Siemens 1PH728 Operating Instructions Manual
Operating Instructions Edition 03/2008
Three-phase induction motor
AC COMPACT DRIVES
Type 1PH728.
Siemens Hardware
17.03.2008 10:00
Safety information
1
Description
2
Transport, assembly, and
connection
3
Start-up
4
Operation
5
Faults
6
Maintenance
7
Spare parts
8
Notes
9
Three-phase induction motor
A
C COMPACT DRIVES
1PH728
Operating Instructions
Edition 03/2008
Siemens Hardware
Safety Guidelines
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
with a safety alert symbol, indicates that minor personal injury can result if proper precautions are not taken.
CAUTION
without a safety alert symbol, indicates that property damage can result if proper precautions are not taken.
NOTICE
indicates that an unintended result or situation can occur if the corresponding information is not taken into
account.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The device/system may only be set up and used in conjunction with this documentation. Commissioning and
operation of a device/system may only be performed by qualified personnel. Within the context of the safety notes
in this documentation qualified persons are defined as persons who are authorized to commission, ground and
label devices, systems and circuits in accordance with established safety practices and standards.
Prescribed Usage
Note the following:
WARNING
This device may only be used for the applications described in the catalog or the technical description and only
in connection with devices or components from other manufacturers which have been approved or
recommended by Siemens. Correct, reliable operation of the product requires proper transport, storage,
positioning and assembly as well as careful operation and maintenance.
Trademarks
All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Automation and Drives
Postfach 48 48
90327 NÜRNBERG
GERMANY
A5E00177602A AD
Ⓟ 03/2008
Copyright © Siemens AG 2006,
2007.
Technical data subject to change
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
3
Table of contents
1 Safety information...................................................................................................................................... 7
1.1 Observing the five safety rules.......................................................................................................7
1.2 Safety and application instructions ................................................................................................7
1.3 Electromagnetic fields....................................................................................................................9
1.4 ESD-sensitive components..........................................................................................................10
1.5 EC Declaration by the Manufacturer............................................................................................12
1.6 EC Declaration of Conformity ......................................................................................................13
2 Description............................................................................................................................................... 15
2.1 Applications..................................................................................................................................15
2.2 Siemens Service Center ..............................................................................................................15
2.3 Scope of delivery .........................................................................................................................16
2.4 Rating plate..................................................................................................................................16
2.5 Layout ..........................................................................................................................................17
2.5.1 Cooling.........................................................................................................................................17
2.5.2 Drive.............................................................................................................................................18
2.5.3 Construction types .......................................................................................................................19
2.5.4 Regulations ..................................................................................................................................21
2.5.5 Degree of protection ....................................................................................................................21
3 Transport, assembly, and connection ...................................................................................................... 23
3.1 Transport, storage, and maintenance..........................................................................................23
3.1.1 Transport, storage........................................................................................................................23
3.1.2 Storage.........................................................................................................................................24
3.1.3 Preservation.................................................................................................................................25
3.2 Assembly......................................................................................................................................26
3.2.1 Installation....................................................................................................................................26
3.2.2 Mounting ......................................................................................................................................28
3.3 Electrical connection ....................................................................................................................29
3.3.1 Safety note for the drive-CLIQ interface ......................................................................................29
3.3.2 Connecting the stator winding............................
..........................................................................29
3.3.3 Connecting the ground conductor................................................................................................33
3.3.4 Connecting the fan.......................................................................................................................34
3.3.5 Connecting the speed sensor ......................................................................................................35
3.3.6 Connecting the Sensor Module....................................................................................................36
3.3.7 Connecting the temperature sensor ............................................................................................37
4 Start-up.................................................................................................................................................... 39
4.1 Preparations.................................................................................................................................39
Siemens Hardware
Table of contents
A5E00177602A AD
4 Siemens AG Operating Instructions 2.02 1PH728
4.2 Measures to be performed prior to commissioning..................................................................... 41
4.3 Power on ..................................................................................................................................... 41
5 Operation................................................................................................................................................. 43
5.1 Operation..................................................................................................................................... 43
5.2 Stoppages ................................................................................................................................... 44
5.3 Deactivating ................................................................................................................................ 45
6 Faults....................................................................................................................................................... 47
6.1 Fault diagnosis table ................................................................................................................... 47
7 Maintenance ............................................................................................................................................ 49
7.1 Maintenance................................................................................................................................ 49
7.1.1 Maintenance instructions ............................................................................................................ 49
7.1.2 Maintenance intervals ................................................................................................................. 50
7.1.3 Maintenance of the external fan.................................................................................................. 51
7.1.4 Bearings ...................................................................................................................................... 52
7.1.5 Lubrication................................................................................................................................... 52
7.1.6 Cleaning ...................................................................................................................................... 54
7.2 Inspection.................................................................................................................................... 55
7.2.1 General inspection specifications ............................................................................................... 55
7.2.2 Initial inspection........................................................................................................................... 56
7.2.3 Main service ................................................................................................................................ 56
7.3 Corrective Maintenance .............................................................................................................. 57
7.3.1 Instructions for repair .................................................................................................................. 57
7.3.2 Dismantling ................................................................................................................................. 58
7.3.3 Re-assembly ............................................................................................................................... 62
7.3.4 Screw-type connections.............................................................................................................. 65
7.3.5 Replacing the sensor module ..................................................................................................... 65
8 Spare parts.............................................................................................................................................. 67
8.1 Orders for spare parts ................................................................................................................. 67
8.2 Spare parts 1PH7........................................................................................................................ 68
9 Notes ....................................................................................................................................................... 71
Index........................................................................................................................................................ 75
Tables
Table 2-1
Technical support........................................................................................................................ 15
Table 2-2 Motor rating plate – technical specifications ............................................................................... 16
Table 2-3 Additional hoisting points for different construction types........................................................... 20
Table 2-4 Compliance with standards......................................................................................................... 21
Table 3-1 Weights of standard versions...................................................................................................... 23
Table 3-2 Pressure drop in motors with pipe connection............................................................................ 27
Table 3-3 Terminal designations (with the 1U1-1 as an example).............................................................. 30
Table 3-4 Terminal box assignments .......................................................................................................... 30
Table of contents
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
5
Table 4-1 Measurement voltage, minimum insulation resistance, critical specific insulation
resistance.....................................................................................................................................40
Table 6-1 Diagnosis table for mechanical faults ..........................................................................................47
Table 6-2 Diagnosis table for electrical faults ..............................................................................................48
Table 7-1 Measures after operating times or intervals.................................................................................51
Table 7-2 Rolling-contact bearing greases ..................................................................................................53
Table 7-3 The rotor weights for the 1PH7 three-phase motor can be found in the following table:.............58
Table 7-4 Tightening torque for screwed union connections .......................................................................65
Table 8-1 Spare parts 1PH7 ........................................................................................................................69
Figures
Figure 1-1
ESD protective measures ............................................................................................................10
Figure 2-1 Example - 1PH7 motor rating plate..............................................................................................16
Figure 2-2 Cooling process for ventilating from the non-drive end to the drive end (basic type)..................18
Figure 2-3 View from above onto construction type IM B3 ...........................................................................19
Figure 2-4 Layout of the louvered covers for various construction types......................................................20
Figure 3-1 Connecting direction UVW for connection voltages of 690 V......................................................29
Figure 3-2 Connecting direction UVW for connection voltage of 400 V/480 V .............................................29
Figure 3-3 Detailed view: Connecting points for ground conductor (1 + 2)...................................................33
Figure 3-4 Detailed view of fan, ① fan unit terminal box ..............................................................................34
Figure 3-5 Detailed view: Speed sensor connection.....................................................................................35
Figure 3-6 Electrical connection of the speed sensor ...................................................................................36
Figure 3-7 Sensor Module ① mounted on terminal box ...............................................................................37
Figure 7-1 D-end and N-end end shields with grease nipples ......................................................................54
Figure 7-2 Disassembling the rotary shaft seal.............................................................................................60
Figure 7-3 Detailed view of the speed sensor...............................................................................................60
Figure 7-4 Disassembling the speed sensor: forcing off, 1st option .............................................................61
Figure 7-5 Disassembling the speed sensor: forcing off, 2nd option ............................................................61
Figure 7-6 Sealing gap between enclosure and end shields ........................................................................63
Figure 7-7 Installing the rotary shaft seal ......................................................................................................64
Figure 8-1 Spare parts 1PH7 ........................................................................................................................68
Siemens Hardware
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
7
Safety information
1
1.1 Observing the five safety rules
For your personal safety and to prevent material damage when working on the device,
always observe the safety instructions on the product and the following five safety rules: You
must read the information provided in "Safety information".
The five safety rules:
1. isolate,
2. Protect against reconnection,
3. verify that the equipment is not live,
4. Ground and short circuit,
5. Cover or enclose adjacent components that are still live
Qualified personnel
Commissioning and operation of this machine are to be carried out by qualified personnel
only. For the purpose of the safety information in this Instruction Manual, a “qualified person”
is someone who is authorized to energize, ground, and tag equipment, systems, and circuits
in accordance with established safety procedures.
1.2 Safety and application instructions
The safe use of electrical machines
WARNING
Rotating or live parts
Rotating or live parts are dangerous.
Fatal or severe injuries and substantial material damage can occur if the required covers
are removed or if the machines are not handled, operated, or maintained properly.
Only remove covers in accordance with regulations and operate machines correctly.
Perform regular maintenance on the machine.
Siemens Hardware
Safety information
1.2 Safety and application instructions
A5E00177602A AD
8 Siemens AG Operating Instructions 2.02 1PH728
Qualified personnel
These operating instructions only contain the information that is necessary for the machines
to be used by qualified personnel in accordance with their intended purpose.
Those responsible for plant safety must ensure the following:
● The basic planning work for the system and all work relating to transportation, assembly,
installation, commissioning, maintenance and repairs is carried out by qualified personnel
and checked by responsible, suitably skilled personnel.
● The operating instructions and machine documentation are always available.
● The technical data and specifications relating to installation, connection, ambient and
operating conditions are taken into account at all times.
● The system-specific installation and safety regulations are observed.
● Personal protective equipment is used.
● Work on or in the vicinity of these machines by unqualified persons is prohibited.
● If the machines are used outside industrial areas, the installation site must be
safeguarded against unauthorized access by means of suitable protection facilities (e.g.,
safety gates) and appropriate warning signs.
These operating instructions therefore only contain the information which is necessary for
the machines to be used by qualified persons in accordance with their intended purpose.
Note
Siemens Service Center
We recommend engaging the support and services of your local Siemens Service Center for
all planning, installation, commissioning, and maintenance work.
[ID 2.02]
See also
Siemens Service Center (Page 15)
Safety information
1.3 Electromagnetic fields
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
9
1.3 Electromagnetic fields
Safety information
WARNING
Electromagnetic fields "electro smog"
Electromagnetic fields are generated by the operation of electrical power engineering
installations such as transformers, converters or motors.
Electromagnetic fields can interfere with electronic devices, which could cause them to
malfunction. For example, the operation of heart pacemakers can be impaired, potentially
leading to damage to a person's health or even death. It is therefore forbidden for persons
with heart pacemakers to enter these areas.
The plant operator is responsible for taking appropriate measures (labels and hazard
warnings) to adequately protect operating personnel and others against any possible risk.
● Observe the relevant nationally applicable health and safety regulations. In Germany,
"electromagnetic fields" are subject to regulations BGV B11 and BGR B11 stipulated by
the German statutory industrial accident insurance institution.
● Display adequate hazard warning notices.
● Place barriers around hazardous areas.
● Take measures, e.g. using shields, to reduce electromagnetic fields at their source.
● Make sure that personnel are wearing the appropriate protective gear.
[ID5003.011]
Siemens Hardware
Safety information
1.4 ESD-sensitive components
A5E00177602A AD
10 Siemens AG Operating Instructions 2.02 1PH728
1.4 ESD-sensitive components
ESD guidelines
CAUTION
Electrostatic discharge
Electronic modules contain components that can be destroyed by electrostatic discharge.
These modules can be easily destroyed by improper handling.
To protect your equipment against damage, follow the instructions given below.
● Never touch electronic modules unless absolutely necessary in the course of
maintenance and repair procedures.
● If the modules have to be touched, the body of the person concerned must be
electrostatically discharged immediately beforehand and be grounded.
● Electronic modules should not be brought into contact with electrically insulating materials
such as plastic foil, plastic parts, insulating table supports or clothing made of synthetic
fibers.
● Always place electrostatic endangered assemblies on conductive bases.
● Always store and transport electronic modules or components in conductive packaging
(e.g. metallized plastic or metal containers).
Note
If the modules are to be stored and/or transported in non-conducting packings anyway,
they must be wrapped in conducting materials before doing so. Always use suitable
material for this purpose, for example, conductive foam rubber or household aluminum
foil.
The necessary ESD protective measures for electrostatically sensitive devices are illustrated
once again in the following drawings:
d
ff f f
b
ee
aaaa
cc c
e
b
f
dd
(1) (2) (3)
Figure 1-1 ESD protective measures
Safety information
1.4 ESD-sensitive components
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
11
(1) Sitting
(2) Standing
(3) Standing/sitting
ESD protective measures
a = conductive floor
b = ESD table
c = ESD footwear
d = ESD coat
e = ESD wrist strap
f = cubicle ground connection
[ID 6006.01]
Siemens Hardware
Safety information
1.5 EC Declaration by the Manufacturer
A5E00177602A AD
12 Siemens AG Operating Instructions 2.02 1PH728
1.5 EC Declaration by the Manufacturer
Safety information
1.6 EC Declaration of Conformity
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
13
1.6 EC Declaration of Conformity
Siemens Hardware
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
15
Description
2
2.1 Applications
Overview
Three-phase motors of the 1PH7 series are used as industrial drives. They have been
designed for a wide range of applications in the fields of drive engineering and power
conversion.
They are characterized by their high power density, ruggedness, long lifetime, and overall
reliability.
[ID: 301]
2.2 Siemens Service Center
Contact for further information
Details regarding the design of this electrical machine and the permissible operating
conditions are described in these operating instructions. If you have any questions or
suggestions, or if you require additional information, please contact the Siemens Service
Center:
Table 2-1 Technical support
Phone: +49 (0)180 - 50 50 222
Europe - Germany:
Fax +49 (0)180 - 50 50 223
America - USA: Phone: +1 423 262 2522
Asia - China: Phone: +86 1064 719 990
E-Mail: support.automation@siemens.com
Internet English: www.siemens.com/automation/support-request
Internet Deutsch: www.siemens.de/automation/support-request
Siemens Hardware
Description
2.3 Scope of delivery
A5E00177602A AD
16 Siemens AG Operating Instructions 2.02 1PH728
2.3 Scope of delivery
Checking the scope of delivery for completeness
The drive systems are put together on an individual basis. When you take receipt of the
delivery, please check immediately whether the scope of the delivery matches up with the
accompanying documents. Siemens will not accept any claims relating to items missing from
the delivery and that are submitted at a later date.
● Report any apparent transport damage to the delivery agent immediately.
● Report any apparent defects/missing components to the appropriate SIEMENS office
immediately.
These Operating Instructions are included in the scope of delivery and must be kept in a
location where they can be easily accessed.
The rating plate enclosed as a loose item with the delivery ensures that the motor data can
also be affixed on or near the machine or system.
[ID: 303.02]
2.4 Rating plate
The motor rating plate shows the technical specifications applicable to the supplied motor.
a0RW
*HZ:7 NJ
3++%$$ 1R17'
,3,0
%
7K&O
)
9
$
N: FRV
+] PLQ
(1(&
PLQ
PD[
(1&2'(5B+BB65
.7<
'(:
0$'(,1*(50$1<'1íUQEHUJ
0$'(,1*(50$1<'1íUQEHUJ
SIEMENS
ແ
໎
ໍ
໌
໋
໊
້
່
ໆ
ໄ
ໂ
ໃ
Figure 2-1 Example - 1PH7 motor rating plate
Table 2-2 Motor rating plate – technical specifications
1 Motor type: Three-phase compact motor
2 Type of construction
3 Degree of protection
4 Rated voltage [V] and winding connection
5 Rated current [A]
Description
2.5 Layout
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
17
6 Rated output [kW]
7 Standards and regulations
8 Code, sensor type
9 Serial number
10 Motor weight [kg]
11 Temperature class
12 Rated speed [rpm]
13 Rated frequency [Hz]
14 Power factor [cos φ]
15 Maximum speed [rpm]
[ID: 304.02]
2.5 Layout
2.5.1 Cooling
Description
The three-phase motors of the 1PH7 series are externally ventilated, low-voltage induction
motors with a squirrel-cage rotor and a separately driven fan unit mounted as standard. They
are of an enclosed design, with an internal cooling circuit (cooling method IC 06; DIN EN IEC
60034-6).
The separately driven fan unit and the terminal box can be mounted in a different position
depending on the order.
Siemens Hardware
Description
2.5 Layout
A5E00177602A AD
18 Siemens AG Operating Instructions 2.02 1PH728
Figure 2-2 Cooling process for ventilating from the non-drive end to the drive end (basic type)
A KTY 84-130 temperature sensor is installed in the stator winding to monitor the winding.
Depending on the order, various additional devices such as a space heater or sensor
systems can be installed or built on.
NOTICE
A minimum clearance of 170 mm from devices added on by the customer must be
observed at the air intake opening and at the air outlet openings, in order to guarantee the
necessary flow of cooling air.
[ID: 309.01]
2.5.2 Drive
Description
The variable-speed, three-phase motors of the 1PH7 series are supplied with power by a
frequency converter.
[ID: 313]
Description
2.5 Layout
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
19
2.5.3 Construction types
Further potential applications
The construction type of the motor is stated on the rating plate.
CAUTION
During transportation, motors must only be hoisted in a position corresponding to their
basic construction type.
Basic construction type acc. to
rating plate
Type Other applications in construction
type
IM B3 1PH7 284…1PH7 288 IM B6, IM B7, IM B8
IM B35 1PH7 284…1PH7 288
Optional basic construction
types
Type Other applications in construction
type
IM V5 1PH7 284 ... 1PH7 288 IM V6
IM V 15 1PH7 284 ... 1PH7 288 IM V 36
Additional hoisting points for different construction types (option)
Additional hoisting points are provided for those construction types that differ from the basic
construction types IM B3 and IM 35.
ཱི
ཱི
Figure 2-3 View from above onto construction type IM B3
Siemens Hardware
Description
2.5 Layout
A5E00177602A AD
20 Siemens AG Operating Instructions 2.02 1PH728
Two additional rotatable eyebolts are supplied with these construction types, which must be
bolted on as specified in the table below.
Table 2-3 Additional hoisting points for different construction types
Hoisting points
Construction type
① ② ③ ④
IM B6 X X
IM B7 X X
IM B8 X X
IM V5 X X
IM V6 X X
IM V36 X X
IM V15 X X
Layout of the louvered covers for various construction types
For those construction types that differ from basic construction types IM B3 and IM B35, the
louvered covers must be positioned as follows at the air inlet and air outlet in order to
maintain the degree of protection:
,099
,099
Figure 2-4 Layout of the louvered covers for various construction types
In vertical construction types too, the motor in the separately driven fan must face upwards.
Description
2.5 Layout
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
21
[ID: 315.01]
2.5.4 Regulations
Overview
The motors comply with the following regulations under IEC EN 60034:
Table 2-4 Compliance with standards
Feature Standard
Dimensions and operating performance IEC/EN 60034-1
Degree of protection (1) IEC/EN 60034-5
Cooling IEC/EN 60034-6
Type of construction IEC/EN 60034-7
Noise emission IEC/EN 60034-9
Vibration severity levels IEC/EN 60034-14
(1) See the rating plate for the degree of machine protection.
[ID: 319.01]
2.5.5 Degree of protection
The three-phase motors of the 1PH7 series are built to degree of protection IP55 in
accordance with IEC EN 60034-5.
The shaft gland at the drive end is built to degree of protection IP54 as standard.
The standard version of the motors is not suitable for operation in a salt-laden or corrosive
atmosphere, nor for installation outdoors.
[ID: 320.01]
Siemens Hardware
A5E00177602A AD
Siemens AG Operating Instructions 2.02 1PH728
23
Transport, assembly, and connection
3
3.1 Transport, storage, and maintenance
3.1.1 Transport, storage
Instructions relevant to safety
Please observe the following instructions on the transportation and storage of motors.
WARNING
Motors may only be attached to and hoisted by the main eyebolts that are located at the
end shields. Auxiliary eyebolts, e.g. on fan cowls and cooler attachments, are suitable only
for hoisting the respective parts.
To hoist the motor, in particular at attachments and built-on assemblies, use suitable cableguidance or spreading equipment.
Observe the lifting capacity of the hoisting gear.
(For weight, see rating plate and table "Weights of standard versions").
Table 3-1 Weights of standard versions
Type Weight
1PH7 284 Approx. 1.3 t
1PH7 286 Approx. 1.5 t
1PH7 288 Approx. 1.8 t
NOTICE
If the motor is not immediately commissioned, then it should be stored in a dry room which
is free from vibration and shock.
Siemens Hardware
