below the
model number and serial number which
are located on the bottom of the unit.
Please retain this information.
Operation References
VL-WD250U
Preparation
Basic Operations
Useful Features
Advanced Features
Appendix
• See page 69 for use of Demo mode.
Thank you for purchasing this camcorder from SHARP.
The camcorder will enhance your home video enjoyment and allow you to capture those
special moments. Please read this operation manual to familiarize yourself with the
camcorder’s features, so that you will get the most out of it. The video techniques section will
help you fully enjoy the many features this camcorder offers, and expand your video world.
Important Information for Consumers in the U.S.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol warns the user of uninsulated voltage within the
unit that can cause dangerous electric shocks.
This symbol alerts the user that there are important operating
and maintenance instructions in the literature accompanying
this unit.
CAUTION
(applies to the supplied AC adapter)
TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
COVER. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
If the AC adapter is misplaced or
needs to be replaced, obtain the
same type of adapter from a SHARP
service center of your dealer.
PRODUCT DISPOSAL
This Product utilizes tin-lead solder, and a fluorescent lamp containing a small
amount of mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your
local authorities or the Electronics Industries Alliance: www.eiae.org.
BATTERY DISPOSAL
CONTAINS LITHIUM-ION RECHARGEABLE BATTERY. MUST BE RECYCLED OR
DISPOSED OF PROPERLY. CONTACT LOCAL AGENCIES FOR INFORMATION ON
RECYCLING AND DISPOSAL PLANS IN YOUR AREA.
i
WARNING—FCC Regulations state that any unauthorized changes or modifica-
tions to this equipment not expressly approved by the manufacturer could void the
user’s authority to operate this equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the distance between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
A shielded I/F cable is required to insure compliance with FCC regulations for Class B
computing equipment.
DECLARATION OF CONFORMITY
Sharp Camcorder
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
RESPONSIBLE PARTY:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430
Phone: 1-800-BE-SHARP
CAUTION ON LITHIUM BATTERY (MEMORY BACKUP BATTERY)
If a battery is reversed (positive end where the negative end belongs and vice
versa), it can overheat and rupture. This has happened when young children install
batteries backwards. Warn children
not
to take out batteries or install them.
Parents
should install the lithium battery in the camcorder.
COPYRIGHT WARNING: It is the intent of SHARP that this unit be used in full
compliance with the copyright laws of the United States and
that prior permission be obtained from copyright owners
whenever necessary.
NOTE
The camcorder’s LCD panel is a very high technology product with more than
61,000 thin-film transistors*, giving you fine picture detail. Occasionally, a pixel may
appear on the screen as a fixed point of blue, green, red, or black. Please note that
this does not affect your camcorder’s performance.
*Specifications are subject to change without notice.
ii
IMPORTANT SAFEGUARDS
1. Read Instructions—All the safety and
operating instructions should be read
before the product is operated.
2. Retain Instructions—The safety and
operating instructions should be
retained for future reference.
3. Heed Warnings—All warnings on the
product and in the operating instructions should be adhered to.
4. Follow Instructions—All operating and
use instructions should be followed.
5. Cleaning—Unplug this product from the
wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
6. Attachments—Do not use attachments
not recommended by the product
manufacturer as they may cause
hazards.
7. Water and Moisture—Do not use this
product near water—for example, near
a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near
a swimming pool; and the like.
8. Accessories—Do not place this product
on an unstable cart, stand, tripod,
bracket, or table. The product may fall,
causing serious injury to a child or
or table recommended by the manufacturer, or sold with the product. Any
mounting of the product should follow
the manufacturer’s instructions, and
should use a mounting accessory
recommended by the manufacturer.
9. A product and cart
combination should be
moved with care. Quick
stops, excessive force,
and uneven surfaces
may cause the product
and cart combination to overturn.
10. Ventilation—Slots and openings in the
cabinet are provided for ventilation and
to ensure reliable operation of the
product and to protect it from overheating, and these openings must not be
blocked or covered. The openings
iii
should never be blocked by placing the
adult, and
serious damage
to the product.
Use only with a
cart, stand,
tripod, bracket,
product on a bed, sofa, rug, or other
similar surface. This product should not
be placed in a built-in installation such
as a
bookcase or
rack unless
proper
ventilation is
provided or
the manufacturer’s instructions have
been adhered to.
11. Power Sources—This product should
be operated only from the type of power
source indicated on the marking label. If
you are not sure of the type of power
supply to your home, consult your
product dealer or local power company.
For products intended to operate from
battery power, or other sources, refer to
the operating instructions.
12. Grounding or Polarization—This product
may be equipped with a polarized
alternating-current line plug (a plug
having one blade wider than the other).
This plug will fit into the power outlet
only one way. This is a safety feature. If
you are unable to insert the plug fully
into the outlet, try reversing the plug. If
the plug should still fail to fit, contact
your electrician to replace your obsolete
outlet. Do not defeat the safety purpose
of the polarized plug.
13. Power-Cord Protection—Power-supply
cords should be routed so that they are
not likely to be walked on or pinched by
items placed upon or against them,
paying particular attention to cords at
plugs, convenience receptacles, and
the point where they exit from the
product.
14. Lightning—For added protection for this
product during a lightning storm, or
when it is left unattended and unused
for long periods of time, unplug it from
the wall outlet and disconnect the
antenna or cable system. This will
prevent damage to the product due to
lightning and power-line surges.
15. Power Lines—An outside antenna
system should not be located in the
vicinity of overhead power lines or other
electric light or power circuits, or where
it can fall into such power lines or
circuits. When installing an outside
antenna system, extreme care should
be taken to keep from touching such
power lines or circuits as contact with
them might be fatal.
16. Overloading—Do not overload wall
outlets, extension cords, or integral
convenience receptacles as this can
result in a risk of fire or electric shock.
17. Object and Liquid Entry—Never push
objects of any kind into this product
through openings
as they may touch
dangerous
voltage points or
short-out parts
that could result in
a fire or electric shock. Never spill liquid
of any kind on the product.
18. Servicing—Do not attempt to service
this product yourself as opening or
removing covers may expose you to
dangerous voltage or other hazards.
Refer all servicing to qualified service
personnel.
19. Damage Requiring Service—Unplug
this product from the wall outlet and
refer servicing to qualified service
personnel under the following conditions:
a. When the power-supply cord or plug
is damaged,
b. If liquid has been spilled, or objects
have fallen into the product,
c. If the product has been exposed to
rain or water,
d. If the product does not operate
normally by following the operating
instructions. Adjust only those
controls that are covered by the
operating instructions as an improper adjustment of other controls
may result in damage and will often
require extensive work by a qualified
technician to restore the product to
its normal operation,
e. If the product has been dropped or
damaged in any way, and
f. When the product exhibits a distinct
change in performance—this
indicates a need for service.
20. Replacement Parts—When replacement
parts are required, be sure the service
technician has used replacement parts
specified by the manufacturer or have
the same characteristics as the original
part. Unauthorized substitutions may
result in fire, electric shock, or other
hazards.
21. Safety Check—Upon completion of any
service or repairs to this product, ask
the service technician to perform safety
checks to determine that the product is
in proper operating condition.
22. Wall or Ceiling Mounting—The product
should be mounted to a wall or ceiling
only as recommended by the manufacturer.
23. Heat—The product should be situated
away from heat sources such as
radiators, heat registers, stoves, or
other products (including amplifiers)
that produce heat.
iv
Quick Operation Guide
Please consult this operation manual
further for details on these and other
functions of your camcorder.
Charging the Battery Pack
1Connect the supplied power cord to the
AC power socket on the AC adapter/
battery charger, and insert the AC plug
into a power outlet.
2Align the s mark on the battery pack
with the a mark on the charger (1) and
guide the battery into the groove.
Pressing the battery (2), slide it in the
direction of the arrow (3) until it locks
into place.
Attaching the Battery Pack
1Make sure that the Power switch is set
to OFF.
Inserting a Mini DV Cassette
1Attach the power source to the
camcorder, then slide the cassette
compartment door release and open the
cassette compartment door.
2Insert the cassette fully with the window
facing outwards, and with the erasure
protect tab facing upwards.
SAVE
SAVE
REC
REC
2Lift up the viewfinder.
3Align the - mark on the side of the
battery pack with the q mark on the
camcorder (1), and slide the battery
pack down completely until it locks into
place (2).
v
3Press the W mark gently until the
cassette holder clicks into place. Close
the compartment door by pressing the
center until it clicks into place.
W mark
Easy Camera Recording
Tape Playback
1Make sure that a cassette is inserted.
2Remove the lens cap, and lift up the
viewfinder.
3Hold down the Lock button
and set the Power switch to
CAMERA.
Lock button
4Press the REC START/STOP button to
begin recording.
REC
Zooming
Push the Power Zoom control to T (1)
(telephoto) or W (2) (wide angle) side.
1Press the LCD monitor OPEN release
button (1), and open the LCD monitor
to a 90° angle to the camcorder body
(2).
LCD monitor OPEN
release button
90
2Adjust the LCD monitor to an angle that
allows easy viewing on the on-screen
picture.
3Hold down the Lock button
and set the Power switch to
VCR.
Lock button
4Press e (or r) on the Operation
button to rewind (or fast forward) the
tape to the desired point.
+
AUDIO
12
Power Zoom
control
5Press y to begin playback.
AUDIO
To stop playback
Press d.
+
12
vi
Supplied Accessories
AC adapter/
Battery pack
BT-L221n*
battery charger
UADP-0321TAZZ*
Power cord
QACCD0031TAPZ
DC cable
QCNW-1957TAZZ
Remote control
RRMCG0101TASA
Lens cap
GCOVH1271TASA
* The part numbers for the AC adapter/battery charger and battery pack supplied with this camcorder
are valid only in the U.S. and Latin America. If this camcorder was purchased outside of these areas,
the part numbers may be different. Please refer to the part numbers printed on the labels of the
supplied AC adapter/battery charger and battery pack.
AA battery for
remote control K 2
Shoulder strap
UBNDS0010TASA
CR2025 type
lithium battery
Audio/video cable
(RCA type)
QCNW-2016TAZZ
vii
Optional Accessories
Standard-life
battery pack
BT-L221n
PixLab Video Capture Software
(Lite Version)
VR-PK50E
Note: The listed model names are for U.S. accessories.
For optional and additional accessories, contact your local dealer, call the Sharp Accessories and Supply Center at 1-800-642-2122, or visit SHARP’s website
(http://www.sharp-usa.com).
Extended-life
battery pack
BT-L441n
Zoom microphone
VR-5MCN
viii
Precautions
•When the camcorder is not in use, remem-
ber to remove the cassette tape, turn off
the power, and disconnect the camcorder
from the power source.
•Do not aim the lens at the sun.
Do not allow direct sunlight to strike the
camcorder lens or LCD monitor screen,
whether or not recording is in progress, as it
may damage the CCD sensor or LCD screen
surface. Be particularly careful when
recording outside.
•When shooting in dark places, avoid sudden
brightly lit objects or light sources, such as
the sun. Otherwise, the image may white out.
Should this happen, point the lens in a
different direction until the picture returns to
normal.
•Avoid magnetic sources.
Using the camcorder near
strong fluorescent lights,
motors, televisions, or
other magnetic sources
may adversely affect
recorded images.
•Using the camcorder near a broadcasting
station or other powerful transmission
source may cause buzzing or picture
deterioration.
•Avoid shocks and dropping.
Do not drop or otherwise
subject the camcorder to
hard shocks or strong
vibrations. Bumping or
striking the unit during
recording will generate noise
in the recorded image.
•Avoid placing the
camcorder in close
proximity to lighting
equipment.
The heat from
incandescent lights
may deform the
camcorder, or cause it
to malfunction.
•Always respect prohibitions or restrictions
on the use of electronic equipment on
commercial flights or in other sensitive
areas.
•Be aware of the temperature and humidity.
You can use your camcorder at 32°F to 104°F
(0°C to L40°C), and at 30% to 80% relative
humidity. Do not store the unit in an
unventilated car in the
summer, in direct
sunlight, or near strong
heat sources; this can
result in severe damage
to the unit casing and
circuitry.
•Avoid situations where water, sand, dust or
other foreign matter could get on or inside
the camcorder, and do not use or leave
your camcorder in areas with excessive
smoke, steam or moisture.
Such environments can
cause malfunctions or
cause mildew to form
on the lenses. Be sure
to keep the unit in a
well-ventilated location.
•Some small, portable
tripods may be difficult to
attach and may not be
sturdy enough to support
your camcorder. Be sure to
use only a strong, stable
tripod.
•When using your camcorder in a cold
environment, the LCD monitor screen often
appears less bright immediately after the
power is turned on. This is not a malfunction. To prevent the camcorder from
becoming too cold, wrap it in a thick cloth
(a blanket, etc.).
ix
About Y our Camcorder
DV T echnology
Digital video, DV, is a revolutionary technology
that enables recording and playback of high
quality images with the use of special digital
features previously unavailable with conventional analog formats.
•High horizontal resolution
Detailed, accurate images with the highest
level of horizontal resolution for home use.
•Clear color reproduction with virtually no
color contamination
Provides three times the color resolution of
conventional VCRs (based on Sharp models).
Clear images with virtually no distracting
color contamination (which usually appears
as red).
•Standard use of TBC (Time Base Corrector)
to prevent jittery images
Ensures stable images with a high signal-tonoise ratio.
•PCM digital recording
PCM digital recording gives you high-quality
stereo sound that puts you in the middle of
the action.
The “DV” trademark can only be used on
digital VCR products which have been
evaluated and have met the specifications set
by the HD Digital VCR Conference for
Standardization of Consumer Use Digital
VCR Formats.
This product incorporates copyright protection technology that is protected by method
claims of certain U.S. patents and other
intellectual property rights owned by
Macrovision Corporation and other rights
owners. Use of this copyright protection
technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only
unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
DV and conventional video cassette
tapes
There are two kinds of DV-format video
cassette tapes: the Mini DV cassette and the
larger DV cassette used for extended playback
and recording. This camcorder only operates
with Mini DV cassettes. DV cassettes cannot
be used. Be sure to use Mini DV cassettes with
the i mark.
Mini DV cassetteDV cassette
8 mm, VHS, and Beta cassettes cannot be
used for playback or recording with this
camcorder.
8 mm cassetteVHS cassetteBeta cassette
Note:
• This camcorder reproduces the highest picture
quality when used with an ME tape. It is
recommended you use an ME tape for highquality recording and playback.
x
Contents
Operation References
Preparation
Basic Operations
Part Names ............................................................... 1
• Guía de operación rápida en español................................................................... 73
• Visualizaciones en pantalla en español................................................................ 75
• Affichages sur écran en français .......................................................................... 76
Appendix
xii
Operation References
Operation References
Part Names
For details on the use of each part, refer to the page number indicated in brackets.
Operation References
Left view
Remote sensor [p. 37]
W/B (White Balance) button [p. 47]
CAT’S EYE switch [p. 32]
Lens hood
Zoom lens
Stereo microphone
[p. 59]
GAMMA/BRIGHTER button
[pp. 30, 31, 52]
AUTO ON/OFF button
[p. 25]
Operation button [p. 24]
MENU/DISPLAY button
[p. 24]
DIS (Digital Image Stabilization) switch
[p. 28]
1
Left view
LCD monitor [p. 17]
LCD monitor
OPEN release
button [p. 17]
Zoom microphone
mounting hole [p. 50]
Lithium battery
compartment door
[p. 11]
Operation References
Viewfinder [p. 16]
Diopter adjustment
[p. 16]
Power source
PUSH release
button [pp. 8, 9]
Power source
mounting surface
[pp. 8, 9]
Shoulder strap loop [p. 15]
Bottom view
Tripod socket
2
Operation References
Right view
Operation References
S-VIDEO socket
[pp. 22, 56, 57]
Power Zoom Wide angle/
Telephoto control [p. 19]/
VOLume control [p. 21]
STILL button
[pp. 35, 36]
VIDEO jack
[pp. 22, 56, 57]
AUDIO L jack
[pp. 22, 56, 57]
AUDIO R jack
[pp. 22, 56, 57]
Power switch (CAMERA/VCR
select switch) [p. 24]
RECord START/STOP button
Jack cover
[pp. 22, 56, 57]
Cassette compartment door [p. 10]
Cassette compartment door release [p. 10]
[p. 18]
Shoulder strap
loop [p. 15]
PC connection jack
[p. 62]
DV terminal [p. 58]
EarPHONES jack
[p. 21]
Hand strap [p. 15]
3
Jack cover [pp. 21, 58, 62]
Speaker [p. 21]
Quick Reference List
Below are some examples of camcorder’s features.
•To record the subject with higher-quality audio.
— See page 28 (Selecting the 16-bit Audio Recording Mode)
•To record powerful close-up images.
— See page 29 (Setting the Digital Zoom)
•To record a backlit subject.
— See page 30 (Gamma Brightness Compensation) or page 42 (Manual
Exposure)
•To record subjects at night, e.g. a nocturnal animal.
— See page 32 (Night Recording)
•To quickly return the tape to the end of the last recorded scene after playback.
— See page 34 (Quick Return)
•To record yourself in the scene while monitoring the shot.
— See page 39 (Letting the Subject Monitor the Shot)
•To focus on an off-centered subject.
— See page 43 (Manual Focus)
•To turn off the confirmation sounds which are made when you operate the
camcorder.
— See page 49 (Setting the Confirmation Sounds)
•To enlarge any part of the picture during playback.
— See page 51 (Playback Zoom)
•To brighten the dark portion of the playback images without changing the bright
portion.
— See page 52 (Gamma Playback)
Operation References
4
Operation References
On-screen Display Index
For details on the use of each function, refer to the page number indicated.
Operation References
CAMERA mode
AUTO
pp. 18, 25
AUTO
p. 20
30
p. 20
pp. 31, 32
min
SP
p. 28
p. 18
p. 27
LIGHT
12 bit
p. 28
MANUA L SE T
M
AN. FOCUS
SHUT. SPE E D
EXPOSURE
PIC. EFFECT
SCENE MENU
FADE
QK. RETURN
Easy mode (p. 25)
MENU
FADE
QK. RE TURN
PHOT O
SNAP
SNAP
EFF.
SOUND
DISPLAY
p. 33
p. 34
p. 35
p. 36
p. 49
p. 14
MANU AL SET
M
AN. FOCUS
SHUT. SPEE D
EXPOSURE
PI C. EFFECT
SCENE MENU
FADE
QK. RE TURN
CAMERA SE T
PHOTO SNAP
SNAP E FF.
DGTL ZOOM
TAPE SPEED
AUD I O SET
AUD I O MODE
ZOOM MI C
OTHERS
REMOTE
SOUND
TIME CODE
TC OUT
DEMO MODE
LANGUAGE
LCD VF SET
BACKL IGHT
LCD BRI GHT
LCD COLOR
LCDVFTINT
BRI GHT
CLOCK SET
DISPLAY
SET T ING
12H 24H
p. 43
p. 45
p. 42
p. 49
p. 48
p. 33
p. 34
p. 35
p. 36
p. 29
p. 27
p. 28
p. 50
p. 37
p. 49
p. 41
p. 41
p. 69
p. 12
p. 55
p. 14
p. 13
p. 14
VCR mode
+
AUDIO
12
p. 20
SP
p. 27
PLAYBACK SE T
AUDI O DUB
AUDI O
EFFECT
PIC.
PB EFFECT
Note:
• See pages 24 to 26 for the procedure to display the desired screen.
5
p. 61
PLAYBACK SE T
AUDI O DUB
AUDI O
EFFECT
PIC.
PB EFFECT
OTHERS
REMOTE
SOUND
TIME CODE
TC OUT
LCD
VF SE T
BACKL IGHT
LCD BRI GHT
LCD COLOR
LCD T I NT
BRI GHT
VF
CLOCK SET
DISPLAY
p. 60
p. 61
p. 54
p. 53
p. 37
p. 49
p. 41
p. 41
p. 55
p. 14
Warning Indicators
If a warning indicator appears on the screen, follow the specified instructions.
Operation References
Displayed for the first
3 seconds
Displayed after
INSERT
A CASSE TTE.
EJECT THE
EJECT THE
CASSETTE.
CASSETTE NOT
RECORDABLE.
THE
TAPE
PROTEC T. TAB
ENDS SOON.
CHANGE THE
CASSETTE.
BAT TE RY IS
TOO LOW.
DEW
LAMPLAMP
Note:
•N indicates a flashing display.
3 seconds
CASSETTE.
TAPE END
TAPE END
DEW
Description of warning
There is no video cassette in the camcorder.
Insert a cassette (see page 10).
The video cassette is defective and should be
removed (see page 10).
The erasure protect tab on the video cassette
has been slid to the record-protect position,
preventing recording (see page 65).
The tape is about to end. Prepare a new
cassette (see page 10).
The tape has reached the end. Replace it with a
new cassette (see page 10).
The battery is almost depleted. Replace it with a
fully charged battery pack (see page 8).
Dew has formed inside the camcorder. Wait for
a few hours until the dew disappears (see
page 67).
About 10 seconds after this warning appears,
the camcorder automatically turns off.
The video heads are clogged and should be
cleaned (see page 68).
The fluorescent lamp behind the LCD monitor is
close to the end of its service life. Call your local
authorized Sharp dealer to have it replaced.
When the vertical rotation of the LCD monitor is
between 135° and 180° in CAMERA mode, all
warnings will be indicated by F displayed in
the center of the viewfinder and the LCD
screen. To check the type of warning, rotate the
monitor back to within 135°.
6
Preparation
Preparation
Charging the Battery Pack
Charge the battery pack with the supplied AC
adapter/battery charger before use.
Note:
• Remove the DC cable from the AC adapter/
battery charger when charging the battery pack.
1Connect the supplied power cord to the
AC power socket on the AC adapter/
battery charger, and insert the AC plug
Preparation
into a power outlet.
• The POWER indicator lights up.
POWER indicator
AC power
socket
To power
outlet
2Align the s mark on the battery pack
with the a mark on the charger (1) and
guide the battery into the groove.
Pressing the battery (2), slide it in the
direction of the arrow (3) until it locks
into place.
• The CHARGE indicator lights up.
Charging time and maximum continuous
recording and playback times
Max. continuous
recording time
LCD
closed
LCD
open
pack
Charging
time
100120100100
160240200200
Battery
BT-L221
BT-L441
• The chart specifies the approximate times in
minutes.
Notes:
• Charge the battery pack between 50°F and 86°F
(10°C and 30°C). The battery pack may not charge
properly at temperatures too low or too high.
• The battery pack and charger become warm
during charging. This is not a malfunction.
• Using the zoom (see page 19) and other
functions or turning the power on and off
frequently will increase power consumption. This
may result in a decrease of more than 50% in the
actual recording time compared to the maximum
continuous recording time listed above.
• The charging time and recording time may vary
depending on the ambient temperature and the
condition of the battery pack.
• See page 66 for more information on using the
battery pack.
Caution:
• Charge only SHARP model BT-L221 or BT-L441
battery packs. Other types of battery packs may
burst, causing personal injury and damage.
Max.
continuous
playback
time on
LCD
CHARGE indicator
• The CHARGE indicator turns off when
the battery is fully charged.
3Slide the battery pack in the direction of
the arrow (1), and remove it (2). Then,
remove the AC plug of the power cord
from the power outlet.
7
Extending battery pack life
Even when the battery pack is not used, the
capacity of the battery pack will naturally
deteriorate over time. To limit the deterioration
of the capacity, it is recommended to perform
the following procedure at least once every six
months:
1 Charge the battery pack until the CHARGE
indicator of the charger turns off.
2 Attach the battery pack to the camcorder,
and set the Power switch to CAMERA
without inserting a cassette. Allow the
battery power to fully discharge by leaving it
on the camcorder until the camcorder
power automatically turns off.
3 Remove the battery pack and store it
between 50°F and 68°F (10°C and 20°C).
Attaching and Removing the
Battery Pack
Attaching the Battery Pack
1Make sure that the Power switch is set
to OFF.
Power switch
2Lift up the viewfinder.
Power source
mounting surface
4Lower the viewfinder.
Preparation
Removing the Battery Pack
1Perform steps 1 and 2 above.
2Press the power source PUSH release
button (1), and slide the battery pack
up and take it out (2).
Power source PUSH
release button
3Align the - mark on the side of the
battery pack with the q mark on the
camcorder (1), and slide the battery
pack down completely until it locks into
place (2).
Cautions:
• BEFORE REMOVING THE BATTERY PACK,
ALWAYS STOP RECORDING OR PLAYBACK
AND TURN THE POWER OFF. If you remove the
battery pack during recording or playback, the
tape will remain wound around the video head
drum, potentially causing damage to the tape.
• Remove the battery pack from the camcorder if
you will not use the camcorder for a long period
of time.
• Use only SHARP model BT-L221 or BT-L441
battery packs with this camcorder. Use of other
batteries may present a risk of fire or explosion.
8
Preparation
Powering the Camcorder
from an AC Outlet
You can also power the camcorder from a
power outlet by using the supplied AC adapter/
battery charger and DC cable.
Caution:
• The supplied AC adapter/battery charger is
specially designed for use with this camcorder,
and should not be used as a power supply for
other camcorders.
Preparation
1Make sure that the Power switch is set
to OFF.
2Lift up the viewfinder.
3Align the = mark on the side of the
DC cable connecting plate with the q
mark on the camcorder (1), and slide
the connecting plate down completely
until it locks into place (2).
DC cable
connecting
plate
5Insert the DC cable plug into the DC
OUT jack on the AC adapter. Connect
the supplied power cord to the AC
adapter, and insert the AC plug into a
power outlet.
• The POWER indicator on the AC adapter
lights up, and the camcorder is supplied
power.
DC OUT jack
POWER
indicator To power
outlet
Note:
• When the AC adapter/battery charger is used to
power the camcorder, it cannot be used to
charge the battery pack.
Removing the DC cable from the
camcorder
Perform steps 1 and 2 above. Press the power
source PUSH release button (1), and slide the
connecting plate up and take it out (2).
4Lower the viewfinder.
9
Power source PUSH
release button
Cautions:
• BEFORE REMOVING THE DC CABLE,
ALWAYS STOP RECORDING OR PLAYBACK
AND TURN THE POWER OFF. If you remove the
DC cable during recording or playback, the tape
will remain wound around the video head drum,
potentially causing damage to the tape.
• Disconnect the camcorder from the AC adapter
if you will not use the camcorder for a long
period of time.
Inserting and Removing a
Mini DV Cassette
Inserting a Cassette
1Attach the power source to the
camcorder, then slide the cassette
compartment door release and open the
cassette compartment door.
• A confirmation sound is made, and the
cassette holder extends and opens
automatically.
Cassette compartment
door release
3Press the W mark gently until the
cassette holder clicks into place.
• A confirmation sound is made, and the
cassette holder retracts automatically.
W mark
Preparation
4Wait for the cassette holder to fully
retract. Close the compartment door by
pressing the center until it clicks into
place.
Note:
• If the hand strap is pulled too tight, it can
obstruct the opening of the cassette
compartment door and the cassette holder
may be unable to extend. Should this occur,
loosen the hand strap and open the
cassette compartment door completely.
2Insert the cassette fully with the window
facing outwards, and with the erasure
protect tab facing upwards.
Erasure protect tab
SAVE
SAVE
REC
REC
Removing a Cassette
Perform step 1 above, then take out the
cassette.
Cautions:
• Do not try to close the cassette compartment
door while the cassette holder is extending or
retracting.
• Be careful not to get your fingers caught in the
cassette holder.
• Do not apply force to the cassette holder except
when pressing the W mark to close it.
• Do not tilt the camcorder or hold it upside down
when you are inserting or removing a cassette. It
may damage the tape.
• Remove the cassette if you will not use the
camcorder for a long period of time.
• If you do not correctly close the cassette holder in
step 3, the cassette protection mechanism of the
camcorder might eject the cassette. If this happens,
repeat the insertion procedure.
• Do not attempt to pick up the camcorder by the
cassette compartment door.
Notes:
• If the battery power is too low, you may not be able
to eject the cassette. Replace the battery pack with
a fully charged one.
• See page 65 for more information on the video
cassette tapes intended for use with this camcorder.
10
Preparation
Installing the Lithium Memory
Battery
Installing the Lithium Battery
The supplied lithium battery is used to store the
memory of the date and time settings.
1Press the LCD monitor OPEN release
button (1) and open the LCD monitor
(2).
Preparation
LCD monitor OPEN
release button
2Open the lithium battery compartment
door using the tip of a ballpoint pen or
other pointed object.
5Close the LCD monitor until it clicks into
place.
Removing the lithium battery
Perform steps 1 and 2 above.
Lift up the battery using a
pointed object, and take it out.
Note:
• Replace the battery with a new CR2025 lithium
battery when the time indicator of the camcorder
starts to fall behind the correct time.
Notes on the Use of the Lithium
battery
REPLACE BATTERY WITH TOSHIBA,
MATSUSHITA OR HITACHI MAXELL TYPE
CR2025 ONLY. USE OF A DIFFERENT
BATTERY MAY PRESENT A RISK OF FIRE OR
EXPLOSION.
X KEEP THIS BATTERY AWAY FROM
CHILDREN. IF SWALLOWED, CONSULT A
PHYSICIAN IMMEDIATELY FOR EMERGENCY
TREATMENT.
Z BATTERY MAY EXPLODE IF MIS-
USED OR INSTALLED WITH POLARITY
REVERSED. DO NOT RECHARGE, DISASSEMBLE OR DISPOSE OF IN FIRE.
3Insert the lithium battery into the
compartment with the H side facing out.
4Replace the compartment door, and
close it firmly until it clicks into place.
11
• Do not short-circuit, recharge, disassemble, or
heat the lithium battery.
• Should the lithium battery leak, wipe the battery
compartment clean, and then insert a new
battery.
• The lithium battery will last about one year under
normal usage.
Selecting the Language for
the On-screen Display
This camcorder allows you to choose from
among English, French or Spanish for the onscreen display language.
Note:
• The operation procedures in the following
sections of this operation manual are based
on the use of on-screen displays in English.
MENU/DISPLAY button
Power switch
3Press d or y (1) on the operation
button to select the desired language,
then press e (2).
LANGUAGE
ENGLI SH
Ç
FRAN
AIS
ÑOL
ESPA
SET [ BUTTON]
OTHERS
REMOT E
SOUND
TIME CODE
TC OUT
DE MO MODE
LANGUAGE
ENGLI SH
Preparation
Operation button
Setting the Language
When using the camcorder for the first time,
select the desired language for the on-screen
display by performing the procedure below.
1Press the LCD monitor OPEN release
button (1) and open the LCD monitor
(2).
LCD monitor
OPEN release
button
2Hold down the Lock button
and set the Power switch to
CAMERA.
• The language selection screen
appears on the LCD screen.
Lock button
Changing the Language
1Set the camcorder to CAMERA mode.
2Press the MENU/DISPLAY button until
the menu screen appears.
3Select I, then press r on the
Operation button. Select “LANGUAGE”
(“LANGUE” or “IDIOMA”) (1), then
press r (2).
• The language selection screen appears.
OTHERS
REMOT E
SOUND
TIME CODE
TC OUT
DE MO MODE
LANGUAGE
LANGUAGE
ENGLI SH
FRAN
ESPA
ENGLI SH
Ç
AIS
Ñ
OL
SET [ BUT TON]
4Perform step 3 in “Setting the
Language”.
• The menu screen is displayed in the
language selected.
5Press the MENU/DISPLAY button to
turn off the menu screen.
12
Preparation
Setting the Date and Time
Example: Setting the date to June 2, 2002
(JUN. 2. 2002) and the time to 10:30 am
(10:30 AM).
Note:
• Before performing the procedure below, make
sure that the lithium battery has been installed
(see page 11).
MENU/DISPLAY button
Preparation
Operation button
Power switch
1Press the LCD monitor OPEN release
button (1) and open the LCD monitor
(2).
LCD monitor OPEN
release button
4Press r on the Operation button.
CLOCK SE T
DISPLAY
SET T I NG
SET T I NG
12H 24H
1 2001.
JAN.
:
12 00AM
5Press d or y (1) to select “JUN”
(month), and then press r (2).
CLOCK SE T
DISPLAY
SET T I NG
SET T I NG
12H 24H
JUN.
1 2001.
:
12 00AM
6Press d or y to select “2” (day), and
then press r.
SE TT ING
JUN.
12 00AM
2 2001.
:
7Press d or y to select “2002” (year),
and then press r.
SE TT ING
JUN.
12 00AM
2 2002.
:
2Hold down the Lock button
and set the Power switch to
CAMERA.
3Press the MENU/DISPLAY button until
the menu screen appears.
CLOCK SE T
DISPLAY
SET T I NG
SET T I NG
12H 24H
13
Lock button
JAN.
1 2001.
:
12 00AM
8Press d or y to select “10 AM”
(hour), and then press r.
SE TT ING
JUN.
10 00AM
2 2002.
:
9Press d or y to select “30” (minute),
and then press e.
• The internal clock now starts operating.
SE TT ING
JUN.
10 30AM
2 2002.
:
10 Press the MENU/DISPLAY button to
turn off the menu screen.
Changing to the 24-hour Time Mode
1After performing step 9 above, press d
or y (1) to select “12H/24H”, and
then press r (2).
CLOCK SE T
DISPLAY
SET T I NG
12H 24H
12H
24H
2Press d or y to select “24H”, and
then press e.
21H24H
24H
3Press the MENU/DISPLAY button to
turn off the menu screen.
Notes:
• The date and time, once set, are internally
recorded even when not displayed on the
screen.
• The menu screen automatically turns off if no
settings are made within 5 minutes.
Displaying the Date and Time
of Recording
Follow the procedure below to display the date,
or both the date and time, of recording on the
screen. You can display the date and time
during both recording and playback.
• The example screens for this feature are for
CAMERA mode.
1Hold down the Lock button and set the
Power switch to CAMERA or VCR.
2Press the MENU/DISPLAY button until
the menu screen appears.
3Select P, then press r on the
Operation button. Select “DISPLAY” (1),
then press r (2).
CLOCK SE T
DISPLAY
SET T I NG
12H 24H
OFF
DATE
DATE+TIME
4Press d or y to select “DA TE” or
“DATEHTIME”, and then press e.
DISPLAY
DAT E+TIME
Preparation
5Press the MENU/DISPLAY button to
turn off the menu screen.
• The date (or the date and time) is
displayed.
SP
JUN.
min
50
Notes:
• Before recording, make sure that the date and
time have been correctly set. If they have not
been set, the display will be left blank when
playing back the recording. (The display will also
be left blank for unrecorded or damaged
portions of the tape.)
• In VCR mode, the current date and time are
displayed when the tape is not being played
back.
2002.2
03MA:01
14
Preparation
5
6
7
4
3
2
Adjusting the Hand Strap
1Open the hand strap flap (1) and the
grip strap (2).
Preparation
2Loosen the grip strap, pass your right
hand through the loop, and put your
thumb on the REC START/STOP button.
Then, pull the grip strap tight until it fits
snugly.
REC START/STOP button
3Seal the velcro fasteners of the grip
strap and the hand strap flap.
Caution:
• Do not swing the camcorder by the hand strap.
Using the Lens Cap
When attaching or
removing the lens cap,
press both tabs on the
top and bottom of the
cap.
When recording, hang
the hook of the lens cap
on the hand strap so that
the cap will not get in the
way.
Note:
• Always replace the lens
cap on the lens when the
camcorder is not in use.
Tabs
Hook
Attaching the Shoulder Strap
1Remove the battery pack.
2Hold one end of the strap and thread it
through the loop on the left side of the
power source mounting surface.
3Loosen the strap in the buckle, then feed
the end of the strap through the buckle,
as shown.
4Draw the strap in the direction of the
arrow to secure.
5–7 To attach the other end of the strap to
the loop on the left side of the hand
strap, open the hand strap flap,
perform the same procedure, and then
attach the battery pack.
Attach the strap of the lens cap to the hand
strap as shown below.
15
Loop
Buckle
Loop
Buckle
Loading...
+ 64 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
