SERVICE MANUAL

No. S90L460LE822E

LCD COLOUR TELEVISION

LC-60LE822E

MODELS

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

LC-60LE822ERU

CONTENTS

SAFETY PRECAUTION

IMPORTANT SERVICE SAFETY

PRECAUTION.....................................................i

Precautions for using lead-free solder ...............ii

End of life disposal ............................................ iii

OUTLINE

MAJOR SERVICE PARTS ................................ iv

CHAPTER 1. SPECIFICATIONS

[1] SPECIFICATIONS ......................................... 1-1

CHAPTER 2. OPERATION MANUAL

[1] Parts Name .................................................... 2-1

CHAPTER 3. DIMENSIONS

[1] DIMENSIONS ................................................ 3-1

CHAPTER 4. REMOVING OF MAJOR PARTS

[1] REMOVING OF MAJOR PARTS ................... 4-1

[2] Caution Cleaning Glass ................................. 4-6

[3]

How to replace the Touch Sensor key PWB

......... 4-8

CHAPTER 5. TOUCH SENSOR UNIT POSITIONING FIGURE

[1] TOUCH SENSOR UNIT POSITIONING

FIGURE .........................................................5-1

CHAPTER 6. ADJUSTMENT

[1] ADJUSTMENT PROCEDURE ......................6-1

CHAPTER 7. TROUBLESHOOTING TABLE

[1] TROUBLESHOOTING TABLE ......................7-1

[2] LED flashing specification at the time of the

error .............................................................7-14

CHAPTER 8. MAJOR IC INFORMATIONS

[1] MAJOR IC INFORMATIONS .........................8-1

CHAPTER 9. OVERALL WIRING/BLOCK DIAGRAM

[1] OVERALL WIRING DIAGRAM ......................9-1

[2] SYSTEM BLOCK DIAGRAM .........................9-2

Parts Guide

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.

This document has been published to be used for after sales service only. The contents are subject to change without notice.

LC-60LE822E/LC-60LE822ERU

LC-60LE822E

SAFETY PRECAUTION

Service Manual

IMPORTANT SERVICE SAFETY PRECAUTION

Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow:

 WARNING

1. For continued safety, no modification of any circuit should be attempted.

2. Disconnect AC power before servicing.

CAUTION:

FOR CONTINUED PROTECTION AGAINST A RISK OF FIRE REPLACE ONLY WITH SAME TYPE FUSE.

• Use an AC voltmeter having with 5000 ohm per volt, or higher, sensitivity or measure the AC voltage drop across the resistor.

• Connect the resistor connection to all exposed metal parts having a return to the chassis (antenna, metal cabinet, screw heads, knobs and control shafts, escutcheon, etc.) and measure the AC voltage drop across the resistor. All checks must be repeated with the AC cord plug connection reversed. (If necessary, a nonpolarized adaptor plug must be used only for the purpose of completing these checks.) Any reading of 1.05 V peak (this corresponds to 0.7 mA peak AC.) or more is excessive and indicates a potential shock hazard which must be corrected before returning the monitor to the owner.

F7000, F7001 (5A/250V)

DVM

 BEFORE RETURNING THE RECEIVER (Fire & Shock Hazard)

Before returning the receiver to the user, perform the following safety checks:

3. Inspect all lead dress to make certain that leads are not pinched, and check that hardware is not lodged between the chassis and other metal parts in the receiver.

4. Inspect all protective devices such as non-metallic control knobs, insulation materials, cabinet backs, adjustment and compartment covers or shields, isolation resistor-capacitor networks, mechanical insulators, etc.

5. To be sure that no shock hazard exists, check for leakage current in the following manner.

• Plug the AC cord directly into a 220~240 volt AC outlet.

• Using two clip leads, connect a 1.5k ohm, 10 watt resistor paralleled by a 0.15µF capacitor in series with all exposed metal cabinet parts and a known earth ground, such as electrical conduit or electrical ground connected to an earth ground.

///////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////

TO EXPOSED METAL PARTS

SAFETY NOTICE

Many electrical and mechanical parts in LCD color television have special safety-related characteristics.

These characteristics are often not evident from visual inspection, nor can protection afforded by them be necessarily increased by using replacement components rated for higher voltage, wattage, etc.

Replacement parts which have these special safety characteristics are identified in this manual; electrical components having such features

are identified by “ ” and shaded areas in the Replacement Parts List and Schematic Diagrams.

For continued protection, replacement parts must be identical to those used in the original circuit.

The use of a substitute replacement parts which do not have the same safety characteristics as the factory recommended replacement parts shown in this service manual, may create shock, fire or other hazards.

AC SCALE

1.5k ohm 10W

0.15µF

TEST PROBE

CONNECT TO KNOWN EARTH GROUND

LC-60LE822E/LC-60LE822ERU

Precautions for using lead-free solder

Employing lead-free solder

• “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

Example:

L Fa

Indicates lead-free solder of tin, silver and copper.

L F a/a

Using lead-free wire solder

• When fixing the PWB soldered with the lead-free solder, apply lead-free wire solder. Repairing with conventional lead wire solder may cause damage or accident due to cracks.

As the melting point of lead-free solder (Sn-Ag-Cu) is higher than the lead wire solder by 40 °C, we recommend you to use a dedicated soldering bit, if you are not familiar with how to obtain lead-free wire solder or soldering bit, contact our service station or service branch in your area.

Soldering

• As the melting point of lead-free solder (Sn-Ag-Cu) is about 220 °C which is higher than the conventional lead solder by 40 °C, and as it has poor solder wettability, you may be apt to keep the soldering bit in contact with the PWB for extended period of time. However, Since the land may be peeled off or the maximum heat-resistance temperature of parts may be exceeded, remove the bit from the PWB as soon as you confirm the steady soldering condition.

Lead-free solder contains more tin, and the end of the soldering bit may be easily corroded. Make sure to turn on and off the power of the bit as required.

If a different type of solder stays on the tip of the soldering bit, it is alloyed with lead-free solder. Clean the bit after every use of it.

When the tip of the soldering bit is blackened during use, file it with steel wool or fine sandpaper.

• Be careful when replacing parts with polarity indication on the PWB silk.

Lead-free wire solder for servicing

Part No. Description Code

ZHNDAi123250E J φ0.3mm 250g (1roll) BL ZHNDAi126500E J φ0.6mm 500g (1roll) BK ZHNDAi12801KE J φ1.0mm 1kg (1roll) BM

LC-60LE822E/LC-60LE822ERU

End of life disposal

iii

LC-60LE822E/LC-60LE822ERU

LC-60LE822E

OUTLINE

Service Manual

MAJOR SERVICE PARTS

PWB UNIT

Ref No. Parts Code Description

N DKEYDF455FM07 MAIN Unit (*1) N DUNTKF494FM02 R/C, LED Unit N DUNTKF493FM03 ICON Unit N DUNTKF493FM04 LOGO Unit N RUNTKA761WJQZ TOUCH SENSOR Key Unit(*2) N RUNTKA729WJQZ POWER/LED CONTROL Unit N RUNTK4512TPZA LCD CONTROL Unit

NOTE: (*1) Replace MAIN Unit (DKEYDF455FM07) in case of IC8401 or IC3302 failure.

(*2) TOUCH SENSOR Key Unit (RUNTKA761WJQZ) reuse will be impossible, once it is stuck on front cabinet and exfoliates.

Therefore, please exchange of a TOUCH SENSOR Key Unit in the case of front cabinet exchange.

OTHER UNIT

Ref No. Parts Code Description

N R1LK600D3LW20Z 60" LCD Panel Module Unit

IC FOR EXCLUSIVE USE OF THE SERVICE

Ref No. Parts Code Description Q’ty

IC501 RH-iXD108WJQZS IC 24LC21AT-I/SN 1 IC2002 RH-iXC786WJNJQ IC R5F364A6NFB 1

SERVICE JIGS

Ref No. Parts Code Description Q’ty

N QCNW-G616WJQZ Main Unit to LCD Control Unit (LW) 1 N QCNW-G625WJQZ Main Unit to Power Unit (PL) 1 N QCNW-H184WJQZ Main Unit to Power Unit (PD) 1 N QCNW-H185WJQZ Main Unit to Power (LED Drive) Unit (LB) 1 N QCNW-K594WJQZ Main Unit to R/C, LED Unit (RA) 1 N QCNW-K595WJQZ Main Unit to Speaker (SP) 1 N QCNW-K596WJQZ Main Unit to Icon Unit (RL) 1 N QCNW-K597WJQZ Main Unit to Woofer (SB) 1

LC-60LE822E/LC-60LE822ERU

LC-60LE822E

CHAPTER 1. SPECIFICATIONS

[1] SPECIFICATIONS

Service Manual

Item

LCD panel

LCD COLOUR TV (60"/152 cm), LC-60LE822E, LC-60LE822ERU

152 cm (60") X-Gen panel

Resolution 1,920 x 1,080 x 4 dots

Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60

TV function TV-standard Analogue CCIR (B/G, I, D/K, L/L’)

Digital DVB-T (2K/8K OFDM), DVB-C, DVB-S/S2

Receiving channel

VHF/UHF

CATV

Satellite

IR A ch_E69 ch (Digital), E2_E69 ch, F2_F10 ch, I21_I69 ch, IR A_IR J ch

Hyper-band, S1_S41 ch

950_2150 MHz*

TV-tuning system Auto Preset 999 ch (non-Nordic [DTV]), Auto Preset 9999 ch (Nordic [DTV]),

Auto Preset 99 ch (ATV), Auto Label, Auto Sort, Auto Preset 9999 ch (SAT)

STEREO/BILINGUAL NICAM/A2

Audio amplifier 10 W x 2/15 W x 1

Speaker (234 mm x 22 mm) x 2/Ø 110 mm

Terminals Antenna

UHF/VHF 75 Ω Din type (analogue & digital), Satellite 75 Ω F type (DVB-S/S2)

RS-232C D-Sub 9 pin male connector

EXT 1 SCART (AV input, Y/C input, RGB input, TV output)

EXT 2 RCA pin (AV input/AUDIO L/R)

EXT 3 15 pin mini D-sub

HDMI 1 (EXT 4) HDMI (ARC)

HDMI 2 (EXT 5) HDMI

HDMI 3 (EXT 6) HDMI

HDMI 4 (EXT 7) HDMI

USB USB

ETHERNET (10/100) Home network connector

HDMI 2/EXT 3 AUDIO (L/R) Ø 3.5 mm jack*

DIGITAL AUDIO OUTPUT Optical S/PDIF digital audio output

C. I. (Common Interface) EN50221, R206001, CI Plus specification

OUTPUT/Headphones RCA pin (AUDIO R/L)/Ø 3.5 mm jack (audio output)

OSD language Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek,

Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian, Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian

Power requirement

Power consumption (method IEC62087) 198 W (0.2 W standby*

AC 220_240 V, 50 Hz

)

Weight 42.0 kg (without stand), 52.9 kg (with stand)

Operating temperature

The HDMI 2 and EXT 3 terminals can both use the same audio input terminal.

Standby power consumption applies when the TV is set to not receive EPG data.

The satellite channel’s frequency may vary according to satellites and antennas.

•

As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product

0°Cto+40°C

improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

1 – 1

LC-60LE822E

CHAPTER 2. OPERATION MANUAL

[1] Parts Name

TV (front view)

1 3 458672

Service Manual

1 2

3 4 5 6 7 8

LC-60LE822E/LC-60LE822ERU

VOL / (Volume buttons) CH / (Programme [channel]

buttons)

INPUT (Input source button) MENU (Menu button) POWER (Power button)

OPC sensor Remote control sensor Illumination LED

TV (rear view)

3 4 5

Antenna terminal

Satellite antenna terminal

EXT 1 (RGB) terminal

RS-232C terminal

DIGITAL AUDIO OUTPUT

terminal USB terminal

ETHERNET (10/100) terminal

OUTPUT (Headphones/AUDIO

(L/R)) terminal EXT 2 (AV IN/VIDEO/AUDIO (L/R))

terminal EXT 3 (ANALOGUE RGB (PC/

COMPONENT)) terminal HDMI 2/EXT 3 AUDIO (L/R) jack

11 12

HDMI 1 (HDMI/ARC) terminal HDMI 2 (HDMI) terminal

13 14

HDMI 3 (HDMI) terminal

HDMI 4 (HDMI) terminal

C.I. (COMMON INTERFACE) slot

MAIN POWER switch

WARNING

Excessive sound pressure from earphones and headphones can cause hearing loss. Do not set the volume at a high level. Hearing experts advise against extended listening at high volume levels.

The HDMI 2 and EXT 3 terminals can both use the same audio input terminal (HDMI 2/EXT 3 AUDIO (L/R)). However, the proper item

must be selected in the "Audio select" menu. When the MAIN POWER switch is turned off ( ), the amount of electric power consumed will be reduced to 0.01 W or less. However,

unlike when unplugging the AC cord, the power is not completely disconnected.

2 – 1

LC-60LE822E/LC-60LE822ERU

Remote control unit

TV (Standby/On)

ATV

Press to access conventional analogue TV mode.

DTV

Press to access digital TV mode.

SAT

Press to access satellite mode.

RADIO

DTV/SAT: Switch between radio and data mode.

When only data broadcasting (no radio broadcasting) is transmitted by DVB, the radio broadcasting will be skipped.

AQUOS LINK buttons

If external equipment such as a AQUOS BD player is connected via HDMI cables and is AQUOS LINK compatible, you can use these AQUOS LINK buttons.

TIME SHIFT (READY/ /

)

Press to temporarily record a programme you are watching if you want to interrupt a programme to answer a phone call, for example.

Numeric buttons 0_9

Set the channel. Enter desired numbers. Set the page in teletext mode.

When the five Nordic countries (Sweden, Norway, Finland, Denmark or Iceland) are selected in the country setting from "Auto installation", DTV services are four digits. When another country is selected, DTV services are three digits.

(Flashback)

Press to return to the previously selected channel or external input.

(Sound mode)

Select a sound multiplex mode.

(Wide mode)

Select a wide mode.

(Mute)

TV sound on/off.

114 2

8 9

+/- (Volume)

Increase/decrease TV volume.

"Menu" screen on/off.

CONTROL

Press to display the panel to operate some functions on the screen.

/// (Cursor) Select a desired item on the setting screen.

Execute a command within the "Menu" screen. ATV/DTV/SAT: Display "CH list" when no other "Menu" screen is running.

END

Exit the "Menu" screen.

17 18

20 21 22

(Display information)

Press to display the station information (channel number, signal, etc.) in the upper right corner of the screen.

P. INFO

Press to display programme information transmitted through digital video broadcasting (DTV/SAT only).

(INPUT)

Select an input source.

AV MODE

Select a video setting.

ECO (Standard/Advanced/Off)

Select "Energy save" setting.

(Teletext)

ATV: Display analogue teletext DTV/SAT: Select MHEG-5 and teletext for DTV/SAT.

Select the TV channel.

EPG

DTV/SAT: Display the EPG screen

(Return)

Return to the previous "Menu" screen.

Buttons for useful operations

(Subtitle)

Switch subtitle languages on/off.

(Reveal hidden teletext) (Subpage)

(Freeze/Hold)

Press to freeze a moving image on the screen. Teletext: Stop updating teletext pages automatically or release the hold mode.

R/G/Y/B (Colour) buttons

The coloured buttons are correspondingly used to select the coloured items on the screen (e.g., EPG, MHEG-5, teletext).

2 – 2

LC-60LE822E

CHAPTER 3. DIMENSIONS

[1] DIMENSIONS

1439.0

1334.2

913.0

975.0

LC-60LE822E/LC-60LE822ERU

Service Manual

Unit: mm

400.0

NOTE

Dimensions do not include protrusions such as screws and some parts.•

62.0

121.0

400.0

752.6

546.0

580.0

40.0 174.0

368.0

3 – 1

LC-60LE822E/LC-60LE822ERU

LC-60LE822E

CHAPTER 4. REMOVING OF MAJOR PARTS

Service Manual

[1] REMOVING OF MAJOR PARTS

1. Removing of Stand Unit and Rear Cabinet Ass’y.

1. Remove the 3 lock screw and detach the Support Cover .

2. Remove the 4 lock screws and detach the Stand Unit .

3. Remove the 1 lock screw and detach the AC Cord Cover .

4. Disconnect AC Cord .

5. Remove the 4 lock screws , 5 lock screws , 2 lock screws and 18 lock screws and detach the Rear Cabinet Ass’y.

Rear Cabinet Ass'y

AC Cord

Support Cover

6AC Cord Cover

4 – 1

4Stand Unit

2. Removing of Speaker-L/R.

1. Remove the 2 lock screws and detach the Stand Cover .

2. Disconnect SP wire.

3. Detach the Speaker-L , Speaker-R .

4. Detach the Insulation Sheet (AC)

Insulation Sheet (AC)

LC-60LE822E/LC-60LE822ERU

MAIN Unit

[SP]

4Speaker-R

3 Speaker-L

2 Stand Cover

4 – 2

LC-60LE822E/LC-60LE822ERU

3. Removing of Connectors

1. Disconnect the following connectors from the MAIN Unit. (SB, LB, PD, LW, RA, RL)

2. Disconnect the following connectors from the POWER/LED Drive Unit. (AS, L1, L2, LB, PD, PL)

3. Disconnect the following connectors from the LCD Control Unit. (LW, PL)

MAIN UnitPOWER/LED Drive Unit

[LW]

[PL]

LCD Control Unit

[AS]

POWER/LED Drive Unit

[PL]

[L1] [L2]

[LB]

[PD]

MAIN Unit

[SB]

[LB]

[PD]

[LW] [RA] [RL]

4 – 3

LC-60LE822E/LC-60LE822ERU

4. Removing of MAIN Unit, POWER/LED Drive Unit, Woofer, Stand Angle,60” LCD Panel Module Unit.

1. Remove the 6 lock screws and detach the MAIN Unit .

2. Remove the 2 lock screws and detach the Terminal Angle (Bottom) .

3. Remove the 2 lock screws and detach the Terminal Angle (Side) .

4. Remove the 6 lock screws and detach the POWER/LED Drive Unit .

5. Remove the 4 lock screws and detach the Woofer .

6. Remove the 1 lock screw and detach the LCD Angle (Bottom-R) .

7. Remove the 4 lock screws and detach the LCD Angle (Top-L) .

8. Remove the 2 lock screws and detach the LCD Angle (Top-R) .

9. Remove the 2 lock screws and detach the LCD Angle (Bottom-L) .

10.Remove the 12 lock screws and detach the 2 Stand Angle .

11.Remove the 4 lock screws and detach the 4 FIX Angle (B-MA) .

12.Remove the 2 lock screws and detach the Back Light Chassis Support Angle .

13.Remove the 9 lock screws and detach the 60” LCD Panel Module Unit .

14.Remove the 2 lock screws and detach the ECO Switch with Holder .

Woofer

(Top-L)

[SB]

ECO Switch

with Holder

(Bottom-L)

18LCD Angle

14LCD Angle

Stand Angle

POWER/LED

Drive Unit

FIX Angle (B-MA)

Stand Angle

1919

16 LCD Angle

(Top-R)

2 MAIN Unit

TERMINAL Angle (Side)

TERMINAL Angle (Bottom)

Back Light Chassis Support Angle

[L1] [L2]

60" LCD Panel Module Unit

LCD Angle (Bottom-R)

4 – 4

LC-60LE822E/LC-60LE822ERU

5. Removing of R/C, LED Unit, ICON Unit, LOGO Unit, Front Cabinet Ass’y, Glass Front Panel Ass’y, TOUCH SENSOR KEY Unit.

1. Detach the R/C, LED Unit .

2. Detach the ICON Unit .

3. Detach the LOGO Unit .

4. Remove the 25 Hooks and detach the Front Cabinet Ass’y

5. Detach the Glass Front Panel Ass’y .

6. Detach the Touch Sensor Key Unit .

NOTE: The Touch Sensor Key unit removed once is not reusable.

Front Cabinet Ass'y5

4 4

[RA]

1 RC,LED

Unit

2 ICON Unit

[R]

3 LOGO Unit

[RL]

Glass Front Panel Ass'y

[RK]

7 TOUCH SENSOR KEY Unit

4 – 5

[2] Caution Cleaning Glass

glass

cushion material

flat mat

1. Glass handling

CAUTION: (1) As for handling, wear clean gloves, protective footwear-

and mask.

LC-60LE822E/LC-60LE822ERU

(4)Have a designated place at the time of the handling.

Back side : Black print part

Front side : Protection tape part

You must not have a clear surface.

protective footwear

(2) Inner gloves are covered in the Nitrile gloves.

Inner gloves Nitrile gloves

(3) Nitrile gloves are exchanged with the following standard.

• When it touched a face and so on.

• When another work was done.

• By the work of fifty times.

• In the time for recess.

• When it became dirty.

• When it tore.

Inner gloves

Nitrile gloves

mask

(5) Two people have handling equally by the work.

(Maintain it so that glass is not warped.)

(6) When it is put horizontally, it is put on the flat mat.

glass

flat mat

(7) A cushion material is put between glass.

It doesn't touch it [the front and the front].

It can be put to two glass.

changed to new Nitrile gloves

(8) It has a module part before the CAB-B installation.

(It has a module part.)

A module isn't added. You must not have it.

4 – 6

LC-60LE822E/LC-60LE822ERU

2. Glass cleaning

CAUTION: (1) Visual inspection is done on the black mat.

black mat

(2) Dust and trash are taken with an air blow.

Air blow

glass

(3) Dirt is wiped out with cloth.

Ex.) Cotton

(4) When dirt doesn't clean, it is wiped out with Alcohol.

Alcoho

Cotton

(5) Dirt is wiped out with the Ethanol and clean cloth.

When wipe off a dirt the trace which wiped do not be left.

4 – 7

[3] How to replace the Touch Sensor key PWB

1. Replace the touch sensor key PWB in a clean room.

Be sure to remove the dust from the unit before carrying it into the clean room.

2. Remove the touch sensor key PWB from the front glass.

3. Clean the bonding surface with alcohol.

Depending on the dirt, water solution of 80%vol can be effective.

4. Product Manual Touch Sensor Key with ITO (Transparent Electrode)

LC-60LE822E/LC-60LE822ERU

FPCB/ITO connecting tape

Pull tap of double-sided tape

FPCB

ITO

Pull tap of double-sided tape

Pull tap of protective sheet

i) Remove the touch sensor key from the front glass.

* When peeling the ITO section, check that there is no glue

residue on the front glass. If glue residue, dirt, fingerprints, etc. are found, wipe them off with anhydrous alcohol. Do not apply anhydrous alcohol to the double-sided tape on the metal part attaching to the glass.

4 – 8

LC-60LE822E/LC-60LE822ERU

ii) Adhere the ITO section to the front glass. (Use the positioning jig.)

Tape fixing the FPCB and ITO sections (Adhered by the supplier)

iii) Adhere the FPCB section to the front glass.

ζ-1. Lift the FPCB section to peel the release paper of the

* Be careful not to apply stress to the joint of FPCB and ITO.

ζ-2. Adhere the FPCB section to the front glass. * Be careful not to apply stress to the joint of FPCB and ITO.

ζ-3. Peel the tape fixing the FPCB and ITO sections.

iii-1. Peel the release paper of the double-sided tape

on the ITO section.

iii-2. Slowly adhere it from the end using a roller.

(Position the touch sensor using the jig.)

* Check that there are no bubbles in the ITO section

after adhered.

* Adhering error: r1.0mm

double-sided tape.

5. Attach the touch unit bonding procedure.

It includes peeling of the protective sheet.

How to mount the touch sensor

i) Adhere after positioned using the positioning jig.

ii) Peel the protective sheet by means of the pull tap for peeling the protective sheet.

iii) Adhere the FPCB to the glass. (Do not warp the FPCB if possible.)

Pull tap for peeling the protective sheet of the double-sided tape in the FPCB section.

Glass outline

4 – 9

iv) Peel the protective sheet of the OCA.

Lift the ITO section, then peel the protective sheet by about half by means of the pull tap.

* Peeling it completely reduces workability.

Check the order due to workability.

v) Contact the FPCB and joint end of the transparent electrode film with the glass.

* Grasp the opposite end. Note that the ITO is positioned by adhering.

*Note: Do not bend the PWB (FPCB section)

and sheet (ITO section).

LC-60LE822E/LC-60LE822ERU

vi) Adhere the transparent electrode completely.

Peel the front protective sheet.

If bubbles are found, press those portions with glass cleaning cloth, etc. to remove them as much as possible.

Pull tap for peeling the front protective sheet

• Use a rubber roller since pressure exerted by it removes bubbles easily. See photo below.

• For the TOUCH SENSOR KEY Unit positioning figure, see page 5-1.

4 – 10

LC-60LE822E/LC-60LE822ERU

— MEMO —

4 – 11

LC-60LE822E

CHAPTER 5. TOUCH SENSOR UNIT POSITIONING FIGURE

[1] TOUCH SENSOR UNIT POSITIONING FIGURE

LC-60LE822E/LC-60LE822ERU

Service Manual

TOUCH SENSOR KEY Unit

5 – 1

LC-60LE822E/LC-60LE822ERU

— MEMO —

5 – 2

LC-60LE822E/LC-60LE822ERU

LC-60LE822E

CHAPTER 6. ADJUSTMENT

Service Manual

[1] ADJUSTMENT PROCEDURE

1. Adjustment method after PWB and/or IC replacement due to repair

The unit is set to the optimum at the time of shipment from the factory.

If any value should become improper or any adjustment is necessary due to the part replacement, make an adjustment according to the following procedure.

1. Procure the following units in order to replace the main unit

MAIN UNIT: DKEYDF455FM07

NOTE: [Caution when replacing ICs in the main unit (IC501, IC2002)]

The above ICs are EEPROMs storing the EDID data of PC, and Monitor microcomputer.

Before replacing the relevant part, procure the following parts in which the data have been rewritten.

IC501 RH-iXD108WJQZS PC EDID IC2002 RH-iXC786WJNJQ Monitor microcomputer

NOTE: [Caution when replacing ICs in the main unit (IC8401, IC3302)]

When replacing either IC8401 or IC3302, exchange MAIN units for DKEYDF455FM07

Each part should not be individually exchanged.

IC8401 RH-iXC147WJQZQ Flash IC3302 RH-iXC951WJN1Q Main CPU

NOTE: HDMI ROM Writing

After replacing IC1504, execute “HDMI EDID WRITE” on the page 5/21

Please execute it after checking MODEL NAME & INCH SIZE. are correct.

IF MODEL NAME & INCH SIZE. are not correct, set them previously. (Refer to 2)

The ROM data based on information of MODEL NAME & INCH SIZE

1) Enter the process adjustment mode in TV.

2) Use the cursor keys ( / ) and CH keys ( / ) of R/C to select the item [HDMI EDID WRITE] on the page 5/21.

2. After replacing the LCD panel or LCD control/MAIN UNIT.

1) Enter the process adjustment mode in TV.

2) Use the cursor keys ( / ) and CH keys ( / ) of R/C to select the item.

3) Verify that the Model name is displayed.

4) If the Model name doesn't match, select the values of the Model name with the VOL keys (+/-).

5) After selection in Step 4), press the OK key, and it is completed with OK displayed.

6) Use the cursor keys ( / ) and CH keys ( / ) of R/C to select the item.

7) Verify that the panel size is displayed.

8) If the size doesn't match, select the values of the panel size with the VOL keys (+/-).

9) After selection in Step 8), press the OK key, and it is completed with OK displayed.

3. After replacing the LCD panel or LCD control PWB, adjust the VCOM in the following procedure.

1) Enter the process adjustment mode.

2) Use the cursor keys ( / ) and CH keys ( / ) of R/C to select the item [VCOM ADJ] on the page 10/21.

3) Press the OK key to verify that the adjustment pattern is displayed.

4) Use VOL keys (+/-) of R/C to adjust the flicker in the center of the screen to minimum.

5) When the optimal state is achieved in Step 4, press the OK key to turn the pattern to OFF.

6 – 1

LC-60LE822E/LC-60LE822ERU

2. Notes of Touch sensor unit

Touch sensor unit (RUNTKA761WJQZ) is fixed directly in the module glass.

The unit cannot never be recycled when exfoliated from the module glass.

Therefore, please exchange the touch sensor units when the module glass is changed.

Please note the adhesion and mixing of dust for the module glass when the module glass and the touch sensor unit are exchanged.

Module glass

CPNLHA022WJ32

3. Method of shuts down for Power supply

Please execute the following procedures to shut down Power supply from the state of normal operation.

1) Keep touching the power supply key on the set for 5 seconds from the state of watching.

* The screen disappears when power supply key is touched, but Keep pushing the power supply key.

2) A central icon lights between 500ms when the power supply shuts down.

Please separate the finger from the power supply key when lighting of a central icon is confirmed

4. Entering and exiting the adjustment process mode

Please execute the following procedures to enter the adjustment process mode when the power supply shuts down.

1) While holding down the “VOL (-)” and “INPUT” keys on the set at once, touch the power supply key on the set.

Please separate the fingers from key on the set when boot-up is confirmed with lighting of a central icon etc.

After a while, The letter “K” appears on the screen. This state is in Inspection mode.

2) Next, hold down the “VOL (-)” and “CH ( )” keys on the set at once.

Multiple lines of blue characters appearing on the screen indicate that the set is now in the adjustment Process mode.

If you fail to enter the adjustment process mode (the display is the same as normal startup), retry the procedure.

3) To exit the adjustment process mode after the adjustment is done, unplug the AC power cord to force off the power.

(When the power is turned off with the remote controler, once unplug the AC power cord and plug it in again. In this case, wait for 10 seconds or so after unplugging.)

CAUTION: Use due care in handling the information described here lest the users should know how to enter the adjustment process mode.

If the settings are tampered with in this mode, unrecoverable system damage may result.

5. Remote controler key operation and description of display in adjustment process mode.

1. Key operation

Remote controler key Main unit key Remote controler key Main unit key Function

CH keys ( / ) CH ( / ) VOL keys (+/-) VOL (+/-) Changing a selected item setting (+1/-1) Cursor ( / )

Cursor ( / ) INPUT INPUT Input source switching (toggle switching) (TV→EXT1~9, USB) OK — Executing a function RETURN — Returning to a present page

Input mode is switched automatically when relevant adjustment is started so far as the necessary input signal is available.

— Turning a page (PREVIOUS/NEXT) — Changing a selected line setting (+10/-10)

Moving an item (line) by one (UP/DOWN)

6 – 2

6. Description of display

(1) Present page / number of total pages (4) Inducing display

(3) Present colour system

(2) Input that has been selected now (5) Inch setting and Model name display

1/21 INPUT1 AUTO EURO xxxxx

LC-60LE822E/LC-60LE822ERU

MAIN Version BOOT Version Monitor Version T-CON Version/LED CON Version CPLD Version CI+INFO/SECURE BOOT FRC-N Auto Script Version TCON Master/Slave Serial Version TOUCH SENSOR UCON VERSION LAMP ERROR MONITOR ERR CAUSE

1.00 (E 2009/**/** ) xxxxxxx xxxxxxx xxxxxxxx/xxxx xxxxxxx xxxxx/YES xxxxxxx xxxxxxx xxxxxxx 0

1)xxxxxx 2)xxxxxx

3)xxxxxx 4)xxxxxx

NORMAL STANDBY CAUSE ERROR STANDBY CAUSE

(6) Item name

No. Description Display specification

(1) Present page/number of total pages 2char/2char Decimal Number mark. (2) Input that has been selected now TUNER/DTV/INPUT1/INPUT2/INPUT3/INPUT5/INPUT6/INPUT7 (3) Present colour system AUTO/N358/N443/PAL/SECAM/480i/580i/1080i/50 etc. ⋅⋅⋅ (4) Inducing display EUROPE (5) Inch setting and Model name display Inch setting and Model name display (6) Item name Max. 30 char (7) Parameter Max. 60 char

0 0000

(7) Parameter

6 – 3

LC-60LE822E/LC-60LE822ERU

7. Adjustment process mode menu

The character string in brackets [ ] will appear as a page title in the adjustment process menu header.

Page Line Item Description Remarks (adjustment detail, etc.)

1/21

1 MAIN Version 1xxx (xxxxx) Main software version 2 BOOT Version xxxxxxx BOOT Version. 3 Monitor Version xxxxxxx Monitor software version 4 T-CON Version/LED CON Version xxxxxxxx/xxxx T-CON/H.264 Version 5 CPLD Version xxxxxxx CPLD Version. 7 CI+INFO/SECURE BOOT xxxxx/YES CI+ Key Information/SECURE BOOT 8 FRC-N Auto Script Version xxxxxxx

9 TCON Master/Slave Serial Version xxxxxxx 10 TOUCH SENSOR UCON VERSION xxxxxxx 11 LAMP ERROR 0 Number of termination due to lamp error. 12 MONITOR ERR CAUSE 1) xxxxxx 2) xxxxxx

3) xxxxxx 4) xxxxxx

13 NORMAL STANDBY CAUSE 0 Situation that became standby at the end.

14 ERROR STANDBY CAUSE 0 0 0 0 Error standby cause

2/21

1 INDUSTRY INIT Enter Initialization to factory settings execution.

2 INDUSTRY INIT (-Public) OFF Initialization to factory settings execution.

3 PUBLIC MODE OFF Public mode ON/OFF setting

4 Center Acutime — Main operating hours.

5 RESET OFF Main operating hours reset.

6 Backlight Acutime — Backlight operating hours.

7 RESET OFF Backlight operating hours reset.

8 LAMP ERROR RESET OFF Lamp error reset.

9 ADJ PARAM SET Enter ADJ PARAM SET 10 VIC XPOS 0 X-coordinate setting for VIC READ 11 VIC YPOS 0 Y-coordinate setting for VIC READ 12 VIC SIGNAL TYPE MAIN Signal type setting for VIC READ 13 VIC READ OFF Picture level acquisition function

3/21

1 TUNER ADJ Enter TUNER auto adjustment execution

2 PAL+TUNER ADJ Enter PAL TUNER auto adjustment execution

3 TUNER ADJ (SMPTE) Enter TUNER auto adjustment execution (SMPTE)

4 PAL+TUNER ADJ (SMPTE) Enter PAL TUNER auto adjustment execution (SMPTE)

5 TUNER ADJ (SMPTE CH57) Enter TUNER auto adjustment execution (SMPTE CH57)

6 PAL+TUNER ADJ (SMPTE CH57) Enter PAL TUNER auto adjustment execution (SMPTE CH57)

7 TUNER CONTRAST A_GAIN 16 TUNER signal level adjustment

8 TUNER CONTRAST D_GAIN 2073 TUNER signal level adjustment

9 TUNER CONTRAST OFFSET 256 TUNER signal level adjustment

4/21

1 PAL ADJ Enter PAL adjustment

2 SECAM ADJ Enter SECAM adjustment

3 N358 ADJ Enter N358 adjustment

4 PAL CONTRAST A_GAIN 14 PAL contrast adjustment

5 PAL CONTRAST D_GAIN 2149 PAL contrast adjustment

6 PAL CONTRAST OFFSET 255 PAL contrast adjustment

7 SECAM CONTRAST A_GAIN 14 SECAM contrast adjustment

8 SECAM CONTRAST D_GAIN 2123 SECAM contrast adjustment

9 SECAM CONTRAST OFFSET 256 SECAM contrast adjustment 10 N358 CONTRAST A_GAIN 14 N358 contrast adjustment 11 N358 CONTRAST D_GAIN 2192 N358 contrast adjustment 12 N358 CONTRAST OFFSET 255 N358 contrast adjustment

Last error standby cause.

(Excluding the error)

(Public mode is excluded)

(Level appears in green on the upper right)

6 – 4

LC-60LE822E/LC-60LE822ERU

Page Line Item Description Remarks (adjustment detail, etc.)

5/21

1 HDMI CEC TEST Enter HDMI CEC test

2 INSPECT USB TERM Enter Reading inspection of USB memory terminal

3 HDMI EDID WRITE Enter HDMI EDID WRITING

4 MONIDATA READ [TEMP/OPC] OFF MONITOR Temperature/OPC Acquisition tool.

5 CAUSE RESET Enter Reset of standby cause

6 SD CARD TEST Size 1 SD CARD TEST

7 SD CARD REC SIZE xx SD CARD REC SIZE

8 RESET OFF SD CARD RESET

6/21

1 COMP15K ALL ADJ Enter Component 15K picture level adjustment

2 COMP15K MAIN Y GAIN 141 Y GAIN adjustment value

3 COMP15K MAIN CB GAIN 150 Cb GAIN adjustment value

4 COMP15K MAIN CR GAIN 150 Cr GAIN adjustment value

5 COMP15K Y OFFSET 64 Y OFFSET adjustment value

6 COMP15K CB OFFSET 128 Cb OFFSET adjustment value

7 COMP15K CR OFFSET 128 Cr OFFSET adjustment value

7/21

1 HDTV ADJ Enter HDTV video level adjustment

2 HDTV Y GAIN 141 HDTV Y GAIN adjustment value

3 HDTV CB GAIN 150 HDTV Cb adjustment value

4 HDTV CR GAIN 150 HDTV Cr adjustment value

5 HDTV Y OFFSET 64 HDTV Y OFFSET adjustment value

6 HDTV CB OFFSET 128 HDTV Cb OFFSET adjustment value

7 HDTV CR OFFSET 128 HDTV Cr OFFSET adjustment value

8/21

1 ANALOG PC ADJ Enter DVI ANALOG video level adjustment

2 R OFFSET 64 R CUTOFF adjustment value

3 G OFFSET 64 G CUTOFF adjustment value

4 B OFFSET 64 B CUTOFF adjustment value

5 R GAIN 44 R DRIVE adjustment value

6 G GAIN 44 G DRIVE adjustment value

7 B GAIN 44 B DRIVE adjustment value

9/21

1 SCART RGB ADJ Enter SCART RGB level adjustment

2 SCART RGB ADJ (FAST SW) ENTER SCART RGB level adjustment with FAST SW.

3 SCART R CUTOFF 64 SCART R CUTOFF adjustment value

4 SCART G CUTOFF 64 SCART G CUTOFF adjustment value

5 SCART B CUTOFF 64 SCART B CUTOFF adjustment value

6 SCART R GAIN 44 SCART R GAIN adjustment value

7 SCART G GAIN 44 SCART G GAIN adjustment value

8 SCART B GAIN 44 SCART B GAIN adjustment value

10/21

1 VCOM ADJ 0 Common bias adjustment

11/ 21

1 R GAIN (LO) 0 R DRIVE adjustment value

2 G GAIN (LO) 0 G DRIVE adjustment value

3 B GAIN (LO) 0 B DRIVE adjustment value

4 R GAIN (HI) 0 R DRIVE adjustment value

5 G GAIN (HI) 0 G DRIVE adjustment value

6 B GAIN (HI) 0 B DRIVE adjustment value

12/21

1 MONITOR TIME OUT ON Monitor and the main communication time-out setting

2 MONITOR MAX TEMP 45 MONITOR MAX temperature setting

3 MONITOR EEP READ/WRITE WRITE MONITOR EEPROM READ/WRITE Setting/execution

4 MONITOR EEP ADR 0x 0 MONITOR EEPROM arbitrary addressing

5 MONITOR EEP DATA 0x 0 MONITOR EEPROM arbitrary data specification

13/21

1 LCD TEST PATTERN OFF Pattern with built-in LCD controler display

2 LCD TEST PATTERN 1 OFF

3 LCD TEST PATTERN 2 OFF

4 LCD TEST PATTERN 3 OFF

5 LCD TEST PATTERN 4 OFF

6 – 5

LC-60LE822E/LC-60LE822ERU

Page Line Item Description Remarks (adjustment detail, etc.)

14/21

1 FRC-N Firmware Version xxxxx

2 FRC-N Boot Script Version xxxxx

3 FRC-N Device Version xxxxx

4 TCON FPGA1 Serial Flash Version xxxxx

5 TCON FPGA2 Serial Flash Version xxxxx

6 TCON FPGA1 Config Rom Version xxxxx

7 TCON FPGA2 Config Rom Version xxxxx

15/21

1 POWER LED BRIGHTNESS 0

2 MENU LED BRIGHTNESS 0

3 INPUT LED BRIGHTNESS 0

4 CH UP LED BRIGHTNESS 0

5 CH DOWN LED BRIGHTNESS 0

6 VOL UP LED BRIGHTNESS 0

7 VOL DOWN LED BRIGHTNESS 0

8 LOGO LED BRIGHTNESS 99

9 ICON LED BRIGHTNESS 99 10 ICON LED BRIGHTNESS (STANDBY) 30

16/21

1 POWER KEY SENSITIVITY 0

2 MENU KEY SENSITIVITY 0

3 INPUT KEY SENSITIVITY 0

4 CH UP KEY SENSITIVITY 0

5 CH DOWN KEY SENSITIVITY 0

6 VOL UP KEY SENSITIVITY 0

7 VOL DOWN KEY SENSITIVITY 0

17/21

1 KEY STRENGTH GET MODE Enter

2 POWER KEY STRENGTH

3 MENU KEY STRENGTH

INPUT KEY STRENGTH 4 CH UP KEY STRENGTH 5 CH DOWN KEY STRENGTH 6 VOL UP KEY STRENGTH 7 VOL DOWN KEY STRENGTH

18/21

1 READ/WRITE READ Read/Write 2 SLAVE/ADDRESS SLAVE0 Slave address 3 REGISTER ADDRESS 0x 0 Register address

0x 0

4 WRITE DATA 0x 0 Writing data

0x 0

5 READ DATA 0x 0 Reading data

0x 0

19/21

1 RF AGC BG 6 RF-AGC BG adjustment execution 2 RF AGC DK 5 RF-AGC DKG adjustment execution 3 RF AGC I 6 RF-AGC I adjustment execution 4 RF AGC L/L' 4 RF-AGC L/L' adjustment execution

20/21

1 ERROR STANDBY CAUSE 1 NO RECORD ERROR STANDBY CAUSE 2 ERROR STANDBY CAUSE 2 NO RECORD 3 ERROR STANDBY CAUSE 3 NO RECORD 4 ERROR STANDBY CAUSE 4 NO RECORD 5 ERROR STANDBY CAUSE 5 NO RECORD 6 STANDBY CAUSE RESET OFF Reset stand by cause.

6 – 6

LC-60LE822E/LC-60LE822ERU

Page Line Item Description Remarks (adjustment detail, etc.)

21/21

1 EEP SAVE OFF Writing setting values to EEPROM. 2 EEP RECOVER OFF Reading setting values from EEPROM. 3 MONITOR ERROR CAUSE RESET OFF Reset of monitor error cause 4 MODEL NAME LE705 MODEL NAME 5 PANEL SIZE 40 Panel size setting. (40/46/52) 6 SHORT CHECK MODE Enter Check LED Back light 7 SHORT CHECK CURRENT 60 8 CURRENT SW LOW 9 PRODUCT EEP ADR 0x 0 Don't touch when serving (for producer of factory)

10 PRODUCT EEP DATA 0x 0 Don't touch when serving (for producer of factory) 11 PRODUCT FACTORY 1 Don't touch when serving (for producer of factory)

8. Special features

1. NORMAL STANDBY CAUSE (Page 1/21)

Display of a cause (code) of the last standby.

The cause of the last standby is recorded in EEPROM whenever it is possible.

Checking this code will be useful in finding a problem when you repair the troubled set.

2. EEP SAVE (Page 21/21)

Storage of EEP adjustment value

3. EEP RECOVER (Page 21/21)

Retrieval of EEP adjustment value from storage area.

4. MONITOR ERR CAUSE (Page 1/21)

Display of a cause (code) of Error from sub-Microcomputer.

The cause of Error is recorded in EEPROM whenever it is possible.

Checking this code will be useful in finding a problem when you repair the troubled set.

1) This displays Error code and time when the error occurred.

The latest error is displayed on “1)”

The error that happens ahead of “1)” is displayed on “2)”.

2) The character depends on the way how to acquire Time Information

T: Time is acquired from digital broadcasting

This doesn't contain “Time offset” which is considered a time difference and Daylight-Saving Time, etc. ...

U: Time is acquired from analog broadcasting (teletext) B: Accumulation time of Backlight

In the case that Time information cannot be acquired, “B” is displayed.

Example) In this example, it is shown that the error occurred 3 times.

1) 16 T07/01/01 12:03 Error code: 16 (lamp error) Time: 07/01/01 12:03

* It is latest Error. * Time is acquired from digital broadcasting. * Time is UTC which doesn't have Time offset.

2) 16 U01/01/01 04:07 Error code: 16 (lamp error) Time: 07/01/01 04:07

* It is Error that happens ahead of “1)”. * Time is acquired from analogue broadcasting.

3) 16 B00000004:11 Error code: 16 (lamp error) Accumulation time: It is displayed that 4:11 have passed after Backlight driving.

* It is Error that happens ahead of “2)”.

4) 00 0000000000000 No error (“00” shows that the error is not occurred.)

6 – 7

LC-60LE822E/LC-60LE822ERU

9. Lamp Error detection

1. Function

This LCD colour TV set incorporates a Lamp error detection feature that automatically turns off the power for safety under abnormal lamp or lamp circuit conditions. If by any chance anything is wrong with the lamp or lamp circuit or if the lamp error detection feature is activated for some reason, the following will result.

1) The power is interrupted in about 500ms after it is turned on.

(A central icon on the front of the TV flash on and off.: ON for 400ms and OFF for 1600ms.).

2) If the above phenomenon 1) occurs 5 times, it becomes impossible to turn on the power.

(A central icon keep flashing on/off.)

2. Measures

1) Set the lamp error detection to OFF

Enter the adjustment process mode, referring to “4. Entering and exiting the adjustment process mode.”

The adjustment process mode can ignore “5 times count”, so If the above phenomenon 1) occurs 1~4 times, the lamp will go out.

If Lamp Error detection pin (6pin of LB: P9602) is “High” by a trouble with the lamp and lamp circuit, it can boot-up by the adjustment process mode.

Please execute “Lamp Error detection off-mode”.

While holding down the “VOL (-)” and “CH ( )” keys on the set at once, touch the power supply key on the set.

After a central icon flash off, separate the fingers from key on the set.

Touch the power supply key on the set again, so the power will boot-up.

Then, you can check the operation to see if the lamp and lamp circuit are in trouble.

If you fail boot-up, retry the procedure.

2) Resetting the lamp error count

After the lamp and lamp circuit are improved from a trouble, reset the lamp error count.

(Because the power cannot be turned on, if a lamp error is detected 5 consecutive times)

a) Enter the adjustment process mode, referring to “4. Entering and exiting the adjustment process mode.”

b) Using the cursor ( / ) key, move to the cursor to [LAMP ERROR RESET], Line 8 on adjustment process mode service page 2/21.

c) With the cursor ( / ) keys, select the [LAMP ERROR RESET] value.

Finally press the cursor (OK)., the count is reset.

Check LAMP ERROR Count on adjustment process mode Page 2/21.

Table of contents of adjustment process mode Page 2/21

INDUSTRY INIT Enter INDUSTRY INIT (-Publicl) OFF Public MODE OFF Center Acutime RESET OFF Backlight Acutime RESET OFF LAMP ERROR RESET OFF ADJ PARAM SET Enter VIC XPOS VIC YPOS VIC SIGNAL TYPE MAIN

0 0

VIC READ OFF

Resetting to "0"

6 – 8

LC-60LE822E/LC-60LE822ERU

10. Public Mode

1. Starting the Public Mode

• There are two following ways to display the PUBLIC Mode setting screen.

1) Method of needing password

a) Turn off the power, refer to “3. Method of shuts down for Power supply”

b) While holding down the “INPUT” and “Volume (+)” keys on the set at once, touch the power supply key on the set.

Please separate the finger from the power supply key when boot-up is confirmed with lighting of a central icon etc.

After a while, value of Public Mode appears on the screen.

c) Display the Pass Word input screen.

Public Mode

Operation procedure

• The initial input position is the digit at the left end.

• For the numeric keys “0” to “9” of R/C, key input is accepted.

Input of the other keys is prohibited.

• Change “—” to “ * ” by inputting the numeric key at the input position, and shift the input position rightward one digit.

• When three digits are completely input, the Pass Word is judged.

d) Check the Pass Word by inputting three digits.

If the Pass Word “0” “2” “7”, it shifts to the PUBLIC Mode setting screen.

In another case, the screen is erased, and it operates in the ordinary mode.

2. Exiting the Public Mode Setting screen

• There are two following ways to exit the Public Mode setting screen.

1) Turn off the power.

2) Select “Execution” in the PUBLIC_Mode to execute it.

Activate the restart under the set content.

Here, the START input SOURCE setting is excluded since this item is referred to only when the power is turned on.

3. Set value of the Public Mode

• When the shipment setting is done, a set each value in Public Mode is initialized.

(PUBLIC MODE in the process mode Setting of a flag is also initialized)

• Separately, the shipment beginnings when all except for each set value in Public Mode is initialized are provided for a process mode.

(INDUSTRY INIT (-Public))

• Only when turning on the PUBLIC MODE item, each setting is effective.

• After it decides it with EXECUTE, it AC OFF/ON it to reflect a set value.

Public Mode

6 – 9

LC-60LE822E/LC-60LE822ERU

No Power off by remote control.

4. Basic operation in the Public Mode

Vol (+/-) or Cursor ( / )

CH ( / ) or Cursor ( / ) Decision (ok) Execution (Used by the items “Execution” and “RESET”.)

Public Mode setting screen.

Public Mode POWER ON FIXED [VARIABLE] SHUT DOWN MODE [NORMAL] MAXIMUM VOLUME [60] VOLUME FIXED [VARIABLE] VOLUME FIXED LEVEL [20] RC BUTTON [RESPOND] PANEL BUTTON [RESPOND] MENU BUTTON [RESPOND] AV POSITION FIXED [VARIABLE] ON SCREEN DISPLAY [YES] INPUT MODE START [NORMAL] INPUT MODE FIXED [VARIABLE] LOUD SPEAKER [ON] RC PATH THROUGH [OFF] 232C POWON [DISABLE] PUBLIC MODE [ON] RESET EXECUTE

Change or execution of the set value.

Movement to the selected item.

5. Operation after “RESET”

Select “RESET” in the PUBLIC Mode, and it operates as follows when it is executed (refer to the basic operation).

• The set contents in the PUBLIC mode are initialized.

• It does not exit the PUBLIC mode.

• If “EXCUTE” is not executed, the content that does RESET is not reflected.

6. Setting items (* Item names and selective items are expressed in English.)

1) Power ON fixed [POWER ON FIXED]

Option “VARIABLE”, “FIXED_ALL”, “FIXED_BODYKEY” or “RCRESPOND” (loop enabled) Default “VARIABLE” Function • VARIABLE : “POWER/RECEPTION” key on TV unit or remote control is enabled.

• FIXED_ALL“ : “POWER/RECEPTION” key on TV unit or remote control is disabled.

• FIXED_BODYKEY : only the “MAIN POWER” key on TV unit is disabl ed (the remote control is enabled).

• RC RESPOND : the main unit’s POWER switch toggles between ON and Standby (the same operation by the remote control).

Key disabled when set other than default Remarks • When selecting to “FIXED_ALL”, function related standby factors (see below) doesn't work. and not selecting

If the power button is pressed in the ordinary mode in setting to “FIXED_ALL” and “FIXED_BODYKEY”, the caution is displayed for 5 seconds.

When power button on the main unit is pressed When power button on R/C is pressed

• OFF TIMER (SLEEP) (* Only when setting to FIXED_ALL)

OFF TIMER (Sleep) No operation OFF No signal OFF (including the power management) * These items does not exist according to the model.

No Power off by power button.

* The OSD display is an example.

If another ODS is previously displayed, the status is reset (MENU or similar).

6 – 10

LC-60LE822E/LC-60LE822ERU

2) Instantaneous current shutdown setting in turning off the power [SHUT DOWN MODE]

Option “NORMAL” or “QUICK” Default NORMAL Function • This function decides whether scanning digital tuner is enabled or disabled when the power is standby. NORMAL : Scanning digital tuner is enabled when the power is standby.

QUICK : Scanning digital tuner is disable

It is possible to put into the standby state instantaneously due to power off input, when the power is standby. Immediately, state is a complete standby.

Remarks In selecting “QUICK”, the function does not work for the following items (selection impossible.)

• ON TIMER, QUICK START, DIGITAL FIXED, etc.

* These items does not exist according to the model.

3) Volume maximum level [MAXIMUM VOLUME]

Option 0~60 (loop disabled) Default 60 Function The volume cannot be increased more than the adjusted value (the main unit’s speaker only). Remarks • When setting to 59 or less, only the figure is displayed in the normal mode; the volume bar is not displayed.

• The volume of the headphones is limited. or monitor output

• The setting is impossible when VOLUME FIXED is set to FIXED.

4) Volume fixed [VOLUME FIXED]

Option “VARIABLE”, “FIXED”, “ACCTRL” or “AC/RCCTRL” (loop enabled) Default “VARIABLE” Function • VARIABLE : The volume is not fixed.

• FIXED : The volume is fixed to the value adjusted in the volume fixed level.

• AC CTRL : The unit starts at the volume specified in the volume fixed level, when power is turned on in

• AC/RC CTRL : The unit starts at the volume specified in the volume fixed level, when power is turned on in

Exception • In the adjustment process, the volume can be set to any level regardless of this setting. Disabled key when setting to FIXED Remarks • [MAXIMUM VOLUME] has priority to [VOLUME FIXED]

• VOLUME UP/DOWN [both remote control and main unit]

•MUTE

* When setting to FIXED, Maximum volume is fixed.

• The volume of the headphones is fixed.

• When setting to “FIXED”, the volume is not displayed in operating Disabled key

• In menu operation, the main unit's keys (Vol (+/-)) are enabled.

the case of the AC-ON only.

any case. (AC→ON, remote control→ON, main unit's key→ON)

5) Volume fixed level [VOLUME FIXED LEVEL]

Option 0~60 (loop disabled) Default 20 Function The volume is fixed to the adjusted value (the main unit’s speaker only). Exception • In the adjustment process, the volume can be set to any level regardless of this setting. Remarks • When [VOLUME FIXED] is set to “VARIABLE”, the setting cannot be changed.

6) Remote control operation [RC BUTTON]

Option “RESPOND”, “NORESPOND” or “LIMITED” (loop enabled) Default “RESPOND” Function The operation of the remote control’s keys is set. RESPOND : the remote control’s keys in the normal state are enabled.

NO RESPOND : the remote control’s keys in the normal state are disabled.

The POWER key (RECEPTION/STANDBY key) is also disabled.

LIMITED : only a part of keys (CHANNEL, etc.) is enabled and other keys are disabled.

Exception • In the adjustment process mode, inspection mode are enabled regardless of this setting.

Remarks The enable keys when setting to “LIMITED” are depended on keys of controler for Public.

• All the keys are enabled regardless of this setting while entering the adjustment process mode, inspection mode

or Public Mode setting screen.

It is different according to Model.

6 – 11

LC-60LE822E/LC-60LE822ERU

7) Main Unit Operation [PANEL BUTTON]

Option “RESPOND” or “NORESPOND” (loop enabled) Default “RESPOND” Function • RESPOND : The main unit’s keys are enabled.

• NO RESPOND : The main unit’s keys are disabled excluding the POWER key (RECEPTION/STANDBY

Exception • The start operation in the adjustment process mode, inspection mode are enabled regardless of this setting.

8) Menu operation [MENU BUTTON]

Option “RESPOND” or “NO RESPOND” (loop enabled) Default “RESPOND” Function The MENU key on the main unit and remote control is decided whether it is enabled or disabled. Exception • RESPOND : The menu key is enabled.

Disabled key excluding Menu key when setting to not default Remarks When setting to “NO RESPOND”

• All the keys are enabled regardless of this setting while entering the adjustment process mode, inspection mode

or Public Mode setting screen.

• For the models with the MENU key on the main unit, menu operation is possible regardless of the setting during

the initial setting when the power is turned on for the first time.

• NO RESPOND : The menu key is disabled.

All the direct transition keys to menu display (AUTO PRESET, MANUAL MEMORY and others) * These keys does not exist according to the model.

• For the models with the MENU key on the main unit, menu operation is possible regardless of the setting while

the initial setting when the power is turned on for the first time

key).

: The start operation in the adjustment process mode, inspection mode is enabled regard-

less of this setting.

: All the keys are enabled regardless of this setting while entering the process mode, inspec-

tion mode or Public Mode setting screen.

9) AV position fixed [AV POSITION FIXED]

Option “VARIABLE” or “FIXED” (loop enabled) Default “VARIABLE” Function • VARIABLE : AV position is not fixed.

• FIXED : AV position is fixed.

: The image/sound adjustment items in the menu are fixed in the selected state. : When receiving “AV POSITION” of the remote control, only the actual state is displayed,

and setting is not changed.

Remarks • When receiving the sound select direct keys (AV POSITION key, OPC, DOLBY key, etc.), only the actual state is

displayed; no setting is changed. * These keys does not exist according to the model.

• The settings for the Public mode are retained after the personal data is initialized, each item for the AV position

and image/sound adjustment are not initialized.

6 – 12

10)OSD display [ON SCREEN DISPLAY]

LC-60LE822E/LC-60LE822ERU

Option “YES”, “NO” or “LIMITED” (loop enabled)

Default “YES” Function • YES : OSD is displayed

Key which may be enabled (Example of the confusing key)

Disabled key when setting to not default

Remarks • When setting to “NO”,

11)Start mode [INPUT MODE START]

Option “NORMAL” or “Input source 1 (input selection or channel)” . . . (loop enabled) Default “NORMAL” Function which kinds of input source or channel is decided when the power turning on.

Remarks • When setting to not Normal,

“LIMITED” is looped only in case of need (destination).

• NO : the following OSD is not displayed. Registration, setting, adjustment menu, channel call, volume bar, and input select

• LIMITED : only a part of OSD (CH call: “New Information” etc. ...) is not displayed.

• It is OK in the case that simple input select occure or the original state returns soon automatically.

• When setting to “NO”, the keys which is related to visibility of the screen and sound cannot be used.

STILL IMAGE, SCREEN DISPLAY, OFF TIMER, AV POSITION, BRIGHTNESS SENSOR, SCREEN SIZE SELECT, AUTO PRESET, MANUAL MEMORY, IMAGE SELECT, SOUND SELECT, LANGUAGE, Closed caution * Disabled keys dependeds on the models.

ON TIMER (Watching reservation) is cleared. OFF TIMER “SLEEP” is cleared. * These items does not exist according to the model.

• When setting to “NO”,

These Displays (Version-up, Public mode setting screen, Pass Word input screen of Public Mode, the adjustment process mode, K mark of inspection mode) are enabled regardless of this setting.

NORMAL : the content of the last memory is followed.

ON TIMER (Watching reservation) has priority.

• When setting to “NORMAL”, [INPUT MODE FIXED] is set to “VARIABLE”. and [INPUT MODE FIXED] is prohib-

ited to select. (selection impossible.)

Example of option: “NORMAL”

“TVD (002TV)”, “INPUT1”, “INPUT2”, “INPUT3”, “HDMI1”, “HDMI2”, “HDMI3”, “HDMI4”.

12)Input fixed [INPUT MODE FIXED]

Option “VARIABLE” “FIXED”, “ACCTRL” or “AC/RCCTRL” (loop enabled) Default VARIABLE Function VARIABLE : If [INPUT MODE START] is set to Normal, input mode is not fixed.

FIXED : when “INPUT MODESTART” is active, it is impossible to switch to another channel or input

source.

AC CTRL : when “INPUT MODESTART” is active the unit starts at the input mode which is selected

when power is turned on in the case of the AC-ON only.

AC/RC CTRL : when “INPUT MODESTART” is active the unit starts at the input mode which is selected

when power is turned on in any case (AC→ON, remote control→ON, main unit's key→ON)

Disabled key when setting to “FIXED” Remarks • If [INPUT MODE START] is Normal, this function cannot be set.

CHANNEL (+/-), DIRECT CHANNEL buttons, FLASHBACK, INPUT SELECT, TV/VIDEO, AUTO PRESET, MANUAL

MEMORY, i.LINK, DIRECTINPUTSELECT, ATV, DTV, EPG, RADIO etc. ...

Set to “VARIABLE” automatically.

• When setting to “FIXED”,

The item related to the channel setting and input selection in Menu are not displayed. ON TIMER (Watching reservation) is not active. * These items does not exist according to the model.

6 – 13

LC-60LE822E/LC-60LE822ERU

13)Speaker ON/OFF selection [LOUD SPEAKER]

Option “ON” or “OFF” (loop enabled) Default ON Function ON : The sound from the speakers is output.

OFF : The sound from the speakers is not output even if the headphones are not used.

Remarks • When the VOL (+/-) key is pressed, the mute icon is displayed for 4 seconds.

• For the MUTE key and sound-related keys, caution is displayed.

• For the headphones, normal operation is possible.

14)Remote control path through [RC PATH THROUGH]

Option “OFF”, “ON: TVRCE” or “ON: TVRCD” (loop enabled) Default OFF Function The item decide whether the signal received by the remotecontrol’ slight-receiving section is output to the blankpin

(9pin) of RS232C. OFF : this function is not active. ON: TVRCE : this function is active, and remote control is active, too ON: TVRCD : this function is active, but remote control is not active

Exception • In the case of “ON:TV RCD”, the start operation in the adjustment process mode, inspection mod are enabled

regardless of this setting.

• In the case of “ON: TV RCD”, all the keys are enabled regardless of this setting while entering the adjustment pro-

cess mode, inspection mode or Public mode setting screen.

Remarks * Remote control path through does not exist according to the model.

15)232C power ON control [232C POWON]

Option “ENABLE” or “DISABLE” (loop enabled) Default DISABLE Function The item decide whether Power ON by the 232C command is enabled/disabled in the standby state.

The same function as 232C command “RSPW”. ENABLE : POWR0001 is always enabled. DISABLE : Start-up may be impossible at POWR0001.

16)Public mode setting [PUBLIC MODE]

Option “OFF” or “ON” (loop enabled) Default OFF Function The item decide whether Public mode setting menu are enabled or disabled.

The same item as [PUBLIC MODE] in the adjustment process menu. OFF : Public mode is not active ON : Public mode is active

Remarks Each operation of the Public mode is impossible unless this item is set to ON.

(If the 232C command reception module is set to OFF, the command is invalid.)

11. Video signal adjustment procedure

The adjustment process mode menu is listed in Section 5.

Signal generator level adjustment check (Adjustment to the specified level)

• Composite signal PAL/SECAM : 0.7Vp-p ± 0.02Vp-p (Pedestal to white level)

• RGB signal : 0.7Vp-p ± 0.02Vp-p

• 15K component signal (50 Hz) : Y level : 0.7Vp-p ± 0.02Vp-p (Pedestal to white level) : PB, PR level : 0.7Vp-p ± 0.02Vp-p

• 33K component signal (50 Hz) : Y level : 0.7Vp-p ± 0.02Vp-p (Pedestal to white level) : PB, PR level : 0.7Vp-p ± 0.02Vp-p

• ANALOG RGB signal : RGB level : 0.7Vp-p ± 0.02Vp-p

11.1. Entering the adjustment process mode

Enter the adjustment process mode according to Section 4.

6 – 14

11.2. PAL signal adjustment

100% white Black

Adjustment point Adjustment conditions Adjustment procedure

1 Setting [Signal]

PAL Full field colour bar composite signal

[Terminal] EXT1 SCART IN

LC-60LE822E/LC-60LE822ERU

• Feed the PAL full field colour bar signal (75% colour saturation) to EXT1 SCART IN. [VIDEO input signal]

2 Auto adjustment

performance

* ATTENTION: Please execute [3. TUNER adjustment] afterwards if you adjust [2. PAL signal adjustment] after all adjustments are completed.

Adjustment process [PAL ADJ] page 4/21

Bring the cursor on [PAL ADJ] and press [OK]. [PAL ADJ OK] appears when finished.

11.3. TUNER adjustment

Adjustment point Adjustment conditions Adjustment procedure

1 Setting [Signal]

PAL split field colour Bar RF signal UV

[Terminal] TUNER

• Feed the PAL Split Field colour bar signal (E-12ch) to TUNER.

• Make sure the PAL colour bar pattern has the sync level of 7:3 with the picture level.

Signal level: 55 dB µV ± 1dB (75Ω LOAD) [E-12CH]

100% white

2 Auto adjustment

performance

Adjustment process [TUNER ADJ] page 3/21

Bring the cursor on [TUNER ADJ] and press [OK]. [TUNER ADJ OK] appears when finished.

11.4. SECAM adjustment

Adjustment point Adjustment conditions Adjustment procedure

1 Setting [Signal]

SECAM Full field colour Bar Signal

[Terminal] EXT1 SCART IN

2 Auto adjustment

performance

Adjustment process [SECAM ADJ] page 4/21

• Feed the SECAM full field colour bar signal (75% colour saturation) to EXT1 SCART IN. [VIDEO input signal]

Bring the cursor on [SECAM ADJ] and press [OK]. [SECAM ADJ OK] appears when finished.

6 – 15

LC-60LE822E/LC-60LE822ERU

100% white Black

11.5. ADC adjustment (Component 15K)

Adjustment point Adjustment conditions Adjustment procedure

1 Setting [Signal]

COMP15K, 50Hz 100% Full field colour bar Signal

[Terminal] EXT3 COMPONENT IN

• Feed the COMPONENT 15K 100% full field colour bar signal (100% colour saturation) to EXT3 COMPONENT IN.

2 Auto adjustment

performance

Adjustment process [COMP15k ALL ADJ] page 6/21

11.6. ADC adjustment (Component 33K)

Adjustment point Adjustment conditions Adjustment procedure

1 Setting [Signal]

COMP33K, 50Hz 100% Full field colour bar Signal

[Terminal] EXT3 COMPONENT IN

2 Auto adjustment

performance

Adjustment process [HDTV ADJ] page 7/21

11.7. PC signal adjustment (ANALOG RPG)

Adjustment point Adjustment conditions Adjustment procedure

1 Setting [Signal]

XGA, 60Hz 100% Full Field Colour Bar Signal

Bring the cursor on [COMP15k ALL ADJ] and press [OK] [COMP15k ALL ADJ] [OK] appears when finished.

• Feed the COMPONENT 33K 100% full field colour bar signal (100% colour saturation) to EXT3 COMPONENT IN.

Bring the cursor on [HDTV ADJ] and press [OK]. [HDTV ADJ OK] appears when finished.

• Feed the XGA 60Hz 100% full field colour bar signal (100% colour saturation) to EXT3 PC IN.

[Terminal] EXT3 PC IN

2 Auto adjustment

performance

Adjustment process [ANALOG PC ADJ] menu page 8/21

11.8. RGB (SCART) adjustment (RGB 15K)

Adjustment point Adjustment conditions Adjustment procedure

1 Setting [Signal]

RGB 15K, 50Hz 100% Full field colour bar signal

[Terminal] EXT1 SCART RGB IN

2 Auto adjustment

performance

Adjustment process [SCART RGB ADJ] menu page 9/21

Bring the cursor on [ANALOG PC ADJ] and press [OK]. [ANALOG PC ADJ OK] appears when finished.

• Feed the RGB 15k 50Hz 100% full field colour bar signal (100% colour saturation) to EXT1 SCART IN.

Bring the cursor on [SCART RGB ADJ] and press [OK]. [SCART RGB ADJ OK] appears when finished.

6 – 16

LC-60LE822E/LC-60LE822ERU

12. White Balance Adjustment

For white balance adjustment, adjust the offset values on pages 11/21.

[Condition of the unit for inspection] : Modulated light (+16), Colour temperature (High)

AV MODE: DYNAMIC Active Backlight: OFF OPC: OFF

Asing Time: Min,60 minute [Input signal condition] : HDMI 1080i 15IRE (LO), 78IRE (HI) [Adjustment reference device] : Minolta CA-210

[Adjustment procedure]

1) Display the current adjustment status at R/G/B_GAIN (HI). (Page 11/21 of process adjustment)

The signal of 78IRE is input.

2) Read the value of the luminance meter. x = 0.272, y = 0.277

3) Change R_GAIN (HI)/B_GAIN (HI) (Adjustment offset value) on page 11/21 of process adjustment so that the values of the luminance meter approach x = 0.272 and y = 0.277.

(Basically, G is not changed. If adjustment fails with R and B, change G. When G is lowered, the weaker of R or B must be fixed.)

4) Display the adjustment status of the current R/G/B_GAIN (LO).

The signal of 15IRE is input.

Change R_GAIN (LO)/B_GAIN (LO) (adjustment offset value) on page 11/21 of process adjustment so that the values of the luminance meter approach x = 0.272 and y = 0.277.

5) Both HI and LO are repeating the step from 1 to 4 until becoming an aim value.

[Adjustment reference standard value]

Adjustment spec ± 0.002 Inspection spec ± 0.004 (point LO)

Adjustment spec ± 0.001 Inspection spec ± 0.002 (point HI)

6) After completing adjustments, set EEP SAVE (21/21) to ON in the process menu to save the white balance adjustment value.

13. Confirmation item

1. HDMI-CEC Inspection

After repairing the CEC function, check the operation about HDMI-CEC circuit

2. CI card Inspection

After repairing the CI function, check that the DTV signal is received in the UK setting by inserting CAM

And check the KEY certification by inserting CAM which is prepare for CI+

3. LAN Inspection

After repairing the LAN function, check the communication by connecting PC and LAN terminal.

6 – 17

LC-60LE822E/LC-60LE822ERU

Menu(Setup Software Update)

14. Initialization to factory settings

CAUTION: When the factory settings have been made, all user setting data, including the channel settings, are initialized. (The adjustments done in the adjustment process mode are not initialized.) Keep this in mind when initializing these settings.

Adjustment point Adjustment conditions Adjustment procedure

1 Factory settings ends by turning off the

MAIN POWER key. (See to below caution)

After adjustments, exit the adjustment process mode. To exit the adjustment process mode, unplug the AC power cord from the outlet to forcibly turn off the power. When the power is turned off with the remote control, unplug the AC power cord and plug it back in (wait approximately 10 seconds before plugging in the AC power cord) Please execute the initialized in the factory setting again when you turn on the power supply after the initialized in the factory setting is set.

[Factory setting with adjustment process mode]

• Enter the adjustment process mode.

• Move the cursor to [INDUSTRY INIT] on page 2/21.

• Use the R/C key to select a region from [EUROPE/RUSSIA] and press the [OK] key.

• “EXECUTING” display appears.

• After a while, “SUCCESS” display appears, the setting is completed.

When succeeding: Background colour (green) When failing: Background colour (red)

The following items are initialized in the factory setting.

1) User settings

2) Channel data (e.g. broadcast frequencies)

3) Maker option setting

4) Password data

15. Upgrading the software

1. Turn on the AC power.

2. Insert the upgrading USB flash memory for upgrade into the service slot.

(After a while, an external input changes into USB automatically.)

3. Use the Menu button and cursor keys ( / / / ), CH keys ( / ) of R/C or on the set to select Menu - Setup - Information - Software update on OSD menu.

4. The message (Insert the USB memory device contains the software update file) shows up.

Push OK when if there is no problem.

5. After a while, if software update file is detected in the USB memory device, the following screen shows up.

Select OK when if there is no problem.

NOTE: If there is no software update file in the USB memory device, caution shows up.

Please insert the correct file and retry software update.

NOTE: If software update file in the USB memory device doesn't mutch this model, caution shows up.

Please insert the correct file and retry software update.

NOTE: If software update file in the USB memory device is already installed, caution shows up.

Please reconfirm the software version and reinstall (if necessary).

Software update file is detected

in the USB memory device start update

current version : xxxxxx update version : xxxxxx

YES NO

6 – 18

6. The caution for update showes up.

Menu(Setup Software Update)

• The picture will temporary go dark until the software update display apeeares

• Wait several minutes and don't unplug the AC cord

Select OK when if there is no problem.

7. Software update starts.

Please wait for a while until the bar shows 100%

NOTE: Do not take out the USB memory device during updating.

Now Updating Don't unpluged AC cord update version xxxxxxx

8. When all the procedures are complete, the following upgrade success screen shows up.

The new software version can be confirmed on screen.

After a while, Turn off power and boot-up automatically.

NOTE: TV is restarted automatically, the AC code need not be pulled out.

LC-60LE822E/LC-60LE822ERU

LExxx

xx %

Software Update Complete

9. After boot-up, the following caution shows up.

Select OK when if there is no problem.

Software update is completed, please remove the USB memory device.

system software was succesfully updated Remove the USB memory device.

LExxx

xxxxxxx

NOTE: Then get the set started and call the process adjustment screen 1/21 to check the main software version.

6 – 19

LC-60LE822E/LC-60LE822ERU

LC-60LE822E

CHAPTER 7. TROUBLESHOOTING TABLE

Service Manual

[1] TROUBLESHOOTING TABLE

No power (Central Icon LED failure to light up) or No startup (Central Icon LED is flashing)

Is the AC cord connector tightly connected to the set? NO Reconnect the AC cord tightly and turn on the power again.

YES Are the wire harnesses and other cables properly connected in the set?

YES Is there the pins (11/BU+5V) of P9601as specified? NO Replace the power unit.

YES Is there the pins (10/PS_ON) of P9601 at “H”? NO Check the signal line between PS_ON and IC2002.

YES Is there the pins (9/AC_DET) of P9601 at “H”? NO Check the power unit, and the signal line between AC_DET and

NO Reconnect the wire harnesses and other cables properly in the

set.

IC2002.

YES Is there the pins (1, 2, 3, 4/UR+13V) of P9601 at “H”? NO Check the signal line between PS_ON and IC2002.

YES Are the DC/DC converter outputs and the output voltages along the control lines as specified?

1) BU3.3V (IC9609 etc.)

2) D3.3V (IC9605 etc.)

3) D5.6V (IC9608 etc.)

4) D5V (IC9612 etc.)

5) D+1.8V (IC9606 etc.)

6) D+1.05V (IC9604 etc.)

7) STB+3.3V (Q9604 etc.)

8) S+8V (IC9610 etc.)

9) CPU+1.2V (IC9603 etc.)

NO Check the DC/DC converters and the control lines.

Replace defective parts as required.

7 – 1

LC-60LE822E/LC-60LE822ERU

The sound is not emitted from the Speaker & Woofer though the picture has come out.

No sound output in all modes?

YES Is the signal output from pins (F30/AOLRCK), (F28/AOBCK)

(G28/AOSDATA0) of IC3302 (Digital AV decode & Main CPU)?

YES Is the signal sent to pins (7), (8), (9) of IC2701 (DSP)? NO Check the line between IC3302 and IC2701.

YES Is the signal output from pins (43/AOBCKL), (44/AMP_LRCLK),

(45/AMP_DATA_LR), (46/AMP_DATA_SW), (47/AMP_MCLK) of IC2701?

YES In the case that the sound is not emitted from the Speaker, refer to (A) In the case that the sound is not emitted from the Woofer, refer to

(B)

(A)

Is the signal sent to pins (5), (6), (7), (8) of IC2703 (SP_AMP)?

NO Check IC3302 and its peripheral circuits.

NO Check IC2701 and its peripheral circuits.

NO Check the line between IC2701 and IC2703.

YES

Is the audio signal output from pins (28/OUTML), (30/ OUTPL), (12/OUTPR), (14/OUTMR) of IC2703?

YES Is the audio signal input to pins (1, 2/L-ch), (3, 4/R-ch) of IC2703?

YES Check Speaker (right and left) and wire harness.

(B)

Is the signal sent to pins (5), (6), (7), (8) of IC2702 (Woofer_AMP)?

YES Is the audio signal output from pins (28/OUTML), (30/OUTPL), (12/OUTPR), (14/OUTMR) of IC2702?

YES Is the audio signal input to pins (1/SUB(+)), (2/SUB(-)) of IC2702?

YES Check Woofer (right and left) and wire harness.

NO Check IC2703 and its peripheral circuits.

NO P2701 terminal and the peripheral circuit (L/C filter) are checked.

NO Check the line between IC2701 and IC2702.

NO Check IC2702 and its peripheral circuits.

NO P2702 terminal and the peripheral circuit (L/C filter) are checked.

7 – 2

LC-60LE822E/LC-60LE822ERU

No sound (during the reception of TV (ANALOG) broadcasting)

Does not the sound go out though the picture has come out when UHF/VHF is received?

Is a SIF signal output from pin (13) of TUNER (TU1101)? NO Check the tuner and its peripheral circuits.

YES Is a SIF signal input to (AB27/S_IF) of IC3302 (Digital AV decode & Main CPU) from pin (13) of TU1101?

YES Refer to “No sound output in all modes.”

No sound (during the reception of TV (DIGITAL) broadcasting)

Does not the sound go out though the picture has come out when DTV is received?

Is IF signal output to pins (10, 11) of TU1101? NO Check the tuner and its peripheral circuits.

NO Check the line between TU1101 and IC3302.

Replace as required.

(Q1104, etc.)

Replace as required.

YES Is IF signal sent to pins (14, 15) of IC1102 (Multiplexer)? NO Check the line between TU1101 and IC1102.

YES Are pins (9, 10, 11) of IC1102 at H/L?

L Is IF signal sent to pins (AA29/D__IF_P, AB29/D__IF_N) of

IC3302 (Digital AV decode & Main CPU)?

YES

Refer to “No sound output in all modes.” H Is IF signal sent to pins (41/INM, 42/INP) of IC1106? NO Check the line between IC1102 and IC1106.

YES Is signal output to pins (17/CTS_CK_60MHz, 18/CTS_SY, 19/ CTS_VA, 21/CTS_D0) of IC1106?

YES Is signal sent to pins (2, 3/CS_TS_CK, 5, 6/CS_TS_SY, 10, 11/ CS_TS_VA, 14/CS_TS_D7) of IC4409 (TS SW)?

NO Check IC1106 and its peripheral circuits.

NO Check the line between IC1106 and IC4405.

YES Is pins (2) of IC4409 at H? NO Check the line between IC4409 and 21pins of IC4405.

YES Is signal sent to pins (11/TS_DATA1, 12/TS_DATA2, 13/

TS_DATA3, 14/TS_DATA4) of IC4405?

YES

NO Check the line between IC1106 and IC4405.

7 – 3

LC-60LE822E/LC-60LE822ERU

Is signal output to pins (122/TS_VALIDO, 123/TS_CLKO, 124/ TS_DATAO, 124/TS_SYNCO) of IC4405?

YES Is signal sent to pins (A30/TS_CPUIN_VAL, B30/ TS_CPUIN_CLK, C30/TS_CPUIN_SYNC, C29/TS_CPUIN_D0) of IC3302 (Digital AV decode & Main CPU)?

YES Refer to “No sound output in all modes.”

No sound (during the reception of TV (DIGITAL-Satellite) broadcasting)

Does not the sound go out though the picture has come out when DTV is received?

Is signal input to TU1301? NO Check the setting of an external input device that connects with

YES Is signal sent to pins (2, 3/CS_TS_CK, 5, 6/CS_TS_SY, 10, 11/

CS_TS_VA, 14/CS_TS_D7) of IC4409 (TS SW)?

YES Is pins (2) of IC4409 at L? NO Check the line between IC4409 and 21pins of IC4405.

NO Check IC4405 and its peripheral circuits.

NO Check the line between IC4405 and IC3302.

TU1301.

NO Check the line between TU1301 and IC4409.

Check TU1301 and its peripheral circuits (IC1301 etc. ⋅⋅⋅). Replace as required.

YES Is signal sent to pins (4/CS_TS_SCK, 7/CS_TS_SSY, 9/

CS_TS_SVA, 12/CS_TS_SDATA) of IC4409?

YES Is signal sent to pins (11/T0_DATA1, 12/T0_DATA2, 13/ T0_DATA3, 14/T0_DATA4) of IC4405?

YES Is signal output to pins (122/TS_VALIDO, 123/TS_CLKO, 124/ TS_DATAO, 124/TS_SYNCO) of IC4405?

YES Is signal sent to pins (A30/TS_CPUIN_VAL, B30/

TS_CPUIN_CLK, C30/TS_CPUIN_SYNC, C29/TS_CPUIN_D0) of IC3302 (Digital AV decode & Main CPU)?

YES Refer to “No sound output in all modes”.

NO Check IC4409 and its peripheral circuits.

NO Check the line between IC4409 and IC4405.

NO Check IC4405 and its peripheral circuits.

NO Check the line between IC4405 and IC3302.

7 – 4

LC-60LE822E/LC-60LE822ERU

No sound from external input devices (1)

Does not the sound of the audio signal input to EXT1 go out?

Is there a audio input signal to pins (19/AUDIO_IN_L) and (21/ AUDIO_IN_R) of EXT1 (SC505)?

YES Is there a audio input signal to pins (V28/SC1_L) and (V27/ SC1_R) of IC3302 (Digital AV decode & Main CPU) from SC505?

YES Refer to “No sound output in all modes.”

No sound from external input devices (2)

Does not the sound of the audio signal input to EXT2 go out?

Is there a audio input signal to pins (4/CVBS_IN_L) and (1/ CVBS_IN_R) of EXT2 (J505)?

NO Check the setting of an external input device that connects with

EXT1.

NO Check the line between SC505 and IC3302.

NO Check the setting of an external input device that connects with

EXT2.

YES Is there a audio input signal to pins (R28/CVBS_L) and (T28/ CVBS_R) of IC3302 (Digital AV decode & Main CPU) from J505?

YES Refer to “No sound output in all modes.”

No sound from external input devices (3)

Does not the sound of the audio signal input to HDMI-2 mode go out?

Check whether it is selected “Video + Audio” by the Audio setup under Menu-Setup-Option-Input terminal setting - PC input.

YES YES Is there a audio input signal to pins (2/PC/HDMI_L) and (3/PC/HDMI_R) of J501 (PC AUDIO_IN)?

YES

Is there a audio input signal to pins (V30/PC/HDMI_L) and (V29/ PC/HDMI_R) of IC3302 (Digital AV decode & Main CPU) from J501?

NO Check IC3302 and its peripheral circuits.

Does not the sound of the audio signal input to PC/Component mode go out?

Check whether it is selected “HDMI + Analog” by the Audio setup under Menu-Setup-Option-Input terminal setting - PC input.

NO Check the setting of an external input device that connects with

J501.

NO Check the line between J501 and IC3302.

YES Refer to “No sound output in all modes.”

7 – 5

No sound from external input devices (4)

Does not the sound of the audio signal input to HDMI1/2/3/4 go out?

Please Refer to “[External input HDMI-1/2/3/4] No picture on the display (10)”.

No sound from external output device (1)

No audio signal output to EXT1 terminal.

Is there a audio input signal to pins (10/AUDIO_OUT_L) and (12/ AUDIO_OUT_R) of EXT1 (SC505)?

NO Is SC1-MUTE [118pins of IC3302 (Digital AV decode & Main CPU)] or MUTE_A_ALL [21pin of IC2002 (UCOM)] at “H”?

NO Is there a audio output signal to pins (M30/TUNER_OUT_L) and (M29/TUNER_OUT_R) of IC3302?

YES Check the setting of an external input device that connects with

YES Check the peripheral circuits of IC3302 and SC1-MUTE.

YES Check the line between IC3302 and SC505.

LC-60LE822E/LC-60LE822ERU

EXT1.

(Q502, D529 etc.)

NO Check IC3302 and its peripheral circuits.

No sound from external output device (2)

No sound from HEAD PHONE_OUTPUT/ AUDIO_OUTPUT terminal.

Does not the sound of the audio signal output to Headphone mode go out?

Check whether it is selected “Headphone” by Headphone/Audio out select under Menu-Setup-Option- Input terminal setting.

YES YES

Is there a audio output signal to pins (2/HP/MONI_L) and (3/HP/MONI_R) of J504 (HEAD PHONE_OUTPUT/ AUDIO_OUTPUT terminal)?

Is the HP_PLUG signal input to [91/HP_PLUG] of IC4405 from pin (6) of J504?

YES Is HP/MONI_MUTE [AJ11 of IC3302 (Digital AV decode & Main CPU)] or MUTE_A_ALL [21pin of IC2002 (UCOM)] at “H”?

NO Check the line between J504 and IC4405.

YES Check the peripheral circuits of IC3302 and HP-MUTE_LINE.

Does not the sound of the audio signal output to Audio out mode go out?

Check whether it is selected “Audio out” by Headphone/Audio out select under Menu-Setup-Option-Input terminal setting.

YES Check the setting of an external input device that connects with J504.

(D527, Q506, etc.)

Is audio signal (HP_L/R) input to pins (M28/HP/MONI_L, M27/ HP/MONI_R) of IC3302?

Check IC3302 and its peripheral circuits.

YES Check the line between IC3302 and J504.

7 – 6

LC-60LE822E/LC-60LE822ERU

No sound from external output device (3)

No sound from DIGITAL AUDIO OUTPUT terminal.

Is the audio signal output to pins (1) of sound output terminal (D520)?

NO Is SPDIF_MUTE signal SPDIF_MUTE [H29/IC3302] or MUTE_A_ALL [21pin of IC2002 (UCOM)] at “H”?

NO Is an audio signal input to pin (2) of IC503 from [J28/SPDIF_OUT] of IC3302 and is the logic signal input into pin

(1) of IC503?

NO Check IC3302 and its peripheral circuits.

No sound from external output device (4)

YES Check D520 and peripheral circuits.

YES Check the peripheral circuits of IC3302 and SPDIF_MUTE.

(Q505, D530, etc.)

YES Check the IC503 and peripheral circuits.

Does not the sound of the audio signal output to HDMI1 go out?

Is the audio signal output to pins (14) of SC1503 (HDMI1 terminal)?

NO Is the audio signal output to pins (8) (10) (12) of IC1508? YES Check the line between SC1503 and IC1508.

NO Is the audio signal input to pins (9) (11) (13) of IC1508? Is the audio signal output to pins (6) of IC1508?

Is the audio signal input to pins (5) of IC1508?

NO Is the audio signal output to pins (4) of IC1505? YES Check the line between IC1508 and IC1505.

NO Is SPDIF_MUTE signal ARC_MUTE [AK2/IC3302] or

MUTE_A_ALL [21pin of IC2002 (UCOM)] at “H”?

NO Is an audio signal input to pin (2) of IC1505 from

[J28/SPDIF_OUT] of IC3302 and is the logic signal input into pin (1) of IC1505?

YES Check SC1503 and peripheral circuits.

YES Check SC1508 and peripheral circuits.

YES Check the peripheral circuits of IC3302 and ARC_MUTE.

(Q1501, D1513, etc.)

YES Check the IC1505 and peripheral circuits.

NO Check IC3302 and its peripheral circuits.

7 – 7

LC-60LE822E/LC-60LE822ERU

No picture on the display (1)

The picture doesn't appear in all modes.

Is the LVDS signal output from IC3302 (DIGITAL_AV_DECODER_&_MAIN_CPU_&_VIDEO PROCESSER) respectively? LVDS0_D0N/P (D14/C14), LVDS0_D1N/P (D15/C15), LVDS0_D2N/P (D16/C16), LVDS0_CLKN/P_83MHz (D17/C17), LVDS0_D3N/P (D18/C18), LVDS0_D4N/P (D19/C19), LVDS1_D0N/P (B14/A14), LVDS1_D1N/P (B15/A15), LVDS1_D2N/P (B16/A16), LVDS1_CLKN/P_83MHz (B17/A17), LVDS1_D3N/P (B18/A18), LVDS1_D4N/P (B19/A19)

Check IC3302 and its peripheral control circuits.

YES

Is the above-mentioned LVDS signal output to connector P2601? NO Check the line between IC3302 and P2601.

YES

Similarly, is LCD controler's control signal normal? NO Please check each control signal of DET_POW (DET_PNL12V),

YES PANEL_UNIT: Is the LVDS signal input to connector LW of the panel module?

NO NO Wire harness (LW) is checked.

(IC2002, IC3501, IC3502, X3302, etc.)

PE. (PNL_EN)

YES Check the panel module.

Does not the picture come out when VHF/UHF is received?

Is the video signal (TUNER_CVBS) output from pin (16) of TUNER (TU1101)?

YES Is the video signal (TUNER_CVBS) sent to pin (AD29/ TU_CVBS) of IC3302 (Digital AV decode & Main CPU)?

YES Refer to “The picture doesn't appear in all modes.”

Does not the picture come out when DTV is received?

No picture on the display (2)

NO Check the tuner and its peripheral circuits.

Replace as required.

NO Check the line between TU1101 and IC3302. (Q1106, etc.)

No picture on the display (3)

Refer to “No sound (during the reception of TV (DIGITAL) broadcasting).”

No picture on the display (4)

Does not the picture come out when DTV (Satellite) is received?

Refer to “No sound (during the reception of TV (DIGITAL-Satellite) broadcasting)”.

7 – 8

LC-60LE822E/LC-60LE822ERU

[External input EXT1] No picture on the display (5)

Does not the picture of the CVBS signal input to EXT1 go out?

Is CVBS signal sent to pin (14) of EXT1 (SC505)? NO Check the setting of an external input device that connects with

YES Is CVBS signal from EXT1 (SC505) sent to pin (AG29/ SC1_CVBS_Y) of IC3302 (Digital AV decode & Main CPU)?

YES Refer to “The picture doesn't appear in all modes.”

[External input EXT1] No picture on the display (6)

Does not the picture of the Y/C video signal input to EXT1 go out?

Is Y/C video signal sent to pins (14)/Y and (4)/C of EXT1 (SC505)?

NO Check the line between SC505 and IC3302.

NO Check the setting of an external input device that connects with

EXT1.

YES Is Y/C signal from EXT1 (SC505) sent to pins (AG29/ SC1_CVBS_Y) and (AG28/SC1_C1) of IC3302 (Digital AV decode & Main CPU)?

YES Refer to “The picture doesn’t appear in all modes.”

[External input EXT1] No picture on the display (7)

Does not the picture of the R/G/B signal input to EXT1 go out?

Is RGB1 signal sent to pins (4)/RGB_IN_RED/C, (6)/ RGB_IN_GREEN and (8)/RGB_IN_BLUE of EXT1 (SC505)?

YES Is RGB1 signal from EXT1 (SC505) sent to pins (AH22/RED1), (AJ22/GREEN_1) and (AJ21/BLUE_1) of IC3302 (Digital AV decode & Main CPU)?

YES Refer to “The picture doesn’t appear in all modes.”

NO Check the line between SC505 and IC3302.

NO Check the setting of an external input device that connects with

EXT1.

NO Check the line between SC505 and IC3302.

7 – 9

LC-60LE822E/LC-60LE822ERU

[External input EXT2] No picture on the display (8)

Does not the picture of the CVBS signal input to EXT2 go out?

Is a CVBS signal input to pin (3) of EXT8 (J505)? NO Check the setting of an external input device that connects with

YES Is CVBS signal sent to pin (AE29/CVBS_IN) of IC3302? NO Check the line between J505 and IC3302.

YES Refer to “The picture doesn't appear in all modes.”

[External input EXT3] No picture on the display (9)

Does not the picture of the component video signal input to EXT3 (15pin-D-SUB terminal) go out?

Is it selected “Component” by the Audio setup under MenuSetup-Option-Input terminal setting - Input select?

NO Set the “Component”.

EXT2.

YES Is a COMPONENT video signal input to pins (1)/PC_R_COM, (2)/PC_G_COM, (3)/PC_B_COM of EXT3 (SC501)?

YES Is COMPONENT signal sent to pins (AJ17/PC_R_CM), (AJ16/ PC_G_CM) and (AJ15/PC_B_CM) of IC3302?

YES Refer to “The picture doesn't appear in all modes.”

[External input EXT3] No picture on the display (10)

Does not the picture of the DVI (ANALOG) video signal input to EXT3 (15pin-D-SUB terminal) go out?

Is it selected “PC (RGB)” by the Audio setup under Menu-SetupOption-Input terminal setting - Input select?

YES Are the video signal and the synchronized signal input from pin

(1, 2, 3)/(PC_R, G, B), (14 and 13)/(V, H.Sync) of EXT4 (SC501)?

YES Are the video signal and the synchronized signal input from pins

(AK17/PC__R) (AK16/PC__G) (AH15/PC__B) and (AK14/ PC_HSYNC) (AJ14/PC_VSYNC) of IC3302 (Digital AV decode & Main CPU)?

NO Check the setting of an external input device that connects with

EXT3.

NO Check the line between SC501 and IC3302.

NO Set the “PC (RGB)”.

NO Check the connection and setup with the external DVI devices.

NO Check the line between SC501 and IC3302.

YES Refer to “The picture doesn't appear in all modes.”

7 – 10

LC-60LE822E/LC-60LE822ERU

[External input HDMI-1/2/3/4] No picture on the display (11)

Does not the picture/sound of the HDMI signal input to HDMI-1/2/3/4 go out?

Is the Hot plug detection function output from pin (19) of the HDMI-1 (SC1503) normal?

NO Check the line between SC1503 and pin (45) of IC1504 (HDMI-

SW).

Is the Hot plug detection function output from pin (19) of the HDMI-2 (SC1502) normal?

Is the Hot plug detection function output from pin (19) of the HDMI-3 (SC1501) normal?

Is the Hot plug detection function output from pin (19) of the HDMI-4 (SC1505) normal?

YES

Is EDID data pins (44/HDMI1_SCL), (43/HDMI1_SDA) of IC1504 accessed, and is it read from pins (15, 16) of a HDMI-1 (SC1503)?

Is EDID data pins (40/HDMI2_SCL), (39/HDMI2_SDA) of IC1504 accessed, and is it read from pins (15, 16) of a HDMI-2 (SC1502)? Is EDID data pins (34/HDMI3_SCL), (33/HDMI3_SDA) of IC1504 accessed, and is it read from pins (15, 16) of a HDMI-3 (SC1501)?

Is EDID data pins (30/HDMI3_SCL), (29/HDMI3_SDA) of IC1504 accessed, and is it read from pins (15, 16) of a HDMI-4 (SC1505)?

YES Is TMDS signal input into pins (20, 19/HDMI1_CLKP/N), (22,21/

HDMI1_D0P/N), (24, 23/HDMI1_D1P/N), (26, 25/HDMI1_D2P/N) of IC1504 from HDMI-1 (SC1503)?

Is TMDS signal input into pins (12, 11/HDMI2_CLKP/N), (14, 13/ HDMI2_D0P/N), (16, 15/HDMI2_D1P/N), (18, 17/HDMI2_D2P/N) of IC1504 from HDMI-2 (SC1502)?

Is TMDS signal input into pins (2, 1/HDMI3_CLKP/N), (4, 3/ HDMI3_D0P/N), (6, 5/HDMI3_D1P/N), (8, 7/HDMI3_D2P/N) of IC1504 from HDMI-3 (SC1501)? Is TMDS signal input into pins (66, 65/HDMI4_CLKP/N), (68, 67/ HDMI4_D0P/N), (70, 69/HDMI4_D1P/N), (72, 71/HDMI4_D2P/N) of IC1504 from HDMI-4 (SC1505)?

NO Check the line between SC1502 and pin (41) of IC1504 (HDMI-

SW).

NO Check the line between SC1501 and pin (35) of IC1504 (HDMI-

SW).

NO Check the line between SC1505 and pin (31) of IC1504 (HDMI-

SW).

NO Check the setting of an external input device that connects with HDMI-1/2/3/4.

NO Is access possible in the exchange of IC1504?

Check the peripheral circuit of SC1502/1503/1505/1501and IC1504.

NO Check the line between HDMI-1 (SC1503) and IC1504.

NO Check the line between HDMI-2 (SC1502) and IC1504.

NO Check the line between HDMI-3 (SC1501) and IC1504.

NO Check the line between HDMI-4 (SC1505) and IC1504.

YES Are TMDS_Rx and the I2C_SINK signal output from IC1504 respectively?

Pins (62, 63/SW_TMDS_CLKP/N), (60, 61/SW_TMDS_D0P/N), (58, 59/SW_TMDS_D1P), (56, 57/SW_TMDS_D2P)

YES Is the TMDS_Rx/ I2C_SINK signal input to IC3302 (Digital AV

decode & Main CPU)? Pins (AK6, AJ6/SW_TMDS_CLKP/N), (AK7, AJ7/ SW_TMDS_D0P/N), (AK8, AJ8/SW_TMDS_D1P/N), (AK9, AJ9/ SW_TMDS_D2P/N) from IC1504

YES Refer to “The picture doesn't appear in all modes.” or “No sound output in all modes.”

NO Check the IC1504 and peripheral circuits.

NO Check the line between IC1504 and IC3302.

7 – 11

LC-60LE822E/LC-60LE822ERU

<During external connection> No picture on the monitor

No picture appears on EXT1connected monitor during the ATV/DTV reception.

Is CVBS signal output into pin (2) of EXT1 (SC505)? YES Check the setting of an external input device that connects with

Is CVBS signal output to pin (2) of IC504? YES Check the line between SC505 and IC504.

Is TU_OUT_CVBS_MUTE [pin (1) of IC504] at “H”? YES Check the peripheral circuits of IC3302.

Is CVBS signal input to pin (6) of IC504? YES Check the IC504 and their peripheral circuits.

NO Is CVBS signal output to pin (A27) of IC3302 (Digital AV decode & Main CPU)?

YES Check the line between IC504 and IC3302.

EXT1.

NO In the case that No picture appears on EXT1connected monitor during the ATV reception., refer to (A) In the case that No picture appears on EXT1connected monitor during the DTV reception., refer to (B)

(A) (B) Refer to “No picture on the display (2)” Refer to “No picture on the display (3)”

[External input Network] No picture on the display

Does not the signal input to Network go out?

Does the signal in/output to pins (1), (2), (3), (4) of LAN-jack (J9501)?

YES Does the signal in/out to pins (12, 11/TX+-), (10, 9/RX+-) of IC9501?

YES Does the signal in/output to pins [18, 19, 47, 29, 41, 27, 23, 22/ ONDA6~13], [21, 20, 35, 36, 38, 39, 34/ONDD8~14], [28, 33/

N_ONDCE0, N_ONDCE1] of LAN-jack (J9501)?

YES Does the signal in/output to pins [A8, B8, C9, C8, A7, F10, A4, B4/ONDA6~13], [D13, F13, D11, E11, F12, E12, E13/

ONDD8~14], [C6, B3/N_ONDCE0, N_ONDCE1] of IC3302 (Digital AV decode & Main CPU)?

NO Check the interface device and peripheral circuits. (power-LED of

hub, LINK-LED of hub)

NO Check the line between J9501 and IC9501.

NO Check IC9501 and its peripheral circuits.

NO Check the line between X9501 and IC9501.

Check the crystal X9501. (SCA219WJ)

YES Check IC9501 and its peripheral circuits.

7 – 12

LC-60LE822E/LC-60LE822ERU

No light (Back Light doesn't light)

Is the AC cord connector tightly connected to the set? NO Reconnect the AC cord tightly and turn on the power again.

YES Are the wire harnesses and other cables properly connected in the set?

YES Does Power starts up (central Icon LED lights up)? NO Refer to “No power (central Icon LED failure to light up) or no

YES Is there the pins (12/PNL_POW) of P9601 at “H”? NO Check the power unit, and the signal line between PNL_POW

YES Is there the pins (8/STB) of P9602 at “H”? NO Check the power unit, and the signal line between STB and

YES Replace the power unit.

NO Reconnect the wire harnesses and other cables properly in the

set.

startup (central Icon LED failure is flashing)”

and IC3302.

IC2002.

Does a single or several vertical stripes appear on the LCD screen?

The backlight functions. Does not the image come out in the LCD screen (screen black)?

Does a single or several horizontal stripes appear on the LCD screen?

Does the entire LCD screen look whitish all over?

LCD Panel failure (1)

Do luminescent or black dots appear on the screen?

Replace the LCD panel or the power unit.

LCD Panel failure (2)

Does the QS drive function?

Replace the LCD_CONT_UNIT.

Is the on-screen image rippling or distorted?

Is there any portion which some screens were darkish or became whitish?

Are the data bit dropout? (No solution even when turning on and off the QS drive)

Does all LED of one line are not lighting?

Is the gamma correction as specified?

7 – 13

LC-60LE822E/LC-60LE822ERU

[2] LED flashing specification at the time of the error

Display method

• Refer to Table 1.

• LED that can be used is only one of the central icons.

This expresses the error situation by combining blinking at low speed and blinking at high speed.

• For this model, the blinking pattern displayed first is only a low-speed blinking.

This expresses a rough content of the error.

• For this model, details are displayed by high-speed blinking

This expresses details of the error.

Details are distinguished by the blinking frequency.

• It doesn't return to the outline display again (blink at low speed) by pushing the MENU key (The toggle is not done).

Please confirm “MONITOR ERR CAUSE” of the adjustment Process mode (1/21), when the error doesn't reproduce by having returned from the error.

• The process of the upgrade is expressed by the brightness of point LED that smoothness changes.

• The upgrade completion is expressed by the LED brightness that changes in a staircase pattern.

LED flashing method

by pushing remote control MENU key.

Central icons

400ms

By pushing remote control MENU key.

Central icons

400ms

Central icons

1600ms

OFF

1600ms

300ms

100ms

OFF

500ms

Central icons

1000ms

500ms

OFF

1000ms 1000ms 1000ms

7 – 14

LC-60LE822E/LC-60LE822ERU

Table 1. Concrete flashing pattern

Expression for a rough content Expression for Details

Item

Lamp system failure Flashes once — Flashes once Flashes once Lamp error

Power PWB failure Flashes twice — Flashes twice Flashes once Power Error 1 AC_DET error (*2)

(Power failure, etc.) Flashes twice Power Error 2 UR+13.5V error (*2)

Main PWB failure Flashes 3 times — Flashes 3 times Flashes once Initial communication error (Communication Flashes twice Start-up confirmation communication error failure, etc.) Flashes 3 times Regular communication error

Others Flashes 4 times — Flashes 4 times Flashes once Temperature error

Upgrade executing smoothness

Upgrade completion a staircase

Upgrade failed — Flashing

ROM data failure — Flashing

*2: It depends on the system. The power supply error suitable for the product is defined.

*3: For details, refer to ERROR STANDBY CAUSE on the adjustment process screen.

*4: If the boot section is abnormal, there is no flashing (flashing disabled).

low-speed

blinking

changes.

pattern.

high-speed

blinking

— — — Version upgrading

— — — Version upgrade succeeded

(Continuous)

low-speed

blinking

— — Version upgrade failed

— — Start-up after failing version upgrade (*4)

high-speed

blinking

Flashes 3 times Power Error 3 D3.3V error (*2) Flashes 5 times Panel power supply error

Flashes 5 times Other communication error

Flashes twice Sync error Flashes 3 times Notification from the main microprocessor

(*3)

Cause

MONITOR ERR STBY table

Outline: Communication/Power failure detected by the monitor microprocessor (IC2002) is stored on EEPROM, states can be confirmed in the

adjustment process mode.

Location: Page 1/21 of the adjustment process mode: MONITOR ERR CAUSE “0” if there is no error. It is cleared to 0 on the page (2/21) of the

adjustment process mode.

Display Error description

02 Start-up communication error 2 Initial communication from the main CPU is not received. 03 Start-up communication error 3 Only the initial communication is received. 04 Start-up communication error 4 Until panel information request reception 05 Start-up communication error 5 Until initialization completion reception 06 Start-up communication error 6 Until version notification transmission 07 Start-up communication error 7 Until start-up information notification transmission 08 Start-up communication error 8 Until start-up information response reception

09 Start-up communication error 9 Until time-out setting reception 0A Communication error A REQ time-out 0B Communication error B Restart time-out during the beginning of time acquisition start-up 0C Communication error C Ending sequence time-out 0D Communication error D Preset start-up time-out during completion 0E Communication error E Download start-up time-out

0F Communication error F Time acquisition time-out

11 Communication error H Regular communication time-out

16 Panel-related error Lamp failure 1A Other error 2 Monitor temperature failure 1D Power supply error 1 PS_ON (AC_DET) failure 1E Power supply error 2 D_POW (DET_13V) failure

1F Power supply error 3 D_POW (DET_D3V3) failure

21 Power supply error 5 Panel power failure

23 Other error 3 Error standby request from the main CPU

7 – 15

LC-60LE822E/LC-60LE822ERU

LED flashing timing chart at the time of the error

100ms 400ms 1.6sec

1) Low-speed blinking

Error type Expression of Central Icon LED Note: Pins are monitor microprocessor pins (IC2002).

Lamp failure low-speed blinking Flashes once

Power failure low-speed blinking Flashes twice

Communication failure with main CPU low-speed blinking Flashes 3 times

Others low-speed blinking Flashes 4 times

2) Lamp failure details (Low-speed blinking: Flashes once + High-speed blinking)

Error type Expression of Central Icon LED Note: Pins are monitor microprocessor pins unless otherwise

Lamp failure

Flashes once (High speed)

H: ON

L: OFF H: ON

L: OFF

H: ON

L: OFF

H: ON

L: OFF

Refer to “Lamp failure details”. LOW/High blinking by pressing the [MENU] key on the remote control.

Refer to “Power failure details”. LOW/High blinking by pressing the [MENU] key on the remote control.

Refer to “Communication failure details”. LOW/High blinking by pressing the [MENU] key on the remote control. Communication line failure or main CPU communication failure.

Refer to “Other failure details”. LOW/High blinking by pressing the [MENU] key on the remote control.

specified (IC2002).

ERR_PNL (40pin): Abnormal H. Confirmed after 8 consecutive detections at 64ms intervals (detected only when the backlight is on).

NOTE: After 5 detection counts, the lamp cannot be activated

except in the monitoring process. To confirm the problem, “Lamp Error detection off-mode” is prepared. This mode compulsorily starts the set disregarding the count. Please refer to [ADJUSTMENT PROCEDURE - 7. Lamp Error detection]

3) Power failure details (Low-speed blinking: Flashes twice + High-speed blinking)

Error type Expression of Central Icon LED Note: Pins are monitor microprocessor pins unless otherwise

specified (IC2002).

PS_ON AC_DET failure Flashes once (High speed)

SM_POW Main 13V failure Flashes twice (High speed)

D_POW Digital 3.3V failure Flashes 3 times (High speed) PANEL_POW Panel 12V failure Flashes 5 times (High speed)

H: ON

L: OFF

H: ON

L: OFF

H: ON

L: OFF

H: ON

L: OFF

AC_DET (72pin: Abnormal (L). If error is detected during start-up or operation, the power is turned on again by interrupt handling (instantaneous blackout processing).

DET_13V (38pin): Abnormal (L). Main 13V is not applied. If error is detected during start-up or operation, the power is turned on again by polling.

DET_D3V3 (36pin): abnormal (L). Digital 3.3V is not applied.

If error is detected during start-up or operation, the power is turned on again by polling. DET_PNL12V (35pin): abnormal (L). DET_PNL12V is not applied.

Detection starts after receiving command from Panel Power ON. The power is turned off by polling.

7 – 16

LC-60LE822E/LC-60LE822ERU

4) Communication failure details (Low-speed blinking: Flashes 3 times + High-speed blinking)

Error type Expression of Central Icon LED Note: Basically, debug print logs are analyzed or

communication logs are analyzed by a bus monitor.

Initial communication reception failure Flashes once (High speed)

Start-up confirmation reception failure Flashes twice (High speed)

Regular communication failure

Flashes 3 times (High speed) Other communication failure

Flashes 5 times (High speed)

5) Other failure details (Low-speed blinking: Flashes 4 times + High-speed blinking)

Error type Expression of Central Icon LED Note: Pins are monitor microprocessor pins unless otherwise

Monitor temperature failure

Flashes once (High speed)

Main failure

Flashes 3 times (High speed)

H: ON

L: OFF

H: ON

L: OFF

H: ON

L: OFF

H: ON

L: OFF

H: ON

L: OFF

H: ON

L: OFF

Initial communication from the main CPU is not received. (Request for the monitor model No. is not received.) → Communication line failure or main CPU start-up failure

Start-up reason confirmation from the main CPU cannot be received. (Startup communication until start-up reason notification command is not received.) → Main CPU start-up failure or monitor microprocessor reception failure

Regular communication that is performed at 1 second intervals in the normal operation is interrupted. → Main CPU operation failure or monitor microprocessor reception failure

When a request (PM_REQ=H) is sent from the main microprocessor, the request command is not output from the main CPU, etc. → Main CPU operation failure or monitor microprocessor reception failure

specified (IC2002).

If the panel temperature is 60°C or more for 15s or more in a row, CAUTION appears on the OSD (flashes in red in the lower right screen). If the panel temperature is 60°C or more for 25s or more in a row, error standby is activated. (MONITOR MAX TEMP on page 13/21 of the adjustment process: Change AD value for temperature failure): Thermistor

Main microprocessor detection error (CPU temperature error, etc.) Details are displayed on page 1/21 of the adjustment process for the main microprocessor.

7 – 17

LC-60LE822E/LC-60LE822ERU

LC-60LE822E

CHAPTER 8. MAJOR IC INFORMATIONS

Service Manual

[1] MAJOR IC INFORMATIONS

REF NO Name Part Code Description

[MAIN UNIT]

IC8401 RH-iXC147WJQZQ Flash This IC is 512MB NAND flash memory.

This IC stores the software data that processes the system of TV such as the graphic processing, the LCD controls, and backlights etc.

IC3302 RH-iXC951WJN1Q Main CPU This IC is Video Processor & MAIN CPU.

IC2002 RH-iXC786WJQZQ

for service (RH-iXC786WJNYQ)

IC3501/3502 RH-iXC754WJQZQ DDR This IC is 1GB DDR2 SDRAM.

IC501 VHi24LC21AT-1Y

for service (RH-iXD108WJQZS)

IC8455 VHiR24064AS-1Y 64K bit E2PROM The BR24S64W is a 64Kbit-2-wire (I2C bus type) serial EEPROM that

IC506 VHiM3221EIP-1Y RS232C-DRIVER The MAX3221E is a single driver, single receiver RS-232 solution

IC4405 VHiMT8295AE-1Q CI controler This is a control IC for PCMCIA cards. This controls information on IC

IC2004 VHiR24002AS-1Y 2K bit E2PROM This is a 2Kbit-2-wire (I2C bus type) serial EEPROM that can be pro-

IC1504 VHiSii9287+-1Q HDMI_Port _Processor The SiI9287 HDMI port processor is the second generation of HDMI

IC1106 VHiSTV0297E-1Q COFDM The STV0297E’s demodulator is a complete QAM (quadrature ampli-

IC9501 VHiKSZ8041T-1Y Ethernet Bus Interface This IC is a single supply 10Base-T/100Base-TX Physical Layer

IC2701 VHiYSS951VZ-1Y Sound processor This IC is the Sound processing LSI with built-in two DSP (MDSP/

IC2702/2703 VHiYDA164QZ-1Y Audio-AMP This IC is digital audio power amplifier with digital audio interface.

IC1301 RH-iXC563WJQZY LNB supply and control It is IC for amplifying the feeble electric wave sent from satellite broad-

UCOM The monitor microprocessor is intended to communicate with the main

1K bit E2PROM This IC is a 1Kbit-2-wire (I2C bus type) serial EEPROM that can be

In this IC, the decode processing and the video signal processing are done. Moreover, OSD is generated here and added to a picture signal.

CPU and to operate the system. It also controls power of the entire system.

This IC operates as a memory of IC3302 (Video Processor). ***

programmed electrically. The EEPROM chip stores the EDID data of PC input. This data is controlled through I2C signals.

can be programmed electrically. This IC stores the menu data and the adjustment value data of adjustment process mode etc. The data is given out by commands from the main microprocessor.

operating from a single Vcc supply. The RS-232 pins provide IEC G1000-4-2 ESD Protection. The device meets the requirements of TIA/EIA-232-F and provides the electrical interface between an asynchronous communication controler and the serial-port connector. The charge pump and four small external capacitors allow operation from a single 3V to 5.5V supply.

cards inserted into the PCMCIA card slot (SC4401) or information on software version upgrade cards saved on flash memories to transfer the data to CPUs and memories.

grammed electrically. This IC stores the menu data and the adjustment value data of adjustment process mode etc. The data is given out by commands from the main microprocessor.

devices that support revision 1.3 of the HDMI specification. The main feature is as follows.

1) 4-input, 1-output HDMI port processor.

2) Integrated TMDS receiver and transmitter cores capable of receiving and transmitting at 2.25Gbps.

3) Supports video resolutions up to 1080p, 60Hz, 12bit or 720p/1080i, 120Hz,12bit.

4) Receiver fully comply with DVI1.0, HDCP1.1 and HDMI1.3 specifications.

tude modulation) demodulation and FEC (forward error correction) solution that performs IF to transport stream block processing of QAM signals. It is intended for the digital transmission of compressed television, sound, and data services over cable.

Transceiver, which provides MII/RMII/SMII interfaces to transmit and receive data.

SDSP) and FM (frequency modulation) oscillators. This IC process sound signal and sent it to AMP for Speaker and Woofer

The power-supply voltage is corresponded to A.8V~18V and the maximum output is 20Wx2ch.

casting on the level which can treat a decoder, and changing and processing signal.

8 – 1

LC-60LE822E/LC-60LE822ERU

— MEMO —

8 – 2

LC-60LE822E

CHAPTER 9. OVERALL WIRING/BLOCK DIAGRAM

[1] OVERALL WIRING DIAGRAM

OVERALL WIRING DIAGRAM

LC-60LE822E/LC-60LE822ERU

Service Manual

Woofer

㧸㧱㧰˴㨁㧺㧵㨀

QCNW-K570WJQZ

ޣL1ޤ

ޣL2ޤ

POWER Unit

ޣASޤ

ޣACޤ

POWER

QCNW-K556WJQZ

QACCKA053WJPZ(For E/RU) QACCBA102WJPZ(For UK)

LCD-Controler

ޣLWޤ

QCNW-K977WJQZ

ޣPLޤ

ޣLBޤ

ޣPDޤ

ޣPLޤ

ޣLBޤ

P9602

QCNW-K980WJQZ

ޣPDޤ P9601

QCNW-K979WJQZ

ޣSPޤ

P2701

QCNW-K568WJQZ

ޣLWޤ

QCNW-K578WJQZ

QCNW-K567WJQZ

P2601

ޣRAޤ P2005

ޣRLޤ

P2006

1 9

1 8

1 5

SC CARD Connector

1 3

ޣSBޤ P2702

91 1916

20 19

SC8454

TUNER

MAIN Unit

DVB-S

TUNER

J9501

Audio out

SC501

PC/COMP

D-SUB

J501

HDMI/PC/COM

Audio

SC1503

HDMI1

SC1502

HDMI1

SC1501

HDMI1

SC1505

HDMI1

CI card slot

SC4401

J3301

USB

LAN

J504

H/P

J505

AV-IN

USB

HDM I HD MI

HDM I

RS232C

D-SUB 9pin

SC504

OpticalOut

D520

SCART

SC505

QCNW-K569WJQZ

Touch Key

R/C Unit

ޣRAޤ

ޣKMޤ

Icon Unit

ޣRIޤ

LOGO

ޣRLޤ

1097654

1311 191816151412 17

9 – 1

LC-60LE822E/LC-60LE822ERU

MAIN

Thermister

RGB/HDMI

Audio

(Mini Plug)

[SP]

P2701

EXT-SP

OPTICAL

OUT

27.000MHz

X3302 X'tal

X2002

Xtal

TU1101 Analog/ Digital

Tuner

+5V

J3301

USB

IC506

RS232C TxRx

M3221EIP

RS-232C

+3.3V

IC501

EEPROM

BU+3.3V

IC8455

EEPROM

64kbit

+3.3V

HDMI 1

[RA] P102(5p)

R/C

D-SUB

RGB

/Component

MENU/POWER

INPUT/CHANNEL

VOLUME

IC3501

DDR2(1066M)

1Gbit

IC1106

Demodulator

DVB-C

STV0297E

+3.3V

+1.2V

X1101

Xtal

27.000MHz

CVBS/LR

RGB

TUNER_OUT

LR_OUT

FS/FB

CVBS/LR

CARD

INTERFACE

D+5V

IC3301

LINE Reg.

BD6538G

+3.3V

+8.0V

+3.3V

+1.8V

+1.25V

+1.05V

BU+3.3V

IC2001

Reset

BU+3.3V

From CPU

IC2004 EEPROM

2kbit

BU+3.3V

+3.3V

IC3502

DDR2(1066M)

1Gbit

IC4405

CI Controller

MT8295

HDMI 2

HDMI 3

HDMI 4

+3.3V

+1.8V

X4401

Xtal

27.000MHz

IC1102

IF_DEMUX

LV4053FT

IC503

OPT OUT T7SET08

From CPU

From CI

IC4401

IC4402

IC4403

LCX244FT

+3.3V

J9501

Ethernet for LAN

IC9501

Ethernet Bus

Interface

KSZ8041T

+3.3V

From CPU

SC8454

SD Connector

for Time Shift

IC2701

DSP

YSS951VZ

IC2702

Woofer AMP

(0.1CH)

VHIYDA164QZ

[SB]

P2702

EXT-SP

Woofer

+3.3V

+1.8V

+13V

[KM] J1(8p)

32.768kHz

IC1505

OPT OUT

AHC1G08

IC8452

LCX157FT

OPC sensor

R/C receiver

TU1301

Satellite

Tuner

From CPU

IC4409 LCX157

[RA] P2005 (15p)

IC2601

Spliter

HC2G66DP

[LB]

P9602

(9pin)

IC9601

Spliter

HC2G66DP

[LW]

P2601 (41p)

From CPU

[PD]

P9601

(12PIN)

LED

[RI] P202 (2p)

ICON

LOGO

[RL] P2006(3p)

[RL] P201(3p)

[2] SYSTEM BLOCK DIAGRAM

SYSTEM BLOCK DIAGRAM

EXT2

EXT1

(SCART1)

SPEAKER

CVBS CVBS_L/R

CVBS

L/R S-Video RGB

TUNER CVBS OUT

TUNER OUT L/R

FAST_SW

SLOW SW

From CPU or UCON

Mute

SP AMP(2CH) VHIYDA164QZ

IC2703

Mute

I2C_0 (400KHz)

AMP_DATA_LR

LRCK/BCLK/MCLK

AMP_DATA_ SW

From CPU or

UCON

IC504

TUNER OUT

MM1506XN

TU_CVBS_OUT_MUTE

I2C_0 (400KHz)

UCOM_RST

RS_BUF_CNT

I2C_0

B_STATUS

(400KHz)

PNL_EN

PNL_ROM_EN

O_S_SET FRAME

DET_SYNC

VCOM_WP

TCON_I2C

B_STATUS

DET_POW

PE PE

ROM_WP

CNVss

P_TS_SW

RF IN

Headphone/

EXT3/HDMI2

EXT3 Comp/RGB

Audio

Out

TS_CIIN

CVBS

IF_AGC

TUNER_I2C

I2C

SIF

(400KHz 3.3V)

TUNER_RESET

RGB_LR_IN

OPT_OUT

Mute

From CPU or

UCON

Mute

From CPU or UCON

D_IF IN-/+

DVB_TC_IFSW

CI_D[7:0] /CI_A[14:0]

TS_CIIN

AGC

TS_CIOUT

DVB_CS_SW

FE_RST

I2C_0 (400KHz)

PDD[7:1]

TxD/RxD

No.9 pin RC Passthrough

DDC_4

Mute

CEC_0

From CPU or

UCON

HDMI_4

DDC_3 HDMI_3

DDC_2 HDMI_2

DDC_1 HDMI_1

IC1504 HDMI-SW

SII9287B

I2C_0_400KHz

CI_CEB, CI_RB

CI_CNT_RESET

I2S(DATA/LRCK/BCLK)

TUNER OUT_L/R

HP/MONI_L/R

CVBS_L/R

SCART_L/R

RGB_L/R

SPDIF

N_CPU_RST

TUNER CVBS OUT

ADIN5

DAC OUT1

DAC OUT2

CI-CPU_IN

CI-CPU_OUT IF_AGC

D_IF_IN-/+ TUNER_I2C

I2C_0 I2C_1 I2C_2

RGB HV RGB/Component in

DDC_I2C_1 HDMI_1

Audio out

SIF

Audio in

DTV/SPDIF

RESET

FBIN

RGB

ADIN0

S-Video

IC3302

MT5391W(FHD)

H.264 / CI+

Digital AV decode & Main CPU

CPU_UARXD0_RS

IC8401

NAND FLASH

512Gbit

IXC147WJQZQ

CPU_UATXD0_RS

SPI_FLASH

CVBS

PM_REQ, CBOOTS

STB_CPU

SDIOCMD/SDIOCLK

SDI0㨪3

USB_0

CPU_UARXD2_UCOM

CPU_UATXD2_UCOM

LVDS OUT

PWM_0

PWM_1

ONDD8㨪15ONDA6㨪

CNVss

OFL1

OFL2

IC2008

Gate

7WH126FU

RxD,TxD_CPU

X2001

Xtal

RxD,TxD

UART

THERMO

A/D

20MHz

PM_REQ,

N_SRESET

CEC_0

EEPROM_SCL/SDA

FRAME

O_S_SET

DET_SYNC

IC2002

M16C/64A

IXC786WJ

SUB MCU

ERR_PNL

AC_DET

PS_ON

PNL_POW

I2C

RC,OPC

KEY_POW,KEY_SCL,KEY_SDA

DET_PNL12V

STB

ILL_CTRL1

PNL_I2C_EN

DET_13V,DET_3.3V

1) BU3.3V

2) D3.3V

3) D5.6V

4) D5V

5) D+1.8V

6) D+1.05V

7) STB+3.3V

8) S+8V

9) CPU+1.2V

POWER CIRCUIT

PNL_WP

UR13V

S13V

BU5V

ERROR

VON

OFL

DMMER

AC_DET PS_ON PNL_POW

KEY

1097654

1311 191816151412 17

9 – 2

PartsGuide

LC-60LE822E/LC-60LE822ERU

PARTS GUIDE

No. S90L460LE822E

LCD COLOUR TELEVISION

LC-60LE822E

MODELS

[1] PRINTED WIRING BOARD

ASSEMBLIES

[2] LCD PANEL MODULE

[3] CABINET PARTS

LC-60LE822ERU

CONTENTS

[4] SUPPLIED ACCESSORIES

[5] PACKING PARTS

(NOT REPLACEMENT ITEM)

[6] SERVICE JIGS

(USE FOR SERVICING)

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.

This document has been published to be used for after sales service only. The contents are subject to change without notice.

LC-60LE822E/LC-60LE822ERU

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[1] PRINTED WIRING BOARD ASSEMBLIES

N DKEYDF455FM07 CK N S MAIN Unit N DUNTKF494FM02 AP N S R/C, LED Unit N DUNTKF493FM03 AP N S ICON Unit N DUNTKF493FM04 AQ N S LOGO Unit N RUNTKA761WJQZ N S TOUCH SENSOR Key Unit N RUNTKA729WJQZ N S POWER/LED CONTROL Unit N RUNTK4512TPZA BV N X LCD CONTROL Unit

[2] LCD PANEL MODULE

N R1LK600D3LW20Z ET N S 60" LCD Panel Module Unit

DESCRIPTION

[3] CABINET PARTS

1-9

1-8

2-9

2-1

2-3

2-2

2-8

1-3

1-1

1-6

1-4

1-5

1-4

1-2

1-7

2-4

2-5

2-7

2-6

MAIN

Unit

60" LED

PANEL Module

POWER/LED Drive Unit

LOGO

Unit

ICON

Unit

R/C, LED Unit

TOUCH

SENSOR

Unit

LC-60LE822E/LC-60LE822ERU

NO. PARTS CODE

[3] CABINET PARTS

1 CCABAC609WJ35 CD N S Front Cabinet Ass'y 1-1 Not Available - N - Front Cabinet 1-2 HDECQB420WJ3A S R/C Decoration Cover 1-3 HDECZA031WJSA S Front Decoration Plate 1-4 PSHEZA252WJZZ S Coner Tape, x4 1-5 PSHEZA256WJZZ S Up Side Tape 1-6 PSHEZA261WJZZ S Side Tape, x2 1-7 PSPAGA909WJZZ S Spacer 1-8 PSPAHC201WJZZ S Himelon, x4 1-9 PSPAZC528WJZZ S Spacer, x6

2 CCABBB701WE01 N S Rear Cabinet Ass'y 2-1 Not Available - N - Rear Cabinet 2-2 HiNDPD710WJSA AG N S Terminal Label (Side) 2-3 HiNDPD727WJSA AE N S Terminal Label (Bottom) 2-4 PSPAHC152WJ3Z AD S Himelon 2-5 PSPAHC159WJZZ AE S Himelon 2-6 PSPAHC160WJZZ AC J Himelon 2-7 PSPAHC194WJZZ AD S Himelon, x7 2-8 PSPAZC462WJZZ AE N S Spacer, x2 2-9 PZETKA539WJKZ BD N S Barrier Sheet

3 CPNLHA022WJ32 N S Glass Front Panel Ass'y

4 CANGKC709WJ01 BC S Support Ass'y

5 CDAi-A711WJ01 BR N S Stand Base Ass'y

6 GCOVAD699WJ3A AG S AC Cord Cover

7 GCOVAD702WJKA AW N S Support Cover

8 GCOVAD706WJSA AL N S Terminal Cover (Side)

9 GCOVAD709WJ1A AG N S ECO Switch Cover

10 GCOVAD711WJSA AK N S Terminal Cover (Bottom) 11 GCOVAD864WJ3A AZ N S Stand Cover 12 LANGFA776WJFW AK N J BL Support Angle 13 LANGKC694WJFW N S LCD Fixing Angle B-L 14 LANGKC696WJFW N S LCD Fixing Angle T-L 15 LANGKC697WJFW N S LCD Fixing Angle T-R 16 LANGKC698WJFW N S 17 LANGKC701WJFW AP N S Stand Angle, x2 18 LANGKD010WJFW AG S LCD Fixing Angle B-R 19 LHLDKA011WJKZ AD N J AC Cord Band 20 LHLDWA143WJKZ AC N J Holder, x4 21 LHLDWA294WJUZ AC N J Holder, x8 22 LHLDZA506WJKZ AC N J Spacer, x5 23 LX-BZA170WJF9 AC J Screw, x4 24 LX-BZA364WJF7 AB N J Screw, x4 (for Sub Woofer) 25 LX-BZA366WJZZ AD N S Screw, x6 (Support Angle) 26 LX-BZA391WJF7 AB N S Screw, x7 27 LX-NZA049WJFN AC N J Nut 28 NSFTZA362WJFW AB J PWB Angle, x4 29 PCLiCA004WJKZ AC J Rivet, x2 30 PCUSGA142WJKZ AF J Rubber Bush, x2 31 PMLT-A578WJZZ AE S Gasket, x2 32 PMLT-A634WJZZ AK N S Gasket, x2 33 PMLT-A636WJZZ AF N J Gasket 34 PMLT-A652WJZZ AF N S Gasket 35 PSPAGA888WJZZ AB N J Spacer, x4 36 PSPAGA932WJKZ AE S Spacer, x2 37 PSPAGA934WJKZ AD S Spacer, x2 38 PSPAH0053TPZZ AC N J Himelon, x2 39 PSPAHC160WJZZ AC J Himelon, x2 40 PSPAZC634WJZZ AC N S Spacer, x7 41 PZETKA538WJKZ BB S Barrier Sheet 42 PZETKA556WJKZ AE S Insulation Sheet (ECO) 43 PZETKA562WJKZ AF S Insulation Sheet (AC)

44 QACCKA053WJPZ AR N S AC Cord (Except for U.K. and Russia) 44 QACCBA102WJPZ AT N S AC Cord (for U.K.) 44 QACCKA053WJPZ AR N S AC Cord (for Russia) 45 QCNW-K556WJQZ AW N S Connecting Cord (AS) 46 QCNW-K567WJQZ AX N S Connecting Cord (RA) 47 QCNW-K568WJQZ AL N S Connecting Cord (SP) 48 QCNW-K569WJQZ AE N S Connecting Cord (RL) 49 QCNW-K570WJQZ AG N J Connecting Cord (SB) 50 QCNW-K578WJQZ AW N S Connecting Cord (LW) 51 QCNW-K977WJQZ AE N J Connecting Cord (PL) 52 QCNW-K979WJQZ AH N S Connecting Cord (PD) 53 QCNW-K980WJQZ AG N S Connecting Cord (LB) 57 QEARZ0057CEFW AB J Ground Part 58 RCORF0103CEZZ AK J Core 59 RSP-ZA474WJZZ AY N S Speaker (L/R), x2 60 RSP-ZA475WJZZ BA N S Speaker (Woofer) 61 TLABZC354WJZZ AB S Eco Label 62 TLABZC587WJZZ AE N S Quattron Label 63 XBBS740P06000 AA J Screw, x12 64 XBPS730P06WS0 AA J Screw, x33 65 XBPS730P10WS0 AA J Screw, x9 66 XBPS830P06WS0 AA J Screw, x19 67 XBPS830P14WS0 AB J Screw, x2

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

DESCRIPTION

LCD Fixing Angle B-MA, x4

LC-60LE822E/LC-60LE822ERU

NO. PARTS CODE

PRICE

RANK

[3] CABINET PARTS

68 XBPS840P12000 AB N S Screw, x3 69 XBPS950P12KS0 AC N S Screw, x4 70 XEBS940P10000 AB J Screw, x7 71 TLABN0134BMZZ N S Material Label

[4] SUPPLIED ACCESSORIES

Remote control unit ( x 1) “AAA” size alkaline battery ( x 2) Cable clamp ( x 1)

RGB component cable ( x 1) SCART cable ( x 1) AV cable ( x 1)

NEW

MARK

PAR T

DELIVERY

X12X13

DESCRIPTION

X14

Operation manual

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[4] SUPPLIED ACCESSORIES

X1 RRMCGA841WJSA AX N S Remote Control Unit X2 LHLDWA298WJKA AD J Cable Clamp X3 Not Available - - AAA size alkaline battery, x2 X4 TCAUZA408WJZZ N S Eco Direction (Except for Russia) X5 TCAUZA428WJZZ AC N S Caution Sheet X6 TiNS-E812WJZZ AV N S Operation Manual X6 TiNS-E813WJZZ AW N S Operation Manual (Except for U.K. and Russia) X7 TCAUSA034WJZZ AB S Caution Card (Except for U.K. and Russia) X8 TGAN-B078WJZZ AC S Guarantee Card (Except for U.K. and Russia)

X9 TGAN-B079WJZZ AC S Guarantee Coupon (Except for U.K. and Russia) X10 TGAN-A077WJZZ AE N J Guarantee Card (for Russia) X10 TGAN-A801WJZZ AD N S Guarantee Card (for U.K.) X11 TGAN-A802WJZZ AD N S AQUOS Care Plan (for U.K.) X12 QCNWGA158WJPZ AU N S SCART Cable X13 QCNWGA159WJPZ AM N S RGB Component Cable X14 QCNWGA160WJPZ AM N J AV Cable

DESCRIPTION

LC-60LE822E/LC-60LE822ERU

[5] PACKING PARTS (NOT REPLACEMENT ITEM)

X6 X7

X8 X9

S8 X2 X3

X12 X13 X14

S9 X4 X5

X6 X10 X11

LC-60LE822E/LC-60LE822ERU

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PAR T

DELIVERY

[5] PACKING PARTS (NOT REPLACEMENT ITEM)

S1 SPAKCF901WJZZ - N - Packing Case (Top)

S2 SPAKCF498WJZZ - N - Packing Case (Bottom)

S3 SPAKAA639WJZZ - N - Rear Pad

S4 SPAKPB550WJZZ - N - Wrapping Paper

S5 SPAKPB551WJZZ - N - Wrapping Paper (Stand)

S6 SPAKXC923WJZZ - N - Packing Add. (Top)

S7 SPAKXC928WJZZ - N - Packing Add. (Bottom)

S8 SSAKAA009WJZZ - - Polyethylene Bag

S9 SSAKAA111WJZZ - - Polyethylene BagÇP, x2

[6] SERVICE JIGS (USE FOR SERVICING)

N QCNW-G616WJQZ N J Main Unit to LCD Control Unit (LW) N QCNW-G625WJQZ N J Main Unit to Power Unit (PL) N QCNW-H184WJQZ N J Main Unit to Power Unit (PD) N QCNW-H185WJQZ N J Main Unit to Power (LED Drive) Unit (LB) N QCNW-K594WJQZ N J Main Unit to R/C, LED Unit (RA) N QCNW-K595WJQZ N J Main Unit to Speaker (SP) N QCNW-K596WJQZ N J Main Unit to Icon Unit (RL) N QCNW-K597WJQZ N J Main Unit to Woofer (SB)

DESCRIPTION

LC-60LE822E/LC-60LE822ERU

No Part of this publication may be reproduced, stored in a retrieval system, or transmitted in any from or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

Sep. 2010 SH. DS

SHARP CORPORATION AV Systems Group CS Promotion Center Yaita,Tochigi 329-2193, Japan

Sharp LC-60LE822E Schematic

Specifications and Main Features

Frequently Asked Questions

User Manual
