LC-10A2U
LCD COLOR TELEVISION
ENGLISH
OPERATION MANUAL
ENGLISH
2
Important Information
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
The lightning flash with arrowhead symbol, within an equilat-
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment
not expressly approved by the manufacturer could void the user’s authority to operate this equipment.
eral triangle, is intended to alert
the user to the presence of
uninsulated “dangerous voltage”
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the
user to the presence of important operating and maintenance
(servicing) instructions in the
literature accompanying the
product.
U.S.A. ONLY
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
“Note to CATV system installer: This reminder is provided to call the CATV system installer’s attention to Article 820-40
of the National Electrical Code that provides guidelines for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.”
IMPORTANT:
To aid reporting in case of loss or theft, please
record the TV’s model and serial numbers in the
space provided. The numbers are located at the
rear of the TV.
Model No.:
Serial No.:
U.S.A. ONLY
3
CONTENTS
Page
DEAR SHARP CUSTOMER .............................................................................................................5
IMPORTANT SAFETY PRECAUTIONS ....................................................................................... 5,6
SUPPLIED ACCESSORIES ............................................................................................................. 7
PREPARATION ............................................................................................................................ 8-10
Preparing and Using the Remote Control ............................................................................... 8
Batteries for Remote Control ....................................................................................................8
Power Connection ...................................................................................................................... 9
Antenna Connection .............................................................................................................. 9,10
FRONT AND REAR CONTROL OPTIONS ................................................................................... 11
REMOTE CONTROL ...................................................................................................................... 13
BASIC OPERATION ................................................................................................................. 13-16
Turning on POWER................................................................................................................... 14
Switching TV/VIDEO AV1/AV2/TV Mode ................................................................................ 14
Sound Volume ........................................................................................................................... 15
ON/OFF Standby ....................................................................................................................... 15
Changing the Channels ............................................................................................................ 16
SELECTING THE MENU ITEMS .................................................................................................... 17
Selecting a Menu Item .............................................................................................................. 17
EZ SETUP DURING FIRST POWER ON....................................................................................... 18
ADJUSTMENT .......................................................................................................................... 19-26
Adjusting the LANGUAGE Settings ........................................................................................ 19
Adjusting the SLEEP TIMER Settings ....................................................................................19
Adjusting the VIDEO ADJUST Settings ............................................................................ 20,21
Adjusting the PRESET Settings .............................................................................................. 22
SETUP .................................................................................................................................. 23-25
Adjusting the BLUE SCREEN Settings .................................................................................. 26
LISTENING WITH A HEADPHONE ...............................................................................................27
EXAMPLE OF APPLICATION ....................................................................................................... 27
CONNECTING WITH EXTERNAL DEVICES .......................................................................... 28-30
TROUBLESHOOTING ............................................................................................................... 31,32
SPECIFICATIONS........................................................................................................................... 33
4
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp LCD Color TV product. To ensure safety and
many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product.
IMPORTANT SAFETY PRECAUTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and property
damage if improperly handled. This product has been engineered and manufactured with the highest
priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent
potential danger, please observe the following instructions when installing, operating and cleaning the
product. To ensure your safety and prolong the service life of your LCD color TV product, please read the
following precautions carefully before using the product.
1. Read instructions—All operating instructions must be read and understood before the product is
operated.
2. Keep this manual in a safe place—These safety and operating instructions must be kept in a safe
place for future reference.
3. Observe warnings—All warnings on the product and in the instructions must be observed closely.
4. Follow instructions—All operating instructions must be followed.
5. Cleaning—Unplug the power cord from the AC outlet before cleaning the product. Use a damp
cloth to clean the product. Do not use liquid cleaners or aerosol cleaners.
6. Attachments—Do not use attachments not recommended by the manufacturer. Use of inadequate
attachments can result in accidents.
7. Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen
sink and laundry tub, swimming pool and in a wet basement.
8. Stand—Do not place the product on an unstable cart, stand, tripod or table. Placing the product
on an unstable base can cause the product to fall, resulting in serious personal injuries as well as
damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.
9. When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops,
excessive force and uneven floor surface can cause the product to fall from the cart.
10. Ventilation—The vents and other openings in the cabinet are designed for ventilation. Do not
cover or block these vents and openings since insufficient ventilation can cause overheating and/
or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar
surface, since they can block ventilation openings. This product is not designed for built-in
installation; do not place the product in an enclosed place such as a bookcase or rack, unless
proper ventilation is provided or the manufacturer’s instructions are followed.
11. Power source—This product must operate on a power source specified on the specification label.
If you are not sure of the type of power supply used in your home, consult your dealer or local
power company. For units designed to operate on batteries or another power source, refer to the
operating instructions.
12. Power cord protection—The power cords must be routed properly to prevent people from stepping
on them or objects from resting on them. Check the cords at the plugs and product.
13. If the AC adapter is misplaced or needs to be replaced, obtain the same type of adapter from a
SHARP service center or your dealer.
14. The LCD panel used in this product is made of glass. Therefore, it can break when the product is
dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the
LCD panel breaks.
15. Overloading—Do not overload AC outlets or extension cords.
Overloading can cause fire or electric shock.
16. Entering of objects and liquids—Never insert an object into the product through vents or openings.
High voltage flows in the product, and inserting an object can cause electric shock and/or short
internal parts. For the same reason, do not spill water or liquid on the product.
5
IMPORTANT SAFETY PRECAUTIONS (Continued)
17. Servicing—Do not attempt to service the product yourself. Removing covers can expose you to
high voltage and other dangerous conditions. Request a qualified service person to perform
servicing.
18. Repair—If any of the following conditions occurs, unplug the power cord from the AC outlet, and
request a qualified service person to perform repairs.
a.When the power cord or plug is damaged.
b.When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d.When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper
adjustment of controls not described in the instructions can cause damage, which often requires
extensive adjustment work by a qualified technician.
e.When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product
indicates that the product needs servicing.
19. Replacement parts—In case the product needs replacement parts, make sure that the service
person uses replacement parts specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can result in fire, electric
shock and/or other danger.
20. Safety checks—Upon completion of service or repair work, request the service technician to
perform safety checks to ensure that the product is in proper operating condition.
21. Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the
product according to the method recommended by the manufacturer.
22. Heat sources—Keep the product away from heat sources such as radiators, heaters, stoves and
other heat-generating products (including amplifiers).
23. Polarization—This AC adapter may be equipped with a polarized alternating current line plug (a
plug having one blade wider than the other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug.
The LCD panel is a very high technology product with 921,600 thin film transistors, giving you fine
picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or
red.
Please note that this does not affect the performance of your product.
6
SUPPLIED ACCESSORIES
Make sure the following accessories are provided with the product.
Operation Manual (×1) Wireless Remote Control (×1)
ENGLISH
LC-10A2U
FRAN AIS
LCD COLOR TELEVISION
T L VISION COULEUR ¸
CRAN ¸ CRISTAUX
LIQUIDES (LCD)
OPERATION MANUAL
MODE D EMPLOI
PRINTED IN JAPAN
IMPRIM AU JAPON
Printed on post-consumer recycled paper.
Imprim sur du papier recycl.
TINS-7236CEZZ
TINS-7236CEZZ
0C. T2444-A
RRMCG1559CESA
Wall Mount Bracket (×1)
Wall Mount Bracket Screws (×4)
Fixed Screw for Set Stand (×1)
AC CordAntenna Cable
QCNW-5730CEZZ
QACCD3093CEZZ
Size AAA Dry Battery (×2)AC Adapter (×1)
LANGU9053CE01
UADP-0211CEZZ
UBATU0026GEZZ
7
PREPARATION
Preparing and Using the Remote Control
■ Use the remote control by pointing it towards the remote sensor window.
Objects between the remote control and sensor window may prevent proper
operation.
Cautions regarding use of remote control
■ Do not expose the remote control to shock.
In addition, do not expose the remote control to liquids, and do not place in
an area with high humidity.
■ Do not install or place the remote control under direct sunlight.
The heat may cause deformation of the unit.
■ The remote control may not work properly if the remote sensor window of the
main unit is under direct sunlight or strong lighting. In such case, change the
angle of the lighting or LCD TV set, or operate the remote control closer to
the remote sensor window.
Batteries for Remote Control
If the remote control fails to operate LCD color TV functions, replace the batteries in the remote
control.
1 Open the battery
cover.
2 Insert batteries (two
size-AAA batteries,
supplied with product).
3 Close the battery
cover.
■ Slide the cover while
pressing down.
–
Caution!
Cautions regarding batteries
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the
instructions below.
• Place batteries with their terminals corresponding to the (+) and (–) indications.
• Different types of batteries have different characteristics. Do not mix batteries of different types.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new
batteries and/or cause old batteries to leak chemicals.
• Remove batteries as soon as they are non-operable.
Chemicals that leak from batteries can cause a rash. If chemical leakage is found, wipe with a
cloth.
• The batteries supplied with the product may have a shorter life expectancy due to storage conditions.
• If the remote control is not used for an extended period of time, remove batteries from the remote
control.
■ Place batteries with their
terminals corresponding to
the (+) and (–) indications
in the battery compartment.
8
PREPARATION (Continued)
Power Connection
Connect to the DC input
terminal of the product.
Plug into AC outlet.
Household power outlet
To DC input terminal
(DC 12V)
AC cord
Notes:
■ Use a commercially available AC plug adapter, if necessary, depending on the design of the wall socket.
■ Always turn the main power switch of the LCD TV set to OFF when connecting the AC adapter.
■ Always unplug the AC adapter from the product and power outlet when not using for long periods of time.
AC adapter
Antenna Connection
CABLE TV (CATV) CONNECTION
• A 75 ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75
ohm coaxial cable to the set, screw the 75 ohm cable to the COAXIAL CABLE CONNECTOR.
• Some cable TV companies offer “premium pay channels”. Since the signals of these premium
pay channels are scrambled, a cable TV converter/descrambler is generally provided to the
subscriber by the cable TV company. This converter/descrambler is necessary for normal
viewing of the scrambled channels. (Place your TV on channel 3 or 4, typically one of these
channels is used. If this is unknown, consult your cable TV company.) For more specific instructions on installing cable TV, consult your cable TV company. One possible method of utilizing the
converter/descrambler provided by your cable TV company is explained below.
Please note: RF switch equipped with position A/B (not provided) is required.
“A” position on the RF switch (not supplied) : You can view all unscrambled channels using the TV’s
“B” position on the RF switch (not supplied) : You can view the scrambled channels via the converter/
RF switch (not supplied)
OUT
Cable TV converter/
descrambler
(not supplied)
Note:
■ Consult your SHARP Dealer or Service Center for the type of splitter, RF switch or combiner that might be
required.
channel keys.
descrambler using the converter’s channel keys.
Two-set
signal
splitter
(not
IN
supplied)
Cable TV Line
9
PREPARATION (Continued)
Antenna Connections
Antennas
■ The antenna requirements for good color television reception are more important than those for black & white
television reception. For this reason, a good quality outdoor antenna is strongly recommended.
The following is a brief explanation of the type of connections that are provided with the various antenna
systems:
F-type connector
1. A 75 ohm system is generally a round cable with F-type
connector that can easily be attached to a terminal without
tools (not supplied).
2. A 300 ohm system is a flat “twin-lead” cable that can be
attached to a 75 ohm terminal through a 300-75 ohm
ADAPTOR (not supplied).
OUTDOOR ANTENNA CONNECTION
• Use one of the following two diagrams if you connect an outdoor antenna.
A: Using a VHF/UHF combination outdoor antenna.
B: Using separate VHF and/or UHF outdoor antenna.
• Connect an outdoor antenna cable lead-in to the COAXIAL CABLE CONNECTOR on the rear of the TV set.
75-ohm coaxial cable (round)
300-ohm twin-lead cable (flat)
A. Combination VHF/UHF Antennas
VHF/UHF ANTENNA
300-ohm
twin-lead
VHF/UHF ANTENNA
or
75-ohm
coaxial cable
300/75-ohm
ADAPTOR
(Not supplied)
B. Separate VHF/UHF Antenna
VHF
ANTENNA
or
UHF
ANTENNA
300-ohm
twin-lead
300-ohm
twin-lead
75-ohm coaxial
cable
COMBINER
(not supplied)
IN OUT
To antenna input
terminal
Supplied antenna cable
10
FRONT AND REAR CONTROL OPTIONS
Main unit (front view)
Remote sensor window
Power/standby indicator
A green indicator lights when the power is on and a red indicator
lights when in the standby mode (the indicator will not light when
the power is off).
(The actual location is not visible)
Top control panel
BRIGHT
DISPLAY
VOLUME UP (+)/
DOWN ( )
− ＋
BRIGHT
■ The (MUTE), DISPLAY, MENU, VOLUME UP(+)/DOWN(–), CHANNEL UP(▲)/DOWN(▼), and TV/VIDEO
buttons provide the same functions as the buttons on the remote control.
(The MENU button has a slightly different function from the remote control button.)
MUTE
DISPLAY
MUTE
MENU
VOL CH
MENU
TV/VIDEO
CHANNEL UP (])
DOWN ([)
TV/VIDEO
OFF ON
MAIN POWER
MAIN POWER
11
FRONT AND REAR CONTROL OPTIONS (Continued)
Main unit (rear view)
Adjust the set stand to an angle so that
the screen is easily visible. The set stand
can be opened up to 80¡.
Rear terminal section
AV input 1
terminal
S
V
AV-IN1
L
R
S-Video input
Video input
Audio R/L
Audio
Audio
ANT
AUDIO
HEADPHONE
V
V
POWER
INPUT
DC12V
AV-IN2
AV-OUT
AV input 2
terminal
AV output
terminal
Headphone output
terminal
DC input terminal
Antenna input terminal
12
REMOTE CONTROL/BASIC OPERATION
POWER
TV/VIDEO
CHANNEL SELECT
POWER
TV/VIDEO
VOL
−
1123
456
8
7
000
LCDTV
MENU
CH
CH
FLASHBACK
DISPLAY
9
MUTE
VOL
MENU
CH (])/([)
+
]Selects next higher channel
[Selects next lower channel
FLASHBACK
Returns to previous channel
DISPLAY
Press....Displays receiving channel for 10 seconds.
Channel indication reduces in size after
about 10 seconds.
Press again....After the CH call is displayed in large
size, COLOR SYSTEM except N358
and is displayed for 10 seconds, and
then CH will be displayed in small
size only.
↓
Small CH display
↓
No display
↓
The above three displays can
be switched.
MUTE
Press....Stops sound.
BASIC OPERATION
This product is factory set to comply with the TV broadcasting system in the United States. For Brazil,
Argentina and Uruguay, set the color system according to the country before using this product by
following the table below.
The VIDEO INPUT mode is compatible with color systems worldwide and is automatically set.
Country
U.S.A
Canada, Mexico, Color: NTSC NTSC (N358) World Multi
Latin America TV ch: US ch US ch Auto System
Brazil
Argentina, Color: PAL-N NTSC (N358) World Multi Set color system to
Uruguay TV ch: US ch US ch Auto System PAL-N (see page 21)
TV broadcasting
system
Color: NTSC NTSC (N358) World Multi Not required
TV ch: US ch US ch Auto System or N/A
Color: PAL-M NTSC (N358) World Multi Set color system to
TV ch: US ch US ch Auto System PAL-M (see page 21)
Factory setting of color system User setting
TV Video TV
Not required or N/A
* The World Multi Auto System
is compatible with all color
systems indicated below.
1
PAL-STANDARD
2
PAL-M
3
PAL-N
4
NTSC
5
SECAM
13
BASIC OPERATION (Continued)
Turning on POWER
Control section of main unit
1 Slide the MAIN POWER switch,
located on the upper side of the
MAIN POWERCHVOL TV/VIDEO
main unit to ON.
2 The Power indicator instantane-
ously changes from red to green
and the main unit is turned on.
Note:
Input mode indication disappears after
several seconds.
Notes:
Power/Standby indicator
Switching TV/VIDEO AV1/AV2/TV Mode
1 Turn on the power of the con-
nected video equipment.
2 Press the TV/VIDEO and select the
MENU
CH
applicable input source. The screen
displays AV1, AV2 or TV mode at
the upper right corner each time
TV/VIDEO is pressed.
CH
FLASHBACK
DISPLAY
8
9
MUTE
0
LCDTV
Notes:
■ AV input mode indication remains for
five seconds.
• AV1: Video equipment connected to the
AV1 input terminals.
S-video input terminals are
additionally provided for the AV1
input. If both S-video and normal
video terminals are connected
with cables, the S-video input
terminals take precedence.
POWER
TV/VIDEO
POWER
TV/VIDEO
1 23
456
7
▼ ON-screen display
AV1 mode
AV2 mode
14
TV mode
Sound Volume
BASIC OPERATION (Continued)
POWER
TV/VIDEO
123
456
7
8
0
LCDTV
CH
CH
9
MENU
FLASHBACK
DISPLAY
MUTE
1 Press the VOL (+) to increase sound
volume. The segment of indicator
increases.
2 Press the VOL (–) to decrease sound
volume. The segment of indicator
decreases.
MUTE
To mute sound
1 Press the MUTE to temporarily turn
off the sound.
Screen display MUTE MARK.
2 Press the MUTE or VOL (+)/(–) to
turn the sound back to the previous
level.
The following buttons can also be
used to cancel MUTE: CH, TV/
VIDEO, FLASHBACK, POWER ON/
OFF, BRIGHT.
ON/OFF Standby
POWER
TV/VIDEO
123
456
8
7
0
LCDTV
CH
CH
9
MENU
FLASHBACK
DISPLAY
MUTE
POWER
To turn off the LCD TV
Press the POWER on the remote
control.
The Power indicator will turn red.
To turn the LCD TV back on
Press the POWER again.
The Power indicator will turn green.
15
BASIC OPERATION (Continued)
Changing the Channels
Changing channels using the CHANNEL SELECT on the remote control
• To handle the increasing number of channels available, this LCD TV set allows you to select up to
125 positions (Channels 1 to 125). One-digit, two-digit and three-digit methods of selection can be
used. Follow the procedure shown below to select channels.
To select a one-digit channel (e.g.,
POWER
TV/VIDEO
123
456
8
7
0
CH
CH
9
MENU
FLASHBACK
DISPLAY
MUTE
CHANNEL
SELECT
Channel 5):
Basically, the 2-digit entry is used.
1 Press the button.
2 Press the
5
button.
LCDTV
Channel 115):
1 Press the button.
2 Press the button.
To select a three-digit channel (e.g.,
3 Press the
Note:
■ Complete this procedure within 3 seconds,
otherwise the selection will not be made.
Changing channels with the CH (])/([) on the remote control.
Press the CH (]) and the channels change in the order shown below:
1 → 2 → 3 → . . . → 125 →1 → 2 → 3 → . . .
Press the CH (
3 → 2 → 1 → . . . → 125 → . . . → 3 → 2 → 1 → . . .
Air CH (]) 2 → 3 → . . . → 68 → 69 → 2 → 3 → . . .
CH ([) 3 → 2 → 69 → 68 → . . . → 3 → 2 → . . .
STD CH (]) 2 → 3 → . . . → 124 → 125 → 2 → 3 → . . .
CH ([) 3 → 2 → . . . → 125 → 124 → . . . → 3 → 2 → . . .
HRC CH (]) 1 → 2 → 3 → . . . → 124 → 125 → 1 → 2 → . . .
CH ([) 1 → 125 → 124 → . . . → 3 → 2 → 1 → . . .
IRC CH (]) 1 → 2 → 3 → . . . → 124 → 125 → 1 → 2 → . . .
CH ([) 2 → 1 → 125 → 124 → . . . → 3 → 2 → 1 → . . .
[) button and the channels change in the order shown below:
5
button.
16
SELECTING THE MENU ITEMS
1
Selecting a Menu Item
• This LCD TV set allows you to adjust the picture and sound, and set the channels and other features
using the On Screen Display. Select the desired menu item by following the steps below and then refer
to the indicated page for details.
SLEEP TIMER
menu ----------------- Page 19
VIDEO ADJUST menu
(TV mode) -----Page 20, 21
POWER
TV/VIDEO
123
456
8
7
0
LCDTV
CH
CH
9
MENU
FLASHBACK
DISPLAY
MUTE
MENU
CH (])/
([)
1 Press the MENU to display the
MENU screen.
2 Press the CH (])/([) to select the
desired menu item.
•
The “>” mark moves up or down.
•
The “>” mark indicates the selected
menu item.
3 Press the VOL (+)/(–) to enter.
4 Press the MENU to exit.
Notes:
■ The TINT display only appears when
the color system sets N358 or N443
or AUTO in the NTSC mode.
■ The displayed items differ depending
on the setting conditions.
■ The selected item changes to yellow.
■ Items in purple cannot be selected.
■ TV mode
Note:
This product is factory set to comply
with the color system (NTSC-N358)
in the United States. For Brazil (PALM), Argentina (PAL-N) and Uruguay
(PAL-N), set the color system before
using this product.
■ COLOR SYSTEM
Set the system to AUTO for normal
reception. The AUTO mode automatically detects the receiving signal
system and changes the reception
system of the set.
When the picture or sound is not
stable, switching to an appropriate
system may improve the picture or
sound quality.
VIDEO ADJUST menu
(AV mode) ----- Page 20, 21
PRESET menu ---- Page 22
SETUP
menu ------ Page 23, 24, 25
* The screen indications shown above are larger than actual for easy reading.
17
EZ SETUP DURING FIRST POWER ON
■ When you turn on the LCD TV for the first time, it will automatically memorize the broadcasting
channels.
Please perform the following instructions before you press the power button.
(1) Insert the batteries into the remote control. (See page 8)
(2) Connect the antenna cable to the TV set. (See page 9 ~ 10)
(3) Plug in the AC adapter to the wall outlet.
Control section of main unit
MAIN POWERCHVOL TV/VIDEO
Power/Standby indicator
POWER
POWER
TV/VIDEO
123
456
7
MENU
CH
CH
FLASHBACK
DISPLAY
8
9
0
MENU
CH (])/
([)
MUTE
1 Slide the MAIN POWER button on
the LCD TV set or on the Remote
Control to turn on the LCD TV. The
SELECT LANGUAGE mode will be
displayed.
2 Press CH (])/([) to select
“ENGLISH”, “SPANISH
(ESPAÑOL)” or “FRENCH
(FRANÇAIS)”.
3 Press VOL (+)/(–) to display EZ
SETUP mode.
4 Press VOL (+).
The tuner will automatically search
for the broadcasting and cable TV
channels. (The CH No. will automatically increase when it appears.)
If you want to stop the EZ SETUP
process once it has started, press
VOL (–) and it will be canceled.
(SELECT LANGUAGE mode)
(EZ SETUP mode)
If you want to SETUP again,
LCDTV
please refer to page 22 on SETUP.
Press VOL (–) to cancel EZ
SETUP.
5 Once EZ SETUP is completed, the
smallest channel number memorized will be displayed.
Notes:
■ If EZ SETUP does not memorize all the channels in your region, please refer to page 23 for more information on
manual memorizing the channels using CHANNEL SETTING.
■ It may be difficult to PRESET when the broadcasting signals are weak, the channel cycle frequency is incorrect or
the frequency jamming is occuring around the area. Please refer to pages 23 ~ 24 for more information on manual
memorizing the channels using CHANNEL SETTING.
18
ADJUSTMENT
Adjusting the LANGUAGE Settings
The language for the ON SCREEN DISPLAY can be ENGLISH, SPANISH or FRENCH.
Setting the ON SCREEN DISPLAY Language.
1 Press the MENU to display the
MENU screen.
2 Press the CH (])/([)
POWER
TV/VIDEO
MENU
CH
MENU
“>” mark to “SETUP”.
3 Press VOL (+)/(–)
CH
123
456
8
9
7
0
FLASHBACK
DISPLAY
MUTE
CH (])/
([)
SETUP mode, then press CH (])/
to move the “>” mark to
([)
“LANGUAGE”.
4 Press VOL (+)/(–)
LANGUAGE change mode.
5 Press the CH (])/([) to select
“ENGLISH”, “SPANISH
(ESPAÑOL)” or “FRENCH
(FRANÇAIS)”.
6 Press MENU to exit.
Adjusting the SLEEP TIMER Settings
to move the
to display
to display
(MAIN MENU screen)
POWER
TV/VIDEO
123
456
8
7
0
LCDTV
CH
CH
9
MENU
FLASHBACK
DISPLAY
MUTE
MENU
CH (])/
([)
1 Press the MENU to disply the
MENU screen.
2 Press the CH (])/([) to move the
cursor to SLEEP TIMER.
3 Press the VOL (+)/(–) to display
SLEEP TIMER screen.
4 Press the VOL (+)/(–) to set the
sleep timer (in minutes).
The setting can be set in increment
of 30 minutes and in the range
between 30 and 120 minutes.
The setting is turned off when --- is
displayed.
5 Press the MENU to return to the
main screen.
(MAIN MENU screen)
(SLEEP TIMER screen)
19
ADJUSTMENT (Continued)
Adjusting the VIDEO ADJUST Settings
1 Press the MENU to display the
MENU screen.
POWER
TV/VIDEO
123
456
7
MENU
CH
CH
FLASHBACK
DISPLAY
8
9
0
LCDTV
MUTE
MENU
CH (])/
([)
2 Press the CH (])/([) to move the
cursor to VIDEO ADJUST.
3 Press the VOL (+)/(–) to display
the VIDEO ADJUST Menu screen.
(MAIN MENU screen)
4 Press the CH (])/([) to move the
cursor and select the desired
adjustment item.
All of adjustment item is shown in
the diagram on page 21.
5 Press the VOL (+)/(–) to display
the screen for the selected adjustment item.
6 Press the VOL (+)/(–) to make
adjustment.
7 Press the MENU to return to the
main screen.
(VIDEO ADJUST screen)
20
ADJUSTMENT (Continued)
Adjusting the VIDEO ADJUST Settings (Continued)
TV mode
Selected item Press the VOL (–). Press the VOL (+).
PICTURE Decrease contrast Increase contrast
TINT Toward purple Toward green
COLOR Lower color intensity Higher color intensity
BLACK LEVEL Less bright More bright
SHARPNESS Soft picture Sharp picture
COLOR SYSTEM
AV mode
Selected item Press the VOL (–). Press the VOL (+).
PICTURE Decrease contrast Increase contrast
TINT/WHITE BALANCE Toward purple Toward green
COLOR Lower color intensity Higher color intensity
BLACK LEVEL Less bright More bright
SHARPNESS Soft picture Hard picture
RED-BLUE More red level More blue level
GREEN Less green level More green level
COLOR SYSTEM Press the VOL (+)/(–) to select COLOR SYSTEM.
Note:
■ TINT is displayed only when N358 or N443 is selected.
■ COLOR SYSTEM is displayed only when in the AV mode.
■ In BLUE BACK, PICTURE setting displayed in purple cannot be selected.
■ Selecting RESET will return all settings to the factory settings.
■ TV mode
This product is factory set to comply with the color system (NTSC-N358) in the United States. For Brazil (PALM), Argentina (PAL-N) and Uruguay (PAL-N), set the color system before using this product.
■ COLOR SYSTEM
Set the system to AUTO for normal reception. The AUTO mode automatically detects the receiving signal
system and changes the reception system of the set.
When the picture or sound is not stable, switching to an appropriate system may improve the picture or sound
quality.
21
ADJUSTMENT (Continued)
Adjusting the PRESET Settings
■ The PRESET items can be set by the
user.
1 Press the MENU to display the
MENU screen.
POWER
TV/VIDEO
MENU
CH
MENU
2 Press the CH (])/([) to move the
cursor to PRESET.
3 Press the VOL (+)/(–) to display
PRESET screen.
4 Check the factory setting of each
item on the PRESET screen.
(MAIN MENU screen)
123
456
8
9
7
0
CH
FLASHBACK
DISPLAY
MUTE
CH (])/
([)
The user can change the settings
LCDTV
by using CH (])/([) and VOL (+)
/(–).
5 Press the MENU to return to the
main screen.
(PRESET screen)
Selected item Factory setting Setting change
Brightness [BRIGHT] Maximum brightness [NORMAL] Brightness 60% → Suitable for viewing in well-lit areas. Saves energy.
[DARK] Brightness 20%
Auto Power Off [OFF] [ON] The power of the LCD TV set is turned off when there is no signal for
(only TV mode) 5 minutes.
[OFF] This feature is inactivated.
→ Sufficiently bright when viewing in dim areas.
UPSIDE [NORMAL] Normal vertical [DOWN] Inverted image → To display images upside down for special
image orientation uses.
ABC
ABC
RIGHT/LEFT [NORMAL] Normal horizontal [MIRROR] Mirror image → To display mirror images for special uses.
* Brightness can be adjusted by using the BRIGHT button on the top control panel of the main unit.
22
image orientation
ABC
ABC
ADJUSTMENT (Continued)
SETUP
■ EZ SETUP
By operating the channel presetting functions, you can preset your LCD TV to the desired
channels for viewing.
1 Press MENU to display the MENU
screen.
2 Press CH (])/([) to move the “>”
POWER
TV/VIDEO
123
456
8
7
0
CH
CH
9
MENU
FLASHBACK
DISPLAY
MUTE
MENU
CH (])/
([)
mark to “SETUP”.
3 Press VOL (+)/(–)
to display
SETUP mode, then press CH (])/
([) to move the “>” mark to “CH
SETTING”.
4 Press VOL (+)/(–) to display CH
SETTING mode.
(MAIN MENU screen)
(SETUP mode)
5 Press VOL (+)/(–) to display EZ
SETUP mode.
6 Press VOL (+).
The tuner will automatically search
for the broadcasting and cable TV
channels. (The CH No. will automatically increase when it appears.)
If you want to stop the EZ SETUP
process once it has started, press
VOL (–). Search will be canceled.
Press VOL (–) to cancel EZ
SETUP.
7 Once EZ SETUP is completed, the
smallest channel number memorized will be displayed.
(CH SETTING mode)
(EZ SETUP mode)
23
ADJUSTMENT (Continued)
SETUP (Continued)
■ CHANNEL SETTING
If EZ SETUP does not memorize all the channels in your region, follow the instructions below
to manually memorize the channel.
1 Press MENU to display the MENU
screen.
2 Press CH (])/([) to move the “>”
mark to “SETUP”.
(MAIN MENU screen)
POWER
TV/VIDEO
123
456
8
7
0
CH
CH
9
MENU
FLASHBACK
DISPLAY
MUTE
MENU
CH (])/
([)
3 Press VOL (+)/(–) to display
SETUP mode.
4 Press CH (])/([) to move the “>”
mark to “CH SETTING”.
(SETUP mode)
5 Press VOL (+)/(–) to display CH
SETTING mode.
LCDTV
6 Press CH (])/([) to move the “>”
7 Press CH (])/([) to move the “>”
8 Press MENU to exit.
Note:
■ Receivable channels of your TV set are:
AIR channels: CABLE channels:
VHF: 2 through 13. 1 (HRC and IRC mode only)
UHF: 14 through 69. 2 through 125 (STD, HRC and IRC)
(CH SETTING mode)
mark to “AIR/CABLE”, then press
VOL (+)/(–) to display AIR/CABLE
mode.
mark to the desired mode.
(AIR/CABLE mode)
24
ADJUSTMENT (Continued)
SETUP (Continued)
■ Saving broadcast TV channels into memory.
1.1 Press MENU to display the MENU
screen, then press CH (])/([) to
move the “>” mark to CH SETTING.
1.2 Press VOL (+)/(–) to display
SETUP mode, then press CH (])/
([) to move the “>” mark to “CH
SETTING”.
1.3 Press VOL (+)/(–) to display CH
SETTING screen.
1.4 Press CH (])/([) to move the “>”
mark to “CH SEARCH”, then press
VOL (+)/(–) to display CH SEARCH
screen.
START
2.1 Press VOL (+). The tuner will
search through all available channels in your area and add them into
the TV’s memory.
STOP
2.2 Press VOL (–). CH SEARCH will
stop at the current channel and will
not add any higher channels.
2.3 Press MENU to exit.
(CH SETTING mode)
(CH SEARCH mode)
■ Adding weak or additional channels or erasing unwanted channels from TV
memory.
1.1 Press MENU to display the MENU
screen, then press CH (])/([) to
move the “>” mark to “SETUP”.
1.2 Press VOL (+)/(–) to display
SETUP mode, then press CH (])/
([) to move the “>” mark to “CH
SETTING”.
POWER
TV/VIDEO
MENU
CH
MENU
1.3 Press VOL (+)/(–) to display CH
SETTING mode, then press CH
(])/([) to move the “>” mark to
(CH SETTING mode)
“CH MEMORY”.
CH
123
456
8
9
7
0
FLASHBACK
DISPLAY
MUTE
CH (])/
([)
CHANNEL
SELECT
2.1 Press VOL (+)/(–) to display CH
MEMORY.
2.2 Use CH (])/([) or CHANNEL
SELECT to select each desired
channel to add or erase.
2.3 Press VOL (+) to add a channel to
VOL (+)
to add channel 12
to the TV memory
VOL (–)
to erase channel 12
to the TV memory
the TV’s memory or press VOL (–)
to erase a channel from the TV’s
memory.
2.4 Press MENU to exit.
Note:
■ If you press VOL (+) again while in the CH SEARCH mode, auto-program will start again, and the previously
memorized channels will be lost.
25
ADJUSTMENT (Continued)
Adjusting the BLUE SCREEN Settings
■ BLUE SCREEN
Automatically turns the screen blue if a broadcast signal is not received.
1 Press the MENU to display the
MENU screen.
2 Press CH (])/([) to move the “>”
POWER
TV/VIDEO
MENU
CH
MENU
mark to “SET UP”.
(MAIN MENU screen)
(SETUP mode)
123
456
8
9
7
0
CH
FLASHBACK
DISPLAY
MUTE
CH (])/
([)
3 Press VOL (+)/(–) to display
SETUP mode.
4 Press the VOL (+)/(–) to display
BLUE SCREEN select mode.
(SETUP mode)
5 Press the VOL (+)/(–) to select
“ON”.
6 Press the MENU
Notes:
■ Poor reception due to weak signals, or too much noise might activate the BLUE SCREEN function despite the
presence of a broadcast signal. To continue watching TV under these conditions, switch the BLUE SCREEN
“OFF”.
■ While AV input mode is selected, the BLUE SCREEN will not be shown on your TV even if the BLUE SCREEN is
turned on.
to exit.
26
LISTENING WITH A HEADPHONE
■ Plug the headphone mini-plug into the headphone jack located on the rear side of the set.
▼ Screen display
Mini-plug
Headphone
jack
Headphone
Notes:
■ The headphone is not included in the supplied accessories.
■ No sound will be heard from the main unit speakers when connecting the headphone set.
EXAMPLE OF APPLICATION
View by mounting the set to the wall using mounting bracket.
■ When using the unit on the wall, etc. (Installation example)
CAUTION:
The thickness and the
material of the wall
must use plywood or
solid wood of 0.5 in.
(12 mm) or more in
thickness.
Wall
LCD TV
Wall Mount
Bracket Screws
(4 pcs.)
Supplied AC adapter
Supplied AC cord
Notes: Location of installation
■ Do not install the unit in a place exposed to vapor.
■ Do not install the unit in a place exposed to oily soot.
■ Install the unit in locations having room temperatures within 0°C to 40°C.
■ This product is not designed to resist water. Make sure to install the unit in a place not exposed to water or oily soot.
27
CONNECTING WITH EXTERNAL DEVICES
It is possible to enjoy video and sound by connecting VCR's and home video game systems to the
terminals located on the rear of the main unit.
When connecting an external device, turn off the power of the main unit and connecting device to prevent
any possible damage.
Example of external devices that can be
connected.
• Video camera
• Home video game system
• VCR
• Laser disc player
To AV-IN 1 or 2
terminal
AUX 1
TUNER/BAND
AUX 2
AUX 3
DVD
SURROUND
ON/OFF
* PC connection not available.
Notes:
■ For the cable, use a commercially available video/audio cord.
■ Only connect video/audio signals to AV-IN 1 and 2 terminals. Connecting other signals may result in malfunc-
tion.
■ The video input terminal and the S-Video input terminal on the AV-IN side are shared connections with priority
given to the S-Video terminal. When making connections to both terminals, the screen when selecting AV-IN 1
will be that from the S-Video input terminal.
When viewing video from the video input terminal, do not make any connection to the S-Video input terminal.
■ For details concerning the usage and connection of the connecting devices, see the respective instruction
manuals.
28
CONNECTING WITH EXTERNAL DEVICES (Continued)
Connecting a VCR or home video game system (AV-IN 1/2)
S
V
AV-IN 1
L
R
Audio
AUDIO
AV-IN 2
V
AV-OUT
Connect the video and
audio cords correctly.
To S-Video
input terminal
S-Video cord
(commercially
available product)
To S-Video
output terminal
Video
Audio
(R)
To AV input 1
terminal
Video/audio cord
(commercially
available product)
To video/audio
output terminal
Audio
(L)
Audio
(R)
Audio
(L)
To AV input 2
terminal
VCR connection
cord (commercially
available product)
To video/audio
output terminal
Video
Notes:
■ When connecting both Video input and S-Video terminals for AV-IN 1, priority is given to the S-Video input.
■ Do not connect antennas or headphones to AV-IN 2.
29
CONNECTING WITH EXTERNAL DEVICES (Continued)
Outputting video and audio (video output)
It is possible to output video and audio from the set through the AV output terminal (AV-OUT).
S
V
AV-IN 1
L
R
AUDIO
AUDIO
AV-IN 2
V
AV-OUT
Outputs video and audio
Note:
■ When using S-Video input for AV-IN 1, no video output will be made to the AV output terminal, but audio output
will be made for connection to external audio systems.
30
TROUBLESHOOTING
■ Before calling for repair service, check the following items for possible remedies to
the encountered symptoms.
TV set
Sound
Problem Check item
• Make sure the AC adapter is properly inserted in the
There is no
picture or
sound.
There is no
picture.
There is no
picture from
AV-IN 1.
There is no
sound.
There is no
picture or
sound, just
noise.
power outlet.
• Reception other than those of broadcasting stations
can be considered.
• Make sure the input mode is set to TV.
• Make sure the main power switch of the main unit is
on.
• Make sure the BLACK LEVEL is properly adjusted.
• Fluorescent lamp may have reached the end of
service life.
• Make sure the S-Video terminal is free of connections.
• Make sure the volume is not set to minimum.
• Make sure the sound is not set to mute.
• Make sure the headphone is not connected.
• Make sure the antenna cable is properly connected.
• Bad reception can be considered.
Reference
Pages
18
14
14
20, 21
–
29
15
15
27
9
–
Picture is not
clear.
Picture is light
or improperly
tinted.
The picture is
too dark.
Remote control does not work.
• Make sure the antenna cable is properly connected.
• Bad reception can be considered.
• Check color adjustment.
• Check color system setting.
• Press the Brightness button.
• Check PICTURE and BLACK LEVEL adjustment.
• Fluorescent lamp may have reached the end of
service life.
• Check to see if batteries in the remote control have
sufficient power.
• Make sure the remote sensor window is not under
strong fluorescent lighting.
9
–
20, 21
20, 21
33
8
8
31
TROUBLESHOOTING (Continued)
Antenna
Problem Check item
• The reception may be weak.
• The state of the broadcast may also be bad.
The picture is
not sharp.
The picture
moves.
The picture is
doubled or
tripled.
The picture is
spotted.
• Make sure the antenna is facing the right direction.
• Make sure the outside antenna is not disconnected.
• Make sure the antenna is facing the right direction.
• There may be reflected electric waves from mountains or
buildings.
• There may be interference from automobiles, trains, high
voltage lines, neon lights, etc.
• There may be interference between the antenna cable and
power cable. Try positioning them further apart.
There are
stripes on the
screen or
colors fade.
• Is the unit receiving interference from other devices?
Transmission antennas of radio broadcasting stations and
transmission antennas of amateur radios and cellular phones
may also cause interference.
• Use the unit as far apart as possible from devices that may
cause possible interference.
32
SPECIFICATIONS
ITEMS
MODEL
LC-10A2U
LCD panel 10.4” TFT LCD
Number of pixels 921,600 pixels VGA
Video color systems N358, N443, PAL, PAL-M, PAL-N, SECAM, PAL-60
Destination USA/Latin A/Twn
TV Standard (CCIR) NTSC/PAL-M/PAL-N
TV TV Turning System PLL 181 ch.
FUNCTION STEREO AV STEREO
EZ SETUP Yes
CATV 125 ch.
4-LINE COMB FILTER Yes
Brightness 400 cd/m
2
Lamp life 25,000 Hours
Viewing angles H: 120° V: 100°
Audio amplifier 1.0 W × 2
Speakers 1-3/16 × 1-37/64 in. (3 × 4 cm), 2 pcs
Terminals AV1 AV-IN 1, S-IN
AV2 AV-IN 2
AV OUT AV-OUT
ANT F-Type
H/P Mini-jack for stereo (3.5 ø) (Rear)
OSD LANGUAGE English/French/Spanish
Power supply DC 12 V, AC110-240 V
Weight 3.97 lbs (1.8 kg) w/o accessories
Accessories R/C, Batteries, Wall mount parts, Antenna cable,
AC adapter, AC cord
■ Design and specifications are subject to change without notice.
DIMENSIONAL DRAWINGS
10-1/2 (267)
1/32 (1)
8-3/8 (213.2)
4-1/4 (107.8)
7/8 (22)
7-19/32 (193)
3-3/8 (81.2)
3-1/8 (79.2)
1/32 (1)
4-5/32 (105.5)
4-27/32 (123)
4-31/32 (126.5)
2-1/2 (63.5)
1-7/8 (47.5)
1-11/16 (43.5)
1-3/8 (35)
1-15/16 (49.5)
2-9/16 (65)
5/8 (15.5)
19/32
9/169/16
3-15/32 (88.5)
1/2 (12.5)
9/16
2-27/32 (72)
3-9/16 (90.1)
4-1/16 (103)
2-3/8 (60)
6-31/32 (177)
9-5/8 (243.8)
1-3/16
33
Calling for Service
For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories, supplies, or customer
assistance, please call 1-800-BE-SHARP.
LIMITED WARRANTY
END-USER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first end user purchaser that this Sharp brand product (the
“Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it
will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured
equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below
nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or
other misuse, abnormal service or handling, or which has been altered or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide
proof of purchase to the servicer.
To the extent permitted by applicable state law, the warranties set forth herein are in lieu of, and exclusive of, all other
warranties, express or implied. Specifically, ALL OTHER WARRANTIES OTHER THAN THOSE SET FORTH ABOVE ARE
EXCLUDED. ALL EXPRESS AND IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY,
FITNESS FOR USE, AND FITNESS FOR A PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED. If, under
applicable state law, implied warranties may not validly be disclaimed or excluded, the duration of such implied warranties
is limited to the period(s) from the date of purchase set forth below.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those
described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and
exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described
herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were
caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable
or in any way responsible for any incidental or consequential economic or property damage. Some states do not allow
limits on warranties or on remedies for breach in certain transactions; in such states, the limits herein may not apply.
Model Specific Section
Your Product Model Number & Description: LC-10A2U-B/LC-10A2U-W LCD Color Television
Warranty Period for this Product: One (1) year parts and labor from the date of purchase.
Additional Item(s) Excluded from
Warranty Coverage (if any): None
Where to Obtain Service: From a Sharp Authorized Servicer located in the United States.
What to do to Obtain Service: Ship prepaid or carry in your Product to a Sharp Authorized Servicer.
TO OBTAIN PRODUCT INFORMATION, CALL 1-888-LCD-SHARP.
(Be sure to have this information available when you need service for
your Product.)
To find the location of the nearest Sharp Authorized Servicer, call
Sharp toll free at 1-800-BE-SHARP.
Be sure to have Proof of Purchase available. If you ship the Product,
be sure it is insured and packaged securely.
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07430-2135
34
ESPAÑOL
LC-10A2U
PORTUGUÊS
LCD TELEVISION EN COLOR
TELEVISOR COLORIDO LCD
MANUAL DE MANEJO
MANUAL DE OPERAÇAO
0C. T2444-A
TINS-7236CEZZ
IMPRESO EN JAPÓN
IMPRESSO NO JAPÃO
Printed on post-consumer recycled paper.
Imprimé sur du papier recyclé.
Impreso en papel reciclado.
Impresso em papel reciclado pós utilização.
LC-10A2U
IMPRIMÉ AU JAPON
PRINTED IN JAPAN
TINS-7236CEZZ
0C. T2444-A
OPERATION MANUAL
MODE D’EMPLOI
LIQUIDES (LCD)
TÉLÉVISION COULEUR À
ÉCRAN À CRISTAUX
LCD COLOR TELEVISION
LC-10A2U
FRANÇAIS
ENGLISH
Loading...
