Date: Dec.18,1998
Multifunction printer: UX3600
[Service Information]
Correction of PS PCU-PWB circuit diagram of parts
guide and service manual
1. Model Name: UX3600
2. General: Correction of PS PCU-PWB circuit diagram in parts guide and service manual
No. : MFE-004
3. Description: Correction of circuit diagram of PCU-PWB
(1) Abolishment of tinned jumper wire (J21)
(2) Change of IC protector (ICP301) from ICP-N50 (VHVCPN50//-1)to ICP-N25(VHVCPN25//-1)
(3) Addition of IC protector ICP-N38 (VHVICPN38//-1) on IC302 Pin 2 and CN304 Pin 1 side
(4) Pattern cutting between D103 and R111, and addition of micro fuse (QFS-Z7013XCZZ)
Correction of parts guide
SHARP CORPORATION Printer and Scanner Division
1/5
Orange
C
2/5
3/5
4/5
Ref.
Model
No.
name
1 UX3600
<Interchange>
1. Interchangeable. 4. Not interchangeable.
2. Current type can be used in place of new type.
New type cannot be used in place of current type.
3. Current type cannot be used in place of new type.
New type can be used in place of current type.
Parts marked with " " is important for maintaining the safety of the set. Be sure to replace these parts with specified ones
for maintaining the safety and performance of the set.
Version
P/G No.
9 -15 CPAKC7674XC01 CPAKC7674XC02 FX Packing case
3 -10 MSPRP7128XCZZ MSPRP7128XCZB AF
3 -41 MSPRC7139XCZZ
ALL
12 -98 VHI377P8-012/
12 -99 QSOCZ7004XC54 - - IC Socket
12 -101 VHVICPN50//-1
12 - - VHVICPN38//-1
12 - -
Current parts
Parts code Parts code
- LX-WZ7012XCZZ AB Washer
New parts
MSPRC7139XCZA
VHI377P8-016/
VHVICPN25//-1
QFS-Z7013XCZZ
5. Interchangeable if replaced with same types of related
parts in use.
6. Others.
Parts name
Price
rank
Original fixing
plate spring
AC A4 Sensor spring
BC PCU ROM
AD
IC Protector
AF
Micro Fuse
Effec-
tive
time
-
Inter-
change-
ability
Note
5/5
