Sharp R-2120JW, R-2120JK Owner’s Manual
Follow by
To aid in reporting this microwave oven in case of loss or theft, please record below the model number and serial
number located on the unit. We also suggest you record all the information listed and retain for future reference.
MODELNUMBER SERIALNUMBER
DMEOFPURCHASE
DEALER TELEPHONE
SERVICER TELEPHONE
TO PHONE:
DIAL 1-800-BE-SHARP (237-4277 )for :
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your authorized parts distributor)
ADDITIONAL CUSTOMER INFORMATION
DIAL 1-800-642-2122 for :
ACCESSORIES and COOKBOOK
TO WRITE:
Sharp Electronics Corporation
Customer Assistance Center
1300 Naperville Drive
Romeoville, IL 60446-1091
TO ACCESS INTERNET: www.sharpusa.com
Please provide the following information when you write or call: model number, serial number, date of purchase,
your complete mailing address (including zip code), your daytime telephone number (including area code) and
description of the problem.
PRECAUTIONSTOAVOIDPOSSIBLE
EXPOSURETOEXCESSIVE
MICROWAVEENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. Itis important not to defeat or tamper with
the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken
or loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
For Customer Assistance .......................... 2
Reheat ...................................................... 22-23
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy ............... 2
Contents ...................................................... 3
Consumer Limited Warranty ..................... 4
Product Information Card .......................... 4
Important Safety Instructions ................... 5
Unpacking and Installation Instructions, 6-14
Unpacking and Examining Your Oven ...... 6
Installation Instructions ............................. 6-14
Optional Accessories ............................... 14
Information You Need to Know ................. 15-17
About Your Oven ...................................... 15
About Food ............................................... 15
About Utensils and Coverings .................. 16
About Children and the Microwave ........... 16
Cook ......................................................... 23-24
Popcorn .................................................... 24
Meal Time ................................................. 25
Breakfast Bar ............................................ 25-26
Lunch on the Run ..................................... 26
Dinner Delights ......................................... 27
Dinner Delights Recipes ........................... 27-28
Easy Defrost ............................................. 28-29
Keep Warm Plus ....................................... 29
Short Cuts ................................................. 30
Other Convenient Features ....................... 31-32
Custom Help ............................................. 31
Multiple Sequence Cooking ...................... 31
Demonstration Mode ................................ 32
Minute Plus ............................................... 32
About Microwave Cooking ........................ 17
About Safety ............................................. 17
Part Names ................................................. 18-19
Before Operating ........................................ 20
To Set the Clock ....................................... 20
Stop/Clear ................................................. 20
Manual Operation ....................................... 21
Time Cooking ............................................ 21
To Set Power Level .................................. 21
Using the Rack .......................................... 21
Manual Defrost .......................................... 21
Special Features ......................................... 22-30
Sensor Center ........................................... 22
Help .......................................................... 32
Timer ......................................................... 32
More or Less Time Adjustment ................. 32
Light Hi/Lo ................................................. 32
Fan Hi/Lo .................................................. 32
Cleaning and Care ...................................... 33
Replacing Parts .......................................... 34
Service Call Check ..................................... 35
Cookbook Information ............................... 35
Specifications ............................................. 36
Guia Auto-Touch ........................................ 37-38
Auto-Touch Guide ................. 39-Back Cover
CONSUMERLIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand
product (the "Product"), when shipped in its original container, will be free from defective workmanship
and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product
or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for
the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded
item(s) set forth below nor to any Product the exterior of which has been damaged or defaced, which has
been subjected to misuse, abnormal service or handling, or which has been altered or modified in design
or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth
below and provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted
to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF
MERCHANTABILITYAND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF
PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other
than those described herein, or to extend the duration of any warranties beyond the time period described
above on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be
the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the
period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of
Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims,
whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in
any way responsible, for any damages or defects in the Product which were caused by repairs or at-
tempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any
way responsible for any incident or consequential economic or property damage. Some states do not
allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE.
Your Product Model Number R-2120J and R-2130J Home Use Microwave Oven. (Be sure to have
& Description: this information available when you need service for your Product.)
Warranty Period for this Product: One (1) year parts and labor in-home service. The warranty period
continues for an additional six (6) years, for a total of seven (7)
years, with respect to the magnetron tube in the Product for parts
only. Labor and the servicer trip charge are not provided free of
charge for this additional period.
Non-functional accessories and light bulbs.Additional Item(s) Excluded from
Warranty Coverage (if any):
Where to Obtain Service:
From a Sharp Authorized Servicer located In the United States. Be
sure to have Proof of Purchase available. For in-home service,
the servicer will come to the unit's location. If it is necessary to re-
move the unit for repair, the servicer will reinstall the unit at no extra
charge, provided it was installed according to Sharp's Installation
Instructions. To find the location of the nearest Sharp Authorized
Servicer, call Sharp toll free at 1-800-BE-SHARP (1-800-237-4277).
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP OR VISIT www.sharpusa.com
SAVE THE PROOF OF PURCHASE AS IT IS NEEDED SHOULD YOUR OVEN EVER REQUIRE WARRANTY SERVICE,
The product information card should be completed within ten days of purchase and returned. It is necessary to write
the model and serial numbers, found on the nameplate in the oven cavity, on the product information card. We will
keep it on file and help you access the information in case of loss, damage or theft. This will also enable us to
contact you in the unlikely event that any adjustments or modifications are ever required for your oven.
When using electricalappliances basic safety precautionsshould be followed, includingthe following:
WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy:
1. READ ALL INSTRUCTIONS BEFORE USING
THE APPLIANCE.
2. Readandfollow thespecific "PRECAUTIONS TO
AVOID POSSIBLE EXPOSURETO EXCESSIVE
MICROWAVE ENERGY" on inside front cover.
3. This appliance must be grounded. Connect only
to properly grounded outlet. See "ELECTRICAL
GROUNDING INSTRUCTIONS" on page 7.
4. Installor locatethis appliance only in accordance
with the provided installation instructions.
5. Some products such as whole eggs and sealed
containers--for example, closed glass jars--are
able to explode and should not be heated in
this oven.
6. Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors inthis appliance. This type
of oven is specifically designed to heat, cook or
dry food. It is not designed for industrial or
laboratory use.
7. As with any appliance, close supervision is
necessary when used by children.
8. Do not operate this appliance if it has a damaged
cordor plug, if it is not working properlyor ifit has
been damaged or dropped.
9. This appliance should be serviced only by
qualified service personnel. Contact nearest
Sharp Authorized Servicer for examination,
repair or adjustment.
10. Do not cover or block any openings on the
appliance.
11. Do not store or use this appliance outdoors. Do
not use this product near water--for example,
near a kitchen sink, in a wet basement or near a
swimming pool, or similar locations.
12. Do not immerse cord or plug inwater.
13. Keep cord away from heated surfaces.
14. Do not let cordhangoveredge oftable or counter.
15. Seedoor surface cleaning instructionson page33.
16. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend
appliance when paper, plastic or other
combustible materials are placed inside the
oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic
bags before placing bag inoven.
c. If materials inside the oven should ignite,
keep oven door closed, turn oven off and
disconnectthepower cordorshut offpower
at the fuse or circuit breaker panel.
d. Donot use the cavityfor storage purposes.Do
not leave paper products,cooking utensils or
food in the cavity when not in use.
17. Liquids, such as water, coffee or tea are able to
be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or
boiling when the container is removed from the
microwave oven is not always present. THI8
COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN A SPOON
OR OTHER UTENSIL 18 INSERTED INTO THE
LIQUID.
To reduce the risk of injury to persons:
a. Do not overheat the liquid.
b. Stirthe liquidbothbeforeand halfwaythrough
heating it.
c. Do not use straight-sided containers with
narrow necks.Useawide-mouthedcontainer.
d. After heating, allow the container to stand in
the microwave oven at least for 20 seconds
before removing the container.
e. Use extreme carewhen inserting a spoon or
other utensil into the container.
18. Clean ventilation openings and grease filters
frequently--Grease should not be allowed to
accumulate on ventilation openings, louver or
grease filters.
19. Use care when cleaning the louver and the
greasefilters. Corrosive cleaningagents, such as
lye-based oven cleaners, may damage the lou-
ver and the grease filters.
20. Whenflamingfood underthe hood, turn the fanon.
21. This appliance is suitable for use above both gas
and electric cooking equipment36" wide or less.
SAVE THESE INSTRUCTIONS
UNPACKING AND EXAMINING YOUR OVEN
Open the bottom of the carton, bend the carton flaps back and tilt the oven over to
rest on plasticfoam pad. Lift carton off oven and remove all packing materials,
WALL and TOP CABINET TEMPLATES. SAVE THE CARTON AS IT MAY MAKE
INSTALLATION EASIER.
1. Remove the feature sticker from the outside of the door, if there is one.
2. Check to see that there is a WALL TEMPLATE and TOP CABINET TEMPLATE.
Read enclosures and SAVE the Operation Manual.
Check the oven for any damage, such as misaligned or bent door, damaged door
seals and sealing surfaces, broken or loose door hinges and latches and dents
inside the cavity or on the door. If there is any damage, do not operate the oven
and contact your dealer or SHARP AUTHORIZED SERVICER. See Installation
Instructions for more details.
__ Oven cavity
Safety door Door seals and
latches sealing sulfaces
INSTALLATION INSTRUCTIONS
Please read all instructions thoroughly before installing the Over the Range Microwave Oven/Hood
System. Two people are recommended to install this product.
If a new electrical outlet is required, its installation should be completed by a qualified electrician
before the Microwave Oven/Hood is installed. See 3 ELECTRICAL GROUNDING INSTRUCTIONS on
page 7.
1 MOUNTINGSPACE
This Microwave Oven/Hood requires a mounting space on
a wall as shown in Figure 1. It is designed to be used with
standard 12-inch wall cabinets.
There needs to be least 2 inches from the top of the range
backsplash to the bottom of the over the range.
If the space between the wall cabinets is 36 or 42 inches, a
Filler Panel Kit can be used to fill the gap. The metal filler
panels come in 3-inch wide pairs. One set is needed for a
36-inch opening and 2 sets for a 42-inch opening. The Filler
Panel Kit should be installed before the Microwave Oven/
Hood is installed. See page 14 for ordering informations.
Backsplash _ 1
2 WALLCONSTRUCTION
This Microwave Oven/Hood should be mounted against and supported by a fiat vertical wall. The wall must be flat
for proper installation. If the wall is not fiat, use spacers to fill in the gaps. Wall construction should be a minimum of
2" x 4" wood studding and 3/8" or more thick dry wall or plasterllath. The mounting surfaces must be capable of
supporting weight of 110 pounds--the oven and contents--AND the weight of all items which would normally be
stored in the top cabinet above the unit.
The unit should be attached to a minimum of one 2" x 4" wall stud.
To find the location of the studs, one of the following methods may be used:
A. Use a stud finder, a magnetic device which locates the nails in the stud.
B. Use a hammer to tap lightly across the mounting surface to find a solid sound. This will indicate stud location.
The center of the stud can be located by probing the wall with a small nail to find the edges of the stud and then
placing a mark halfway between the edges. The center of any adjacent studs will normally be 16" or 24" to either
side of this mark.
6
At least 2"
Figure I
30" or more from
cookingsurface
m
66" or more
from floor
/
m
|UNPACKING AND INSTALLATION INSTRUCTIONS
3 ELECTRICALGROUNDINGINSTRUCTIONS
This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding plug.
It must be plugged into a wall receptacle that is properly installed and grounded in accordance with the National
Electrical Code and local codes and ordinances. In the event of an electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the electric current.
WARNING - Improper use of the grounding plug can result in a risk of electric shock.
Electrical Requirements s-P_oo__u_
The oven is equipped with a 3-prong grounding plug. DO NOT UNDER ANY
CIRCUMSTANCES CUT OR REMOVE THE GROUNDING PIN FROM THE PLUG.
The Power Supply Cord and plug must be connected to a separate 120 Volt AC, 60
Hz, 15 Amp, or more branch circuit, single grounded receptacle. The receptacle GroundingPin
should be located inside the cabinet directly above the Microwave Oven mounting
location as shown in Figure 2. 3-ProngReceptacle/f
NOTE:
1. If you have any questions about the grounding or electrical
instructions, consult a qualified electrician or serviceperson.
Figure 2
2. Neither Sharp nor the dealer can accept any liability for
damage to the oven or personal injury resulting from failure to
observe the correct electrical connection procedures.
Ground
Receptacle
Radio or TV Interference
Should there be any interference caused by the microwave oven
to your radio or TV, check that the microwave oven is on a
different electrical circuit, relocate the radio or TV as far away from
the oven as feasible or check position and signal of
receiving antenna.
Opening for
Power Cord
Ground
Receptacle Box
4 HOODEXHAUSTDUCT
When the hood is vented to the outside, a hood exhaust duct is required. All ductwork must be metal; absolutely do
not use plastic duct. Check that all connections are made securely. Please read the following carefully:
Exhaust connection: The hood exhaust has been designed to connect to a standard 3-1/4" X 10" rectangular
duct. If round duct is required, a rectangular-to-round adapter must be used.
Rear exhaust: If a rear or horizontal exhaust is to be used, care should be taken to align the exhaust with the
space between the studs, or wall should be prepared at the time it is constructed by leaving enough space
between wall studs to accommodate exhaust.
Maximum duct length: For satisfactory air movement, the total duct length of 3-1/4" X 10" rectangular or 6"
diameter round duct should not exceed 140 feet.
Elbows, adapters, wall caps, roof caps, etc. present
additional resistance to air flow and are equivalent to a
section of straight duct which is longer than their actual
physical size. When calculating the total length, add
the equivalent lengths of all transitions and adapters
plus the length of all straight duct sections. Figure 3
shows the approximate feet of equivalent length of
some typical ductwork parts. Use the values in paren-
theses for calculating air flow resistance equivalent,
which should total less than 140 feet.
95= ELBOW (10 Fq,)
90_ ELBOW (25 FT.)
Figure 3
45= ELBOW (5 Fq,)
45_ ELBOW (5 F£)
ADAPTOR (5 FT.)
WALL CAP (40 FT.)
I 0"WIDE ELBOW (10 FT.)
ROOF CAP (24 FB_)
|UNPACKING AND INSTALLATION INSTRUCTIONS
5 TOOLSRECOMMENDEDFORINSTALLATION
• Phillips Screwdriver
• Electric Drill
• 1/2", 5/8" and 3/32" Drill Bits
• 1-1/2" Wood Bit or Metal Hole Cutter
(if metal cabinet is used)
• Saw to cut exhaust opening • Scissors
(if needed) • Pencil
• Protective Drop Cloth for product and
range - you may also use carton for
protection • Tape
• Measure
6 INSTALLATIONHARDWARE
The INSTALLATION HARDWARE items 1_ - (_) are in a small bag. Items (_) - _ are packed separately. All items
are in a small carton packed below the oven.
ITEM NAME QUANTITY PART CODE
(_ Wood Screw 5 X 30 mm 6* XTSSD50P35000
Toggle Bolt with nuts #10 - 24 X 50 mm 4** LX-BZ0195WRE0
(_ Top Cabinet Screw 5 X 60 mm 2 XBRSD50P60000
(_) Power Cord Hanger 1 LX-MZB001MRE0
(_ Tapping Screw 4 x 12 mm 8 XOTSE40P12000
(_) Flat Washer 30 mm diameter 2 XWHSD50-16300
(_ Grommet 1 LBSHC0040MRE0
_) Rear Cushion 1 PCUSUB059MRP0
(_) Exhaust Damper Assembly 1 FFTA-B005MRK0
_) Scale Plate 2 LANG-B004MRP0
@ Grease Filter 2 PFIL-B008MRE0
@ Bottom Sash 1 HDEC-B001MRF0
* Mustusetwo- mayuseremainingfour. **Maynotusealldependingon studlocation.
Figure 4
Partsshownnot to commonscale.
¢ ® @ /_, ® ® ®
® ®
®
/ °
@
[UNPACKING AND INSTALLATION INSTRUCTIONS
7 PREPARATIONOFTHEOVEN
1. Turn oven on the side. See Figure 5.
2. Follow steps (A)-(D) to remove mounting plate from the back of the oven as shown in Figure 5.
(A) Release mounting plate by pulling out the lever that is on the bottom of the oven. See Figure 6.
(B) When lever is out, pull that side of the mounting plate away from the oven. See Figure 5.
(C) Repeat step (A) on other side.
(D) Repeat step (B) on other side.
Figure 5
(A)
(B)
Use screwdriver to
assist in releasing
mountingplate.
(c)
Figure 6
(A)
MountingPlate
Bottom of
Microwave
|UNPACKING AND INSTALLATION INSTRUCTIONS
8 VENTILATIONSYSTEM(PREPARINGOVENFORINSTALLATION)
This Microwave Oven/Hood is designed for adaptation to three types of hood ventilation systems. Select the type
required for your installation.
Recirculating -- non-vented, ductless. Follow installation procedure (A). Recirculating requires the use of the
Charcoal Filter, which has already been installed in the oven.
Horizontal Exhaust -- outside ventilation. Follow installation procedure (B).
Vertical Exhaust -- outside ventilation. Follow installation procedure (C).
(A) RECIRCULATING: Non-Vented, Ductless Operation
The unit is shipped assembled for recirculating.
NOTE: 1. The Exhaust Damper Assembly (_ is not required for recirculating operation.
2. The Charcoal Filter should be replaced every 6 to 12 months, depending on use.
3. The Charcoal Filter RK-260 is also sold as an accessory. See Page 14 for ordering information.
(B) HORIZONTAL EXHAUST: OUTSIDE VENTILATION
1. Remove 2 screws from back edge and 3 screws from the top center of Fan Cover Bracket. Save 2 screws to be
used later and discard remaining 3. Remove Fan Cover Bracket by sliding it in the opposite direction of the arrow
on the Fan Cover Bracket, as shown in Figure 7.
2. Lift Hood Fan Unit carefully and slip wires out of cavity. See Figure 8. CAUTION: Do not pull or stretch hood fan
wiring.
3. Rotate the Hood Fan Unit 180 so that the fan blade openings are facing the back of the oven. See Figure 9 (A).
Replace Hood Fan Unit into the oven. Be careful not to pinch the wire and the Hood Fan Unit. See Figure 9 (B).
4. Put the wire back into the cavity. See Figure 10.
Figure 7 Figure 8
I
Figure 9 Figure 10
(A) Rotate180°
I
Save fan cover bracket for
future instructions.
10
|UNPACKING AND INSTALLATION INSTRUCTIONS
(C) VERTICAL EXHAUST: OUTSIDE VENTILATION
1. Remove and save 2 screws from back edge and 3 screws from the top center of the Fan Cover Bracket.
Remove Fan Cover Bracket by sliding it in the opposite direction of the arrow on the Fan Cover Bracket as
shown in Figure 11.
2. Lift Hood Fan Unit carefully and slip wires out of cavity. See Figure 12. CAUTION: Do not puff or stretch hood fan
wiring.
3. Rotate the Hood Fan Unit 90 so that the fan blade openings are facing the top of the oven. See Figure 13 (A).
Replace Hood Fan Unit into the oven. Be careful not to pinch the lead wire between the inner bracket and the
Hood Fan Unit. Put the lead wire into Wire Box. See Figure 13 (B).
4. Replace the Fan Cover Bracket by sliding it into the slits in the same direction as the arrow on the Fan Cover
Bracket. Make sure the fan blades are visible through the top openings in the oven before proceeding.
5. Attach the Fan Cover Bracket to unit with the 2 screws from back edge and 3 screws from the top center of the
Fan Cover Bracket, which were removed in Step 1 above. See Figure 14. The Hood Fan Unit is now rotated for
vertical exhaust operation.
6. Attach the Exhaust Damper Assembly _ to the fan cover on the top of the outercase cabinet by sliding it into
the slits in the same direction as the arrow. Use 1 Tapping Screw 4 X 12 mm <_ from the INSTALLATION
HARDWARE and tighten into place. See Figure 15.
Figure 11
Figure 12
Figure 13
(A) Rotate 90"
(B)
J
Figure 15
ExhaustDamperAssembly
11
|UNPACKING AND INSTALLATION INSTRUCTIONS
9 OVENINSTALLATION
THIS OVEN CANNOT BE PROPERLY INSTALLED WITHOUT REFERRING TO THE MOUNTING INSTRUC-
TIONS FOUND ON WALL AND TOP CABINET TEMPLATES.
THE NEXT STEP IS TO READ AND FOLLOW MOUNTING INFORMATION ON WALL AND TOP CABINET
TEMPLATES. THIS OVEN MUST BE ATTACHED TO AT LEAST ONE WALL STUD. SEE WALL CONSTRUC-
TION ON PAGE 6.
WHEN DONE WITH TEMPLATES, PROCEED TO MOUNTING SCALE PLATE SECTION.
MOUNTING SCALE PLATE
Attach 2 Scale Plates _ with tape (not included). See Figure 16 and WALL TEMPLATE for locations.
Figure 16
Scale Plates J
o o o o o o o o
MountingPlate
oooooo
o o o o o
MOUNTING PLATE
1. Separate 4 Toggle Bolts (_, packed in the INSTALLATION HARDWARE, from the Toggle Nuts.
2. Match 5/8" holes (not in studs), drilled through WALL TEMPLATE into wall to corresponding holes on Mounting
Plate.
3. Insert Toggle Bolts into matched openings on Mounting Plate. Put Toggle Nuts on Toggle Bolts. See Figure 17.
4. Position the Mounting Plate with the Toggle Bolts attached at the wall location and insert Toggle Nuts and Bolts
through the holes in the wall with the Toggle Nuts closed. Figure 18. Use Wood Screws _1_to attach the Mount-
ing Plate to studs.
NOTE: Before insertion, be sure you leave a space more than the thickness of the wall between the Mounting
Plate and the end of each of the Toggle Nuts (in the closed position). If you do not leave enough space, the
Toggle Nut will not be able to open on the other side of the wall. Also, once a Toggle Nut opens, it cannot be
withdrawn from the hole; therefore make sure all of the Toggles are in the correct position before
insertion.
5. Align the Mounting Plate carefully and hold in position while tightening Toggle Bolts. Pull Toggle Bolt toward you
and turn clockwise to tighten. Figure 19.
Figure 17
Figure 18 Figure 19
Mounti
Plate
_ pace morethan
wall thickness
Wall
12
Loading...
