Sharp VLAH50H User Manual

LIQUID CRYSTAL DISPLAY CAMCORDER

OPERATION MANUAL

Operation Summary

Please read this operation manual

carefully before using the VIEWCAM.

If you require any advice or assistance

regarding your Sharp product, please

visit our web-site www.sharp.co.uk/

support. Customers without Internet

access may telephone 08705 274277

during office hours (or (01)676 0648

if telephoning from Ireland) .

MODEL

VL-AH50H

Preparation

Camera Recording

Basic Operations

Playback

Useful Features

PAL

Advanced Features

References

This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC.

Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG.

Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE.

Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/EEG, gewijzigd door 93/68/EEG.

Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med tillæg nr. 93/68/ EEC.

Quest’ apparecchio è conforme ai requisiti delle direttive 89/336/EEC e 73/23/EEC, come emendata dalla direttiva 93/68/EEC.

« В„Н·Щ‹ЫЩ·ЫБ ·ıЩﬁ ·МЩ·ФНТﬂМВЩ·И ЫЩИЪ ··ИЩﬁЫВИЪ Щ˘М Ф‰Б„И˛М ЩБЪ EıТ˘·˙НﬁЪ EМ˘ЫБЪ 89/336/EOK Н·И 73/23/EOK, ¸˘Ъ ФИ Н·МФМИЫПФﬂ ·ıЩФﬂ ЫıПОБТ˛ЛБН·М ·¸ ЩБМ Ф‰Б„ﬂ· 93/68/EOK.

Este equipamento obedece às exigências das directivas 89/336/CEE e 73/23/CEE, na sua versão corrigida pela directiva 93/68/CEE.

Este aparato satisface las exigencias de las Directivas 89/336/CEE y 73/23/CEE, modificadas por medio de la 93/68/CEE.

Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/EEC och 73/23/EEC så som kompletteras av 93/68/EEC.

Dette produktet oppfyller betingelsene i direktivene 89/336/EEC og 73/23/EEC i endringen 93/ 68/EEC.

Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita on muutettu direktiivillä 93/68/EEC.

WARNING

TO PREVENT SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

This equipment should be used with the recommended AC adapter or battery pack.

CAUTION

To prevent electric shocks and fire hazards, do NOT use any other power source.

Important:

Recording and playback of any material may require consent. Please refer particularly to the provisions of the Copyright Act 1956, the Dramatic and Musical Performers Protection Act 1958, the Performers Protection Acts 1963 and 1972 and to any subsequent statutory enactments and orders.

CAUTION

To prevent shock, do not open the cabinet. No user serviceable parts inside. Refer servicing to a qualified dealer or service centre.

Power supply:

WARNING: THIS AC ADAPTER IS NOT FOR USE WITH TOYS. THIS AC ADAPTER IS FOR USE WITH SHARP VIEWCAM MODEL VL-AH50H ONLY.

This unit can be operated by connecting it to either the AC adapter or battery pack. The AC adapter incorporates the AUTO VOLTAGE (AC 110–240 V, 50/60 Hz) function.

SPECIAL NOTE FOR USERS IN THE U.K.

The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 3A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked

or and of the same rating as above, which is also indicated on the pin face of the plug,

must be used.

Always refit the fuse cover after replacing the fuse. Never use the plug without the fuse cover fitted.

In the unlikely event of the socket outlet in your home not being compatible with the plug supplied, cut-off the mains plug and fit an appropriate type.

DANGER: The fuse from the cut-off plug should be removed and the cut-off plug destroyed

To fit an appropriate plug to the mains lead, follow the instructions below: IMPORTANT: The wires in the mains lead are coloured in accordance with the following code:

As the colours of the wires in the mains lead of this product may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:

— The wire which is coloured blue must be connected to the plug terminal which is marked N

— The wire which is coloured brown must be connected to the plug terminal which is marked

Ensure that neither the brown nor the blue wire is connected to the earth terminal in your threepin plug.

Before replacing the plug cover make sure that:

— If the new fitted plug contains a fuse, its value is the same as that removed from the cut-off

— The cord grip is clamped over the sheath of the mains lead and not simply over the lead

IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.

immediately and disposed of in a safe manner.

Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket outlet, as a serious electric shock may occur.

Blue: Neutral Brown: Live

or coloured black.

L or coloured red.

plug.

wires.

Your VIEWCAM is designed to record in SP mode only. It will not perform normal playback for programmes prerecorded in LP mode.

This VIEWCAM does not have a PCM recording or playback function. PCM recordings made using other VCRs or audio dubbing cannot be played back on this unit.

If you record on a tape on which PCM sound has already been recorded, the audio track of the new VIEWCAM recording may not come out if the tape is played back on a PCM-capable VCR. If this occurs, set the VCR’s audio monitor select switch to the “Standard” position.

NOTE:

The VIEWCAM’s LCD panel is a very high technology product with close to 90,000 thin-film transistors*, giving you fine picture detail. Occasionally, a pixel may appear on the screen as a fixed point of blue, green, red, or black. Please note that this does not affect your VIEWCAM’s performance.

*Specifications are subject to change without notice.

Precautions

• When the VIEWCAM is not in use,

remember to remove the cassette tape, turn off the power, and disconnect the VIEWCAM from the power source.

• Do not aim the lens at the sun. Do not allow direct sunlight to strike the VIEWCAM lens or LCD monitor screen, whether or not recording is in progress, as it may damage the CCD sensor or LCD screen surface. Be particularly careful when recording outside.

• When shooting in dark places, avoid sudden brightly lit objects or light sources, such as the sun. Otherwise, the image may white out. Should this happen, point the lens in a different direction until the picture returns to normal.

• Avoid magnetic

sources.

Using the VIEWCAM near strong fluorescent lights, motors, televisions, or other magnetic sources may adversely affect recorded images.

• Using the VIEWCAM near a broadcasting

station or other powerful transmission source may cause buzzing or picture deterioration.

• Avoid shocks and dropping.

Do not drop or otherwise subject the VIEWCAM to hard shocks or strong vibrations. Bumping or striking the unit during recording will generate noise in the recorded image.

• Always respect prohibitions or restrictions

on the use of electronic equipment on commercial flights or in other sensitive areas.

• Be aware of the temperature and humidity.

You can use your VIEWCAM at 0⬚C to Ⳮ40⬚C, and at 30% to 80% relative humidity.

Do not store the unit in an unventilated car in the summer, in direct sunlight, or near strong heat sources; this can result in severe damage to the unit casing and circuitry.

• Avoid situations where water, sand, dust or

other foreign matter could get on or inside the VIEWCAM, and do not use or leave your VIEWCAM in areas with excessive smoke, steam or moisture.

Such environments can cause malfunctions or cause mildew to form on the lenses. Be sure to keep the unit in a well-ventilated location.

• Some small, portable

tripods may be difficult to attach and may not be sturdy enough to support your VIEWCAM. Be sure to use only a strong, stable tripod.

• When using your VIEWCAM in a cold

environment, the LCD monitor screen often appears less bright immediately after the power is turned on. This is not a malfunction. To prevent the VIEWCAM from becoming too cold, wrap it in a thick cloth (a blanket, etc.).

• Avoid placing the VIEWCAM in close proximity to lighting equipment.

The heat from incandescent lights may deform the VIEWCAM, or cause it to malfunction.

About Your VIEWCAM

Recording Format

Hi8 is a high-performance extension of the ordinary 8 mm format. It uses advanced technology to achieve even higher resolution and picture quality. Use a video cassette with the mark for high-quality recording and playback, or with the mark to enjoy ordinary 8 mm recording and playback.

• When you load a Hi8 tape, recording is in Hi8 format. (The indicator appears on the LCD screen.) When you load a normal 8 mm tape, recording is in ordinary 8 mm format. (The indicator does not appear.)

• During playback, the recorded format is automatically detected.

• Video equipment not for use with Hi8 is unable to play back a tape recorded in Hi8 format.

• If you want to record with a Hi8 tape in normal 8 mm format, set the menu item to “OFF” on the (MENU 2) screen (Camera mode) before recording. (See page 23 for operation of the menu screen.)

LCD Monitor Screen

The VIEWCAM is equipped with a large LCD monitor screen that allows you to record scenes while comfortably holding the camcorder. The LCD monitor screen can be rotated for easy recording at high or low angles. It also functions as a handy playback monitor so you can enjoy what you have just recorded.

Cautions:

• Do not apply pressure to the screen.

• Do not expose the screen to shocks, as it may

break.

• Do not place the VIEWCAM with the screen facing down.

Note:

• Use a soft cloth to clean the screen.

Supplied Accessories

Battery pack

BT-H22 AC adapter Infrared remote control

CR2025 type

Audio/video cable

lithium battery Shoulder strap Lens cap

Power cord

AA battery for

Sun hood

iii

remote control ⳯ 2

Optional Accessories

Standard type

battery pack

BT-H22

Soft case

Extended type

battery pack

BT-H32

Accessory

shoe adapter

VR-30AD

Tripod adapter

for 180° recording

VR-33FA

Contents

Operation Summary Part Names .......................................................... 3

On-screen Display Index ..................................... 5

Quick Reference Index ........................................ 6

Warning Indicators ............................................... 7

Preparation

Basic Operations

Inserting and Removing the Battery Pack ........... 8

Charging the Battery Pack ................................... 9

Powering the VIEWCAM from an AC Outlet......... 10

Inserting and Removing a Cassette .................. 11

Installing the Lithium Memory Battery ................ 12

Setting the Date and Time ................................. 13

Using the Hand Strap and the Lens Cap........... 14

Attaching the Shoulder Strap ............................. 14

Using the Sun Hood ........................................... 15

Camera Recording

Easy Camera Recording with Full Auto Mode ... 16

Zooming ............................................................. 17

Tips on Recording Positions .............................. 17

Remaining Recording Time Display .................. 18

Remaining Battery Power Display ..................... 18

Playback

Playback ............................................................ 19

Volume Control................................................... 19

Watching the Playback on a TV ......................... 20

Video Search...................................................... 21

Still...................................................................... 21

Slow.................................................................... 21

Operation Summary

Useful Features

Advanced Features

Operations of the On-screen Controls

Using the Control Buttons............................... 22

Selecting the Mode/Menu Screens ................ 22

Adjusting the Menu Settings........................... 23

Recording the Date and Time ............................ 24

Setting the Digital Zoom..................................... 25

Digital Quick Zoom (Extend Zoom).................... 26

Still Recording .................................................... 27

Strobe Recording ............................................... 28

Digital Image Stabilization (DIS) ........................ 28

Fade In and Fade Out ........................................ 29

Quick Review ..................................................... 30

Quick Return ...................................................... 31

Edit Search......................................................... 31

Gamma Brightness Compensation .................... 32

Gain-up (Cat’s Eye)............................................ 33

Wide Screen (16:9) ........................................... 34

Macro Shots ....................................................... 34

Removing the Lens Hood .................................. 34

Self Recording ................................................... 35

Setting the VIEWCAM to Full Auto Mode ........... 37

Program Search ................................................. 38

Tape Counter Feature ........................................ 39

Using the Remote Control .................................. 41

Digital Picture Effects ......................................... 42

Scene Menu (Program AE) ................................ 43

Superimposing a Title ........................................ 44

Changing the Preset Titles ................................. 45

Auto/Manual Focus ............................................ 46

White Balance Lock ........................................... 47

Manual Exposure ............................................... 48

Digital Dual Picture ............................................ 49

Picture/Backlight Adjustments ........................... 51

Gamma Playback............................................... 52

Turning Off the LCD Monitor Backlight .............. 52

Editing ................................................................ 53

Preparation

Camera Recording

Basic Operations

Playback

Useful Features

Advanced Features

References Useful Information .............................................. 54

Demonstration Mode.......................................... 58

Before Requesting Service ................................ 59

Specifications..................................................... 61

References

Operation Summary

Part Names

For details on the use of each part, refer to the page number indicated in the brackets.

Operation Summary

Front view

Terminal cover

Microphone

Zoom lens

VIDEO jack [pp. 20, 53]

AUDIO jack [pp. 20, 53]

DC IN jack [pp. 9, 10]

Speaker

When the cassette compartment door is open

Cassette holder [p. 11]

Lens hood [p. 34]

Cassette compartment door

[p. 11]

Cassette compartment door release [p. 11]

Shoulder strap loop [p. 14]

Lithium battery holder [p. 12]

Rear view

Operation Summary

RECord START/STOP button [p. 16]

Remote sensor

[p. 41]

CHARGE indicator

[p. 9]

MENU button

[p. 22]

Operation buttons [p. 22]

Bottom view

LCD monitor screen

DISPLAY button [p. 22]

Power Zoom Wide angle/ Telephoto control [p. 17] VOLume control [p. 19]

Shoulder strap loop [p. 14]

DUAL/SNAP button [pp. 27, 49, 50]

Hand strap [p. 14]

Power switch (CAMERA/VCR select switch) [pp. 16, 19]

Battery compartment door release [p. 8]

Battery compartment door

[p. 8]

Tripod socket

Operation Summary

On-screen Display Index

For details on the use of each function, refer to the page number indicated.

Operation Summary

Camera Mode

p. 42

p. 26

EX TEND FADE

p. 28

p. 46

p. 31

p. 44

VCR Mode

TLE

p. 26

p. 25

GAMA

p. 29

PIC

EFF

REW

p. 30

p. 28

pp. 27, 49

EXTEND 2X DGTL ZOOM OFF DIS DUAL / SNA P

pp. 32, 33

p. 39

COU

NTER

ROBE

p. 47

WHI TE EXPO

BAL.

p. 48

SUREFOCUS

p. 34

RE TURN

16 9

SCENE

p. 43

p. 51

p. 29

p. ii

p. 41

p. 58

p. 24

p. 13

FADE

REMOTE DEMO MODE O FF

DATE

DI SPLAY OFF SELECT DATE T IME SETT ING

12H 24H

TIME/

SET

MENU 2

OFF DUAL

PIC

NORMAL AUTO ON

1 000

24H

PAGETURE

+ 1 2000

p. 19

REW PLAY STOP STI LLFF

p. 21

p. 53

p. ii

p. 41

p. 39

p. 52

GAMA EFF.

COU NTER

SE ARCH

p. 38

p. 51

Note: See pages 22 and 23 for the procedure to display the desired screen.

ED IT

REMOTE

SET

OFF AUTO ON

PIC TURE

Operation Summary

Quick Reference Index

This index lists some example uses of the VIEWCAM’s features.

Operation Summary

• To record with a Hi8 tape in normal 8 mm format.

• To record powerful close-up images.

• To instantly zoom in on a subject.

• To quickly check what you have just recorded.

• To quickly return the tape to the end of the last recorded scene after playback.

• To locate the point on the tape where to begin recording while in Camera mode.

• To record a backlit subject.

• To record in a dark or poorly-illuminated location.

• To record yourself while monitoring the shot.

• To record a short video message for somebody.

—See page ii ( Recording Format)

—See page 25 (Setting the Digital Zoom)

—See page 26 (Digital Quick Zoom)

—See page 30 (Quick Review)

—See page 31 (Quick Return)

—See page 31 (Edit Search)

—See page 32 (Gamma Brightness Compensation) or page 48 (Manual

Exposure)

—See page 33 (Gain-up)

—See page 35 (Self Recording)

—See page 36 (Self-recording Message)

• To find the beginning of a recorded scene to be played back. —See page 38 (Program Search)

• To display the elapsed recording or playback time. —See page 39 (Tape Counter Feature)

• To focus on an off-centred subject. —See page 46 (Manual Focus)

• To record an inset picture within the main picture. —See page 49 (Digital Dual Picture)

• To increase the brightness of the subject during playback. —See page 52 (Gamma Playback)

Operation Summary

Warning Indicators

Operation Summary

Displayed for the first

3 seconds

Displayed after

3 seconds

Description of warning

The video cassette is defective and should be removed (see page 11).

Dew has formed inside the VIEWCAM. Wait for a few hours until the dew disappears (see page 55). About 10 seconds after this warning appears, the VIEWCAM automatically turns off.

The battery is almost depleted. Replace it with a fully charged battery pack (see page 8).

The video heads are clogged and should be cleaned (see page 55).

There is no video cassette in the VIEWCAM. Insert a cassette (see page 11).

The erasure protect tab on the video cassette has been slid to the record-protect position, preventing recording (see page 57).

The tape is about to end. Prepare a new cassette (see page 11).

The tape has reached the end. Replace it with a new cassette (see page 11).

Note: indicates a flashing display.

In Self Recording mode, all warnings will be indicated by displayed in the centre of the monitor. To check the type of warning, rotate the monitor back to the normal position.

Preparation

Inserting and Removing the Battery Pack

Inserting the Battery Pack

1 Make sure that the Power switch is set

to OFF.

Power switch

2 Slide the battery compartment door

release on the bottom of the VIEWCAM in the direction of the arrow to open the battery compartment door.

Battery compartment door release

4 Close the door, pressing it firmly in the

centre until it clicks.

Preparation

Removing the Battery Pack

1 Perform steps 1 and 2 above.

2 Press the battery release as shown to

remove the battery pack.

Battery release

3 Insert the battery pack into the com-

partment as shown, and push it in completely until it locks into place.

Caution:

• Do not force the battery pack into the battery compartment if it does not go in easily.

Cautions:

• BEFORE REMOVING THE BATTERY PACK,

ALWAYS STOP THE TAPE AND TURN THE POWER OFF. If you remove the battery pack

during recording or playback, the tape will remain wound around the video head drum, potentially causing damage to the tape.

• Make sure the battery compartment door is closed firmly during operation. If it is not, the battery pack may fall out or VIEWCAM operation may fail because of the poor contact pressure.

• Remove the battery pack from the VIEWCAM if the VIEWCAM will not be used for a long period of time.

• When removing the battery pack, do not tilt

the VIEWCAM so that the battery compartment faces down. The battery pack may fall out.

• Do not expose the battery compartment door to strong force, as it may come off.

• Use only SHARP model BT-H22 or BT-H32 battery packs with this VIEWCAM. Use of other batteries may present a risk of fire or explosion.

Preparation

Charging the Battery Pack

Power switch

CHARGE indicator

Preparation

1 Insert the battery pack into the VIEWCAM

(see page 8). Make sure that the Power switch is set to OFF.

• The battery pack will not charge when the Power switch is set to CAMERA or VCR.

2 Connect the power cord to the AC adapter,

then insert the AC plug into a power outlet.

3 Open the terminal cover on the VIEWCAM

and insert the DC plug of the AC adapter into the DC IN jack on the VIEWCAM.

• The CHARGE indicator will light up in red.

Terminal cover

Charging time and maximum continuous recording and playback times

Battery

BT-H22

BT-H32

Notes:

• Using the zoom (see page 17) and other

• The charging time and recording time may vary

• It is recommended that you have enough battery

• See page 56 for more information on using the

Caution:

• Charge only SHARP model BT-H22 or BT-H32

Charging

pack

functions or turning the power on and off frequently will increase power consumption. This may result in a decrease of more than 50% in the actual recording time compared to the maximum continuous recording time listed above.

depending on the ambient temperature and the condition of the battery pack.

packs on hand to provide two to three times your estimated recording time.

battery pack.

battery packs. Other types of battery packs may burst, causing personal injury and damage.

time

approx.

3 hr.

approx.

6 hr.

Max.

continuous

recording

time

approx.

1 hr. 35 min.

approx.

3 hr. 10 min.

Max.

continuous

playback

time

approx.

1 hr. 35 min.

approx.

3 hr. 10 min.

DC IN jack

To power outlet

4 When the battery is fully charged, the

CHARGE indicator will light up in green. Remove the DC plug from the VIEWCAM, and close the terminal cover.

Caution:

• When removing the plugs, grasp the plug, not the cable.

Powering the VIEWCAM from an AC Outlet

Caution:

• The supplied AC adapter is specially designed for use with this VIEWCAM, and should not be used as a power supply for other camcorders.

Power switch

1 Connect the power cord to the AC

adapter, then insert the AC plug into a power outlet.

2 Make sure that the Power switch is set

to OFF.

3 Open the terminal cover and insert the

DC plug of the AC adapter into the DC IN jack on the VIEWCAM.

Terminal cover

Cautions:

• BEFORE REMOVING THE DC PLUG, ALWAYS

STOP THE TAPE AND TURN THE POWER OFF.

If you remove the DC plug during recording or playback, the tape will remain wound around the video head drum, potentially causing damage to the tape.

• Remove the DC plug from the VIEWCAM if you will not use the VIEWCAM for a long period of time.

• When removing the plugs, grasp the plug, not the cable.

Note:

• Close the terminal cover after use.

Preparation

DC IN jack

To power outlet

4 Hold down the Lock

button and slide the Power switch to CAMERA or VCR.

Lock button

Preparation

Inserting and Removing a Cassette

Inserting a Cassette

1 Supply power to the VIEWCAM, then

slide the release and open the cassette compartment door.

• The cassette holder extends and opens

Preparation

automatically.

Cassette compartment

door release

2 Insert the cassette fully with the window

facing outwards, and with the erasure protect tab facing upwards.

Erasure protect tab

4 Wait for the cassette holder to fully

retract. Close the compartment door by pressing the centre until it clicks into place.

Removing a Cassette

Perform step 1 above, then take out the cassette.

Cautions:

• Do not try to close the cassette compartment door while the cassette holder is extending or retracting.

• Be careful not to get your fingers caught in the cassette holder.

• Do not apply force to the cassette holder except when pressing the PUSH mark to close it.

• Do not tilt the VIEWCAM or hold it upside down when you are inserting or removing a cassette. It may damage the tape.

• Remove the cassette if you will not use the VIEWCAM for a long period of time.

• If you do not correctly close the cassette holder in step 3, the VIEWCAM’s cassette protection mechanism might eject the cassette. If this happens, repeat the insertion procedure.

• Do not attempt to pick up the VIEWCAM by the cassette compartment door.

3 Press the PUSH mark gently until the

cassette holder clicks into place.

• The cassette holder retracts automatically.

PUSH mark

Notes:

• If the battery power is too low, you may not be able to eject the cassette. Replace the battery pack with a fully charged one.

• See page 57 for more information on the video cassette tapes for use with this VIEWCAM.

Installing the Lithium Memory Battery

The supplied lithium battery is used to store the memory of the date and time settings.

1 Slide the cassette compartment door

release and open the cassette compartment door.

5 Close the cassette compartment door by

pressing the centre until it clicks into place.

Preparation

Cassette compartment

door release

Note: The cassette holder will extend and open when the VIEWCAM is connected to a power source. Be sure to close the cassette holder before proceeding to the next step (see page 11).

2 Pull out the lithium battery holder using

a pointed object such as the tip of a ballpoint pen.

Lithium battery holder

3 Insert the lithium battery

into the battery holder with the ` side of the battery facing the j side of the holder.

Removing the Lithium Battery

Perform steps 1 and 2 above, then lift out the battery from the battery holder.

Note:

• Replace the battery with a new CR2025 battery when the date and time indicator starts to fall behind the correct time.

Notes on the Use of the Lithium Battery

CAUTION: Danger of explosion if battery is

incorrectly replaced. Replace only with the same or equivalent type CR2025 recommended by the equipment manufacturer.

WARNING KEEP THIS BATTERY AWAY FROM

CHILDREN. IF SWALLOWED, CONSULT A PHYSICIAN IMMEDIATELY FOR EMERGENCY TREATMENT.

CAUTION BATTERY MAY EXPLODE IF MIS-

USED OR INSTALLED WITH POLARITY REVERSED. DO NOT RECHARGE, DISASSEMBLE OR DISPOSE OF IN FIRE.

• Do not short-circuit, recharge, disassemble, or heat the lithium battery.

• Should the lithium battery leak, wipe the battery compartment and holder clean, and then insert a new battery.

• The lithium battery will last about one year of normal usage.

4 Push the battery holder back

into position.

j mark

Preparation

2 000

1 2000

SETTI NG

2 000

6 2001

SETTI NG

10 00

6 2001

SETTI NG

10 30

6 2001

SETTI NG

Setting the Date and Time

Example: Setting the date to 2 June 2001 (2. 6.

2001) and the time to 10:30 am (10:30).

Note:

• Check that the lithium memory battery has been installed before setting the date and time.

Power switch

Preparation

MENU button

DISPLAY button

1 Hold down the Lock

Lock button

button and slide the Power switch to CAMERA.

2 Press the MENU button until

(MENU 3) appears.

DATE

TIME/ DI SPLAY OFF SELECT DATE TIME SETTING

12H 24H

• If MENU 1 appears on the screen, press the PAGE button ( ) until MENU 3 appears.

24H

SET

3 Press the SET button (B).

DATE

SET

TIME/ DI SPLAY OFF SELECT DATE TIME SETTING

12H 24H

24H

SET

1 000

PIC

1 000

PIC

+ 1 2000

PAGETURE

+ 1 2000

PAGETURE

4 Press the 쑽 or 쒀 button (C or D) to

select “2” (day), and press the SET button.

5 Press the 쑽 or 쒀 button to select “6”

(month), and press the SET button.

SETTING

6 2000

000

6 Press the 쑽 or 쒀 button to select

“2001” (year), and press the SET button.

7 Press the 쑽 or 쒀 button to select “10”

(hour), and press the SET button.

8 Press the 쑽 or 쒀 button to select “30”

(minute), and press the SET button.

• The internal clock now starts operating.

9 Press the DISPLAY button to turn off the

SET

DATE

DI SPLAY OFF SELECT DATE TIME SETTING

12H 24H

TIME/

10 30 AM 12H

SET

PIC

+ 6 2001

PAGETURE

menu screen

Changing to the 12-hour Time Mode

After performing step 8 above, press the 쑽 or 쒀 button (Q) to select “12H/24H”, then press

the SET button (B) (W) to select “12H”.

Notes:

• The date and time, once set, are stored in memory.

• The menu screen automatically turns off if no settings are made within 5 minutes.

• When changing the date and time settings, press the 쑽 or 쒀 button (C or D) to select “SETTING”, then press the SET button.

Using the Hand Strap and the Lens Cap

1 Open the hand strap flap (Q) and grip

strap (W), and pass the grip strap through the loop at the end of the lens cap cord (E).

Hand strap flap

Grip strap

Notes:

• Always replace the lens cap on the lens when the VIEWCAM is not in use.

• Attach the lens cap to the hand strap so it will not get in the way during recording.

Attaching the Shoulder Strap

1 Hold one end of the strap and thread it

through the loop on the left side of the LCD screen.

Preparation

2 Pass your hand through the hand strap

and put your thumb close to the Power Zoom control. Then pull the grip strap tight until it fits snugly, seal the Velcro closures (Q), and close the hand strap flap (W).

Caution:

• Do not swing the VIEWCAM by the hand strap.

Attaching and Removing the Lens Cap

When attaching or removing the lens cap, press both tabs on the sides of the cap.

Press both tabs.

2 Loosen the strap in the buckle, then feed

the end of the strap through the buckle, as shown.

3 Draw the strap in the direction of the

arrow to secure.

4–6 Use the same procedure to attach the

other end of the strap to the loop on the lens side.

LCD screen side Lens side

Buckle

Preparation

Using the Sun Hood

It is recommended that you use the supplied sun hood when recording outdoors on a sunny day or at a brightly illuminated location.

Attaching the Sun Hood

Fit the bottom clip on the sun hood into the slot below the LCD screen (Q), and align the top clip with the ridge above the LCD screen (W).

Preparation

Then press the sun hood until it clicks into place.

Top clip

Bottom clip

Opening the Sun Hood

Open the sun hood by lifting the top cover in the direction of the arrow. (The side covers will open automatically.)

Top cover

Closing the Sun Hood

1 Fold in both side covers while holding the

top cover open.

2 Close the top cover by gently pressing the

mark down until the cover clicks into

place.

Removing the Sun Hood

Carefully lift the top clip up with your thumb while supporting the sun hood with your hand (Q). Then pull the sun hood in the direction of the arrow (W) to release the bottom clip.

Side covers

Note:

• You can operate the Operation buttons below the LCD screen with the sun hood attached.

Cautions:

• Be sure to close the sun hood before transporting the VIEWCAM. If the VIEWCAM is transported with the sun hood open, the sun hood may fall off or become damaged.

• Do not leave the sun hood in an unventilated car in direct sunlight. The high temperature may cause a deformation of the casing.

+ 50 hidden pages
