Sharp KC-830U User Manual
KC-830U
AIR PURIFIER
with Humidifying Function
Device of this mark is a trademark of Sharp Corporation.
“Plasmacluster” and “Device of a cluster of grapes” are
registered trademarks of Sharp Corpration in Japan,
USA and elsewhere.
Free standing type
Type mobile
Tipo vertical sin soporte
OPERATION MANUAL
Purifi cateur d’air à fonction
d’humidifi cation
MANUEL D’UTILISATION
PURIFICADOR DE AIRE
Con función de humidifi cación
MANUAL DE OPERACIÓN
ENGLISH
FRANÇAIS
ESPAÑOL
This product earned the ENERGY STAR by meeting strict energy effi ciency guidelines set by the US
EPA. US EPA does not endorse any manufacturer
claims of healthier indoor air from the use of this
product.
The energy effi ciency of this ENERGY STAR quali-
fi ed model is measured based on a ratio between
the model’s CADR for Dust and the electrical energy it consumes, or CADR/Watt.
Ce produit a le droit de porter la marque ENERGY
STAR après avoir répondu à des critères stricts en
ce qui concerne l’efficacité énergétique, tels qu’
établis par l’agence EPA aux É-U. L’agence EPA
aux É-U n’appuie aucunement les témoignages
publicitaires du fabricant indiquant que ce produit
rend l’air intérieur des locaux plus sain.
L’effi cacité énergétique de ce modèle, qui bénéfi cie
de la reconnaissance ENERGY STAR, est mesurée
par le rapport entre le DAP (débit d’air purifi é) du
modèle et l’énergie électrique qu’il consomme, soit
le rapport DAP/Watt.
Please read before operating your new Air Purifi er
Some odors ingredients absorbed by the fi lter may become separated and
may be discharged through the air outlet and result in additional odor. Depending on the usage environment, especially when the product is used in
a condition signifi cantly more severe than household use, this odor may be-
come strong in a shorter period than expected.
In this case we recommend purchasing the optional replacement fi lter kit
FZ-P30SFU.
NOTE
• The air purifi er is designed to remove air-suspended dust and odor, but not harmful gases (for
example, carbon monoxide contained in cigarette smoke). If the odor sources still exist, it cannot
completely remove the odor (for example, odors from construction materials and pet odors).
• It is suggested to open the window a bit when you are smoking in order to facilitate ventilation.
True HEPA fi lter (white)
Deodorizing fi lter (black)
Dust
pollen, dust, particles of cigarette
smoke, pet dander
Odor
cigarette smoke odor,household odor
ENGLISH
FEATURES
Unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster
+ Humidifi cation
TRAPS DUST*
Washable pre-filter traps dust and other
large airborne particles.
DECREASES ODORS
Deodorizing filter absorbs many common
household odors.
REDUCES POLLEN & MOLD*
True HEPA fi lter traps 99.97% of particles
as small as 0.3 microns.
FRESHENS
Plasmacluster refreshes the air similar to
the way nature cleans the environment by
emitting a balance of positive and negative
ions.
HUMIDIFIES
Runs up to 10 hours per fi lling.**
*When air is drawn through the filter sys-
tem.
**Room size : up to 124 sq. ft.
Sensor Technology continuously monitors
air quality, automatically adjusting operation based on detected air purity and humidity.
Declaration of Conformity
SHARP AIR PURIFIER KC-830U
This device complies with Part 18 of FCC rules.
Responsible Party:
SHARP ELECTRONICS CORPORATION
Sharp Plaza,
Mahwah, New Jersey 07495-1163
CONTENTS
FOR CUSTOMER ASSISTANCE(U.S)
CONSUMER LIMITED WARRANTY(U.S)
FOR CUSTOMER ASSISTANCE(CANADA)
LIMITED WARRANTY(CANADA)
IMPORTANT SAFETY INSTRUCTIONS
• WARNING ..................................................
• CAUTIONS CONCERNING OPERATION .
• INSTALLATION GUIDELINES ....................
• FILTER GUIDELINES ................................
PART NAMES
• MAIN UNIT DISPLAY .................................
• ILLUSTRATIVE DIAGRAM .........................
• INCLUDED .................................................
• BACK ..........................................................
PREPARATION ...........................................
• FILTER INSTALLATION ...........................
• REFILLING WATER TANK .......................
OPERATION
• MAIN UNIT OPERATION .........................
CARE AND MAINTENANCE
• FILTER INDICATOR LIGHT .....................
• BACK PANEL AND SENSORS ................
• WATER TANK ..........................................
• UNIT .........................................................
• HUMIDIFYING TRAY ...............................
• HUMIDIFYING FILTER .............................
•
FILTER REPLACEMENT GUIDELINES
TROUBLESHOOTING
SPECIFICATIONS
.............................................
.............................................
.................
............................
....................................
......
.....
....
...........
...
.....
E-2
E-3
E-4
E-5
E-6
E-6
E-7
E-7
E-7
E-8
E-8
E-8
E-9
E-9
E-10
E-10
E-11
E-12
E-12
E-13
E-13
E-13
E-14
E-14
E-15
E-16
E-17
E-18
E-19
ENGLISH
Declaration of Conformity
SHARP AIR PURIFIER KC-830U
This ISM device complies with Canadian
ICES-001
Responsible Party:
SHARP ELECTRONICS OF CANADA LTD.
335 Britannia Road East Mississauga, Ontario
L4Z 1W9 Canada
TEL: (905) 568-7140
Thank you for purchasing the SHARP Air Purifi er. Please read this manual carefully for the
correct usage information. Before using this
product, be sure to read the section: “Important Safety Instructions.”
After reading this manual, retain it in a convenient location for future reference.
E-1
FOR CUSTOMER ASSISTANCE
To aid in answering questions if you call for service or for reporting loss or theft, please use
the space below to record the model and serial number located on the back of the unit.
MODEL NUMBER
SERIAL NUMBER
DATE OF PURCHASE
Dealer Name
Address
City
State
Zip
Telephone
(the United States)
TO PHONE: Dial 1-800-BE-SHARP (237-4277) for:
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your Authorized Parts Distributor)
ACCESSORIES
ADDITIONAL CUSTOMER INFORMATION
TO WRITE: For service problems, warranty information, missing items and other assistance:
Sharp Electronics Corporation
Customer Assistance Center
1300 Naperville Drive
Romeoville, IL 60446-1091
TO ACCESS OUR WEB SITE: www.sharpusa.com
Please provide the following information when you write or call: model number, serial
number, date of purchase, your complete mailing address (including zip code), your daytime
telephone number (including area code) and description of the problem.
E-2
CONSUMER LIMITED WARRANTY
CONSUMER LIMITED WARRANTY FOR U.S. USERS
SHARP ELECTRONICS CORPORATION warrants to the fi rst consumer purchaser that this Sharp brand product (the
“Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees
that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth
below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper
voltage or other misuse, abnormal service or handling, or which has been altered or modifi ed in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by
law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE
ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not
allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and
exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described
herein, shall constitute complete fulfi llment of all liabilities and responsibilities of Sharp to the purchaser with respect
to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict
liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the
Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor
shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. Some
states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFlC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE.
Your Product Model Number & Description:
Warranty Period for this Product:
Additional Item(s) Excluded From Warranty
Coverage:
Where to Obtain Service:
KC-830U Air Purifi er. Be sure to have this information available when
you need service for your Product.
One (1) year parts and labor from date of purchase.
Appearance items of the Product, fi lters, accessories, or any printed
materials. Product which has been used for rental and/or commercial
purposes.
From a Sharp Authorized Servicer located in the United States. To
fi nd the location of the nearest Sharp Authorized Servicer, call Sharp
Toll Free at 1-800-BE-SHARP.
ENGLISH
What to Do to Obtain Service:
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP, OR VISIT OUR WEBSITE AT
www.sharpusa.com
Ship prepaid or carry in your Product to a Sharp Authorized Servicer.
Be sure to have Proof of Purchase available. If you ship the Product,
be sure it is insured and packaged securely.
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
E-3
FOR CUSTOMER ASSISTANCE
To aid in answering questions if you call for service or for reporting loss or theft, please use
the space below to record the model and serial number located on the back side of the unit.
MODEL NUMBER
SERIAL NUMBER
DATE OF PURCHASE
Dealer Name
Address
City
Province
Postal Code
Telephone
(Canada)
TO PHONE: Dial 1-905-568-7140 for:
SERVICE (for your nearest Sharp Authorized Servicer)
PARTS (for your Authorized Parts Distributor)
ACCESSORIES
ADDITIONAL CUSTOMER INFORMATION
TO WRITE: For service problems, warranty information, missing items and
other assistance:
Sharp Electronics of Canada Ltd.
Customer Care
335 Britannia Road East
Mississauga, Ontario L4Z 1W9
TO ACCESS OUR WEB SITE: www.sharp.ca
Please provide the following information when you write or call: model number, serial number,
date of purchase, your complete mailing address (including Postal Code), your daytime telephone number (including area code) and description of the problem.
E-4
LIMITED WARRANTY
Consumer Electronics Products
Congratulations on your purchase!
Sharp Electronics of Canada Ltd. (hereinafter called “Sharp”) gives the following express warranty to the first consumer purchaser for this
Sharp brand product, when shipped in its original container and sold or distributed in Canada by Sharp or by an Authorized Sharp Dealer:
Sharp warrants that this product is free, under normal use and maintenance, from any defects in material and workmanship. If any such
defects should be found in this product within the applicable warranty period, Sharp shall, at its option, repair or replace the product as
specified herein.
This warranty shall not apply to:
(a) Any defects caused or repairs required as a result of abusive operation, negligence, accident, improper installation or inappropriate
use as outlined in the owner’s manual.
(b) Any Sharp product tampered with, modified, adjusted or repaired by any party other than Sharp, Sharp’s Authorized Service Centres
or Sharp’s Authorized Servicing Dealers.
(c) Damage caused or repairs required as a result of the use with items not specified or approved by Sharp, including but not limited to
head cleaning tapes and chemical cleaning agents.
(d) Any replacement of accessories, glassware, consumable or peripheral items required through normal use of the product including but
not limited to earphones, remote controls, AC adapters, batteries, temperature probe, stylus, trays, filters, belts, ribbons, cables and
paper.
(e) Any cosmetic damage to the surface or exterior that has been defaced or caused by normal wear and tear.
(f) Any damage caused by external or environmental conditions, including but not limited to transmission line/power line voltage or liquid
spillage.
(g) Any product received without appropriate model, serial number and CSA/cUL markings.
(h) Any products used for rental or commercial purposes.
(i) Any installation, setup and/or programming charges.
Should this Sharp product fail to operate during the warranty period, warranty service may be obtained upon delivery of the Sharp product
together with proof of purchase and a copy of this LIMITED WARRANTY statement to an Authorized Sharp Service Centre or an
A
uthorized Sharp Servicing Dealer. In home warranty service may be provided at Sharp’s discretion on any Sharp television with the
screen size of 27” or larger and on any Sharp Over-the-Range Microwave Oven.
This warranty constitutes the entire express warranty granted by Sharp and no other dealer, service centre or their agent or employee is
authorized to extend, enlarge or transfer this warranty on behalf of Sharp. To the extent the law permits, Sharp disclaims any and all
liability for direct or indirect damages or losses or for any incidental, special or consequential damages or loss of profits resulting from a
defect in material or workmanship relating to the product, including damages for the loss of time or use of this Sharp product or the loss o
f
information. The purchaser will be responsible for any removal, reinstallation, transportation and insurance costs incurred. Correction o
f
defects, in the manner and period of time described herein, constitute complete fulfillment of all obligations and responsibilities of Sharp to
the purchaser with respect to the product and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict
liability or otherwise.
WARRANTY PERIODS: Parts & Labour (exceptions noted)
Audio Product 1 year
redrocmaC 1 year
DVD Product 1 year
Projector 1 year (lamp 90 days)
LCD TV 1 year
Microwave Oven 1 year (magnetron component-4 additional years)
Air Purifier 1 year
Portable Air Conditioner 1 year
Plasmacluster Ion Generator 1 year
To obtain the name and address of the nearest Authorized Sharp Service Centre or Dealer, please contact:
SHARP ELECTRONICS OF CANADA LTD. 335 Britannia Road East Mississauga, Ontario L4Z 1W9
For more information on this Warranty, Sharp Extended Warranty
Offers, Sharp Canada Products, Accessory Sales, Dealer or Service
Locations, please call (905) 568-7140
Visit our Web site: www.sharp.ca
T
O
B
E
T
H
E
B
E
S
T
T
H
R
O
U
G
H
C
U
S
T
O
M
E
R
S
A
T
I
S
F
A
C
T
I
O
N
SERVICE
ENGLISH
E-5
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING
• Read all instructions before using the unit.
• Use only a 120 volt outlet.
• The air purifi er has a polarized plug (one blade is wider than the other). This plug will fi t in a polar-
ized outlet only one way. If the plug does not fi t into the outlet, reverse it. If it still does not fi t, con-
tact a qualifi ed electrician or service person.
• Do not use the unit if the power cord or plug is damaged or the connection to the wall outlet
is loosened.
• Periodically remove dust from the power plug.
• Do not insert fi ngers or foreign objects into the intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
Electrical shock and/or fi re from short circuit may occur as a result.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or fi replaces.
• Remove the power plug from the wall outlet before cleaning the unit and when not using the
unit.
Electrical shock from bad insulation and/or fi re from short circuit may occur as a result.
• When refi lling the Water Tank, cleaning the unit, or when the unit is not in use, be sure to
unplug the unit. Electrical shock and/or fi re from a short circuit may result.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent,
Sharp Authorised Service Centre or similarly qualifi ed person in order to avoid a hazard.
• Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,
sparks from lit cigarettes, chemical fumes in the air or in very high humidity conditions, such as a
bathroom.
• Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior.
• Only Sharp Authorised Service Centre should service this air purifi er. Contact the nearest Service
Centre for any problems, adjustments, or repairs.
• When carrying the unit, remove the Water Tank and Humidifying Tray fi rst and hold the unit by han-
dles on both sides.
• Do not drink the water in the Humidifying Tray or Water Tank.
• Change the water in the Water Tank daily with fresh tap water and regularly clean the Water Tank
and Humidifying Tray. (See E-14 and E-15). When unit is not in use, dispose of the water in the
Water Tank and Humidifying Tray. Leaving water in the Water Tank and/or Humidifying Tray may
result in mold, bacteria and bad odors.
In rare cases, this bacteria may cause harmful physical effects.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not play with the appliance.
- To reduce the risk of electrical shock, fi re or injury to persons:
NOTE
If this air purifi er should cause interference to radio or television reception, try to correct the interfer-
ence by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the unit and radio/TV receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This product fulfi ls the requirement of the International standard CISPR 11.
In conformity with this standard, this product is classifi ed as group 2 class B equipment.
Group 2 means that the equipment intentionally generates radio-frequency in the form of
electromagnetic radiation for electro-discharge machining equipment.
Class B equipment means that the equipment suitable to be used in domestic establishments.
- Radio or TV Interference
E-6
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may come into
contact with steam.
• Always operate the unit in an upright position.
• Always hold the handles on both sides of the unit when moving it.
Holding the back panel when carrying may cause it to detach, thus dropping the unit and resulting
in bodily injury.
• Do not operate the unit without the fi lters, Water Tank, and Humidifying Tray properly in-
stalled.
• Do not wash and reuse the fi lters.
Not only does it not improve fi lter performance, it may cause electrical shock or malfunction.
• Clean the exterior with a soft cloth only.
Do not use volatile fl uids and/or detergents.
The unit surface may be damaged or cracked.
In addition, the sensors may malfunction as a result.
• Frequency of maintenance required (descaling) will depend on the hardness or the impurities of the water that you use; the harder the water the more often descaling will be necessary.
• Keep the unit away from water.
ENGLISH
INSTALLATION GUIDELINES
• During the operation of the product, please place the unit at least 6.5ft. (2m) away from
equipment utilizing electrical waves such as televisions, radios or wave clocks.
• Avoid use in locations where furniture, fabrics or other items may come in contact with and
restrict the air intake and/or air outlet.
• Avoid use in locations where the unit is exposed to condensation or rapid temperature
changes. (Use under appropriate conditions between 41 - 95˚F (5 - 35˚C) in the room.)
(If it is unavoidable please allow unit to stand for 1 hour before switching on.)
• Place on a stable surface with suffi cient air circulation.
When placing the unit on a heavily carpeted area, it may cause the unit to vibrate slightly.
• Avoid use in locations where grease or oily smoke is generated (such as in a kitchen, etc.).
The unit surface may crack or the sensor may malfunction as a result.
• Place the unit about 1-2 ft. (30 - 60cm) away from the wall in order to ensure proper airfl ow.
The wall directly behind the air outlet may become dirty over time. When using the unit for an ex-
tended period of time in the same location, periodically clean the wall and protect the wall with a
vinyl sheet, etc. to prevent the wall from becoming dirty.
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the fi lters.
Use only fi lters designed for this product.
E-7
PART NAMES
MAIN UNIT DISPLAY
Plasmacluster Ion ON/OFF Button
POWER ON/OFF Button
Fan Speed Button
Humidify Mode
Indicator Light
Filter Reset Button
Filter Indicator Light
ILLUSTRATIVE DIAGRAM
Sensor
Fan Speed
Indicator Lights
CLEAN SIGN
The sensor continuously monitors the
air and changes color depending on air
purity.
Plasmacluster
Ion ON/OFF
Indicator Light
Green Orange Red
Clean Very Impure
Main Unit Display
Handle
E-8
Main Unit
INCLUDED
• Operation manual
BACK
Air Outlet
Handle
Tank Handle
Water Tank
For humidifying
(
Humidifying fi lter
Tank Cap
Humidifying Tray
Float
Power Cord
Plug
)
True HEPA
ENGLISH
fi lter (white)
Deodorizing
fi lter (black)
Tab
Back Panel
(Pre-fi lter)
Air outlet
Air Inlet
Date Label
E-9
PREPARATION
Be sure to remove the power plug from the wall outlet.
FILTER INSTALLATION
To maintain the quality of the fi lters they are installed in the main unit and packed
in plastic bags. Be sure to remove the fi lters from the plastic bags before using
the unit.
Remove the fi lters
1
Remove the Back Panel.
1
Pull the tab at the top of the Back Panel.
Remove the Deodorizing fi lter
2
and True HEPA fi lter from the
plastic bags.
Ta b
2
Install the fi lters
Place the True HEPA fi lter (white) and Deodorizing fi lter
1
(black) within the main unit.
Do not install the True HEPA fi lter backwards
or the unit will not operate properly.
Replace the Back Panel to the main unit.
2
Fill in the usage start date and
3
place on the unit as guide for when
the fi lters should be replaced.
True HEPA fi lter (white)
Deodorizing fi lter (black)
Date Label
E-10
REFILLING THE WATER TANK
The unit can be used in the Clean Air Mode without
putting water in the Water Tank. When using in the Humidify Mode, the Water Tank should be fi lled with water.
Remove the Water Tank by unlatching the
1
top.
Remove the Tank Cap and carefully fi ll the
2
Water Tank with tap water.
Change the water in the Water Tank every day with
fresh tap water.
ENGLISH
Tank Cap
After fi lling, securely tighten the Tank Cap.
3
• Check to see that there is no water leaking.
• Be sure to wipe off any excess water on the outside of
the Water Tank.
• When carrying the Water Tank, hold it with both hands
so that the Water Tank opening is facing up.
Replace the Water Tank in the unit.
4
The top latch will “click” in place when the Water Tank is
properly installed.
CAUTION
• Do not expose the unit to water. Short circuit and/or electrical shock may occur as a result.
• Do not use hot water 104 ºF (40 ºC), chemical agents, aromatic substances, dirty water, or
other damaging substances, deformation and/or malfunction may occur.
• Use only fresh tap water. Use of other water sources may promote the growth of mold, fungus and/or bacteria.
E-11
OPERATION
MAIN UNIT OPERATION
Fan Speed Button
Plasmacluster Ion
ON/OFF Button
Fan Speed Indicator Lights
Plasmacluster Ion Indicator Light
POWER ON/OFF
Button
To select Clean Air mode, be sure the water tank and humidifying tray are empty.
To select Clean Air plus Humidify mode, fi ll the water tank and install on the unit.
Power ON/OFF Button
• Press to start operation (short beep) and stop operation
(long beep)
• Plasmacluster Indicator Light and Fan Speed Indicator
Light turn on/off.
• Unless the power cord has been unplugged, the operations starts in the previous mode it was operated in.
Fan Speed Button
• Press the Fan Speed Button to select the desired fan
speed. Indicator Lights will show the fan speed currently selected.
• The operation mode can be switched as below.
The fan speed is automatically switched
(between HIGH and LOW) depending on the
amount of impurities in the air. The sensor
detects impurities for effi cient air purfi cation.
The unit will operate quietly using
minimal air in
take.
The unit will operate at a fan speed
of MAX.
Plasmacluster Ion ON/OFF Button
Press the Plasmacluster Ion ON/OFF Button to turn
Plasmacluster Ion Mode ON and OFF.
When Plasmacluster Ion is ON, the Plasmacluster Ion
Indicator Light will turn on.(blue)
The unit will operate at a fan speed
of MEDIUM.
E-12
CARE AND MAINTENANCE
To maintain optimum performance of this air purifi er, please clean the unit including
the sensor and fi lters periodically.
When cleaning the unit, be sure to fi rst unplug the power cord, and never handle the
plug with wet hands. Electrical shock and/or bodily injury may occur as a result.
FILTER INDICATOR LIGHT
Care Cycle
The Filter Indicator Light will illuminate as a reminder to perform maintenance of the
Back Panel/Pre-fi lter, Sensor, and Humidifying Filter. The Indicator Light will turn on
after approximately 720 hours of use.
After 720 hours of use
30days × 24hours = 720)
(
After performing maintenance, reset the Filter
Indicator.
Plug the unit in, turn power ON.
1
Press the RESET button for 3 seconds.
2
• The Filter Indicator Light will go off.
• Even if the Filter Indicator Light is already off, the RESET
button should be pressed to reset the maintenance timer.
BACK PANEL and SENSOR
Care Cycle
Gently remove dust from the sensor opening and the back panel, using a vacuum
cleaner attachment or similar tool.
Whenever dust accumulates
on the unit or every 2 months
ENGLISH
<When the back panel has stubborn dirt>
In case of heavy dirt, soak the back panel in water with a small amount of kitchen
detergent.
1
(Approx. 10min.)
(Avoid scrubbing the back panel when washing.)
Rinse the back panel repeatedly with clean water to remove
the solution residue.
2
Drip dry the panel to remove excess water.
3
E-13
Back Panel
CARE AND MAINTENANCE
WATER TANK
Care Cycle
Rinse the inside of the tank by leaving a small amount of lukewarm water inside, closing the tank cap firmly, and shaking
the tank. Mild household detergents may be used to clean the
inside of the tank, but detergent should be diluted and the tank
should be thoroughly rinsed to remove all detergent residue.
(Note the Water Tank is not dishwasher safe.)
Every day when Humidifying
Tank Cap
Water Tank
UNIT
Care Cycle
To prevent dirt or stains on the unit, clean regularly. If stains are allowed to remain, they may
become diffi cult to remove.
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
Do not use volatile fl uids
Benzene, paint thinner, polishing powder, may damage the surface.
Do not use detergents
Detergent ingredients may damage the unit.
Whenever dust accumulates on the unit or every 2 months
E-14
HUMIDIFYING TRAY
Care Cycle
Remove the Water Tank and Humidifying
1
Tray.
Unlatch the Water
Tank first, then remove the tray. Use
both hands when
pulling out the Humidifying Tray to
avoid spilling water.
Remove the Humidifying filter from the
Humidifying Tray. Drain accumulated wa-
2
ter by tilting the Humidifying Tray slowly.
Humidifying fi lter
1 month
Frequency of maintenance cycle will depend on the hardness
of the water. Avoid spilling water when removing or cleaning
the tray.
Humidifying Tray
When Water Deposits are Diffi cult to Remove
Fill Humidifying Tray halfway with lukewarm water,
1
add a small amount of mild
kitchen detergent, and leave
to soak for about 30 minutes.
Dilute detergent according to
instructions on the container.
Clean diffi cult-to-reach parts
with a cotton swab or tooth
brush.
Rinse the Humidifying
2
Tray with lukewarm water.
• Rinse until all detergent residue
is removed.
• Inadequate rinsing may cause
the detergent odor or changes in
the shape/color of the main unit.
ENGLISH
Rinse the inside of the Humidifying
3
Tray with lukewarm water to remove
impurities.
• Do not remove the Styrofoam fl oat.
• Clean diffi cult-to-reach parts with a cotton-
tipped swab or tooth brush.
If the Styrofoam fl oat comes off,
replace by inserting the tabs of
the Float into the holes in the
Humidifying Tray as shown in the
diagram.
Insert the tab of the
fl oat into the hole.
E-15
CAUTION
• Use only mild kitchen detergents to
clean the Humidifying Tray. Use of
non-designated chemicals or detergents can cause deformation, tarnishing, cracking (water leakage).
Insert the fl oat below
this tab.
Insert the tab on
the other side of the
fl oat into the hole.
Loading...
