Sherwood VD-4502 User Manual

VD-4502

Introduction

2

UNPACKING AND INSTALLATION

READ THIS BEFORE OPERATING YOUR UNIT

CAUTION:

TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute
a risk of electric shock to persons.

This symbol is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.

WARNING

: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

FCC INFORMATION(FOR U.S.A.)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION : Any changes or modifications in construction of this device which are not expressly approved by

the party responsible for compliance could void the user’s authority to operate the equipment.

CAUTION : USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER

THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.

CAUTION

Invisible laser radiation when the unit is open.
Do not stare into beam.

NOTE ON RECYCLING (FOR EUROPE)

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in
accordance with the local recycling regulations.
When discarding the unit, comply with local rules or regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with the local
regulations concerning chemical waste.
This product and the accessories packed together constitute the applicable product according to the
WEEE directive except batteries.

Safety Introduction

3

1. Read Instructions – All the safety and operating instructions
should be read before the product is operated.

2. Retain Instructions – The safety and operating instructions
should be retained for future reference.

3. Heed Warnings – All warnings on the product and in the
operating instructions should be adhered to.

4. Follow Instructions – All operating and use instructions should
be followed.

5. Cleaning – Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

6. Attachments – Do not use attachments not recommended by
the product manufacturer as they may cause hazards.

7. Water and Moisture – Do not use this product near water – for
example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement, or near a swimming pool; and the like.

8. Accessories – Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory
recommended by the manufacturer.

9. A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause
the product and cart combination to overturn.

10. Ventilation – Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not be
blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation
is provided or the manufacturer’s instructions
have been adhered to.

11. Power Sources – This product should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your home,
consult your product dealer or local power
company. For products intended to operate from battery power,
or other sources, refer to the operating instructions.

12. Grounding or Polarization – This product may be equipped
with a polarized alternating-current line plug (a plug having one
blade wider than the other). This plug will fit into the power
outlet only one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the
polarized plug. Alternate Warnings – This product is equipped
with a three-wire grounding-type plug, a plug having a
third(grounding) pin. This plug will only fit into a grounding-type
power outlet. this is a safety feature. If you are unable to insert
the plug into the outlet, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the
grounding-type plug.

13. Power – Cord Protection – Power-supply cords should be
routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where
they exit from the product.

14. Outdoor Antenna Grounding – If an outside antenna or cable
system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection
against voltage surges and built-up static charges. Article 810 of
the National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of
antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode. See Figure 1.

15. Lightning – For added protection for this product during a
lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the
product due to lightning and power-line surges.

16. Power Lines – An outside antenna system should not be
located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or
circuits as contact with them might be fatal.

17. Overloading – Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
fire or electric shock.

18. Object and Liquid Entry – Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.

19. Servicing – Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service
personnel.

20. Damage Requiring Service – Unplug this product form the
wall outlet and refer servicing to qualified service personnel
under the following conditions :

a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the

product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions as an improper

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to

restore the product to its normal operation.
e) If the product has been dropped or damaged in any way,

and
f) When the product exhibits a distinct change in performance -

this indicates a need for service.

21. Replacement Parts – When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics
as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.

22. Safety Check – Upon completion of any service or repairs to
this product, ask the service technician to perform safety checks
to determine that the product is in proper operating condition.

23. Wall or Ceiling Mounting – The product should be mounted to
a wall or ceiling only as recommended by the manufacturer.

24. Heat – The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.

Notes:

1. Item 12 is not required except for grounded or polarized product.

2. Item 14 and 16 are not required except for units provided with
antenna terminals.

3. Item 14 complies with UL in U.S.A.

Precautions

4

FOR YOUR SAFETY

PRECAUTIONS

U.S.A

and

CANADA

120V

Units shipped to the U.S.A and Canada are designed for operation on 120V AC only.
Safety precaution with use of a polarized AC plug.

However, some products may be supplied with a nonpolarized plug.

CAUTION

: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

ATTENTION

: Pour éviter chocs électriques, introduire la lame la plus large de la fiche

dans la borne correspondante de la prise et pousser jusqu’ au fond.

CHINA,

EUROPE,

AUSTRALIA

and

other

countries

220V

~

240V

The available power supply voltage differs according to country or region. However, this unit
is equipped with an Automatic Voltage Selector.
The power supply voltage of the area where the unit will be used automatically meets the
required voltage within the range of AC 220 - 240 V, without any manual voltage adjustment.
To ensure safe operation, the three-pin plug supplied must be inserted only into a
standard three-pin power point which is effectively earthed through the normal
household wiring. Extension cords used with the equipment must be three-core and be
correctly wired to provide connection to earth.
Improper extension cords are a major cause of fatalities. The fact that the equipment
operates satisfactorily does not imply that the power point is earthed and that the installation
is completely safe. For your safety, if in any doubt about the effective earthing of the power
point, consult a qualified electrician.

■ Moisture condensation
Moisture may form on the lens in the following conditions.

• Immediately after a heater has been turned on.

• In a steamy or very humid room.

• When this unit is moved from a cold place to a warm one.
If moisture forms inside this unit, it may not operate properly.
In this case, turn on the power and wait about one hour for the moisture to evaporate.

■ If there is noise interference on the TV while a broadcast is being received.
Depending on the reception condition of the TV, interference may appear on the TV screen while
you are watching a TV broadcast and this unit is left on. This is not a malfunction of this unit or the TV.
To watch a TV broadcast, turn off this unit.

■ Do not transport this unit with discs left in it.

■ Do not place on the component such as amplifier or receiver that generates heat.

If so, the temperature inside this unit rises and malfunction may occur.

CAUTION

• Leave a space around the unit for sufficient ventilation.

• Avoid installation in extremely hot or cold locations, or in an area that is exposed to direct sunlight or heating equipment.

• Keep the unit free from moisture, water, and dust.

• Do not let foreign objects in the unit.

• The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table-cloths, curtains, etc.

• No naked flame sources, such as lighted candles, should be placed on the unit.

• Please be care the environmental aspects of battery disposal.

• The unit shall not be exposed to dripping or splashing for use.

• No objects filled with liquids, such as vases, shall be placed on the unit.

• Do not let insecticides, benzene, and thinner come in contact with the set.

• Never disassemble or modify the unit in any way.

■

Notes on the AC power cord and the wall outlet

• The unit is not disconnected from the AC power source(mains) as long as it is connected to the wall outlet, even if the unit has been turned off.

• When disconnecting the power cord from the wall outlet, always pull the plug, not the power cord.

• Disconnect the plug from the wall outlet when not using the unit for long periods of time.

• The wall outlet shall be installed near the unit and shall be easily accessible.

Contents

5

Introduction / Safety Introduction / Precautions ............................................................................................. 2

Getting Started

Notes on Discs............................................................................................................................................... 6

Playable Discs / Notes on DVD Videos / About Video CDs / MP3/WMA/JPEG/DivX Compatibility /
Care and Handling Discs / Differences in Disc Composition / Notes on Copyright

Facilities and Connections

Control Position and Names ......................................................................................................................... 9

Front Panel / Rear Panel / Display / Remote Controller

Preparing the Remote Controller ................................................................................................................. 12

Inserting the Batteries / Using the Remote Controller

System Connections.................................................................................................................................... 13

Before Making Any Connections / AV Cable & Sockets / Connecting to a TV /
Connecting to TV with SCART connector / Connecting to A/V Amplifier or Receiver

Basic Operations

Turning on.................................................................................................................................................... 16

Connecting the POWER

Basic Playback............................................................................................................................................. 17

Starting Playback / Various Playback / Playing back MP3/WMA/JPEG
Rotating a Picture(JPEG Files Only) / Various Play Modes

Advanced Operations

Other Operations ......................................................................................................................................... 20

Locating a Specific Title / Chapter / Track / File by Entering the Numbers /
CD Program Playback / MP3 / WMA / JPEG / Program Playback /
Random Play / Repeat Play / A-B Repeat Play / Viewing Information

DVD Settings................................................................................................................................................ 26

Selecting a Playback Audio Setting / Changing the Subtitle Language /
Changing the Camera Angle

Function Setup

Customizing the Function Settings............................................................................................................... 27

Progressive Setting / Setting Steps / General Setup / Audio Setup / Preferences

Others

Troubleshooting .......................................................................................................................................... 32

Specifications .............................................................................................................................................. 34

DVD Menu Language Code List ................................................................................................................. 35

Notes on Discs

6

This DVD Player can playback the following discs.

*1

This unit can play CD-R and CD-RW discs recorded in
CD Audio or MP3/WMA/JPEG in accordance with the
ISO 9660 format. However, there may be some discs
that cannot be played back with this unit. The causes of
this impossibility include incompletion of disc finalization
and the recording characteristics of the recorder as well
as the properties, damage or stain of the disc in use and
stain or condensation on the pickup lens of this unit. For
details, please refer to the instruction manual of the
recorder.

• You cannot playback discs other than those listed
above.

• This unit can play SVCDs, but some functions will not
work.

• This unit can play DVD-R, DVD+R, DVD-RW, and
DVD+RW discs, but depending on the recording unit,
the disc manufacturer, etc., playback sometimes may
not be possible.

• This player cannot play back any of the following discs.

– DVD AUDIO discs
– DVD-ROM discs
– DVD-RAM discs
– SACD discs
– CD-ROM discs (Except MP3 and JPEG discs

[ISO 9660 level 1])
– VSD discs
– CDV discs (Only the audio part can be reproduced.)
– CD-G/CD-EG/CD-EXTRA discs (Only the audio can

be reproduced.)
– Photo CD discs (Never attempt to play them.)

• This DVD player uses the PAL/NTSC color system,
and cannot playback DVD videos recorded in any
other color system (SECAM, etc.).

• Avoid using heart-shaped or octagonal discs. Playing
irregularly shaped discs may damage the internal
mechanism of the DVD receiver.

• Do not use discs that have residue from adhensive
tape, rental discs that have peeling labels, or discs that
have custom labels or stickers. Otherwise, you may
not be able to eject the discs or the DVD receiver may
become inoperative.

About playing copy-controlled CDs

Some audio CDs feature copy protection that doesn’t
conform to the official CD standard. Since these are
nonstandard discs, they may not play properly in the
VD-4502.

■

Region code

• DVD players and DVD Videos have their own Region
Code numbers which are assigned to each country or
area as shown below. DVD players are set to your
Region Code number at the factory. As a result, if the
region code number of this DVD player is different
from that of the DVD Video, playback of the DVD
Video will not be allowed by the DVD player.

Examples of playerble DVD Videos :

• In U. S. A • In Europe

Playable Discs

Notes on DVD Videos

Notes on Discs

7

• Folder and file names are displayed up to 11 characters.

• Characters except “A~Z”, “0~9”, “ - ” may be not displayed.

• The playback order of folders and files shown in the
menu may differ from the order shown in a PC.

• This unit supports multi-session discs. Some
multi-session discs may take a long time to load and
some may not be loaded at all.

Notes for making a private disc.

• Use “UDF format” as the disc format for
DVD-R/DVD-RW, DVD+R/DVD+RW.

• Use “ISO 9660” as the disc format for CD-R/CD-RW.

• Folders can be up to eight levels deep.

• Some disc may not play due to disc characteristics,
recording conditions, etc.

MP3

• MP3 files must have a “.mp3” or “.MP3” file name extension.

• It is recommended that you record your material at a

44.1kHz sampling rate, using the 128 kbps data transfer rate.

• Fixed bit-rate files are recommended. Variable
bit-rate(VBR) files are playable, but playing time may be
displayed incorrectly.

• ID3 Tag is not available.

• MP3i and MP3 Pro are not available.

JPEG

• JPEG files must have a “.jpg”, “.JPG”, “.jpeg” or “.JPEG”
file name extension.

• It is recommended that you record your material at a
720X480 pixel resolution.

• This unit cannot play a baseline JPEG file of more than
6000X4500 pixels and a progressive JPEG file of more
than 5120X3840 pixels.

WMA

• WMA files must have a “.wma” or “.WMA” file name
extension.

• It is recommended that you record your material at a bit
rate of 64 kbps or higher.

• WMA Tag is not available.

• This unit cannot play copyright protected files and files
recorded with a bit rate under 32kbps.

When saving files onto media

Ensure that the session is closed or finalized when data
has been written on media. There are cases where media
on which the session has not be closed or finalized will
not be played back correctly with this equipment.

• There are cases where the folder names and file
names will not be displayed correctly depending on the
software used to save them.

• Do not store files or folders other than MP3, WMA or
JPEG on media to be played back with this equipment.

• It is recommended that ten or less sessions are stored
when recording MP3 files onto a media.

• In case of a multisession disc, some time may be

required until playback begins.

• There are cases where playback is not possible when
MP3/WMA/JPEG files (CD-ROM) and music CD
information (CD-DA) are saved on the same media.

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of

Dolby Laboratories.

DTS and DTS Digital Out are trademarks of Digital

Theater Systems, Inc.

MP3/WMA/JPEG/DivX Compatibility

This DVD Player supports Video CDs equipped with the
PBC(Version 2.0) function (PBC is the abbreviation for
Playback Control).
You can enjoy two playback variations depending on the
type of disc.

• Video CD not equipped with PBC function

(Version 1.1)

Sound and movies can be played on this DVD Player
in the same way as an audio CD.

• Video CD equipped with PBC function (Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback with
interactive software and search function using the
menu displayed on the TV screen (Menu Playback).
Some of the functions described in this Instruction
Manual may not work with some discs.

About Video CDs

• In handling a disc, hold it carefully with edges.

• Do not stick paper or write anything on the printed
surface.

• Fingermarks and dust on the recorded surface should
be carefully wiped off with a soft cloth. Wipe straight
from the inside to the outside of the disc.

• Always keep the discs in their cases after use to
protect them from dust and scratches.

• Do not use a cracked, deformed, or repaired disc.
These discs are easily broken and may cause serious
personal injury and apparatus malfunction.

Notes:

• Because the temperature inside this unit is very high,
in case of no further playback of disc, unload the disc
to prevent the high temperature from deforming the
disc.

• Do not expose discs to direct sunlight, high humidity or
high temperature for a long time.

• When loading or unloading a disc in the disc tray,
always place it with the printed side up.

■ DVD

All discs are divided up into smaller, more manageable
sections so that you can find specific content more easily.
DVDs are divided into one or more titles. Each title may
be further divided into several chapters. Occasionally, a
chapter may contain index points, effectively dividing the
chapter up into several parts.

■ CD

Video CDs and CDs are divided into a number of tracks.
In rare cases, a track may contain a number of index
points, effectively dividing the track up into several parts.

■ MP3/WMA/ JPEG

MP3 (MPEG1 Audio Layer 3) is a compressed audio file
format.
JPEG is a format for saving image files, such as those
containing digital photographs or illustrations.
Tracks within folders are automatically numbered T_001,
T_002, etc.

• Please check the copyright laws in your country to
record from DVD, Audio CD, MP3, WMA and JPEG
disc, etc. Recording of copyrighted material may
infringe copyright laws.

• DVD Video is protected by the copyguard system.

• When you connect the unit to your VCR directly, the
copyguard system activates and the picture may not
be played back correctly.

This product incorporates copyright protection technology
that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection
technology must be authorized by Macrovision, and is
intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.

Notes on Discs

8

Care and Handling of Discs Differences in Disc Composition

Notes on Copyright

Control Position and Name

9

Front Panel

Rear Panel

①

POWER button

Turns on the main power supply.

②

STANDBY indicator

Lights in the standby mode.

③

Display

④

Disc tray

Toggle for standby and on.

⑤

Open/Close

5

button

Press to open or close the disc tray.

⑥

Play/Pause button

Begins to play disc (close disc tray first if it is open).
Temporarily stops playback when a disc is playing.
Press this button again for normal playback.

⑦

Stop button

Stops playing a disc. When disc is playing, if you press
Stop and Play , the disc will start resume play.
When Stop is pressed again during stop mode, the
resume function is canceled.

⑧

Skip buttons

Allow you to move to the previous chapter or track / the
next chapter or track on a disc.

①

DIGITAL OUTPUT COAXIAL jack

Use coaxial cable to connect your DVD Player to an AV
component that features digital input capability. If the
component has a Dolby Digital or DTS decoder, you
can enjoy theater-quality multichannel sound.

②

DIGITAL OUTPUT OPTICAL jack

Use optical cable to connect your DVD Player to an AV
component that features digital input capability. If the
component has a Dolby Digital or DTS decoder, you
can enjoy theater-quality multichannel sound.

③

ANALOG OUTPUT jacks

Insert audio cables (left and rights) to these jacks on
your DVD Player and to the corresponding Audio Input
jacks (left and right) on your TV or receiver.

④

VIDEO OUTPUT S-VIDEO jack

If your TV has a S-Video jack, you can connect an
S-Video cable to your TV and to your DVD Player for
improved video quality. The S-Video cable only carries
the video signal; remember to connect the left and right
audio cables.

⑤

VIDEO OUTPUT VIDEO jack

Connect a video cable to this jack and to the Video
Input jack on your TV.

⑥

VIDEO OUTPUT COMPONENT (P

R/CR

, PB/CB, Y) jacks

If your TV has component inputs, you can connect a
component video cable to your TV and to your DVD
Player for ideal video quality. The component video
cable only carries the video signal; remember to
connect the left and right audio cables. If you connect a
TV that is compatible with a Progressive scan signal,
you can enjoy both Interlaced and Progressive scan.

⑦

AV SCART OUTPUT CONNECTOR(Regional Option)

Refer to CONNECTING TO TV WITH SCART
CONNECTOR(Regional Option)

Control Position and Name

10

①

Disc indicators

Indicates the type of disc currently loaded.

②

Play/Pause indicators

Illuminates in play or pause mode.

③

PROGRESSIVE indicator

Illuminates when the DVD player is set to progressive
mode.

④

PBC indicator

Illuminates when PBC is on for Video CD.

⑤

TITLE indicator

Illuminates to indicate the current title number.

⑥

CHAPTER indicator

Illuminatesto indicate the current chapter number of DVD disc.

⑦

TRACK indicator

Illuminates to Indicate the current track number of
Video CD or CD.

⑧

Time indicator

Indicates playing time.

⑨

MEM. indicator

Illuminates during memory playback.

⑩

REPEAT indicator

Illuminates during repeat playback.

⑪

RESUME indicator

Illuminates when the player is ready to resume
playback.

⑫

Parental Lock indicator

Illuminates in parental lock mode.

⑬

Multifunction indicator

Indicates operating status, messages, etc.

⑭

RANDOM indicator

Illuminates during random playback.

• During DVD-Video playback:

Notes

Some discs may not display chapter numbers.

• During CD playback:

• During MP3/WMA playback:

Notes

Track number is consecutive.

• During JPEG image playback:

Note

The disc indicator does not light up for CDs that
contain JPEG images.

Display

■ Display Examples

Control Position and Name

11

①

POWER ON button

②

ZOOM button

③

PROGRESSIVE button

When component video connection is used to connect
this player and TV is compatible with progressive, press
to enjoy the progressive video image.

④

RANDOM button

Press to do random playback.

⑤

REPEAT button

Press to repeat playback. You can repeat a title,
chapter, track or entire discs.

⑥

A-B button

Press to play section A-B repeatedly.

⑦

PAUSE/STEP button

Temporarily stops playback when a disc is playing.
Press PLAY button for normal playback.

⑧

ANGLE button

Press to select various camera angles on a disc.

⑨

AUDIO button

Press to select various audio languages on a disc.
When playing a Video CD, press to select the audio
channel.

⑩

ENTER button

Press this button to select and execute a highlighted
menu item.

⑪

Cursor buttons ( )

Use the cursor buttons to select the items or settings.

⑫

MENU button

Displays the DVD Disc Menu on the TV screen in play
mode.

⑬

TITLE / PBC button

If some DVD Videos which contain more than one title
may have the menu like as a list of the titles, the TITLE
button can be used to select the desires title.
(The details of operation differ depending on the disc used.)
When playing a Video CD equipped with PBC function,
DVD Player will automatically enter the PBC on mode.
Press once to turn PBC off and press again to turn on.

⑭

Number buttons(0~9)

Select numbers by pressing these buttons.

⑮

PROGRAM button

Press to see Program Edit Display on the screen in
stop mode.

⑯

STANDBY button

⑰

B.MARK button

⑱

OPEN/CLOSE button

Press to open or close the disc tray.

⑲

SLOW buttons

Allow you to play movies in slow mode. Each time you
press this button, slow speed will be changed, reverse
SLOW cannot be activated.

⑳

SKIP buttons

Allow you to move to the previous chapter or track / the
next chapter or track on a disc.

󱇽

SEARCH buttons

Allow you to search in reverse or forward through a disc
while it is in play mode. Each time you press these
buttons, search speed changes.

󱇾

STOP button

Stops playing a disc. When a disc is playing, if you
press STOP and PLAY , the disc will start
resume play. When STOP is pressed again during
stop mode, the resume function is canceled.

󱇿

PLAY button

Begins to play disc (close disc tray first if it is open).

󱈀

SUBTITLE button

Press to select various subtitle language on a disc.

󱈁

SETUP button

Press to call up the Setup menu programmed on the DVD.
Depending on the DVD, the Setup menu may be
identical to DVD menu or title menu.(In Stop mode only)

󱈂

RETURN button

When you’re using the DVD Player’s menu system,
press this button to return to the preceding menu screen.

󱈃

DISPLAY button

Press this button while you’re playing a disc to see
contained various playback features and gives you the
information about the disc you’re playing.

󱈄

CLEAR button

Press to clear entered values and settings.

Remote Controller

Preparing the Remote Controller

12

①

Remove the battery compartment cover by
pressing the tab and lifting up the cover.

②

Insert the two batteries (size AAA/R3).

Be sure to match the + and – ends of the batteries with
the diagram inside the battery compartment.

③

Replace the battery compartment cover.

Notes

• Do not mix new batteries with old batteries or different
kinds of batteries.

• To avoid corrosion, remove the batteries if the remote
controller is not to be used for a long time.

• Remove dead batteries immediately to avoid damage
from corrosion. If the remote controller does not
operate smoothly, replace both batteries at the same
time.

• The life of the batteries supplied is about six months
but this will vary depending on usage.

Point the remote controller toward the remote control
sensor.

Notes

• Place the unit away from strong light such as direct
sunlight or inverted fluorescent light which can prevent
proper operation of the remote controller.

• Using another remote controller of the same type in
the same room or using the unit near equipment which
uses infrared rays may cause operational interference.

• Do not put any object such as a book on the remote
controller. The buttons of the remote controller may be
pressed by mistake and drain the batteries.

• Make sure the audio rack doors do not have colored
glass. Placing the unit behind such doors may prevent
proper remote controller operation.

• If there is any obstacle between the remote controller
and the remote control sensor, the remote controller
will not operate.

Inserting the Batteries Using the Remote Controller
