Network-Capable Multifunctional Performer
in a Compact Design
OPTION
Fax
OPTION
Network Colour Scan
OPTION
Network Print
AR-M201
Digital Multifunctional System
Colour Scan
Print
Copy
Sharpdesk
20
CPM
First copy time
1st.
8.0
sec.
.....
1515151
5
1
5
Document is
scanned...
Multi-page
original
stored in
memory...
Copies
electronically sorted...
and stacked offset
during output.
Electronic Sorting and
Offset Stacking
550
Duplex Copying
Train No. Classification Destination Departure Track
Euro Comet 08 Limited Express Brehmen 09:30 3
Euro Comet L238 Local Train Brehmen 10:15 4
Euro Comet E512 Express Hamburg 10:40 4
Euro Comet 09 Limited Express Potsdam 11:30 1
Euro Night EN131 Express Rendsburg 11:15 2
Euro Night EN47 Limited Express Itzehoe 11:25 3
Euro Star EN187 Express Eckernforde 11:30 1
Euro Line C156 Local Train Rendsburg 11:40 5
Euro ES14 Limited Express Flensburg 11:45 3
Euro EVE3 Express Glucksburg 11:55 2
Euro City CNL Local Train Eckernforde 12:00 1
Euro TGV3 Limited Express Glucksburg 12:07 3
Euro Night EN900 Express Itzehoe 12:15 4
Euro Star EN747 Limited Express Potsdam 12:17 1
Euro Line E787 Local Train Glucksburg 12:25 3
Euro ES06 Limited Express Eckernforde 12:35 5
Euro EVE5 Express Kiel 12:45 7
Euro City CNL Local Train Rendsburg 12:55 6
Euro TGV7 Limited Express Itzehoe 13:07 1
Euro Night EN700 Express Flensburg 13:15 2
Euro Star EN963 Limited Express Husum 13:25 3
Euro Line E145 Local Train Itzehoe 13:35 2
Euro ES14 Limited Express Heide 13:45 4
Euro EVE3 Express Eckernforde 13:57 6
Euro City CNL Local Train Kiel 14:03 2
Euro TGV3 Limited Express Rendsburg 14:07 3
Euro Night EN900 Express Schleswig 14:15 1
Euro Star EN747 Limited Express Heide 14:17 5
Euro Line E145 Local Train Husum 14:25 4
Euro ES14 Limited Express Eckernforde 14:37 3
EURO EXPRESS RAILWAYS
LUNA GULF
MILAN
PARK
PINO LAKE
Harbour Bridg
e
Harb
our St.
M
ilan P
ark
Chinatown
Luna Cinema
Com
et Hote
l
GX Theatre
Hig
h
Court
M
idtown 5
M
idtown 3
M
St. 1
M
St. 3
M St. 5
M St. 8
M St.
10
HARBOUR LINE
H
CENT
RAL LINE
C
LAKE LINE
L
Horton Bldg.
Telephone Office
Central Sq
uare
City Hall
Church Sq
uare
Airport St.
City
Library
Green M
all
Herman Theatre
Star Museum
North Police Station
Hor
ton University
N
ROUTE M
AP
LUNA GULF
MILAN
PARK
PINO LAKE
Harbour Bridge
Harbour St.
Milan Park
Chinatown
Luna Cinema
Comet Hotel
GX Theatre
High Court
Midtown 5
Midtown 3
M St. 1
M St. 3
M St. 5
M St. 8
M St. 10
HARBOUR LINE
H
CENTRAL LINE
C
LAKE LINE
L
Horton Bldg.
Telephone Office
Central Square
City Hall
Church Square
Airport St.
City Library
Green Mall
Herman Theatre
Star Museum
North Police Station
Horton University
N
ROUTE MAP
Euro Night EN700 Express
Euro Star EN963 Limited Express
Euro Line E145 Local Train
Euro ES14 Limited Express
Euro EVE3 Express
Euro City CNL Local Train
Euro TGV3 Limited Express
Euro Night EN900 Express
Euro Star EN747 Limited Express
Euro Line E145 Local Train
Euro ES14 Limited Express
The AR-M201 is a powerful performer with a space-saving design. Speedy copying
and printing functions, including duplexing, and vivid colour scanning deliver
high-quality images, while Sharpdesk software makes the integrated desktop
management of documents part of this compact package. For added efficiency
and function, the AR-M201 can be teamed up with options like the Fax Expansion
Kit. And adding the Network Expansion Kit lets you integrate the AR-M201’s
powerful features into your office network for a whole new level of productivity.
Speedy Copying and Quick First Copy Time
The AR-M201 has a quick first copy time
of 8.0 seconds to save valuable time
when performing multiple short-run jobs.
And with a continuous copy rate of 20
cpm, you can do more copy jobs in less time.
Electronic Sorting and Offset Stacking
The AR-M201’s Scan Once/Print Many (SOPM) function does one
scan of multiple-page
documents and stores them
in memory for making up to
99 copies of each page. The
Electronic Sorting function
then automatically collates
multiple sets of copies in
page order without the aid
of a sorter. The AR-M201
also stacks each set slightly
shifted apart from the
previous (offset stacking)
for easy retrieval. All this
adds up to speedy copying
that boosts productivity even
for large-volume documents.
Efficient Duplex Copying and Optional RSPF
The AR-M201 can automatically
produce duplex copies from
one- or two-sided originals. This
reduces paper costs and helps
save filing space. Duplex
copying is even more productive
when used together with the
optional RSPF (reversing single pass feeder), which efficiently
feeds in up to 50 pages of either one- or two-sided originals.
Paper Capacity
The AR-M201 comes standard with a 250-sheet paper
tray and a 50-sheet multi-bypass feeder. An optional paper feed
unit is available for a total paper capacity of 550 sheets.
Superb Image Quality
600-dpi resolution and 256-level greyscale ensure finely detailed
reproduction, while Digital Auto Exposure Control provides
optimum copy contrast. For the best results, users can select Text
mode for text-only originals or Photo mode that gives detailed,
high-quality reproduction of photos and delicate halftone images.
Other Key Features
• Wide zoom range from 25% to 400% with 7 preset ratios
• Margin shift, 2-in-1 copy
• Cost-efficient Toner Save mode
• Pre-Heat and Auto Power Shut-Off modes
COPYING
High-Speed Operation
The AR-FX13 Fax Expansion Kit turns the AR-M201
into a 33.6 Kbps Super G3 fax. Using JBIG
compression technology, the AR-M201 can send an A4 (8 1/2" x
11") size page in under 3 seconds. Use the optional RSPF to
further boost faxing efficiency. And because Quick On-Line
Transmission can start dialling and transmitting as soon as the
first page is scanned into memory, you can send documents in
much less time.
Duplex Transmission and Reception
With the optional RSPF, the AR-M201 scans both pages of twosided documents and sorts them in memory. The pages are then
transmitted in the proper order. Thanks to the built-in duplex
module, the AR-M201 can also print incoming faxes onto both
sides of paper, thus saving you paper costs.
Other Key Features
• Memory transmission/reception
• Rapid and group dials (18 in total), 100 speed dials
• Long originals up to 500 mm can be sent using RSPF
(Note: Duplex transmission not possible)
FAXING (option)
20
PPM
Network Printing (option)
Full-Colour Network Scanning (option)
NO!
Macintosh
Scan paper
document
Unknown IP or MAC
addresses will be
denied access
Scan
Print
Ethernet
(10Base-T/100Base-TX)
Windows® and
Windows Server
®
Desktop
Client PCs
Internet
E-mail
FTP server
Scan to
Scan
Document
Full-Colour Scanning
The AR-M201 lets you easily scan colour originals in 600 x 1,200dpi resolution and use them to create vivid, impressive colour
documents or presentation materials. The optional 50-sheet RSPF
gives efficient multi-page document scanning.
Push and Pull Scanning
Operation is quick and easy—simply press the Scan button, select
an application, and press Start (push scan). Up to six pre-registered
applications are available, including Sharpdesk, e-mail, Microsoft®
Word, OCR, and PC-fax. Button Manager allows you to
change/assign these destination applications and scan settings.
With support for the TWAIN standard, the AR-M201 lets you
import scanned images to a commercially available TWAINcompliant application.
Sharpdesk 3.2
Sharpdesk is an original
Sharp application that
provides integrated desktop
management of documents
in over 200 file formats.
Once you scan documents
and images, or drag-anddrop existing files on your PC into Sharpdesk, you can view their
thumbnail images and organise, edit, and share your documents
right on your PC desktop. And Sharpdesk Composer combines
different types of files into a single document.
PRINTING
COLOUR SCANNING
Printer Status Window
Speedy Printing with Sharp Technology
The AR-M201 is a high-performance printer
incorporating Sharp Printer Language with
Compression (SPLC) technology. SPLC effectively
reduces the data size of print jobs, speeding up the
data transfer time and printing process while improving overall
throughput. Also, the RIP Once/Print Many (ROPM) function
saves print data in the AR-M201’s internal memory and transfers it
to output at a quick rate of 20 ppm in 600-dpi resolution.
Printer Status Window
A Printer Status Window conveniently
allows you to monitor important printer
information on your PC, including online/off-line status, name of the active
print job, and machine conditions such
as amount of paper or toner.
Other Key Features
• USB 2.0 port
• Duplex printing, Pamphlet Style printing
• N-up (2/4), Fit to Page, Watermarks
• Offset output
Secure Network Printing
The AR-M201 supports popular network protocols including
TCP/IP and IPX/SPX. The optional AR-NB2A Network Expansion Kit
allows easy printer sharing through your office network. The ARNB2A also supports PCL and PostScript* printer languages. And
with its IP/MAC address filtering function, only PCs that have
either their IP address or MAC (media access control) address
registered are allowed to use the AR-M201.
* Optional AR-PK1N PS3 Expansion Kit required.
Network Utility Software
Sharp’s original Printer Administration Utility software makes
printer networks easier to manage by allowing network
administrators to customise monitored items and view settings
such as the IP address directly from their PC.
Scan to Desktop, E-Mail, or FTP Server
The optional AR-NB2A Network Expansion Kit turns the AR-M201
into a convenient full-colour network scanner. As easy as making a
copy, you can send scanned images anywhere over the network.
Scanned files can be forwarded directly to your PC* (scan to
desktop), sent as an attachment to any e-mail address over the
Internet (scan to e-mail), or stored on a file server where they can
be easily accessed from any PC on the network (scan to FTP server).
* Sharpdesk must be installed on the PC.
LDAP Support
The AR-NB2A provides the AR-M201 with LDAP (lightweight
directory access protocol) support, which eliminates the need to
enter or register an entire e-mail address. Simply select Global
Address from the LCD control panel, enter the first few letters of the
recipient’s name, and the AR-M201 displays a list of possible matches
from names and e-mail addresses on
your company’s LDAP server. After
searching, addresses can be stored
on the AR-M201 for easy access.
Sharpdesk screen
Distributed by:
(tentative)
SPECIFICATIONS
Desktop
Max. A4 (8 1/2" x 14"), min. A6 (5 1/2" x 8 1/2")
300 sheets (250 + 50), max. 550 sheets with option
8.0 seconds
– (Auto Start mode)*
2
64 MB
Rated local AC voltage ±10%, 50/60 Hz
Max. 1.0 kW
518 x 445 x 298 mm (20 1/2" x 17 5/8" x 11 3/4")
Approx. 18.3 kg (40.3 lbs) without developer
Copy speed
Original size
Continuous copy
Resolution
Gradation
Zoom range
Preset copy ratios
Features
Max. 20 cpm (A4, 8
1
/2" x 11")
Max. A4 (8 1/2" x 14")
Max. 99 copies
Scan: 600 x 600 dpi (Photo mode)
600 x 300 dpi*3 (AE/Text mode)
Print: 600 x 600 dpi
256 levels
25% to 400% in 1% increments (50% to 200% using RSPF)
7 ratios (4 reduction + 3 enlargement)
Margin shift, electronic sorting, 2-in-1, offset stack,
toner save mode, pre-heat/auto power shut-off modes,
duplex copy, scan once/print many
Facsimile (optional AR-FX13 required)
Compression method
Communication protocol
Transmission time
Modem speed
Transmission resolution
Memory
Greyscale levels
Features
Type
Paper size
Paper capacity
First copy time*
1
Warm-up time
Memory
Power requirements
Power consumption
Dimensions (W x D x H)
Weight
General
Copier
Printer
Print speed
Resolution
Interface
Supported OS
PDL emulation
Available fonts
Features
Max. 20 ppm (A4, 8
1
/2" x 11")
600 dpi
USB 2.0
Windows® 98/Me, Windows® 2000 Professional,
Windows® XP Home Edition/Professional, Windows Vista®
Standard: SPLC (Sharp Printer Language with Compression)
Option*4: PCL 6/5e, PS3 emulation
80 fonts for PCL, 136 fonts for PS3 emulation*
5
Duplex print, RIP once/print many, offset print, status window,
N-up (2/4), fit to page, watermarks, image orientation,
rotation print, auto paper selection, image adjust, 2-gradation
print, binding edge, pamphlet style, auto configuration
Colour Scanner
Scan method
Resolution
Protocols
Interface
Supported OS
Scanner utilities
Push scan (via control panel), pull scan (TWAIN-compliant
application)
600 x 1,200 dpi (setting range: 50 to 9,600 dpi)
TWAIN, WIA (Windows
®
XP and Windows Vista®), STI
USB 2.0
Windows® 98/Me, Windows® 2000 Professional,
Windows
®
XP Home Edition/Professional, Windows Vista
®
Button Manager, Sharpdesk 3.2
Network Printing/Scanning (optional AR-NB2A required)
Network interface
Supported OS*
6
Memory
Network protocols*
6
Features
10Base-T/100Base-TX
Windows
®
98/Me/2000/XP, Windows Server® 2003,
Windows Vista®, Mac OS 9.x, Mac OS X 10.1 to 10.4.10
64 MB, expandable to 320 MB with SO-DIMM 256 MB (144-pin)
TCP/IP, IPX/SPX (Netware), NetBEUI, EtherTalk (AppleTalk)
Network scan (scan to e-mail/FTP server/desktop),
LDAP support, PCL and PS3 emulation*5, Sharpdesk 3.2
JBIG/MMR/MR/MH
Super G3/G3
Less than 3 seconds*
7
33,600 bps to 2,400 bps with automatic fallback
From Standard (203.2 x 97.8 dpi) to Super Fine (406.4 x 391 dpi)
2MB flash memory
Equivalent to 256 levels
Duplex transmission/reception, memory transmission/reception,
rapid and group dials (18 in total), 100 speed dials,
long original transmission (max. 500 mm), address book
import/export
AR-M201
Digital Multifunctional System
*1: When feeding A4 (8 1/2" x 11") sheets from paper tray, in Auto Exposure mode.
*2: Auto Start mode allows the user to go to reserved copy by pushing the start key while the machine is turning on after
being off or in energy-saving mode. Copying starts automatically once the machine has turned on.
*3: Can be changed to 600 x 600 dpi via user setting.
*4: AR-NB2A required. AR-PK1N also required for PostScript printing.
*5: AR-PK1N required.
*6: AR-PK1N required for Mac OS and EtherTalk.
*7: In Super G3 mode, at 33.6 Kbps.
• Design and specifications are subject to change without prior notice.
• Windows, Windows Vista, and Windows Server are registered trademarks of Microsoft Corporation in the United States
and/or other countries.
• All other brand names and product names may be trademarks or registered trademarks of their respective owners.
• The Energy Star logo is a certification mark and may only be used to certify products that have been determined to
meet the Energy Star programme requirements. Energy Star is a US registered mark. The Energy Star guidelines apply to
products only in the US, Europe, Australia, New Zealand, and Japan.
OPTIONS
Some options may not be available in some areas.
AR-RP9 50-Sheet Reversing Single Pass Feeder (RSPF)
AR-D33 250-Sheet Paper Feed Unit
AR-NB2A Network Expansion Kit (Printing/Scanning)
MX-USX1/X5 Sharpdesk 1/5-License Kit
MX-US10/50/A0 Sharpdesk 10/50/100-License Kit
AR-FX13 Fax Expansion Kit
AR-PK1 N PS3 Expansion Kit
AR-PF1 Barcode Font Kit
AR-PF2 Flash Memory for Downloaded Fonts
518 mm
(20
1
/
2
")
445 mm
(17
5
/
8
")
459 mm
(18 1/8")
(shown with options)
Loading...
