Showtec LED Operator 6 User manual

MANUAL

ENGLISH

LED Operator 6 V2

Ordercode: 50728

Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherland s

LED Operator 6

Table of contents

Warning ........................................................................................................................................................................... 2

Unpacking Instructions ............................................................................................................................................. 2

Safety Instructions ..................................................................................................................................................... 2

Operating Determinations ....................................................................................................................................... 3

Connection with the mains ..................................................................................................................................... 4

Return Procedure ...................................................................................................................................................... 4

Claims ......................................................................................................................................................................... 4

Description of the device ............................................................................................................................................. 5

Overview .................................................................................................................................................................... 5

Frontside ..................................................................................................................................................................... 6

Backside ..................................................................................................................................................................... 7

Installation ...................................................................................................................................................................... 7

Set Up and Operation ................................................................................................................................................... 7

Fixture Linking ............................................................................................................................................................. 7

Data Cabling ............................................................................................................................................................. 8

Control Modes ........................................................................................................................................................... 8

1. Color Presets ....................................................................................................................................................... 9

2. Color Fade .......................................................................................................................................................... 9

3. Auto Mode ........................................................................................................................................................ 10

4. Chase ................................................................................................................................................................. 10

5. RGB Offset ......................................................................................................................................................... 10

6. Color Macro ...................................................................................................................................................... 10

7. Sound-Override ................................................................................................................................................ 11

8. Strobe-Override ................................................................................................................................................ 11

9. Blackout ............................................................................................................................................................. 11

10. Manual RGBWAUV ......................................................................................................................................... 11

Maintenance ................................................................................................................................................................ 12

Troubleshooting ........................................................................................................................................................... 12

No Light ..................................................................................................................................................................... 12

No Response to DMX .............................................................................................................................................. 12

Product Specifications ................................................................................................................................................ 13

Dimensions ................................................................................................................................................................... 14









































1

Ordercode: 50728

LED Operator 6

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixtur e mu st be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.

Your shipment includes:

 Showtec LED Operator 6
 DC power adapter (1,5 m)
 User manual

Safety Instructions

Every person involved with the installation, operation and maintenance of this device has to:

 be qualified
 follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to
warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

2

Ordercode: 50728

LED Operator 6

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.

 Never let the power cord come into contact with other cables! Handle the power cord and all

connections with the mains with particular caution!

 Never remove warning or informative labels from the unit.
 Never use anything to cover the ground contact.
 Never leave any cables lying around.
 Do not insert objects into air vents.
 Do not open the device and do not modify the device.
 Do not connect this device to a dimmer pack.
 Do not switch the device on and off in short intervals, as this would reduce the device’s life.
 Do not shake the device. Avoid brute force when installing or operating the device.
 Only use device indoor, avoid contact with water or other liquids.
 Only operate the fixture after having checked that the housing is firmly closed and all screws are

tightly fastened.

 Only operate the device after having familiarized with its functions.
 Avoid flames and do not put close to flammable liquids or gases.
 Always keep case closed while operating.
 Always disconnect power from the mains, when device is not used or before cleaning! Only handle

the power cord by the plug. Never pull out the plug by tugging the power cord.

 Make sure that the device is not exposed to extreme heat, moisture or dust.
 Make sure that the available voltage is not higher than stated on the rear panel.
 Make sure that the power cord is never crimped or damaged. Check the device and the power

cord from time to time.

 If device is dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

 If the device has been e xposed to drastic temperature fluctuation (e.g. after transportation), do not

switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.

 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Showtec dealer for service.

 For adult use only. Device must be installed out of the reach of children. Never leave the unit running

unattended.

 The user is responsible for correct positioning and operating of the LED Operator 6. The manufacturer

will not accept liability for damages caused by the misuse or incorrect installation of this device.

This device falls under protection class I. Therefore it is essential to connect the yellow/green



conductor to earth.

 Repairs, servicing and electric connection must be carried out by a qualified technician.
 WARRANTY: Till one year after date of purchase.

Operating Determinations

 This device is not designed for permanent operation. Consistent operation breaks will ensure that the

device will serve you for a long time without defects.

 The minimum distance between light-output and the illuminated surface must be more than 1 meter.
 The maximum ambient temperature ta = 40° C must never be exceeded.
 The relative humidity must not excee d 50 % with an ambient temperature of 40° C.
 If this device is operated in any other way, than the one described in this manual, the produ ct may

suffer damages and the warranty becomes void.

 Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.

You endanger your own safety and the safety of others!

3

Ordercode: 50728

LED Operator 6

Connection with the mains

Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.

International EU Cable UK Cable US Cable Pin

L BROWN RED YELLOW/COPPER PHASE

N BLUE BLACK SILVER NEUTRAL

YELLOW/GREEN GREEN GREEN PROTECTIVE GROUND

Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

Return Procedure

Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Au thorization Number (RMA numb er). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.

Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:

01) Your name.

02) Your address.

03) Your phone number.

04) A brief description of the symptoms.

Claims

The client has the ob ligation to check the delivered goods immediately upon delivery for any short­comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims wi th the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

4
