OPERATION MANUAL

This operation manual contains important information which you should read

carefully before using your microwave oven.

IMPORTANT: There may be a serious risk to health if this operation manual is not

followed or if the oven is modified so that it operates with the door open.

If you require any advice or assistance regarding your

Sharp product, please visit our website:

http://www.sharp.co.uk/support

Customers without Internet access may telephone (during office hours):

08705 274277

or from Ireland

(01) 676 0648

A. Information on Disposal for Users (private households)

1. In the European Union

Attention: If you want to dispose of this equipment, please do not use the ordinary dust bin! Used electrical and electronic equipment must be treated separately and in accordance with

legislation that requires proper treatment, recovery and recycling of used electrical and

Attention:

Your product is

marked with this

symbol.

It means that used electrical and electronic

products should

not be mixed

with general

household

waste. There

is a separate

collection

system for these

products.

electronic equipment. Following the implementation by member states, private households within the EU states may

return their used electrical and electronic equipment to designated collection facilities free of charge*.

In some countries* your local retailer may also take back your old product free of charge if you purchase a similar new one.

*) Please contact your local authority for further details. If your used electrical or electronic equipment has batteries or accumulators, please dispose

of these separately beforehand according to local requirements. By disposing of this product correctly you will help ensure that the waste undergoes the

necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health which could otherwise arise due to inappropriate waste handling.

2. In other Countries outside the EU

If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal.

For Switzerland: Used electrical or electronic equipment can be returned free of charge to the dealer, even if you don’t purchase a new product. Further collection facilities are listed on the homepage of www.swico.ch or www.sens.ch.

B. Information on Disposal for Business Users

1. In the European Union

If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product.

You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities.

For Spain: Please contact the established collection system or your local authority for take-back of your used products.

2. In other Countries outside the EU

If you wish to discard of this product, please contact your local authorities and ask for the correct method of disposal.

R-27STM-A.indd BR-27STM-A.indd B 7/3/09 5:31:03 PM7/3/09 5:31:03 PM

CONTENTS

OVEN AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

ONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

AFETY:

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 5

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

PERATION:

Maff Heating Category . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

How Your Oven Works. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Microwave Power Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

How to Operate Your Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 10

Auto Cook / Auto Cook Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 - 12

Express Cook / Express Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 15

Express Cook Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Express Defrost Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Convenient Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

OOKING ADVICE:

Microwave Cooking Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 - 18

Suitable Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Defrosting Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Reheating Advice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

OOKBOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 - 34

FTERCARE:

Cleaning & Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

To Replace the Mains Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Calling for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

UARANTEE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

R-27STM-A.indd 1R-27STM-A.indd 1 7/3/09 5:31:03 PM7/3/09 5:31:03 PM

OVEN AND ACCESSORIES

OVEN:

1. Oven lamp

2. Control panel

3. Door opening handle

4. Waveguide cover (DO NOT REMOVE)

5. Oven cavity

6. Coupling

7. Door latches

8. Door hinges

9. Door seals and sealing surfaces

10. Door

11. Power cord

12. Ventilation openings

13. Outer cabinet

ACCESSORIES:

Check to make sure the following accessories are provided:

14. Turntable

15. Roller stay

• Place the roller stay in the coupling

on the oven floor, then place the turntable on to the roller stay, ensuring it is located firmly.

• To avoid turntable damage, ensure dishes or containers are lifted clear of the turntable rim when removing them from the oven.

NOTES:

• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it is not damaged.

• Always operate the oven with the turntable and roller stay fitted correctly. This promotes thorough, even cooking. A badly fitted turntable may rattle, may not rotate properly and could cause damage to the oven.

• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you start the oven. This does not affect cooking performance.

• When you order accessories, please quote both the PART NAME and MODEL NUMBER to your dealer or SHARP approved service facility.

WARNING: The door, outer cabinet, oven cavity, turntable and dishes will become very hot during operation. To prevent burns, always use thick oven gloves.

R-27STM-A.indd 2R-27STM-A.indd 2 7/3/09 5:31:03 PM7/3/09 5:31:03 PM

CONTROL PANEL

1. DIGITAL DISPLAY

2. INDICATORS

BUTTONS:

3. AUTO COOK

4. EXPRESS COOK

5. EXPRESS DEFROST

6. START/AUTO MINUTE

7. TIME/WEIGHT

8. STOP/CLEAR

9. POWER LEVEL

R-27STM-A.indd 3R-27STM-A.indd 3 7/3/09 5:31:03 PM7/3/09 5:31:03 PM

INSTALLATION

WARNING:

Inspect the Oven:

• Check the oven carefully for damage before and regularly after installation.

• Make sure the door closes properly, that it is not misaligned or warped.

• Check the hinges and door safety latches are not broken or loose.

• Ensure the door seal and sealing surfaces are not damaged. If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

• Inspect the oven interior and door for dents.

IMPORTANT: If any damage is apparent, do not operate

the oven in any way, until it has been repaired by a SHARP trained engineer.

1. Remove all packing materials including the feature sticker (if applicable). Do not remove the plastic film from the inside of the oven window as this protects it from dirt. The waveguide cover prevents food and grease from entering the waveguide area where it could cause damage. DO NOT REMOVE THE WAVEGUIDE COVER.

2. Place oven on a secure, level surface. Ensure it is strong enough to take the oven weight, plus the heaviest item likely to be cooked in the oven.

3. The minimum height of free space necessary above the top surface of the oven is 15cm.

4. Do not place the oven where heat, moisture or high humidity are generated, (for example, near or above a conventional oven) or near combustible materials (for example, curtains). Do not block or obstruct air vent openings. Do not place objects on top of the oven.

15cm

5. Make sure the power supply cord is undamaged (See “ELECTRICAL CONNECTION” below).

Do not allow the power supply cord to run over any hot or sharp surfaces, such as the hot air vent area at the top rear of the oven.

6. The socket must be readily accessible so that it can be easily unplugged in an emergency.

7. Do not use the oven outdoors.

BUILDING-IN-KIT.

No built-in kit is available for this oven. This oven is designed to be used on a countertop only. Do not place the oven in a cabinet.

ELECTRICAL CONNECTION.

• Do not allow water to come into contact with

the power supply cord or plug.

• Insert the plug properly into the socket.

• Do not connect other appliances to the same

socket using an adaptor plug.

• If the power supply cord is damaged, it must be

replaced by a Sharp approved service facility or a similarly qualified person to avoid a hazard.

• When removing the plug from the socket

always grip the plug, never the cord as this may damage the power supply cord and the connections inside the plug.

• If the plug fitted to your oven is a rewireable

type and in the event of the socket outlet in your home not being compatible with the plug supplied, remove the plug properly (do not cut off).

• If the plug fitted to your oven is a non-

rewirable type and in the event of the socket outlet in your home not being compatible with the plug supplied, cut-off the mains plug.

• Refit with a suitable type, observing the wiring

code given in `To replace the mains plug’ on page 37.

R-27STM-A.indd 4R-27STM-A.indd 4 7/3/09 5:31:03 PM7/3/09 5:31:03 PM

INSTALLATION

IMPORTANT!

• The fuse from the cut-off plug should be removed and the plug disposed of in a safe manner.

• Under no circumstances should the cut-off plug be inserted into a socket outlet as a serious electric shock may occur.

• The plug must not be used without the fuse cover fitted.

WARNING: THIS APPLIANCE MUST BE EARTHED

To wire an appropriate plug, follow the wiring code given in `To replace the mains plug’ on page 37.

• If you have any doubt about your microwave oven obtain the help of a qualified electrician.

• When replacing the plug please ensure that you use a BSI or ASTA approved plug to BS1363, this should be fitted with a brown coloured 13 amp fuse approved by BSI or ASTA to BS1362. If you have any doubt about electrical connection seek the help of a qualified electrician.

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

Oven Use:

• The oven is for domestic food use only.

• Never operate the oven when empty.

• Do not leave or store anything inside the oven when not in use.

• Never attempt to use the oven with the door open. It is important not to force or tamper with the door safety latches.

• Never operate the oven with any object caught in the door.

• Do not insert fingers or objects in the holes of the door latches or air-vent openings as this may damage the oven and cause an electric shock.

• If water or food drops inside the air vent openings switch off the oven immediately, unplug it and call a SHARP approved service facility. (See page 37).

• Never move the oven while it is operating.

Pacemaker: If you have a heart pacemaker, consult your doctor or the pacemaker manufacturer prior to oven use.

WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode. Microwave heating of beverages can result in delayed eruptive boiling, therefore care has to be taken when handling the container. Stir the liquid prior to and during heating/ reheating, let liquid stand for at least 20 seconds in the oven after cooking.

FIRE: If smoke is observed, switch off and unplug the appliance and keep the door closed in order to stifle any flames.

R-27STM-A.indd 5R-27STM-A.indd 5 7/3/09 5:31:03 PM7/3/09 5:31:03 PM

MAFF HEATING CATEGORY

Microwave output power in Watts (based on international (IEC

60705) standard).

Letter representing the oven heating category.

Microwave Symbol.

OVEN OUTPUT POWER

OVEN OUTPUT CATEGORY

Less heating time required

600 700 800 900 1000 Watts

More heating time required

Less heating time required

A B C D E

More heating time required

HOW YOUR OVEN WORKS

Microwaves are energy waves, similar to those used for TV and radio signals.

Electrical energy is converted into microwave energy, which is directed into the oven cavity via a waveguide. To prevent food and grease entering the wave guide it is protected by the waveguide cover.

Microwaves cannot pass through metal, because of this the oven cavity is made of metal and there is a fine metal mesh on the door. During cooking the microwaves bounce off the sides of the oven cavity at random.

The heating category (a letter A to E) developed by MAFF (Ministry of Agriculture, Fisheries and Food) with microwave oven and food manufacturers indicates the ability of the oven to heat small quantities of food (up to 500g [1lb 2oz]). It does not represent the general performance of the oven.

Food packs carry cooking instructions for heating categories A to E. Follow instructions for the letter corresponding to the oven’s heating category. The higher the output power and heating category of the oven the less heating time is required as shown opposite.

Microwaves will pass through certain materials, such as glass and plastic, to heat the food. (See “Suitable Cookware” on page 19).

Water, sugar and fat in food absorb microwaves which cause them to vibrate. This creates heat by friction, in the same way your hands get warm when you rub them together.

The outer areas of the food are heated by the microwave energy, then the heat moves to the centre by conduction, as it does in conventional cooking. It is important to turn, rearrange or stir food to ensure even heating.

Once cooking is complete, the oven automatically stops producing microwaves.

Standing time is necessary after cooking, as it enables the heat to disperse equally throughout the food.

R-27STM-A.indd 6R-27STM-A.indd 6 7/3/09 5:31:04 PM7/3/09 5:31:04 PM

BEFORE OPERATION

Your oven has an Energy Save Mode. This facility saves electricity when the oven is not in use.

To operate the oven:

1. Plug in the oven. Nothing will appear on the display at this time.

2. Open and close the door.

The display will show:

NOTES: If you do not operate the oven for 3 minutes or more (i.e. after closing the door, pressing the STOP/CLEAR key, or at the end of cooking), you will not be able to operate the oven until you open

and close the oven door. Whilst in Energy Save Mode the display is blank.

R-27STM-A.indd 7R-27STM-A.indd 7 7/3/09 5:31:04 PM7/3/09 5:31:04 PM

MICROWAVE POWER LEVELS

Press the

Power Level

HIGH x 1 100P

MEDIUM HIGH x 2 70P

MEDIUM x 3 50P

MEDIUM LOW

(Defrost)

LOW

(Defrost)

POWER

LEVEL button

x 4 30P

x 5 10P

x 6 0P

POWER LEVEL

BUTTON

Percentage

• Your oven has 6 power levels, as shown opposite.

• To change the power level for cooking, enter the cooking time and then press the POWER

LEVEL button.

Power level:

The microwave power level is varied by the microwave energy switching on and off. When using power levels other than 100P you will be able to hear the microwave energy pulsing on and off as the food cooks or defrosts.

IMPORTANT: The microwave power level will cook at 100P unless you press the POWER LEVEL button to the desired setting.

Check the power level:

To check the microwave power level during cooking, press the POWER LEVEL button. As long as your finger is pressing the POWER LEVEL button the power level will be displayed. The oven continues to count down although the display will show the power level.

R-27STM-A.indd 8R-27STM-A.indd 8 7/25/09 10:29:47 AM7/25/09 10:29:47 AM

HOW TO OPERATE YOUR OVEN

Opening and closing the door:

To open the oven door, pull the door opening handle.

Starting the oven:

Close the door and press the START/AUTO MINUTE button.

Stopping the oven:

If you want to stop the oven during cooking, press the STOP/CLEAR button once or open the oven door. If you want to cancel the cooking programme, press the STOP/CLEAR button twice.

Your oven enables you to cook and defrost food using the automatic programmes, or to cook and defrost food manually. Automatic cooking and defrosting allows you to cook and defrost using preset programmes where the timings have been calculated for you.

Manual cooking and defrosting allows you to cook/defrost foods and weights which are not included in the automatic programmes. The following are examples of manual cooking and defrosting. For automatic cooking and defrosting refer to pages 11 - 15.

Example:

To cook for 2 minutes 30 seconds on 70P microwave power.

1. Enter the cooking time by turning the

TIME/WEIGHT knob.

2. Input the power level by pressing the

POWER LEVEL button twice.

3. Press the START/AUTO MINUTE button

once to start cooking.

The display will count down

through the cooking time.

MANUAL COOKING

• Enter the cooking time and use microwave power levels 0P to 100P to cook (refer to page 8).

• Stir or turn the food, where possible, 2 - 3 times during cooking, if required.

• After cooking, cover the food and leave to stand, if required.

• Refer to the cooking charts in the cookbook section, pages 24 - 26.

SETTING THE COOKING TIME:

Your oven can be programmed for up to 90 minutes. (90.00) The input unit of cooking (defrosting) time varies from 10 seconds to 5 minutes. It depends on the total length of the cooking (defrosting) time as shown on the table.

Cooking time Increasing unit

0-5 minutes 10 seconds 5-10 minutes 30 seconds 10-30 minutes 1 minute 30-90 minutes 5 minutes

R-27STM-A.indd 9R-27STM-A.indd 9 7/25/09 10:30:28 AM7/25/09 10:30:28 AM

HOW TO OPERATE YOUR OVEN

MANUAL DEFROSTING

• Enter the defrosting time and use microwave power levels 10P or 30P to defrost (refer to page 8).

• Stir or turn the food, where possible, 2 - 3 times during defrosting.

• After defrosting, cover the food in foil and leave to stand until thoroughly defrosted.

• Refer to the defrosting chart in the cookbook section, page 23.

NOTES FOR MANUAL COOKING AND DEFROSTING:

• When the oven starts, the oven lamp will light and the turntable will rotate clockwise or anti-clockwise.

• Your oven can be programmed up to 90 minutes, (90.00).

NOTE: If you cook food for more than the

standard time (see chart on page 36) using the same cooking mode, the oven’s safety mechanisms automatically activate. The microwave power level will be reduced.

• If the door is opened during cooking/defrosting to stir or turn over food, the cooking time in the display stops automatically. The cooking/ defrosting time starts to count down again when the door is closed and the START/ AUTO MINUTE button is pressed.

• When cooking/defrosting is complete, “ . 0 ” will reappear in the display.

• If you want to know the power level during cooking, press the POWER LEVEL button. As long as your finger is touching the button, the power level will be displayed.

Example:

To defrost for 10 minutes on 30P microwave power.

1. Enter the defrosting time by turning the TIME/WEIGHT knob.

2. Input the power level by pressing the POWER LEVEL button 4 times.

3. Press the START/AUTO MINUTE button

once to start defrosting.

The display will count down through the defrosting time.

R-27STM-A.indd 10R-27STM-A.indd 10 7/3/09 5:31:04 PM7/3/09 5:31:04 PM

AUTO COOK

AUTO COOK enables you to cook foods listed on the control panel and the chart on page 12. Follow the example below for details on how to operate this function.

Example: To cook 0.3kg Rice using Auto Cook AC-2.

1. Select the menu required by pressing the AUTO COOK button twice.

2. Enter the weight by turning the TIME/WEIGTH knob until the desired weight is displayed.

3. Press the START/ AUTO MINUTE button to start cooking.

R-27STM-A.indd 11R-27STM-A.indd 11 7/3/09 5:31:04 PM7/3/09 5:31:04 PM

+ 29 hidden pages
