LCD AV MONITOR
ENGLISH
OPERATION MANUAL
ENGLISH
LC-15M4U(01-08)Eng.p65 01.7.24, 5:21 PM1
IMPORTANT INFORMATION
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
The lightning flash with arrowhead symbol, within an equilat-
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Declaration of Conformity
SHARP LCD AV MONITOR MODEL LC-15M4U
This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Responsible Party:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430
TEL : 1-800-BE-SHARP (1-800-237-4277)
eral triangle, is intended to alert
the user to the presence of
uninsulated “dangerous voltage”
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the
user to the presence of important operating and maintenance
(servicing) instructions in the
literature accompanying the
product.
U.S.A. ONLY
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment
not expressly approved by the manufacturer could void the user’s authority to operate this equipment.
U.S.A. ONLY
CAUTION: Use the supplied AC cord as it is.
Do not remove the core part from the AC cord, and do not
change the way of winding cables around the core part.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Relocate or adjust the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
U.S.A. ONLY
2
LC-15M4U(01-08)Eng.p65 01.7.24, 5:21 PM2
IMPORTANT INFORMATION (Continued)
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury.
Disposal of these materials may be regulated due to environmental considerations. For disposal or
recycling information, please contact your local authorities or the Electronic Industries Alliance:
www.eia.org
LC-15M4U(01-08)Eng.p65 01.7.24, 5:21 PM3
3
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp LCD product. To ensure safety and many
years of trouble-free operation of your product, please read the Safety Precautions
carefully before using this product.
IMPORTANT SAFETY PRECAUTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and property
damage if improperly handled. This product has been engineered and manufactured with the highest
priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent
potential danger, please observe the following instructions when installing, operating and cleaning the
product. To ensure your safety and prolong the service life of your LCD product, please read the following
precautions carefully before using the product.
1. Read instructions—All operating instructions must be read and understood before the product is
operated.
2. Keep this manual in a safe place—These safety and operating instructions must be kept in a safe
place for future reference.
3. Observe warnings—All warnings on the product and in the instructions must be observed closely.
4. Follow instructions—All operating instructions must be followed.
5. Cleaning—Unplug the power cord from the AC outlet before cleaning the product. Use a damp
cloth to clean the product. Do not use liquid cleaners or aerosol cleaners.
6. Attachments—Do not use attachments not recommended by the manufacturer. Use of inadequate
attachments can result in accidents.
7. Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen
sink and laundry tub, swimming pool and in a wet basement.
8. Stand—Do not place the product on an unstable cart, stand, tripod or table. Placing the product
on an unstable base can cause the product to fall, resulting in serious personal injuries as well as
damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.
9. When relocating the product placed on a cart, it must be moved with utmost care.
Sudden stops, excessive force and uneven floor surface can cause the product to
fall from the cart.
10. Ventilation—The vents and other openings in the cabinet are designed for
ventilation. Do not cover or block these vents and openings since insufficient
ventilation can cause overheating and/or shorten the life of the product. Do not
place the product on a bed, sofa, rug or other similar surface, since they can
block ventilation openings. This product is not designed for built-in installation; do
not place the product in an enclosed place such as a bookcase or rack, unless
proper ventilation is provided or the manufacturer’s instructions are followed.
11. Power source—This product must operate on a power source specified on the specification label.
If you are not sure of the type of power supply used in your home, consult your dealer or local
power company. For units designed to operate on batteries or another power source, refer to the
operating instructions.
12. Power cord protection—The power cords must be routed properly to prevent people from stepping
on them or objects from resting on them. Check the cords at the plugs and product.
13. If the AC adapter is misplaced or needs to be replaced, obtain the same type of adapter from a
SHARP service center or your dealer.
14. If you plan to use a 12-VDC power supply unit other than the AC adapter supplied with the
product, make sure the power supply unit provides stable voltage with minimum fluctuations.
Unstable power supply can cause problems in the product.
15. The LCD panel used in this product is made of glass. Therefore, it can break when the product is
dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the
LCD panel breaks.
16. Overloading—Do not overload AC outlets or extension cords. Overloading can cause fire or
electric shock.
17. Entering of objects and liquids—Never insert an object into the product through vents or openings.
High voltage flows in the product, and inserting an object can cause electric shock and/or short
internal parts. For the same reason, do not spill water or liquid on the product.
4
LC-15M4U(01-08)Eng.p65 01.7.24, 5:21 PM4
18. Servicing—Do not attempt to service the product yourself. Removing covers can expose you to
high voltage and other dangerous conditions. Request a qualified service person to perform
servicing.
19. Repair—If any of the following conditions occurs, unplug the power cord from the AC outlet, and
request a qualified service person to perform repairs.
a.When the power cord or plug is damaged.
b.When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d.When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper
adjustment of controls not described in the instructions can cause damage, which often requires
extensive adjustment work by a qualified technician.
e.When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product
indicates that the product needs servicing.
20. Replacement parts—In case the product needs replacement parts, make sure that the service
person uses replacement parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can result in fire, electric
shock and/or other danger.
21. Safety checks—Upon completion of service or repair work, request the service technician to
perform safety checks to ensure that the product is in proper operating condition.
22. Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the
product according to the method recommended by the manufacturer.
23. Heat sources—Keep the product away from heat sources such as radiators, heaters, stoves and
other heat-generating products (including amplifiers).
24. Polarization—This AC adapter may be equipped with a polarized alternating current line plug (a
plug having one blade wider than the other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
The LCD panel is a very high technology product with 921,600 thin film transistors, giving you fine
picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or
red.
Please note that this does not affect the performance of your product.
LC-15M4U(01-08)Eng.p65 01.7.24, 5:21 PM5
5
CONTENTS
Page
DEAR SHARP CUSTOMER .............................................................................................................4
IMPORTANT SAFETY PRECAUTIONS .......................................................................................... 4
SUPPLIED ACCESSORIES ............................................................................................................. 7
PREPARATION................................................................................................................................. 8
Power Connection ...................................................................................................................... 8
Batteries for Remote Control ....................................................................................................8
NAMES OF PARTS (Main Unit) ......................................................................................................9
Names of Parts (Remote Control).......................................................................................... 11
BASIC OPERATION ....................................................................................................................... 12
Turning on MAIN POWER ........................................................................................................12
Switching the AV INPUT [AV1/AV2] Mode .............................................................................12
Sound Volume ........................................................................................................................... 13
ON/OFF Standby ....................................................................................................................... 13
SELECTING THE MENU ITEMS .................................................................................................... 14
ADJUSTMENT ................................................................................................................................ 15
Adjusting the LANGUAGE Settings........................................................................................ 15
Adjusting the PICTURE Settings ............................................................................................ 16
Adjusting the SET UP Settings ...............................................................................................18
Adjusting the SLEEP TIMER Settings ....................................................................................19
CONNECTING TO EXTERNAL DEVICES..................................................................................... 20
Connecting to a VCR, a DVD player etc. (AV 1/2 IN) ............................................................ 20
Connecting to a DVD player (COMPONENT terminal) ......................................................... 21
Outputting video and audio (video output) ...........................................................................22
Listening with Headphones ..................................................................................................... 22
Watching TV .............................................................................................................................. 23
EXAMPLE OF APPLICATION ....................................................................................................... 24
Mounting the LCD monitor on a wall ..................................................................................... 24
TROUBLESHOOTING .................................................................................................................... 25
SPECIFICATIONS........................................................................................................................... 26
DIMENSIONAL DRAWINGS .......................................................................................................... 27
6
LC-15M4U(01-08)Eng.p65 01.7.24, 5:21 PM6
SUPPLIED ACCESSORIES
Make sure the following accessories are provided with the product.
Operation Manual (×1) Wireless Remote Control (×1)
Printed on post-consumer recycled paper.
Imprimé sur du papier recyclé.
TINS-7526CEZZ
AC Adapter (×1)
LC-15M4U
LCD AV MONITOR
MONITEUR AV Á CRISTAUX
LIQUIDES
OPERATION MANUAL
MODE D’EMPLOI
Printed in Japan
Imprimé au Japon
TINS-7526CEZZ
ENGLISH
FRANÇAIS
RRMCG1459CESA
AC Cord (×1)
UADP-0228CEPZ
“AAA” size (UM/SUM-4)
Dry Battery (×2)
UBATU0026GEZZ
LC-15M4U(01-08)Eng.p65 01.7.24, 5:21 PM7
Wall Mount Bracket (×1)
QACCD3097CEPZ
* Product shape varies in some countries
Wall Mount Anchor
and Screw (×4)
Fixed Screw
for Set Stand (×1)
LANGU9041CESA
7
PREPARATION
Power Connection
Connect to DC input
terminal of the product.
Plug into AC outlet.
AC cord
Notes:
■ Always turn the main power switch of the LCD monitor to OFF when connecting the AC adapter.
■ Always unplug the AC adapter from the product and power outlet when not being used for a long period of time.
Household power outlet
DC input terminal
(12 VDC)
AC adapter
Batteries for Remote Control
If the remote control fails to operate monitor functions, replace the batteries in the remote control.
1 Open the battery
cover.
2 Insert batteries (two “AAA”
size (UM/SUM-4) batteries,
supplied with product).
3 Close the battery
cover.
■ Slide the cover while
pressing down.
■ Place batteries with their
terminals corresponding to
the (+) and (–) indications
in the battery compartment.
Caution!
Cautions regarding batteries
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the
instructions below.
• Place batteries with their terminals corresponding to the (+) and (–) indications.
• Different types of batteries have different characteristics. Do not mix batteries of different types.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries
and/or cause old batteries to leak chemicals.
• Remove batteries as soon as they are non-operable.
Chemicals that leak from batteries can cause a rash. If chemical leakage is found, wipe with a cloth.
• The batteries supplied with the product may have a shorter life expectancy due to storage conditions.
• If the remote control is not used for an extended period of time, remove batteries from the remote
control.
8
LC-15M4U(01-08)Eng.p65 01.7.24, 5:21 PM8
NAMES OF PARTS (Main Unit)
Main unit (front view)
Remote sensor
window
Power/Standby
indicator
Side control section
POWER
ON
OFF
AV INPUT
+
VOL
SELECT
MENU
MAIN
Speakers
MAIN POWER switch
AV INPUT button
VOL (+)/(–) buttons
SELECT (])/([)
buttons
MENU button
The six buttons shown at the left
have the same functions as
those on the remote control.
* When this manual describes
button functions, it is referring
to the buttons on the remote
control.
LC-15M4U(09-14)Eng.p65 01.7.24, 5:20 PM9
9
NAMES OF PARTS (Main Unit) (Continued)
Main unit (rear view)
Stand
Rear terminal section
AV 2 IN/OUT
AUDIO VIDEO
R L
AUDIO
VIDEO
VIDEO
Can also be used as video
output terminals.
AUDIO
R L
AUDIO
VIDEO
Rear Speaker
(woofer)
AV 1 IN
COMPONENT
Y P
B
P
POWER
INPUT
DC12V
HEAD
PHONE
R
POWER INPUT
DC12V
COMPONENT
HEADPHONE
AV 1 INAV 2 IN/OUT
10
LC-15M4U(09-14)Eng.p65 01.7.24, 5:20 PM10
NAMES OF PARTS (Remote Control)
Remote control
Infrared transmitter window
Menu control section
Power ON/OFF
button
AV INPUT
ON/OFF
AV INPUT
SELECT
MUTE
Sound MUTE button
MENU
MENU button
button
VOLVOL
SELECT
LCD MONITOR
SELECT (])/([) buttons
VOL (+)/(–) buttons
■ The side control section of the main unit is also provided with the AV INPUT, SELECT (])/([),
VOL (+)/(–) and MENU buttons.
* When this manual describes button functions, it is referring to the buttons on the remote control.
ON/OFF
AV INPUT
SELECT
LC-15M4U(09-14)Eng.p65 01.7.24, 5:20 PM11
The main power
switch is not
provided on the
remote control.
AV INPUT
MUTE
MENU
VOLVOL
Side control section of main unit
MAIN
POWER
ON
OFF
MENU
SELECT
VOLVOL
SELECT
AV INPUT
+
VOL
SELECT
MENU
ON/OFF
AV INPUT
MUTE
MENU
SELECT
VOLVOL
SELECT
11
BASIC OPERATION
Turning on MAIN POWER
Control section of main unit
1 Slide MAIN POWER, located on the
right side of the main unit, to ON.
2 The power indicator instantaneously
changes from red to green and the
OFF
POWER
ON
MAIN
main unit is turned on.
Notes:
■ When the Power indicator is red, press
ON/OFF on the remote control to turn on
the monitor.
The Power indicator changes from red to
green.
■ The input mode indication disappears after
five seconds.
Power/Standby indicator
Switching the AV INPUT [AV1/AV2] Mode
1 Turn on the power of the connected
video equipment.
2 Press AV INPUT and select the
applicable input source. The screen
displays AV1 or AV2 mode at the
upper right corner each time AV
INPUT is pressed.
ON/OFF
AV INPUT
ON/OFF
AV INPUT
MUTE
MENU
SELECT
▼ On-screen display
Initial mode (AV1)
AV1
N358
SELECT
LCD MONITOR
12
LC-15M4U(09-14)Eng.p65 01.7.24, 5:20 PM12
VOLVOL
Note:
■ The AV input mode indication remains for
five seconds.
• AV1: Video equipment connected to the
AV1 input terminals.
The display of the AV1 mode indicates
either AV1 or COMPONENT depending on the adjustment of the SET UP
settings.
AV1 is displayed when AV1 is set to
NORMAL in the SET UP settings, and
COMPONENT is displayed when AV1
is set to COMPONENT.
(see page 18)
• AV2: The AV2 mode can be set to either IN
or OUT in the SET UP settings.
(see page 18)
AV2 indication is not displayed when
the mode is selected to OUT.
AV1 mode
AV1
AV2 mode
AV2
VOLUME
10
Sound Volume
VOLUME
30
VOLUME
50
BASIC OPERATION (Continued)
ON/OFF
AV INPUT
SELECT
SELECT
LCD MONITOR
MUTE
MENU
To adjust the volume
Press VOL (+) to increase the sound
MUTE
|
volume. The indicator segment
increases.
VOLVOL
Press VOL (–) to decrease the sound
|
volume. The indicator segment
VOL
decreases.
(+)/( )
To mute the sound
Press MUTE to temporarily turn off the
|
sound.
The MUTE mark
Press MUTE or VOL (+)/(–) to turn the
|
sound back to the previous level.
The MUTE mark
Note:
■ MUTE is automatically cleared when the
following button is pressed: ON/OFF,
VOL (+)/(–) or MUTE.
is displayed.
disappears.
ON/OFF Standby
ON/OFF
AV INPUT
MUTE
MENU
SELECT
SELECT
LCD MONITOR
ON/OFF
VOLVOL
To turn off the LCD monitor
Press ON/OFF.
The power indicator turns red.
To turn the LCD monitor back on
Press ON/OFF again.
The power indicator turns green.
13
LC-15M4U(09-14)Eng.p65 01.7.24, 5:20 PM13
SELECTING THE MENU ITEMS
Selecting the Menu Items
• This LCD monitor set allows you to adjust the picture, sound, and other features using the On-screen
Display. Select the desired menu item by following the steps below and then refer to the indicated page
for details.
ON/OFF
AV INPUT
LCD MONITOR
SELECT
SELECT
MUTE
MENU
VOLVOL
VOL
(+)/( )
MENU
SELECT
(])/([)
1 Press MENU to display the MENU
screen.
2 Press SELECT (])/([) to select
the desired menu item.
• The cursor moves up or down.
• The cursor indicates the selected
menu item.
3 Press VOL (+)/(–) to enter.
4 Press MENU again to exit.
MENU
SET UP
LANGUAGE
ENTER: –VOL+SELECT: EXIT: MENU
Notes:
■ The displayed items differ depending
on the setting conditions.
■ The selected item is highlighted in
yellow.
■ Items in purple cannot be selected.
■ The original screen is restored by
pressing MENU on the menu screen
or any of the adjustment screens.
The original screen is also restored
when no buttons have been pressed
for about a period of 30 seconds.
The adjustment values and settings
that were changed before the screen
is restored are saved as is in the
memory.
(Pages 16 and 17)
PICTURE(AV1)
CONTRAST
TINT
COLOR
BLACK LEVEL
SHARPNESS
RED-BLUE
GREEN
COLOR SYSTEM
RESET
[ 30]
[ 0]
[ 0]
[ 0]
[ 0]
[ 0]
[ 0]
[ AUTO]
ENTER: –VOL+SELECT: EXIT: MENU
(Pages 18 and 19)
SET UP
BRIGHTNESS
UPSIDE
RIGHT/LEFT
BLUE SCREEN
AV1
AV2 IN/OUT
SLEEP TIMER
[BRIGHT ]
[NORMAL]
[NORMAL]
[OFF ]
[NORMAL]
[IN ]
[ – – – REMAIN]
ADJUST: –VOL+SELECT: EXIT: MENU
(Page 15)
LANGUAGE
ENGLISH
ESPAÑOL
FRANÇAIS
SELECT: EXIT: MENU
* The screen indications shown above are larger than actual size for easy reading.
14
LC-15M4U(09-14)Eng.p65 01.7.24, 5:21 PM14
ADJUSTMENT
Adjusting the LANGUAGE Settings
MENU on the LCD monitor set can also be used to select the language.
ON/OFF
AV INPUT
SELECT
SELECT
LCD MONITOR
MUTE
MENU
VOLVOL
VOL
(+)/( )
MENU
SELECT
(])/([)
1 Press MENU to display the MENU
screen.
2 Press SELECT (])/([)
to move the
cursor to LANGUAGE, and then press
VOL (+)/(–)
to display the LANGUAGE
screen.
3 Press SELECT (])/([) to select the
language you want to display.
4 Press MENU again to exit.
MENU
SET UP
LANGUAGE
ENTER: –VOL+SELECT: EXIT: MENU
LANGUAGE
ENGLISH
ESPAÑOL
FRANÇAIS
SELECT: EXIT: MENU
LC-15M4U(15-19)Eng.p65 01.7.24, 5:18 PM15
15
ADJUSTMENT (Continued)
Adjusting the PICTURE Settings
ON/OFF
AV INPUT
LCD MONITOR
SELECT
SELECT
MUTE
MENU
VOLVOL
VOL
(+)/( )
MENU
SELECT
(])/([)
1 Press MENU to display the MENU
screen.
2 Press SELECT (])/([) to move the
cursor to PICTURE, and then press
VOL (+)/(–) to display the PICTURE
screen.
3 Press SELECT (])/([) to move the
cursor and select the desired
adjustment item.
All items that can be adjusted are
shown in the table on the next page.
4 Press VOL (+)/(–) to display the screen
for the selected adjustment item.
5 Press VOL (+)/(–) to make the
adjustment.
6 Press MENU again to exit.
MENU
SET UP
LANGUAGE
ENTER: –VOL+SELECT: EXIT: MENU
PICTURE(AV1)
CONTRAST
TINT
COLOR
BLACK LEVEL
SHARPNESS
RED-BLUE
GREEN
COLOR SYSTEM
RESET
COLOR
0
– +
[ 30]
[ 0]
[ 0]
[ 0]
[ 0]
[ 0]
[ 0]
[ AUTO]
ENTER: –VOL+SELECT: EXIT: MENU
ADJUST: –VOL+SELECT: EXIT: MENU
16
LC-15M4U(15-19)Eng.p65 01.7.24, 5:19 PM16
ADJUSTMENT (Continued)
Adjusting the PICTURE Settings (Continued)
Selected item Press VOL (–). Press VOL (+).
CONTRAST Decrease contrast Increase contrast
TINT Toward purple Toward green
COLOR Lower color intensity Higher color intensity
BLACK LEVEL Decrease brightness Increase brightness
SHARPNESS Soft picture Sharp picture
RED-BLUE More red More blue
GREEN Less green More green
COLOR SYSTEM Press VOL (+)/(–) to select COLOR SYSTEM.
Note:
■ TINT is displayed only when N358 or N443 is selected.
Switching the COLOR SYSTEM
Set the system to AUTO for normal reception. The AUTO mode automatically detects the receiving signal
system and changes the reception system of the set.
When the picture or sound is not stable, switching to an appropriate system may improve the picture or
sound quality.
LC-15M4U(15-19)Eng.p65 01.7.24, 5:19 PM17
17
ADJUSTMENT (Continued)
Adjusting the SET UP Settings
The SET UP items can be set by the user.
1 Press MENU to display the MENU
screen.
2 Press SELECT (])/([) to move the
cursor to SET UP.
ON/OFF
AV INPUT
SELECT
MUTE
MENU
VOL
(+)/( )
MENU
VOLVOL
SELECT
SELECT
LCD MONITOR
(])/([)
3 Press VOL (+)/(–) to display the SET
UP screen.
4 Check the factory setting of each item
on the SET UP screen.
The user can change the settings with
SELECT (])/([) and VOL (+)/(–).
5 Press MENU again to exit.
Selected item Factory setting Setting change
BRIGHTNESS
UPSIDE
[BRIGHT] Maximum brightness
[NORMAL] Normal vertical
image orientation
[NORMAL] Brightness 60% → Suitable for viewing in well-lit areas.
[DARK] Brightness 20% → Sufficiently bright when viewing in
[DOWN] Inverted image → To display images upside down for
MENU
SET UP
LANGUAGE
SET UP
BRIGHTNESS
UPSIDE
RIGHT/LEFT
BLUE SCREEN
AV1
AV2 IN/OUT
SLEEP TIMER
Saves energy.
dim areas.
special uses.
ENTER: –VOL+SELECT: EXIT: MENU
[BRIGHT ]
[NORMAL]
[NORMAL]
[OFF ]
[NORMAL]
[IN ]
[ – – – REMAIN]
ADJUST: –VOL+SELECT: EXIT: MENU
RIGHT/LEFT
BLUE SCREEN
AV1
AV2 IN/OUT
SLEEP TIMER
[NORMAL] Normal horizontal
image orientation
[OFF] This feature is
inactivated.
[NORMAL]
[IN]
[ – – – REMAIN]
[MIRROR] Mirror image → To display mirror images for special
[ON] The screen is turned blue when there is no signal.
[COMPONENT]
[OUT
] Line Output is selected, Output volume is fixed, Speaker
[OUT
The setting can be specified in increments of 30 minutes and in a
range between 30 and 120 minutes. (see page 19)
output is available.
] Line Output is selected, Output volume is variable,
Speaker output is Mute.
Note:
■ In BLUE SCREEN, PICTURE setting displayed in purple cannot be selected.
uses.
ABC
ABC
ABC
18
LC-15M4U(15-19)Eng.p65 01.7.24, 5:19 PM18
Adjusting the SLEEP TIMER Settings
ADJUSTMENT (Continued)
ON/OFF
AV INPUT
SELECT
SELECT
LCD MONITOR
MUTE
MENU
VOLVOL
VOL
(+)/( )
MENU
SELECT
(])/([)
1 Press MENU to display the MENU
screen.
2 Press SELECT (])/([)
to move the
cursor to SET UP, and then press VOL
to display the SET UP screen.
(+)/(–)
3 Press SELECT (])/([)
to move the
cursor to SLEEP TIMER, and then
press VOL (+)/(–)
to set SLEEP TIMER
(in minutes).
The setting can be specified in
increments of 30 minutes and in a
range between 30 and 120 minutes.
The setting is turned off when --- is
displayed.
4 Press MENU again to exit.
Note:
■ If the monitor’s power is turned off and then
turned back on again after the SLEEP TIMER
has been set, the setting will be canceled.
MENU
SET UP
LANGUAGE
SET UP
BRIGHTNESS
UPSIDE
RIGHT/LEFT
BLUE SCREEN
AV1
AV2 IN/OUT
SLEEP TIMER
ENTER: –VOL+SELECT: EXIT: MENU
[BRIGHT ]
[NORMAL]
[NORMAL]
[OFF ]
[NORMAL]
[IN ]
[ – – – REMAIN]
ADJUST: –VOL+SELECT: EXIT: MENU
LC-15M4U(15-19)Eng.p65 01.7.24, 5:19 PM19
19
CONNECTING TO EXTERNAL DEVICES
POWER
INPUT
DC12V
Connecting to a VCR, a DVD Player, etc. (AV 1/2 IN)
This LCD monitor can be connected to most external devices as shown below.
When connecting to an external device, turn off the power of the main unit and then connect to the device
to prevent any possible damage.
To AUDIO input
terminal
Audio cord
To audio output
terminal
AV 2 IN/OUT
AUDIO VIDEO
R L
VIDEO
AUDIO
R L
To VIDEO input
terminal
(BNC TYPE)
To video output
terminal
Audio
(R)
Audio
(L)
Video
AV 1 IN
Y P
To AUDIO input
terminal
Audio cordVideo cord
To audio output
terminal
COMPONENT
B
Audio
(R)
P
Audio
(L)
R
To VIDEO input
terminal
Video cord
(BNC TYPE)
To video output
terminal
Video
AUX 1
AUX 1
TUNER/BAND
TUNER/BAND
AUX 3AUX 2
AUX 3AUX 2
DVD
DVD
SURROUND
SURROUND
ON/OFF
ON/OFF
VCR, Laser disc player, etc. DVD Player, etc.
* For improved picture quality from video
sources with COMPONENT output, use
the connection diagram on page 21.
Notes:
■ PC connection is not possible.
■ Use a commercially available audio/video cord for the cable.
■ When connecting or disconnecting the video cord (BNC TYPE) to or from the VIDEO input terminal, disconnect the
audio cable.
■ Only connect audio/video signals to AV 1/2 IN terminals. Connecting other signals may result in a malfunction.
■ Do not connect headphones to AV 2 IN.
■ For details concerning the usage and connection of external devices, see their respective instruction manuals.
20
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM20
CONNECTING TO EXTERNAL DEVICES (Continued)
POWER
INPUT
DC12V
Connecting to a DVD player (COMPONENT terminal)
AV 2 IN/OUT
AUDIO VIDEO
R L
VIDEO
AUDIO
R L
To AUDIO
input terminal
Audio cord
To audio
output terminal
Audio
(R)
Audio
(L)
AV 1 IN
COMPONENT
Y PB
PR
To COMPONENT
terminal
Video cord
(BNC TYPE)
To COMPONENT
terminal
Y
P
B
P
R
AUX 1
AUX 1
TUNER/BAND
TUNER/BAND
AUX 3AUX 2
AUX 3AUX 2
DVD
DVD
SURROUND
SURROUND
ON/OFF
ON/OFF
DVD Player
Note:
■ To view the image from the component connected to the terminals for AV 1 IN, set AV1 to COMPONENT with the
SET UP setting (see page 18).
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM21
21
CONNECTING TO EXTERNAL DEVICES (Continued)
POWER
INPUT
DC12V
VOLUME
60
Outputting video and audio (video output)
It is possible to output video and audio from the set through the AV output terminals (AV-OUT).
AV 2 IN/OUT
AUDIO VIDEO
R L
VIDEO
AUDIO
R L
AV 1 IN
COMPONENT
Y P
B
P
R
Connect a VCR, Audio amplifies, etc
Notes:
■ AV2 can be set to input or output. When set to input, output is not possible and vice versa.
■ When using COMPONENT, there is no video output can be made to the AV output terminal, but there is audio output
for connecting to external audio systems.
Listening with Headphones
■ Plug the headphone mini-plug into the headphone jack located on the rear side of the set.
POWER
INPUT
HEAD
DC12V
PHONE
Mini-plug
HEADPHONE
jack
Headphones
Notes:
■ The headphones are not included in the supplied accessories.
■ No sound will be heard from the main unit speakers when the headphones are connected.
22
▼ On-screen display
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM22
CONNECTING TO EXTERNAL DEVICES (Continued)
Watching TV
To view a TV broadcast on the LCD monitor, the set-top box must be used with a TV tuner, satellite tuner
or VCR. Refer to the diagram below for wiring.
TV ROOM ANTENNA SET-TOP BOX MONITOR
TERMINAL
TV BROADCAST
(ON AIR)
PAY TV
SATELLITE TV
TV ANT
TV ANT
CABLE
SATELLITE
RF IN
VCR
RF IN
TV TUNER
RF IN
SET TOP BOX
RF IN
SATELLITE TUNER
VIDEO OUT
VIDEO OUT
VIDEO OUT
VIDEO OUT
RL
RL
RL
RL
VIDEOAUDIO
(BNC TYPE)
VIDEOAUDIO
(BNC TYPE)
VIDEOAUDIO
(BNC TYPE)
VIDEOAUDIO
(BNC TYPE)
WEB TV
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM23
TV ANT
TEL, LINE
RF IN
Web
SET TOP BOX
VIDEO OUT
RL
VIDEOAUDIO
(BNC TYPE)
23
EXAMPLE OF APPLICATION
Mounting the LCD monitor on a wall
Note:
■ Consult with your dealer and authorized shop before installation. (Various materials are used for wall. Some materials may not be strong enough or thick enough to hold the mounting screws in place or support the weight of the set.)
1 Drill holes measuring 0.3 in. (8 mm) in
diameter on the wall (hollow wall, plaster
board).
2 Insert the supplied anchors into the holes,
and strike the heads of the anchors with a
hammer until the anchors are securely
installed in the wall.
Note:
■ The supplied anchor screws are inserted in
anchors. Remove the screws from the anchors
before installation.
3 Position the supplied wall mount bracket in
place using the anchor screws. Tighten the
anchor screws securely.
CAUTION: • The wall mount bracket must be
installed with four anchor screws.
Be sure to thighten so that it will
not fall down under a pulling
force of at least 44 lbs (20 Kg).
• The anchors are designed for
plaster boards with a thickness
of 0.5 in. (12.5 mm). For a 0.4in. (9.5 mm) thickness board or a
wooden wall, find similar anchors
or screws at a hardware store.
0.3 in. (8 mm) ø
Anchor Screw
(Supplied)
Wall Mount
Bracket
(Supplied)
1.6 in. (40 mm)
4.3 in. (110 mm)
0.5 in. (12.5 mm)
Anchor
(Supplied)
4 Mount the back stand of the main unit on the
wall mount bracket with the supplied fixed
screw.
* To change the vertical angle of the
monitor, tilt the screen up to 8°
downward. Adjust the angle of the
monitor for the most comfortable
viewing.
24
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM24
Wall Mount Bracket (× 1)
Anchor and Screw (× 4)
Fixed Screw (× 1)
(Supplied)
TROUBLESHOOTING
Problem Check item Pages
• Make sure that the AC power cord plug is securely
inserted in AC power outlet and AC adapter.
• Make sure that the AC adapter’s DC output is securely
connected to main unit’s DC input terminal.
• Make sure that the main power switch of the main unit is
on.
• Make sure that the AV input is properly set.
• Make sure that the cables are correctly connected to
No image on screen, and
no sound from speakers.
rear terminal section of LCD monitor.
• Check to see if the batteries in the remote control have
sufficient power.
• Make sure that the unit is not in the standby mode
(power indicator is red).
8
12
12
8
13
Speakers produce sound,
but no image on screen.
Image is too light or
improperly tinted.
Image is displayed, but no
sound from speakers.
• Make sure that the cables are correctly connected.
• Check COLOR and TINT adjustments. (NTSC ONLY)
• Check CONTRAST and BLACK LEVEL adjustments.
• Check RED-BLUE adjustments.
• Make sure that the VCR connection cord is correctly
connected to the COMPONENT terminal.
• Make sure that the cables are properly connected to
rear terminal section of LCD monitor.
• Check the volume adjustment.
• Make sure that the sound is not muted.
• Make sure that the headphones are not connected.
• Check to see if BRIGHTNESS is set to DARK.
• Check CONTRAST and BLACK LEVEL adjustments.
• Lamp may have reached the end of its life. (Contact a
Sharp service shop for a lamp replacement.)
20, 21
17
17
13
13
22
18
17
Image is too dark.
No colors on image.
Remote control does not work.
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM25
• Check COLOR adjustment.
• Check the color system setting.
• Make sure that the VCR connection cord is correctly
connected to P
COMPONENT terminal.
• Check to see if the batteries in the remote control
have sufficient power.
• Make sure that (+) and (–) side of batteries are
properly positioned in remote control.
• Make sure that the remote sensor window is not
under strong fluorescent lighting.
B and PR of the
17
17
8
8
25
SPECIFICATIONS
ITEMS LC-15M4U
LCD Panel 15” Black TFT LCD
Number of dots 921,600 (640 × 3 × 480) dots
Low reflection Non-glare
Brightness 430 cd/m
Viewing angles Left to right 160°
Upper to lower 160°
Lamp Life 60,000 hours (at normal mode)
COLOR SYSTEM System N358/N443/PAL/PAL-M/PAL-N/PAL-60/SECAM
AUDIO Output 3.4 W (0.7 W × 2 + 2.0 W)
Speaker Full range 1.2 × 1.6 in. (3 × 4 cm) Oval, 2 pcs.
Woofer 2.6 in. (6.5 cm) Round, 1 pc.
TERMINALS AV 1 IN Video Composite (BNC TYPE), Audio R/L
Component input, Y/PB/PR (BNC TYPE)
AV 2 IN/OUT Video Composite (BNC TYPE), Audio R/L
Headphone jack 0.1 in. (3.5 mm) ø jack
POWER SUPPLY DC operation DC 12 V, Typical: 1.9 A, Max: 3.2 A
AC operation AC 110~240 V, 50/60 Hz with AC adapter
Power consumption AC 120 V, Typical: 28 W, Standby: 0.5 W
APPEARANCE Exterior color Silver
Outside dimensions 14.1 (W) × 12.2 (H) × *2.5 (D) in.
(357.0 (W) × 309.2 (H) × *62.5 (D) mm)
Net weight 7.5 lbs (3.4 kg), incl. stand, excl. accessories
ACCESSORIES Operation manual Language: English/French/Spanish/Portuguese
Remote control Infrared wireless type
Wall mount parts Wallmount Bracket × 1 pc.
Fixed Screw × 1 pc.
Wallmount Anchor and Screw × 4 pc.
AC adapter Auto-wide type, 1 pc.
DC cable: 6.5 ft (2 m)
DC power converter:
2.5 (W) x 1.5 (H) x 4.7 (D) in.
(65 (W) x 37 (H) x 120 (D) mm)
AC cord 6.1 ft (1.85 m), 1 pc.
Batteries “AAA” size (UM/SUM-4) Dry Battery × 2 pc.
OSD LANGUAGE Language English/French/Spanish
2
As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of
production units. There may be some deviations from these values in individual units.
* Excluding stand.
26
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM26
DIMENSIONAL DRAWINGS
Unit: inch/mm
14.1/357
5.4/136.7
12.2/309.2
1.2/31
0.6/16
1.4/36.6
2.5/62.5
MAIN
POWER
ON
OFF
AV INPUT
VOL
SELECT
MENU
3.4/87
6.7/169
90°
POWER
VIDEO AUDIO VIDEO COMPONENT HEAD
AUDIO
RL RL Y PBP
AV 1 INAV 2 IN/OUT
POWER
INPUT
DC12V
PHONE
R
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM27
27
Calling for Service
For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or customer
assistance, please call 1-800-BE-SHARP.
LIMITED WARRANTY
END-USER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first end user purchaser that this Sharp brand product (the
“Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it
will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured
equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below
nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or
other misuse, abnormal service or handling, or which has been altered or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide
proof of purchase to the servicer.
To the extent permitted by applicable state law, the warranties set forth herein are in lieu of, and exclusive of, all other
warranties, express or implied. Specifically, ALL OTHER WARRANTIES OTHER THAN THOSE SET FORTH ABOVE ARE
EXCLUDED. ALL EXPRESS AND IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY,
FITNESS FOR USE, AND FITNESS FOR A PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED. If, under
applicable state law, implied warranties may not validly be disclaimed or excluded, the duration of such implied warranties is
limited to the period(s) from the date of purchase set forth below.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those
described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and
exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described
herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise.
In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused
by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any
way responsible for any incidental or consequential economic or property damage. Some states do not allow limits on
warranties or on remedies for breach in certain transactions; in such states, the limits herein may not apply.
Model Specific Section
Your Product Model Number & Description: LC-15M4U LCD AV MONITOR
Warranty Period for this Product: One (1) year parts and labor from the date of purchase.
Additional Item(s) Excluded from
Warranty Coverage (if any): None
Where to Obtain Service: From a Sharp Authorized Servicer located in the United States.
What to do to Obtain Service: Ship prepaid or carry in your Product to a Sharp Authorized Servicer.
TO OBTAIN PRODUCT INFORMATION, CALL 1-888-LCD-SHARP.
(Be sure to have this information available when you need service for
your Product.)
To find the location of the nearest Sharp Authorized Servicer, call
Sharp toll free at 1-800-BE-SHARP.
Be sure to have Proof of Purchase available. If you ship the Product,
be sure it is insured and packaged securely.
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
28
LC-15M4U(20-28)Eng.p65 01.7.24, 5:17 PM28
Loading...
