Sharp LC-60LE830U, LC-52LE830U, LC-40LE830U, LC-46LE830U User Manual

LC-40LE830U LC-46LE830U LC-52LE830U LC-60LE830U

LIQUID CRYSTAL TELEVISION TÉLÉVISEUR ACL TELEVISOR CON PANTALLA

DE CRISTAL LÍQUIDO

OPERATION MANUAL MODE D'EMPLOI MANUAL DE OPERACIÓN

ENGLISHFRANÇAISESPAÑOL

ENGLISHFRANÇAISESPAÑOL ENGLISHFRANÇAISESPAÑOL

IMPORTANT : Please read this operation manual before starting operating the equipment.

IMPORTANT : Veuillez lire ce mode d'emploi avant de commencer à utiliser l'appareil.

IMPORTANTE : Lea este manual de operación antes de comenzar a operar el equipo.

LC-40LE830U LC-46LE830U LC-52LE830U LC-60LE830U

LIQUID CRYSTAL TELEVISION

ENGLISH

OPERATION MANUAL

IMPORTANT: To aid reporting in case of loss or theft, please record the TV's model and serial numbers in the space provided. The numbers are located at the rear of the TV.

IMPORTANT INFORMATION

Model No.:

Serial No.:

ENGLISH

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

The lightning ﬂash with arrow-head

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

CAUTION:

WARNING: FCC Regulations state that any unauthorized changes or modiﬁcations to this equipment not expressly

approved by the manufacturer could void the user's authority to operate this equipment.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product's enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

IMPORTANT INFORMATION

CAUTION:

This product satisﬁes FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for connections.

DECLARATION OF CONFORMITY:

SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-40LE830U/LC-46LE830U/LC-52LE830U/LC-60LE830U This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RESPONSIBLE PARTY:

For Business Customers: URL http://www.sharpusa.com

INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07495-1163 TEL: 1-800-BE-SHARP

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Wireless Radio

For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible. This device is going to be operated in 5.15–5.25GHz frequency range, it is restricted in indoor environment only. Important: Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device. This device and its antenna(s) must not be colocated or operation in conjunction with any other antenna or transmitter.

Wireless Radio

For product available in the USA/Canada market, only channel 1–11 can be operated. Selection of other channels is not possible. The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure. Note that this is not intended to prohibit transmission of control or signaling information or the use of repetitive codes where required by the technology. Important: Any changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

“Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the National Electrical Code that provides guidelines for proper grounding and, in particular, speciﬁes that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”

This product qualiﬁes for ENERGY STAR when "Home" is selected for "TV Location". Setting "TV Location" to "Home" allows the TV to achieve an energy-saving status for household use.

DEAR SHARP CUSTOMER

Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years of trouble-free operation of your product, please read the Important Safety Instructions carefully before using this product.

IMPORTANT SAFETY INSTRUCTIONS

Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or ﬁre. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your Liquid Crystal Television, please read the following precautions carefully before using the product.

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories speciﬁed by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Additional Safety Information

15) Power Sources—This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

16) Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of ﬁre or electric shock.

17) Object and Liquid Entry—Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a ﬁre or electric shock. Never spill liquid of any kind on the product.

18) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualiﬁed service personnel under the following conditions:

a) When the AC cord or plug is damaged, b) If liquid has been spilled, or objects have fallen into the product, c) If the product has been exposed to rain or water, d) If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment

of other controls may result in damage and will often require extensive work by a qualiﬁed technician

to restore the product to its normal operation, e) If the product has been dropped or damaged in any way, and f) When the product exhibits a distinct change in performance - this indicates a need for service.

19) Replacement Parts—When replacement parts are required, be sure the service technician has used replacement parts speciﬁed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in ﬁre, electric shock, or other hazards.

20) Safety Check—Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

21) Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product according to the method recommended by the manufacturer.

IMPORTANT SAFETY INSTRUCTIONS

• Outdoor Antenna Grounding — If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges.

Article 810 of the National Electrical Code, ANSI/NFPA 70,

provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

ANTENNA LEAD IN WIRE

ELECTRIC SERVICE EQUIPMENT

GROUND CLAMP

NEC — NATIONAL ELECTRICAL CODE

ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING

ELECTRODE SYSTEM (NEC ART 250, PART H)

• Water and Moisture — Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the manufacturer's instructions. Use only the mounting hardware recommended by the manufacturer.

• Selecting the location — Select a place with no direct sunlight and good ventilation.

• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and openings since insufﬁ cient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer's instructions are followed.

• The front panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.

• Heat — The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including ampliﬁ ers) that produce heat.

• The Liquid Crystal panel is a very high technology product with 2,073,600 pixels, giving you ﬁ ne picture details.

Occasionally, a few non-active pixels may appear on the screen as a ﬁ xed point of blue, green, red or yellow. Please note

that this does not affect the performance of your product.

• Lightning — For added protection for this television equipment during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due to lightning and power-line surges.

• Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

• To prevent ﬁ re, never place any type of candle or ﬂ ames on the top or near the TV set.

• To prevent ﬁ re or shock hazard, do not place the AC cord under the TV set or other heavy items.

• Do not display a still picture for a long time, as this could cause an afterimage to remain.

• To prevent ﬁ re or shock hazard, do not expose this product to dripping or splashing.

No objects ﬁ lled with liquids, such as vases, should be placed on the product.

• Do not insert foreign objects into the product. Inserting objects in the air vents or other openings may result in ﬁ re or electric shock. Exercise special caution when using the product around children.

Precautions when transporting the TV

• When transporting the TV, never carry it by holding or otherwise putting pressure onto the display. Be sure to always carry the TV by two people holding it with two hands — one hand on each side of the TV.

Caring for the cabinet

• Use a soft cloth (cotton, ﬂ annel, etc.) and gently wipe the surface of the cabinet.

• Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of the main unit cabinet or cause cracking.

• Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.

• If the cabinet is very dirty, wipe with a soft cloth (cotton, ﬂ annel, etc.) soaked in neutral detergent diluted with water and thoroughly wrung out, and then wipe with a soft dry cloth.

• Avoid using benzene, thinner, and other solvents, as these may deform the cabinet and cause the paint to peel off.

• Do not apply insecticides or other volatile liquids.

Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period of time. Plasticizers

inside the plastic may cause the cabinet to deform and cause the paint to peel off.

IMPORTANT SAFETY INSTRUCTIONS

Caring for the front panel

• Turn off the main power and unplug the AC cord from the wall outlet before handling.

• Gently wipe the surface of the front panel with a soft cloth (cotton, ﬂ annel, etc.).

To protect the front panel, do not use a dirty cloth, liquid cleaners, or a chemical cloth (wet/dry

sheet type cloth, etc.). This may damage the surface of the front panel.

• Wiping with a hard cloth or using strong force may scratch the surface of the front panel.

• Use a soft damp cloth to gently wipe the front panel when it is really dirty.

(It may scratch the surface of the front panel when wiped strongly.)

• If the front panel is dusty, use an anti-static brush, which is commercially available, to clean it.

• To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved cleaning cloths are

available directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800-BE-SHARP for ordering, or VISIT http://www.sharpusa.com/SharpDirect.

CHILD SAFETY:

It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

THE ISSUE

•

The home theater entertainment experience is a growing trend and larger ﬂ at panel displays are popular purchases. However, ﬂ at panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations.

•

Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and cause injury.

THIS MANUFACTURER CARES!

•

The consumer electronics industry is committed to making home entertainment enjoyable and safe.

TUNE INTO SAFETY

•

One size does NOT ﬁ t all. Follow the manufacturer’s recommendations for the safe installation and use of your ﬂ at panel display.

•

Carefully read and understand all enclosed instructions for proper use of this product.

•

Don’t allow children to climb on or play with furniture and television sets.

•

Don’t place ﬂ at panel displays on furniture that can easily be used as steps, such as a chest of drawers.

•

Remember that children can become excited while watching a program, especially on a “larger than life” ﬂ at panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down.

•

Care should be taken to route all cords and cables connected to the ﬂ at panel display so that they cannot be pulled or grabbed by curious children.

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

•

Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL).

•

Follow all instructions supplied by the display and wall mount manufacturers.

•

If you have any doubts about your ability to safely install your ﬂ at panel display, contact your retailer about professional installation.

•

Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.

•

A minimum of two people are required for installation. Flat panel displays can be heavy.

CEA is the preeminent trade association promoting growth in the $161 billion U.S.

Note:

consumer electronics industry. More than 2,200 companies enjoy the beneﬁ ts of CEA membership, including legislative advocacy, market research, technical training and education, industry promotion and the fostering of business and strategic relationships

Contents

IMPORTANT INFORMATION ..................... 1

DEAR SHARP CUSTOMER ....................... 3

IMPORTANT SAFETY INSTRUCTIONS ........ 3-5

Supplied Accessories ............................ 7

QUICK REFERENCE

Attaching the Stand ............................ 7

QUICK INSTALLATION TIPS ................... 9

Using the Remote Control Unit ................. 9

Preparation

Antennas ...................................... 10

Installing Batteries in the Remote Control Unit

Part Names

TV (Front) ..................................... 11

TV (Rear) ...................................... 11

Remote Control Unit ........................... 12

Introduction to Connections

Experiencing HD Images ...................... 13

Types of Connection .......................... 13

Displaying an External Equipment Image ....... 13

Connecting to External Equipment

Connecting a Blu-ray Disc/DVD Player or

HD Cable/Satellite Set-top Box ...........14-15

Connecting a VCR, Game Console,

Camcorder or Cable/Satellite Set-top Box .... 15

Connecting an Audio Ampliﬁ er ................. 16

Connecting an AV Ampliﬁ er .................... 16

Connecting a PC .............................. 17

Watching TV

Turning On/Off the Power ..................... 18

Initial Installation ............................18-20

Direct Button Operation

Changing Channels ....................... 21

Changing Volume .......................... 21

MUTE ...................................... 21

Sleep Timer ................................ 21

FLASHBACK ............................... 21

FREEZE .................................... 21

AV MODE .................................. 22

INPUT ...................................... 22

APPS ...................................... 22

POWER SAVING ........................... 22

Closed Captions and

Digital Closed Captions ................... 23

VIEW MODE ............................... 24

On-Screen Display Menu

On-Screen Display Menu Operation ........... 25

Menu Operation Buttons ...................... 25

Menu Items ................................... 26

Picture Settings ............................27-28

Audio Settings ................................ 29

Power Control ................................. 30

System Options ............................31-33

Initial Setup.................................34-37

Information .................................38-40

... 10

Enjoying Photo/Music/Video Playback

Connecting a USB Memory Device/

USB Hard Drive .............................. 41

Connecting a Home Network (DLNA) Server . . . 41

Select the Files to Play Back ................... 42

Playing Back Files

on a USB Memory Device .................43-47

Playing Back Files

on a Home Network (DLNA) Server .......48-49

Other Viewing Options

Presetting Remote Control Function ........... 50

Operating the Connected Equipment .......50-51

Using AQUOS LINK

Controlling HDMI Equipment

Using AQUOS LINK .......................52-54

Link Operation Menu .......................54-55

Using a PC

Displaying a PC Image on the Screen .......... 56

Adjusting the PC Image ....................... 57

Setting Audio Input ............................ 57

PC Compatibility Chart ........................ 57

Control of the TV ...........................58-59

Using the Internet

Connecting to the Internet ..................60-61

Internet Setup ..............................62-63

Displaying Updated Information and

Support Service ............................. 63

Entering Text (Software Keyboard) ............. 64

Using the Browser ..........................65-68

Using Applications via the Internet ............. 69

Appendix

Removing the Stand ........................... 71

Setting the TV on the Wall ..................... 72

Optional Accessories .......................... 72

Troubleshooting ............................ 73-74

Troubleshooting - Error Message .............. 74

Trademarks ...................................... 75

Speciﬁ cations

TV .........................................76-77

Wireless LAN .................................. 78

Information on the Software License for

This Product .................................79-80

Calling for Service ............................... 81

LIMITED WARRANTY ............................ 81

Dimensional Drawings

•

The dimensional drawings for the LCD TV set are shown on the inside back cover.

• The illustrations and on-screen displays in this operation manual are for explanation purposes and may vary slightly from the actual operations.

• The examples used throughout this manual are based on the LC-60LE830U model.

Supplied Accessories

Make sure the following accessories are provided with the product.

LC-40LE830U

LC-46LE830U LC-52LE830U

LC-60LE830U

Remote control unit

(g1)

Page 9

Operation manual (g1) ■ Connection guide (g1)

■

• Always use the AC cord supplied with the TV.

• The illustrations above are for explanation purposes and may vary slightly from the actual accessories.

“AAA” size battery

(g2)

Page 10

Cable tie

(g1)

Page 9

Stand unit

(g1)

Page 7

Stand unit

(g1)

Page 8

Stand unit

(g1)

Page 8

QUICK REFERENCE

Attaching the Stand

• Before attaching (or detaching) the stand, unplug the AC cord.

• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.

CAUTION

• Attach the stand in the correct direction.

• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.

• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.

LC-40LE830U

■

Conﬁ rm that there are 7 screws (3 long screws, 3

middle screws and 1 short screw) supplied with the stand unit.

Attach the supporting post for the stand unit onto

the base as shown below.

The supporting post attaches to the base at an off-

• centered location on the base. Be sure to attach the supporting post in the direction indicated below and attach the stand to the TV with the wider side of the base facing forward.

Forward

Long screws

Insert and tighten the 3 screws into the 3 holes on

the rear of the stand unit.

Middle screws

Insert the stand cover.

Insert the screw to secure the stand cover.

Short screw

Insert the stand into the openings on the rear of the

TV.

Soft cushion

• To detach the stand, perform the steps in reverse

order.

QUICK REFERENCE

LC-46LE830U/LC-52LE830U

■

Conﬁ rm that there are 9 screws (4 long screws, 4

middle screws and 1 short screw) supplied with the stand unit.

Attach the supporting post for the stand unit onto

the base as shown below.

The supporting post attaches to the base at an off-

• centered location on the base. Be sure to attach the supporting post in the direction indicated below and attach the stand to the TV with the wider side of the base facing forward.

Forward

Insert the stand into the openings on the rear of the

TV.

Soft cushion

Long screws

Insert and tighten the 4 screws into the 4 holes on

the rear of the stand unit.

Middle screws

Insert the stand cover.

Insert the screw to secure the stand cover.

Short screw

LC-60LE830U

■

Conﬁ rm that there are 10 screws (4 long screws, 4

middle screws and 2 short screws) supplied with the stand unit.

Attach the supporting post for the stand unit onto

the base as shown below.

The supporting post attaches to the base at an off-

• centered location on the base. Be sure to attach the supporting post in the direction indicated below and attach the stand to the TV with the wider side of the base facing forward.

Insert the stand into the openings on the rear of the

TV.

Soft cushion

Long screws

Forward

• To detach the stand, perform the steps in reverse

order.

Insert and tighten the 4 screws into the 4 holes on

the rear of the stand unit.

Middle screws

Insert the stand cover.

Insert the 2 screws to secure the stand cover.

Short screws

• To detach the stand, perform the steps in reverse

order.

QUICK REFERENCE

QUICK INSTALLATION TIPS

Attach your antenna to the back of the television.

(See page 10.) Connect the AC plug for the television into the AC

outlet.

AC outlet

• Place the TV close to the AC outlet, and keep the power plug within reach.

• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT

TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE AC CORD CONNECTED.

Bundle the cords properly with the cable tie.

Using the Remote Control Unit

Use the remote control unit by pointing it towards the remote control sensor on the TV. Objects between the remote control unit and the remote control sensor may prevent proper operation.

Remote control sensor

30º

30º 30º

30º *

17´ (5 m)

When turning on the TV for the ﬁ rst time, press

POWER on the touch sensor panel on the front of

the TV.

POWER

Insert the batteries into the remote control unit. (See

page 10.)

The angle is 20º when the stand is attached to the LC-

40LE830U/LC-46LE830U/LC-52LE830U model.

Cautions regarding the remote control unit

■

• Do not expose the remote control unit to shock. In addition, do not expose the remote control unit to liquids, and do not place in an area with high humidity.

• Do not install or place the remote control unit under direct sunlight. The heat may cause deformation of the remote control unit.

• The remote control unit may not work properly if the remote control sensor on the TV is under direct sunlight or strong lighting. In such cases, change the angle of the lighting or the TV, or operate the remote control unit closer to the remote control sensor.

IMPORTANT:

IF THE UNIT DOES NOT POWER ON - UNPLUG THE TELEVISION FROM THE OUTLET AND REPEAT THE INSTALLATION STEPS.

IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.

• Speakers cannot be detached from the TV.

• The TV can be rotated up to 20 degrees to right and left.

Preparation

Antennas

To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial cable with an F-type connector, plug it into the antenna terminal at the rear of the TV set. For connecting the antenna cable to the TV, use commercially available cables.

Connecting Antenna

Cable

• Connect the antenna cable to the TV using one of the methods in the illustration as shown (1, 2, 3 or 4).

Home Antenna

Cable without a CATV

Cable TV lead-In

converter

VHF/UHF antenna

75-ohm coaxial cable (round)

Combination VHF/

UHF antenna

Separate VHF/UHF

antenna

75-ohm coaxial cable (round)

300-ohm twin-lead cable (ﬂat)

VHF

NTENNA

UHF ANTENNA

300-ohm twin-lead cable

75-ohm coaxial cable

1. A 75-ohm system is generally a round cable with F-type connector that can easily be attached to a terminal without tools.

terminal (75-ohm)

Coaxial cable

Home Antenna terminal (75-ohm)

Coaxial cable

300/75-ohm adapter

OUT

Combiner

To TV antenna terminal

F-type connector

75-ohm coaxial cable (round)

2. A 300-ohm system is a ﬂ at “twin-lead” cable that can be attached to a 75-ohm terminal through a 300/75-ohm adapter.

300-ohm twin-lead cable (ﬂ at)

NOTICE

When connecting the RF cable to the TV set, do not tighten F-type

F-type connector should be ﬁ nger-tightened only.

F-type connector

connector with tools. If tools are used, it may cause damage to your TV set. (The breaking of internal circuit, etc.)

75-ohm coaxial cable

Installing Batteries in the Remote Control Unit

If the remote control fails to operate TV functions, replace the batteries in the remote control unit.

1 Open the battery cover.

2 Insert two “AAA” size batteries (supplied with

the product).

• Place the batteries with their terminals corresponding to the (e) and (f) indications in the battery compartment.

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.

• Do not mix batteries of different types. Different types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical leakage in old batteries.

• Remove batteries as soon as they are worn out. Chemicals that leak from batteries that come in contact with skin can cause a rash. If you ﬁ nd any chemical leakage, wipe thoroughly with a cloth.

• The batteries supplied with this product may have a shorter life expectancy due to storage conditions.

• If you will not be using the remote control unit for an extended period of time, remove batteries from it.

3 Close the battery cover.

Part Names

TV (Front)

OPC sensor *1

Remote control sensor

TV (Rear)

Center Icon illumination (See page 33.)

VOLl/

*1 OPC: Optical Picture Control (See page 27.) *2 See pages 18 and 25 for using the touch sensor panel.

CHV/

POWER *2INPUT

RS-232C terminal

USB 2

terminal

ETHERNET

terminal

Antenna/ Cable in

DIGITAL AUDIO OUTPUT terminal

AUDIO IN terminal

(shared for PC IN and HDMI 1)*2

PC IN terminal

VIDEO 2 terminals

VIDEO 1 terminals

COMPONENT

terminals

AUDIO OUT terminal

USB 1 terminal

HDMI 1 terminal

ARC: Audio Return Channel (See pages 52 and 53.)

HDMI 2 terminal

HDMI 3 terminal

HDMI 4 terminal

*1 See pages 13 to 17 and 52 for external equipment connection. *2 See page 57 for details on the Audio Select function.

Part Names

Remote Control Unit

18 19

4 5

20 21

7 8

10 11

22 23

24 25

12 13

15 16

28 29

• When using the remote control unit, point it at the TV.

1 POWER: Switch the TV power on or enter standby. (See

page 18.)

2 TV, STB, DVD•VCR, AUDIO: Switches the remote

control for TV, STB, DVD, BD, VCR and AUDIO operation. (See pages 50 to 51 for details.)

* To enter the code registration mode, you need to press

an appropriate button (STB, DVD•VCR or AUDIO) and

DISPLAY at the same time.

3 External equipment operational buttons: Operate the

external equipment.

4 OPTION: Display the Link Operation Menu screen. This

button will function only when AQUOS LINK is used. (See pages 52 to 55 for details.)

5 SLEEP: Set the sleep timer. (See page 21.) 6 0–9: Set the channel. (See page 21.) 7 • (DOT): (See pages 21 and 50.) 8 CC: Display captions from a closed-caption source. (See

page 23.)

AV MODE: Select an audio or video setting. (See page 22.)

9 10 MUTE: Mute the sound. (See page 21.) 11 VOLk/l: Set the volume. (See page 21.) 12 MENU: Display the menu screen. (See page 25.) 13 AQUOS NET: Switches the display to the TVkWeb,

Web or TV screen. (See pages 62 to 68 for details.)

14 a/b/c/d, ENTER: Select a desired item on the screen. 15 EXIT: Turn off the menu screen. 16 FAVORITE CH: Set the favorite channels. (See page 35.) 17 A, B, C, D: Select 4 preset favorite channels in 4 different

categories. (See page 35.)

While watching, you can toggle the selected channels by

pressing A, B, C and D.

18 DISPLAY: Display the channel information. 19 POWER (SOURCE): Turns the power of the external

equipment on and off.

20 FREEZE: Set the still image. Press again to return to

normal screen. (See page 21.)

21 POWER SAVING: Select Power Saving settings. (See

page 22.)

22 ENT: Jumps to a channel after selecting with the 0–9

buttons.

23 FLASHBACK: Return to the previous channel or external

input mode. (See page 21.)

24 VIEW MODE: Select the screen size. (See pages 24 and

56.)

25 INPUT: Select a TV input source. (TV, HDMI1, HDMI2,

HDMI3, HDMI4, COMPONENT, VIDEO1, VIDEO2, PC IN, Home Network (DLNA), USB) (See pages 13 and 22.)

26 CHr/s: Select the channel. (See page 21.) 27 APPS: Display the application window. (See page 22.) 28 RETURN: Return to the previous menu screen. 29 FAV APP 1, 2, 3: You can assign your favorite

applications to these buttons. (See page 35.)

Introduction to Connections

INPUT

HDMI1

HDMI2

HDMI3

INPUT

HDMI1

HDMI2

HDMI3

Experiencing HD Images

An HDTV without an HD source is just an ordinary TV. To enjoy HD images on the TV, you should get HD programming from the following:

Over-the-air broadcasting via HD quality antenna

• HD cable/satellite subscription

• HD compatible external equipment

•

For information on updating to HD programming, ask your cable/satellite service provider.

•

Types of Connection

Image quality differs depending on the terminal used. To enjoy clearer images, check the output terminals of your external equipment and use its appropriate terminals for higher quality images. For connecting the TV to external equipment, use commercially available cables.

The illustrations of the terminals are for explanation purposes and may vary slightly from the actual products.

•


Quality

Standard

Quality

Terminal on external

equipment

AUDIO

DVI OUT

Cable

HDMI-certiﬁed cable

Ø 3.5 mm stereo minijack cable

DVI-HDMI conversion cable

Component video cable

Audio cable

AV cable

Terminal

on the TV

Page 14

Page 15

Displaying an External Equipment Image

To view external source images, select the input source by pressing INPUT on the remote control unit or on the TV.

Example

INPUTINPUT

Example

Input

AIR

Press INPUT.

•

The INPUT list screen displays.

Press a/b to select the input source.

•

You can also select the input source by pressing INPUT. Each time INPUT is pressed, the input source toggles.

HDMI1 HDMI2 HDMI

•

An image from the selected source automatically

HDMI

displays.

•

If the corresponding input is not plugged in, you cannot change the input. Be sure to connect the equipment beforehand.

Connecting to External Equipment

You can connect many types of external equipment to your TV. To view external source images, select the input source from INPUT on the remote control unit or on the TV. (See pages 13 and 22.) For connecting the TV to external equipment, use commercially available cables.

CAUTION

• To protect equipment, always turn off the TV before connecting any external equipment.

• Please read the relevant operation manual (Blu-ray disc player, etc.) carefully before making connections.

Connecting a Blu-ray Disc/DVD Player or HD Cable/Satellite Set-top Box

When using HDMI cable (HDMI 1, 2, 3 or 4):

■

The HDMI (High Deﬁ nition Multimedia Interface) terminal is an audio-video interface that enables a connection for audio and video signals using a single cable. The HDMI terminal supports high-resolution video input.

• Blu-ray disc player • DVD player

• HD cable/satellite set-top box

HDMI-certiﬁed cable

HDMI OUT

Back panel vertical inputs

• To enjoy 1080p display capability, connect your external equipment using an HDMI-certiﬁ ed cable or a component cable and set the equipment to 1080p output.

• Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.

• When you connect external equipment using a DVI-HDMI conversion cable or when you connect ARC-compatible equipment, use HDMI 1.

When using DVI-HDMI conversion cable (HDMI 1):

■

Blu-ray disc player • DVD player

•

• HD cable/satellite set-top box

Back panel horizontal inputs

Ø 3.5 mm stereo minijack cable

Back panel vertical inputs

DVI-HDMI conversion cable

AUDIO DVI OUT

• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in addition to connecting a DVI-HDMI conversion cable to the HDMI 1 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO IN terminal and set "Audio Select" to "HDMI+Analog". (See page 57.)

Connecting to External Equipment

When using Component cable (COMPONENT):

■

Blu-ray disc player • DVD player

•

• HD cable/satellite set-top box

AUDIO-L (White)

AUDIO-R (Red)

Back panel surface inputs

Audio cable

Component video cable

COMPONENT OUT

• To enjoy 1080p display capability, connect your external equipment using an HDMI-certiﬁ ed cable or a component cable and set the equipment to 1080p output.

• See page 14 for connecting a Blu-ray disc player, DVD player or an HD cable/satellite set-top box to the HDMI terminal.

(Red)

Y (Green) PB (Blue)

Connecting a VCR, Game Console, Camcorder or Cable/Satellite Set-top Box

When using Composite cable (VIDEO 1 or 2):

■

Game console

•

Camcorder

•

VCR

•

• Cable/Satellite set-top box

AV cable

AUDIO-R (Red) AUDIO-L (White) VIDEO (Yellow)

Back panel surface inputs

Connecting to External Equipment

Connecting an Audio Ampliﬁ er

When using optical ﬁ ber cable:

■

It is possible to output audio through the DIGITAL AUDIO OUTPUT terminal. (See page 32 for details.) PCM audio outputs from the terminal.

OPTICAL

DIGITAL AUDIO INPUT

• Depending on the connected equipment, audio will not output from the DIGITAL AUDIO OUTPUT terminal in HDMI connection. In this case, set the audio formats of the connected equipment to PCM, 32/44.1/48 kHz. Optical digital audio will be output in 2-ch stereo when it is from the external equipment connected to the TV using an HDMI cable.

•

When using audio cable:

■

Optical ﬁber cable

Back panel horizontal inputs

Back panel vertical inputs

Audio cable

ANALOG AUDIO IN

• See page 32 for details on the Output Select function.

Connecting an AV Ampliﬁ er

HD Cable/Satellite set-top box

HDMI-certiﬁed cable

HDMI OUT

HDMIINHDMI

• If the image is not in sync with the audio, check the settings of the connected surround system.

• Letting the TV output the audio to an AV ampliﬁ er:

When you connect ARC-compatible equipment, use the HDMI 1 terminal.

If the equipment to be connected is not compatible with the ARC, connect an optical ﬁ ber cable.

OUT

Back panel vertical inputs

Connecting to External Equipment

Connecting a PC

Refer to page 57 for a list of PC signals compatible with the TV.

When using HDMI cable (HDMI 1, 2, 3 or 4):

■

HDMI-certiﬁed cable

HDMI OUT

• Depending on the board, only video signals may be output. In this case, in addition to connecting an HDMI-certiﬁ ed cable to the HDMI 1 terminal, connect a Ø 3.5 mm stereo minijack cable to the AUDIO IN terminal and set "Audio Select" to "HDMI+Analog". (See page 57.)

The HDMI terminals only support digital signal.

•

When using DVI-HDMI conversion cable (HDMI 1):

■

Ø 3.5 mm stereo minijack cable

Back panel vertical inputs

Back panel horizontal inputs

AUDIO

DVI OUT

Back panel vertical inputs

DVI-HDMI conversion cable

• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in addition to connecting a DVI-HDMI conversion cable to the HDMI 1 terminal, connect terminal and set "Audio Select" to "HDMI+Analog". (See page 57.)

When using analog RGB cable (PC IN):

■

Analog RGB cable

(D-sub 15-pin cable or VGA cable)

Ø 3.5 mm stereo minijack cable

AUDIORGB

a Ø 3.5 mm stereo minijack cable

to the AUDIO IN

Back panel surface inputs

Back panel horizontal inputs

• When using an analog RGB cable, input the audio signal to the AUDIO IN terminal of PC IN.

• When connecting a PC to the PC IN, set "Audio Select" to "Video+Audio". (See page 57.)

Watching TV

Turning On/Off the Power

POWER

POWER (On/Standby)

Press POWER on the TV or on the remote control unit to turn the power on.

• The Initial Installation starts when the TV powers on for the

ﬁ rst time. If the TV has been turned on before, the Initial Installation will not be invoked. For changing the settings of the Initial Installation, perform "EZ setup" on the Initial Setup menu on page 34.

Press POWER on the TV or on the remote control unit again to turn the power off.

• The TV enters standby and the image on the screen

disappears.

Initial Installation

When you turn on the TV for the ﬁ rst time, it will automatically memorize the broadcasting channels available in the region where you live. Perform the following steps before you press POWER on the remote control unit.

Insert the batteries into the remote control unit. (See page 10.)

2. Connect the antenna cable to the TV. (See page 10.)

3. Plug in the AC cord to the AC outlet. (See page 9.)

Language (Language setting)

Select from among 3 languages: English, French and Spanish.

Press a/b to select the desired language listed

on the screen, and then press ENTER.

Language

TV Location

Antenna & Cable/STB

Air/Cable

CH Search

Completed

TV Location

Select "Home" or "Store" for the location where you plan to install the TV. This product qualiﬁ es for ENERGY STAR in Home mode default setting.

Press c/d to select "Home" or "Store".

Press ENTER to enter the setting.

English

Français

Español

• If you are not going to use this TV for a long period of time,

be sure to remove the AC cord from the AC outlet.

• Weak electric power is still consumed even when the TV is

turned off.

Select

Home

Home: “Power Saving” is set to "Advanced", and AV

MODE is set to "STANDARD".

Store: “Power Saving” is set to "Off" and AV MODE is

set to "DYNAMIC (Fixed)". Picture Reset and Feature Demo can be set.

Picture Reset: AV MODE will be set to "DYNAMIC (Fixed)"

regardless of whether Picture Reset is "On" or "Off". If you select "On", AV MODE will be reset to "DYNAMIC (Fixed)" if there is no operation for 30 minutes. When "Off" is selected, AV MODE will be set to "DYNAMIC (Fixed)".

Feature Demo: When “On” is selected, after all the settings

are completed, the Feature Demo screen is displayed if there is no operation for several minutes.

Store

• ENERGY STAR qualiﬁ cation is based on AV MODE "STANDARD".

Watching TV

Antenna & Cable/STB

Select the type of connection you will use to watch TV.

Press

To watch TV via an antenna or cable

Select "Antenna & Cable", and then go to step 4.

To watch TV via a set-top box:

c/d

to select "Antenna & Cable" or "Set-

top box", and then press ENTER.

Antenna & Cable

Set-top box

connection (without using a set-top box):

Select "Set-top box", and then press ENTER.

To watch TV, select the input source

corresponding to the terminal connected to the set-top box. When doing so, you must make the setting to skip "TV". Press

c/d

to select

"On", and then press ENTER.

When this is set to "On", the channel on the TV

• cannot be changed using the remote control unit or menu. (e.g. CH r/s, Favorite CH, etc.) See page 32 for details on the Input Skip function.

•

Press INPUT to select the input source

Off

corresponding to the terminal connected to the set-top box. Make the necessary settings on the connected external equipment.

•

See the operation manual of the connected equipment for setting up the equipment.

Air/Cable (Antenna setting)

Make sure what kind of connection is made with your TV when selecting "Air" or "Cable".

Press

Press ENTER to enter the setting.

c/d

to select "Air" or "Cable".

CH Search (Channel search)

Channel auto search makes the TV look for all channels viewable in the set area.

When "Air" is selected in Antenna setting:

Press

When "Cable" is selected in Antenna setting:

c/d

to select "Start", and then press

ENTER.

Start

Cancel

1 Press a/b to select "Analog & Digital Search

Start" to search both analog and digital broadcasts, or to select “Analog Search Start” to search only analog broadcasts, and then press ENTER.

Analog & Digital Search Start

Analog Search Start

Cancel

The Channel search will start automatically.

• To exit the Channel search screen, select "Cancel",

• and then press ENTER.

The Channel search results may include

scrambled channels or channels that are not viewable in the set area. Press

c/d

to select

"Yes", and then press ENTER to remove scrambled channels.

Yes

Air

Cable

Watching TV

Completed

The settings conﬁ rmation screen is displayed.

Conﬁ rm the information displayed on the screen, and then press ENTER.

Examples of the settings conﬁ rmation screen

When one or more channel is received after

"Antenna & Cable" was selected in step 3 and a search was carried out.

Language : English TV Location : Home Anntena & Cable/STB : Antenna & Cable Air/Cable : Air Search Result : Digital 4ch Analog 7ch

Press the INPUT button,

then the right arrow d,

to see the list of channels found.

When no channel is received after "Antenna & Cable" was selected in step 3 and a search was carried out.

Language : English TV Location : Home Anntena & Cable/STB : Antenna & Cable Air/Cable : Cable Search Result : No channel

Channel not found.

Antenna/Cable are not properly connected

or Air/Cable setup is incorrect.

Please check your Antenna/Cable connection

and Air/Cable setup.

When "Set-top box" was selected in step 3 and a search was carried out.

Language : English TV Location : Home Anntena & Cable/STB : Set-top box TV Input Skip : On

Please make sure to change INPUT to the

speciﬁc input terminal you are connecting

your set-top box to get the picture. Closed caption, sub-channel audio

and channel selection need to be selected

with your set-top box.

•

If no channel is found, conﬁ rm the type of connection made with your TV and try "EZ Setup" again. (See page 34.)

•

For changing the settings of the Initial Installation, perform "EZ setup" on the Initial Setup menu on page 34.

•

To see the list of channels found during Channel search, press INPUT, and then press

Direct Button Operation

Changing Channels

You can change channels in several ways.

Method 1 Using CH Method 2 Using remote control buttons 0-9, • (DOT).

Method 3

Selecting the program from Channel list.

Press INPUT on the remote control unit.

Press

Press a/b to select the desired channel, and then

r/s

on the remote control unit or on the TV.

Examples: To select a 1 or 2-digit channel number (e. g., Channel 5): Press 5 ENT. To select a 3-digit channel number (e. g., Channel 115): Press 1 1 5 ENT. To select a 4-digit channel number (e. g., Channel 22.1):

Press 2 2 • (DOT) 1 ENT.

The INPUT list displays.

•

c/d

•

The Channel list displays.

to select "AIR" or "CABLE".

press ENTER.

MUTE

Mutes the current sound output. Press MUTE.

•

" " will be displayed on the screen for 30 minutes, and the sound is silenced.

•

Within 30 minutes of pressing MUTE, mute can be canceled by pressing VOLk/l or MUTE.

•

Mute will be canceled after 30 minutes have passed. However, the TV will not suddenly output a loud sound as the volume level is set to 0 automatically.

Sleep Timer

Allows you to set a time when the TV automatically switches to standby. Press SLEEP.

•

The remaining time displays when the sleep timer has been set.

•

Each time you press SLEEP, the remaining time switches as shown below.

Off 30 60 90 120

•

When set, the time automatically starts counting down.

•

If you want to adjust the sleep timer, you can press SLEEP twice then change the time setting.

•

When it is 5 minutes before the time expires, the remaining time will start to keep appearing every minute.

•

Select "Off" by pressing SLEEP to cancel the sleep timer.

•

The TV will enter standby when the remaining time reaches 0.

FLASHBACK

Press FLASHBACK to switch to the previously tuned channel.

•

Press FLASHBACK again to switch back to the currently tuned channel.

•

When selecting a 1-digit channel number, it is not necessary to press 0 before the number.

•

When you enter 0-9 only, channel selection will be made if there is no operation within a few seconds.

•

If you push "0" by itself, nothing will happen.

•

Complete the above steps within a few seconds.

•

When you enter 0-9 and • (DOT), channel selection will be made if there is no operation within a few seconds.

Changing Volume

You can change the volume by pressing VOLk/l on the TV or on the remote control unit.

•

To increase the volume, press VOLk.

•

To decrease the volume, press VOLl.

Audio status

Output device

Speaker Variable sound Mute

•

When "Output Select" is set to "Variable", the indicator on the screen changes as shown below.

Output Select

Fixed Variable

•

See page 32 for details on the Output Select function.

•

FLASHBACK will not work if no channel has been changed after the TV is turned on.

FREEZE

Allows you to capture and freeze a moving image that you are watching. Press FREEZE.

•

A moving image is captured.

•

Press FREEZE again to cancel the function.

•

When this function is not available, "No displaying still image available." will display.

•

The still image automatically goes out after 30 minutes.

•

If you are using the freeze function and a broadcast activates the V-CHIP BLOCK, the freeze function will be canceled and a V-CHIP BLOCK message will appear.

• You can have the same settings by choosing "Freeze" on the menu items. (See page 31.)

Direct Button Operation

AV MODE

AV MODE gives you several viewing options to choose from to best match the surrounding environment of the TV, which can vary due to factors like room brightness, type of program watched or the type of image input from external equipment.

Press AV MODE. Current AV MODE displays.

•

Press AV MODE again before the mode displayed on the screen disappears. The mode changes as shown below:

Example: When the input source is TV, COMPONENT, VIDEO 1 or 2

AUTO STANDARD MOVIE GAME

DYNAMIC (Fixed)

Example: When the input source is PC IN or HDMI 1 to 4

AUTO

DYNAMIC (Fixed) DYNAMIC

* "x.v.Color" can only be selected when an x.v.Color

signal is input using HDMI 1 to 4.

AUTO: Optimizes the image quality automatically based

STANDARD:

MOVIE: For a movie. GAME: Lowers image brightness for easier viewing. PC: For PC. USER: Allows the user to customize settings as desired.

x.v.Color: Supports the x.v.Color international standard

DYNAMIC: For a clear-cut image emphasizing high

DYNAMIC (Fixed): Changes the image and sound

STANDARD

on the room brightness and image signal.

lighting.

You can set the mode for each input source.

for wide color space. The x.v.Color signal allows you to experience colors that conventional color signals cannot reproduce.

contrast, useful for sports viewing.

settings to the factory preset values. No adjustments are allowed.

DYNAMIC

For a highly deﬁ ned image in a normal

USER [TV]

MOVIE

GAME

x.v.Color* USER[ ]

INPUT

To view external source images, select the input source by pressing INPUT on the remote control unit or on the TV.

Press INPUT.

The INPUT list screen displays.

•

Press a/b or press INPUT again to select the

input source.

•

An image from the selected source automatically displays.

•

Each time INPUT is pressed, the input source toggles.

•

If the corresponding input is not plugged in, you cannot change the input. Be sure to connect the equipment beforehand.

•

See pages 13 to 17 and 52 for external equipment connection.

APPS

Allows you to directly activate various types of applications.

Press APPS to display the application window.

Press a/b/c/d to select the desired application,

and then press ENTER.

If " " is displayed after you switch to USB mode, check

• the USB connection. If " " is displayed after you switch to Home Network

• (DLNA) mode or after you connect to the Internet, check your TV's network settings and connection.

• See pages 42, 62, 63 and 69 for details of viewable applications.

• You can display the application window by choosing "APPS" on the menu items. (See page 31.)

• When this function is not available, "Can not operate this function now" will display.

POWER SAVING

Allows you to set the Power Saving level in order to decrease the power consumption and increase the backlight lifespan.

Press POWER SAVING.

•

Each time you press POWER SAVING, the mode changes as shown below.

•

You can select a different AV MODE item for each input mode. (For example, select STANDARD for TV input and DYNAMIC for COMPONENT.)

•

When you play games, "GAME" is recommended for AV MODE.

•

You cannot set "GAME" or "PC" when the TV is connected to the Internet or when the input source is "Home Network (DLNA)" or "USB".

• You can have the same settings by choosing "AV MODE" on the menu items. (See page 27.)

Off

Standard

•

You can have the same settings by choosing "Power Saving" on the menu items. (See page 30.)

Advanced

Direct Button Operation

Closed Captions and Digital Closed Captions

Your TV is equipped with an internal Closed Caption decoder. It allows you to view conversations, narration and sound effects as subtitles on your TV. Closed Captions are available on some TV programs and on some VHS home video tapes at the discretion of the program provider.

Digital Closed Caption service is a new caption service available only on digital TV programs (also at the discretion of the service provider). It is a more ﬂ exible system than the original Closed Caption system, because it allows for a variety of caption sizes and font styles. When the Digital Closed Caption service is in use, it will be indicated by the appearance of a 3-letter abbreviation that also indicates the language of the Digital Closed Captions: ENG (English), SPA (Spanish), FRA (French) or other language codes.

Not all programs and VHS videotapes offer closed captions. Please look for the “N” symbol to ensure that captions will be shown.

In the Closed Caption system, there can be more than one caption service provided. Each is identiﬁ ed by its own number. The “CC1” and “CC2” services display subtitles of TV programs superimposed over the program's picture.

In the Closed Caption system, the “Text1” or “Text2” services display text that is unrelated to the program being viewed (e.g., weather or news). These services are also superimposed over the program currently being viewed.

Press CC.

•

This will present the Closed Caption information display.

Press CC while the Closed Caption information is

still on the screen.

• Press repeatedly until you select the desired closed caption service.

Air

DIGITAL

22.1

Audio : STEREO

Video 480p (4:3) CC 1/2 CC1: Ratings : NONE

: NONE

• Depending on the number of caption services in the signal being received, you will see information such as 1/2 or 1/4 displayed. 1/2 means “the ﬁ rst of two services”.

Example:

If a program has three services (Digital CC(ENG), CC1 and Text1), the closed caption display will toggle in this sequence:

1/3 ENG 2/3 CC1 3/3 Text1 Off

• The CC button keeps a record of the last service selected in its memory. If the last closed caption mode (e.g. 1/3 ENG) you selected is not available for the next program, or on another channel, the closed caption service that is available is automatically selected, and this service appears in parentheses, e.g. “1/3(CC1)”. Closed Caption services that appear in parentheses will not be stored in the CC button's memory as your last selected service. Only services that you have selected with the CC button are stored.

Examples:

In a case where there are two closed caption services provided (for instance, Digital CC(ENG) and CC1), and Digital CC(ENG) is displayed as your current selection, if Digital CC(ENG) is not broadcast for the next program, the other closed caption service, CC1, will be displayed in parentheses. A closed caption service appears in parentheses because the service you selected is not available and a different service is displayed on your screen. “1/1(CC1)” is displayed instead of “1/2/ENG”.

Closed Caption information

• When “Power Saving” is set to “Standard” or “Advanced”, the Power Saving leaf icon appears on the channel information window. See page 30 for details of Power Saving settings.

• See page 33 for detailed closed caption settings.

• When the program contains no closed caption, “--” displays in the closed caption information.

• If the language code, e.g. “ENG”, is not found on Digital TV programs, “--” will be shown.

• Four kinds of closed caption service (CC1, CC2, Text1, Text2) are potentially available, but a broadcast may contain none or only some of these services at the discretion of the program provider.

• When TV+Web or Web is displayed, Closed Captions are not available.

• You can have the same settings by choosing "Change CC" on the menu items. (See page 32.)

Direct Button Operation

VIEW MODE

For HD programs

■

Stretch Dot by Dot (Full Screen) S.Stretch (Smart stretch) Zoom

You can select the screen size.

Press VIEW MODE.

•

The View Mode menu displays.

•

The menu lists the View Mode options selectable for the type of video signal currently being received.

Press VIEW MODE or a/b while the View Mode menu is displayed to select a

desired item on the menu.

• You can sequentially select a View Mode that has its own aspect ratio.

•

You can have the same settings by choosing "View Mode" on the menu items. (See page 31.)

Suitable for viewing widescreen 1.78:1 aspect ratio program, stretch mode will still show very thin black bands at the top and bottom of the screen.

•

When using Dot by Dot or Full Screen, it is possible to see noise or bars around different outer portions of the screen. Please change view mode to correct this.

For 4:3 programs

■

Example: Screen size images

Side Bar S.Stretch (Smart stretch) Zoom Stretch

Suitable for viewing conventional 4:3 programs in their normal format.

For USB-Video, DLNA-Video or Internet applications

■

Example: Screen size images

Input signal Auto Original

Dot by Dot (1080i/p only):

Detects the resolution of the signal and displays an image with the same number of pixels on the screen. Full Screen (720p only): You can select "Full Screen" only when receiving a 720p signal.

Suitable for stretching 4:3 programs to ﬁ ll the screen.

Suitable for viewing widescreen 2.35:1 anamorphic DVDs in full screen.

Suitable for viewing widescreen 2.35:1 aspect-ratio programs in full screen.

This mode is useful for 1.78:1 DVDs. When viewing 1.85:1 DVDs, stretch mode will still show very thin black bands at the top and bottom of the screen.

Keeps the original aspect ratio in a full screen display.

Displays an image by an original size.

+ 60 hidden pages
