Sharp PN-V550, PN-V551 User Manual
PN-V551
ENGLISH FRANÇAIS ESPAÑOL
PN-V550
LCD MONITOR
MONITEUR LCD
MONITOR LCD
ENGLISH FRANÇAIS ESPAÑOL
SETUP MANUAL
MANUEL D’INSTALLATION
MANUAL DE INSTALACIÓN
ENGLISH ...... E1
FRANÇAIS ..... F1
ESPAÑOL .... S1
IMPORTANT:
To aid reporting in case of loss or theft, please record the
product’s model and serial numbers in the space provided.
The numbers are located in the rear of the product.
Model No.:
Serial No.:
U.S.A. ONLY
ENGLISH
Contents
[ENGLISH]
IMPORTANT INFORMATION ............................................1
DEAR SHARP CUSTOMER ..............................................1
SAFETY PRECAUTIONS ..................................................2
SAFETY INSTRUCTION ...................................................3
MOUNTING PRECAUTIONS ............................................4
Supplied Components .....................................................5
Connections .....................................................................5
Read the manuals in the provided CD-ROM. (Adobe Reader is required to view the manuals.)
Turning Power On/Off ......................................................8
Specications ................................................................10
Mounting Precautions
(For SHARP dealers and service engineers) ...............10
IMPORTANT INFORMATION
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
The lightning ash with arrowhead symbol, within
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
a triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within a triangle is
intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING:
FCC Regulations state that any unauthorized changes or modications to this equipment not expressly approved by the
manufacturer could void the user’s authority to operate this equipment.
NOTE:
This equipment has been tested and found to comply with the limits for Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
U.S.A. ONLY
DEAR SHARP CUSTOMER
Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your
product, please read the Safety Precautions carefully before using this product.
1
E
SAFETY PRECAUTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can
result in electric shock and/or re. In order to prevent potential danger, please observe the following instructions when installing,
operating and cleaning the product. To ensure your safety and prolong the service life of your LCD product, please read the
following precautions carefully before using the product.
1. Read instructions — All operating instructions must be read and understood before the product is operated.
2. Keep this manual in a safe place — These safety and operating instructions must be kept in a safe place for future
reference.
3. Observe warnings — All warnings on the product and in the instructions must be observed closely.
4. Follow instructions — All operating instructions must be followed.
5. Cleaning — Unplug the power cord from the AC outlet before cleaning the product. Use a dry cloth to clean the product. Do
not use liquid cleaners or aerosol cleaners.
6. Attachments — Do not use attachments not recommended by the manufacturer. Use of inadequate attachments can result
in accidents.
7. Water and moisture — Do not use the product near water. Do not install the product in a place where water may splash onto
it. Be careful of equipment which drains water such as an air-conditioner.
8. Ventilation — The vents and other openings in the cabinet are designed for ventilation.
Do not cover or block these vents and openings since insufcient ventilation can cause overheating and/or shorten the life
of the product. Do not place the product on a sofa, rug or other similar surface, since they can block ventilation openings.
Do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
9. Power cord protection — The power cords must be routed properly to prevent people from stepping on them or objects from
resting on them.
10. The LCD panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with
impact. Be careful not to be injured by broken glass pieces in case the LCD panel breaks.
11. Overloading — Do not overload AC outlets or extension cords. Overloading can cause re or electric shock.
12. Entering of objects and liquids — Never insert an object into the product through vents or openings. High voltage ows in
the product, and inserting an object can cause electric shock and/or short internal parts.
For the same reason, do not spill water or liquid on the product.
13. Servicing — Do not attempt to service the product yourself. Removing covers can expose you to high voltage and other
dangerous conditions. Request a qualied service person to perform servicing.
14. Repair — If any of the following conditions occurs, unplug the power cord from the AC outlet, and request a qualied service
person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls
not described in the instructions can cause damage, which often requires extensive adjustment work by a qualied
technician.
e. When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product indicates that the product
needs servicing.
15. Replacement parts — In case the product needs replacement parts, make sure that the service person uses replacement
parts specied by the manufacturer, or those with the same characteristics and performance as the original parts. Use of
unauthorized parts can result in re, electric shock and/or other danger.
16. Safety checks — Upon completion of service or repair work, request the service technician to perform safety checks to
ensure that the product is in proper operating condition.
17. Wall mounting — When mounting the product on a wall, be sure to install the product according to the method
recommended by the manufacturer.
18. Heat sources — Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating
products (including ampliers).
19. Batteries — Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment,
dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below:
• Use the specied batteries only.
• Install the batteries with due attention to the plus (+) and minus (-) sides of the batteries according to the instructions in the
compartment.
• Do not mix old and new batteries.
• Do not mix batteries of different types. Voltage specications of batteries of the same shape may vary.
• Replace an exhausted battery with a new one promptly.
• If you will not use the remote control for a long time, remove the batteries.
• If leaked battery uid gets on your skin or clothing, rinse immediately and thoroughly. If it gets into your eye, bathe your
eye well rather than rubbing and seek medical treatment immediately. Leaked battery uid that gets into your eye or your
clothing may cause a skin irritation or damage your eye.
20. Usage of the monitor must not be accompanied by fatal risks or dangers that, could lead directly to death, personal injury,
severe physical damage or other loss, including nuclear reaction control in nuclear facility, medical life support system, and
missile launch control in a weapon system.
E
2
ENGLISH
SAFETY PRECAUTIONS (Continued)
21. Do not stay in contact with the parts of the product that become hot for long periods of time. Doing so may result in
low-temperature burns.
22. Do not modify this product.
WARNING:
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may
be required to take adequate measures.
To maintain compliance with EMC regulations, use shielded cables to connect to the following terminals: DVI-D output
terminal, DVI-I input terminal, PC/AV HDMI input terminal, PC/AV D-SUB input terminal, RS-232C input/output terminals, and
DisplayPort input/output terminals.
If a monitor is not positioned in a sufciently stable location, it can be potentially hazardous due to falling. Many injuries,
particularly to children, can be avoided by taking simple precautions such as:
• Using xing devices like wall mount brackets recommended by the manufacturer.
• Only using furniture that can safely support the monitor.
• Ensuring the monitor is not overhanging the edge of the supporting furniture.
• Not placing the monitor on tall furniture (for example, cupboards or bookcases) without anchoring both the furniture and the
monitor to a suitable support.
• Not standing the monitors on cloth or other materials placed between the monitor and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the monitor or its controls.
• This equipment is not suitable for use in locations where children are likely to be present unsupervised.
Especially for child safety
- Don’t allow children to climb on or play with the monitor.
- Don’t place the monitor on furniture that can easily be used as steps, such as a chest of drawers.
- Remember that children can become excited while watching a program, especially on a “larger than life” monitor. Care
should be taken to place or install the monitor where it cannot be pushed, pulled over, or knocked down.
- Care should be taken to route all cords and cables connected to the monitor so that they cannot be pulled or grabbed by
curious children.
SAFETY INSTRUCTION
- Do not use the monitor where there is a lot of dust, where
humidity is high, or where the monitor may come into contact
with oil or steam. Do not use in an environment where
there are corrosive gases (sulfur dioxide, hydrogen sulde,
nitrogen dioxide, chlorine, ammonia, ozone, etc.). As this
could lead to re.
- Ensure that the monitor does not come into contact with
water or other uids. Ensure that no objects such as paper
clips or pins enter the monitor as this could lead to re or
electric shock.
- Do not place the monitor on top of unstable objects or in
unsafe places. Do not allow the monitor to receive strong
shocks or to strongly vibrate. Causing the monitor to fall or
topple over may damage it.
- Do not use the monitor near heating equipment or in places
where there is likelihood of high temperature, as this may
lead to generation of excessive heat and outbreak of re.
- Do not use the monitor in places where it may be exposed to
direct sunlight. Risk of cabinet deformation and failure if the
monitor is used in direct sunlight.
- Please be sure to constantly remove dust and garbage that
has attached to the ventilation opening.
If dust collects in the ventilation opening, it may lead to
excessive heat, outbreak of re, or malfunction.
- As a standard, clean the inside of the monitor once every
year. If dust collects inside the monitor, it may lead to
excessive heat, outbreak of re, or malfunction. Please
request a cleaning of the inside of the monitor from an
authorized SHARP servicing dealer or service center.
- The AC outlet shall be installed near the equipment and shall
be easily accessible.
The Power Cord
- Use only the power cord supplied with the monitor.
- Do not damage the power cord nor place heavy objects on
it, stretch it or over bend it. Also, do not add extension cords.
Damage to the cord may result in re or electric shock.
- Do not use the power cord with a power tap.
Adding an extension cord may lead to re as a result of
overheating.
- Do not remove or insert the power plug with wet hands.
Doing so could result in electric shock.
- Unplug the power cord if it is not used for a long time.
- Do not attempt to repair the power cord if it is broken
or malfunctioning. Refer the servicing to the service
representative.
3
E
MOUNTING PRECAUTIONS
Cable clamp attachment
• This product is for use indoors.
• A VESA-compliant mounting bracket is required.
• Since the monitor is heavy, consult your dealer before
installing, removing or moving the monitor.
• Mounting the monitor on the wall requires special expertise
and the work must be performed by an authorized SHARP
dealer. You should never attempt to perform any of this
work yourself. Our company will bear no responsibility
for accidents or injuries caused by improper mounting or
mishandling.
• Use the monitor with the surface perpendicular to a level
surface.
• This monitor should be used at an ambient temperature
between 32°F (0°C) and 104°F (40°C).
• Be careful of high temperatures in the surrounding area.
If it is difcult to provide sufcient space for any reason
such as the installation of the monitor inside a housing, or
if the ambient temperature may be outside of the range
of 32°F (0°C) to 104°F (40°C), install a fan or take other
measures to keep the ambient temperature within the
required range.
• Temperature condition may change when using the monitor
together with the optional equipments recommended by
SHARP. In such cases, please check the temperature
condition specied by the optional equipments.
• Do not block any ventilation openings. If the temperature
inside the monitor rises, this could lead to a malfunction.
• Do not place the monitor on a device which generates heat.
• Adhere to the following when installing the monitor in its
portrait orientation. Failing to adhere to the following may
cause malfunctions.
- To install in landscape orientation, rotate the monitor 90
degrees to the right.
- Set the MONITOR on the MONITOR menu to PORTRAIT.
(See OPERATION MANUAL.)
- Be sure to clamp the power cord (supplied) onto the cable
clamp attachment using the supplied cable clamp. When
clamping the power cord, take care not to stress the
terminal of the power cord. Do not bend the power cord
excessively.
Power cord
(Supplied)
Cable clamp
• A video wall should be only be composed of identical
models. Do not use this monitor as part of a video wall that
includes another model.
E
4
ENGLISH
Supplied Components
If any component should be missing, please contact your dealer.
Liquid Crystal Display Monitor: 1
Cable clamp: 4
Cable clamp (insertion type): 2
Power cord: 1
CD-ROM (Utility Disk for Windows): 1
Setup Manual (this manual): 1
Remote control sensor box mounting hole concealing sticker: 2
* The remote control unit is supplied with the PN-ZR01A control kit (optional).
* SHARP Corporation holds authorship rights to the Utility Disk program. Do not reproduce it without permission.
* For environmental protection!
Do not dispose of batteries in household waste. Follow the disposal instructions for your area.
Connections
Caution
• Be sure to turn off the main power switch and disconnect the plug from the power outlet before connecting/disconnecting
cables. Also, read the manual of the equipment to be connected.
• Be careful not to confuse the input terminal with the output terminal when connecting cables. Accidentally reversing cables
connected to the input and output terminals may cause malfunctions and the other problems.
• Do not use any cable that has a damaged or deformed terminal. Using such cables may cause malfunctions.
• Do not forcibly bend or apply force to cables. Doing so may result in wire breakage or other damage.
1
2
3
4
5
6
7 8 9
TIPS
• Set the audio input terminal used for each input mode in AUDIO SELECT on the SETUP menu. The factory settings are
shown below.
10 11 12 15
Power cord
(Supplied)
13 14
For power outlet
1. DisplayPort input terminal
2. DisplayPort output terminal
3. DVI-I input terminal
4. DVI-D output terminal
5. Audio input terminal
6. Control kit terminal
7. PC/AV HDMI input terminal
8. PC/AV D-sub input terminal
9. Audio output terminal
10. RS-232C input terminal
11. RS-232C output terminal
12. LAN terminal
13. AC input terminal
14. Main power switch
15. Optional terminal
Input mode Audio input terminal (Factory setting)
DisplayPort DisplayPort input terminal
HDMI[PC], HDMI[AV] PC/AV HDMI input terminal
DVI-I, D-SUB[RGB],
D-SUB[COMPONENT],
D-SUB[VIDEO]
• The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks
of HDMI Licensing, LLC in the United States and other countries.
• DisplayPort is a registered trademark of Video Electronics Standards Association.
• Adobe, Acrobat, and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United
States and/or other countries.
• All other brand and product names are trademarks or registered trademarks of their respective holders.
Audio input terminal
5
E
Remote control sensor box
First monitor Second monitor
First monitor Second monitor
Connections
Multiple monitor connection
The monitors can be aligned and used as a large screen.
[Example]
(Supplied with the PN-ZR01A (optional))
Second monitor
Secondary
(Expansion unit)
ID No.: 2
Third monitor
Secondary
(Expansion unit)
ID No.: 3
* Always install the remote control sensor box on the primary
monitor.
Connection with video cable
n
Connection with DVI cable
May vary depending on the system being used.
If using the DVI-I input terminal/DVI-D output terminal, up to 5
monitors can be connected in a daisy chain.
First monitor
Primary
(Main unit)
ID No.: 1
Fourth monitor
Secondary
(Expansion unit)
ID No.: 4
Connection with DisplayPort cable
Up to 25 monitors (4 monitors when supporting HDCP) can be
connected in a daisy chain.
DisplayPort
input terminal
DisplayPort
output
terminal
DisplayPort cables
(commercially available)
To DisplayPort output terminal
shows the signal
flow
DisplayPort
input terminal
To PC digital RGB output terminal
DVI-I input
terminal
DVI-D
output
terminal
Digital signal (DVI) cables
(commercially available)
shows the signal
flow
DVI-I input
terminal
E
6
ENGLISH
First monitor: primary
Second monitor: secondary
secondary RS-232C input terminal
For the monitor in
For the monitor in
Fixing screw
Connection
Connections
Connection with RS-232 cable
n
If you connect the monitor in a daisy chain using RS-232
cables, settings are copied from the primary (main unit) to the
secondary (expansion unit) and operation from the primary
can perform operation for all monitors.
Connect the RS-232 cables in order, starting with the rst
monitor (primary monitor).
If monitors are connected in a different order they may not be
operable.
RS-232C
output
terminal
RS-232C
input
terminal
RS-232C
output terminal
Caution
• When attaching the remote control sensor box, turn the
main power switch OFF.
• Connect the monitors together in a daisy chain with RS-232
cable.
1. Peel off the sticker (
monitor’s remote control sensor box mounting hole.
2. Secure the mounting bracket by inserting the mounting
screw into the monitor’s remote control sensor box
mounting hole.
3. Adjust the angle of the remote control sensor box, and
secure it with the xing screw, so that it may accurately
receive signals from the remote control unit.
Mounting screw
Mounting bracket
) that has been afxed to the
Angle adjustment
Remote control
sensor box
Remote control sensor
box mounting hole
Connect in the same way to the third and subsequent
monitors.
Up to 25 monitors can be connected. (Depending on the
length of the cable used and the surrounding environment.)
Setting each ID No. in the monitor is required.
Perform operation with the rear side buttons on the primary
monitor. If you set AUTO ASSIGN ID No., located in the menu
of the monitor to ON, the ID No. will be automatically assigned
in order from the primary.
Mounting the control kit (optional) on the
n
monitor
If performing operation of the monitor with the remote control
unit, the PN-ZR01A control kit (optional) is required.
Attach the remote control sensor box as shown in the following
illustration.
landscape orientation
RS-232 straight cable
(commercially available)
Third monitor: connects to
portrait orientation
4. Insert the remote control sensor box connection cable into
the control kit terminal.
cable
Remote control
sensor box
Control kit terminal
Installing the batteries
1. Press the cover gently and slide it in the direction of the
arrow.
2. See the instructions in the compartment and put in the
batteries (R-6 (“AA” size) x 2) (supplied with the PN-ZR01A
(optional)) with their plus (+) and minus (-) sides oriented
correctly.
3. Close the cover.
7
E
Turning Power On/Off
Caution
• Turn on the monitor rst before turning on the PC or
playback device.
Turning on the main power
Main power switch
Caution
• The main power must be turned on/off with the main power
switch. Do not connect/disconnect the power cord or turn
the breaker on/off while the main power switch is on.
• When switching the main power switch or the POWER
button off and back on, always wait for at least 5 seconds.
• For a complete electrical disconnection, pull out the main
plug.
Turning power on/off
Press the POWER button or POWER switch to turn the power
ON/OFF.
Power LED
Status Status of the monitor
Green lit Power on
Orange lit Power off (Standby mode)
Green ashing Input signal waiting mode
E
8
ENGLISH
Turning Power On/Off
ENTER
Mode setting
n
When the monitor is turned on for the rst time after being
shipped from the factory, the mode setting screen will be
displayed.
(1)Press
(2)Press
YES:
• STANDBY MODE is set to LOW POWER.
• Compared to when set to STANDARD, the current
• While the monitor is in standby mode, control via LAN
• While the monitor is in standby mode/input signal waiting
• While the monitor is in standby mode/input signal waiting
• Depending on the input signal, the monitor may not
NO:
• STANDBY MODE is set to STANDARD.
• Compared to when set to LOW POWER, the startup/
or to select YES or NO.
ENTER
.
consumption is reduced while the monitor is in standby
mode/input signal waiting mode, but the startup/return
time from standby mode/input signal waiting mode
becomes longer.
will be disabled.
mode, only certain RS-232C commands can be used.
mode, the remote control unit cannot be used to operate
the display of the secondary unit.
switch to input signal waiting mode and may not return
from input signal waiting mode.
return time from standby mode/input signal waiting mode
is reduced, but more power will be consumed in standby
mode/input signal waiting mode.
Date/time setting
n
• If the time has yet to be set when the monitor is rst turned
on, the date/time setting screen appears. Set the date and
time.
DATE/TIME SETTING
//
01 01 15/12 AM00
OK···[ENTER] CANCEL···[RETURN]
: :
:/ 20
1. Press or to select the date and time, and
press
2. Press
• Be sure to set the date and time.
• The date/time setting screen will close automatically if
no operation is performed for about 15 seconds. The
date and time can be set using DATE/TIME SETTING
from the SETUP menu when the date/time setting screen
disappears.
TIPS
• Set the date in “Month/Day/Year” order.
• Set the time on a 12-hour basis.
• The clock is maintained by the internal battery.
• If you already set the time but the date/time setting screen
appears when the power is turned on, the internal battery
may be exhausted. Please contact an authorized SHARP
servicing dealer or service center for assistance with
battery replacement.
• Estimated service life of the internal battery: About 5 years
(depending on monitor operation)
• The initial battery was inserted at the factory when the
monitor was shipped, so it may run out of power before its
expected operation life.
or to change the numerical values.
.
9
E
Loading...
