Page 1
VERSATILE DESIGN FOR EXCEPTIONAL CUSTOMER SERVICE
UP-800 S E R I E S
P O I N T
-O F -S A L E S Y S T E M
Page 2
INCR EA SE D FLE XI BI LI T Y AND
US ER
-F RI EN DLY FEATURES...
AT YOU R S ER VI CE
Now it’s easy to get the power, efficiency and expandability that your business needs
to stay one step ahead. Built on Sharp’s world-renown reliability and innovative
technology, the new UP-800 Series offers advanced, easy-to-use features that allow
you to customize your Point-of-Sales System for your hospitality or retail needs.
Enhanced software features combined with a new innovative touch screen and
programmable keyboard are designed to increase speed of service when entering
transactions. A 6.5" backlit LCD color display makes it easy for operators to verify
items, prices and order data. Employees can utilize the keyboard or the new
Touch Screen Interface to enter data, allowing for fast order entry and improved
service. With integrated easy-to-use software and flexible configuration options, any
of the models in the UP-800 Series can easily grow as your business needs evolve.
IM PR ES SI VE FE AT UR ES FO R BUSY ENVIRONMENTS
The UP-800 Series builds on years of Sharp technology expertise to
deliver a flexible yet incredibly reliable POS system. Well-designed
hardware and a stable operating platform provide for faster order
entry, enhanced back-end operations and improved customer
service. Advanced features include:
• Color touch LCD screen
• Space saving cash drawer maximizes counter space for operations
• 30 flexible function menus put the right options together
for fast operations
• Enhanced manager control of discounts and voids minimizes abuse
• Quantity tax handling for special merchandise
• Hold and recall a transaction to help a customer without stopping
your sales flow
• SD Card interface simplifies backup for data and programs
• Ethernet interface for multiple terminals (Up to 32)
• Flexible payment options to meet customer demands
• Credit/Debit
• Gift Card processing
• EBT Electronic Benefits Transfer
Easy-to-use touch-screen menus for programming and reporting access.
All the models in the UP-800 Series allow for an advanced set
of upgradeable options to meet your growing business needs.
Optional features include scale, scanner for UPC/EAN, coin dispenser,
2-line 20 character pole display, ViVOpay™ contactless payment
device, real-time output to printer or security systems, and a
BERG drink dispenser.
Customizable function key for the HOME MENU and up to
30 function menus.
Page 3
AD VA NC ED T EC HN OLOGY SE RV ES UP A
HI GH ER LE VEL O F P ER FO RM AN CE
Designed to meet a variety of hospitality and retail needs, the Sharp
UP-800 Series delivers efficient management tools that provide
outstanding performance, reliability, and versatility needed for today’s
busy environments.
LOR LCD TOUCH PANEL
CO
The UP-800 Series 6.5" color LCD backlit display details eight lines
of on-screen information, making it easy for servers to verify orders
and confirm sales data. Optimized for use in dim light, the screen is
also adjustable and can accommodate up to 15 customizable keys for
quick entry.
QUICK CUSTOMER SERVICES
The Sharp UP-800 Series delivers enhanced speed as well as more
accurate order entry. Time-saving features include fast keyboard
entry, touch-screen operation for modifiers and choices, plus
flexible function menus that combine special functions for fast
and efficient action.
INCREASE SALES AND PROFITS
The Sharp UP-800 Series supports promotions and combo meals,
enabling you to drive sales with targeted specials and offers. Detailed
reporting lets you analyze sales and purchase history so you can
pinpoint trends and make menu modifications accordingly.
EASY-TO-USE INTERFACE
The UP-800 Series is incredibly user-friendly, so you’ll spend less time
training employees. Automated prompts and simple, customized
screens make it easy for staff and managers to enter information
quickly and accurately.
ENHANCED CONTROL WITH STANDARD ETHERNET
For increased versatility, one UP-800 can function as a central terminal
for all others in the location. Ethernet capability enables POS data to
be combined centrally, so you can save time closing out and totaling.
FLEXIBLE PAYMENT OPTIONS
To support a variety of tender options, the UP-800 Series offers an
optional magnetic card reader for credit and debit purchases, gift card
purchases and EBT Electronic Benefits Transfers.
ARP INTELLIGENT DATA ENTERPRISE
SH
Designed for businesses with
multiple locations, SIDE leverages
the power of the internet to view
automatically polled data from
multiple stores. Now you can easily
review data, spot variances, trends
and issues and react more quickly
to customer demands. Data can
be analyzed, exported and
manipulated to improve daily
operations. With optional SIDE reporting, you get a simple and
inexpensive solution that enhances operational control and
management for multi-unit operators, Franchisees, Franchisers
and Corporate Owned operations.
(SIDE)
SDW BACK OFFICE SOFTWARE
The Sharp UP-800 Series delivers
increased functionality with the
"back-of-house" solution. Get
more control to manage your
business with detailed reporting
features. You can easily schedule
communications between the
POS and the software to provide
access for changes at the POS and
sale data in the PC for reporting. Several optional modules allow you
to meet your growing business needs with graphic reporting, data
export, and inventory control.
PRI N TE R AN D KE Y B O A RD ST Y L ES T H AT F I T YO UR BU S IN E S S
UP-810F
• Single Station Printer
• Flat Keyboard
UP-820F
• Two-Station Printer
• Flat Keyboard
UP-820N
• Two-Station
• Raised Keyboard
Page 4
UP- 80 0 SE RIE S S P EC IFI CATI ONS
Features
QSR
Hold/Recall to interrupt an order
Combination meals: One button Upsize, Auto combo
meal recognition
Price level shift allows one item to act for up to 6 sizes
Menu level shift allows more items per keyboard
Auto prompted condiment choices; Flexible
condiment trees
Split pay for individual payments
Tax adjustment based on order; Take Out vs. Eat In
Cafeteria
Hold / Recall to allow another customer transaction
Tray Subtotal for independent subtotals
Accept multiple payments for individual payment of
transaction
UPC scanning
UPC learning for new item sales
Scale items w/ open/preset tare weight
C-store/Retail
Up to 60,000 items
UPC scanning
UPC learning for new item sales
UPC Price Change in transaction
Scale items w/ tare weight
Mix & match tables for multiple item price adjustment
TSR
Open table list
Cover Count
Split Check
Condiment choices
Condiment call a different condiment
Check Transfer
Gratuity
Event Deposit
General
Price Lookup in transaction
Drawer Cash Management: Enter Start/End cash for
cashier reporting
Dollar ($) and Percent (%) discounts: By item
or subtotal
Media approval system: Allow only desired checks or
exclude disapproved accounts
Credit cards, Debit cards and Gift card payments
Reporting
Cashier reports
System and Terminal reports
Hourly reports
Specifications
Color: Black (Gray2)
Dimensions:
(WxDxH) 13.74" x 17.24" x 10.27"
Dimensions with
Drawer: (WxDxH) 13.97" x 17.24" x 15"
Weight: 31.63 lbs.
Temperature/Humidity: 0° to 40° C (32° to 104° F) 20%
to 90%
Operator Input: Touchscreen and keyboard
Magnetic Card Reader: UP-E13MR3 optional
Data Card: SD card slot x 1
(Max SD card size 2GB)
LAN Ethernet: TCP/IP 10Base-T/100Base-TX
Input/Output Ports: Serial RS-232 x 4 (Db9 x 2,
RJ-45 x 2), Customer Display
x 1, Pole Display x 1
Drawer: 1 standard ( 2nd optional)
Power Supply: 120V AC/ 60Hz +- 10%
Power Consumption: 67W (Max.)
Power Saving Modes: Automatic Standby
Memory Backup: Internal Rechargeable Battery
Sharp Optional Accessories
ER-04MB2 Optional Memory
ER-03DWB7 Cash Drawer
ER-04DW Cash Drawer
ER-56DWB3 Cash Drawer
UP-E13MR3 Card Reader
© 2008 Sharp Electronics Corporation. All rights reserved.
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, NJ 07495-1163
1-800-BE-SHARP • www.sharpusa.com
Printed in U.S.A.
Design and specifications subject to change without notice. Sharp, My Sharp and
all related trademarks are trademarks or registered trademarks of Sharp Corporation
and/or its affiliated companies. Windows, Windows Server and Windows Vista are
trademarks or registered trademarks of Microsoft Corporation. All other trademarks
are the property of their respective owners.
