (TRw) 22 °C
24-hour heating limit (THG) -3 °C
Changeover temperature (TRw-THG) heating off = 19 °C
Switching differential (fixed) -1 °C
Changeover temperature heating on = 18 °C
By changing the value entered, the respective heating periods will be shortened or
extended.
Increase: Heating mode will start
changeover to ECO
earlier,
later.
Decrease: Heating mode will start
• The function is not active in operating mode ”Continuously Comfort temperature“
• The display shows ECO
• To consider the building’s thermal dynamics, the outside temperature is attenuated
Flow temperature setpoint limitations
HC1 HC2 HCP
740 1040 1340 Flow temp setpoint min
741 1041 1341 Flow temp setpoint max
Using this limitation, a temperature range for the flow temperature setpoint can be
defined. If the flow temperature setpoint demanded by the heating circuit reaches the
relevant limit and the heat request increases or decreases, the flow temperature
setpoint will be maintained at the maximum or minimum limit.
TV
max
akt
min
later,
changeover to ECO
Line no. Operating line
TVmin
earlier.
TVw
TVmax
2358Z09
0 10 20 30 40 50 60 70 80 90 100
TVw Current flow temperature setpoint
TVmax Flow temperature setpoint maximum
Tvmin Flow temp setpoint minimum
°C
Room influence
HC1 HC2 HCP
Line no. Operating line
750 1050 1350 Room influence
Types of compensation
When a room temperature sensor is used, there is a choice of 3 different types of
compensation.
75/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Pure weather
compensation
Weather compensation
with room influence
Pure room compensation
Room temp limitation
Setting Type of compensation
− − − %
Pure weather compensation *
1…99 % Weather compensation with room
influence *
100 %
Pure room compensation
* Outside sensor required.
The flow temperature is calculated via the heating curve, depending on the composite
outside temperature.
This type of compensation calls for a correct adjustment of the heating curve since in
that case the control gives no consideration to the room temperature.
Deviations of the actual room temperature from the setpoint are acquired and taken into
account when controlling the temperature. Heat gains can thus be considered,
facilitating more accurate room temperature control. The authority of deviation is set as
a percentage figure. The better the reference room (correct room temperature, correct
mounting location, etc.) the higher the value can be set.
• Example:
Approx. 60 % Good reference room
Approx. 20 % Unfavorable reference room
To activate the function, following must be considered:
• A room sensor must be connected.
• “Room influence“ must be set to a value between 1 and 99 %.
• There should be no thermostatic radiator valves in the reference room (mounting
location of the room sensor). (If such valves are present, they must be set to their
fully open position).
The flow temperature is controlled depending on the room temperature setpoint, the
current room temperature and the progression of the room temperature. For example, a
slight increase of the room temperature causes an immediate drop of the following
temperature.
To activate the function, following must be considered:
• A room sensor must be connected.
• “Room influence“ must be set to 100 %.
• There should be no thermostatic radiator valves in the reference room (mounting
location of the room sensor). (If such valves are present, they must be set to their
fully open position).
HC1 HC2 HCP
Line no. Operating line
760 1060 1360 Room temp limitation
In the case of pump heating circuits, a switching differential for temperature control
must be set. The function necessitates a room temperature sensor.
Room temperature limitation does not work in the case of pure weather compensation.
76/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Boost heating
°C
TRx
TRw+SDR
TRw
t
ON
P
OFF
TRx Actual value of room temperature
TRw Room temperature setpoint
SDR Room’s switching differential
P Pump
T Time
2371D02
HC1 HC2 HCP
Line no. Operating line
770 1070 1370 Boost heating
Boost heating is used to reach the new setpoint more quickly when switching from the
Reduced setpoint to the Comfort setpoint, thus reducing the heating up time. During
boost heating, the room temperature setpoint is raised by the value set here.
A higher setting leads to shorter heating up times, a lower setting to longer heating up
times.
• Boost heating is possible with or without room sensor
Quick setback
°C
TR
w
20
TR
15
x
DTRSA
2371D03
t
TRw The room temperature setpoint
TRx Actual value of the room temperature
DTRSA Increase of room temperature setpoint
HC1 HC2 HCP
Line no. Operating line
780 1080 1380 Quick setback
Off
Down to reduced setpoint
Down to frost prot setpoint
During quick setback, the heating circuit pump is deactivated and, in the case of mixing
valve circuits, the mixing valve is fully closed.
• Function with room sensor:
When using the room sensor, the function keeps the heating switched off until the room
temperature has dropped to the level of the Reduced setpoint or the frost level.
When the room temperature has fallen to the Reduced level or the frost level, the
heating circuit pump will be activated and the mixing valve will be released.
77/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Example
Optimum start / stop control
Optimum start control max
Optimum stop control max
• Function without room sensor:
Quick setback switches the heating off for a certain period of time, depending on the
outside temperature and the building time constant.
Duration of quick setback when Comfort setpoint minus Reduced setpoint = 2°C
(e.g. Comfort setpoint = 20°C and Reduced setpoint =18°C)
Outside
temperature
0 2 5 10 15 20 50
Building time constant:
composite:
15 °C
10 °C
5 °C
0 °C
-5 °C
-10 °C
-15 °C
-20 °C
0 3.1 7.7 15.3 23 30.6 76.6
0 1.3 3.3 6.7 10 13.4 33.5
0 0.9 2.1 4.3 6.4 8.6 21.5
0 0.6 1.6 3.2 4.7 6.3 15.8
0 0.5 1.3 2.5 3.8 5.0 12.5
0 0.4 1.0 2.1 3.1 4.1 10.3
0 0.4 0.9 1.8 2.6 3.5 8.8
0 0.3 0.8 1.5 2.3 3.1 7.7
Duration of quick setback in hours
• Quick setback is possible with or without a room sensor
HC1 HC2 HCP
Line no. Operating line
790 1090 1390 Optimum start control max
791 1091 1391 Optimum stop control max
The change from one temperature level to the other is optimized in a way that the
Comfort setpoint is reached at the relevant switching time.
The change from one temperature level to the other is optimized in a way that the
Comfort setpoint minus 1/4 °C is reached at the relevant switching time
• Optimum start / stop control is possible with or without room sensor.
0
Xein Xaus
24
TRx
TRw
ZSP
Xein Switch-on time shifted forward in time
Xaus Switch-off time shifted forward in time
ZSP Time program
TRx Actual value of room temperature
TRw Room temperature setpoint
1/4 °C
2358Z02
78/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Increase of Reduced setpoint
A
HC1 HC2 HCP
Line no. Operating line
800 1100 1400 Reduced setp increase start
801 1101 1401 Reduced setp increase end
The function is used primarily in connection with heating systems with
only little spare
capacity (e.g. low-energy houses). In that case, the heating up time would be too long if
outside temperatures are low. When the Reduced setpoint is raised, the rooms are
prevented from cooling down to too low levels, thus shortening the heating up time
when changing to the Comfort setpoint.
TR
TRwA2TRwA1
TRK
TRR
2358Z06
-15
TRwA1 Reduced setp increase start
TRwA2 Reduced setp increase end
TRK Comfort cooling setpoint
TRR Reduced room temperature setpoint
Tagem Composite outside temperature
Overtemperature protection pump heating circuit
HC1 HC2 HCP
Line no. Operating line
820 1120 1420 Overtemp prot pump circuit
In the case of heating plant with pump heating circuits, the flow temperature of the
heating circuit can be higher than the flow temperature demanded by the heating curve,
due to requests from other heat consumers (mixing heating circuit, DHW charging,
external heat demand), or a parameterized minimum boiler temperature. As a result of
this too high flow temperature, the pump heating circuit would assume excessive
temperatures.
Function “Overtemperature protection for pump heating circuits” ensures that the
energy supply for pump heating circuits corresponds to the demand from the heating
curve by activating / deactivating the pump.
Mixing valve control
Line no. Operating line
HC1 HC2
830 1130 Mixing valve boost
832 1132 Actuator type
833 1133 Switching differential 2-pos
834 1134 Actuator running time
ctuator type
The selection of the type of actuator determines the control behavior for the type of
mixing valve actuator used.
-5
2-position ¦ 3-position
TAgem
79/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Switching differential 2-
A
pos
Mixing valve boost
ctuator running time
Floor curing function
Floor curing function
For the 2-position actuator, the 2-position switching differential must also be adapted.
This is not required when using a 3-position actuator.
To ensure proper mixing valve flow temperature control, the flow temperature must be
higher than the demanded setpoint of the mixing valve flow temperature. The value set
here is added to the request.
Setting the running time of the actuator used with the mixing valve.
HC1 HC2 HCP
Line no. Operating line
850 1150 1450 Floor curing function
Off
Functional heating (Fh)
Curing heating (Bh)
Functional/curing heating
Curing heating/ functional heating
Manually
851 1151 1451 Floor curing setp manually
The floor curing function ensures controlled drying of the floor. It controls the flow
temperature according to a temperature profile. Drying of the floor is ensured via the
floor heating system and the mixing valve or pump heating circuit.
Off:
Function is deactivated.
Functional heating (Fh) :
The first part of the temperature profile is automatically completed.
Floor curing heating (Bh)
The second part of the temperature profile is passed automatically.
Functional and floor curing heating
The entire temperature profile (first and second part) is passed automatically.
Floor curing heating and functional heating
The entire temperature profile (first and second part) is traversed automatically.
Manually
It is not a temperature profile that is completed, but the floor setpoint is controlled
manually.
• Observe the relevant standards and regulations of the floor manufacturer!
• Proper functioning is ensured only when the plant is correctly installed (hydraulic
system, electrical installation, settings)!
If not observed, the floor might get damaged!
• The function can be aborted prematurely by choosing Off.
• Maximum limitation of the flow temperature remains active.
80/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
[TVw]
55
50
45
40
35
30
25
20
11
0
57
5101518
[Tag
2358Z10
]
X
1 25
X Start day
Fh Functional heating
Bh Floor curing heating
Excess heat draw
HC1 HC2 HC3P
Line no. Operating line
861 1161 1461 Excess heat draw
Excess heat draw can be triggered by the following functions:
− Inputs H1, H2, H3 or EX2
− Storage tank recooling
− Solid fuel boiler excess heat draw
When dissipation of excess heat is activated, it can be drawn by space heating. This
can be adjusted separately for each heating circuit.
Buffer storage tank / primary controller
HC1 HC2 HCP
Line no. Operating line
870 1170 1470 With buffer storage tank
872 1172 1472 With primary controller / system pump
With buffer storage tank
If a buffer storage tank is used, it must be entered here whether the heating circuit shall
receive its heat from the buffer storage tank or directly from the boiler.
When using alternative heat sources, the buffer storage tank temperature is used as a
control criterion for the release of additional heat sources.
With primary controller /
system pump
It is to be set whether the heating circuit receives its heat via the primary controller or
with the help of the system pump (depending on the type of plant).
Speed-controlled pump
HC1 HC2 HCP
Line no. Operating line
882 1182 1482 Pump speed min
883 1183 1483 Pump speed max
Pump speed min
The minimum speed of the heating circuit pump can be defined.
Pump speed max
The maximum speed of the heating circuit pump can be defined.
Fh
Fh + Bh
Off
Heating mode
Always
Bh
81/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Remote
Setpoints
HC1 HC2 HCP
Line no. Operating line
900 1200 1500 Optg mode changeover
None ¦ Protection ¦ Reduced ¦ Comfort ¦ Automatic
In the case of external changeover via inputs H1 / H2 / H3, the operating mode to be
used can be selected.
6.7 DHW
Line no. Operating line
1610 Nominal setpoint
1612 Reduced setpoint
The DHW can be heated up according to different setpoints. These setpoints are
activated depending on the selected operating mode, thus leading to different
temperature levels in the DHW storage tank.
TWWN
TWWR
TWWmax
Priority
2358Z11
0 10 20 30 40 50 60 70 80 90 100 °C
TWWR DHW reduced setpoint
TWWN DHW nominal setpoint
TWWmax DHW nominal setpoint maximum
Line no. Operating line
1630 Charging priority
Absolute
Shifting
None
MC shifting, PC absolute
When both space heating and DHW heating call for heat, the “DHW priority“ function
ensures that during DHW charging the boiler’s capacity is used primarily for DHW.
Absolute priority
The mixing and pump heating circuit stay locked until DHW heating is finished.
Shifting priority
If the capacity of the heat source is not sufficient, the mixing and pump heating circuit
will be restricted until DHW is heated up.
No priority
DHW charging and space heating take place at the same time.
In the case of tightly sized boilers and mixing heating circuits, it can happen that the
DHW setpoint will not be reached if space heating demands considerable amounts of
heat.
Mixing heating circuit shifting, pump heating circuit absolute
The pump heating circuits stay locked until the DHW storage tank is heated up. If the
capacity of the heat source is not sufficient, the mixing heating circuits will also be
restricted.
82/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Legionella function
Legionella function
Legionella funct circ pump
Circulating pump
Circulating pump cycling
Circulation setpoint
Line no. Operating line
1640 Legionella function
Off
Periodically
Fixed weekday
1641 Legionella funct periodically
1642 Legionella funct weekday
Monday…Sunday
1644 Legionella funct time
1645 Legionella funct setpoint
1646 Legionella funct duration
1647 Legionella funct circ pump
• Periodically
The legionella function is repeated according to the period of time set (operating line
1641). The legionella setpoint is attained via a solar plant, independent of the period of
time set, the period of time will be newly started.
• Fixed weekday
The legionella function can be activated on a fixed weekday (operating line 1642).
When using this setting, heating up to the legionella setpoint takes place on the
selected weekday, independent of previous storage tank temperatures.
During the time the legionella function is carried out, the DHW circulating pump can be
activated.
During the time the legionella function is carried out, there is a risk of scalding when
opening the taps.
Line no. Operating line
1660 Circulating pump release
Time program 3/HCP
DHW release
Time program 4/DHW
Time program 5
1661 Circulating pump cycling
1663 Circulation setpoint
When the function is activated, the circulating pump is switched on for 10 minutes
within the release time and then switched off again for 20 minutes.
If a sensor is installed in the DHW distribution pipe, the controller will monitor its actual
value during the time the legionella function is performed. The adjusted setpoint must
be maintained at the sensor during the adjusted “Dwelling time“.
83/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Pump H1/H2/H3
Excess heat draw
With buffer storage tank
With primary controller /
system pump
6.8 Pump H1/H2/H3
Line no. Operating line
2010 H1 Excess heat draw
2012 H1 with buffer storage tank
2014 H1 prim contr/system pump
2035 H2 Excess heat draw
2037 H2 with buffer storage tank
2039 H2 prim contr/system pump
2046 H3 Excess heat draw
2048 H3 with buffer
2050 H2 prim contr/system pump
Excess heat draw can be triggered by the following functions:
− Inputs H1, H2, H3 or EX2
− Storage tank recooling
− Solid fuel boiler excess heat draw
When dissipation of excess heat is activated, it can be drawn by space heating. This
can be adjusted separately for each heating circuit.
If a buffer storage tank is used, it must be entered here whether the H1/H2/H3 circuit
shall receive its heat from the buffer storage tank or directly from the boiler.
When using alternative heat sources, the buffer storage tank temperature is used as a
control criterion for the release of additional heat sources.
It is to be set whether the H1/H2/H3 circuit receives its heat via the primary controller or
with the help of the system pump (depending on the type of plant).
Setpoints
Setpoint solar heating
Setpoint source heating
Priority
6.9 Swimming pool
Line no. Operating line
2055 Setpoint solar heating
2056 Setpoint source heating
When using solar energy, the swimming pool is heated up until this setpoint is reached.
The protective collector overtemperature function can reactivate the collector pump
until the maximum swimming pool temperature is reached.
When using the heat source, the swimming pool is heated up until this setpoint is
reached.
Line no. Operating line
2065 Charging priority solar
• Off:
Swimming pool heating through solar charging does not give consideration to any
priorities. If the storage tank’s charging priority (operating line 3822) is also deactivated,
the swimming pool is heated alternately with the storage tanks, the temperature
increase being 5 °C.
84/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
• On:
Swimming pool heating through solar charging is given priority. This also applies if a
storage tank with charging priority (operating line 3822) would have to prefer other heat
exchangers.
Plant hydraulics
Line no. Operating line
2080 With solar integration
This setting is made to indicate iff the swimming pool can be charged by solar energy.
6.10 Primary controller / system pump
Primary controller / system pump
Line no. Operating line
2150 Primary controller / system pump
If the plant uses a buffer storage tank, it is to be set here whether, hydraulically, the
primary controller or the system pump is installed upstream from the buffer storage
tank.
6.11 Boiler
Operating mode
Line no. Operating line
2203 Release below outside temp
2205 In economy mode
2208 Full charging buffer
Release below outside
temp
Economy mode
Full charging buffer
Setpoints
The boiler is commissioned only if the mixed outside temperature is below this
threshold. For the release, a fixed switching differential of ½ °C is used.
Economy mode can be selected from menu ”Maintenance / Special operation” (OL
7139).
In Economy mode, the boiler is operated as follows:
Off: Remains locked
DHW only: Boiler will be released for DHW charging
On: Always released
To ensure long on times, the heat source keeps operating until the buffer storage
tank is fully charged.
Line no. Operating line
2210 Setpoint min
2212 Setpoint max
The controlled boiler temperature setpoint can be limited by selecting setpoint minimum
and setpoint maximum. These limitations can be regarded as protective functions for
the boiler.
In normal operation, minimum limitation of the boiler temperature is the lower limit value
of the controlled boiler temperature setpoint, depending on the boiler’s operating mode.
Before buffer st tank
After buffer st tank
Off ¦ On DHW ¦ On
Off ¦ On
85/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
In normal operation, maximum limitation of the boiler temperature is the upper limit
value of the controlled boiler temperature setpoint and, at the same time, setpoint of the
electronic limit thermostat (TR).
The setting range of setpoint minimum and setpoint maximum is limited by the setpoint
of manual operation.
Example when using boiler operating mode “Automatic“:
TK
°C
80
70
60
50
40
0
30
20 10 0 -10 -20
Minimum limitation of the return temperature
Line no. Operating line
2270 Return setpoint min
Return setpoint min
If the boiler return temperature falls below the return temperature setpoint, maintained
boiler return temperature becomes active.
Maintained boiler return temperature allows consumers to be influenced, control of a
bypass pump or use of a return temperature controller.
Output data
Line no. Operating line
2330 Output nominal
2331 Output basic stage
These settings are required in the case of cascaded boilers with different outputs.
2 x 1 cascade
Line no. Operating line
2340 Auto source seq 2x1 casc
Automatic changeover of the heat source enables a lead boiler change at certain
intervals. The boiler sequence changes when the selected time has elapsed.
TK
mi n
TK
Legend
TK Boiler temperature
TK
max
w
SDK
°C
TA
TKw Boiler temperature setpoint
...TKmax maximum limitation of the
Tkmin Minimum limitation of the
SDK Switching differential
Tagem Composite outside
2371Z26
gem
boiler temperature
boiler temperature
temperature
When switching on automatic changeover, heat source 1 (T2) is always started up as
the lead boiler.
The time remaining until the next changeover takes place and the current lead boiler
are not displayed.
86/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Control
A
Restart lock
Switch-on delay
Boiler sequence
uto source seq ch’over
6.12 Cascade
Line no. Operating line
3532 Restart lock
3533 Switch-on delay
The restart lock prevents a deactivated heat source from being switched on again. It is
released again only after the set time has elapsed. This prevents too frequent switching
actions of the heat sources and ensures stable plant operating states.
Correct setting of the switch-on delay ensures that the plant maintains stable operating
states. This prevents too frequent switching actions of the boilers (cycling).
In the case of a DHW request, the delay time is fixed at 1 minute.
Line no. Operating line
3540 Auto source seq ch’over
3541 Auto source seq exclusion
None
First
Last
First and last
3544 Leading source
Device 1…device 16
With automatic source sequence changeover, the boiler loads in a cascade can be
influenced by defining the order of lead and lag boiler.
Fixed order
Setting - - - defines a fixed order. In that case, the lead boiler can be selected on
operating line 3544; the other boilers are then switched on and off in the same order as
the LPB device addresses.
Order according to the number of operating hours
On completion of the number of hours set, the boiler sequence in the cascade changes.
It is always the boiler with the next higher device address which assumes the role of the
lead boiler.
87/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
A
P [kW]
1st changeover 2nd changeover 3rd changeover 4th changeover
K 4
K 3
K 2
K 1
K 1
K 4
K 3
K 2
K 2
K 1
K 4
K 3
K 3
K 2
K 1
K 4
Lag boiler
Lead boiler
2379Z07
t = total number of operating hours of all lead boilers [h]
P = total output of cascade [kW]
100
uto source seq exclusion
Setting automatic source sequence exclusion is only used in connection with the
activated heat source sequence (operating line 3540).
Using automatic source sequence exclusion, the first and / or the last boiler can be
exempted from automatic changeover.
None
The order of switching on the boilers changes when the number of hours set is reached
(operating line 3540).
First
The first boiler in terms of addressing is always the lead boiler. With the other boilers,
the order of switching on changes when the set number of hours is reached (operating
line 3540).
Last
The last boiler in terms of addressing will always stay the last. The other boilers change
when the set number of hours is reached (operating line 3540).
First and last
The first boiler in terms of addressing will always be the lead boiler. The last boiler in
terms of addressing will always be the last. The boilers in between change when the
set number of hours is reached (operating line 3540).
Leading source
The leading source is only selected in connection with the fixed order of the heat
source sequence (operating line 3540).
The boiler selected as the lead boiler is always the first to be switched on, or the last to
be switched off. The other boilers are switched on and off in the order of their device
addresses.
Minimum limitation of the return temperature
Line no. Operating line
3560 Return setpoint min
Return setpoint min
If the return temperature drops below the adjusted return setpoint, maintained boiler
return temperature becomes active.
Maintained boiler return temperature allows consumers to be influenced or a return
temperature controller to be used.
300
400200
t [h]
88/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Charging controller (dT)
6.13 Solar
Line no. Operating line
3810 Temp diff on
3811 Temp diff off
3812 Charg temp min DHW st tank
3815 Charging temp min buffer
3818 Charging temp min swi pool
For charging the storage tank via the heat exchanger, the temperature differential
between collector and storage tank / swimming pool must be sufficient, and the
collector must have reached the minimum charging temperature for the storage tank /
swimming pool .
T
Tkol
SdEin
SdAus
TSp
Priority
Charging prio storage tank
TLmin
On
OFF
Tkol Collector temperature
On / Off Collector pump
SdEin Temperature differential ON
SdAus Temperature differential OFF
TSp Storage tank temperature
TLmin Charging temp min DHW storage tank / buffer / swimming pool
2358Z12
t
Line no. Operating line
3822 Charging prio storage tank
None
DHW storage tank
Buffer storage tank
3825 Charging time relative prio
3826 Waiting time relative prio
3827 Waiting time parallel op
3828 Delay secondary pump
The priority circuit for the swimming pool (operating line 2065) can impact storage tank
priority of solar charging and possibly charge the swimming pool before the storage
tanks.
If a plant uses several heat exchangers, it is possible to set a priority for the integrated
storage tanks, which defines the charging sequence.
None
Every storage tank is charged alternately by 5 °C at a time, until every setpoint of level
A, B or C (see below) is reached. The setpoints of the next higher level are approached
only when all setpoints of the previous level have been reached.
89/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Charging time relative prio
Waiting time relative prio
Waiting time parallel op
Delay secondary pump
Start function
DHW storage tank
During solar charging, preference is given to the DHW storage tank. At every level A, B
or C (see below), it is charged with priority. Only then will the other consumers of the
same level be charged. As soon as all setpoints of a level are attained, those of the
next level are approached, whereby priority is again given to the DHW storage tank.
Buffer storage tank
During solar charging, preference is given to the buffer storage tank. At every level A, B
or C (see below), it is charged with priority. Only then will the other consumers of the
same level be charged. As soon as all setpoints of a level are attained, those of the
next level are approached, whereby priority is again given to the buffer storage tank.
Storage tank setpoints:
Level DHW storage tank Buffer storage tank Swimming pool
A
B
C
(1)
1610 Nominal setpoint Buffer setpoint (slave pointer) 2055 Setpoint solar heating
5050 Charging temperature
max
5051 Storage tank temp
max
4750 Charging temperature
max
4751 Storage tank temp max 2070 Swimming pool temp
2055 Setpoint solar heating
max
When priority for the swimming pool is activated (operating line 2065), the swimming
(1)
pool is charged before the storage tanks.
If the preferred storage tank cannot be charged in accordance with charging control,
priority is transferred to the next storage tank or the swimming pool for the period of
time set (e.g. too great temperature differential between collector and storage tank).
As soon as the preferred storage tank (according to setting "Charging priority storage
tank") is again ready to be charged, the transfer of priority will immediately be stopped.
If the parameter is off (---), setting Charging tank priority is used as a rule.
During the period of time set, the transfer of priority will be delayed. This prevents
relative priority from intervening too frequently.
If solar output is sufficient and solar charging pumps are used, parallel operation is
possible. In that case, the storage tank of the priority model can be the next to be
simultaneously charged, in addition to the storage tank to be charged next. Parallel
operation can be delayed by introducing a waiting time. This way, in the case of parallel
operation, switching on of the storage tanks can be effected in steps.
Setting (---) switches off parallel operation.
To remove any existing cold water in the primary circuit, operation of external heat
exchanger’s secondary pump can be delayed.
Line no. Operating line
3830 Collector start function
3831 Min run time collector pump
90/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
T
Collector start function
If the temperature at the collector (especially in the case of vacuum tubes) cannot be
correctly acquired when the pump is deactivated, the pump can be activated from time
to time.
Min run time collector
pump
The function periodically activates the collector pump for at least the selected minimum
running time.
Frost protection for the collector
Line no. Operating line
3840 Collector frost protection
When there is risk of frost at the collector, the collector pump will be activated to
prevent the heat-carrying medium from freezing.
• If the collector temperature falls below the frost protection temperature, the
collector pump will be activated: TKol < TKolFrost.
• When the collector temperature returns to a level of 1°K above the frost protection
temperature, the collector pump will be deactivated again: TKol > TKolFrost + 1.
Overtemperature protection for the collector
Line no. Operating line
3850 Collector overtemp prot
If there is risk of overtemperature at the collector, storage tank charging is continued to
reduce the amount of surplus heat. When the storage tank’s safety temperature is
reached, charging will be stopped.
TSpSi
TSp
On
Off
TSpSi Storage tank safety temperature
TSp Storage tank temperature
TKolUe Collector temperature for overtemperature protection
TSpmax Maximum charging temperature
Tkol Collector temperature
On / Off Collector pump
T Temperature
t Time
Medium’s evaporation temperature
Line no. Operating line
3860 Evaporation heat carrier
If there is a risk of the heat carrying medium evaporating due to high collector
temperatures, the collector pump will be deactivated to prevent it from reaching
excessive temperatures. This is a protective pump function.
Tkol
1°C
TSpMax
TKolUe
1°C
2358Z 14
t
91/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Speed control
A
Pump speed min
Pump speed max
Yield measurement
ntifreeze
Pump capacity
Line no. Operating line
3870 Pump speed min
3871 Pump speed max
The minimum speed for all solar pumps can be selected.
The maximum speed for all solar pumps can be selected.
Line no. Operating line
3880 Antifreeze
3881 Antifreeze concentration
3884 Pump capacity
The 24-hour and total solar energy yield (operating lines 8526 and 8527) is calculated,
based on these data.
Since the mixing ratio of the collector medium has an impact on heat transmission, the
type of antifreeze used and its concentration must be entered in order to be able to
determine the energy yield.
The flow rate in l/h of the pump used must be determined and serves for calculating the
volume delivered.
Operating mode
Locking other heat
sources
Setpoints
Setpoint min
Boiler / burner control
6.14 Solid fuel boiler
Line no. Operating line
4102 Locking other heat sources
When the solid fuel boiler is put into operation, other heat sources, such as oil / gas
boilers, will be locked.
Locking takes place as soon as the boiler temperature rises to a degree that crossing of
the comparison temperature can be expected.
This anticipating function enables the locked heat sources to terminate any overrun of
pumps before the solid fuel boiler pump is activated. Also, in the case of a common
stack, it can be made certain that only one boiler is in operation at a time.
Line no. Operating line
4110 Setpoint min
The boiler pump will be put into operation only when the boiler temperature has
reached a minimum temperature level, in addition to the required temperature
differential.
Line no. Operating line
4130 Temp diff on
4131 Temp diff off
4133 Comparative temp
DHW sensor B3
DHW sensor B31
Buffer sensor B4
Buffer sensor B41
Flow temp setpoint
Setpoint min
92/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Delta T-controller
For the boiler pump to be put into operation, a sufficiently great temperature differential
between boiler temperature and comparison temperature is required.
T
TKx
SDon
SDoff
Automatic locks
Min st tank temp heat
mode
Overtemperature protection
Recooling
Bx
On
QX
Off
TKx Boiler temperature
Bx Actual value of comparison temperature
On / Off Boiler pump
SDon Temp diff on
SDoff Temp diff off
2359Z138
t
6.15 Buffer storage tank
Line no. Operating line
4720 Auto generation lock
None
With B4
With B4 and B41 / B42
4722 Temp diff buffer/HC
4724 Min st tank temp heat mode
Automatic heat generation lock ensures a temporary hydraulic disconnection of heat
source and buffer storage tank. The heat sources will be put into operation only if the
buffer storage tank is no longer able to satisfy the current demand for heat.
The minimum temperature differential between buffer storage tank and heating circuit
can be adjusted.
If the actual temperature of the buffer storage tank falls below this level, the heating
circuits are shut down if no heat source is available.
Line no. Operating line
4750 Charging temperature max
Solar energy charges the buffer storage tank up to the adjusted maximum charging
temperature.
The protective collector overtemperature function can reactivate the collector pump
until the maximum storage tank temperature is reached.
Line no. Operating line
4755 Recooling temp
4756 Recooling DHW/HCs
4757 Recooling collector
2 functions are available for recooling the buffer storage tank down to the recooling
temperature.
Off
Summer
Always
93/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Recooling DHW/HCs
Recooling collector
Plant hydraulics
Return diversion
Temp diff on/off return div
Compar temp return div
Optg action return
diversion
• Heating energy can be drawn off either by space heating or the DHW storage tank.
This can be selected separately for each heating circuit (operating page heating
circuit 1…).
• If the collector is cold, the energy can be emitted to the environment via the
collector’s surfaces.
Line no. Operating line
4783 With solar integration
Select here whether the buffer storage tank can be charged by solar energy.
Line no. Operating line
4790 Temp diff on return div
4791 Temp diff off return div
4795 Compar temp return div
B4 ¦ B41 ¦ B42
4796 Optg action return diversion
Temp decrease
Temp increase
If there is a certain temperature differential between the common return temperature
sensor (B73) and the selectable comparative temperature, the return is diverted
through the lower section of the buffer storage tank. The function can be used for a
return temperature increase or return temperature decrease (to be selected on
operating line 4796). This is defined on operating line 4796.
.
In addition, the setting of the respective relay output is to be made as “Buffer diverting
valve Y15” in configuration “Relay output QX1, 2 ,3, 4” (operating lines 5890, 5891,
5892 and 5894) and the common return temperature sensor (B73) at BX.
The selected temperature differential defines the switch-on / off point of return
diversion.
Selection of the buffer storage tank temperature sensor with which the return
temperature is compared in order to switch the return diversion based on the selected
temperature differentials.
Temperature decrease
If the consumers’ return temperature is higher than the temperature at the selected
sensor (operating line 4795), the return can be used to preheat the lower storage tank
section. As a result, the return temperature drops further which, in the case of a
condensing boiler, leads to higher efficiency.
Temperature increase
If the consumers’ return temperature is lower than the temperature at the selected
sensor (operating line 4795), the return temperature can be raised by diverting the
return through the lower storage tank section. As a result, the return temperature
increases.
94/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Partial charging
Line no. Operating line
4800 Partial charging setpoint
By hydraulically decoupling the lower buffer storage tank section, the chargeable
storage volume is reduced. As a result, the upper storage tank section is charged in a
shorter period of time. The lower storage tank section is only charged when charging of
the upper section is completed.
As soon as the temperature acquired by the temperature sensor (B4/B42) reaches the
setpoint of partial charging, the diverting valve change over to “through-port” and the
rest of the storage tank is charged also.
For changeover, a fixed switching differential of ¼ °C is used.
If the slave pointer is higher than the adjusted setpoint of partial charging, charging to
the slave pointer value takes place.
Configuration:
Extra function QX…
(operating lines 5890…5894)
Sensor input BX…
Return diverting valve Y15 in the buffer storage
tank
Buffer storage tank sensor B4 or B42
(operating lines 5930…5933)
Full charging
Full charging
Full charging temp min
Full charging sensor
B4/B42
1
0
Line no. Operating line
4810 Full charging
Off ¦ Heating mode ¦ Always
4811 Full charging temp min
4813 Full charging sensor
With B4 ¦ With B42/B41
To ensure long on times, the heat source keeps operating until the buffer storage
tank is fully charged.
Off: Function is deactivated.
Heating mode: Full charging only when there is a request for heat
Always: Full charging also when there is no request for heat
The buffer storage tank is fully charged until the slave pointer setpoint is reached,
or at least to the temperature level set here.
Select the type of buffer storage tank sensor for full charging.
95/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Charging control
Flow setpoint boost
Increase of transfer boost
Type of charging
Overtemperature protection
Recooling
Recooling heat gen/HCs
Recooling collector
Electric immersion heater
6.16 DHW storage tank
Line no. Operating line
5020 Flow setpoint boost
5021 Transfer boost
5022 Type of charging
With B3
With B3 and B31
With B3, legio B3 and B31
The DHW request to the boiler is made up of the current DHW setpoint plus the
adjustable charging increase.
Heat transfer makes it possible to transport energy from the buffer storage tank to the
DHW storage tank. In that case, the actual buffer storage tank temperature must be
higher than the actual temperature of the DHW storage tank.
The temperature differential can be set here.
The storage tank can be charged using up to 2 sensors.
It is also possible to combine partial charging with 1 sensor and the legionella function
with 2 sensors (setting 3).
Line no. Operating line
5050 Charging temp max
Solar energy charges the DHW storage tank up to the adjusted maximum DHW
charging level.
The protective collector overtemperature function can reactivate the collector pump
until the maximum storage tank temperature is reached.
Line no. Operating line
5055 Recooling temp
5056 Recooling heat gen/HCs
5057 Recooling collector
Off
Summer
Always
For recooling the DHW storage tank, there are 2 functions available:
• Heating energy can be drawn off either by space heating or the DHW storage tank.
This can be selected separately for each heating circuit (operating page heating
circuit 1…).
• If the collector is cold, the energy can be emitted to the environment via the
collector’s surfaces.
Line no. Operating line
5060 El imm heater optg mode
Substitute
Summer
Always
5061 El immersion heater release
24 h/day
DHW release
Time program 4/DHW
96/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Electric immersion heater
operating mode
Electric immersion heater
release
5062 El immersion heater control
External thermostat
DHW sensor
Substitute
The electric immersion heater is only used if the boiler delivers a fault status message
or has been shut down via boiler lock. This means that in normal situations the DHW is
always heated by the boiler.
Summer
The electric immersion heater is used as soon as all connected heating circuits have
switched to summer operation. The DHW is again heated by the boiler as soon as at
least one of the heating circuits has switched back to heating operation. But the electric
immersion heater is also used if the boiler delivers a fault status message or has been
shut down via boiler lock.
Always
DHW is heated with the electric immersion heater throughout the year. This means that
when using this application, the boiler is never required for DHW heating.
24 h/day
The electric immersion heater is always released, independent of time programs.
Example:
2358Z24
El immersion heater
control
0 6121824
DHW release
The electric immersion heater is switched on and off according to DHW release.
Example:
0 612 24
17
2358Z25
Time program 4/DHW
For the electric immersion heater, time program 4 / DHW of the local controller is taken
into account.
Example:
0 6121824
2358Z26
External thermostat
The storage tank is charged with an external thermostat without setpoint compensation
of the controller.
DHW sensor
The storage tank is charged with an external thermostat, but with setpoint
compensation of the controller.
Important: To ensure that setpoint compensation works correctly, the external
thermostat must be set to its minimum setting value.
h
h
h
97/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Plant hydraulics
A
With buffer storage tank
With primary controller /
system pump
With solar integration
Speed-controlled pump
Pump speed min
Pump speed max
Line no. Operating line
5090 With buffer storage tank
5092 With prim contr/system pump
5093 With solar integration
If a buffer storage tank is used, it is to be entered here whether the DHW storage tank
receives its heat from the buffer storage tank or directly from the boiler.
When using alternative heat sources, the buffer storage tank temperature is used as a
control criterion for the release of additional heat sources.
It is to be set whether the DHW storage tank receives its heat via the primary controller
or with the help of the system pump (depending on the type of plant).
It is to be set whether the DHW storage tank receives its heat from the solar collectors.
Line no. Operating line
5101 Pump speed min
5102 Pump speed max
The minimum speed of the heating circuit pump can be defined. It is thus possible to
negate the lowest pump speeds, which can no longer be correctly controlled.
The minimum speed of the heating circuit pump can be defined. It is thus possible to
disable the highest pump speeds, if required.
Setpoints
Mixing valve control
ctuator running time
6.17 Instantaneous DHW heater
Line no. Operating line
5406 Min setp diff to tank temp
The maximum DHW temperature setpoint controlled is the current storage tank
temperature minus the adjustable setpoint differential.
Line no. Operating line
5544 Actuator running time
Setting the running time of the actuator used with the mixing valve.
98/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Heating circuits 1 and 2
DHW sensor B3
DHW controlling element Q3
Separate circuit
6.18 Configuration
HC1 HC2
5700 5710 Heating circuit 1, 2
Using this setting, the heating circuits can be switched on and off.
Line no. Operating line
5730 DHW sensor B3
Sensors
The collector calculates the switching points including the switching differential from the
DHW setpoint and the acquired DHW storage tank temperature.
Thermostat
The DHW temperature is controlled based on the switching state of a thermostat
connected to B3.
When using a DHW thermostat, Reduced mode is not possible. This means that when
Reduced mode is active, DHW heating with the thermostat is locked.
• The adjustment of the nominal DHW temperature setpoint must be equal to or higher
than the setpoint adjustment on the thermostat (thermostat calibrated at switch-off
point)
• The flow temperature setpoint for DHW must be set to a minimum of 10 °C (has an
impact on the charging time).
• In that case, the DHW is not protected against frost.
Line no. Operating line
5731 DHW control element Q3
None
No DHW charging via Q3.
Charging pump
The DHW is heated up with a pump connected to terminals Q3 / Y3.
Diverting valve
The DHW is heated up with a diverting valve connected to terminals Q3 / Y3. With this
setting, pump Q2 becomes a boiler pump, provided the boiler pump is not yet defined
for use at a multifunctional relay output QX...
Line no. Operating line
5736 Separate circuit
The separate circuit can only be employed if a boiler cascade is used.
Line no. Operating line
Sensors
Thermostat
None
Charging pump
Diverting valve
99/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
• OFF: The separate circuit is switched off. Every boiler in use can charge the DHW
storage tank
• ON: The separate circuit is switched on. DHW charging takes place exclusively via
the boiler defined for that purpose.
Boiler
1-stage
2-stage
For the separate circuit, DHW controlling element Q3 must be set to “Diverting
valve”!
Line no. Operating line
5770 Source type
1-stage
2-stage
Modulating 3-position
Modulating UX
Without boiler sensor
2 x 1 cascade
In the case of a 1-boiler plant, the burner stage of the 1-stage boiler will be released as
soon as a valid boiler temperature setpoint becomes active.
°C
TKx
40°C
1
BR
0
TKw+SDK½
TKw
TKw-SDK
t
Connections:
Use Space Connector type
L1 Live burner P AGP8S.07A/109
Protective earth
N Neutral conductor
T1 Phase 1st burner stage
T2 1st burner stage on
S3 Input burner fault
4
Input 1st burner stage operating hours
If the required boiler temperature setpoint cannot be reached with the first burner stage,
the second burner stage will be released (release integral satisfied). When the second
burner stage is released, the first burner stage stays active, but setpoint control will be
ensured by the second stage. The first stage can be switched off again only when the
second stage is locked (reset integral satisfied).
Connections:
Use Space Connector type
L1 Live burner P AGP8S.07A/109
Protective earth
N Neutral conductor
T1 Phase 1st burner stage
T2 1st burner stage on
S3 Input burner fault
4
Input 1st burner stage operating hours
½
2371D01
100/156
Siemens Switzerland Ltd. User manual CE1U2354en
HVAC Products The settings in detail 11. May 2007
Loading...
