Sharp LC-52XS1E, LC-65XS1E, TU-X1E Operating Manual

Download

LC-52XS1E LC-65XS1E

TU-X1E

LCD COLOUR TELEVISION LCD-FARBFERNSEHGERÄT TÉLÉVISEUR COULEUR À ÉCRAN

CRISTAUX LIQUIDES (LCD)

TELEVISORE A COLORI LCD

ENGLISHDEUTSCHFRANÇAISITALIANO

LCD-KLEURENTELEVISIE TELEVISIÓN EN COLOR LCD TELEVISOR DE CRISTAL LÍQUIDO

OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUALE DI ISTRUZIONI GEBRUIKSAANWIJZING MANUAL DE MANEJO MANUAL DE OPERAÇÃO

NEDERLANDS

ESPAÑOL

PORTUGUÊS

SPECIAL NOTE FOR USERS IN THE U.K.

The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 13A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked which is also indicated on the pin face of the plug, must be used. Always refit the fuse cover after replacing the fuse. Never use the plug without the fuse cover fitted. In the unlikely event of the socket outlet in your home not being compatible with the plug supplied, cut off the mains plug and fit an appropriate type.

)5)

and of the same rating as above,

DANGER:

The fuse from the cut-off plug should be removed and the cut-off plug destroyed immediately and disposed of in a safe manner. Under no circumstances should the cut-off plug be inserted elsewhere into a 13A socket outlet, as a serious electric shock may occur. To fit an appropriate plug to the mains lead, follow the instructions below:

IMPORTANT:

The wires in the mains lead are coloured in accordance with the following code:

Blue: Neutral Brown: Live

As the colours of the wires in the mains lead of this product may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:

• The wire which is coloured blue must be connected to the plug terminal which is marked N or coloured black.

• The wire which is coloured brown must be connected to the plug terminal which is marked L or coloured red. Ensure that neither the brown nor the blue wire is connected to the earth terminal in your three-pin plug. Before replacing the plug cover make sure that:

• If the new fitted plug contains a fuse, its value is the same as that removed from the cut-off plug.

• The cord grip is clamped over the sheath of the mains lead, and not simply over the lead wires. IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.

OPERATION MANUAL

“TV” when used in this manual means the Display and AVC System.

• The illustrations and the OSD in this operation manual are for explanation purposes and may vary slightly from the actual

•

ENGLISH

operations. The examples used throughout this manual are based on the LC-52XS1E model.

• This model is compatible with H.264 (MPEG4 H.264, MPEG4 AVC, MPEG4 AVC/H.264) compressed broadcasts.

• Refer to page 59 for the meaning of abbreviated terms.

•

ENGLISH

Contents ...........................................................................................1

Introduction ......................................................................................2

Dear SHARP customer ..............................................................2

Important Safety Precautions ..................................................... 2

Trademarks ................................................................................2

Remote control unit ...................................................................3

Part name .................................................................................. 4

Display (Front view/Side view) ..............................................4

AVC System (Front view/Rear view) ......................................4

AVC System (Bottom view)...................................................4

Preparation.......................................................................................5

Supplied accessories ................................................................. 5

Optional accessories ..................................................................5

Inserting the batteries.................................................................6

Using the remote control unit .....................................................6

Cautions regarding the remote control unit ...........................6

Quick guide ......................................................................................7

Initial installation overview...........................................................7

Before turning on the main power ..............................................8

Preparing the Display ...........................................................8

Setting the TV and antenna cables ....................................... 9

Turning on and running the initial auto installation .....................10

Plugging the AC cord to the AC outlet................................10

Power on and run the auto installation ...............................10

Initial auto installation ...............................................................11

Checking signal strength and channel strength (DVB-T/C)

Checking signal strength and channel strength (DVB-S) ..... 16

Watching TV ................................................................................... 17

Daily operation ......................................................................... 17

Switching on/off .................................................................17

Switching between digital, satellite and analogue

broadcasts ......................................................................17

Changing channels ............................................................17

Selecting an external video source .....................................17

Selecting a sound mode ....................................................17

EPG .........................................................................................18

EPG Overview ..........................................................................18

Useful settings for using EPG ................................................... 18

Selecting a programme using EPG ..........................................19

Timer recording using EPG ......................................................20

Cancelling the timer recording ..................................................20

Teletext ....................................................................................21

Using the MHEG-5 application (UK only) ..................................21

Connecting external devices ........................................................22

Introduction to connections......................................................22

HDMI connection ...............................................................23

Component connection .....................................................23

S-VIDEO/VIDEO connection ...............................................23

SCART connection ............................................................24

Controlling devices with SCART using AV Link ................... 24

Speaker/amplifier connection .............................................25

Inserting a CA Card .................................................................26

AQUOS LINK ..................................................................................27

Controlling HDMI devices using AQUOS LINK ..........................27

AQUOS LINK connection ......................................................... 27

AQUOS LINK Setup .................................................................28

Operating an AQUOS LINK device ........................................... 29

Menu operation..............................................................................30

What is the MENU? .................................................................30

Common operations ..........................................................30

...16

Basic adjustment ...........................................................................31

Picture Settings .......................................................................31

AV MODE...........................................................................32

Audio Settings .........................................................................32

Power Save Settings ................................................................33

Channel Settings .....................................................................34

Auto Installation .................................................................34

Programme Setup ..............................................................34

Password/Parental lock settings ........................................37

Language Settings (language, subtitle, multi audio) ..................37

Useful Viewing functions ..............................................................38

Selecting the picture size .........................................................38

Selecting the WSS picture size automatically .....................38

Selecting the WSS picture size manually ............................38

Selecting the picture size manually ..................................... 38

Selecting the recording picture size manually .....................39

Selecting the HDMI picture size automatically ....................39

Other picture and audio settings ..............................................39

Adjusting image position ....................................................39

Automatic volume adjustment ............................................39

Outputting audio only ......................................................... 39

Display Settings .......................................................................40

Channel display..................................................................40

Time and Title display ........................................................40

Other useful features ....................................................................41

Setting when using external devices ........................................41

Input source settings ..........................................................41

Skipping specified inputs ...................................................41

Colour system settings .......................................................41

Additional features ...................................................................41

Connecting a USB device ........................................................42

USB Photo Viewer/Music Player ..............................................42

Photo Mode ....................................................................... 42

Music Mode ....................................................................... 43

USB device compatibility .........................................................43

Gallery Mode ...........................................................................44

Basic operation for Gallery Mode .............................................44

Gallery Mode setting ................................................................44

Troubleshooting for Gallery Mode .......................................45

Connecting a PC ............................................................................46

Connecting a PC .....................................................................46

Displaying a PC image on the screen ....................................... 46

Selecting the picture size ...................................................46

Adjusting the PC image automatically ................................47

Adjusting the PC image manually .......................................47

Selecting input resolution .........................................................47

RS-232C port specifications ....................................................48

PC compatibility chart .............................................................. 49

RS-232C command list ...........................................................49

Appendix ........................................................................................50

Using the universal remote control ...........................................50

Troubleshooting .......................................................................54

Updating your TV via DVB-T ....................................................55

Updating your TV via USB .......................................................55

Reset .......................................................................................55

Identification ............................................................................56

Specifications ..........................................................................57

End of life disposal ................................................................... 58

Abbreviation list .......................................................................59

Introduction

Dear SHARP customer

Thank you for your purchase of the SHARP LCD colour TV product. To ensure safety and many years of troublefree operation of your product, please read the Important Safety Precautions carefully before using this product.

Important Safety Precautions

Cleaning—Unplug the AC cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product.

• Do not use liquid cleaners or aerosol cleaners. Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen sink, laundry tub,

• swimming pool and in a wet basement. Do not place vases or any other water-filled containers on this product. The water may spill onto the

• product causing fire or electric shock. Stand—Do not place the product on an unstable cart, stand, tripod or table. Doing so can cause the

• product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer. When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops,

• excessive force and uneven floor surface can cause the product to fall from the cart. Ventilation—The vents and other openings in the cabinet are designed for ventilation. Do not cover or

• block these vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are followed. The LCD panel used in this product is made of glass. Therefore, it can break when the product is

• dropped or impact applied. If the LCD panel is broken, be careful not to be injured by broken glass. Heat sources—Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating

• products (including amplifiers). Headphones—Do not set the volume at a high level. Hearing experts advise against extended listening at

• high volume levels. To prevent fire, never place any type of candle or naked flames on the top or near the TV set.

• To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy items.

• Do not display a still picture for a long time, as this could cause an afterimage to remain.

• There is power consumption always if main plug is connected.

• Servicing—Do not attempt to service the product yourself. Removing covers can expose you to high

• voltage and other dangerous conditions. Request a qualified person to perform servicing.

The LCD panel is a very high technology product, giving you fine picture details. Due to the very large number of pixels, occasionally a few non-active pixels may appear on the screen as a fixed point of blue, green or red. This is within product specifications and does not constitute a fault.

Precautions when transporting the Display

When transporting the Display, never carry it by holding onto the speakers. Be sure to always carry the Display by two people holding it with two hands—one hand on each side of the Display.

Trademarks

“HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.”•

Manufactured under license from Dolby Laboratories.

• “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

•

TruSurround XT, SRS and h symbol are trademarks of SRS Labs, Inc.

• TruSurround XT technology is incorporated under license from SRS Labs, Inc.

•

The “HD ready” Logo is a trademark of EICTA.

•

The DVB logo is the registered trademark of the Digital Video Broadcasting—DVB—project.

•

“x.v.Colour” and are trademarks of Sony Corporation.•

Introduction

Remote control unit

NOTE

The symbols 8, 9 and 0 indicate that the buttons become available in respective operating mode when using as a universal

• remote control.

TV B (TV Standby/On) (Page 17)

LIGHT D 8 9 0

When pressed, buttons that are frequently used (Pr/s, ik/l, 0–9 numeric buttons, A and b) will light. The light will turn off if no operations are performed within about five seconds. This button is used for performing operations in low-light situations.

FUNCTION 8 9 0

Press this button briefly (for more than 0.2 second), and the remote control switches for DVD, SetTopBox or VCR operation and currently controlled devices will be indicated in the LCD window. See page 50 for how to use this unit as a universal remote control.

LCD window 8 9 0

This screen shows which device you are currently controlling (TV, DVD, STB or VCR).

0–9 numeric buttons 9

Set the channel. Enter desired numbers. Set the page in teletext mode.

When the five Nordic countries

•

(Sweden, Norway, Finland, Denmark, or Iceland) are selected in the country setting from “Auto Installation” (page

34), DTV services are four digits. When another country is selected, DTV services are three digits.

A (Flashback)

Press to return to the previously selected channel or external input.

ATV

Press to access conventional analogue TV mode.

DTV

Press to access digital TV mode.

ik/l (Volume)

Increase/decrease TV volume.

e (Mute)

TV sound on/off.

R/G/Y/B (Colour) buttons

The coloured buttons are correspondingly used to select the coloured items on the screen (e.g. EPG, MHEG-5, Teletext).

a/b/c/d (Cursor) 8

Select a desired item on the setting screen.

OK 8 9

Execute a command within the “MENU” screen. ATV/DTV/SAT: Display the programme list when no other “MENU” screen is running.

END

Exit the “MENU” screen.

Buttons for teletext and other useful features

[ (Subtitle)

Switch subtitle languages on/off (Pages 21 and 37).

m (Teletext)

ATV: Display analogue teletext (Page 21). DTV/SAT: Select MHEG-5 and teletext for DTV/SAT (Page 21).

6 7

8 9

EPG

DTV/SAT: Display the EPG screen (Pages 18–20).

f (WIDE MODE)

Select a wide mode (Pages 38 and 46).

GALLERY

Press to enter the Gallery Mode (Page 44).

3 (Freeze/Hold)

Press to freeze a moving image on the screen. Teletext: Stop updating teletext pages automatically or release the hold mode.

15 16

17 18

b (INPUT SOURCE)

Select an input source (Page 17).

RADIO

DTV/SAT: Switch between Radio and Data mode.

When only data broadcasting (no radio

• broadcasting) is transmitted by DVB, the radio broadcasting will be skipped.

SAT

Press to access satellite mode.

Pr/s 8 9 0

Select the TV channel.

MENU 8

ATV/DTV/SAT: “MENU” screen on/off. DVD: Title menu on/off.

6 (Return)

Return to the previous “MENU” screen.

Buttons for teletext and other useful

features

Flip open the remote control cover on the front.

p (Display information)

Press to display the station information (channel number, signal, etc.) in the upper right corner of the screen (Page 40).

P. INFO

Press to display programme information which is transmitted through digital video broadcasting in the upper left corner of the screen (DTV/SAT only).

7 (Sound mode)

Select a sound multiplex mode (Page 17).

k (Reveal hidden Teletext) (Page 21) 1 (Subpage) (Page 21) v (Top/Bottom/Full)

Set the area of magnification in teletext mode (Page 21).

AV MODE

Select a video setting (Page 32).

AQUOS LINK buttons 8 9 0

TV mode: If external equipment such as a AQUOS BD Player is connected via HDMI cables and is AQUOS LINK compatible, you can use these AQUOS LINK buttons. See pages 27 and 29 for details. DVD/VCR mode: Press OPTION to pause the picture.

The buttons except OPTION are

• correspondingly used to select the items on the screen.

STB mode: Only the B button can be used to operate on STB.

Introduction

Part name

Display (Front view/Side view)

1 2 3 4 5 6 9

il/k Volume buttons*

Ps/r Programme (channel)

buttons* b (INPUT SOURCE) button*

MENU button*

a (Main Power) button*

Remote control sensor

B (Standby/On) indicator

SLEEP indicator

OPC indicator

RESET button

USB terminal

The symbols light up when pressing these buttons. After a

period of time, the light will turn off.

AVC System (Front view/Rear view)

321 4 5 6 7 8

COMMON INTERFACE 1/2 slot

B (Power) button

B (Standby/On) indicator

RESET button

HDMI3 (HDMI) terminal

WARNING

Excessive sound pressure from earphones and headphones can cause hearing loss.

• Do not set the volume at a high level. Hearing experts advise against extended listening at high volume levels.

•

12 13 14 15

7 8

EXT4 (ANALOGUE RGB/AUDIO) terminals EXT8 terminals Headphones

EXT1 (RGB) terminal

EXT2 (RGB) terminal

EXT3 (COMPONENT/AUDIO)

terminals OUTPUT (AUDIO) terminals

AVC System (Bottom view)

SAT (satellite) antenna terminal

Antenna terminal

DC OUTPUT terminal

DIGITAL AUDIO OUTPUT terminal

HDMI1 (HDMI/AUDIO) terminals

17 18 19 20 21 22

HDMI2 (HDMI) terminal

RS-232C terminal

USB terminal

DISPLAY OUTPUT terminal

AC INPUT terminal

Product label is on the bottom of the AVC System.

Preparation

Supplied accessories

HDMI cable holder (g1)

Pages 8

Remote control unit (g1)

Pages 3 and 6

AC cord cover (g1)

This covers the compartment on the

back of the Display after installing the

wall mount brackets or stand units.

“AAA” size alkaline

battery (g2)

Page 6

AC cord (g2)

Product shape varies in some

countries.

Page 10

HDMI cable (g1)

Pages 8 and 9

HDMI cable fixture/

cushion (g1)

Optional accessories

The listed optional accessories are available for this LCD colour TV. Please purchase them at your nearest shop.

Additional optional accessories may be available in the

• near future. When purchasing, please read the newest catalogue for compatibility and check the availability.

Page 9

Operation manual

No. Part name Part number

Wall mount bracket (LC-

52XS1E)

Wall mount bracket (LC-

65XS1E)

3 Stand unit (LC-52XS1E) AN-52ST1

4 Stand unit (LC-65XS1E) AN-65ST1

AN-52AG8

AN-65AG2

Preparation

Inserting the batteries

Before using the TV for the first time, insert two supplied “AAA” size alkaline batteries. When the batteries become depleted and the remote control unit fails to operate, replace the batteries with new “AAA” size batteries.

Open the battery cover.

Insert two supplied “AAA” size alkaline batteries.

Place batteries with their terminals corresponding to the

•

(e) and (f) indications in the battery compartment.

Close the battery cover.

CAUTION

Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the instructions below.

Do not mix batteries of different types. Different types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause chemical

• leakage in old batteries. Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause a rash. If you find any

• chemical leakage, wipe thoroughly with a cloth. Do not overuse the light-up function of the LIGHT D button, doing so may shorten the battery life. Replace the batteries

• when the light on the LCD window or the light-up function becomes weak or when the window becomes blurry. Do not continue to use the remote control unit with the batteries running low. This may result in

• error message or malfunction. Should this happen replace the batteries and leave it unused for a while. Otherwise, you may open the rear battery cover and press the RESET button. When you press the RESET button, your universal remote control settings will be deleted. The remote control unit has a internal memory of external devices. In order not to lose the data,

• replace the batteries quickly. If the manufacturer code is initialised and lost, you can input the manufacturer code again (See page 50–53). The batteries supplied with this product may have a shorter life expectancy due to storage conditions.

• If you will not be using the remote control unit for an extended period of time, remove the batteries from it.

• When replacing the batteries, use alkaline batteries instead of zinc-carbon ones.

•

RESET button

Note on disposing batteries:

The batteries provided contain no harmful materials such as cadmium, lead or mercury. Regulations concerning used batteries stipulate that batteries may no longer be thrown out with the household rubbish. Deposit any used batteries free of charge into the designated collection containers set up at commercial businesses.

Using the remote control unit

Use the remote control unit by pointing it towards the remote control sensor. Objects between the remote control unit and sensor may prevent proper operation.

5 m

30° 30°

Remote control sensor

Cautions regarding the remote control unit

•

Do not expose the remote control unit to shock. In addition, do not expose the remote control unit to liquids, and do not place in an area with high humidity.

•

Do not install or place the remote control unit under direct sunlight. The heat may cause deformation of the unit.

•

The remote control unit may not work properly if the remote control sensor of the Display is under direct sunlight or strong lighting. In such cases, change the angle of the lighting or the Display, or operate the remote control unit closer to the remote control sensor.

Quick guide

Initial installation overview

Follow the steps below one by one when using the TV for the first time. Some steps may not be necessary depending on your TV installation and connection.

Before turning on the main power

Prepare the Display (Page 8)

HDMI cable:

Connect the supplied HDMI cable to the HDMI terminal on the Display.

• Fix the cable to the Display with the supplied HDMI cable holder then.

Set the TV and antenna cables (Page 9)

Display:

•

Select the location of the TV.

HDMI cable fixture/cushion:

•

Connect the supplied HDMI cable with one side connected to the Display as in step 1 to the DISPLAY OUTPUT on the AVC System. Connect the cable to the AVC System with the supplied HDMI cable fixture/cushion.

Analogue/DVB-C/DVB-T antenna:

•

Connect the antenna of an antenna system, cable system, or room antenna to the antenna terminal of the AVC System.

Satellite antenna:

•

Connect an antenna plug, e.g., from the antenna change over switch or from the twin-LCN of a satellite system to the SAT terminal of the AVC System.

Connect external devices or sound components

(Pages 22–25)

If desired, connect external devices such as a DVD recorder.

• Cables and terminals may vary depending on the devices you use.

•

Prepare remote control unit (Page 6)

Insert the supplied “AAA” size alkaline batteries into the remote control unit.

•

Turning on and running the initial auto installation

Turn on the TV power (Page 10)

Plug the AC cord into an AC outlet.

• Press a on the Display to turn on the main power of the Display.

•

Conduct initial auto installation (Pages 11–15)

The initial auto installation wizard appears automatically (only the first time the TV is turned on).

•

Adjust DVB-T/S/C antenna (Page 16)

If necessary position or align the DVB-T/S/C antenna.

•

Quick guide

Before turning on the main power

Preparing the Display

Make sure the Display is turned off before beginning work.

• Before performing work, spread cushioning over the surface on which you will be laying the Display. This will

• prevent it from being damaged.

Connecting the HDMI cable with the HDMI cable holder

HDMI cable

Speaker cable*

Press down on the

1 Connect the HDMI cable to

upper hook and remove the rear terminal cover, pulling towards you.

(supplied)

2 Affix the HDMI cable

the Display.

holder by pressing down.

HDMI cable holder (supplied)

NOTE

These are terminals for the speaker of the TV. Do not connect any other kind of cables.

Do not disconnect the speaker cable unless absolutely necessary. If you disconnect the speaker cable, confirm each colour

• of the speaker plugs and speaker terminals (the order of the colour from left to right: red/black/white) before connecting the speaker cable again.

Mounting the Display on a wall

This Display should be mounted on a wall only with the wall mount bracket available from SHARP

•

(Page 5). The use of other wall mount brackets may result in an unstable installation and may cause serious injuries. Mounting the Display requires special skills and should only be performed by qualified service

•

personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper mounting or mounting that results in accident or injury.

•

You can ask qualified service personnel about using an optional bracket to mount the Display to a wall.

•

To use this Display mounted on a wall, first remove the adhesive tape at the two locations on the rear of the Display

, and then use the screws supplied with the wall mount bracket to secure the bracket to the rear of the

Display

When using wall mount bracket AN-52AG8 or AN-65AG2

You can check the centre of the TV screen using the mark engraved on the wall mount bracket when mounting the Display on the wall.

LC-52XS1E: The centre of the TV screen is at mark “E” on the wall bracket. LC-65XS1E: The centre of the TV screen is at mark “A” on the wall bracket.

Setting the Display with the optional stand

This Display should be set on a table or floor, etc. only with the stand available from SHARP, sold separately

• (Page 5). Be sure to follow the instructions for the stand manual.

•

Quick guide

Setting the TV and antenna cables

Supplying power to the antenna

You must supply power to the antenna in order to receive digital terrestrial broadcasts or satellite broadcasts after running the initial auto installation. Go to “MENU” > “Setup” > “Antenna Setup-DIGITAL” > “Digital Setup” > “Supply Voltage” > select “On”.

NOTE

The B indicator of the AVC System lights up when the main power is turned on after connecting the Display and AVC System using the

• supplied HDMI cable. The HDMI cable should be firmly connected. Failure to do so will loosen the cable and cause a contact failure when moving the AVC System.

• This can cause result in an error message appearing on the screen without a visible picture.

Satellite antenna

cable

Connecting the HDMI cable with the

Standard DIN45325 plug (IEC 169-2) 75 q coaxial cable

HDMI cable (supplied)

fixture/cushion

1 3

4 5

Ta b

Insert the fixture for

1 Detach the parts

the HDMI cable into the hole below the DISPLAY OUTPUT terminal on the AVC System.

of the fixture while holding the tab of the fixture downward. Wrap the cushion

around the HDMI cable.

Attach the parts of

4 Connect the HDMI

the fixture on the cushion, pushing the tab downward.

Do not use excessive force when insering/ removing the HDMI cable. The terminal or cable may become dameged.

cable with the fixture to the DISPLAY OUTPUT terminal while sliding on the bar of the fixture.

Handling the AVC System

CAUTION

Do not put a VCR or other device on top of the AVC System.

• Keep enough space above and to the sides of the AVC

• System. Do not block the ventilation openings on the top and left side or

• the exhaust fan on the right side. Do not spread a thick cloth beneath the AVC System or cover it with one, as this can cause overheating and result in

• malfunction.

5cm

5cm 5cm

Quick guide

Turning on and running the initial auto installation

Plugging the AC cord to the AC outlet

Place the TV close to the AC outlet, and keep the power plug within reach.

AC cord*

Product shape varies in some countries.*

Power on and run the auto installation

Turn on the main power using

a on the Display.

Digital Search

Run the initial auto installation

(Pages 11–15).

Language setting

✔

English

Italiano

Svenska

Home/Store setting

✔

STOREHOME

Country setting

✔

Austria A B/G

Finland

FIN

B/G

Greece GR B/G

Channel search setting

✔

Digital Search

Analogue Search

Skip

Start the digital service settings

(Pages 11–13)

CableTerrestrial

Analogue Search

Start the analogue channel searching

(Page 13)

01 628.25 02 693.25 03 767.25 04 831.25

Skip

Start the satellite service settings

(Pages 14–15)

NoYes

Quick guide

Initial auto installation

Starting channel search.

When the TV is powered on for the first time after purchase, the initial auto installation wizard appears. Follow the menus and make the necessary settings one after another.

Confirm the following before turning on the main power

Are the Display and AVC System connected

using the supplied HDMI cable? Is the antenna cable connected?

Is the AC cord plugged in?

Press a on the Display.

The initial auto installation wizard appears.

•

Setting the OSD language.

English

Italiano

Svenska

Press a/b/c/d to select the desired language, and then press OK.

Selecting the location of the TV.

STOREHOME

Digital Search

Analogue Search

Skip

Press a/b to select “Digital Search”, “Analogue Search” or “Skip”, and then press OK.

To watch analogue broadcasts, digital broadcasts and

• satellite broadcasts, you should perform the channel search setting for each format. If you want to search for more broadcasts, execute

• “Additional Search” from the “Programme Setup” menu (Pages 34–36). When you select “Skip”, only “Satellite Search” will be

• performed. You should perform “Digital Search” and “Analogue Search” from “Auto installation” under the “Setup” menu if needed. After performing “Digital Search” or “Analogue

• Search”, the screen swithes to the “Satellite Search” setting. You should then execute “Yes” if you want to search for the satellite channels.

“Digital Search” setting

Press c/d to select “Terrestrial” or “Cable”, and then press OK.

CableTerrestrial

Press c/d to select where you will use this TV, and then press OK.

HOME: “STANDARD” will be the default value for the

• “AV MODE” setting. STORE: “DYNAMIC (Fixed)” will be the default value

• for the “AV MODE” setting. If the “AV MODE” is changed, the TV will automatically switch back to “DYNAMIC (Fixed)” when there is no signal input from the TV or remote control unit for 30 minutes.

Setting the country.

Austria A B/G

FIN

Finland

Greece GR B/G

B/G

Press a/b/c/d to select your country or area, and then press OK.

This setting screen only appears during the first

• installation.

“Terrestrial” searching

01 628.25 02 693.25 03 767.25 04 831.25

The TV searches for, sorts and stores all the receivable TV stations according to their settings and the connected antenna.

To abort the initial auto installation in progress, press

•

After searching for DVB-T channels, the screen switches to the “Satellite Search” setting (Page

14).

NOTE

•

If you turn off the main power on the Display while performing “Terrestrial” searching, the initial auto installation wizard will not appear. The auto installation function allows you to execute the installation again from the “Setup” menu (Page 34).

•

The initial auto installation wizard will turn off if you leave the TV unattended for 30 minutes before searching for channels.

Quick guide

“Cable” searching

The current DVB-C settings are displayed on the screen.

Scrambled stations:

Search method:

Start frequency: 47.0 MHz

Network ID:

Symbol rate 1:

Symbol rate 2:

QAM modulation 1:

QAM modulation 2:

Channel

None

6875

6900

None

Change SettingStart Search

When you start searching for DVB-C channels

with the current setting:

Press c/d to select “Start Search”, and

then press OK.

01 628.25 02 693.25 03 767.25 04 831.25

When you change each item to the appropriate

settings:

Press c/d to select “Change Setting”, and then press OK.

Scrambled stations

Search method

Start frequency

Network ID

Symbol rate 1

Symbol rate 2

QAM modulation 1

QAM modulation 2

Search start

[No]

[Ch]

[47.0]

[None]

[6875]

[6900]

[64]

[None]

Yes No

Press a/b to select the menu, and then press OK.

Press a/b/c/d or 0–9 to select or input the appropriate item/value, and then press OK.

Press a/b to select “Search start”, and then press OK.

01 628.25 02 693.25 03 767.25 04 831.25

The TV searches for, sorts and stores all the receivable TV stations according to their settings and the connected antenna.

To abort the initial auto installation in progress, press

•

After searching for DVB-C channels, the screen switches to the “Satellite Search” setting (Page

14).

NOTE

If you turn off the main power on the Display while

• performing “Cable” searching, the initial auto installation wizard will not appear. The auto installation function allows you to execute the installation again from the “Setup” menu (Page 34). The initial auto installation wizard will turn off if you leave

• the TV unattended for 30 minutes before searching for channels.

The TV searches for, sorts and stores all the receivable TV stations according to their settings and the connected antenna.

To abort the initial auto installation in progress, press

•

After searching for DVB-C channels, the screen switches to the “Satellite Search” setting (Page

14).

NOTE

If you turn off the main power on the Display while

• the TV unattended for 30 minutes before searching for channels.

Quick guide

Menu Description Selectable Item

Scrambled Stations

Search Method

Start frequency

Network ID

Symbol rate 1*

Symbol rate 2*

QAM Modulation 1

QAM Modulation 2

Set up “Symbol rate 2” if the cable provider uses several

symbol rates.

Specifies if you need to add pay-TV services.

Specifies how you search channels.

————————— 47.0–858.0 MHz

Specifies the network. Set this to register only the specified network ID without registering any special services.

The symbol rates are specified by the cable provider. Input the value received for CATV.

—————————

Yes, No

Channel: Extracts all of information from a channel (quick, but needs corresponding TV stations). Frequency: Checks every frequency in range (slow).

None, 0–65535

1000–9000

16, 32, 64, 128, 256

None, 16, 32, 64, 128, 256

“Analogue Search” setting

01 628.25 02 693.25 03 767.25 04 831.25

The TV searches for, sorts and stores all the receivable TV stations according to their settings and the connected antenna.

•

To abort the initial auto installation in progress, press

After searching for analogue channels, the screen switches to the “Satellite Search” setting (Page 14).

NOTE

If you turn off the main power on the Display while

• performing “Analogue Search”, the initial auto installation wizard will not appear. The auto installation function allows you to execute the installation again from the “Setup” menu (Page 34). The initial auto installation wizard will turn off if you leave

• the TV unattended for 30 minutes before searching for channels.

Quick guide

“Satellite Search” setting

Press c/d to select “Yes”, and the then press OK.

NoYes

If you do not perform “Satellite Search” setting, select “No”,

•

and then press OK.

•

The current DVB-S setting screen is displayed.

Satellite System

Max. 4 satellites on DiSEqC multiswitch

Satellite

ASTRA1SAT1

LNB Frequency

Low

High

9700

10700

Change Setting Next

•

You must first complete “Change Setting” before moving to the “Next” setting.

When starting the satellite search after setting

the scrambled stations: Press c/d to select “Next”, and then press OK.

Change setting:

Press c/d to select “Change setting”, and

then press OK.

The setting screen of “Scrambled stations” and

• “Symbol rate” is displayed.

Scrambled stations

SAT1-Symbol rate 1 SAT1-Symbol rate 2

SAT2-Symbol rate 1

Search start

[No]

[6875] [6875]

[6875]

Yes No

Press a/b to select “Scrambled stations”, and then press OK.

Scrambled stations: Specifies if you need to add pay-

• TV services.

Press c/d to select “Yes”, and then press

OK. Press a/b to select the symbol rate you

want to modify, and then press OK.

Symbol rate: You need to set each symbol rate of all

• the satellite broadcasts that the TV can receive (eight is the maximum number of symbol rates that can be displayed).

Press c/d to select “Search start”, and

then press OK.

Scrambled stations: No

Satellite

SAT1

SAT2

Start Search: DVB-S channel searching.

Press c/d to select “Start Search”, and

ASTRA1

ASTRA2

ASTRA3SAT3

otherSAT4

Symbol rate 1

27500

27500 22000

Symbol rate 2

Change Setting Start Search

then press OK.

01 628.25 02 693.25 03 767.25 04 831.25

The TV searches for, sorts and stores all the receivable TV stations according to their settings and the connected antenna.

To abort the initial auto installation in progress, press

•

22000

01 628.25 02 693.25 03 767.25 04 831.25

The TV searches for, sorts and stores all the receivable TV stations according to their settings and the connected antenna.

To abort the initial auto installation in progress, press

•

Quick guide

When you change the antenna connection

setting: Press c/d to select “Change Setting” on the DVB-S

setting screen in the left column, and then press OK.

The antenna connection setting screen is displayed.

•

Single satellite

2 satellites on 22kHz switchbox

2 satellites on toneburst switchbox

Max. 4 satellites on DiSEqC multiswitch

Communal satellite system

NOTE

•

You can select the antenna connection method from the five types. Consult your dealers before using a method other than “Single Satellite”.

“Single satellite” setting

Press a/b to select “Single satellite”, and then

press OK.

Press a/b to select “SAT1 [None]” to display the satellite broadcasts that the TV can receive, and then press OK.

SAT1 [None]

EXAMPLE

SAT1 LOW [9000] 9000

SAT1 HighOK[12000]

Press a/b to select “OK”, and then press OK.

9000

12000

After completing this setting, the screen switches to the DVB-S setting screen shown in the left column on page 14.

Press a/b/c/d to select your favorite satellite,

and then press OK.

You cannot select “Next” unless you set the satellite

• broadcast in step 3.

ASTRA 1

ASTRA 3

Altalntic Bird 3

Press a/b to select “Next”, and then press OK.

SAT1 [ASTRA 1]

Press c/d to select “Yes (0/22kHz)” or “No” to set the LNB frequency, and then press OK.

NoYes (0/22kHz)

Press a/b to select the item and press c/d to adjust 9,000 MHz to 12,000 MHz to the appropriate value.

Quick guide

Checking signal strength and channel strength (DVB-T/C)

If you install a DVB-T/C antenna for the first time or relocate it, you should adjust the alignment of the antenna to receive a good reception while checking the antenna setup screen.

Press MENU and the “MENU” screen displays.

Press c/d to select “Setup”.

Press a/b to select “Antenna Setup-DIGITAL”,

and then press OK. Press a/b to select “Digital Setup”, and then

press OK.

Checking signal strength

Press a/b to select “Signal Strength”, and then press OK.

Supply Voltage

Signal Strength

Channel Strength

CH No. 21

Signal Strength

Current Max 0

Quality

Current Max 0 0

Checking signal strength and channel strength (DVB-S)

If you install a DVB-S antenna for the first time or relocate it, you should adjust the alignment of the antenna to receive a good reception while checking the antenna setup screen.

Press MENU and the “MENU” screen displays.

Press c/d to select “Setup”.

Press a/b to select “Antenna Setup-DIGITAL”,

and then press OK. Press a/b to select “Satellite Setup”, and then

press OK.

Checking signal strength

Press a/b to select “Signal Strength”, and then press OK.

Signal Strength

Channel Strength

Signal Strength

Current Max 0 0

Quality

Current Max 0 0

Checking channel strength

Press a/b to select “Channel Strength”, and then press OK.

You can input a specified frequency band using the

•

0–9 numeric buttons.

Channel strength of DVB-T

Supply Voltage

Signal Strength

Channel Strength

474. 0

CH No. 21

Signal Strength

Current Max0

Quality

Current Max00

Channel strength of DVB-C

Supply Voltage

Signal Strength

Channel Strength

Position and align the antenna so that the

Frequency

Symbol rate

QAM Modulation

Signal Strength

Current Max0

Quality

Current Max00

74640 MHz.

*******

maximum possible values for “Signal Strength” and “Quality” are obtained.

MHz

Checking channel strength

Press a/b to select “Channel Strength”, and then press OK.

You can input a specified frequency band using the

•

0–9 numeric buttons.

Channel strength of DVB-S

Signal Strength

Channel Strength

Frequency

Symbol rate

Band

Signal Strength

Current Max0

Quality

Current Max00

********

Vert/Low

00 MHz

NOTE

The values of “Signal Strength” and “Quality” indicate when

• to check the appropriate alignment of the antenna.

Watching TV

Daily operation

Switching on/off

Turning on/off the main power

Press a on the Display. Switch it off by pressing a on the Display.

NOTE

When turning off the main power

•

using a on the Display, EPG data will be lost, and programmed timer recordings will not be performed by the TV.

Standby mode

To standby mode

If the TV is switched on, you can switch it to standby by pressing TV B on the remote control unit or B on the AVC System.

Switching on from standby

From standby, press TV B on the remote control unit or B on the AVC System.

Changing channels

With Pr/s:

With 0–9:

Selecting an external video source

Once the connection is made, press b to display the “INPUT SOURCE” screen, and then press a/b to switch over to the appropriate external source with OK.

INPUT SOURCE TV

EXT1 EXT2 EXT3

EXT4

HDMI1

Selecting a sound mode

DTV/SAT mode:

If multi sound modes are received, each time you press 2 the mode switches as follows.

Audio (ENG) : STEREO

L/R LRLR

B indicator status (Display/AVC System)

B indicator

Off Blue Red

Power off

Power on

Standby

NOTE

If you are not going to use this TV for a long period of time, be sure

• to remove the AC cord from the AC outlet. A small amount of electric power is still consumed even when a is

• turned off.

Status

Switching between digital, satellite and analogue broadcasts

Watching satellite

broadcasts

Watching analogue

broadcasts

EWatching digital

broadcasts

Audio (ENG) : CH A

CH A CH B CH AB

Audio (ENG) : MONO

Press c/d to select L or R sound when the STEREO or DUAL MONO screen is displayed.

Audio (ENG) : STEREO

L/R L RLR

NOTE

The sound mode screen disappears in six seconds.

• Selectable items vary depending on the received broadcasts.

•

ATV mode:

Each time you press 2, the mode switches as shown in the following tables.

NICAM TV broadcasts selection Signal Selectable items Stereo Bilingual Monaural

Signal Selectable items Stereo Bilingual Monaural

NICAM STEREO, MONO NICAM CH A, NICAM CH B, NICAM CH AB, MONO NICAM MONO, MONO

A2 TV broadcasts selection

STEREO, MONO CH A, CH B, CH AB MONO

NOTE

When no signal is input, the sound mode will display “MONO”.

•

Watching TV

EPG

EPG is a programme list that is displayed on the screen. With the EPG, you can check the schedule of DTV/SAT/ RADIO/DATA, view detailed information about them, tune to an event currently on-air and set a timer for future events.

EPG Overview

Basic functionsE

Select a programme using EPG (Page 19)

Check programme information (Page 19)

Useful settings for using EPG

Common Operation

Press MENU and the “MENU” screen displays.

Press c/d to select “Digital Setup”.

2 3

Press a/b to select “EPG Setup”, and then press OK.

Digital Setup

REC Picture Size

Download Setup

EPG Setup

Subtitle

CI Select

CI Menu

Press a/b to select the desired item, and then press OK (Example: “EPG Setup”, “Display Range Setup”, etc.).

EPG Setup

Display Range Setup

Genre Icon Setup

Press a/b/c/d to select or adjust the desired

item, and then press OK (Example: “Yes”, “No”, etc.).

[16:9 TV]

[Yes]

Yes No

Useful functionsE

Search for a programme by category (Page 19)

Search for a programme by date and time

(Page 19) Timer recording using EPG (Page 20)

EPG display settings

EPG Setup (setting for receiving EPG data)

If you want to use the EPG for digital stations, select “Yes”. The EPG data must be automatically captured while the TV is in standby mode. After setting to “Yes”, it may take some time to turn off the power using the remote control unit due to the process of the data capture.

NOTE

If the main power is switched off, the EPG data will not be

• captured.

Display Range Setup

The “Display Range Setup” allows you to select three types of time spans for display on the screen.

Item

Mode1: Displays six hours of programme information. Mode2: Displays three hours of programme information. Mode3: Changes to the EPG display format with a

vertical time span.

Genre Icon Setup

You can grey out or place a mark on desired genres and smoothly search for programmes you frequently watch.

Genre Icon List

Icon Genre Icon Genre

Movie/Drama Music/Ballet/Dance

News/Current affairs

Show/Game show

Sports

Children’s/Youth programmes

Arts/Culture (without music)

Social/Political Issues/Economics

Education/Science/ Factual topics

Leisure hobbies

Watching TV

Selecting a programme using EPG

Basic Operation

The illustrations on this page are explained using three digit services.

Display/Close the EPG screen

Press EPG.

Select a programme

Select the time span

Press c/d to select the time span you want to search.

Continue to press d to display programmes in the next time span.

•

Select the desired programme

Press a/b to select the desired programme.

If a or b are displayed on the left of the services, continue to press a/b to display next or previous screen.

•

EPG [Mon]16/04 10:57 AM[DTV-TV] To da y (Tue)20 (Wed)21 (Thu)22 (Fri)23 (Sat)24 (Sun)25 (Mon)26

040

BBC News 24 BBC News

10 : 00AM - 1 : 00 AM

BBC TWO 002

BBC THREE 007

BBC FOUR 010

BBC FIVE 012

CBBC Channel 030

BBC 1 061

BB22 062 BBC NEWS 24 340

BBCi 351

SIT 1 994

SIT 2 995 SIT 3 996

SIT 4 997 SIT 5 998

BBC ONE 999

: Select : Enter6: Back

10 AM 11 0 PM 1 2 3

This is BBC THREE

BBC NEWS BBC NEWS

BBCi BBCi

This is BBC THREE

EPG

RGYB

: Exit Programme info. Search By Genre Search By Date Timer List

345

This is BBC THREE

Selecting a programme

Check programme information

Press a/b/c/d to select the programme you

want to check.

Press R.

040

BBC News 24 BBC News

10 : 00AM - 1 : 00 AM

Programme Info.

BBC TWO 002

BBC THREE 007

BBC FOUR 010

BBC FIVE 012

CBBC Channel 030

BBC 1 061

BB22 062 BBC NEWS 24 340

BBCi 351

Press OK to tune to the selected programme.

Search a programme in a category

Press G.

Press a/b to select the desired genre, and then

press OK.

Press a/b to select a programme you want to watch, and then press OK.

Genre

Movie/Drama

News/Current affairs

Show/Game show

Sports

Children’s/Youth programmes

Music/Ballet/Dance

Arts/Culture (without music)

Social/Political Issues/Economics

Education/Science/Factual Topics

Leisure hobbies

Programme Information

Programme Info.

Back to EPG

The BBC’s rolling news service with headlines every 15 minutes.

10 AM 11 0 PM 1 2 3

This is BBC THREE

BBC NEWS BBC NEWS

BBCi BBCi

This is BBC THREE

[Today] AM [Today] PM [Tue] 20 AM [Tue] 20 PM

10 : 50 AM - 11 : 05 AMMon 19/05CBBC Cahnnel 030 time 10 : 50 AM - 11 : 10 AMMon 19/05BBC TWO 002 School is Lock

11 : 05 AM - 11 : 20 AMMon 19/05CBBC Cahnnel 030 Words and Pictures

Search for a programme by date/time

Press Y.

Press c/d to select the desired time span, and

then press OK.

Date/Time

Search by Time

: Select Time

BBC TWO 002

BBC THREE 007

BBC FOUR 010

BBC FIVE 012

CBBC Channel 030

BBC 1 061

BB22 062 BBC NEWS 24 340

SIT 1 994

Press a/b to select the desired programme,

0 AM -

6 AM

: Enter

: Select Time

: Enter

10 AM 11 0 PM 1 2 3

This is BBC THREE

BBC NEWS BBC NEWS

6 AM -

0 PM

Back to EPG

Today

This is BBC THREE

0 PM -

6 PM

Enter G +1 Week

6 PM - 0 AM

and then press OK.

NOTE

When you select a programme outside of the current time

• span, the timer setting screen is displayed (Page 20).

Refer to page 18 for the genre setting.

•

Watching TV

Timer recording using EPG

You can record TV programmes using data from the EPG.

Press EPG. Press a/b/c/d to select the programme you

want to record, and then press OK. Press c/d to select the preferred timer setting,

and then press OK.

Watch Record No

If you select “No”, the TV returns to the EPG screen.

•

Watching a programme at a set time

Press c/d to select “Watch”, and then press

OK.

Press c/d to select “Yes”, and then press OK.

The selected TV programme is marked with an icon.

•

Recording a programme at a set time

Press c/d to select “Record”, and then press

OK.

Press c/d to select the preferred timer recording type, and then press OK.

Item

AQUOS LINK: Records a programme at a set time when

a device compatible with AQUOS LINK is connected.

AV LINK: Records a programme at a set time when a

device compatible with AV LINK is connected.

VHS tape: Records a programme at a set time when a

device compatible with VHS tape is connected.

Cancelling the timer recording

Press EPG.

1 2

Press a/b/c/d to select the programme on timer setup, and then press OK.

Press c/d to select “Cancel”, and then press

OK.

Press c/d to select “Yes”, and then press OK.

Cancelling using the B button on the

remote control unit

Press EPG.

Press B to display the timer recording screen.

2 3

Press a/b to select a programme with a set timer recording you want to change, and then press OK.

Press c/d to select “Cancel” and then press

OK.

Press c/d to select “Yes”, and then press OK.

The selected TV programme is marked with an icon.

•

NOTE

Refer to pages 22–25 and 27–28 for connecting external

• devices.

Watching TV

Teletext

What is Teletext?

Teletext broadcasts pages of information and entertainment to specially equipped TV. Your TV receives teletext signals broadcast by a TV network, and decodes them into graphical format for viewing. News, weather and sports information, stock exchange prices and programme previews are among the many services available.

Turning Teletext on/off

Select a TV channel or external source providing

a teletext programme.

Press m to display the Teletext.

Many stations use the TOP operating system, while

• some use FLOF (e.g. CNN). Your TV supports both these systems. The pages are divided into topic groups and topics. After switching on the teletext, up to 2,000 pages are stored for fast access. Each time you press m, the screen switches as

• shown below. Press m again to display the teletext on the right

• screen and the normal image on the left screen. If you select a programme with no teletext signal, “No

• Teletext available” displays. The same message displays during other modes if no

• teletext signal is available.

Buttons for teletext operations

Buttons Description Pr/s Colour (R/G/

Y/B)

0–9

v (Top/ Bottom/Full)

k (Reveal hidden Teletext)

3 (Freeze/ Hold)

[ (Subtitle for Teletext)

1 (Subpage)

Increase or decrease the page number.

Select a group or block of pages displayed in the coloured brackets at the bottom of the screen by pressing the corresponding Colour (R/G/Y/B) on the remote control unit.

Directly select any page from 100 to 899 by using the 0–9 numeric buttons.

Switch the teletext image to Top, Bottom or Full.

Reveal or hide hidden information such as an answer to a quiz.

Stop updating teletext pages automatically or release the hold mode.

Display the subtitle or exit the subtitle screen.

Subtitles will not be displayed when

• the service does not contain subtitle information.

Reveal or hide subpages.

R button: Move to the previous

• subpage. G button: Move to the following

• subpage.

•

These two buttons are shown on the screen by the symbols “e” and “f”.

TELETEXT

NOTE

Teletext will not work if the selected signal type is

• RGB (Page 41).

Using the MHEG-5 application (UK only)

Some services bring you programmes with the MHEG application encoded, letting you experience DTV/SAT interactively. When provided, the MHEG-5 application will start when you press m.

Sample MHEG-5 screen

Connecting external devices

Before connecting ...

Be sure to turn off the TV and any devices before making any connections.

• Firmly connect a cable to a terminal or terminals.

• Carefully read the operation manual of each external device for possible connection types. This also helps you get the best

• possible audiovisual quality to maximise the potential of the TV and the connected device. Refer to page 46 for connecting a PC to the AVC System.

•

Introduction to connections

The AVC System is equipped with the terminals as shown below. Find the cable corresponding the terminal and connect the device.

NOTE

•

The cables illustrated in pages 22–25 are commercially available items.

Audio device (Page 25)

Optical audio cable

Audio cable

Component cable

Video recording device

(Pages 23 and 24)

Game console or camcorder

(Pages 23 and 24)

HDMI device (Page 23)

Audio cable

SCART cable

AV cable*

or or

S-video cable*

HDMI-certified cable

DVI/HDMI cable

Rear view

Front view

When using an S-video cable, you also need to connect an audio cable (R/L).*

ø 3.5 mm stereo minijack cable

Connecting external devices

HDMI connection

YPB

Component connection

CB)

CR)

(

Example of connectable devices

DVD player/recorder E Blu-ray player/recorder

Game console

The HDMI connections permit digital video and audio transmission via a connection cable from a player/ recorder. The digital picture and sound data are transmitted without data compression and therefore lose none of their quality. Analogue/digital conversion is no longer necessary in the connected devices, which also would result in quality losses.

HDMI-certified cable

ø 3.5 mm

stereo

minijack

cable

DVI/HDMI cable

Example of connectable devices

VCR E DVD player/recorder

Blu-ray player/recorder

You will enjoy accurate colour reproduction and high quality images through the EXT3 terminal when connecting a DVD player/recorder or other device.

Component

cable

YPB

(

CB)

CR)

COMPONENT AUDIO

LRPR

Audio cable

DVI/HDMI conversion

Using a DVI/HDMI cable, the digital video signals of a DVD can also be played via the compatible

HDMI

connection. The sound must be fed in additionally.

When connecting a DVI/HDMI cable to the HDMI terminal, the

• image may not come in clearly.

•

Both HDMI and DVI use the same HDCP copy protection method.

After connecting

HDMI Audio Select

After connecting, you must set the audio signal compatible with the cable you use for the HDMI device.

Go to “MENU” > “Option” > “HDMI Audio

Select”. Select “Digital” for audio signals via the

HDMI terminal. Select “Analogue” for audio signals via the AUDIO jack (HDMI1).

NOTE

•

If a connected HDMI device is AQUOS LINK compatible, you can take advantage of versatile functions (Pages 27–29).

•

Video noise may occur depending on the type of HDMI cable used. Make sure to use a certified HDMI cable.

•

When playing the HDMI image, the best possible format for the picture will be detected and set automatically.

Supported video signal:

576i, 576p, 480i, 480p, 1080i, 720p, 1080p See page 49 for PC signal compatibility.

S-VIDEO/VIDEO connection

Example of connectable devices

VCR E DVD player/recorder

Blu-ray player/recorder

Game console E Camcorder

You can use the EXT8 terminal when connecting to a game console, camcorder, a DVD player/recorder or other device.

S-video cable

AV cable

NOTE

When using an S-video cable, you also need to connect an

•

audio cable (R/L).

EXT8: The S-VIDEO terminal has priority over the VIDEO terminal.

•

Connecting external devices

SCART connection

Example of connectable devices

DecoderE

SCART cable

Decoder

Example of connectable devices

VCR E DVD player/recorderE

When using the EXT2 (SCART) terminal

If your VCR supports TV-VCR advanced AV Link systems, you can connect the VCR using a fully wired SCART cable.

SCART cable

DecoderVCR

NOTE

In cases when the decoder needs to receive a signal from the TV, make sure to select the appropriate input terminal to which

• the decoder is connected in “Manual Adjust” in the “Analogue Setting” menu (Page 36). TV-VCR advanced AV Link systems may not be compatible with some external sources.

• You cannot connect the VCR with decoder using a fully wired SCART cable when selecting “Y/C” under “EXT2” in the “Input

• Select” menu.

Controlling devices with SCART using AV Link

This TV incorporates four typical AV Link functions for smooth connections between the AVC System and other audiovisual equipment.

One Touch Play

While the TV is in standby mode, it automatically turns on and plays back the image from the audiovisual source (e.g. VCR, DVD player/recorder).

TV Standby

When the TV enters standby mode, the connected audiovisual equipment (e.g. VCR, DVD player/recorder) enters standby mode as well.

WYSIWYR

When the remote control unit of the connected VCR has the WYSIWYR button, you can automatically start recording by pressing the WYSIWYR button.

Preset Download

Automatically transfers the channel preset information from the AVC System to the one on the connected audiovisual equipment (e.g. VCR) via the EXT2 terminal.

NOTE

Refer to the operation manuals of external equipment for details.

• The AV Link function works only when audiovisual equipment is connected to the EXT2 terminal with a fully wired SCART cable.

• The use of the AV Link function is only possible if the TV has enforced a complete auto installation with the connected

• audiovisual equipment (Pages 11–15, Initial auto installation). The availability of the AV Link function depends on the audiovisual equipment used. Depending on the manufacturer and type of equipment used, it is possible that the described functions may be completely or partially unusable.

Connecting external devices

Speaker/amplifier connection

Connect an amplifier with external speakers as shown below.

input

Connecting an amplifier with analogue

EConnecting an amplifier with digital audio

audio input

Optical audio cable

DIGITAL AUDIO IN

Amplifier with

digital audio input

After connecting

Digital audio output setting

After connecting an amplifier with digital audio input and external speakers as shown, you should set an audio output format compatible with the programme you are watching or the device connected.

Go to “MENU” > “Option” > “Digital Audio Output” > select “PCM” or “Dolby Digital”.

NOTE

When you set this to “Dolby Digital”, and you receive

• the Dolby Digital or Dolby Digital Plus audio formats, Dolby Digital audio is output. Otherwise, PCM audio is output. When you set this to “PCM”, PCM audio is output no matter what audio formats you receive.

Audio cable

AUX OUT

analogue audio input

AUX1 IN

Amplifier with

Connecting external devices

Inserting a CA Card

In order to receive coded digital stations, a Common Interface Module (CI Module) and a CA Card must be inserted in the CI slot of the AVC System (See below). The CI Module and the CA Card are not supplied accessories. They are usually available from your dealers.

Inserting the CA Card into the CI Module

With the side with the gold coloured contact

chip facing the side of the CI Module marked with the provider’s logo, push the CA Card into the CI Module as far as it will go. Note the direction of the arrow printed on the CA Card.

Inserting the CI Module in the CI slot

Carefully insert the CI Module in the CI slot with the contact side forward. The logo on the CI Module must be facing upward. Do not use excessive force. Make sure the module is not bent in the process.

Checking CI Module information

NOTE

Make sure that the CI Module is properly inserted.

• This menu is only available for digital stations.

•

Press MENU and the “MENU” screen displays.

Press c/d to select “Digital Setup”.

2 3

Press a/b to select “CI Menu”, and then press OK.

The content of this menu depends on the provider of

• the CI Module.

Module

General information on CI Module displays.

Adjustment parameters of each CA Card displays.

Enquiry

You can input numerical values such as passwords here.

NOTE

The content of each screen depends on the provider of

• the CI Module.

Removing the CI Module

Remove the CI slot cover.

Press the EJECT

button to pop out the CI module from the CI slot.

Selecting CI slot

The AVC System has two CI slots. You should select which CI slot is used for each broadcast standard.

Press MENU and the “MENU” screen displays.

Press c/d to select “Digital Setup”.

2 3

Press a/b to select “CI Select”, and then press

OK.

Press a/b to select the broadcast standard (DTV or SAT1, etc), and then press OK.

DTV

SAT1

SAT2

SAT3

SAT4

Press c/d to select “CI 1” or “CI 2”, and then press OK.

CI 1 CI 2

AQUOS LINK

Controlling HDMI devices using AQUOS LINK

What is AQUOS LINK?

Using the HDMI CEC protocol, with AQUOS LINK you can interactively operate compatible system devices (AV amplifier, DVD player/recorder, Blu-ray player/recorder) using a single remote control unit.

NOTE

AQUOS LINK-compatible AQUOS AUDIO speaker system and AQUOS Recorder are scheduled

• to be on sale after the release of this TV (as of October 2008).

What you can do with AQUOS LINK

One Touch Recording (DTV/SAT only)

✔

You do not have to search for the remote control unit of your recording device. Press the REC E or REC STOP H buttons inside the flip cover to start/stop recording what you see on the recorder.

✔

One Touch Play

When the TV is in standby mode, it will automatically turn on and play back the image from the HDMI source.

✔

Single remote control operation

AQUOS LINK automatically recognises the connected HDMI devices and you can control the TV and the devices as if using a universal remote control unit.

✔

Operating Title list of external devices

In addition to displaying the TV’s own Timer list (Page 19), you can also call up the external player’s Top menu or AQUOS BD Player’s/AQUOS Recorder’s Title list provided that the devices support AQUOS LINK.

✔

Multiple control of HDMI devices

You can select which HDMI device to operate using the OPTION button.

NOTE

When you use AQUOS LINK, make sure to use a certified HDMI cable.

• Point the remote control unit toward the Display, not to the connected HDMI device.

• Video noise may occur depending on the type of HDMI cable used. Make sure to use a certified

• HDMI cable. Up to three HDMI recording devices, one AV amplifier and two players can be connected using

• this system. These operations affect the HDMI device selected as the current external source. If the device

• does not operate, turn on the device and select the appropriate external source using b. When you insert/remove HDMI cables or change connections, turn on all connected HDMI

• devices before turning on the TV. Confirm that picture and audio are correctly output by selecting “HDMI1”, “HDMI2” or “HDMI3” from the “INPUT SOURCE” menu.

AQUOS LINK connection

First connect the AQUOS AUDIO speaker system or an AQUOS BD Player/AQUOS Recorder that supports the HDMI CEC protocol.

NOTE

Refer to the operation manual of the device to be connected for further details.

• After unplugging connection cables or changing the connection pattern, turn on the main power of the Display after all relevant

• devices’ power have been turned on. Change the external input source by pressing b, select the appropriate external source and verify the audiovisual output. The cables illustrated in the following explanation are commercially available items.

•

AQUOS LINK

Connecting an AQUOS BD Player/AQUOS Recorder via the AQUOS AUDIO speaker system

Optical

audio cable

HDMI-certified cable

AQUOS BD Player/ AQUOS Recorder

AQUOS AUDIO

speaker system

AQUOS LINK Setup

Connecting an AQUOS BD Player/AQUOS Recorder only

HDMI-certified

cable

AQUOS BD Player/

AQUOS Recorder

AQUOS LINK Control

Set to “On” to enable AQUOS LINK functions.

Press MENU and the “MENU” screen displays.

Press c/d to select “Option”.

2 3

Press a/b to select “AQUOS LINK Setup”, and then press OK.

Press a/b to select “AQUOS LINK Control”, and then press OK.

Press c/d to select “On”, and then press OK.

Auto Power On

If this is activated, the One Touch Play function is enabled. While the TV is in standby mode, it automatically turns on and plays back the image from the HDMI source.

Repeat steps 1 to 3 in AQUOS LINK Control.

Press a/b to select “Auto Power On”, and then press OK.

Press c/d to select “On”, and then press OK.

NOTE

The factory default for this item is “Off”.

•

Selecting Recorder

Here, you can select a recorder for the recording from several connected recorders.

Repeat steps 1 to 3 in AQUOS LINK Control.

Press a/b to select “Selecting Recorder”, and

then press OK.

Select the recorder, and then press OK.

NOTE

If you have connected the AQUOS AUDIO speaker system

• between the AVC System and an AQUOS Recorder, the external source’s indication changes (e.g. from “HDMI1” to “HDMI1 (Sub)”).

Selecting Channel Key

This function allows you to select the channel of the connected HDMI device using the TV’s remote control unit.

Repeat steps 1 to 3 in AQUOS LINK Control.

Press a/b to select “Selecting Channel Key”,

and then press OK. Press a/b to select the input source of the

connected HDMI device you want to control using the TV’s remote control unit, and then press OK.

Press c/d to select “On”, and then press OK.

Using Genre Info.

This function allows you to automatically switch to the appropriate sound mode depending on the genre information included the digital broadcast.

Repeat steps 1 to 3 in AQUOS LINK Control.

Press a/b to select “Using Genre Info.”, and

then press OK. Press c/d to select “On”, and then press OK.

AQUOS LINK

Operating an AQUOS LINK device

AQUOS LINK allows you to operate the HDMIconnected device with a single remote control unit.

Open the remote control unit’s flip cover. Press PLAY I to start playback of a title.

See the right column, section “Playback of titles

•

using AQUOS LINK” if you want to start playback using the list of the titles of the AQUOS BD Player/ AQUOS Recorder.

Press FWD J to fast forward. Press REV G to reverse. Press STOP H to stop. Press B to turn the HDMI-connected device on/off.

Listening with the AQUOS AUDIO speaker system

You can choose to listen to the TV sound only from the AQUOS AUDIO speaker system.

Open the remote control unit’s flip cover, and then press OPTION.

AQUOS LINK Menu

Recorder EPG Top Menu/Title List Media change

By AQUOS AUDIO SP

By AQUOS SP Sound mode change Setup Menu Model select

Press a/b to select “By AQUOS AUDIO SP”, and then press OK.

The sound from the TV speaker and headphone

• terminal is silenced and only the sound from the AQUOS AUDIO speaker system is audible.

Listening with the AQUOS TV speaker system

You can choose to listen to the TV sound only from the AQUOS TV speaker system.

Open the remote control unit’s flip cover, and

then press OPTION. Press a/b to select “By AQUOS SP”, and then

press OK.

Manually changing the AQUOS AUDIO speaker system’s sound mode

Open the remote control unit’s flip cover, and then press OPTION.

Press a/b to select “Sound mode change”.

The sound mode changes every time you press OK.

Refer to the operation manual of the AQUOS AUDIO

• speaker system for details.

Calling up the menu of an external device connected with the TV via HDMI

You can call up the menu of an HDMI CEC-compatible external device (player, recorder, decoder, etc.) using the “Setup Menu” function.

Open the remote control unit’s flip cover, and

then press OPTION.

Press a/b to select “Setup Menu”, and then press OK.

NOTE

If a connected device does not have this function or the

• device is in a status where the menu cannot be displayed (recording, entering standby, etc.), this function may not be available.

Playback of titles using AQUOS LINK

This section explains how to play back a title in the AQUOS BD Player/AQUOS Recorder.

Open the remote control unit’s flip cover, and

then press OPTION. Press a/b to select “Top Menu/Title List”, and

then press OK.

The linked recorder now powers on and the TV

• automatically selects the appropriate external input source. The title list data from the connected AQUOS BD

• Player/AQUOS Recorder displays.

Select the title with a/b/c/d, and then press

PLAY I.

Selecting media type for CEC-compatible recorder

If your recorder has multiple storage media, select the media type here.

Open the remote control unit’s flip cover, and then press OPTION.

Press a/b to select “Media change”, and then press OK.

Select the desired medium, such as DVD recorder or HDD. The media type changes every time you press OK.

HDMI device selection

If multiple HDMI devices are connected in a daisy chain, you can specify which device to control here.

Open the remote control unit’s flip cover, and then press OPTION.

Press a/b to select “Model select”, and then press OK. The HDMI device changes every time you press OK.

Recording via the AQUOS Recorder EPG (only for recorders)

You can call up the CEC-compatible recorder’s EPG and preset timer recordings using the TV’s remote control unit.

Open the remote control unit’s flip cover, and

then press OPTION.

Press a/b to select “Recorder EPG”, and then press OK.

The external input source switches and the recorder’s

• EPG is displayed.

Select the programme to record.

Refer to the operation manual of the recorder for details.

•

Menu operation

What is the MENU?

You need to call up the OSD to perform settings for the TV. The OSD for the settings is called “MENU”.

• The “MENU” enables various settings and adjustments.

• The “MENU” can be operated with the remote control unit.

•

Common operations

Display the MENU

screen

Press MENU and the “MENU” screen displays.


DYNAMIC

OPC [Off]

Backlight [+14] –16

Contrast

Brightness

Colour

Tint

Sharpness

Advanced

Reset

[+30]

[0]

–30

[0]

–30

[0]

–30

[0]

–10

Exit the MENU

screen

+16

+40

+30

+10

Select an item

Press a/b/c/d to select/adjust the desired menu, and adjust the item to the desired level, and then press OK.

Press 6 to return to the previous “MENU” page.

Selecting in the MENUE

ECO

Energy Save

No Signal Off

No Operation Off

Sleep Timer

Selecting optionsE

[Off]

[Disable]

The operation will exit the “MENU” screen if you press END before it is completed.

NoYes

NOTE

“MENU” options differ in the selected input modes, but the operating procedures are the same.

• The screens in the operation manual are for explanation purposes (some are enlarged, others cropped) and may vary slightly from the actual screens.

•

Items with 4 cannot be selected for various reasons.

Operation without a remote control unit

This function is useful when there is no remote control unit within your reach.

Press MENU and the “MENU”

About the Guide Display

The Guide Display at the bottom of the screen shows operations with the OSD.

screen displays. Press Pr/s instead of a/b

or ik/l instead of c/d to select the item.

Press b to complete the setting.

NOTE

The “MENU” screen will disappear if left unattended for several

• seconds.

The bar above is an operational guide for the remote control unit. The bar will change in accordance with each menu setting screen.

: Select : Enter

: Back

: End

Basic adjustment

Picture Settings


DYNAMIC

OPC [Off]

Backlight [+14] –16

Contrast

Brightness

Colour

Tint

Sharpness

Advanced

Reset

[+30]

[0]

–30

–10

+16

+40

+30

+10


OPC

Automatically adjusts the brightness of the screen.

Item

Off: The brightness is fixed at the value set in “Backlight”. On: Automatically adjusts. On:Display: Displays the OPC effect on the screen while

adjusting the brightness of the screen.

NOTE

When set to “On”, the TV senses the surrounding light and

• automatically adjusts the backlight brightness. Make sure no object obstructs the OPC sensor, which could affect its ability to sense surrounding light.


Picture adjustments

Adjusts the picture to your preference with the following picture settings.

Adjustment items

Selectable

items Backlight Contrast Brightness

Colour

Tint

Sharpness

c button d button

The screen dims The screen brightens

For less contrast For more contrast

For less brightness For more brightness

For less colour intensity

Skin tones become purplish

For more colour intensity

Skin tones become greenish

For less sharpness For more sharpness


Advanced

This TV provides various advanced functions for optimising the picture quality.

[ 0]

f30

[ 0]

100Hz

Film Mode

Active Contrast

Gamma setup

DNR

3D-Y/C

Monochrome

Range of OPC

f30

[ 0]

f30

[ 0]

f30

[ 0]

f30

C.M.S.-Hue

This function adjusts the hue of a selected colour using a sixcolour adjustment system.

C.M.S.-Saturation

This function increases or decreases the saturation of a selected colour using a six-colour adjustment system.

Colour space

You can select the range of colour for reproducing colour combinations.

Item

Standard: Reproduces standard colour. Advanced:

Reproduces brighter colour, taking advantage of the

backlight

Colour Temp.

Adjusts the colour temperature to give the best white image.

Item

High: White with bluish tone. Mid-High: Middle: Natural tone. Mid-Low: Low: White with reddish tone. R Gain/G Gain/B Gain: Adjusts the white balance by changing

Intermediate tone between “High” and “Middle”.

Intermediate tone between “Middle” and “Low”.

the value of “R Gain”, “G Gain” or “B Gain”.

100Hz

“100Hz” technology provides superior solutions for digital display picture quality removing motion blur.

NOTE

This effect is greater on fast moving images.

• “100 Hz” will have no effect in the following cases;

•

1) The type of signal received is a PC signal.

2) An OSD is being displayed.

3) Teletext is activated. If images appear blurred, set the “100Hz” to “Off”.

•

e30

Basic adjustment

Film Mode

Automatically detects a film-based source (originally encoded at 24 or 25 frames per second, depending on the vertical frequency), analyses it and then recreates each still film frame for high-definition picture quality.

Active Contrast

Automatically adjusts the contrast of an image according to the scene.

Gamma setup

Select the tone difference of the brightness and darkness of the picture according to the type of programme watched from the four items (“Mode1”, “Mode2”, “Mode3” or “Mode4”).

NOTE

When “AV MODE” is set to “x.v.Colour” or “PC”, you can not

• change the gamma selection.

DNR

“DNR” produces a clearer image (“Off”, “High”, “Middle”, “Low”).

3D-Y/C

Provides high quality images with minimal dot crawl and cross colour noise by detecting changes in the image.

Item

Standard: Normal adjustment. Fast: Sets the optimum image quality for fast-moving

images.

Slow: Sets the optimum image quality for slow-moving

images.

NOTE

“3D-Y/C” may not operate depending on the input signal type or

• when the input signal is noisy. “3D-Y/C” has even more effect on composite video signals (CVBS).

•

Monochrome

For viewing a video in black & white.

Range of OPC

The brightness level range of the OPC sensor’s automatic adjustments can be set according to your preferences. The adjustment range of the OPC sensor can be set to a maximum of e16 and a minimum of f16.

Selectable

items Max. Min.

f16 through e16

NOTE

This function is available only when the “OPC” setting is set to “On”

• or “On:Display”. The maximum setting cannot be set to a smaller number than the

• minimum setting. The minimum setting cannot be set to a bigger number than the

• maximum setting. The maximum and minimum settings cannot be set to the same

• number. Depending on the brightness of the surrounding light, the OPC

• sensor might not operate if the adjustment range is small.

Description

AV MODE

“AV MODE” gives you several viewing options to choose from to best match the system environment, which can vary due to factors like room-brightness, type of programme watched or the type of image input from external equipment.

Press AV MODE.

Each time you press AV MODE, the mode

changes.

You can also switch the mode on the “Picture” and

•

“Audio” menu screen by pressing AV MODE.

Item

STANDARD: For a highly defined image in a normally

bright room.

MOVIE: For viewing a movie in a darkened room. MOVIE (Living room): For viewing a movie such as CG

animation with dynamic picture quality.

GAME: For playing of video games. PC*: For PC. x.v.Colour**: Produce realistic colour on the TV screen

unlike any other signal.

USER: Allows you to customise settings as desired. You

can set the mode for each input source.

DYNAMIC (Fixed): For a clear-cut image emphasising

high contrast for sports viewing (The “Picture” and “Audio” settings cannot be adjusted).

DYNAMIC: For a clear-cut image emphasising high

contrast for sports viewing.

NOTE

The item marked with * is available only when selecting

• “HDMI1”, “HDMI2”, “HDMI3” or “EXT4” from the “INPUT SOURCE” menu. The item marked with ** is available only when accepting

• an “x.v.Colour” signal through an HDMI terminal.

Audio Settings

Audio

DYNAMIC

Treble

Bass

Balance

Surround

Sound Mode [Mode4]

Reset

[ 0] –15

[ 0]

–15

[ 0]

+15

[Off]

Audio

Audio adjustment

You can adjust the sound quality to your preference with the following settings.

Selectable

items Treble Bass Balance

c button d button

For weaker treble For stronger treble

For weaker bass For stronger bass

Decrease audio from the right speaker

Decrease audio from the left speaker

Basic adjustment

[0]

Audio

Surround

This function allows you to enjoy realistic live sound.

Audio

Sound Mode

This function allows you to select the sound mode depending on the type of programme watched.

Item

Mode1: For viewing movie and documentary

programmes.

Mode2: For viewing music and sports programmes. Mode3: For viewing news and variety programmes. Mode4: Normal viewing mode.

Power Save Settings

ECO

Energy Save

No Signal Off

No Operation Off

Sleep Timer

ECO

[ Standard]

[Disable]

Energy Save

This function enables you to automatically reduce the backlight brightness in order to decrease the power consumption and increase the backlight life span.

Item

Standard: Reduces the backlight brightness by 20%. Advanced: Reduces the backlight brightness by 30%. Off: The backlight brightness is the same value of your

settings in the selected “AV MODE”.

NOTE

This function does not work when “AV MODE” is set to

• “DYNAMIC (Fixed)”.

“Energy Save” status icons

Icon Description

EXAMPLE


DYNAMIC

OPC [On]

Backlight [+14] –16

Contrast

htness

Bri

When “OPC” is set to “On” or “On:Display”, an “Energy

• Save” status icon appears to the left of “OPC” in the “Picture” menu. When “OPC” is set to “Off”, an “Energy Save” status icon

• appears to the left of “Backlight” in the “Picture” menu.

[+30]

0 –30

+16

+40

+30

EXAMPLE

BBC1

ATV

PAL I NICAM STEREO

Subtitle Teletext Off:

New Information

ECO

No Signal Off

When set to “Enable”, the TV will automatically enter standby mode if there is no signal input for 15 minutes.

Five minutes before the TV enters standby mode, the

• remaining time displays every minute.

NOTE

Even if a TV programme finishes, this function may not

• operate because of interference from other TV stations or other signals.

ECO

No Operation Off

The TV will automatically enter standby mode if no operations are performed during the time span you set (“30min.” or “3hr.”).

Five minutes before the TV enters standby mode, the

• remaining time displays every minute.

ECO

Sleep Timer

“Energy Save” is set to “Standard”.

“Energy Save” is set to “Advanced”.

When “Energy Save” is set to “Standard” or “Advanced”, “Energy Save” status icons appear in the “Picture” menu and channel information windows as shown in the right column.

Allows you to set a time when the TV automatically enters standby mode.

NOTE

Select “Off” to cancel the sleep timer.

• When the time has been set, countdown automatically

• starts. Five minutes before the preset of time expires, the

• remaining time displays each minute.

Basic adjustment

Channel Settings

Auto Installation

Setup

Auto Installation

The TV automatically detects and stores all available services in your area. This function also allows you to perform the channel setting for digital, satellite and analogue individually and reconfigure the settings after the initial auto installation has been completed.

Press c/d to select “Yes”, and then press OK.

Press a/b/c/d to select the desired

language, and then press OK.

You cannot set the Home/Store setting and the country

• setting in “Auto Installation” in the “Setup” menu. If you want to reconfigure those settings, automatically execute initial auto installation after executing “Reset” from the “Setup” menu.

•

The current country setting is displayed on the screen.

Press a/b to select the broadcast standard

you want to search, and then press OK.

Digital Search

After selecting the service you want to search, either “Terrestrial” or “Cable”, refer to “Digital Search” setting on pages 11–13.

NOTE

The “Digital Search” has a “Reset” function. This function

• allows you to reset all setting values.

Analogue Search

The TV searches for, sorts and stores all the receivable TV stations. Refer to “Analogue Search” setting on page 13.

Satellite Search

After selecting “Satellite Search”, the current DVB-S setting screen is displayed. Refer to the “Satellite Search” setting on pages 14–15.

NOTE

After selecting “Next” in the DVB-S setting screen, you

• need to select your preferred satellite broadcast to start searching. The “Satellite Search” has a “Reset” function. This allows

• you to reset all setting values.

Programme Setup

Setup

Programme Setup

You can reconfigure each service setting automatically or manually.

Press a/b to select the broadcast standard you want to reconfigure, and then press OK.

Digital Setting

Satellite Setting

Analogue Setting

Digital Setting

Additional Search

Use this menu to add new services automatically after auto installation has been completed.

Manual Search

Add new services within a specified frequency band.

Enter the frequency using the 0–9 numeric buttons.

• You can perform “Manual Search” with a service number

• only when the five Nordic countries have been selected in the country setting.

Manual Adjust

Configure various settings for each service using the Colour (R, G, B) buttons.

Service

No.

DTV 993

DTV 994 ✔ SIT 2

DTV 995 ✔SIT 1

DTV 999 HD Monosco

: Lock

Press a/b to select the desired service.

Press the colour button on the remote control

Name SIT 3

: CH Skip

Lock

: Sort

Skip

unit corresponding with the item you want to reconfigure.

The ✔ mark indicates the operation is set to on. Each

• time the colour button is pressed, you can switch the corresponding operation on/off.

Old

LCN

Basic adjustment

Buttons for Manual Adjust operation

Lock: Press R button.

When the service is locked, you must enter your PIN whenever you tune to the service.

CH Skip: Press G button.

Services with a ✔ mark are passed over when pressing

Pr/s on the Display or remote control unit.

Sort: Press B button.

The item position of services can be sorted.

Press a/b to select the service whose item position you want to move, and then press OK.

DTV 994 ✔ SIT 2

DTV 995 ✔SIT 1

Press a/b to move it to the desired position, and then press OK.

DTV 994✔SIT 1

DTV 995✔SIT 2

Repeat steps 1 and 2 until all desired service

items are sorted.

Cable Setting

Additional Search

Use this menu to add new services automatically after auto installation has been completed. Follow steps 1 to 5 in the right column on page 12.

Manual Search

Add new services within a specified frequency band. After setting the items on the following screen, the TV starts searching.

Refer to the table about menu items in the left column on

• page 13.

Frequency

Symbol rate

QAM Modulation

Search start

[47.0]

[6900]

[64]

47.0 MHz

Satellite Setting

Before selecting the type of search in “Satellite Setting”, you need to select the satellite broadcast.

SAT1 [ASTRA 1]

SAT2 [Hot Bird 13E]

4 SAT3 [None]

SAT4 [Turksat]

Additional Search

Use this menu to add new services automatically after auto installation has been completed. Follow steps 1 to 6 in the right column on page 14.

Manual Search

Add new services within a specified frequency band. After setting the items on the following screen, select “Yes” from “Search start” menu.

Band

Frequency

Symbol rate

Search start

Manual Adjust

This function is the same as in “Digital Setting”. Refer to “Manual Adjust” in “Digital Setting”.

[Vert/Low]

[9944]

[27500]

Vert/Low

Vert/High

Horiz/Low

Horiz/High

Manual Adjust

This function is the same as in “Digital Setting”. Refer to “Manual Adjust” in “Digital Setting”.

Basic adjustment

Analogue Setting

You can reconfigure the analogue TV channels settings automatically or manually.

Additional Search

Use this menu to add new channels automatically after auto installation has been made.

Start searching channels after selecting the colour system.

•

Manual Adjust

Use this menu to set up analogue TV channels manually.

After selecting “Yes” on the screen, press a/b/ c/d to select the channel you want to set and

then press OK.

Fine

You can adjust the frequency to the desired position.

NOTE

•

Adjust while checking the background picture as a reference.

•

Instead of pressing c/d to adjust the frequency, you can set by directly entering the frequency number of the channel with 0–9 numeric buttons.

EXAMPLE

179.25 MHz: Press 1 s 7 s 9 s 2 s 5.

•

49.25 MHz: Press 4 s 9 s 2 s 5 s OK.

•

Colour sys.

Select the optimum colour system to receive (“Auto”, “PAL”, “SECAM (L/L’)”).

Sound sys. (Broadcasting systems)

Select the optimum sound systems (Broadcasting systems) to receive (“B/G”, “D/K”, “I”, “L/L’”).

Label

When a TV channel sends its Network Name, the “Auto Installation” detects the information and assigns a name to it. However, you can change channel names individually.

Press a/b/c/d to select each character of the

new name for the channel, and then press OK. Repeat step 1 above until the name is fully spelt

out.

Skip

Channels with “Skip” set to “On” are passed over when using Pr/s even if selected while watching the image from the TV.

Decoder

When connecting a decoder to the AVC System, you need to select “EXT1” or “EXT2”.

NOTE

The factory preset value is “Off”.•

Lock

You can block the viewing of any channel.

NOTE

See “Child Lock” for setting a PIN.

• When “Lock” is set to “On” for a channel, “Child lock has

• been activated” displays, and the image and sound of the channel are blocked. When pressing 6 while “Child lock has been activated”

• displays, the PIN input window will display. Inputting the correct PIN unlocks the “Child Lock” temporarily until the power is turned off.

Sort

Channel positions can be sorted freely.

Press c/d to select “Yes”, and then press OK.

Press a/b/c/d to select the channel you want

to move, and then press OK. Press a/b/c/d to move it to the desired

position, and then press OK.

Repeat steps 2 and 3 until all desired channels are sorted.

Erase Programme

Channels can be erased individually.

Press c/d to select “Yes”, and then press OK.

Press a/b/c/d to select the channel you want

to erase, and then press OK.

A message window pops up.

•

Press c/d to select “Yes”, and then press

OK to erase the selected channel. All the

subsequent channels move up.

Repeat steps 2 and 3 until all desired channels are erased.

NOTE

The name can be five characters or less.

• If a channel name is less than five characters, select “END”

• to set the channel name.

Basic adjustment

Password/Parental lock settings Language Settings (language,

subtitle, multi audio)

Setup

Child Lock

Allows you to use a PIN to protect certain settings from being accidentally changed.

Change PIN

Enter the four-digit number as a PIN using 0–9

numeric buttons. Enter the same four-digit number as in step 1 to

confirm.

“The system PIN has been changed successfully” displays.

•

You can select a OSD language from the “Setup” menu. Select from among 23 languages (Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian, Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian).

Setup

Language

Digital Setup

Subtitle

NOTE

To view a locked channel, you must enter the PIN (See pages 35

• and 36 for locking channels from viewing in DTV, SAT and ATV mode). When you select a locked channel, a PIN prompt message pops up. Press 6 to display the PIN input window.

Cancel PIN

Allows you to reset your PIN.

NOTE

•

As a precautionary measure, make a note of your PIN on the back of this operation manual, cut it out and keep it in a safe place that children cannot reach.

Parental rating

This function allows DTV services to be restricted. It prevents children from watching violent or sexual scenes that may be harmful.

NOTE

•

“Universal viewing” and “Parental approval pref.” are ratings used exclusively in France.

•

Refer to page 59 for details about ratings.

Set up to two preferred subtitle languages (including subtitles for the hearing impaired) to display if subtitles are available.

Selectable items

1st Language E 2nd Language

For hearing impaired

Switching subtitle languages

Each time you press [ on the remote control unit, the subtitle switches.

1st LanguageOff

••••••

Set “For hearing impaired” to “Yes”

Subtitles for the hearing impaired have priority over each of the subtitle language settings (Example: “1st Language”, “2nd Language”, etc.).

EXAMPLE

(For hearing impaired)

NOTE

Subtitles will not be displayed when the service does not contain

• subtitle information.

2nd Language

1st Language1st Language

Option

Digital Audio Language

Set up to three preferred multi audio languages to display if the audio languages are available.

Switching the multi audio languages

Each time you press 2 on the remote control unit, the audio language switches.

Useful Viewing functions

Selecting the picture size

Selecting the WSS picture size automatically

Setup

WSS

The “WSS” allows the TV to switch automatically among the different picture size.

NOTE

Use “WIDE MODE” if an image does not switch to the

• appropriate picture size. When the broadcast signal contains no “WSS” information, the function will not work even if enabled.

Selecting the WSS picture size manually

Setup

4:3 Mode

The “WSS” signal has 4:3 auto-switching that allows you to select between “Normal” and “Panorama”.

Item

Normal: Normal range keeping 4:3 or 16:9 aspect ratio. Panorama: Wide image without side bars.

WSS signal 4:3 screen

4:3 mode “Panorama”4:3 mode “Normal”

Selecting the picture size manually

You can select the picture size. Selectable picture size varies with the type of signal received.

Item (for SD [Standard-Definition] signals)

Normal: Keeps the original aspect ratio in a full screen

display.

Zoom 14:9: For 14:9 letterbox pictures. A thin side bar

appears on each side, and you may also see bars on the top and bottom with some programmes.

Panorama: In this mode, the picture is stretched toward

each side of the screen. The picture may appear similar to “Full” depending on broadcast signals.

Full: For 16:9 squeeze pictures. Cinema 16:9: For 16:9 letterbox pictures. Bars may

appear on the top and bottom with some programmes.

Cinema 14:9: For 14:9 letterbox pictures. Bars may

appear on the top and bottom with some programmes.

Item (for HD [High-Definition] signals)

Full: Displays with an Overscan image. Crops all sides of

screen.

Underscan: Displays with an Underscan image only

when receiving a 720p signal. Displays with the HighDefinition image adjusted optimally. Noise may appear on the edge of the screen with some programmes.

Dot by Dot: Displays an image with the same number

of pixels on the screen when receiving 1080i/1080p signals only.

NOTE

Some items do not appear depending on the type of

• received signal.

Press f.

The “WIDE MODE” menu displays.

• The menu lists the “WIDE MODE” options selectable

• for the type of video signal currently received.

Press f or a/b while the “WIDE MODE”

menu displays on the screen.

As you toggle the options, each is immediately

• reflected on the screen. There is no need to press OK.

Basically, if you set “WSS” to “On” in the “Setup” menu, the optimum “WIDE MODE” is automatically chosen for every broadcast, VCR or DVD player/ recorder.

NOTE

•

Even if you select your desired “WIDE MODE” manually, the TV may automatically switch to the optimum “WIDE MODE” depending on the signal received when “WSS” is set to “On”.

Useful Viewing functions

Selecting the recording picture size manually

Digital Setup

REC Picture Size

You can use this menu to set the appropriate picture size for viewing a 16:9 format TV programme on a 4:3 TV.

Setting to “4:3 TV” Setting to “16:9 TV”

NOTE

This function must be set before recording.

•

Automatic volume adjustment

Option

Auto Volume

Different sound sources sometimes do not have the same volume level, such as a programme and its commercial breaks. The Automatic Volume Control (Auto Volume) reduces this problem by equalizing levels.

Outputting audio only

Option

Audio Only

When listening to music from a music programme, you can set the TV off and enjoy audio only.

Item

Off: Both screen images and audio are output. On: Audio is output without a screen image.

Selecting the HDMI picture size automatically

Setup

HDMI Auto View

This function allows you to automatically change to the appropriate picture size when viewing an HDMI signal using the HDMI1, 2 and 3 terminals.

Other picture and audio settings

Adjusting image position

Setup

Position

For adjusting a picture’s horizontal and vertical position.

Item

H-Pos.: Centres the image by moving it to the left or

right.

V-Pos.: Centres the image by moving it up or down.

NOTE

Adjustments are stored separately for each input source.

• Depending on the input signal type or “WIDE MODE”

• setting, a position setting may not be available. This function is not available for DTV/SAT broadcasts with

• MHEG signals.

Useful Viewing functions

Display Settings

Channel display

You can display the channel information by pressing p on the remote control unit.

DTV Mode ATV Mode

BBC1

DTV TV

Audio (ENG) STEREO :

Dolby Digital Plus Video

Subtitle ENG 1/3:

New Information

001

1080i:

BBC2

ATV

PAL I

NICAM STEREO

Subtitle Teletext Off:

New Information

SAT Mode

SAT1 TV

Audio (ENG) STEREO :

Video 1080i :

Subtitle ENG 1/3:

New Information

Four digit numbers (e.g. 0001) are displayed after

BBC2

0001

selecting the five Nordic countries in the country setting.

Time display in channel information

You can display the time information included in DTV/ SAT and teletext broadcasts.

NOTE

Skip step 1 if receiving DTV/SAT broadcasts.

•

Select a TV channel (The time information is

automatically captured).

Press p. The channel display will appear on the screen.

Press p again within the several seconds that the channel display is on the screen. Time information will be shown in the lower-right corner of the screen for several seconds.

Even when you change the TV channel, you can

display the time information with steps 2 and 3 above.

NOTE

If acquired successfully, the time information will appear in

• the upper-right corner of the screen by pressing MENU.

Time and Title display

Option

Time Display

This function allows you to display the clock time in the lower-right corner of the screen.

Item

On: Displays the clock time. On (half-hourly): Displays the clock time in 30-minute

increments.

Off: Hides the clock time.

Time Format

You can select the time format (either “24HR” or “AM/ PM”) for the clock time.

Option

Game Play Time

This function allows you to display the elapsed time on the screen when “AV MODE” is set to “GAME”.

Item

On: Under connecting a game console to the AVC

System, the elapsed time is displayed in 30-minute increments after you start playing a game.

Off: Hides the time.

NOTE

This menu is not selectable if the input source is “TV” or

• “USB”.

Option

Programme Title Display

This function allows you to display programme information such as the title and airtime by tuning a channel.

NOTE

This function is available only when the DTV/SAT mode is

•

selected.

Other useful features

Setting when using external devices

Input source settings

Option

Input Select

For setting the signal type of external equipment.

Item

EXT1: Y/C, CVBS, RGB EXT2: Y/C, CVBS, RGB EXT8: Auto, S-VIDEO, VIDEO

NOTE

If no (colour) image displays, try changing to another

•

signal type.

Check the operation manual of the external equipment for

• the signal type. When the signal type is set to “Auto”, the input terminal

• where a cable is connected is automatically selected.

Setup

Input Label

You can label each input source with a custom description.

Press b to select the desired input source.

Go to “MENU” > “Setup” > “Input Label”.

Press a/b/c/d to select each character of the

new name for the input source, and then press

OK.

Skipping specified inputs

Setup

Input Skip

This setting allows you to skip the SCART, HDMI, RGB, ATV, DTV or SAT input on the Input Source Selection operation.

EXT1 (SCART)

EXT2 (SCART)

EXT4 (RGB)

HDMI1

HDMI2

HDMI3

ATV

DTV

SAT1

SAT2

Yes

Colour system settings

Option

Colour System

You can change the colour system to one that is compatible with the image on the screen.

NOTE

The factory preset value is “Auto”.

• If “Auto” is selected, the colour system for each channel

• is automatically set. If an image does not display clearly, select another colour system (e.g. “PAL”, “SECAM”).

DVD

– _

0 1 2 3 4 5 6 7 8 9

Repeat until the label is fully spelt out.

CLEAR

BACK

END

NOTE

The label can be six characters or less.

• When you want to set an input source label of less than six

• characters, select “END” to set the name.

INPUT SOURCE TV

EXT1 EXT2

DVD

EXT4 HDMI1 EXT6

NOTE

•

You cannot change labels if the input source is “TV” or “USB”.

Additional features

Option

Setting Display Colour

You can change the background colour of the OSD (menu screen), EPG screen, channel display and programme information, etc. to the blue, gray, red or green.

Setup

Wireless power link

When turning on the main power of the Display while “Wireless power link” is set to “Linked to main power”, the power of each wireless unit connected to the Display and AVC System will be turned on in conjunction with the main power of the Display.

Item

Linked to main power: The wireless unit’s power will be turned

on in conjunction with the main power of the Display.

Power always on: The wireless unit’s power will be usually

turned on.

Other useful features

Connecting a USB device

Connect a USB device to the AVC System as shown below.

Depending on the USB device, the TV may not be able to

• recognise the contained data. Use only alphanumeric characters for naming files.

• File names over 80 characters (may vary depending on

• character set) may not be displayed. Do not disconnect a USB device or memory card from the

• AVC System while transferring files, using the slide show function, when a screen is switching to another or before you exit “USB” from the “INPUT SOURCE” menu. Do not connect and disconnect a USB device from the

• AVC System repeatedly.

USB Photo Viewer/Music Player

In this mode, you can enjoy viewing photos and listening to music from external USB devices. Select “USB” from the “INPUT SOURCE” menu to enter this mode.

NOTE

You cannot enter this mode when there

• is no USB device connected to the AVC System. This mode is not available during DTV/

• SAT timer recording. “WIDE MODE” is fixed during this mode.

• “USER (USB)” is the default value for the “AV MODE”

• setting. Each time you press AV MODE, the mode changes between “USER (USB)”, “DYNAMIC (Fixed)”, “DYNAMIC” and “STANDARD”.

INPUT SOURCE TV

EXT1 EXT2 EXT3 EXT4 HDMI1 HDMI2 HDMI3 EXT8

USB

Photo Mode

Viewing thumbnails

Sample

Demo/Demo 01 Demo.jpg 2007:10:18 13:30:00 600KB 1600X1200

Buttons for thumbnail operations

Buttons Description

a/b/c/d (Cursor)

R button G button Y button B button

NOTE

•

When there are invalid photo files, the g mark will be displayed for the file.

•

You can see the file name, shooting date, file size and pixel size of the selected photo in the lower-left corner of the screen (shooting date is only available in the EXIF file format).

When selecting the folder icon with the 6 mark: Go back to the parent directory. When selecting a folder icon: Enter this directory. When selecting a photo thumbnail: Display the photo in full screen.

Select a desired item.

Return to the top menu.

Go back to the previous page.

Go to the next page.

Select BGM for the slide show.

Start the slide show.

Selecting modes and devices

Select mode

Photo Mode Music Mode

Select USB drive

Drive 1

Drive 5 Drive 6 Drive 7 Drive 8 Drive 9 Drive 10 Drive 11 Drive 12 Drive 13 Drive 14 Drive 15 Drive 16

Press c/d to select between “Photo Mode”

and “Music Mode”, and then press OK.

Press a/b/c/d to select the drive where you want to find your files, and then press OK.

NOTE

You do not need to select the drive in step 2 when there is

• only one drive in the connected USB device. 16 is the maximum number of drives that can be displayed.

•

Drive 2 Drive 3 Drive 4

Viewing photos in full screen

Buttons for full screen display operation

Buttons Description

c/d (Cursor)

R button

G button

B button

NOTE

Rotating photos only applies to the temporarily selected

• item and this setting is not saved.

Go to the previous/next photo in the same directory.

Return to the thumbnail selection screen.

Rotate the photo by 90 degrees to the left.

Rotate the photo by 90 degrees to the right.

Reveal/hide the Guide Display.

Other useful features

Slide show

Selecting the BGM

File name

Demo/Demo1

SONGS CLASSIC SONG_01.MP3 SONG_02.MP3

SONG_03.MP3

SONG_04.MP3 SONG_05.MP3 SONG_06.MP3 SONG_07.MP3 SONG_08.MP3 SONG_09.MP3

Playing:

SONG_02.MP3

Slide Show BGM:

SONG_03.MP3

Time

3:05 3:15

3:02

6:05 4:52 0:00 3:13 3:23 3:33

1:00 / 3:15

Buttons for slide show BGM select operation

Buttons Description

When selecting the folder icon with the 6 mark: Go back to the parent directory. When selecting a folder icon: Enter this directory. When selecting a music file: Play music.

a/b (Cursor) c (Cursor) d (Cursor)

R button G button Y button

Select a desired item.

Page up.

Page down.

Return to the thumbnail selection screen.

Stop music.

Play/Pause music.

Set the selected music to the slide show BGM.

B button

Reset the slide show BGM.

NOTE

Only one song can be set to the slide show BGM.

• Slide show BGM will be reset in the cases below.

•

Go back to the top menu.

• Change the “INPUT SOURCE”.

•

When there are invalid music files, the g mark will be

• displayed for the file. The displayed play time may differ slightly from the actual

• play time depending on the files.

Slide show

Buttons for slide show operation

Buttons Description

B button

NOTE

The selected BGM is played repeatedly.

• The slide show continues until you press 6.

• The slide show speed is approximately 10 seconds per

• photo.

Return to the thumbnail selection screen.

Reveal/hide the Guide Display.

Music Mode

File name

Demo/Demo1

ROOT CLASSIC SONG_01.MP3 SONG_02.MP3

SONG_03.MP3

SONG_04.MP3 SONG_05.MP3 SONG_06.MP3 SONG_07.MP3 SONG_08.MP3 SONG_09.MP3

Playing:

SONG_02.MP3 1:00 / 3:15

Buttons for Music Mode

Buttons Description

a/b (Cursor) c (Cursor) d (Cursor)

R button G button B button

NOTE

When there are invalid music files, the g mark will be

• displayed for the file. The displayed play time may differ slightly from the actual

• play time depending on the files.

When selecting the folder icon with the 6 mark: Go back to the parent directory. When selecting a folder icon: Enter this directory. When selecting a music file: Play music.

Select the desired item.

Page up.

Page down.

Return to the top menu.

Stop music.

Play/Pause music.

Turn off the screen image for audio only output.

Time

3:05 3:15

3:02

6:05 4:52 0:00 3:13 3:23 3:33

USB device compatibility

USB device

File system Photo file

format Music file

format

NOTE

Progressive format jpeg files are not supported.

• Music files in USB 1.1 devices may not be played properly.

• Operation using USB hubs is not guaranteed.

•

USB Memory, USB card reader (Mass Storage class)

FAT/FAT32

JPEG (.jpg) (DCF2.0 compliant)

MP3 (.mp3) Bitrate: 32k, 40k, 48k, 56k, 64k, 80k, 96k, 112k, 128k, 160k, 192k, 224k, 256k, 320kbps Sampling frequency: 32k, 44.1k, 48kHz

Other useful features

Gallery Mode

You can display pictures saved in USB devices for your wallpaper picture by pressing GALLERY on the remote control unit.

NOTE

Compatible files include those taken by digital cameras with the DCF 2.0 specification or mobile phones’ built-in cameras.

• Music cannot be played during this mode.

• SD card readers or USB hubs cannot be used.

• This mode continues when timer recording starts, but ends when timer viewing starts.

• During this mode, the power on the AVC System turns off while the main power on the Display is on (but standby/on indicator turns to

• red). Gallery Mode stops by pressing END on the remote control unit, and the TV returns to the normal viewing mode.

•

Basic operation for Gallery Mode

Displaying pictures saved in a USB device

Connect a USB device to the Display as shown below.

Press GALLERY on the remote control unit after

connecting a USB device to the Display.

A slide show will then start.

NOTE

Make sure that a USB device is connected before pressing

• GALLERY. The playback order is based on the save dates and cannot

• be changed. The device contains up to 100 files. If there are more than

• 100, some may not be displayed. The picture files should be in the top directory, and the files

• in any subordinate folders cannot be displayed. Refer to the right column Gallery Mode setting to change

• the viewing options. If there are incompatible files, an error displays for the file

• until the next compatible picture is displayed. Refer to pages 42–43 for details on connecting USB

• devices and device/file compatibility. Slide show will stop if you disconnect the USB device.

• Press END and go back to the normal viewing mode,

• and then press GALLERY again when you switch USB devices.

Gallery Mode setting

Option

Gallery Setup

You can adjust the display size, slide show time length, brightness and sleep timer.

Press MENU and the “MENU” screen displays.

Press c/d to select “Option”.

2 3

Press a/b to select “Gallery Setup”, and then press OK.

Press a/b to select the desired items, and then press OK.

Picture size

Colour mode

Slide show interval

Brightness

Auto Power Off

Repeat step 4 until the setting is complete.

NOTE

To start Gallery Mode during this setting, press GALLERY

• on the remote control unit.

Normal

Dot by Dot

Cinema

Half size screen

Other useful features

Picture size

Item

Normal: Keeps the original aspect ratio in a full screen

display.

Dot by Dot: Displays images with a 1:1 pixel ratio on the

screen without any scaling.

Cinema: Keeps the original aspect ratio in a full screen

display without showing any black bars.

Half size screen: Images are displayed in the centre of a

screen at half the size of a full screen image.

NOTE

The factory preset value is “Cinema”.

• When set to “Half size screen”, the background colour is

• black and this cannot be changed.

Colour mode

You can select your preferred colour mode.

Item

Mode1: Display brighter colour. Mode2: Display accurate colour in images.

Slide show interval

You can set the slide show time length for each picture to “15 sec.”, “30 sec.” or “30 min.”.

NOTE

The factory preset value is “15 sec.”.

• The sequence will repeat from the first picture after all the

• pictures have displayed.

Troubleshooting for Gallery Mode

Follow the possible solutions listed below when you see the error message.

(Example of an error display)

Possible Solution

Images that do not conform to the DCF 2.0 specification may

• not be displayed. If the images have been changed or edited on a PC, the data may change to a format that is incompatible with the TV.

The file size may be over 5MB. The file size can be reduced by

• selecting a smaller pixel size when taking pictures with a digital camera. The resizing function of digital cameras can also reduce the file

• size.

The pixel size may exceed 4,096 g 3,072. A smaller pixel size

• can be selected when taking pictures with a digital camera. The resizing function of digital cameras can also reduce the pixel

• size.

There may be incompatible or corrupt data. If only this error

• message is displayed, the top directory in the USB device may not contain any compatible JPEG files.

Brightness

You can set the brightness of the screen in Gallery Mode.

Item

Mode1: Lowest brightness with maximum power saving. Mode2: A brighter mode suitable for displaying pictures

in most situations.

Mode3: Suitable for displaying in brightly lit areas. Auto: Adjusts the brightness automatically depending on

the surrounding brightness.

NOTE

The factory preset value is “Mode1”.

•

Auto Power Off

You can set the time length until the TV automatically enters sleep mode to “30 min.”, “1 h”, “3 h” or “24 h”.

NOTE

The factory preset value is “1 h”.

•

Connecting a PC

HDMI Connection

HDMI-certified cable

Analogue Connection

ø 3.5 mm stereo

minijack cable

DVI/HDMI cable

ø 3.5 mm stereo minijack cable

RGB cable

HDMI1, 2 or 3

HDMI1

EXT4

Displaying a PC image on the screen

Selecting the picture size

You can select the picture size.

Press f.

The “WIDE MODE” menu displays.

•

Press f or a/b to select a desired item on the

menu.

NOTE

Connect the PC before making adjustments.

• Selectable picture size may vary with input signal type.

•

EXAMPLE

Normal Full

Item

Full: An image fully fills the screen. Cinema: For letterbox pictures. Bars may appear on the

top and bottom with some programmes.

Normal: Keeps the original aspect ratio in a full screen

display.

Dot by Dot: Displays an image with the same number of

pixels on the screen.

DVI/RGB conversion cable

EXT4

ø 3.5 mm stereo minijack cable

NOTE

The PC input terminals are DDC1/2B-compatible.

• Refer to page 49 for a list of PC signals compatible with

• the TV. A Macintosh adaptor may be required for use with some

• Macintosh computers. When connecting to a PC, the input signal type is

• automatically detected except 1,024 g 768 and 1,360 g 768 signals.

NOTE

Refer to page 38 for AV signals (See below).

• HDMI: 480i/480p/576i/576p/720p/1080i/1080p ANALOGUE RGB: 576p/720p (50Hz)/1080i

•

The ANALOGUE RGB terminal (PC) (EXT4) is not compatible with 480i/576i/1080p signals.

Connecting a PC

Adjusting the PC image automatically

This function enables the screen to be automatically adjusted to its best possible condition when the analogue terminals of the AVC System and PC are connected with a commercially available DVI/RGB conversion cable, etc.

Setup

Auto Sync.

30%

NOTE

When “Auto Sync.” is successful, “Auto Sync completed

• successfully” displays. If not, “Auto Sync.” failed. “Auto Sync.” may fail even if “Auto Sync completed

• successfully” displays. “Auto Sync.” may fail if the PC image has low resolution,

• has unclear (black) edges, or is moved while executing “Auto Sync.”. Be sure to connect the PC to the AVC System and switch

• it on before starting “Auto Sync.”. “Auto Sync.” can be executed only when inputting

• analogue signals through the EXT4 terminal.

Adjusting the PC image manually

Item

H-Pos.: Centres the image by moving it to the left or

right.

V-Pos.: Centres the image by moving it up or down. Clock: Adjusts when the image flickers with vertical

stripes.

Phase: Adjusts when characters have low contrast or

when the image flickers.

NOTE

For resetting all adjustment items to the factory preset

•

values, press a/b to select “Reset”, and then press OK. “Clock” and “Phase” in the “Fine Sync.” menu can be

• adjusted only when inputting analogue signals through the EXT4 terminal.

Selecting input resolution

Some input signals may have to be registered

• manually to display properly. The pairs of input signals (resolutions) in the list

• below are not distinguishable when received. In such cases, you have to set the correct signal manually. After setting once, it will display when the same signal (resolution) is input again.

Setup

Input Signal

1024 x 768

1360 x 768

Ordinarily you can easily adjust the picture as necessary to change image position using “Auto Sync.”. In some cases, however, manual adjustment is needed to optimise the image.

Setup

Fine Sync.

Press a/b to select the specific adjustment

item.

Press c/d to adjust the item to the desired position.

H-Pos. [ 90] ab

[ 39]

V-Pos.

Clock

Phase

Reset

[ 90]

[ 20]

(Example)

NOTE

You can only select the “Input Signal” on the “Setup” menu

• when receiving one of the two input signals listed above.

Connecting a PC

RS-232C port specifications

PC Control of the TV

When a programme is set, the TV can be controlled

• from the PC using the RS-232C terminal. The input signal (PC/video) can be selected, the volume can be adjusted and various other adjustments and settings can be made, enabling automatic programmed playing. Use an RS-232C serial control cable (cross type)

• (commercially available) for the connections.

NOTE

This operation system should be used by a person who is

• accustomed to using PCs.

RS-232C serial control cable (cross type)

Communication conditions

Set the RS-232C communications settings on the PC to match the TV’s communications conditions. The TV’s communications settings are as follows:

Baud rate:

Data length: Parity bit: Stop bit: Flow control:

Communication procedure

Send the control commands from the PC via the RS232C connector. The TV operates according to the received command and sends a response message to the PC. Do not send multiple commands at the same time. Wait until the PC receives the OK response before sending the next command. Make sure to send “A” with the carriage return and confirm that “ERR” returns before operating.

9,600 bps

8 bits

None

1 bit

None

Parameter

Input the parameter values, aligning left, and fill with blank(s) for the remainder (Be sure that four values are input for the parameter). When the input parameter is not within an adjustable range, “ERR” returns (Refer to “Response code format”).

0009

–30

100

0055

When “?” is input for some commands, the present setting value responds.

????

Response code format

Normal response

Return code (0DH)

Problem response (communication error or incorrect command)

ERR

Return code (0DH)

After sending the return code (0DH), make sure to send the line feed (0AH) as well.

Command format

Eight ASCII codes eCR

C1 C2 C3 C4 P1 P2 P3 P4

Command four digits

Command four digits: Command. The text of four characters. Parameter four digits: Parameter 0–9, blank, ?, minus

Parameter four digits

Return code

Connecting a PC

PC compatibility chart

Horizontal

Frequency

31.5 kHz 60 Hz

37.9 kHz 60 Hz

48.4 kHz 60 Hz

47.7 kHz 60 Hz

64.0 kHz 60 Hz

65.3 kHz 60 Hz

VGA

SVGA

XGA

WXGA

SXGA

SXGA+

Resolution

640 g 480

800 g 600

1,024 g 768

1,360 g 768

1,280 g 1,024

1,400 g 1,050

VGA, SVGA, XGA, WXGA, SXGA and SXGA+ are registered trademarks of International Business Machines Corporation.

RS-232C command list

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS

POWER SETTING P O W R 0 _ _ _ POWER OFF (STAND BY)

INPUT SELECTION A I T G D _ _ _ _ INPUT SWITCHING (TOGGLE)

CHANNEL D C C H * * _ _ TV DIRECT CHANNEL (1–99)

INPUT SELECTION B I N P 1 0 _ _ _ EXT1 (Y/C)

AV MODE SELECTION A V M D 0 _ _ _ TOGGLE

VOLUME V O L M * * _ _ VOLUME (0–60)

I T V D _ _ _ _ TV (CHANNEL FIXED)

I D T V _ _ _ _ DTV (CHANNEL FIXED)

I A V D * _ _ _ EXT1–4, 8 (1–4, 8), HDMI1–3

C H U P _ _ _ _ CHANNEL UP

C H D W _ _ _ _ CHANNEL DOWN

D T V D * * * _ THREE DIGIT DTV DIRECT

D T V D * * * * FOUR DIGIT DTV DIRECT

I D E G _ _ _ _ DIGITAL NETWORK CHANGE

D S C 1 * * * * DVB-S 1 DIRECT CHANNEL

D S C 2 * * * * DVB-S 2 DIRECT CHANNEL

D S C 3 * * * * DVB-S 3 DIRECT CHANNEL

D S C 4 * * * * DVB-S 4 DIRECT CHANNEL

D T U P _ _ _ _ DTV CHANNEL UP

D T D W _ _ _ _ DTV CHANNEL DOWN

I N P 1 1 _ _ _ EXT1 (CVBS)

I N P 1 2 _ _ _ EXT1 (RGB)

I N P 2 0 _ _ _ EXT2 (Y/C)

I N P 2 1 _ _ _ EXT2 (CVBS)

I N P 2 2 _ _ _ EXT2 (RGB)

I N P 8 0 _ _ _ EXT8 (AUTO)

I N P 8 1 _ _ _ EXT8 (Y/C)

I N P 8 2 _ _ _ EXT8 (CVBS)

A V M D 1 _ _ _ STANDARD

A V M D 2 _ _ _ MOVIE

A V M D 3 _ _ _ GAME

A V M D 4 _ _ _ USER

A V M D 5 _ _ _ DYNAMIC (Fixed)

A V M D 6 _ _ _ DYNAMIC

AVMD7 _ _ _PC

A V M D 8 _ _ _ x.v.Colour

A V M D 1 0 _ _ MOVIE (LIVING ROOM)

(5–7)

CHANNEL (1–999) (Non-Nordic countries)

CHANNEL (1–9999) (Nordic countries only)

(1–9999)

Vertical

Frequency

Analogue (D-

Sub)

Digital (HDMI)

✔✔✔

✔✔

NOTE

This TV has only limited PC compatibility, correct operation

• can only be guaranteed if the video card conforms exactly to the VESA 60 Hz standard. Any variations from this standard will result in picture distortions.

CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS

POSITION H P O S * * * _ H-POSITION (AV/PC)

WIDE MODE W I D E 0 _ _ _ TOGGLE (AV)

MUTE M U T E 0 _ _ _ TOGGLE

SURROUND A C S U 0 _ _ _ SURROUND TOGGLE

AUDIO CHANGE A C H A _ _ _ _ TOGGLE

SLEEP TIMER O F T M 0 _ _ _ OFF

TEXT T E X T 0 _ _ _ TEXT OFF

V P O S * * * _ V-POSITION (AV/PC)

C L C K * * * _ CLOCK (0–180)

P H S E * * * _ PHASE (0–40)

W I D E 1 _ _ _ NORMAL (AV)

W I D E 2 _ _ _ ZOOM 14:9 (AV)

W I D E 3 _ _ _ PANORAMA (AV)

W I D E 4 _ _ _ FULL (AV)

W I D E 5 _ _ _ CINEMA 16:9 (AV)

W I D E 6 _ _ _ CINEMA 14:9 (AV)

W I D E 7 _ _ _ NORMAL (PC)

W I D E 8 _ _ _ CINEMA (PC)

W I D E 9 _ _ _ FULL (PC)

W I D E 1 0 _ _ DOT BY DOT (AV/PC)

W I D E 1 1 _ _ UNDERSCAN (AV)

M U T E 1 _ _ _ MUTE ON

M U T E 2 _ _ _ MUTE OFF

A C S U 1 _ _ _ SURROUND ON

A C S U 2 _ _ _ SURROUND OFF

O F T M 1 _ _ _ SLEEP TIMER 30 MIN

O F T M 2 _ _ _ SLEEP TIMER 1 HOUR

O F T M 3 _ _ _ SLEEP TIMER 1 HOUR 30 MIN

O F T M 4 _ _ _ SLEEP TIMER 2 HOUR

O F T M 5 _ _ _ SLEEP TIMER 2 HOUR 30 MIN

T E X T 1 _ _ _ TEXT ON (TOGGLE)

DCPG***_

VESA

Standard

DIRECT PAGE JUMP (100–899)

Appendix

Using the universal remote control

You can operate connected AV products (DVD player/ recorder, SetTopBox, VCR and others) by setting up your remote control as a universal remote control unit.

NOTE

Some manufacturer code indicated in the operational

• manual and the universal remote control device do not correspond. When recording a signal other than the signal being watched, some signals cannot be recorded depending on the signal being viewed.

LCD window

Presetting the manufacturer code

Press FUNCTION repeatedly until you reach the

device you wish to control. (TV, DVD1, DVD2, STB1, STB2 and VCR)

Press this button briefly (for more than 0.2 seconds) to

• move between the items.

Press and hold both FUNCTION and OK for 3

seconds.

In the LCD window, the 3-digit manufacturer code

• input screen blinks.

Enter the 3-digit manufacturer code using a/b/

c/d, and then press OK.

The TV returns to the normal TV mode.

•

LCD Window

Display

DVD1/DVD2

VCR

STB1/STB2**

Home Theatre in a Box System

SAT and CBL are integrated

Category Manufacturer

DVD player Magnum - Zenith

DVD recorder JVC - Yukai

DVD/LD Pioneer

DVD part of DVD/VCR Bush - Toshiba

DVD part of DVD/DVR

Panasonic - Toshiba

HTIB* Aiwa - Sony

DVD part of SAT/DVD Humax

DVD part of TV/DVD Bush - Toshiba

VCR part of DVD/VCR Bush - Toshiba

VCR part of TV/VCR Aiwa - Toshiba

VCR Adelsound - Yoko

SAT part of SAT/DVD Humax

SAT part of SAT-DVR

BSSkyB - Zehnder

Satellite AB Sat - Woorisat

Satellite receiver Hauppauge

Satellite receiver/

recorder

Humax - Kathrein

Cable box ABC - Wittenberg

Manufacturer code

DVD Manufacturer Code

Sharp 029 128 143 177 191 Magnum 101 Acoustic Solutions 001 Aiwa 004 039 131 231 Akai 034 095 Akura 108 Alba 001 014 017 018 040 Apex 139 Awa 001 Axion 001 Best Buy 107 Bosston 152 Brainwave 034 Brandt 002 012 030 Britannia 150 Bush 001 019 032 042 045 087 092

Cambridge Audio 104 163 CAT 153 154 Celestial 161 Centrex 109 Centrum 154 CGV 104 CineVision 157 Classic 001 100 Clatronic 106 Coby 001 Conia 102 Crypto 159 C-Tech 105 CyberHome 003 022 025 036 Daewoo 023 038 078 113 114 115 Dalton 162 Dansai 034 151 227 Daytek 005 020 DEC 106 Denon 123 138 164 188 199 210 Denver 106 108 133 Denzel 103 Desay 155 Diamond 104 105 Digitor 160 DK Digital 032 176 Dmtech 111 Dual 001 103 D-Vision 034 DVX 105 Easy Home 107 Eclipse 104 Elta 034 124 134 Emerson 129 Enzer 103 Euroline 034 Finlux 104 Fisher 132 Global Solutions 105 Global Sphere 105 Go Video 126 GoldStar 015 Goodmans 001 014 018 045 106 109 158

Graetz 103 Grundig 018 038 099 109 127 H&B 106 156 Haaz 104 105 Harmon/Kardon 144 HE 001 HiMAX 107 Hitachi 011 047 088 101 103 107 126

Home Electronics 001 Humax 048 Innovation 096 101 128 JDB 001 Jeutech 152 JVC 002 016 080 081 082 083 084

Kenwood 037 123 142 170 208 211 219

Kingavon 106 Kiss 103 156 Koda 106 KXD 107 Lawson 105 Lecson 151 Lenco 106 LG 015 024 090 129 185 216 Life 096 128 Lifetec 096 101 128 Limit 105 Loewe 044 127 LogicLab 105 Luxor 109 Magnavox 002 106 165

102 106 149 158 209 223 224 225 226

203 228

190 196 206 215

085 120 173 182 184 212

229

DVD Manufacturer Code

Marantz 049 098 200 201 Matsui 030 MBO 001 145 Mediencom 150 Medion 096 101 112 128 158 Metz 094 MiCO 104 Micromaxx 096 101 128 Micromedia 002 Micromega 171 Microstar 096 101 128 Mirror 158 Mitsubishi 125 166 Mizuda 106 107 Monyka 103 Mustek 001 100 198 Mx Onda 104 NAD 143 Naiko 109 Nakamichi 147 Neufunk 103 NU-TEC 102 Omni 150 Onkyo 002 097 165 Optim 151 Optimus 168 Orava 106 Orion 087 Oritron 096 P&B 106 Pacific 105 Palsonic 149 Panasonic 013 079 093 123 164 194 195

Philips 233 002 006 027 035 043 044

Philips Magnavox 121 Pioneer 007 008 010 046 094 168 174

Proline 109 Provision 106 Raite 103 RCA 135 REC 149 150 RedStar 108 Reoc 105 Revoy 156 Roadstar 001 014 106 149 Rowa 102 109 Rownsonic 154 Saba 012 030 Sabaki 105 Sampo 136 Samsung 011 076 077 126 175 186 213

Sansui 104 105 Sanyo 028 033 089 179 189 218 ScanMagic 001 Schneider 096 110 111 112 Scientific Labs 105 Scott 017 162 SEG 014 026 103 105 110 141 Sherwood 140 Shinco 135 Sigmatek 107 Silva 108 Singer 104 105 Skymaster 001 026 100 105 134 Skyworth 108 SM Electronic 001 105 Sony 004 009 021 031 041 075 122

Soundmaster 105 Soundmax 105 Standard 105 Star Cluster 105 Starmedia 106 Supervision 001 105 Synn 105 TCM 096 101 128 Teac 094 102 105 192 Tec 108 Technics 101 164 193 232 Technika 034 Technosonic 034 Telefunken 154 Tevion 096 101 105 128 162 Thomson 012 091 116 117 118 119 148

Tokai 103 108 Toshiba 002 086 087 121 165 187 TruVision 107

214 232

049 074 098 121 127 165 171 181 202

178 183 207 220

217

169 180 204 205 221 222

167 172 197

Appendix

DVD Manufacturer Code

United 001 Voxson 001 Vtrek 159 Wharfedale 104 105 130 Wintel 152 Xbox 167 Xlogic 105 XMS 149 Yakumo 109 Yamada 109 Yamaha 006 013 123 137 164 230 Yamakawa 103 146 Yukai 001 Zenith 002 129 165

DVD

Recorder

JVC 057 058 059 060 LG 065 Panasonic 052 062 Philips 050 051 053 061 063 064 Sony 054 055 056 Toshiba 067 068 069 Yukai 066

DVD/LD Manufacturer Code

Pioneer 007

DVD/VCR

Combo

Sharp 029 (DVD)/028 032 (VCR) Bush 087 (DVD)/036 (VCR) Daewoo 078 (DVD)/029 (VCR) Hitachi 088 (DVD)/025 (VCR) JVC 080 081 082 083 084 085

LG 015 (DVD)/014 030 (VCR) Orion 087 (DVD)/038 (VCR) Panasonic 079 (DVD)/031 037 (VCR) Philips 074 (DVD)/026 (VCR) Samsung 076 077 (DVD)/210 (VCR) Sanyo 089 (DVD)/039 (VCR) Sony 075 (DVD)/027 (VCR) Toshiba 086 (DVD)/035 (VCR)

DVD/DVR Manufacturer Code

Panasonic 052 062 Pioneer 070 071 072 Samsung 073 Toshiba 067

HTIB Manufacturer Code

Aiwa 231 DK Digital 176 Hitachi 215 JVC 184 Kenwood 219 LG 216 Mustek 198 Panasonic 194 195 214 Pioneer 220 Samsung 213 Sanyo 189 218 Sony 205 221 222

SAT/DVD Manufacturer Code

Humax 048

TV/DVD Combo

Bush 092 LG 090 Panasonic 093 Thomson 091 Toshiba 087

TV VCR

combo

Aiwa 042 Bush 042 Daewoo 021 040 GoldStar 209 Goodmans 047 Grundig 041 Orion 045 Philips 041 046 Roadstar 042 045 Samsung 043 Sony 044 Tatung 042 Toshiba 042 043 045 048

VCR Manufacturer Code

Sharp 001 015 028 032 063 064 073

Adelsound 056

Manufacturer Code

(DVD)/007 025 033 034 (VCR)

Manufacturer Code

089 149 150 151 153 165

VCR Manufacturer Code

Adyson 055 Aiwa 014 026 042 045 049 050 051

Akai 045 050 058 060 128 149 150

Akiba 055 Akura 050 055 060 Alba 021 026 045 051 052 055 058

Allorgan 043 126 Ambassador 052 058 Amstrad 026 049 055 061 149 162 189 Anitech 055 Ansonic 056 ASA 053 054 059 149 150 153 Asuka 026 049 053 054 055 059 149 ASWO 179 Audiosonic 061 AudioTon 058 Baird 021 026 049 050 060 061 123

Basic Line 021 051 052 055 058 061 Bauer 160 187 Baur 054 070 Beaumark 157 Bestar 021 052 058 061 Black Panther Line 021 061 Blaupunkt 006 008 054 057 069 070 071

Blue Sky 051 059 Bondstec 052 055 058 Brandt 009 060 132 Brandt Electronique Brinkmann 051 Broksonic 155 157 BSR 188 Bush 021 026 036 042 045 051 055

Carrefour 121 Casio 026 Cathay 061 Catron 052 058 CGE 026 049 050 060 149 Cimline 051 055 Clatronic 052 055 058 Combitech 045 Condor 021 052 058 061 Continental Edison 154 Crown 021 052 055 058 061 Curtis Mathes 157 Cybermaxx 072 Daewoo 018 021 029 040 045 052 058

Dansai 055 061 Dantax 051 Daytron 021 061 De Graaf 054 Decca 007 026 049 050 054 060 DeGraaf 063 120 123 Denko 055 Denon 098 Diamant 059 209 Dual 026 050 054 060 061 154 Dumont 026 049 054 123 Elbe 061 Elcatech 055 Elin 067 126 Elsay 055 Elta 055 061 Emerson 055 121 155 ESC 021 058 061 126 Etzuko 055 Europhon 058 Ferguson 007 009 026 050 060 071 132

Fidelity 026 049 055 Finlandia 026 054 063 120 123 Finlux 026 049 050 054 080 120 123

Firstline 018 051 053 055 059 080 114

Fisher 058 122 123 149 150 153 159

Flint 051 Formenti/Phoenix 054 Frontech 052 058 Fujitsu 026 049 Funai 026 049 149 150 153 188 Galaxy 026 049 GBC 052 055 058 GE 157 GEC 054 Geloso 055 General 052 058 General Technic 006 043 051

059 060 102 111 149 150 153

153 158 193

061 128 129 130

154

083 119 124 125 149 150 151 153 171 179

154

061 075 127 128 129 130

061 072 121

201 202 204

149 150 153 197 207

120 121 127

178

VCR Manufacturer Code

Genexxa 123 Go Video 157 GoldHand 055 GoldStar 026 049 053 059 149 150 153

Goodmans 021 026 047 049 051 052 053

Graetz 050 060 123 126 Granada 026 054 057 059 063 071 120

Grandin 021 026 049 052 053 055 058

Grundig 009 041 054 055 057 069 070

Hanseatic 053 054 059 061 Hantor 058 Harwood 055 HCM 055 075 Hinari 045 051 055 056 060 061 075

Hisawa 045 051 166 Hitachi 005 016 019 026 049 050 054

Hypson 051 055 061 Impego 052 058 Imperial 026 049 126 149 Ingersol 056 126 Inno Hit 021 052 054 055 058 061 067

Innovation 006 043 051 Interbuy 053 055 059 Interfunk 054 123 Intervision 026 049 051 059 061 209 Irradio 053 055 059 ITT 050 060 077 123 126 ITT Nokia 154 ITV 021 053 058 059 061 JBL 147 JC Penney 098 155 157 JVC 007 025 033 034 050 060 077

Kaisui 055 Karcher 054 Kendo 018 021 051 052 055 059 128 Kenwood 050 060 Kimari 122 Kneissel 045 051 Korpel 055 Kuba 122 Kyoto 055 Lenco 021 Leyco 055 LG 010 014 024 026 030 049 053

Lifetec 006 043 051 072 Loewe 006 137 Loewe Opta 053 054 056 057 059 071 124

Logik 055 056 067 126 Lumatron 021 061 072 Luxor 055 063 073 080 114 122 123

M Electronic 026 049 059 Magnin 157 Manesth 018 055 121 Marantz 054 057 071 073 179 Mark 061 Matsui 026 045 051 053 056 059 126

Mediator 054 Medion 006 043 051 072 M-Electronic 026 059 209 Memorex 026 049 053 059 063 098 122

Memphis 055 Metz 006 008 057 070 071 124 125

MGN 157 Micromaxx 006 043 051 072 Microstar 006 043 051 072 Migros 026 049 Minerva 070 071 125 181 187 Minolta 098 Mitsubishi 007 049 054 080 107 114 149

Multitech 026 049 052 054 055 058 123 Murphy 026 049 National 006 069 124 NEC 007 050 060 154 155 177 Neckermann 050 054 057 060 154 179 NEI 054 Nesco 026 045 055

155 157 209

055 058 059 061 067 073 126 127

123 126

059 061 072

071 074 075 076 090 125 149 150 153 173 179 181 182 187

127

056 060 098 115 120 123 126 149 150 153 175 185

126

078 079 098 105 106 140 149 150 153 154 161 200 204

059 112

131 151 169 179 209

149 150 153 180 195

133 162 164

123 155

131 179 181 187

150 153 155 170 199

VCR Manufacturer Code

Nikkai 052 055 058 061 Nokia 050 060 061 063 067 120 123

Nordmende 007 009 050 060 077 124 134

Oceanic 026 049 050 060 063 123 Okano 051 055 061 128 Optimus 155 156 Orion 038 045 051 056 129 130 155

Orson 026 049 Osaki 026 049 053 055 059 Osume 127 Otake 129 130 Otto Versand 054 187 Palladium 050 053 055 056 057 059 060

Panasonic 002 006 008 023 031 037 069

Pathe Cinema 056 114 Pathe Marconi 050 060 154 Pentax 098 Perdio 026 049 Philco 055 098 Philips 005 011 017 019 020 026 041

Phonola 054 Pioneer 007 054 120 149 150 153 156

Portland 021 052 058 061 Prinz 026 049 Profex 055 Profi-Tronic 126 Proline 026 049 075 127 Prosonic 026 051 061 Pulsar 157 Pye 005 054 Quasar 155 Quelle 049 054 057 070 071 149 150

Radialva 055 059 063 Radio Shack 155 Radiola 054 151 Realistic 155 157 Rex 050 060 077 154 161 RFT 052 054 055 058 Roadstar 021 042 045 053 055 059 061

Royal 055 Saba 009 050 060 077 138 139 149

Saisho 051 055 056 162 Salora 080 114 123 149 150 153 180 Samsung 210 043 067 126 157 176 194

Samurai 007 052 055 060 Sansui 007 050 Sanwa 056 Sanyo 039 063 099 109 122 123 149

Saville 045 061 126 SBR 054 Schaub Lorenz 026 049 050 060 123 Schneider 018 021 026 049 051 052 053

Scott 155 Sears 098 155 SEG 055 061 067 126 SEI-Sinudyne 054 056 188 Seleco 050 058 059 060 154 161 Sentra 052 055 058 127 Sentron 055 Shintom 055 123 Shivaki 053 059 Shorai 056 Siemens 053 057 059 070 071 123 125

Silva 053 059 Silver 061 Sinudyne 054 056 Solavox 052 058 Solovox 058 Sonitron 122 Sonneclair 055 Sonoko 021 061 072 Sonolor 063 Sontec 053 059

126 128 180 195

149 150 153 154 161 201 204 205

163 166 188 191 192

071 126 128

086 091 101 124 131 137 149 150 151 153 155 167 169 171 174 190 198

046 054 057 062 065 071 076 077 087 090 092 093 095 100 104 108 110 136 149 150 153 179

203

153 179 181 182 187

067 126

150 153 154 161

196

150 153 180

054 055 059 061 126 149 150 153

179 181 187

Appendix

VCR Manufacturer Code

Sony 003 004 013 022 027 044 066

Soundwave 059 Standard 021 061 Starlite 059 123 Stern 061 Sunkai 051 Sunstar 026 049 Suntronic 026 049 Sunwood 055 Supra 059 126 Symphonic 026 055 Taisho 051 056 Tandberg 061 070 Tansai 149 Tashiko 026 049 059 063 126 Tatung 026 042 049 050 054 060 063

TCM 006 043 051 072 Teac 026 060 061 Tec 052 055 058 061 Technics 006 069 Teleavia 050 060 Telefunken 007 009 050 060 077 078 081

Teletech 055 061 Tenosal 055 Tensai 026 049 053 055 056 059 149 Tevion 006 043 051 072 Thomson 007 009 050 060 065 077 078

Thorn 050 059 060 123 154 161 208 Tivo Hdd 065 088 Tokai 053 055 059 060 123 149 Tonsai 055 Toshiba 012 018 035 042 043 045 048

Towada 055 183 Towika 055 TVA 052 058 Uher 053 059 126 154 Ultravox 061 Unitech 067 126 United Quick Star 021 061 Universum 026 049 051 053 054 057 059

Victor 007 078 Videon 006 043 051 Wards 155 157 Weltblick 053 059 Yamishi 055 Yokan 055 Yoko 052 053 055 058 059 067 126

SAT/DVR Manufacturer Code

Humax 005 BSkyB 035 Humax 007 TechniSat 347 011 Zehnder 034

AB Sat 004 056 066 103 AGS 056 Akai 077 001 139 Alba 004 086 095 332 006 036 037

Aldes 080 086 003 105 106 107 Allsat 068 076 077 298 003 042 108

Allsonic 049 080 088 002 039 106 Alltech 004 097 Alpha 077 Altai 089 Amitronica 004 Ampere 045 089 001 109 Amstrad 004 008 045 050 060 061 079

Anglo 004 Ankaro 004 049 078 080 088 286 305

Anttron 076 095 334 002 036 106 Arcon 045 078 337 003 109 110 123 Armstrong 077 001 038 ASA 090 Asat 077 001 139

068 082 083 084 085 088 094 096 097 103 113 116 117 118 119 145 146 147 160 168 184 185 186

114

132 135 149 150 153 154 161 206

098 132 134 138 141 142 143 144 148 152 154 156 157 161 201 204

050 054 060 077 080 114 121 154 162 172

070 071 076 125 126

Satellite Manufacturer Code

105 106 127 141

139

084 089 098 099 101 165 279 282 292 295 305 313 331 002 038 140

313 331 002 039 106

Satellite Manufacturer Code

ASLF 004 AST 082 288 001 114 Astacom 056 161 Astra 004 053 071 085 093 288 005

Astro 020 022 048 049 050 053 088

AudioTon 095 002 042 106 Aurora 059 Austar 059 065 Avalon 089 Axiel 056 Axis 049 087 088 093 003 039 113

Barcom 305 313 331 001 110 Best 049 088 002 039 110 Blaupunkt 020 022 001 040 Blue Sky 004 061 Boca 004 045 094 160 177 180 192

Boston 045 056 Brain Wave 078 083 001 041 Broadcast 085 001 117 Broco 004 093 BSkyB 008 165 BT 056 BT Satellite 161 001 143 Bubu Sat 004 Bush 068 076 086 005 037 108 118

BVV 078 Cable 296 Cambridge 050 160 305 313 331 Canal Satellite 048 081 166 Canal+ 048 001 142 Channel Master 086 001 105 Chaparral 305 313 322 331 001 136 CHEROKEE 056 066 285 Chess 004 047 052 001 147 CityCom 044 053 057 065 002 037 120

Clatronic 083 001 041 Clearmax 275 Colombia 045 Columbia 045 COLUMBUS 285 001 125 Comag 045 Commander 078 Commlink 080 001 106 Comtec 080 087 Condor 049 053 088 001 039 Connexions 049 088 089 001 116 Conrad 044 045 049 050 053 088 094

Conrad Electronic 004 053 Contec 087 094 002 119 120 Daewoo 002 004 Dansat 068 076 001 108 D-Box 168 DDC 086 001 105 Dew 087 001 119 Digiality 053 Digipro 062 Discoverer 047 052 Discovery 056 Diseqc 056 Distratel 061 Distrisat 077 DNR 078 DNT 077 089 002 116 139 Drake 305 307 313 331 001 123 DStv 059 Dune 049 088 Dynasat 055 Echostar 004 066 089 166 167 238 241

Einhell 004 045 050 079 080 003 036

Elap 004 056 Elsat 004 099 Elta 049 077 088 298 332 004 036

EmmeEsse 049 055 088 167 003 039 118

Engel 004 EURIEULT 046 060 061 274 Eurocrypt 071 Europa 050 053 077 078 094 Europhon 045 053 Eurosat 298 001 038 Eurosky 044 045 049 050 053 088 002

038 111 112 113 133

095 159 004 039 040 106 107

119

197 204 207 208 216 223 250 260 269 002 038 133

127 141

294

156

245 273 274 276 285 290 305 310 313 325 330 331 002 116 147

038 106

039 042 139

129 312

038 039

Satellite Manufacturer Code

Eurostar 044 053 055 057 104 001 038 Eutelsat 004 Eutra 097 Exator 095 002 036 106 Fenner 004 047 049 052 Ferguson 068 076 158 327 328 335 336

Fidelity 050 079 098 Finlandia 071 001 037 Finlux 071 091 156 329 340 003 037

Flair Mate 004 Foxtel 059 064 065 Fracarro 167 305 313 331 334 001 141 Freecom 022 050 002 036 128 Freesat 060 097 FTE 088 094 160 291 308 337 002

FTEmaximal 004 049 Fuba 022 044 049 071 088 089 274

Fugionkyo 062 Funai 323 Galaxis 044 049 059 065 080 087 088

Galaxisat 082 Gardiner 057 Giucar Record 305 313 331 Goldbox 048 081 166 Gooding 051 Granada 071 001 111 Grandin 046 069 Grundig 008 020 022 050 051 059 061

G-Sat 076 Hanseatic 052 157 001 135 Hänsel & Gretel 045 053 Hantor 083 003 036 041 132 Hase & Igel 078 Heliocom 053 001 109 Helium 053 Hinari 076 086 001 105 Hirschmann 020 021 022 049 050 053 056

Hisawa 083 001 041 HNE 045 Houstion 078 Humax 005 007 017 065 144 272 001 Huth 045 053 063 078 080 083 085

Hypson 046 274 ID Digital 065 Imex 046 Ingelen 060 International 045 Interstar 062 Intervision 053 096 001 042 ITT/Nokia 071 090 156 168 JEEMON 298 305 313 331 Johansson 083 305 313 324 331 001 041 JOK 056 100 161 JVC 051 Kamm 004 Kathrein 003 004 005 010 015 016 020

Kathrein Eurostar 044 Key West 045 Klap 056 Konig 053 329 Kosmos 092 308 003 128 129 130 KR 095 097 001 106 Kreiselmeyer 020 022 001 040 K-SAT 004 Kyostar 045 095 001 036 L&S Electronic 045 049 Lasat 044 045 047 049 053 087 088

Lemon 078 Lenco 004 044 049 053 078 088 093

Lenson 050 001 050 Lexus 077 Lifesat 004 045 047 049 052 088 157

Lorenzen 045 053 078 101 Lupus 049 088 001 039

004 037 043 108 118

111 126

109 130

285 300 334 009 036 039 040 110 112 116 125 126 139

093 144 289 298 326 008 039 042 106 113 119 127 145 246

074 084 162 164 165 236 237 240 297 305 313 331 006 037 040 106 118 140

060 089 090 092 153 156 340 002 040 129

087 094 007 038 041 042 106 117 119 129

022 044 056 057 066 077 092 095 159 169 287 288 305 308 313 331 040 120 130 136 139

160 005 039 107 131 132 133

334 003 036 128 134

005 039 135 145 147 150

Satellite Manufacturer Code

Luxor 050 071 084 156 168 288 305

M & B 052 157 Manata 004 045 046 056 161 Manhattan 056 161 298 004 037 042 107

Mascom 092 001 107 Maspro 004 020 022 051 070 078 097

Matsui 020 022 051 056 086 161 346

Max 053 MB 052 157 001 135 Mediabox 048 081 166 Mediasat 048 050 081 093 166 001 113 Medion 004 045 049 088 005 039 135

Medison 004 Mega 077 001 139 Melectronic 057 Memphis 322 Metronic 004 046 057 061 069 080 095

Metz 020 022 297 001 040 Micro 004 050 053 Micro electronic 004 Micro Technology 004 093 001 124 Micromaxx 049 005 039 135 145 147 150 Microtec 004 Minerva 051 297 001 040 MNet 296 Morgan's 004 045 077 094 160 003 038

Motorola 058 Multichoice 059 001 059 Multistar 308 002 130 132 Multitec 047 001 147 Muratto 082 002 115 128 Mysat 004 Navex 083 001 041 NEC 075 001 137 Network 076 Neuhaus 004 050 053 078 093 094 003

Neusat 004 078 NextWave 063 Nikko 004 001 038 Nokia 012 013 023 071 090 156 168

Nordmende 083 086 158 333 334 335 336

Nova 059 Novis 083 001 041 Octagon 078 087 095 334 003 036 106

Okano 308 003 038 129 130 Ondigital 032 072 073 Optex 274 298 002 042 120 Optus 048 059 063 Orbitech 047 048 050 094 154 155 001

Osat 084 001 106 Pace 008 027 032 056 066 068 076

Packsat 056 Palcom 086 285 305 313 331 004 050

Palladium 050 051 001 038 Palsat 047 050 291 Panasat 054 059 Panasonic 001 008 165 003 037 118 140 Panda 022 053 068 071 002 037 108 Patriot 045 056 Philips 011 020 022 048 051 056 057

Phoenix 076 087 002 119 127 Phonotrend 080 144 004 037 042 106 129 Pioneer 048 166 315 Predki 083 001 041 Preisner 045 089 094 160 Premier 048 Premiere 048 065 081 166 183 210 211

Profile 056 Prosat 080 086 096 305 313 331 004

Prosonic 101

306 313 331 001 111

118

162 288 305 313 331 003 037 118 136

001 143

145 147 150

036 106 107 110

133 139

042 113

176 188 190 196 210 211 214 219 221 224 227 247 249 253 257 268 271 280 281 283 288 340 005 037 111 118 171

005 036 037 043 105 107

119

036

163 165 239 240 242 243 277 284 305 313 331 332 006 037 040 108 118 127 140

105 112 125

072 073 076 077 078 081 094 095 161 162 164 166 169 235 240 242 004 037 118 139 170

217 227 271 002 042 142

105 106 127 141

Appendix

Satellite Manufacturer Code

Pye 051 Quadral 049 056 066 080 086 088 094

Quelle 044 053 079 001 040 Radiola 077 001 139 Radix 009 060 089 097 116 203 213

Rainbow 095 097 001 106 Red Star 049 088 Redpoint 093 001 113 Rex 334 RFT 077 078 080 154 002 106 139 RITAR 288 Roadstar 004 Roch 046 Rover 004 049 096 Saba 044 053 056 061 076 078 100

Sagem 102 001 043 Sakura 087 305 313 331 002 119 127 Salora 071 288 306 002 111 137 Samsung 006 019 275 308 314 001 036 SAT 050 082 098 003 105 114 115 Sat Cruiser 063 Sat Partner 050 Sat Team 004 Satcom 052 053 085 157 309 334 002

Satec 004 076 001 118 Satelco 049 088 Satford 085 001 117 Satline 096 Satmaster 085 001 117 SatPartner 083 006 036 041 106 107 128

Satplus 047 Schacke 095 Schneider 047 056 164 004 039 145 147

Schwaiger 045 047 052 053 061 076 094

SCS 044 Sedea Electronique Seemann 088 093 003 038 113 116 SEG 049 052 083 088 101 157 184

Seleco 167 334 001 042 Septimo 061 Servi Sat 004 046 Siemens 020 022 160 294 297 001 040 Skantin 004 Skardin 093 001 113 Skinsat 050 SKR 004 SKY 058 Skymaster 004 014 034 047 052 080 096

Skymax 077 001 139 SkySat 004 047 050 052 053 335 SL 045 078 SM Electronic 004 047 Smart 004 044 045 060 Sony 048 244 001 140 SR 045 002 038 133 Starland 004 001 147 Starring 083 001 041 Strong 049 059 062 088 186 187 189

STVI 046 274 Sunny Sound 049 088 Sunsat 004 093 Sunstar 045 049 088 002 038 133 Super Sat 055 Supermax 063 Systec 045 Tandberg 285 001 043 Techniland 085 001 117 TechniSat 347 011 047 048 050 067 077

Technology 059 Technosat 063 Technowelt 045 053 061 Telanor 285 300 001 105

096 161 311 341 342 343 344 003 039 105 106

256 003 172 174

158 161 333 339 004 107 118 124 141

117 135

129

150

157 006 120 122 135 144 146 246

045 062

186 189 199 206 215 225 258 261 263 334 004 036 039 041 135

104 157 182 199 202 205 212 223 229 262 267 003 106 135 147

193 198 201 210 216 227 228 248 270 291 299 305 312 313 331 005 036 039 106 128 141

154 155 173 175 179 181 191 194 195 220 251 259 264 301 302 345 004 116

Satellite Manufacturer Code

Telasat 044 052 053 157 001 135 Tele Piu 296 Teleciel 095 Telecom 004 Teledirekt 076 Telefunken 056 161 334 338 003 036 118

Teleka 050 053 078 089 092 095 162

Telesat 052 053 157 001 135 Telestar 047 048 050 001 Teletech 104 Televes 045 050 002 037 149 Tempo 063 Tensai 303 Tevion 004 005 039 135 145 147 150 Thomson 004 024 026 028 030 031 044

Thorn 305 313 331 003 037 108 118 Tioko 045 001 120 Tokai 077 Tonna 004 050 085 003 037 042 117 Triad 082 003 114 115 128 Triasat 050 091 001 126 Triax 004 044 045 050 091 316 317

Tristar 291 Turnsat 004 Twinner 004 045 046 001 149 UEC 059 064 Uher 047 Ultravox 298 Uniden 098 278 293 305 313 331 001

Unisat 045 077 087 002 038 119 Universum 020 022 044 051 053 090 098

Variosat 020 022 Vega 049 Ventana 077 001 139 Vestel 101 Viasat 066 Visionic 062 Visiosat 004 056 100 041 042 147 148 Viva 078 Vivid 064 Vortec 032 321 334 001 036 VTech 057 001 115 082 100 114 Wela 094 Welltech 047 WeTeKom 047 050 052 Winersat 083 305 313 324 331 001 041 Wintergarten 080 WINTERNITZ 279 288 Wisi 020 022 050 053 082 089 094

World 083 Worldsat 056 Xrypton 049 088 XSat 004 066 Zaunkonig 078 Zehnder 025 044 049 057 082 088 101

Zenith 058 Zinwell 065 Zodiac 095 001 106 Cabletime 305 313 331 Kenwood 305 313 331 Apollo 036 Aston 148 Brandt 143 Clemens Kamphus 129 CNT 107 Comtech 119 Cosat 042 Crown 038 Cybermaxx 150 Daeryung 116 Decca 121 Delega 105 Diamond 122 Diskxpress 110 Ditristrad 042 Dong Woo 132 Elekta 107 Emanon 036 Ep Sat 037 Eurodec 043 Eurospace 124

143

003 038 106 116

048 053 056 081 158 230 231 232 233 234 242 335 037 043 143

318 319 320 002 040

138

101 001 040

100 116 178 185 190 191 197 200 209 218 219 220 222 226 252 254 255 256 265 266 318 005 037 040 114 115

304 308 318 005 039 107 110 115 130

Satellite Manufacturer Code

Finnsat 043 119 France Satellite/TV 125 Galaxi 110 GMI 038 GoldStar 128 Goodmans 037 127 Grothusen 036 128 Hanuri 107 Hitachi 037 118 Houston 042 Imperial 127 141 Innovation 039 135 145 147 150 Intertronic 038 ITT Nokia 037 111 118 JSR 042 Leng 041 Lennox 042 LG 128 Life 145 Lifetec 039 135 145 147 150 Lion 124 Lorraine 128 Lyonnaise 043 Macab 043 Marantz 139 Mediamarkt 038 Microstar 039 135 145 147 150 Mitsubishi 037 040 143 Mitsumi 133 Morgan Sydney 149 Next Wave 146 Nomex 151 Oceanic 122 124 Orbit 114 Origo 124 Otto Versand 040 Pacific 122 Paltec 112 Polsat 043 Polytron 120 Priesner 038 Profi 134 Promax 037 Protek 122 Provision 107 Quiero 043 Rediffusion 137 Redstar 039 Ruefach 134 Sabre 037 Silva 128 Sky Digital 140 Skyvision 042 Start Trak 036 Sumida 038 Tandy 106 Tantec 037 050 118 125 Tatung 121 TCM 039 135 145 147 150 Teco 038 133 Telemaster 107 Telemax 131 Telewire 042 Thorens 122 TPS 102 Unitor 041 110 Variostat 040 Vector 124 Via Digital 024 Vivanco 152 Wevasat 037 Wewa 037 Woorisat 107

Satellite Reciever

Hauppauge 018 029

Satellite Reciever/ Recorder

Humax 005 Kathrein 033

Cable Box Manufacturer Code

ABC 375 Alcatel 373 374 Amstrad 378 380 Arcon 380 Axis 380 Cabletime 348 349 350 366 368 370 Clyde Cablevision 351 Comcrypt 376 Cryptovision 352 Fidelity 380

Manufacturer Code

Cable Box Manufacturer Code

Filmnet 376 Filmnet Cablecrypt 353 369 Filmnet Comcrypt 353 Finlux 355 Foxtel 378 France Telecom 371 372 377 Freebox 379 GEC 351 General Instrument Gooding 354 Grundig 380 354 Hirschmann 355 ITT Nokia 355 Jerrold 356 362 364 367 375 JVC 354 Macab 372 377 Maspro 354 Matsui 354 Minerva 354 Mnet 369 376 Movie Time 361 Mr Zapp 377 Multichoice 376 Nokia 355 Noos 377 Palladium 354 Philips 354 363 371 372 377 Pioneer 380 357 358 PVP Stereo Visual Matrix Sagem 372 377 SAT 380 Scientific Atlanta 359 360 Starcom 375 Tele+1 353 369 376 Telepiu 369 376 Torx 375 United Cable 364 Universum 354 355 Videoway 365 Visiopass 355 371 372 377 Wittenberg 380

Humax 005 (SAT)/048 (DVD)

367 375

364

SAT/DVD Manufacturer Code

Appendix

Troubleshooting

Problem Possible Solution

No power.• Make sure the Display and AVC System are connected correctly (Page 9).

The TV cannot be operated.• External influences such as lightning, static electricity, etc., may cause improper operation. In

Remote control unit does not operate.•

Picture is cut off.• Is the image position correct?

Strange colour, light colour, or dark

• Adjust the picture tone. colour, or colour misalignment.

Power is suddenly turned off.• The TV’s internal temperature has increased.

No picture.• Are connections to external equipment correct? (Pages 22–24)

The message “LOSS OF SYNC” is

• Is the HDMI cable between the Display and AVC System properly connected? (Pages 8 and 9)• displayed.

No sound.• Is the volume too low?

The TV sometimes makes a cracking

• This is not a malfunction. This happens when the cabinet slightly expands and contracts sound.

•

Check if you pressed TV B on the remote control unit.

•

If the indicator on the Display lights up red, press TV B. Is the AC cord disconnected?

•

Check if you pressed a on the Display.

•

• this case, operate the TV after first turning off the power of the Display and AVC System, or unplugging the AC cord and re-plugging it in after one or two minutes.

Are batteries inserted with polarity (e, f) aligned?

• Are batteries worn out? (Replace with new batteries.)

• Are you using it under strong or fluorescent lighting?

• Is a fluorescent light illuminating to the remote control sensor?

•

• Are screen mode adjustments (WIDE MODE) such as picture size made correctly? (Pages 38 and 46)

•

• Is the room too bright? The picture may look dark in a room that is too bright.

• Check the “Colour System” setting (Pages 36 and 41).

•

• Remove any objects blocking the vent or clean. Is the “Sleep Timer” set? Select “Off” from the “Sleep Timer” menu (Page 33).

• Is “No Signal Off” or “No Operation Off” activated?

•

• Is the input signal type selected correctly after connection? (Page 41)

• Is the correct input source selected? (Page 17)

• Is a non-compatible signal being input? (Page 49)

• Is the picture adjustment correct? (Pages 31–32)

• Is the antenna connected properly? (Page 9)

• Is “On” selected in “Audio Only”? (Page 39)

•

• Make sure that headphones are not connected.

• Check if you pressed e on the remote control unit.

•

• according to changes in temperature. This does not affect the TV’s performance.

Cautions regarding use in high and low temperature environments

When the TV is used in a low temperature space (e.g. room, office), the picture may leave trails or appear slightly delayed.

• This is not a malfunction, and the TV will recover when the temperature returns to normal. Do not leave the TV in a hot or cold location. Also, do not leave the TV in a location exposed to direct sunlight or near a

• heater, as this may cause the cabinet to deform and the LCD panel to malfunction. Storage temperature: e5 °C to e35 °C.

Information on the software license for this product

Software composition

The software included in this product is comprised of various software components whose individual copyrights are held by SHARP or by third parties.

Software developed by SHARP and open source software

The copyrights for the software components and various relevant documents included with this product that were developed or written by SHARP are owned by SHARP and are protected by the Copyright Act, international treaties, and other relevant laws. This product also makes use of freely distributed software and software components whose copyrights are held by third parties. These include software components covered by a GNU General Public License (hereafter GPL), a GNU Lesser General Public License (hereafter LGPL) or other license agreement.

Obtaining source code

Some of the open source software licensors require the distributor to provide the source code with the executable software components. GPL and LGPL include similar requirements. For information on obtaining the source code for the open source software and for obtaining the GPL, LGPL, and other license agreement information, visit the following website: http://www.sharp-eu.com/gpl/ We are unable to answer any questions about the source code for the open source software. The source code for the software components whose copyrights are held by SHARP is not distributed.

Acknowledgements

The following open source software components are included in this product:

• linux kernel • busy box • uClibc • zlib • libpng • libjpeg

Appendix

Updating your TV via DVB-T

Ensure that your TV software version is always up to date. From time to time SHARP will make updated TV base software and DVB software available.

Digital Setup

Download Setup

Searching for updates*

All countries except UK and Sweden are set to “No”

for this function. The TV automatically determines whether a new software version is available when the TV is in standby mode.

Item

Yes: Automatically searches for new software updates

available when the TV is in standby mode.

No: Does not search for update information. Now: Checks if there is new software immediately.

Downloading the software

You can select the method of update.

If the software is updated, the confirmation

message “New download information has been detected.” appears.

If the TV receives the update service while in standby

• mode, a confirmation message displays after turning on the power.

Follow the screen prompts.

Item

Yes: Starts downloading immediately. It takes

approximately one hour to update. You cannot carry out other operations while downloading. Cancels the download by pressing OK on the remote

• control unit when “Discontinue” is displayed on the screen during the update.

No: Starts downloading automatically several minutes

after entering standby mode.

NOTE

The TV must remain in standby mode for download. Do not

•

turn off the main power using a on the Display. Updating the software may take some time.

•

Information

Message List

When new software is detected, you can confirm the update information and download the software from “Message List”.

NOTE

When the TV succeeds at downloading new software,

• the message is updated in the “Message List” of the “Information” menu. The software update will not be carried out if there is no

• new software available at the specified download time.

Information

Receiver Report

Display reports regarding failures and changes for timer settings.

Reset

If complex adjustments are made so that the settings cannot be restored to normal, you can reset the settings to the factory preset values.

Setup

Reset

Go to “MENU” > “Setup” > “Reset”.

Press c/d to select “Yes”, and then press OK.

“Now, TV will restart automatically. OK?” displays on

• the screen.

Press c/d to select “Yes”, and then press OK.

“Now initialising...” displays on the screen and blinks.

• After the reset has completed, the main power shuts

• off and then comes back on. The screen will have returned to its original settings.

Now initialising...

Identification

Setup

Identification

You can check the TV ID on the screen for reporting to customer service.

Picture maintenance

When you use your TV for a long period of time, colour shading on the screen may appear due to degradation of the LED backlight. You can control the colour shading after performing “Picture maintenance” in “Identification”, following the guide display on the screen.

NOTE

This function allows you to control the colour shading.

• Therefore, the brightness of the screen may reduced.

Appendix

Updating your TV via USB

Setup

Software Update

The TV displays a confirmation screen while

checking the data in the inserted USB device.

This function allows you to update to the latest software using a USB device. You must update the software individually for both the Display and AVC System through the USB terminal located on each.

Press MENU and the “MENU” screen displays.

Press c/d to select “Setup”.

Press a/b to select “Software Update”, and

then press OK.

Setup

Auto Installation

Programme Setup

Child Lock

Software Update

Identification

Wireless power link

Reset

Press c/d to select the device you want to

[Power always on]

update, and then press OK.

MonitorAVC system

Item

AVC system: Select “AVC system” when you want to

update the system for the AVC system.

Monitor: Select “Monitor” when you want to update the

system for the Display.

Press OK and then insert the USB device containing the software update file.

Checking

CAUTION

If the data is not compatible with the system, an error

• message appears on the screen. Repeat steps 5 and 6 after pressing OK. When an error message displays, check to see if:

•

The USB device is inserted firmly.

• The USB device is inserted in the USB terminal of the device

• you selected in step 4.

•

The USB memory has two or more software update files.

•

No data for updating the system exists in the USB memory.

•

The software update file is broken.

•

The software update file is not compatible with your TV’s software.

•

The current system is same as the system update data.

The TV displays the software version information

after checking the data.

Press c/d to select “Yes” to update the system, and then press OK.

NoYes

Press OK to automatically reset and start the update opration.

NOTE

This operation may take a while.

•

The TV starts updating the system

A confirmation message appears on the screen after completing the update and then automatically restarts the TV. Press OK to complete the operation.

CAUTION

Be sure to insert the USB device correctly into the terminal

• of device you select in step 4.

CLEARING THE PIN

Go to “MENU” > “Setup”.

Press a/b to select “Auto Installation”,

“Programme Setup”, “Child Lock” or “Reset”, and then press OK. The PIN input window will display.

Press and hold both Pr and ik on the

Display simultaneously until the message appears on the screen.

Appendix

Specifications

Item

52XS1E (Display), TU-X1E (AVC System)

52o LCD COLOUR TV, Model: LC-

LCD panel

Resolution

Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60

TV Function TV-Standard Analogue CCIR (B/G, I, D/K, L/L’)

Digital DVB-T (2K/8K OFDM), DVB-C, S/S2

Receiving Channel

TV-Tuning System Auto Preset 999 ch: non-Nordic / 9999 ch: Nordic (ATV: 99 ch), Auto Label, Auto Sort

STEREO/BILINGUAL NICAM/A2

Brightness 450 cd/m

Backlight life 60,000 hours (when “Backlight” is set to the default position)

Viewing angles H: 176°, V: 176°

Audio amplifier

Speaker

Terminals (AVC System)

Terminal (Display) USB USB

OSD language

Power Requirement AC 220–240 V, 50 Hz

Power Consumption

Weight 45.0 kg (Display), 3.8 kg (AVC System) 62.5 kg (Display), 3.8 kg (AVC System)

Operating temperature

As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior

• notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

Front EXT4 15 pin mini D-sub, Ø 3.5 mm jack

Rear Antenna input

(Method IEC62087)

VHF/UHF E2–E69 ch, F2–F10 ch, I21–I69 ch, IR A–IR J ch (Digital: IR A ch–E69 ch)

CATV Hyper-band, S1–S41 ch

HDMI3 (EXT7) HDMI

EXT8 S-VIDEO (Y/C input), RCA pin (AV input)

C.I. (Common Interface)

Headphones Ø 3.5 mm jack (Audio output)

RS-232C D-Sub 9 pin male connector

EXT1 SCART (AV input, Y/C input, RGB input, TV output)

EXT2 SCART (AV input/monitor output, Y/C input, AV Link, RGB input)

EXT3 COMPONENT IN: Y/P

HDMI1 (EXT5) HDMI, Ø 3.5 mm jack

HDMI2 (EXT6) HDMI

USB USB

DIGITAL AUDIO OUTPUT

OUTPUT RCA pin (AUDIO R/L)

DISPLAY OUTPUT

DC OUTPUT DC 5V 1.8A MAX

DISPLAY INPUT

DC OUTPUT DC 5V, 1.8A MAX

SPEAKER OUTPUT

52o Advanced Super View & BLACK TFT LCD 65o Advanced Super View & BLACK TFT LCD 2,073,600 pixels (1,920 g 1,080)

7.5 W g 2, 15 W (subwoofer) 50 mm g 120 mm g 2, Ø 26 mm g 2, Ø 77 mm g 1

EN50221, R206001

UHF/VHF 75 q Din type (Analogue & Digital) Satellite 75 q F type (DVB-S1/S2)

)/PR(CR), RCA pin (AUDIO R/L)

B(CB

Optical S/PDIF Digital audio output

HDMI

L/R, WOOFER

Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek, Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian, Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian

LC-52XS1E 294 W (1.0 W Standby) LC-65XS1E 512 W (1.0 W Standby)

TU-X1E 49 W (0.5 W Standby) TU-X1E 49 W (0.5 W Standby)

0 °C to e40 °C

65o LCD COLOUR TV, Model: LC65XS1E (Display), TU-X1E (AVC System)

NOTE

Refer to the inside back cover for dimensional drawings.

•

End of life disposal

A. Information on Disposal for Users (private households)

1. In the European Union

Attention: If you want to dispose of this equipment, please do not use the ordinary dust bin!

Used electrical and electronic equipment must be treated separately and in accordance with legislation that requires proper treatment, recovery and recycling of used electrical and electronic equipment. Following the implementation by member states, private households within the EU states may return their used

Attention: Your product is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collection system for these products.

electrical and electronic equipment to designated collection facilities free of charge*. In some countries* your local retailer may also take back your old product free of charge if you purchase a similar new one. *) Please contact your local authority for further details.

If your used electrical or electronic equipment has batteries or accumulators, please dispose of these separately beforehand according to local requirements.

By disposing of this product correctly you will help ensure that the waste undergoes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health which could otherwise arise due to inappropriate waste handling.

2. In other Countries outside the EU

If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal.

For Switzerland: Used electrical or electronic equipment can be returned free of charge to the dealer, even if you don’t purchase a new product. Further collection facilities are listed on the homepage of www.swico.ch or www.sens.ch.

B. Information on Disposal for Business Users

1. In the European Union

If the product is used for business purposes and you want to discard it:

Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities.

For Spain: Please contact the established collection system or your local authority for take-back of your used products.

2. In other Countries outside the EU

If you wish to discard of this product, please contact your local authorities and ask for the correct method of disposal.

Information on Battery Disposal

For EU: The crossed-out wheeled bin implies that used batteries should not be put to the general household waste! There is a separate collection system for used batteries, to allow proper treatment and recycling in accordance with legislation. Please contact your local authority for details on the collection and recycling schemes.

For Switzerland: The used battery is to be returned to the selling point.

For other non-EU countries: Please contact your local authority for correct method of disposal of the used battery.

Rating table for Child Lock

Broadcasted

rating Useradjusted rating

Universal viewing

Parental approval pref.

X-rated

Broadcasted

rating User-

adjusted rating

Universal viewing

Parental approval pref.

X-rated

456789101112131415161718

——————————————

✔

✔✔✔✔✔

✔✔✔✔✔✔✔✔✔✔✔✔✔✔✔

Universal viewing Parental approval pref. X-rated

———

✔

✔✔

——————————

AGE

Abbreviation list

Abbreviated term Stands for

ATV CEC DNR DTV DVB-C DVB-S DVB-T DVI EPG HDCP HDMI MHEG MPEG OSD PCM SAT USB WSS WYSIWYR

Analogue TV

Consumer Electronics Control

Digital Noise Reduction

Digital TV

Digital Video Broadcasting-Cable

Digital Video Broadcasting-Satellite

Digital Video Broadcasting-Terrestrial

Digital Visual Interface

Electronic Pogramme Guide

High-bandwidth Digital Content Protection

High-Definition Multimedia Interface

Multimedia and Hypermedia Expert Group

Moving Picture Experts Group

On Screen Display

Pulse Code Modulation

Satellite

Universal Serial Bus

Wide Screen Signalling

What You See Is What You Record

——

—

Memo

(

1528.0)/[1243.0

(

1528,0)/[1243,0

54.0 / 54,0

] ]

47.1 / 47,1

22.8 / 22,8

(

1429.0 )/[1156.0

(

]

765,0 [ / )

933,0 (

[ 200.0 ]

[ 200,0 ]

1429,0 )/[1156,0

]

765.0 [ / )

933.0 (

( 1046.0) / [ 878.0 ]

( 1046,0) / [ 878,0 ]

113.0

113,0

)

400.0

400,0

(

] ]

(

1312.0)/[1075.0

(

1312,0)/[1075,0

400.0 400,0

]

652.0

[

)

804.0

(

] ]

]

652,0 [ / )

804,0 (

]

511.0 [ / )

598.0 (

]

511,0 [ / )

598,0 (

56.6 / 56,6

60.4 / 60,4

( ) : LC-65XS1E

[ ] : LC-52XS1E

: LC-52XS1E/65XS1E

71.0

71,0

430.0 430,0

318.3 318,3

328.9 328,9

: TU-X1E

SHARP ELECTRONICS (Europe) GmbH

Sonninstraße 3, D-20097 Hamburg

SHARP CORPORATION

Printed in Japan Gedruckt in Japan Imprimé au Japon Stampato in Giappone Gedrukt in Japan Impreso en Japón Impresso no Japão

TINS-D825WJN1

08P12-JA-KG

Sharp LC-52XS1E, LC-65XS1E, TU-X1E Operating Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Introduction

Dear SHARP customer

Important Safety Precautions

Trademarks

Remote control unit

Part name

Display (Front view/Side view)

AVC System (Front view/Rear view)

AVC System (Bottom view)

Preparation

Supplied accessories

Optional accessories

Inserting the batteries

Using the remote control unit

Cautions regarding the remote control unit

Quick guide

Initial installation overview

Before turning on the main power

Preparing the Display

Setting the TV and antenna cables

Turning on and running the initial auto installation

Plugging the AC cord to the AC outlet

Power on and run the auto installation

Initial auto installation

Checking signal strength and channel strength (DVB-T/C)

Checking signal strength and channel strength (DVB-S)

Watching TV

Daily operation

Switching on/off

Changing channels

Selecting an external video source

Selecting a sound mode

Switching between digital, satellite and analogue broadcasts

EPG Overview

Useful settings for using EPG

Selecting a programme using EPG

Timer recording using EPG

Cancelling the timer recording

Teletext

Using the MHEG-5 application (UK only)

Connecting external devices

Introduction to connections

HDMI connection

Component connection

S-VIDEO/VIDEO connection

SCART connection

Controlling devices with SCART using AV Link

Speaker/amplifier connection

Inserting a CA Card

AQUOS LINK

Controlling HDMI devices using AQUOS LINK

AQUOS LINK connection

AQUOS LINK Setup

Operating an AQUOS LINK device

Menu operation

What is the MENU?

Common operations

Basic adjustment

Picture Settings

AV MODE

Audio Settings

Power Save Settings

Channel Settings

Auto Installation

Programme Setup

Password/Parental lock settings Language Settings (language,

Useful Viewing functions

Selecting the picture size

Selecting the WSS picture size automatically

Selecting the WSS picture size manually

Selecting the picture size manually

Selecting the recording picture size manually

Automatic volume adjustment

Outputting audio only

Selecting the HDMI picture size automatically
