MX-M364N MX-M464N MX-M564N
ESSENTIALS SERIES MONOCHROME DOCUMENT SYSTEMS
The new Sharp Essentials Series workgroup document systems
deliver full multifunction capability and excellent value.
The MX-M364N, MX-M464N and MX-M564N monochrome document systems offer flexible
multitasking workflow features and high quality output at speeds up to 56 pages-per-minute.
Designed for busy workgroup environments, these models combine versatile paper handling
with robust finishing options in a compact modular design that is also affordable. The new
Sharp Essentials Series can help virtually any office accomplish more in less time.
MX-M564N shown with options.
Key Features
• Standard full multifunction capability out-of-box includes copying, PCL® 6 network printing
and color network scanning for today’s demanding office environments
• High-capacity tandem paper drawer and productive inner finisher options provide high
functionality in a compact footprint
• Heightened security, including 256-bit data encryption, up to seven-times overwrite protection,
Color touch-screen display with intuitive
menu navigation.
Standard 100-sheet RSPF scans up to 56
images-per-minute.
and a convenient End-of-Lease feature that erases all user data and job history at trade-in time
Up to 6,600-sheet paper capacity with
available options.
Available compact inner finisher with 50-sheet
staple capacity.
Enhanced multifunctional capability allows you to meet tomorrow’s document needs today.
Available 500 + 2,000-sheet tandem paper
•
drawer expands maximum online paper capacity
to 6,600 sheets
Flexible paper handling system feeds up
•
to 80 lb. cover through the paper trays and
up to 110 lb. cover through the bypass tray
Supports Sharp’s enhanced security platform
•
with standard 256-bit data encryption,
up to 7 times overwrite protection, and
convenient End-of-Lease feature
Standard 100-sheet reversing single pass
•
7" (diagonally measured) color touch-screen
•
display with intuitive menu navigation
Supports the Sharp OSA® development
•
platform, enabling businesses to easily
integrate with network applications and
cloud services
Network ready PCL® 6 printing system with
•
available PostScript® 3™
Available full-size, retractable keyboard
•
allows quick and easy data entry
600 x 600 dpi printing provides clear, crisp
•
images even on jobs with fine detail
ImageSEND™ function scans documents to
•
E-mail, network folders, USB devices and more
Energy efficient design offers low power
•
consumption, fast warm-up and longer life
parts and supplies
MX-M364N/M464N/M564N SPECIFICATIONS
Main Specifications
MX-M364N/ Base models include multitasking controller, 100-sheet RSPF,
M464N/M564N PCL®6 printing system, network scanning, auto duplexing,
Type Monochrome multi-function digital document system
Display 7" (diagonally measured) color dot matrix touch panel display.
Functions Copy, print, network print, network scan, document filing and fax
Copy System Dry electrostatic transfer/Dual component developer/Magnetic
Originals Sheets and bound documents
Original Sizes 5½" x 8½", 8½" x 11", 8½" x 11" R, 8½" x 14", 11" x 17"
Copy Size Min. 5½" x 8½", Max. 11" x 17" + 12" x 18"
Copy Speed 36/46/56 ppm (8½" x 11")
Multiple Copy Max. 999 copies
First Copy Time MX-M364N MX-M464N MX-M564N
Seconds2 Platen Glass 4.5 3.9 3.7
Warm Up Time 12 seconds
Magnification 25% to 400% in 1% increments (with document feeder
Original Feed 100-sheet RSPF with original size detection
Scan Speed Copy: Up to 56 IPM2
Paper Capacity Standard: 600 Sheets/Maximum: 6,600 Sheets
Paper Feed Standard: (1) 500-sheet paper drawer (letter/legal/ledger/
System statement) and 100-sheet bypass tray (letter/legal/ledger/
Paper Weights Paper drawers: 16 lb. bond to 80 lb. cover. Other paper types
and Types include plain, pre-printed, recycled, pre-punched, letterhead and
Duplexing Standard automatic duplex copying and printing
CPU Up to 800 MHz multi-processor controller
Interface RJ-45 Ethernet (10/100/1000Base-T), USB 2.0 (2 host ports,
Memory Standard 3 GB copy/print (shared)
Hard Disk Drive 320 GB
Copy Resolution Scan: B&W/color: 600 x 600 dpi; Copy Output: 600 x 600 dpi
Copy Modes Monochrome/Grayscale
Exposure Control Modes: Automatic, Text, Text/Photo, Text/Printed-Photo,
Halftone 256 gradations/2 levels (monochrome)
Copy Features Scan-Once Print-Many, electronic sorting, offset-stacking, Auto
Account Control Up to 1,000 users. Supports user-number authentication, login
Output Tray Main output tray (top): 400 sheets (face down); optional right
Capacity side exit tray: 100 sheets (face down)
Firmware Flash ROM with local (USB), network update capability and firmware
Management update 1 to N with SRDM (Sharp Remote Device Manager)
Device Setup Web-based management/cloning with user/administrator level login
Service/Functions Remote front panel, remote access to service logs and
Accessibility Adjustment of key touch sound and speed, document feede r
Features free stop, job programs, remote front panel, universal grip for
Environmental International Energy Star Program Ver. 2.0, European RoHS
Standards
Power AC 100-127 VAC, 60 HZ, 12 Amps
Power Consumption 1.44 kW or less
Weight Approx. 145 lbs.
Dimensions Approx. 24 1/4" (w) x 28" (d) x 33 1/4" (h)
1 x 500-sheet paper drawer and a 100-sheet bypass tray.
800 x 480 dots (W-VGA).
brush development/OPC drums/Belt type fusing/white LED
exposure
2
2
25%-200%)
Scan: Up to 56 IPM
statement/envelope). Optional: single, double or triple drawer
paper deck (500 sheets each drawer), tandem paper deck
(2,500 sheets) letter/legal/ledger/statement.
color paper. Bypass tray: 16-28 lb. bond (plain paper), 13-16
lb. bond (thin paper), 80-110 lb. cover (heavy paper), 20-24
lb. bond (Monarch/Com-10 envelope), tab paper (letter). Also
label paper, gloss paper, pre-printed, recycled, pre-punched,
letterhead, color paper and OHP film.
2
front and rear), USB 2.0 (1 device port, rear)
Printed-Photo, Photo, Map, Pale-Color Document.
Settings: Auto or 9 step manual
Paper Selection (APS), Auto Magnification Selection (AMS), Auto
Tray Switching (ATS), black-white reversal, book copy, card
shot, center erase, centering, cover pages, dual page copy,
edge erase, image edit, image preview, insert pages, job build,
job programs, margin shift, mirror image, mixed size original,
multi-page enlargement, original count, pamphlet style, proof
copy, reserve copy, rotated copy, stamp, suppress background,
tab copy, tab-paper insertion, tandem copy, toner save mode,
transparency inserts, watermark, 2-in-1 / 4-in-1 multi-shot
name/password or login name/LDAP password
click counts
paper trays, and disable screen timeout
Network Printing System
PDL Standard PCL® 6, optional PostScript® 3™ compatible and
Resolution 600 x 600 dpi
Print Speed 36/46/56 pages per minute (8½" x 11")
Print Drivers Windows Server® 2003-2008, 2012, Windows XP, Windows XP
1
Features Auto configuration, bar code font printing, carbon copy
Direct Printing File Types: TIFF, JPEG, PCL, PRN, TXT, PDF, Encrypted PDF,
Resident Fonts 80 outline fonts (PCL), 136 fonts (PS)
Interface RJ-45 Ethernet 10/100/1000 Base-T, USB 2.0
Operating Systems Windows Server 2003-2012, Windows XP, Windows Vista,
Network Protocols TCP/IP (IPv4, IPv6, IPSEC) SSL (HTTP, IPP, FTP), SNMPv3, SMTP,
Printing Protocols LPR, IPP, IPPS, PAP, Raw TCP (port 9100), FTP, POP3, HTTP,
Network Security IP/MAC address filtering, protocol filtering, port management,
Security Standards IEEE-2600™-2008, DoD (NSTISSP) #111
Network Scanning System
Scan Modes Standard: Color, monochrome, grayscale
Optical Resolution 600 dpi
Output Modes 600 dpi, 400 dpi, 300 dpi, 200 dpi, 100 dpi
Image Formats Monochrome: TIFF, PDF, PDF/A, Encrypted PDF, XPS
Image Monochrome Scanning: Uncompressed, G3 (MH), G4 (MR/MMR)
Compression Color/Grayscale: JPEG (high, middle, low)
Scan Destinations E-mail, Desktop, FTP, Folder (SMB), USB, Internet fax (option),
One-touch Up to 1,000 (combined scan destinations)
Destinations
Group Destinations Up to 500
Programs 48 (combined)
Max. Jobs Up to 94
Network Protocols TCP/IP and SSL (includes HTTP, SMTP, LDAP, FTP, POP3), SMB,
Network Security E-mail server user authentication for LDAP and Active Directory
Software Sharpdesk® desktop personal document management software
B&W Super G3 Fax Kit (option)
Transmission Mode Super G3, G3
Modem Speed 33.6 KBPS
Compression JBIG, MMR, MR, MH
Scanning Method Sheet fed simplex or duplex or book
Max. Resolution 400 dpi
Transmit Speed Approx. 2 seconds with Super G3/JBIG
Auto Dialing Up to 1,000 (combined scan destinations)
Group Dial Up to 500 destinations
Inbound Fax Forwards received fax data to E-mail, FTP, SMB, Desktop, Fax,
Routing I-Fax
Long Originals Up to 33 1/4" (for transmission)
Programs 48 (combined)
Memory 1 GB
Halftone 256 levels
optional XPS
2
x64, Windows Server 2003-2008 x64, 2012 x64, Windows Vista®,
Windows Vista® x64, Windows 7, Windows 7 x64, Windows 8,
Windows 8 x64, MAC OSX (including 10.4-10.8), all MAC PPD
print, chapter inserts, color adjustment settings, color mode,
confidential print, continuous printing, different cover page/last
page/other page, document control, document filing, duplex
printing, electronic sorting, folding, form overlay, image rotation,
image type, job bypass print, job retention, layout print, margin
shift, multiple pamphlet, network tandem print, N-up printing,
offset stacking, page interleave, pamphlet style, poster print,
proof print, print mode, punching, stapling, tab paper print, tab
printing, toner save mode, transparency inserts, tray status, user
authentication, watermarks, zoom print
PostScript and XPS.1 Methods: Sharpdesk Mobile, FTP, SMB,
Web page, E-mail and USB
Windows 7, Windows 8, MAC OS X10.4, X10.5, X10.6, X10.7,
X10.8, Novell® Netware® Unix®, Linux® and Citrix® (XenApp 5.0
6.0, 6.5) and Windows Terminal Services, SAP device types.
POP3, LDAP, 802.1x for Windows and Unix. LPD and LPR for
Unix. IPX/SPX® for Novell environments. EtherTalk®. AppleTalk®
for Macintosh® environments.
1
1
and Novell Pserver/Rprinter
user authentication and document administration
Color: Grayscale, Color TIFF, JPEG, PDF, PDF/A, Encrypted PDF,
XPS; Internet Fax: TIFF-FX, TIFF-F, TIFF-S
1
1
Internet Fax mode: MH/MMR (option)
Super G3 fax (option)
ESMTP and 802.1x
(1 user license included), Sharpdesk Mobile (download)
3
4
1
1K Saddle Stitch Finisher (option)
Type Console finisher with dual exit trays (mounts on left side
Output Trays Upper tray: Offset stack tray
Output Capacity 1,000 sheets (letter/statement size) or 500 sheets
Stapling Up to 50 sheets (letter/statement size) or 25 sheets
Output Delivery Face down
Stapling Media Plain paper, letter/legal/ledger size or mixed
Stapling Positions 1 front, 1 rear, or both
Saddle Stitch Center stitch/center folding (2 staples)
Function letter/legal/ledger paper sizes
Saddle Stitch Up to 10 sets (11-15 sheets per set)/15 sets
Max. Sets (6-10 sheets per set)/20 sets (1-5 sheets per set)
Power Approx. 70 W or less
Consumption
Hole Punching Optional three-hole punch unit MX-PNX5B (MX-FN10)
Weight Approx. 88 lbs.
Dimensions MX-FN10 (with tray extended):
Inner Finisher (option)
Type Built-in type stacking finisher
Output Tray Offset stacking tray
Output Capacity 500 sheets (letter size, non-stapled)
Stapling Three position; Up to 50 sheets (letter/statement)
1
Power Approx. 50 W
Consumption
Hole Punching Optional three-hole punch unit MX-PN11B
Weight Approx. 26.5 lbs.
Dimensions (MX-FN11): Approx. 20" (w) x 25" (d) x 43" (h)
Optional Equipment
MX-DE12 Stand/1 x 500-sheet Paper Drawer
MX-DE13 Stand/2 x 500-sheet Paper Drawer
MX-DE14 Stand/3 x 500-sheet Paper Drawer
MX-DE20 Stand/500 + 2,000-sheet Tandem Paper Drawer
MX-LT10 Long Paper Feeding Tray
MX-36ABD Rolling Cabinet Base
MX-LC11 Large Capacity Tray
MX-FN17 Inner Finisher
MX-PN11B 3 Hole Punch Unit (MX-FN17)
MX-SCX1 Staple Cartridge (MX-FN17)
MX-FN10 1K Saddle Stitch Finisher
MX-RB22 Paper Pass Unit
MX-PNX5B 3 Hole Punch Unit (MX-FN10)
AR-SC3 Staple Cartridge (MX-FN10/MX-FN18)
MX-FN11 4K Stacking Finisher
MX-FN18 4K Saddle Stitch Finisher
MX-PNX6B 3 Hole Punch Unit (MX-FN11/MX-FN18)
AR-SC2 Staple Cartridge (MX-FN11/MX-FN18)
MX-TR13N Right-side Exit Tray Unit
MX-TU12 Center Exit Tray Unit
MX-PK11 PostScript 3 Expansion Kit
MX-PUX1 XPS Expansion Kit
MX-SHP2GBXPS 2 GB Memory Upgrade (Required for MX-PUX1)
MX-KB14N Retractable Keyboard
MX-FX11 Fax Expansion Kit
MX-FWX1 Internet Fax Kit
MX-PF10 Bar Code Font Kit
AR-SU1 Stamp Unit
AR-SV1 Stamp Cartridge (Requires AR-SU1 Stamp Unit)
MX-AMX1 Application Integration Module
MX-AMX2 Application Communication Module
MX-AMX3 External Accounting Module
MX-FR45U Commercial Data Security Kit
DVENDFS Generic Vendor Interface Kit
Supplies
MX-560NT Toner Cartridge
MX-560NV Developer
MX-560DR Drum
of host machine)
Lower tray: Book tray for saddle stitch
(legal, ledger, letter)
(legal, ledger or mixed)
Approx. 26" (w) x 25" (d) x 39" (h)
(Required for MX-FN10, MX-FN11 and MX-FN18)
(Requires MX-SHP2GBXPS)
(Available shortly after launch)
1
Some features require optional equipment. See your local dealer.
2
May vary depending on product configuration, machine settings
and operating and/or environmental conditions.
3
Actual transmission time will vary based on line conditions.
4
Based on Sharp Standard Test Chart with approximately 700
characters, letter size in standard resolution.
SHARP ELECTRONICS CORPORATION
1 Sharp Plaza, Suite 1
Mahwah, NJ 07495-1123
1-800-BE-SHARP • www.sharpusa.com
© 2014 Sharp Electronics Corporation. All rights reserved. Printed in U.S.A. 08/14
Design and specifications subject to change without notice. Sharp, Sharp
OSA, Sharpdesk, My Sharp, and all related trademarks are trademarks or
registered trademarks of Sharp Corporation and/or its affiliated companies.
Windows and Windows Server are trademarks or registered trademarks
of Microsoft Corporation. PostScript 3 is a trademark or registered trademark
of Adobe Systems Inc. All other trademarks are the property of their
respective owners.
Loading...
