Dear SHARP Customer
P
U
L
L
-
O
P
E
N
Thank you for buying SHARP's Colour
Television. We hope you will have many
years of enjoyment from this television
set. To ensure proper operation, please
read this manual carefully, and keep it in
a safe place for future reference.
Accessories
ENGLISH
The following accessories are included with this television.
Remote control Size-AA batteries
Operation manual
Z
JZ
W
52
7
SF
-B
S
-M
IN
02
T
05P
E 2
Easy setup
To use your TV set, perform the easy setup procedure below.
The mark indicates the page numbers with more detailed information.
Connect the antenna.
• See
22
to connect the antenna.
Connect any video equipment.
22
• See
• See the operation manual of your video equipment when
connecting to the TV set.
23
,
to connect video equipment.
Insert the batteries into the remote
control.
• Use the two batteries included with the TV.
• See
6
.
E 3
Insert the AC plug to the power outlet.
• If you will not use the TV set for a considerable length of
time, as a safety precaution, unplug the cord from the
outlet.
Tune the channels.
• Use the buttons on the TV.
• See
14, 15
.
Safety precautions
Damage
Turn off the power and unplug the power cord from the wall
outlet immediately if the TV set begins to make any unusual
noises or gives off smoke or an unusual smell. Then call your
dealer for service.
Servicing
To reduce the risk of electric shock, do not remove the back of
the cabinet. This TV set contains dangerous voltage.
Unstable surface and shocks
Do not place this TV set on an unstable cart, stand, shelf, or
table. The TV set may fall, causing serious injury to a child or
adult, and serious damage to the set.
Sharp recommends securing the TV set to a stable surface or
wall to prevent the set from falling due to sudden shocks or
impact.
ENGLISH
Water
To prevent fire or electrical shock, do not place the TV set near a
bathroom, swimming pool or other area where it may become wet.
Moisture
To prevent electrical shock, do not use the TV set in an
excessively damp place.
Power-cord protection
To prevent electrical shock, do not subject the AC power cord to
damage by bending or twisting it, or by placing heavy items on
top of it and do not place the AC power cord under the TV set. If
the AC power cord becomes damaged, unplug it from the wall
outlet immediately and call your dealer for service.
E 4
Safety precautions
Liquid entry
Do not place a flower vase or anything else containing liquid on
the TV set, as liquid spilt on the TV set can cause electrical
shock or failure.
Object entry
Never insert or drop any metallic or inflammable objects into the
ventilation openings of the TV set, as this can cause fire,
electrical shock, or electrical failure.
Ventilation
Do not place this TV set in a confined area, such as on a
bookshelf or in a built-in case. Leave adequate space behind the
TV for proper ventilation.
TV Set position
Do place the TV set onto an even stand, table or track which size
is bigger than the TV set.
If the TV set is put onto a smaller size or uneven stand, table or
track may cause the TV cabinet distort.
Do not put or insert anything between TV set and the stand, table
or track.
Uneven surface and excessive force
Television equipment and cart combination should be moved
with care. Quick stops, excessive force, and uneven surfaces
may cause the equipment and cart combination to overturn.
Fire prevention
To prevent fire, never place any type of candle or naked flames
on the top or near the TV set.
E 5
Part names
The mark indicates the page numbers with more detailed information.
Remote control
Turns the TV on or to
Standby mode.
Returns to previously
viewed channel.
/
Adjusts the volume.
Used for MENU setup.
TIMER
Calls the TIMER screen.
FEATURE
Calls the FEATURE
screen.
CH-SET
Calls the CH-SETTING
screen.
NORMAL
Resets all settings.
8
11
8
19
18
16
17
Infrared transmitter window
Aim this window at the infrared
sensor window on your TV set.
TV/VIDEO
1
2
3
4
5
6
7
8
9
0
CH
CH
TIMERFEATURE
NORMAL
CH-SET
TV
TV/VIDEO
11
Switches between TV broadcasts
and A/V input programmes.
Number buttons
8
8
Switches between one- or two-digit
mode channel selection.
CH
8
Selects the channel.
Used for MENU setup.
10
Mutes the sound and restores
sound to previous level.
17
Calls the PICTURE screen.
10
Displays the channel and timer
settings on the screen.
ENGLISH
CH
/
Installing batteries in the remote control unit
With your thumbnail, pull
up at the slit to open the
battery cover.
• Be sure to match the battery j/k terminals with the j/k marks inside the compartment.
• Remove the batteries if weak or if the unit is not in use for long periods.
• Do not mix old and new batteries.
• Incorrect installation of the batteries may damage the remote control.
Insert two batteries
(size AA).
Replace the battery cover.
E 6
Part names
TV set
TV front
POWER
POWER switch
Turns on and off the main power.
Power indicator
Power can be turned on by
the remote control when the
indicator is dimly.
Infrared sensor window
Receives the infrared wave
from the remote control.
Behind the door
MENU/PRESET
MENU/PRESET button
Tunes the channels.
Used for MENU setup.
Volume up/down buttons
Adjusts the volume.
Makes adjustments in PRESET.
Channel up/down buttons
Tunes or sets the channels.
12
/
CH
Selects the channels.
8
8
PULL-OPEN
6
Headphone jack
9
Use to listen to the
audio with headphone.
Audio input terminal (AV-IN)
8
23
CH
/
8
23
Connects to a camcorder,
video game, etc.
Video input terminal (AV-IN)
Connects to a camcorder,
video game, etc.
E 7
• When using headphone, see 9.
Watching TV
TV Set
POWER
Power indicator
Behind the door
CH
TV/VIDEO
5
0
CH
CH
TIMERFEATURE
NORMAL
TV
3
6
9
1
4
728
CH-SET
CH
CH
CH
Watching a TV programme
ENGLISH
Simple operations for watching a TV programme
1 Turn on power.
• When the power indicator is off, press
• When the power indicator lights up dimly, press
control. The power indicator changes to bright and a picture appears.
POWER
.
on the remote
2 Select channel.
With
• Press
CH
CH
1 / 2 / ... / 98 / 99 / AV / 0 / 1 / 2 ...
• Press
CH
1 / 0 / AV / 99 / 98 / ... / 2 / 1 / 0 ...
With the number buttons (on remote control)
• To select a one-digit channel, such as 5, press
If “5-” is indicated, press
press
• To select a two-digit channel, such as 15, press
the two-digit input. Press
1
5
5
CH
/
and channels change as shown below.
and channels change as shown below.
5
to select one-digit input, and then
again.
1
, and then press
.
to select
5
--
.
1-
15
PAL
B/G
3 Adjust volume using /
.
• The number of oval blocks “ ”
indicates the volume level.
The volume bar disappears
approximately three seconds after
the volume has been adjusted.
VOLUME 10
• When the power indicator lights up dimly, either
the power.
• The channel number is displayed in green for channels tuned by auto tuning and displayed in yellow for
channels tuned using fine tuning.
• When the power indicator lights up dimly, the TV is in Standby mode and power is still supplied to the
TV. If you will not watch TV for a while, turn off the main power by pressing
if you will not be at home for a considerable length of time, unplug the cord from the outlet.
• The AV input channels cannot be selected using
to select these channel.
• Channels that have been skipped cannot be selected by
• The on-screen displays in this manual may differ from their actual appearance.
CH
CH
CH
/
/
on the TV can be pressed to turn on
POWER
on the TV set. Also,
CH
on the remote control. Use
CH
CH
/
. See 16.
TV/VIDEO
E 8
Watching TV
Operating the TV buttons
Simple operation of the TV set
Behind the door
Behind the door
CH
CH
Using /
Press to increase volume.
Press to decrease volume.
VOLUME 10
Using
Press
CH
CH
to increase channel
/
CH
number.
Press
CH
to decrease channel
number.
Using headphone
Insert headphone plug into headphone jack to listen to audio with
headphone.
• The audio from the speakers is turned off.
5
PAL
B/G
E 9
• Select an appropriate volume so as not to injure your hearing.
• To avoid injuring your hearing, do not put on the headphone before plugging them into the headphone
jack and before the power is turned on.
• The proper impedance for the headphone is 32 ohms.
• Remove the headphone plug from the jack when not using the headphone.
Useful features
1
4
728
CH-SET
5
0
CH
CH
TIMERFEATURE
NORMAL
TV
TV/VIDEO
3
6
9
Channel/Timer display
Displays the current channel number, the timer, and other
settings on the screen.
1 Press .
• The time remaining on the Off timer,
On timer, and Reminder appears on
the screen.
• When no timer is set, the channel
number, colour and sound system
appear on the screen. Press
again to clear these current
settings display on the screen.
OFF 2:30
ON 8:00
1:50
2 Press again.
• The channel number, colour and
sound system appear on the screen.
3 Press once again.
• The display disappears.
5
PAL
B/G
ENGLISH
Mute
Silences the sound.
1 Press .
•“ ” appears on the screen, and the
sound is silenced.
2 Press again.
• The volume returns to its previous
level.
• Mute will be cancelled if the is pressed at any time.
E 10
Useful features
Channel recall
Switches back to the channel you were watching just before
the current channel.
1
4
728
CH-SET
CH
CH
TIMERFEATURE
NORMAL
TV
5
0
TV/VIDEO
3
6
9
TV/VIDEO
Press .
• The channel previously viewed returns to
PAL
the screen.
Example:
After switching from channel 5 to channel
PAL
7, is pressed, the channel will
change to channel 5. Press
PAL
again to return to channel 7.
PAL
TV/Video selection
Switches between TV broadcasts and AV input programmes.
Each time you press the
input switches between AV and TV
programme.
TV/VIDEO
, the
AV
5
7
5
7
25
PAL
B/G
E 11
• The front AV terminals have the priority over the rear AV terminals.
• If 2 equipments are connected to the TV set from the front AV terminals and rear AV terminals, unplug
the front AV terminals cable to view the input from the rear AV terminals.
Selecting menu items
This TV set allows you to adjust the picture and sound, and set the channels and other features
using the On-screen display with the remote control or from the TV set. Select the desired
menu item by following the steps below and then refer to the indicated page for details.
Selecting a menu item
Behind the door
MENU/PRESET
CH
CH
1 Press
MENU/PRESET
on the TV set to
call MENU screen.
2 Press
CH
/
CH
to
select desired menu item.
• The selected item is highlighted in
yellow.
3 Press / to
enter.
• The corresponding menu screen will
appear.
4 Press
MENU/PRESET
until normal screen appears.
on the TV set
MENU
FEATURE
TIMER
CH-SETTING
MENU
FEATURE
TIMER
CH-SETTING
FEATURE
BLUE BACK
:SELECT
CH
:ADJUST
ON
ENGLISH
0
–
--:--
17
FEATURE menu
CH-SETTING menu
2119
FEATURE
BLUE BACK OFF
:SELECT
CH
:ADJUST
CH-SETTING
POSITION CH27
COLOUR AUTO
SOUND B/G
SKIP OFF
FINE
168.25MHz
MENU
FEATURE
TIMER
CH-SETTING
:SELECT
CH
:ENTER
PICTURE menu
CONTRAST 60
COLOUR 0
BRIGHTNESS 0
TINT
SHARPNESS
WHITE TEMP
:SELECT
CH
:ADJUST
TIMER menu
PULL-OPEN
TIMER
OFF --:-ON --:--
POSITION
VOLUME
Operating guide
:SELECT
:SELECT
CH
:ADJUST
•
If you press
MENU screen. To display the MENU screen, press
•
The procedures for setting and selecting the menu items on the following pages are described using the buttons
on the remote control. These procedures can also be performed using the corresponding buttons on the TV set.
MENU/PRESET
on the TV set for more than two seconds, the LANGUAGE mode screen will appear instead of the
MENU/PRESET
until the normal screen appears, then press the button again.
CH
:ADJUST
18
16
E 12
Settings and adjustments
U
N
Ç
S
SH
On-screen display language selection
The on-screen display language can be set to English,
Chinese, French, Malay or Arabic.
Behind the door
MENU/PRESET
CH
CH
TV set
1 Press
2 Press
3 Press
MENU/PRESET
for more than two seconds.
• The language select mode appear.
CH
select desired language.
• Pressing
screen as shown below.
Language MANUAL
MENU/PRESET
until normal screen appears.
on the TV set
/
MENU/PRESET
changes the
AUTO
Normal screen
on the TV set
CH
to
ENGLI
FRA
AI
BAHASA MELAY
E 13
Auto channel tuning
U
N
Ç
S
SH
Automatically tunes in and presets receivable TV stations.
ENGLISH
Behind the door
MENU/PRESET
1 Press
more than two seconds.
• The language select mode appear.
2 Press
MENU/PRESET
MENU/PRESET
again to display AUTO mode
screen.
• Pressing
screen as shown below.
Language MANUAL
on the TV set for
on the TV set
MENU/PRESET
Normal screen
changes the
AUTO
3 Press / on TV
set.
• All the TV stations in your area that
can be received by the TV set are
automatically preset between
channels 1 to 99.
• The screen shows whatever is on
channel 1 when auto channel preset
is finished.
ENGLI
FRA
AI
BAHASA MELAY
AUTO(B/G)
VHF 1
48.25MH
z
1
PAL
B/G
• AUTO PRESET stores all receivable channels including those which may be very weak and not clearly
visible. To preset only those channels designated for the local viewing region, use MANUAL PRESET.
See 15.
• Unused channels are automatically skipped.
E 14
SH
ENGLISH
Settings and adjustments
Enables manual channel tuning to a desired TV station.
Manual channel tuning
Behind the door
MENU/PRESET
TV/VIDEO
CH
CH
TIMERFEATURE
NORMAL
TV
3
6
5
9
0
1
4
728
CH-SET
CH
CH
Number
buttons
CH
CH
1 Press
MENU/PRESET
on the TV set for
more than two seconds.
• The language select mode appear.
2 Press
MENU/PRESET
on the TV set
twice to display MANUAL mode
screen.
• Pressing
MENU/PRESET
changes the
screen as shown below.
Language MANUAL
3 Press
AUTO
Normal screen
CH
/
CH
or
number buttons to select channel
position.
4 Press / on TV
set to locate channel you wish to
preset to current channel
position.
• Search is initiated and when a TV
signal is received during the search,
the search stops.
ENGLI
MANUAL(B/G)
VHF 1
48.25MH
MANUAL(B/G)
VHF 5
107.50MH
z
z
Channel position
E 15
5 Repeat steps 3 and 4 above, to preset channel positions for
other broadcasts.
6 Press
MENU/PRESET
on the TV set again to display normal screen.
Channel setting
Enables individual channel setting.
ENGLISH
1
4
728
CH-SET
5
0
CH
CH
TIMERFEATURE
NORMAL
TV
TV/VIDEO
3
6
9
CH
CH
CH-SET
1 Press
CH-SET
CH-SETTING screen.
2 Press
CH
to call
/
CH
to
CH-SETTING
POSITION CH27
COLOUR AUTO
SOUND B/G
SKIP OFF
FINE 168.25MHz
select desired setting.
:SELECT
3 Each time you press /
CH
:ADJUST
, setting for individual
items changes as follows:
• POSITION
The channel position changes to the higher or lower number.
• COLOUR
AUTO PAL
N443
SECAM
• SOUND
B/G I
D/K
• SKIP
ON
Channel numbers with a “
OFF
” mark on the left are set to SKIP. To turn
off SKIP, press the number buttons to select the desired channel and
then set “SKIP” to “OFF”.
• FINE
The frequency changes to allow fine tuning.
4 Press
normal screen.
CH-SET
to return to
CH-SETTING
POSITION AV
COLOUR AUTO
• When you select AV for the channel
position, the CH-SETTING screen
changes as shown on the right and
the colour mode changes in the
following order:
:SELECT
CH
:ADJUST
AUTO PAL SECAM N443 N358
• Switching COLOUR system:
Set the system to “AUTO” for normal TV reception. The AUTO mode automatically detects the receiving
signal system and changes the reception system of the TV set. When the picture is not stable, switching
to an appropriate system may improve the picture quality.
• In a weak reception area, or under bad reception conditions, you can change the frequency by fine tuning.
• When using FINE, the channel number changes from green to yellow.
• To return the channel to its original frequency setting, follow the manual channel tuning procedure.
See 15.
E 16
Settings and adjustments
Picture adjustment
1
4
728
CH-SET
CH
CH
TIMERFEATURE
NORMAL
TV
5
0
TV/VIDEO
3
6
9
CH
CH
NORMAL
1 Press
screen.
2 Press
CH
select adjustment items.
to call PICTURE
/
CH
to
CONTRAST 50
COLOUR 0
BRIGHTNESS +10
TINT
SHARPNESS -10
WHITE TEMP
3 Adjust using / .
• Wait for approximately three seconds
to return to PICTURE menu.
CONTRAST
-
4 Repeat steps 2 and 3 above to adjust other items.
5 Press
• Pressing
selected mode is reset to the standard (factory-setting) position.
• Pressing
reset all the items of PICTURE menu to the standard (factory-setting)
position.
to return to normal screen.
NORMAL
NORMAL
while a PICTURE selection is displayed, only the
while a PICTURE menu screen is displayed will
50
+
The following table lists the adjustment items shown in the PICTURE menu and how they change as you
press / .
Selected item Press Press
CONTRAST
COLOUR
BRIGHTNESS
TINT
SHARPNESS
WHITE TEMP To more reddish
To decrease
contrast
For less colour
intensity
For less
brightness
To move tint toward
red
For less
sharpness
background
- +
- +
- +
- +
To increase
contrast
For more colour
intensity
For more
brightness
To move tint toward
green
For more
sharpness
To more bluish
background
*: TINT can only be selected and adjusted when receiving NTSC broadcasts. (AV only).
E 17
Blue screen
Automatically turns the screen blue if a broadcast signal is
not received.
ENGLISH
1
4
728
CH-SET
5
0
CH
CH
TIMERFEATURE
NORMAL
TV
TV/VIDEO
3
6
9
FEATURE
1 Press
FEATURE
to call FEATURE
screen.
2 Press / to
select “BLUE BACK” to “ON” or
“OFF”.
3 Press
FEATURE
normal screen.
When BLUE BACK is set to “ON”
No signal
to return to
Blue screen TV off (Indicator)
after 5 seconds after 15 minutes
FEATURE
BLUE BACK
:SELECT
CH
:ADJUST
Standby mode
ON
Power indicator
lights up dimly
• Poor reception due to weak signals and too much noise may activate BLUE BACK, despite the
presence of a broadcast signal. To continue watching TV under these conditions, switch “BLUE BACK”
to “OFF”.
• When Off timer is set, the OFF TIMER setting has priority over BLUE BACK.
E 18
Settings and adjustments
Automatically turns power off after a set length of time has
passed.
Off timer
1
4
728
CH-SET
CH
CH
TIMERFEATURE
NORMAL
TV
5
0
TV/VIDEO
3
6
9
CH
CH
TIMER
NORMAL
1 Press
TIMER
to call TIMER
screen.
2 Press
select “OFF
CH
CH
/
to
”.
3 Press / to set
time for TV to turn off.
• Maximum time that can be preset is
12 hours and 50 minutes.
• As soon as the time is entered, the
timer starts to count down.
4 Press
TIMER
normal screen.
• Five minutes before the preset
length of time expires (in the
example, after two hours and 25
minutes), the remaining time
appears on the screen for several
seconds.
• A flashing display of the remaining
time appears during the last few
seconds.
• When the preset length of time has
passed, the TV set enters the
Standby mode.
to return to
TIMER
OFF --:--
ON --:--
POSITION
VOLUME
:SELECT
CH
:ADJUST
--:--
TIMER
OFF 2:30
ON --:--
POSITION
VOLUME
:SELECT
CH
:ADJUST
OFF
OFF
OFF
0:05
0:04
0:03
OFF
OFF
--:--
0:02
0:01
E 19
OFF
0:00
Flashing
• To cancel the timer setting, press
NORMAL
when “ ” is displayed on the left of “OFF ” so as to set
the timer to “- - : - -”.
• The timer can be set in ten-minute intervals.
• The Off timer is cancelled if the power is turned off or set to the Standby mode using on the
remote control or
POWER
on the TV set, or if the power is otherwise interrupted.
On timer
Automatically turns power on after a set length of time has
passed.
ENGLISH
TV/VIDEO
5
0
CH
CH
TIMERFEATURE
NORMAL
TV
3
6
9
1
4
728
CH-SET
TV Set
Power indicator (Flashing)
CH
CH
TIMER
NORMAL
1 Press
TIMER
to call TIMER
screen.
2 Press
CH
/
CH
to
select “ON ”.
3 Press / to set
time for TV to turn on.
• Maximum time that can be preset is
12 hours and 50 minutes.
• As soon as the time is entered, the
timer starts to count down.
4 Press
CH
/
CH
to
select “POSITION”.
5 Press / to set
the channel.
6 Press
CH
/
CH
to
select “VOLUME”.
7 Press / to
set volume.
8 Press
normal screen.
TIMER
to return to
TIMER
OFF --:--
ON --:--
POSITION
VOLUME
TIMER
OFF --:--
ON 8:00
POSITION
VOLUME
:SELECT
CH
:ADJUST
TIMER
OFF --:-ON 8:00
POSITION
VOLUME
:SELECT
CH
:ADJUST
TIMER
OFF --:-ON 8:00
POSITION
VOLUME
:SELECT
CH
:ADJUST
--:--
--
--
--:--
CH28
--
--:--
CH28
20
--:--
9 Press to put TV set into
Standby mode.
• Power indicator will flash to indicate On Timer is set.
• When the preset length of time (in the above example, eight hours)
has passed, the power turns on and a picture appears on the screen.
• The ON TIMER speaker volume gradually increases from zero to
preset volume.
• To cancel the timer setting, press
timer to “- - : - -”.
• The timer can be set in ten-minute intervals.
• The On Timer is cancelled if the power is turned off using
• If the TV set is turned on by the On Timer, then the TV set will be automatically turned off in two hours if
no buttons are pressed on the TV set or remote control.
NORMAL
when “ ” is displayed on the left of “ON ” so as to set the
POWER
on the TV set.
E 20
Settings and adjustments
Lets you know when a preset length of time has passed by
displaying a countdown timer on the screen. This is useful
for timer cooking while you watch TV.
Reminder on-screen timer
1
4
728
CH-SET
CH
CH
TIMERFEATURE
NORMAL
TV
5
0
TV/VIDEO
3
6
9
CH
CH
TIMER
NORMAL
1 Press
TIMER
to call TIMER
screen.
2 Press
CH
/
CH
to
select “ ”.
3 Press / to set
time.
• Maximum time that can be preset is
12 hours and 50 minutes.
• The right example shows that the
Reminder will be activated after one
hour 50 minutes.
4 Press
TIMER
normal screen.
• Five minutes before the preset
length of time expires (in the
example, after one hour and 45
minutes) and each minute
thereafter, the remaining time
appears on the screen for several
seconds.
• When the preset length of time has
passed, “
to return to
0:00” flashes in red.
TIMER
OFF --:-ON --:--
POSITION
VOLUME
:SELECT
CH
:ADJUST
--:--
TIMER
OFF --:-ON --:--
POSITION
VOLUME
:SELECT
CH
:ADJUST
0:05
0:04
1:50
0:03
0:02
0:01
E 21
0:00
Flashing
• This function also works in the Standby mode. Power is automatically turned on five minutes before the
preset length of time expires. The TV set automatically returns to the Standby mode approximately 1
minute after the timer expired if no buttons are pressed on the TV set or remote control.
• The Reminder is cancelled if
POWER
on the TV set is pressed or if the power is otherwise interrupted.
• The timer can be set in ten-minute intervals.
• To cancel the timer setting, press
NORMAL
when “ ” is displayed on the left of “ ” so as to set the
timer to “- - : - -”.
Connections
Connecting to an antenna
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of
the types of connections that are used for coaxial and feeder cables.
If your outdoor antenna uses a 75-ohm coaxial cable with a standard
DIN45325 plug (IEC 169-2), plug it into the antenna jack at the rear of
the set.
If your outdoor antenna uses a 300-ohm twin-lead flat feeder, connect a
300-ohm to 75-ohm impedance converter and plug it into the antenna
jack at the rear of the set.
TV
Standard DIN45325 plug (IEC169-2)
OUT
AV-IN
75-ohm coaxial cable (round cable) (not supplied)
300-ohm twin-lead
flat feeder
(not supplied)
75-ohm impedance
converter
(not supplied)
Y
AUDIO
P
B
(C
B
)
VIDEO
PR
R
)
(C
Antenna in
ENGLISH
Connecting to an antenna via a VCR
You can also connect the TV set to the tuner on a VCR using the connection shown below.
TV
VCR
OUT
AV-IN
Y
AUDIO
P
B
(C
B
)
VIDEO
PR
(C
R
)
To antenna in
terminal
To RF out
terminal
• When using the RF terminal connection, set the TV to channel zero to make initial adjustments for the VCR.
• Turn off the power on the TV set and the VCR being connected before making the above connections.
Be sure the cord plugs are fully inserted in the connection terminals.
• See the operation manual of your VCR for connection details.
Antenna in
E 22
Connections
Connecting to video equipment
Enjoy playback from a video disc player, VCR or other video equipment by connecting
them to this TV set using the Audio/Video in terminals.
Example use of front terminals
TV
VCR
Behind the door
Example use of rear terminals
For Playback
DVD Player
To Audio/
Video out
terminals
To Audio/
Video out
terminals
VCR
PULL-OPEN
Yellow : To VIDEO
Red : To AUDIO
TV
Camcorder
Video Game
To Audio/Video
out terminals
Yellow : To VIDEO
Red : To AUDIO
For Recording and Editing
VCR
OUT
AV-IN
AUDIO
VIDEO
To Audio/
Video in
terminals
OUT
AV-IN
AUDIO
VIDEO
E 23
• Turn off the power on the TV set and the VCR being connected before making the above connections.
Be sure the cord plugs are fully inserted in the connection terminals.
• The audiovisual cords required to connect the TV set with video equipment may differ from those shown
in the above diagram. See the operation manual of your video equipment for connection details.
• The above recording and editing connections are for intended solely for personal use and not for the
illegal copying of audiovisual material protected by copyright laws.
Troubleshooting
The following problems do not always indicate a hardware failure. Therefore, please use
the troubleshooting guide below before calling for repair service.
If, after following the guide none of the remedies work, unplug the TV set and call for
service.
Quick
Service
Check List
Possible Causes/Remedies
Try a new channel to check for possible
station trouble.
TV not plugged in.
Outlet power OFF.
POWER switch of TV not ON.
Antenna not connected to terminal at the
back of the TV set.
If outside antenna is used, check for
broken wires.
Problems
Remote control does not work.
Bars on screen
Picture distorted.
Picture rolls vertically.
No colour
Poor reception on some channels
Picture weak.
Picture lines or streaks
Picture ghosting
Picture blurred.
Sound OK, picture poor.
Picture OK, sound poor.
No picture or sound
ENGLISH
Check for local interference.
Turn OFF using the POWER switch,
then turn ON again after a minute.
Adjust COLOUR control.
Check batteries in the remote control.
Try fine tuning to correct.
Contrast setting in picture mode might be all the
way to the minus side. Press the NORMAL button
on the remote control to correct.
Increase the volume.
• This unit is equipped with a microprocessor. Its performance could be adversely affected by external
electrical noise or interference. If this should happen, unplug the unit and plug it in again after a few
minutes.
E 24
Specifications
MODEL 21HF2-SS
Receiving System World multi 18 system
TV Broadcasts/ PAL-I SECAM-B/G
VCR Playback PAL-B/G SECAM D/K, K1
VCR Playback NTSC 4.43/5.5 MHz/60 Hz
VCR Playback SECAM-L (French SECAM)
(Using Video-in terminals) PAL 60Hz
Laserdisc Player Playback PAL 5.5 MHz/60 Hz
(Using RF-in terminals) PAL 6.0 MHz/60 Hz
Reception Channels
PAL-B/G VHF E2–E12 ch
SECAM-B/G
PAL-D/K VHF C1–C12 ch, R1–R12 ch
SECAM-D/K, K1
PAL-I VHF B–J ch
CATV S1–S20 ch, S21–S41 ch (Hyper)
Receiving Frequency 48.25 MHz – 863.25 MHz
Channel Tuning 100-Channel Electronic Tuner with Full Auto Tuning System
Picture Tube 21-Inch Flat CRT
Terminals Audio/video input × 2 (front × 1, rear × 1)
Sound Output 2.5 W (RMS) × 2, total 5 W (RMS)
Power Source AC 110 – 240V, 50/60 Hz
Power Consumption 95 W
Dimensions 618 (W) × 471 (H) × 485 (D) mm
Weight 25.5 kg (Approx.)
PAL-D/K
NTSC 4.43/6.0 MHz/60 Hz
NTSC 4.43/6.5 MHz/60 Hz
NTSC 4.43/5.5 MHz/50 Hz
NTSC 4.43/6.0 MHz/50 Hz
NTSC 4.43/6.5 MHz/50 Hz
SECAM-I (6.0 MHz)
NTSC 3.58 MHz
PAL 6.5 MHz/60 Hz
UHF E21–E69 ch
UHF C13–C57 ch, R21–R69 ch
UHF 21–69 ch (Hong Kong)
Audio/video output × 1 (rear) , Headphone jack × 1 (front)
E 25
• Design and specifications are subject to change without notice.
• Receiving system: These receiving systems, encompassing all currently available technology, include
those with planned broadcast, videotape and laserdisc hardware and software.
• Reception channels: Some examples of the main receivable channels are shown above.
SHARP CORPORATION
Loading...
