Sharp R32BST User Manual

R
MICROWAVE OVEN
Thank you for buying a Sharp Microwave Oven. Please keep this operation manual handy, as it describes all the features of your oven and will enable you to cook many varieties of foods. The manual is divided into two sections:
2.MANUAL CHART GUIDES This section is at the back of the manual, it contains the more commonly used information such as how to prepare food, which cooking utensil to use, standing time.
Please take some time to read your operation manual carefully, paying particular attention to the warnings and special notes, the automatic cooking menus programmed into your new oven have been carefully developed to give optimum results when the step by step instructions are followed. When selecting another home appliance, please again consider our full range of Sharp products.
MODEL
CONTENTS
Warranty Warning SpecialNotesandWarning OvenandAccessories/Installation ControlPanel BeforeOperating SettingtheClock MicrowavePowerLevel KitchenTimerFunction ManualOperation MicrowaveCooking AutoMenuFunction OtherConvenientFunctions WeightDefrostFunction TimeDefrostFunction AutoMenuChart ReheatingAdvice CareandCleaning ServiceCallCheck Specifications ManualChartGuides DefrostTimesforMeat,PoultryandBread FreshVegetableChart FrozenVegetableChart RiceandPastaCookingChart ScrambledEggGuide Reheating/DefrostingConvenience CookingandUtensilGuide HelpfulHints Notes
R- 222 B
2 (ST)3
Pages
iii 1 2 3 4 5 5 5 6 6 6 7 8 9 9 10 11 12 12 12 A1 A1 A2 A3 A3 A3 A4 A5 A6

R201T(W) [Cover].indd 1 6/18/10 5:23:32 PM
REPLACEMENT WARRANTY
Consumer Electronic Products
Congratulations on Your Purchase!
This Sharp product is warranted against faults in material and manufacture for the period as stated in the table below.
Should you need to make a claim against this warranty please take your product back to the place of purchase.
This warranty does not extend to defects or injuries caused by or resulting from causes not attributable to faulty parts or the manufacture of the product, including but not limited to, defect or injury caused by or resulting from misuse, abuse, neglect, lack of maintenance, accidental damage, improper voltage, liquid spillage, vermin infestation, software, or any alterations made to the product which are not authorised by Sharp.
Please retain your sales documentation, as this should be produced to validate a warranty claim. This warranty is in addition to and in no way limits, varies or excludes any implied rights and remedies under any relevant legislation in the country of sale.
Australian customers: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. The criteria of a major failure is defined in the Australian Consumer Law. Should you require any assistance with a major failure please
contact Sharp Customer Care.
WARRANTY PERIOD Microwave Oven 12 months Small Home Appliances 12 months
SHARP CORPORATION OF
NEW ZEALAND LIMITED
59 Hugo Johnston Drive
Penrose, Auckland
LIM
PORATION OF
R
039 405
003
SHARP CO
USTRALIA PTY.
A ITED
ABN 40
2 Julius Avenue
orth Ryde N
N SW 2113
SPform 040 (NOV 2016)
IMPORTANT NOTICE: This warranty applies only to products sold in Australia & New Zealand
FOR LOCATION ENQUIRIES WITHIN
AUSTRALIA
REGARDING YOUR LOCAL
SHARP APPROVED SERVICE CENTRE
VISIT OUR WEBSITE AT
www.sharp.net.au
OR CALL SHARP
LOCAL CALL
SHARP CORPORATION OF AUSTRALIA PTY LTD
1 300 135 022
FOR PRODUCTS PURCHASED
NEW ZEALAND
CONTACT YOUR SELLING DEALER/RETAILER
OR CALL
SHARP CUSTOMER SERVICES
TELEPHONE: 09 573 0111
FACSIMILE: 09 573 0113 WEB: www.sharpnz.co.nz
SPform019(NOV 2016)
SHARP CORPORATION OF NEW ZEALAND LIMITED
WARNING
IMPORTANT SAFETY INSTRUCTIONS : READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. To reduce the risk of fi re in the oven cavity:
a. Do not overcook food. b. Remove wire twist-ties from paper or plastic bags before placing bag in the oven. c. Do not heat oil or fat for deep frying. The temperature of the oil cannot be controlled. d. Look at the oven from time to time when food is heated in disposable containers made of plastic,
paper or other combustible materials for signs of smoke or burning.
e. If materials inside the oven should ignite, or smoke is observed, keep oven door closed, turn oven
off, and disconnect the power plug, or shut off power at the fuse or circuit breaker panel. To reduce the risk of an explosion or delayed eruptive boiling when handling the container. Your microwave oven is capable of heating food and beverages very quickly therefore, it is very important that you select the appropriate cooking time and power level for the type and quantity of food to be heated. If you are unsure of the cooking time and power level required, begin with low cooking times and power levels until the food is suffi ciently heated evenly throughout. Additionally:
a. Do not place sealed containers in the oven. Babies bottles fi tted with a screw cap or teat are
considered to be sealed containers.
b. Do not use excessive amount of time. c. When boiling liquids in the oven, use a wide-mouthed container. d. Stand at least for 20 seconds at the end of cooking to avoid delayed eruptive boiling of liquids. e. Stir the liquid before and during cooking. Use extreme care when handling the container or inserting
a spoon or other utensil into the container. This oven is for home food preparation only and should only be used for heating, cooking and defrosting food and beverage. It is not suitable for commercial, laboratory use, or heating therapeutic devices eg. Wheat bags. Never operate the oven whilst any object is caught or jammed between the door and the oven. Do not try to adjust or repair the oven yourself. It is hazardous for anyone other than a qualifi ed service technician trained by SHARP to carry out any service or repair operation. Especially those which involve the removal of a cover which gives protection against exposure to microwave energy are very hazardous. Do not operate the oven if it is not working correctly or damaged until it has been repaired by a qualifi ed service technician trained by SHARP. It is particularly important that the oven door closes properly and that there is no damage to: (1) Door (warped), (2) Hinges and Latches (broken or loosened), (3) Door Seals, Sealing Surfaces and oven cavity (buckled or deformed), (4) Burn marks on the door seal faces. Do not bump, or catch utensils, loose clothes and your accessories on the door safety latches when removing food from the oven. Never poke an object, particularly a metal object, through a grille or between the door and the oven while the oven is operating. Never tamper with or deactivate the door safety latches. Always use oven gloves to prevent burns when handling utensils that are in contact with hot food. Enough heat from the food can transfer through utensils to cause skin burns. Should the power supply cord become damaged, it must be replaced with a special cord supplied by a SERVICE CENTRE APPROVED BY SHARP and it must be replaced by a qualifi ed service technician trained by SHARP in order to avoid a hazard. If the oven lamp fails please consult your dealer or a qualifi ed service technician trained by SHARP. Avoid steam burns by directing steam away from the face and hands. Slowly lift the furthest edge of a dish's cover including microwave plastic wrap etc., and carefully open popcorn and oven cooking bags away from the face. Make sure that the power supply cord is undamaged, and that it does not run under the oven or over any hot surfaces or sharp edges. To prevent the turntable from breaking:
a. Before cleaning the turntable with water, leave the turntable to cool. b. Do not place anything hot on a cold turntable.
c. Do not place anything cold on a hot turntable. Do not place anything on the outer cabinet. Do not store food or any other items inside the oven. Make sure the utensil does not touch the interior walls during cooking. Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
1
SPECIAL NOTES & WARNING
T’NODOD
Eggs, fruits, vegetables, nuts, seeds, sausages and oysters
Popcorn Use specially bagged popcorn for the
Baby food Transfer baby food to small dish and
General Food with fi lling should be cut after
Liquids (Beverages)
Canned foods Remove food from can. .snac ni elihw doof kooc ro taeH**
Sausage rolls, Pies, Christmas pudding
Meats Use a microwave proof roasting rack to
Utensils Check the utensils are suitable for
Aluminium foil Use to shield food to prevent over
Browning dish Place a suitable insulator such as a
Puncture egg yolks and whites and
*
oysters before cooking to prevent “explosion”.
*
Pierce skins of potatoes, apples, squash, hot dogs, sausages and oysters so that steam escapes.
*
microwave oven.
Listen while popping corn for the
*
popping to slow to 1-2 seconds.
*
heat carefully, stirring often. Check for suitable temperature to prevent burns.
Remove the screw cap and teat before
*
warming baby bottles. After warming shake thoroughly. Check for suitable temperature.
*
heating, to release steam and avoid burns.
Use a deep bowl when cooking liquids
*
or cereals to prevent boiling over.
For boiling or cooking liquids see WARNING on page 2 to prevent explosion and delayed eruptive boiling.
Cook for the recommended time. (These foods have high sugar and/or fat contents.)
collect drained juices.
MICROWAVE cooking before you use them.
*
cooking.
Watch for sparking. Reduce foil or keep
*
clear of cavity walls.
microwave and heat proof dinner plate between the turntable and the browning dish.
Cook eggs in shells. This prevents
*
“explosion”, which may damage the oven or injure yourself.
Cook hard/soft boiled eggs.
*
Overcook oysters.
*
Dry nuts or seeds in shells.
*
Pop popcorn in regular brown bags or
*
glass bowls.
Exceed maximum time on popcorn
*
package.
Heat disposable bottles.
*
Overheat baby bottles.
*
Only heat until warm.
Heat bottles with nipples on.
*
Heat baby food in original jars.
*
Heat or cook in closed glass jars or
*
airtight containers.
Deep fat fry.
*
Heat or dry wood, herbs, wet papers,
*
clothes or fl owers.
*
Operate the oven without a load (i.e. an absorbing material such as food or water) in the oven cavity.
*
time. See REHEATING-FOOD CHART on page10.
*
cooking.
*
cooking. Metal refl ects microwave energy and may cause an electrical discharge known as arcing.
*
Use too much.
*
Shield food close to cavity walls.
Sparking can damage the cavity.
*
recommended by the manufacturer. Excessive preheating can cause the glass turntable to shatter and/or damage internal parts of the oven.
rof taeH*
fi hctac yam yeht sa koocrevO* re.*
eht no yltcerid taem ecalP*
p eht deecxE*
emit gnitaeher
dednemmocer naht regnol
rof elbatnrut
EVAWORCIM rof slisnetu latem esU*
2
1
4
13
14. Turntable
6
5
(glass)
16. Coupling
11
SEIROSSECCA DNA NEVO
2
10
9
3
7
8
4
12
15. Turntable support
OVEN
1. Door handle
2. Oven lamp
3. Door hinges
4. Door safety latches
5. Door
6. Door seals and sealing surfaces
7. Turntable motor shaft
8. Oven cavity
9. Control panel
10. Waveguide cover (DO NOT REMOVE)
11. Power supply cord
12. Ventilation openings
13. Outer cabinet
ACCESSORIES:
Check to make sure the following accessories are provided:
(14) Turntable (15) Turntable support (16) Coupling
• Place the coupling into the turntable motor shaft and then place the turntable support in the centre of the oven floor so that it can freely rotate around the coupling. Place the turntable onto the turntable support so that it locates firmly into the coupling.
• To avoid turntable damage, ensure dishes and containers are lifted clear of the turntable rim when removing them from the oven.
NOTE: When you order accessories, please mention two items: part name and model name to your dealer or SHARP authorised service agent.
INSTALLATION INSTRUCTIONS
1. Remove all packing materials from the oven cavity, (do not remove the waveguide cover), and the feature sticker from the outside of the door, if there is one. Check the unit for any damage, such as a misaligned door, damaged door seals around the door or dents inside the oven cavity or on the door. If there is any damage, please do not operate the oven until it has been checked by a SERVICE CENTRE APPROVED BY SHARP and repaired, if necessary.
2. Accessories provided
1) Turntable 2) Turntable support
3) Coupling 4) Operation manual
3. Ensure
4. This oven is designed for countertop or cabinet use as well. It should not be installed in any area where
WARNING: The electrical outlet must be readily accessible so that the unit can be unplugged easily in an
5. Neither the manufacturer nor the distributors can accept any liability for damage to the machine or personal
The A.C. voltage must be single phase 230 – 240V, 50Hz.
6. This appliance must be earthed.
7. Operate the oven from a general purpose domestic outlet.
If a generator is used, do not operate the oven with non-sinusoidal outputs.
hat the coupling is installed.Place the turntable support on the oven floor, then place the
t
turntable onto the turntable support and coupling, ensuring it is located firmly. Refer to the diagram
.
ab veo NEVER operate the oven without the turtable.
excessive heat and steam are generated, for example, next to a conventional oven unit. The oven should be installed so as not to block ventilation openings. Allow a space of at least 10 cm on the top, 5 cm on both sides and at the rear of the oven for adequate air circulation.
emergency.
injury for failure to observe the correct electrical connecting procedure.
3
CONTROL PANEL
1. DIGITAL DISPLAY and INDICATORS
7
8
9
10
1
MICROWAVE indicator
TIME DEFROST indicator
WEIGHT DEFROST indicator
POWER LEVEL indicator
CLOCK indicator
KITCHEN TIMER indicator
2
3
2. Auto Menu options
4
5
6
3. WEIGHT DEFROST button
4. CLOCK button
5. STOP/CLEAR button
6. START/ +30sec./ENTER button
7. MICRO. POWER button
8. TIME DEFROST button
9. KITCHEN TIMER
10. ENTRY dial
Rotate to enter the cooking time, time of day, power level, weight and
AUTO MENU indicator
CHILD LOCK indicator
WEIGHT indicator
A1: Pizza A2: Rice A3: Vegetables A4: Pasta A5: Potato A6: Fish A7: Beverage A8: Popcorn
to select an auto menu
4
