Sharp 21FL84 Service Manual

21FL84

SERVICE MANUAL

COLOR TELEVISION

Chassis No. GA-4

MODEL

In the interests of user-safety (Required by saf ety regulations in some countries ) the set should be restored to its
original condition and only parts identical to those specified should be used.

CONTENTS

» ELECTRICAL SPECIFICATIONS .........................................................................................................1

» IMPORTANT SERVICE SAFETY PRECAUTION .................................................................................2

» LOCATION OF USER'S CONTROL .....................................................................................................4

» INSTALLATION AND SERVICE INSTRUCTIONS................................................................................5

» SERVICE MODE ..................................................................................................................................6

» ADJUSTMENT METHOD...................................................................................................................12

» CHASSIS LAYOUT................................................................................................................................15

» BLOCK DIAGRAM..............................................................................................................................16

» DESCRIPTION OF SCHEMATIC DIAGRAMS & WAVEFORMS........................................................19

» SCHEMATIC DIAGRAMS...................................................................................................................20

» PRINTED WIRING BOARD ASSEMBLIES........................................................................................23

» REPLACEMENT PARTS LIST............................................................................................................26

» PACKING OF THE SET......................................................................................................................31

21FL84

Page

ELECTRICAL SPECIFICATIONS

POWER INPUT....................................... AC 110~220 V, 50/60 Hz

POWER RATING....................................................................88W

PICTURE SIZE .......................................... 1,239 cm2 (192sq inch)

CONVERGENCE ............................................................. Magnetic

SWEEP DEFLECTION .................................................... Magnetic

FOCUS .................................................. QFP/UNI-B1 Electrostatic

INTERMEDIATE FREQUENCIES

Picture IF Carrier Frequency ..................................... 45.75 MHz

Sound IF Carrier Frequency...................................... 41.25 MHz

Color Sub-Carrier Frequency .................................... 42.17 MHz

(Nominal)

AUDIO POWER

OUTPUT RATING........................................3.0 W(RMS) x 2pcs

SPEAKER

SIZE ...................................................................12 x 5 cm, 2pcs

VOICE COIL IMPEDANCE............................. 16 ohm at 400 Hz

ANTENNA INPUT IMPEDANCE

VHF/UHF.....................................................75 ohm Unbalanced

TUNING RANGES

VHF-Channels...............................................................2 thru 13

UHF-Channels ............................................................14 thru 69

CATV Channels ...........................................................1 thru 125

(EIA, Channel Plan U.S.A.)

Specifications are subject to change without
prior notice.

SHARP CORPORATION

This document has been published to be used for after
sales service only.
The contents are subject to change without notice.

21FL84

IMPORTANT SERVICE SAFETY PRECAUTION

Ë

Service work should be performed only by qualified service technicians who are
thoroughly familiar with all safety checks and the servicing guidelines which follow:

WARNING

1. For continued safety, no modification of any circuit
should be attempted.

2. Disconnect AC power before servicing.

3. Semiconductor heat sinks are potential shock
hazards when the chassis is operating.

4. The chassis in this receiver has two ground systems
which are separated by insulating material. The non­isolated (hot) ground system is for the B+ voltage
regulator circuit and the horizontal output circuit. The
isolated ground system is for the low B+ DC voltages
and the secondary circuit of the high voltage
transformer.
To prevent electrical shock use an isolation
transformer between the line cord and power
receptacle, when servicing this chassis.

SERVICING OF HIGH VOLTAGE SYSTEM
AND PICTURE TUBE

When servicing the high voltage system,
remove the static charge by connecting a
10k ohm resistor in series with an insulated
wire (such as a test probe) between the pic­ture tube ground and the anode lead. (AC
line cord should be disconnected from AC
outlet.)

1. Picture tube in this receiver employs integral
implosion protection.

2. Replace with tube of the same type number for
continued safety.

3. Do not lift picture tube by the neck.

4. Handle the picture tube only when wearing
shatterproof goggles and after discharging the high
voltage anode completely.

X-RADIATION AND HIGH VOLTAGE LIMITS

1. Be sure all service personnel are aware of the
procedures and instructions covering X-radiation.
The only potential source of X-ray in current solid
state TV receivers is the picture tube. However, the
picture tube does not emit measurable X-Ray
radiation, if the high voltage is as specified in the
"High Voltage Check" instructions.
It is only when high voltage is excessive that X­radiation is capable of penetrating the shell of the
picture tube including the lead in the glass material.
The important precaution is to keep the high voltage
below the maximum level specified.

2. It is essential that servicemen have available at all
times an accurate high voltage meter.
The calibration of this meter should be checked
periodically.

3. High voltage should always be kept at the rated value

−no higher. Operation at higher voltages may cause
a failure of the picture tube or high voltage circuitry
and;also, under certain conditions, may produce
radiation in exceeding of desirable levels.

4. When the high voltage regulator is operating properly
there is no possibility of an X-radiation problem.
Every time a color chassis is serviced, the brightness
should be tested while monitoring the high voltage
with a meter to be certain that the high voltage does
not exceed the specified value and that it is regulating
correctly .

5. Do not use a picture tube other than that specified
or make unrecommended circuit modifications to the
high voltage circuitry.

6. When trouble shooting and taking test
measurements on a receiver with excessive high
voltage, avoid being unnecessarily close to the
receiver.
Do not operate the receiver longer than is necessary
to locate the cause of excessive voltage.

2

3

3

IMPORTANT SERVICE SAFETY PRECAUTION

DVM

AC SCALE

1.5k ohm
10W

TO EXPOSED
METAL PARTS

CONNECT TO
KNOWN EARTH
GROUND

2

2

(Continued)

21FL84

BEFORE RETURNING THE RECEIVER
(Fire & Shock Hazard)

Before returning the receiver to the user, perform
the following safety checks.

1. Inspect all lead dress to make certain that leads are
not pinched or that hardware is not lodged between
the chassis and other metal parts in the receiver.

2. Inspect all protective devices such as non-metallic
control knobs, insulating materials, cabinet backs,
adjustment and compartment covers or shields,
isolation resistor-capacity networks, mechanical
insulators, etc.

3. To be sure that no shock hazard exists, check for
leakage current in the following manner.

• Plug the AC cord directly into a 110~220 volt AC
outlet, (Do not use an isolation transformer for this
test).

• Using two clip leads, connect a 1.5k ohm, 10 watt
resistor paralleled by a 0.15µF capacitor in series
with all exposed metal cabinet parts and a known
earth ground, such as electrical conduit or electrical
ground connected to earth ground.

• Use an AC voltmeter ha ving with 5000 ohm per volt,
or higher, sensitivity to measure the A C v oltage drop
across the resistor.

• Connect the resistor connection to all exposed metal
parts having a return to the chassis (antenna, metal
cabinet, screw heads, knobs and control shafts,
escutcheon, etc.) and measure the AC voltage drop
across the resistor.
AII checks must be repeated with the AC line cord
plug connection reversed. (If necessary, a non­polarized adapter plug must be used only for the
purpose of completing these check.)
Any current measured must not exceed 0.5 milliamp.
Any measurements not within the limits outlined
above indicate of a potential shock hazard and
corrective action must be taken before returning the
instrument to the customer.

2345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212

2345678901234567890123456789012123456789012345678901234567890121234567890123456789012345678901212

SAFETY NOTICE

Many electrical and mechanical parts in television
receivers have special safety-related characteristics.
These characteristics are often not evident from visual
inspection, nor can protection afforded by them be
necessarily increased by using replacement components
rated for higher voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this manual; electrical
components having such features are identified by "å"
and shaded areas in the Replacement Parts Lists and
Schematic Diagrams.

234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121

234567890123456789012345678901212345678901234567890123456789012123456789012345678901234567890121

3

For continued protection, replacement parts must be
identical to those used in the original circuit. The use of
substitute replacement parts which do not have the same
safety characteristics as the factory recommended
replacement parts shown in this service manual, may
create shock, fire, X-radiation or other hazards.

21FL84

LOCATION OF USER'S CONTROL

Front Panel

POWER

Press → On.
Press again

SENSOR AREA FOR
REMOTE CONTROL

MENU

Press
Press again

→ Off.

→ Accesses MAIN MENU.

→ Exits MAIN MENU.

VOLUME UP/DOWN

(+) Increases sound.
(

) Decreases sound.

Basic Remote Control Functions

POWER

Press → On.
Press again → Off.

REMOTE KEYPAD

Accesses any channel from keypad.

FLASH BACK

Returns to previous channel.

VOLUME UP/DOWN

(+) Increases sound.
(–) Decreases sound.

• In menu mode, changes or selects
the TV adjustments.

MUTE

Press Mutes sound.
Press again Restores sound.

• CLOSED CAPTION appears when

sound is muted.

VIDEO IN 2 L-AUDIO-R

(INSIDE DOOR)

CHANNEL UP/DOWN

(') Selects next higher channel.

) Selects next lower channel.

(

"

Infrared Transmitter Window

INPUT
Press → Switch to external video input
mode.
Press again → Switch to TV mode.

CHANNEL UP/DOWN

(8) Selects next higher channel.
(9) Selects next lower channel.

• Moves the “ ” mark of the MENU

screen.

MENU

Press →

Accesses MAIN MENU.

Press again →

DISPL AY

Press → Displays receiving channel for
4 seconds.
Press again → Removes display.

• Temporarily displays receiving
channel when in Closed Caption
mode.

Exits MAIN MENU.

Note:

The above shaded buttons on the Remote Control glow in the dark. To use the glow-in-the-dark display on the
remote control, place it under a fluorescent light or other lighting.
The phosphorescent material contains no radioactive or toxic material, so it is safe to use.
The degree of illumination will vary depending on the strength of lighting used.
The degree of illumination will decrease with time and depending on the temperature.
The time needed to charge the phosphorescent display will vary depending on the surrounding lighting.
Sunlight and fluorescent lighting are the most effective when charging the display.

4

21FL84

INSTALLATION AND SERVICE INSTRUCTIONS

Note: (1) When performing any adjustments to resistor controls and transformers use non-metallic

screwdrivers or TV alignment tools.

(2)Before performing adjustments, the TV set must be on at least 15 minutes.

CIRCUIT PROTECTION

The receiver is protected by a 3.15A fuse (F701),
mounted on PWB-A, wired into one side of the AC
line input.

X-RADIATION PROTECTOR CIRCUIT TEST

After service has been performed on the horizontal
deflection system, high voltage system, B+ system,
test the X-Radiation protection circuit to ascertain
proper operation as follows:

1. Apply 110~220V AC using a variac transformer for
accurate input voltage.

2. Allow for warm up and adjust all customer controls
for normal picture and sound.

3. Receive a good local channel.

4. Connect a digital voltmeter to P603 pin3 and make
sure that the voltmeter reads 20 ±1.1V.

5. Apply external 27V DC at P603 pin3 by using an
external DC supply, TV must be shut off.

6. To reset the protector, unplug the AC cord and mak e
a short circuit between P603 pin1 and P603 pin2.
Now make sure that normal picture appears on the
screen.

7. If the operation of the horizontal oscillator does not
stop in step 5, the circuit must be repaired before the
set is returned to the customer.

HIGH VOLTAGE CHECK

High voltage is not adjustable but must be checked
to verify that the receiver is operating within safe
and efficient design limitations as specified checks
should be as follows:

1. Connect an accurate high voltage meter between
ground and anode of picture tube.

2. Operate receiver for at least 15 minutes at 110~220V
AC line voltage, with a strong air signal or a properly
tuned in test signal.

3. Enter the service mode and set Y-mute ON by using
Service R/C.

4. The voltage should be approximately 28.7kV (at zero
beam).
If a correct reading cannot be obtained, check circuitry
for malfunctioning components. After the v oltage test,
make Y-mute off to the normal mode.

5

21FL84

SERVICE MODE

Service Mode Overview

1. Service mode is entered by SERVICE key input or CH-UP +VOL-DOWN input during reset.

2. Service mode is cleared by entering SERVICE key command during service mode.

3. If key input port (SERVICE) input is LOW, then it is in service mode.

4. During key input port (SERVICE) input is LOW, clearing service mode by key input SERVICE is disabled.

5. Service mode can be switched to 4 modes as follows by key input MENU;

Adjustment mode

Setting mode

Check mode

Option mode

6. AFT processing is disabled during service mode. PLL setting data is set to fo data.

7. All user data are set to default during service mode. FAO and SPEAKER user settings are off and on respectively
in service mode. Energy Save is off.

8. Sleep timer, View timer, on timer and off timer are inactivated in Service mode.

9. Sound is muting in service mode except at Adjustment Items V20, M01, M03, M04, M05, and M06.

First mode of service mode when SERVICE key is
pressed.

First mode of service mode when local key
CH-UP + VOL-DOWN is pressed after MCU reset.

6

Adjustment Mode Items

No. Item Name IC Register Range Default

V01SUB-PICTURE1 ChipCONTRAST0~127127
V02SUB-TINT1 ChipTINT0~12764
V03SUB-COLOR1 ChipCOLOR0~12764
V04SUB-BRIGHT1 ChipBRIGHT0~255128
V05 SUB-SHARP 1 Chip VIDEO-TONE 0~63 32
V06 V-SHIFT 1 Chip V-SHIFT 0~7 4
V07H-SHIFT1 ChipH-PHASE0~3116
V08RF-AGC1 ChipRF-DELAY0~127127
V09 V-SIZE 1 Chip V-SIZE 0~63 32
V10 PIF-VCO 1 Chip VIF-VCO 0~63 32
V11R-CUTOFF1 ChipR-CUTOFF0~255 64
V12G-CUTOFF1 ChipG-CUTOFF0~255 64
V13B-CUTOFF1 ChipB-CUTOFF0~255 64
V14R-DRIVE1 ChipR-DRIVE0~12764
V15B-DRIVE1 ChipB-DRIVE0~12764
V16SUB-COLOR(YUV)1 ChipCOLOR0~12764
V17SUB-TINT(YUV)1 ChipBASEBAND-TINT0~12764
V18CC-POSMICONCC-POS0~25532
V19SCREEN CUT OFF1 ChipCUT OFF0~20
V20SUB-VOL1 ChipA-ATT0~127127

V21 H-VCO 1 Chip H-VCO 0~7 4
M01MTS-ATTMTSATT (MTS)0~1516
M02MTS-VCOMTSVCO (MTS)0~6332
M03 MTS-FILTER MTS FILTER (MTS) 0~63 28
M04 MTS-WIDEBAND MTS WIDEBAND (MTS) 0~63 27
M05 MTS-SPECTRAL MTS SPECTRAL (MTS) 0~63 32
M06 SUB-VOL MTS VOL (MTS) 0~63 63

21FL84

7

21FL84

Ë

SELF ADJUSTMENT

H-VCO

1. When there is H-VCO self-adjustment key input for adjustment item H-VCO, self-adjustment is performed.

2. H-FREE(1chip) is set to 1.

3. H-OUT is set by intelligent monitor output.

4. IM input is set as TIM input.

5. H-VCO(1chip) data is changed so that the number of input pulse is 125 inside 8ms interval.

6. When adjustment completed, OSD display and H-VCO self-adjustment status data of EEPROM are updated.

7. H-FREE(1chip), intelligent monitor output and IM input mode are recovered.

RF-AGC

1. When there is RF-AGC self-adjustment key input for adjustment item RF-AGC, self-adjustment is performed.

2. AGC-OUT is set by intelligent monitor output.

3. IM input is set as AD input.

4. By decreasing RF-AGC (1chip) data from current RF-AGC adjustment value to 0, AFT input voltage becomes the
maximum setting value.

5. Increase RF-AGC(1chip) data, when AFT input voltage is at (max. 0.3V) point, adjustment is completed.

6. When adjustment completed, OSD display and RF-AGC self-adjustment status data of EEPROM are updated.

7. Intelligent monitor output and IM input mode are recovered.

PIF-VCO

1. When there is PIF-VCO self-adjustment key input for adjustment item PIF-VCO, self-adjustment is performed.

2. VIF-DEF(1chip) is set to 1.

3. AFC is set by intelligent monitor output.

4. IM input is set as AD input.

5. VIF-VCO(1chip) data is changed so that input voltage becomes 2.5V.

6. When adjustment completed, OSD display and PIF-VCO self-adjustment status data of EEPROM are updated.

7. VIF-DEF(1chip), intelligent monitor output and IM input mode are recovered.

8

Setting Mode Items

No. Item Name IC Register Range Default

F01 VIDEO TONE -GAIN (TV) 1 Chips V-TONE 0/1 0
F02 VIDEO TONE -GAIN (AV) 1 Chips V-TONE 0/1 0
F03

VIDEO TONE -GAIN (S-AV)
F04 VIDEO TONE -GAIN(YUV) 1 Chips V -T ONE 0/1 0
F05 ABCL 1 Chips ABCL 0/1 0
F06 BS 1 Chips BS-OFF 0/1 0
F07 ABCL-G 1 Chips ABCL-G 0/1 0
F08 SHP-AV OFFSET VIDEO-TONE(OFFSET) -16~+16 0
F09 SHP-SAV OFFSET VIDEO-TONE(OFFSET) -16~+16 0
F10 SHP-YUV OFFSET VIDEO-TONE(OFFSET) -16~+16 0
F11 RGB-CLIP 1 Chips EXTRGB-CLIP 0/1 0
F12 E-SAVE OFFSET CONTRAST(OFFSET) 0~63 30
F13 FAO-VOL 1 Chips A-ATT 0~127 120
F14 PIF-G 1 Chips VIF-GAIN 0~7 4
F15 Y-DELAY(TV) 1 Chips Y-DELAY 0~7 0
F16 Y-DELAY(AV) 1 Chips Y-DELAY 0~7 0
F17 Y-DELAY(SAV) 1 Chips Y-DELAY 0~7 0
F18 Y-DELAY(YUV) 1 Chips Y-DELAY 0~7 0
F19 TINT-AV OFFSET TINT(OFFSET) -32~+32 0
F20 TINT-SAV OFFSET TINT(OFFSET) -32~+32 0
F21 COL-AV OFFSET COLOR(OFFSET) -32~+32 0
F22 COL-SAV OFFSET COLOR(OFFSET) -32~+32 0
F23 R-DRI(R2) OFFSET R-DRI(OFFSET) -32~+32 0
F24 R-DRI( R) OFFSET R-DRI(OFFSET) -32~+32 0
F25 R-DRI(B) OFFSET R-DRI(OFFSET) -32~+32 0
F26 B-DRI(R2) OFFSET B-DRI(OFFSET) -32~+32 0
F27 B-DRI( R) OFFSET B-DRI(OFFSET) -32~+32 0
F28 B-DRI(B) OFFSET B-DRI(OFFSET) -32~+32 0
F29 V-FREE 1 Chips V-FREE 0/1 0
F30 GAMMA 1 Chips GAMMA 0~3 0
F31 TRAP(TV) 1 Chips TRAP-FINE 0~3 2
F32 TRAP(AV) 1 Chips TRAP-FINE 0~3 2
F33 H-FREE 1 Chips H-FREE 0/1 0
F34 1W(TV) 1 Chips V.WINDOW 0/1 0
F35 1W(AV) 1 Chips V.WINDOW 0/1 0
F36 YLPF 1 Chips YSW-LPF 0/1 1
F37 BS-D 1 Chips BS-DISCHARGE 0~3 0
F38 BS-C 1 Chips BS-CHARGE 0~3 0
F39 SL(TV) 1 Chips S-SLICE DOWN 0~3 0
F40 SL(AV) 1 Chips S-SLICE DOWN 0~3 0
F41 SL(SAV) 1 Chips S-SLICE DOWN 0~3 0
F42 SL(YUV) 1 Chips S-SLICE DOWN 0~3 0
F43 AFC2 1 Chips AFC2-G 0/1 0
F44 VD(TV) 1 Chips VSYNC-DET 0/1 0
F45 VD(AV) 1 Chips VSYNC-DET 0/1 0
F46 AS(TV) 1 Chips AUTO-SLICE 0/1 0
F47 AS(AV) 1 Chips AUTO-SLICE 0/1 0
F48 AS(SAV) 1 Chips AUTO-SLICE 0/1 0
F49 AS(YUV) 1 Chips AUTO-SLICE 0/1 0
F50 FBP(TV) 1 Chips FBP VTH 0/1 0
F51 FBP(AV) 1 Chips FBP VTH 0/1 0
F52 FBP(SAV) 1 Chips FBP VTH 0/1 0
F53 FBP(YUV) 1 Chips FBP VTH 0/1 0
F54 C.CLIP LEVEL 1 Chips C.CLIP LEVEL 0/1 0

1 Chips V-TONE 0/1 0

21FL84

9

21FL84

Setting Mode Items (Continued)

No. Item Name IC Register Range Default

F55 PSW MTS PSW 0/1 0
F56 FAO-VOL MTS VOL 0~63 60
F57 CP PLL CHARGE PUMP 0/1 0
F58 CC LEVEL MICON CC LEVEL 0/1 0
F59 OSD POS MICON OSD POS 0/1 0
F60 OFFSET-ADJ-COL 1 Chips COLOR -32~+32 0
F61 OFFSET-ADJ-TINT 1 Chips TINT -32~+32 0
F62 OFFSET-ADJ-TINT-YUV 1 Chips BASEBAND-TINT -32~+32 0
F63 TIMER4-LOW SPEED 1 Chips TIMER4 VALUE 0~225 50
F64 TIMER4-HIGH SPEED 1 Chips TIMER4 VALUE 0~225 125
F65 R-CUT-YUV 1 Chips R-CUT(OFFSET) -63~+63 0
F66 G-CUT-YUV 1 Chips G-CUT(OFFSET) -63~+63 0
F67 B-CUT-YUV 1 Chips B-CUT(OFFSET) -63~+63 0
F68 R-DRI-YUV 1 Chips R-DRI(OFFSET) -63~+63 0
F69 B-DRI-YUV 1 Chips B-DRI(OFFSET) -63~+63 0
F70 CLOCK-ADJ 1 Chips 0~25 25

10

Option Mode Items

21FL84

No
001 DEMO Without DEMO With DEMO 1
002 DOWNLOAD Without V-CHIP OP With V-CHIP OP 0
003 V-CHIP Without V-CHIP With V -CHIP 0
004 SPEAKER Without SPEAKER With SPEAKER 1
005 FAO Without FAO With FAO 1
006 P.PREF Without P.REF With P.REF 1
007 UNIV+ Without UNIV+ With UNIV+ 1
008 VIEW TIMER Without VIEW TIMER With VIEW TIMER 1
009 EZ-SETUP EZ-SETUP AUTO PRESET 0
010 PON-CH Without POWER-ON With POWER-ON 0
011 FAV-COL FAV-COL COL-TEMP 1
012 COMPONENT Without COMPONENT With COMPONENT 1
013 AV Without AV With AV 1
014 AV2 AV1 system AV2 system 1
015 MTS Without MTS With MTS 1
016 TONE-CTRL Without S-ADJ With S-ADJ 1
017 AUTO-OFF Without AUTO-OFF With AUTO-OFF 1
018 INIT-LANG ENGLISH SPANISH 1
019 SETUP-FLAG NO SET UP AUTO SET UP 1
020 AV-FR
021 AV3/S-IN Without AV3/S-IN With AV3/S-IN 0
022 COMB Without COMB With COMB 0
023 AUTO-INPUT Without AUTO-INPUT With AUTO-INPUT 1
024 CLOCK Without CLOCK With CLOCK 1
025 LED SEMEX MODEL SPC MODEL 0
026 FLAT Not FLAT MODEL FLAT MODEL 1
027 BASS BOOST Without BASS BOOST With BASS BOOST 0
028 DSE Without DSE With DSE 0
029 SRS Without SRS With SRS 0

030 WHITE-OUT Without WHITE-OUT With WHITE-OUT 1

OPTION FUNCTION

01

"0"=NO AV "1"=REAR "2"=FRONT "3"=REAR & FRONT

Default Data

3

Check Mode

Micron mask version, software version and ROM correction function status are displayed in check mode.

11

21FL84

ADJUSTMENT METHOD

Caution:to get into the service mode, one of the ways is press direct key for service items. the other ways

is short the main chassis JA301 and JA410

There is three stage of Service Mode data

First stage data from V01 ~ M06
to go into second stage of service mode data, press MENU key
Second stage data from F01 ~ F70
to go into third stage of service mode data, press MENU key

Third stage data from 001 ~ 030
Below is the contents of these data
First Stage

Data Service Mode Function Range Default Data

V01 SUB-PICTURE CONTRAST 0~127 127
V02 SUB-TINT TINT 0~127 64
V03 SUB-COLOR COLOR 0~127 64
V04 SUB-BRIGHT BRIGHT 0~255 128
V05 SUB-SHARP VIDEO-TONE 0~63 32
V06 V-SHIFT V-SHIFT 0~7 4
V07 H-SHIFT H-PHASE 0~31 16
V08 RF-AGC RF-DELAY 0~127 127
V09 V-SIZE V-SIZE 0~63 32
V10 PIF-VCO VIF-VCO 0~63 32
V11 R-CUTOFF R-CUTOFF 0~255 127
V12 G-CUTOFF G-CUTOFF 0~255 127
V13 B-CUTOFF B-CUTOFF 0~255 127
V14 R-DRIVE R-DRIVE 0~127 64
V15 B-DRIVE B-DRIVE 0~127 64
V16 SUB-COLOR(YUV) COLOR 0~127 64
V17 SUB-TINT(YUV) BASEBAND-TINT 0~127 64
V18 CC-POS CC-POS 0~255 32
V19 SCREEN CUT OFF CUT OFF 0~2 0
V20 SUB-VOL A-ATT 0~127 127
V21 H-VCO H-VCO 0~7 4
M01 MTS-ATT ATT (MTS) 0~15 10
M02 MTS-VCO VCO (MTS) 0~63 32
M03 MTS-FILTER FILTER (MTS) 0~63 28
M04 MTS-WIDEBAND WIDEBAND (MTS) 0~63 27
M05 MTS-SPECTRAL SPECTRAL (MTS) 0~63 32
M06 SUB-VOL VOL (MTS) 0~63 63

Auto Adjustment Item

1. H-VCO

2. RF-AGC

3. PIF-VCO

12

Second Stage

Data Service Mode Function Range Default Data

F01 VIDEO TONE -GAIN (TV) V-TONE 0/1 0
F02 VIDEO TONE -GAIN (AV) V-TONE 0/1 0
F03 VIDEO TONE -GAIN (S-AV) V-TONE 0/1 0
F04 VIDEO TONE -GAIN(YUV) V -T ONE 0/1 0
F05 ABCL ABCL 0/1 0
F06 BS BS-OFF 0/1 0
F07 ABCL-G ABCL-G 0/1 0
F08 SHP-AV VIDEO-TONE(OFFSET) -16~+16 0
F09 SHP-SAV VIDEO-T ONE(OFFSET) -16~+16 0
F10 SHP-YUV VIDEO-TONE(OFFSET) -16~+16 0
F11 RGB-CLIP EXTRGB-CLIP 0/1 0
F12 E-SAVE CONTRAST(OFFSET) 0~63 30
F13 FAO-V OL A-A TT 0~127 120
F14 PIF-G VIF-GAIN 0~7 4
F15 Y -DELAY(TV) Y -DELAY 0~7 0
F16 Y -DELAY(A V) Y -DELAY 0~7 0
F17 Y -DELAY(SAV) Y -DELAY 0~7 0
F18 Y -DELAY(YUV) Y-DELA Y 0~7 0
F19 TINT -A V TINT(OFFSET) -32~+32 0
F20 TINT -SA V TINT(OFFSET) -32~+32 0
F21 COL-AV COLOR(OFFSET) -32~+32 0
F22 COL-SAV COLOR(OFFSET) -32~+32 0
F23 R-DRI(R2) R-DRI(OFFSET) -32~+32 0
F24 R-DRI( R) R-DRI(OFFSET) -32~+32 0
F25 R-DRI(B) R-DRI(OFFSET) -32~+32 0
F26 B-DRI(R2) B-DRI(OFFSET) -32~+32 0
F27 B-DRI( R) B-DRI(OFFSET) -32~+32 0
F28 B-DRI(B) B-DRI(OFFSET) -32~+32 0
F29 V-FREE V-FREE 0/1 0
F30 GAMMA GAMMA 0~3 0
F31 TRAP(TV) TRAP-FINE 0~3 2
F32 TRAP(AV) TRAP-FINE 0~3 2
F33 H-FREE H-FREE 0/1 0
F34 1W(TV) V.WINDOW 0/1 0
F35 1W(AV) V.WINDOW 0/1 0
F36 YLPF YSW-LPF 0/1 1
F37 BS-D BS-DISCHARGE 0~3 0
F38 BS-C BS-CHARGE 0~3 0
F39 SL(TV) S-SLICE DOWN 0~3 0
F40 SL(AV) S-SLICE DOWN 0~3 0
F41 SL(SAV) S-SLICE DOWN 0~3 0
F42 SL(YUV) S-SLICE DOWN 0~3 0
F43 AFC2 AFC2-G 0/1 0
F44 VD(TV) VSYNC-DET 0/1 0
F45 VD(AV) VSYNC-DET 0/1 0
F46 AS(TV) AUTO-SLICE 0/1 0
F47 AS(AV) AUTO-SLICE 0/1 0
F48 AS(SAV) AUTO-SLICE 0/1 0
F49 AS(YUV) AUTO-SLICE 0/1 0
F50 FBP(TV) FBP VTH 0/1 0
F51 FBP(AV) FBP VTH 0/1 0
F52 FBP(SAV) FBP VTH 0/1 0
F53 FBP(YUV) FBP VTH 0/1 0
F54 C.CLIP LEVEL C.CLIP LEVEL 0/1 0
F55 PSW PSW 0/1 0
F56 FAO-VOL VOL 0~63 60

21FL84

13

21FL84

Second Stage (Continued)

Data Service Mode Function Range Default Data

F57CPCHARGE PUMP0/101
F58CC LEVELCC LEVEL0/10
F59 OSD POS OSD POS 0/1 0
F60OFFSET-ADJ-COLCOLOR-32~+32 +10
F61OFFSET-ADJ-TINTTINT-32~+32 +8
F62OFFSET-ADJ-TINT-YUVBASEBAND-TINT-32~+32 -12
F63 TIMER4-LOW SPEED TIMER4 VALUE 0~225 50
F64TIMER4-HIGH SPEEDTIMER4 VALUE0~225125
F65R-CUT-YUVR-CUT(OFFSET)-63~+630
F66G-CUT-YUVG-CUT(OFFSET)-63~+63 +36
F67B-CUT-YUVB-CUT(OFFSET)-63~+63 +2
F68R-DRI-YUVR-DRI(OFFSET)-63~+630
F69 B-DRI-YUV B-DRI(OFFSET) -63~+63 0
F70 CLOCK-ADJ 0~25 25

Third Stage

Data OPTION FUNCTION DATA = "0" DATA ="1" Default Data

001 DEMO DEMO DISABLE ENABLE 1
002 DOWNLOAD V-CHIP OP DISABLE ENABLE 0
003 V-CHIP V-CHIP DISABLE ENABLE 0
004SPEAKERSPEAKER DISABLEENABLE0
005FAOFAO DISABLEENABLE0
006P.PREFP.REF DISABLEENABLE0
007UNIV+UNIV+ DISABLEENABLE0
008VIEW TIMERVIEW TIMER DISABLEENABLE1
009 EZ-SETUP EZ-SETUP AUTO PRESET 0
010 * PON-CH POWER-ON DISABLE ENABLE 0
011FAV-COLFAV-COLCOL-TEMP1
012COMPONENTCOMPONENT DISABLEENABLE0
013AVAV DISABLEENABLE1
014AV2AV1AV21
015MTSMTS DISABLEENABLE0
016TONE-CTRLS-ADJ DISABLEENABLE0
017 AUTO-OFF AUTO-OFF DISABLE ENABLE 1
018 INIT-LANG ENGLISH SPANISH 1
019 SETUP-FLAG NO SET UP AUTO SET UP 1
020 AV-FR
021 AV3/S-IN AV3/S-IN DISABLE ENABLE 0
022 COMB COMB DISABLE ENABLE 0
023 AUTO-INPUT AUTO-INPUT DISABLE ENABLE 1
024 CLOCK CLOCK DISABLE ENABLE 1
025 LED SEMEX MODEL SPC MODEL 0
026 FLAT FLAT DISABLE ENABLE 1
027 BASS BOOST BASS BOOST DISABLE ENABLE 0
028 DSE DSE DISABLE ENABLE 0
029 SRS SRS DISABLE ENABLE 0
030 WHITE-OUT WHITE-OUT DISABLE ENABLE 1

"0"=NO AV "1"=REAR "2"=FRONT "3"=REAR & FRONT

3

*

*POWER ON BY CH-UP/CH-DOWN KEY

14

CHASSIS LAYOUT

H

G

F

21FL84

E

D

C

B

A

654321

15

21FL84

MAIN BLOCK DIAGRAM

J

I

H

G

F

E

D

C

B

A

12345678910

16

21FL84

10 11 12 13 14 15 16 17 18 19

17

654321

A

B

C

D

E

F

G

H

21FL84

CRT BLOCK DIAGRAM

18

DESCRIPTION OF SCHEMATIC DIAGRAM

21FL84

NOTES:

1. The unit of resistance "ohm" is omitted.
(K=kΩ=1000Ω, M=MΩ)

2. All resistors are 1/16 watt, unless otherwise noted.

3. All capacitors are µF, unless otherwise noted.
(P=pF=µµF)

4. (G) indicates ±2% tolerance may be used.

5.

indicates line isolated ground.

VOLTAGE MEASUREMENT CONDITIONS:

1. All DC voltages are measured with DVM connected
between points indicated and chassis ground, line
voltage set at 120V AC and all controls set f or normal
picture unless otherwise indicated.

µ

2. All voltages measured with 1000
signal.

V B & W or Color

WAVEFORMS

WAVEFORM MEASUREMENT CONDITIONS:

1.

Photographs taken on a standard gated color bar
signal, the tint setting adjusted for proper color. The
wave shapes at the red, green and blue cathodes of
the picture tube depend on the tint, color level and
picture control.

2.

indicates waveform check points (See chart,

waveforms are measured from point indicated to
chassis ground.)

å

AND SHADED ( ) COMPONENTS
= SAFETY RELATED PARTS.

ç

MARK= X-RAY RELATED PARTS.

DRGANNES MARQUES
PIECES RELATIVES A LA SECURITE.
MARQUE

This circuit diagram is a standard one, printed circuits
may be subject to change for product improvement
without prior notice.

ç

: PIECS RELATIVE AUX RAYONS X.

å

ET HACHRES ( ):

19

21FL84

SCHEMATIC DIAGRAM: MAIN-1 Unit

H

G

F

E

D

C

B

A

1

2

3

4

5

6

7

98

10

20

21FL84

21

1716 1918151413121110

21FL84

H

G

F

SCHEMATIC DIAGRAM: CRT Unit

E

D

C

B

A

654321

22

PRINTED WIRING BOARD ASSEMBLIES

H

G

F

21FL84

E

D

C

B

PWB-A: MAIN Unit (Wiring Side)

A

654321

23

654321

A

B

C

D

E

F

G

H

21FL84

Z1 A1

RJ8

FDC2

Z3

R617

R613

RJ15

RJ14

R1027

RJ16

R1024

RJ17

C1016

RJ31

RJ32

R626

R624

R623

R618

R1006

R1008

R1009

R1003

R1007

R303

R714

R1081

R709

Q702

Q701

R707

RJ3

R662

RJ30

Q604

R528

R520

C519

C518

R504

RJ9

R432

R431

IC402

R438

RJ21RJ6

C439

R1002

R314

R315

C313

R305

C308

R307

R308

R1802

R801

Q801

R1043

C1004

RJ10R1072

IC1003

RJ12

RJ18C1015

R437

R846

IC403

C401

RJ19

C436

RJ2

R462

IC401

Q803

R377

R353

R372

R374

R378

R363

R458

C453R362

R461

R1083

Q1072

R1079

Q1070

Q1073

R1895

R1896

D801

C808

D810

R840R843

R804

C809

D811

R1851

R1852

D812R805

R806

R1853

C810

RJ29

R807

C814

R1063

R842

Q804

R817

C1009

C1011

C1013

R1064

R1065

C1855

R1066

R1074

R1032

R1098R1097

R373

IC305

R366

R365

R433

R1056

Q1002

R1085

R1078

R1087

R1849

R827

Q805

R821

R831

C845

R835RJ26

R839

C846

R828

C804

FDC3

R802

C802

C806R1850

R803

IC801

R847

R1062

C815

C816

R812

C819

R816

R814

C821

R832

R815

C823

C826

R1061

C1008

D1086

R1055

R1048

R1047

D1089

D1085

IC1001

R1059

R1096

R1044

R1037

R1036

R1076

R1034

R1033

R1090

R1091

R1038

C1864

C1862R1046

R1867R1049

R1041

C1861

C1863

C205

R1861

R435

R1862

R434

R384

R383

R3006

IC3002

C3081

C839

R833

C847RJ4

C841

C1867

C836

R845

C832

R853C85 3

C833

C831

R844

C830

C828

R1854

C1856

R1077

R301

Q1001

R1039

RJ11

RJ5

R213

IC1007

Q202

R206

Q201

R208

C207

R205

C209

R212

C213R209

C212C1896

RJ27

D202

RJ28

C203

R201

R202

B1

R381

R382

FDC1

RJ24

R3009

RJ23

RJ13

RJ25

RJ20R44 1

R439

R220

C208

R207

R440

RJ22

C210

R210

RJ7

R211

R830

Z2

A2

RJ1

PWB-A: MAIN Unit (Chip Parts Side)

24

21FL84

H

G

F

E

D

C

PWB-B: CRT Unit (Wiring Side)

B

A

654321

25

21FL84

)

Ref. No. Part No. « Description Code

PARTS LIST

PARTS REPLACEMENT

Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.

"HOW TO ORDER REPLACEMENT PARTS"

To have your order filled promptly and correctly, please furnish the
following informations.

1. MODEL NUMBE

3. PART NO.4. DESCRIPTION

in USA:Contact your nearest SHARP Parts Distributor to order.

For location of SHARP Parts Distributor, Please call Toll­Free; 1-800-BE-SHARP

p MARK: SPARE PARTS-DELIVERY SECTION

U

Ref. No. Part No. « Description Code

VB51QDK191X1E X Picture Tube CA

p U L706 RCILG0069PEZZ X Degaussing Coil AL

QEARCA012WJZZ X Grounding Strap AE

With CRT Combination

Alt. CRT Description & Destination

1 VB51QDK191X1E — ORION CHI/PER
2 VB51QDK190X2E — ORION MX/COL
3 VB51QDX993X3E — Samsung (CHI/PERU)
4 VB51QDX993X2E — Samsung (MEX/COL

PRINTED WIRING BOARD ASSEMBLIES

(NOT REPLACEMENT ITEM)

PWB-A DUNTKC522WEA2 — MAIN Unit —
PWB-B DUNTKA599WED5 — CRT Unit —

R2. REF. NO.

MARK: X-RAY RELATED PARTS

PICTURE TUBE

PWB-A: DUNTKC522WEA2

MAIN UNIT

TUNER

NOTE:THE PARTS HERE SHOWN ARE SUPPLIED AS AN

ASSEMBLY BUT NOT INDEPENDETLY

U TU201 VTUVT1T5UF202 X Tuner AS

INTEGRATED CIRCUITS

IC301 VHIAN7523++-1 X AN7523++ AF
IC402 VHIMM1501XN-1Y X MM1501XN AD

U IC501 VHISTV9302A-1 X STV9302A AF

IC601 VHIKA78R09AP1 X KIA78R09API AE

U IC701 VHISTRW6753-1 X STR-W6753 AL
U IC702 RH-FXA003WJZZ X PC123Y82 AC
U IC703 VHISE125N++-F X SE125N AF

IC801 VHIM61250CF1EQ X M61250BFP-R71T AQ
IC1001 RH-IXA983WJZZ X RU3AMLF-C4 AN
IC1003 VHIBR24L04F-1Y X BR24L04F-WE2 AD
IC3002 VHIMM1501XN-1Y X MM1501XN AD

TRANSISTORS

Q201 VS2SC2735//1EY X 2SC2735 AB
Q601 VS2SC2235Y/1E+ X 2SC2235-Y AE
Q602 VSTT2140+++-F X TT2140LS AF
Q603 VS2SC3198-G-1+ X 2SC3198-G AB
Q604 VS2SD601AR/-1Y X 2SD601AR AA
Q751 VS2SD468-C/-1+ X 2SD468ACTZ AB
Q752 VS2SD468-C/-1+ X 2SD468ACTZ AB
Q753 VS2SC3198-G-1+ X 2SC3198-G AB
Q754 VS2SD468-C/-1+ X 2SD468ACTZ AB
Q801 VS2SD601AR/-1Y X 2SD601AR AA
Q804 VS2SB709AR/-1Y X 2SB709AR AA
Q805 VS2SD601AR/-1Y X 2SD601AR AA
Q853 VS2SC3789//2E X 2SC3789 AD
Q1002 VS2SD601AR/-1Y X 2SD601AR AA
Q1073 VS2SD601AR/-1Y X 2SD601AR AA

DIODES

D201 RH-EX0676GEZZY X Zener Diode 32V AB
D203 VHD1SS119//-1Y X Diode AA
D392 RH-DX0452CEZZ X Diode AF
D502 VRD-RA2BE103JY X 10k 1/8W Carbon AA
D503 RH-EX0612GEZZY X EX0612GE AB
D505 RH-DX0441CEZZY X Diode AA
D510 RH-DX0131CEZZY X Diode AB
D601 VHD1SS119//-1Y X Diode AA
D602 VHD1SS244//-1Y X Diode AA
D603 RH-EX0667GEZZY X Zener Diode 27V AB
D606 RH-DX0131CEZZY X Diode AB

U D701 RH-DX0476CEZZ X Diode AE

D702 RH-DX0490CEZZY X Diode AB
D703 VHD1SS119//-1Y X Diode AA
D704 RH-EX0650GEZZY X Zener Diode 16V AB
D705 RH-DX0066GEZZY X Diode AC
D706 RH-DX0066GEZZY X Diode AC
D707 RH-DX0066GEZZY X Diode AC
D708 RH-EX0621GEZZY X Zener AB
D710 VHD1SS119//-1Y X Diode AA
D714 VHD1SS119//-1Y X Diode AA
D716 RH-EX0601GEZZY X Zener Diode, 3.7V AB
D751 RH-DXA006WJZZ X Diode AC
D752 RH-DX0247CEZZ X Diode AC
D801 RH-EX1393CEZZY X EX1393CE AB
D802 RH-EX0630GEZZY X Zener Diode 9.1V AB
D803 VHD1SS119//-1Y X Diode AA
D806 VHD1SS119//-1Y X Diode AA
D810 RH-EX0263TAZZY X EX0263TA AB
D811 RH-EX0263TAZZY X EX0263TA AB
D812 RH-EX0263TAZZY X EX0263TA AB
D1001 RH-PX0013PEZZ X LED, ON TIMER AB

26

21FL84

Ref. No. Part No. « Description Code

PWB-A: DUNTKC522WEA2

MAIN UNIT

D1081 VHD1SS119//-1Y X Diode AA
D1085 RH-EX1393CEZZY X EX1393CE AB
D1086 RH-EX1393CEZZY X EX1393CE AB
D1089 RH-EX1393CEZZY X EX1393CE AB
D1091 VHD1SS119//-1Y X Diode AA
D1094 VHD1SS119//-1Y X Diode AA
D1095 VHD1SS119//-1Y X Diode AA
D1801 VHD1SS119//-1Y X Diode AA
VA701 RH-VX0073CEZZ X Varistor AC

U PR701 RMPTP0001PEZZ X Packaged Circuit AG
U R751 RR-DZ0049CEZZY X 3.9M 1/2W Solid AB
U R752 RR-DZ0049CEZZY X 3.9M 1/2W Solid AB

X801 RCRSAA009WJZZ X Crystal, AD

CF201 RFILC0447CEZZ X Filter,FiLC0447CE AC
CF802 RFILC0446CEZZ X Filter,FiLC0446CE AC
SF201 RFILC0405CEZZ X Filter (4.5MHZ) AF

L203 VP-DF270K0000Y X Peaking,27mH AA
L204 VP-XF1R2K0000Y X Peaking,1.2mH AA
L602 RCILP0223CEZZ X Coil, AB
L701 RCILFA060WJZZ X AE
L751 RCILP0179CEZZ+ X Coil AB
L801 VP-DF100K0000Y X Peaking,10mH AA
L802 VP-DF100K0000Y X Peaking,10mH AA
L803 VP-DF100K0000Y X Peaking,10mH AA
L804 VP-XF150K0000Y X Peaking,15mH AA
L806 VP-DF100K0000Y X Peaking,10mH AA
L807 VP-XF1R2K0000Y X Peaking,1.2mH AA

U T602 RTRNFA095WJZZ X H-Volt Transformer AV
U T603 RTRNZA058WJZZ X Transformer AD
U T701 RTRNWA137WJZZ X Transformer AH

[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]

C201 VCEA0A1CW476M+ X 47 16V EL. AA
C202 VCEA0A0JW108M+ X 1000 6.3V EL. AB
C203 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C205 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C206 VCEA0A1HW106M+ X 10 50V EL. AA
C207 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C208 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C209 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C210 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C213 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C301 VCEA0A1CW477M+ X 470 16V EL. AB
C304 VCEA0A1CW106M+ X 10 16V EL. AA
C305 QJUM-0001AJFWY X Jumper Wire AA
C310 VCEA0A1HW105M+ X 1 50V EL. AA
C312 VCEA0A1HW224M+ X 0.22 50V EL. AA
C313 VCKYCY1HB822KY X 8200p 50V Ceramic AA
C317 VCE9GA1CW106M+ X 10 16V EL. AB
C318 VCEA0A1CW107M+ X 100 16V EL. AA
C322 VCEA0A1HW105M+ X 1 50V EL. AA
C391 VCKYPA1HB102K+ X 1000p 50V Ceramic AA
C392 VCQYTA1HM103J+ X 0.01 50V Mylar AA
C393 VCEA0A1EW108M+ X 1000 25V EL. AC
C435 VCE9GA1CW106M+ X 10 16V EL. AB
C437 VCE9GA1HW106M+ X 10 50V EL. AC
C438 VCEA0A1CW106M+ X 10 16V EL. AA
C439 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C452 VCE9GA1CW106M+ X 10 16V EL. AB

DIODES

PACKAGED CIRCUITS

FILTERS

COILS

Coil Line Filter

TRANSFORMERS

CAPACITORS

Ref. No. Part No. « Description Code

C505 VCEA0A1HW107M+ X 100 50V EL. AB
C508 VCFYAA2AA224J+ X 0.22 100V M-Poly. AC
C511 VCEA0A1VW477M X 470 35V EL. AC
C512 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C513 RC-EZA332WJZZ+ X 1000 35V EL. AC
C514 VCFYSA1JB273J+ X 0.027 63V M-Poly. AB
C515 VCEACA1HC335J+ X 3.3 50V EL. AC
C518 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C601 VCQYTA1HM563J+ X 0.056 50V Mylar AA
C602 VCEA0A1HW475M+ X 4.7 50V EL. AA
C603 VCEA0A1HW105M+ X 1 50V EL. AA
C604 VCEA0A2EW336M+ X 33 250V EL. AD
C606 VCKYPA2HB102K+ X 1000p 500V Ceramic AA

U C607 VCFPVC3ZA912H X 9100p 1800 V M.Poly. AC

C608 VCQYTA2AA103K+ X 10000p 100V Mylar AB
C610 VCEA0A1EW227M+ X 220 25V EL. AB
C611 VCFPVC2DB334J X 0.33 250V M-Poly. AC
C642 VCEA0A1EW476M+ X 47 25V EL. AA
C643 VCEA0A1AW477M+ X 470 10V EL. AB
C650 VCKYPA2HB101K+ X 100p 500V Ceramic AA

U C701 RC-FZ029SCEZZ X 0.22 250V Ceramic AC

C702 RC-KZ0029CEZZ+ X 0.01 AC250V Ceramic AB
C703 RC-KZ0029CEZZ+ X 0.01 AC250V Ceramic AB
C704 RC-KZ0029CEZZ+ X 0.01 AC250V Ceramic AB

U C705 RC-EZA097WJZZ X 220 400V EL. AK

C706 VCEA0A1VW226M+ X 22 35V EL. AA
C708 VCKYPA1HB471K+ X 470p 50V Ceramic AA
C709 VCEA9M1HW105M+ X 1 50V EL. AA
C710 VCFYFA1HA104J+ X 0.1 50V M-Poly. AB
C711 VCKYPA1HB681K+ X 680p 50V Ceramic AA
C718 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C743 VCKYPH3DB561K X 560p 2kV Ceramic AB
C750 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C751 RC-KZ0106GEZZ X 3300p AC250V Ceramic AC
C752 VCKYPH3DB561K X 560p 2kV Ceramic AB
C753 RC-EZ0724CEZZ X 100 160V EL. AD
C754 RC-EZ0638CEZZ X 33 160V EL. AD
C755 VCQYTA1HM103J+ X 0.01 50V Mylar AA
C756 VCEA0A1EW228M+ X 2200 25V EL. AD
C757 VCKYPA1HB471K+ X 470p 50V Ceramic AA
C784 RC-KZ1018CEZZ+ X 1000p 2kV Ceramic AC
C801 VCFYFA1HA105J+ X 1 50V M-Poly. AC
C802 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C803 VCEA9M1CW476M+ X 47 16V EL. AB
C804 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C805 VCEA0A1HW105M+ X 1 50V EL. AA
C806 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C807 VCEA0A1CW337M+ X 330 16V EL. AB
C808 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C809 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C810 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C811 VCEA9M1CW106M+ X 10 16V EL. AA
C814 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C815 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C816 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C817 VCEA9M1CW107M+ X 100 16 V EL. AB
C818 VCEA9M1HW475M+ X 4.7 50V EL. AA
C819 VCCCCY1HH121JY X 120p 50 V Ceramic AA
C820 VCEA9M1HW474M+ X 0.47 50V EL. AA
C821 VCKYCY1HF153ZY X 0.015 50V Ceramic AA
C822 VCE9GA1HW105M+ X 1 50V EL. AB
C823 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C824 VCEA0A1CW337M+ X 330 16V EL. AB
C825 VCE9GA1HW105M+ X 1 50V EL. AB
C826 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C827 VCEA0A1CW476M+ X 47 16V EL. AA
C828 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C829 VCEA9M1CW476M+ X 47 16V EL. AB
C831 VCKYCY1CF224ZY X 0.22 16V Ceramic AA

27

21FL84

Ref. No. Part No. « Description Code

PWB-A: DUNTKC522WEA2

MAIN UNIT

CAPACITORS

[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]

C833 VCKYCY1CF224ZY X 0.22 16V Ceramic AA
C834 VCEA0A1CW107M+ X 100 16V EL. AA
C835 VCEA0A1CW106M+ X 10 16V EL. AA
C836 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C837 VCEA9M1HW105M+ X 1 50V EL. AA
C838 VCEA9M1CW106M+ X 10 16V EL. AA
C839 VCKYCY1HB332KY X 3300p 50V Ceramic AA
C840 VCFYFA1HA105J+ X 1 50V M-Poly. AC
C841 VCCCCY1HH101JY X 100p 50V Ceramic AA
C842 VCEA9M1HW474M+ X 0.47 50V EL. AA
C843 VCEA0A1HW105M+ X 1 50V EL. AA
C845 VCKYCY1CF224ZY X 0.22 16V Ceramic AA
C846 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C847 VCCCCY1HH220JY X 22p 50V Ceramic AA
C848 VCEA9M1HW105M+ X 1 50V EL. AA
C1001 VCEA0A1AW107M+ X 100 10V EL. AA
C1003 VCEA0A1CW106M+ X 10 16V EL. AA
C1004 VCKYCY1CF474ZY X 0.47 16V Ceramic AA
C1007 VCEA0A1CW107M+ X 100 16V EL. AA
C1008 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C1009 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C1011 VCKYCY1HB221KY X 220p 50V Ceramic AA
C1012 VCEA0A1HW105M+ X 1 50V EL. AA
C1013 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C1014 VCE9GA1HW475M+ X 4.7 50V EL. AB
C1015 VCCCCY1HH101JY X 100p 50V Ceramic AA
C1016 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C1020 VCEA0A0JW477M+ X 470 6.3V EL. AB
C1081 VCQYTA1HM104J+ X 0.1 50V Mylar AB
C1849 VCFYFA1HA223J+ X 0.022 50V Mylar AB
C1855 VCKYCY1HB561KY X 560p 50V Ceramic AA
C1856 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C1862 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
C1864 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
C1868 VCEA9M1CW336M+ X 33 16V EL. AA
C3080 VCEA0A1CW107M+ X 100 16V EL. AA
C3081 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C3082 VCEA0A1CW106M+ X 10 16V EL. AA
C3083 VCEA0A1CW106M+ X 10 16V EL. AA

RESISTORS

[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]

RJ1 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ3 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ5 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ9 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ10 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ12 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ13 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ14 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ17 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ18 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ19 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ20 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ25 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ26 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ29 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ30 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R201 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R202 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R205 VRS-CY1JF680JY X 68 1/16W M-Ox. AA
R206 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R207 VRS-CY1JF221JY X 220 1/16W M-Ox. AA

Ref. No. Part No. « Description Code
R208 VRS-CY1JF331JY X 330 1/16W M-Ox. AA

R209 VRS-CY1JF392JY X 3.9k 1/16W M-Ox. AA
R216 VRS-RG3LB333J+ X 33k 3.0W M-Ox. AB
R220 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R301 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R302 VRN-RL3DBR10J+ X 0.10 2W M-Film AB
R303 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R304 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R305 VRS-CY1JF274JY X 270k 1/16W M-Ox. AA
R311 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R314 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R315 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R365 VRS-CY1JF564JY X 560k 1/16W M-Ox. AA
R366 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R383 VRS-CY1JF564JY X 560k 1/16W M-Ox. AA
R384 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R431 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R432 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R436 VRD-RA2BE101JY X 100 1/8W Carbon AA
R438 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R461 VRS-CY1JF750JY X 75 1/16W M-Ox. AA
R462 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R502 VRS-RG3AB102J+ X 1k 1W M-Ox. AB
R503 VRN-RL3DB1R2J+ X 1.2 2W M-Film AB
R504 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R506 VRS-RG3AB331J+ X 330 1W M-Ox. AB
R507 VRD-RM2HD1R0JY X 1 1/2W Carbon AA
R513 VRD-RM2HD333JY X 33k 1/2W Carbon AA
R514 VRD-RM2HD682JY X 6.8k 1/2W Carbon AA
R520 VRS-CY1JF123JY X 12k 1/16W M-Ox. AA
R524 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R525 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R526 VRD-RA2BE101JY X 100 1/8W Carbon AA
R528 VRS-CY1JF683JY X 68k 1/16W M-Ox. AA
R601 VRD-RM2HD820JY X 82 1/2W Carbon AA
R602 VRD-RA2BE393JY X 39k 1/8W Carbon AA
R603 VRD-RA2BE273JY X 27k 1/8W Carbon AA
R604 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R605 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R607 VRD-RM2HD121JY X 120 1/2W Carbon AA

U R608 VRD-RM2HD102JY X 1.0k 1/2W Carbon AA

R609 VRD-RM2HD270JY X 27 1/2W Carbon AA

U R611 VRN-RL3AB1R0J+ X 1.0 1W M-Film AB
U R612 VRD-RM2HD270JY X 27 1/2W Carbon AA

R613 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R614 VRD-RA2BE154JY X 150k 1/8W Carbon AA
R615 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R616 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R617 VRS-CY1JF123JY X 12k 1/16W M-Ox. AA
R618 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R621 VRN-RL2HC4R7J+ X 4.7 1/2W M-Film AB
R622 VRS-VV3DB682J X 6.8k 2W M-Ox. AA
R631 VRS-KT3LB391J X 390 3W M-Ox. AD
R637 VRD-RA2BE331JY X 330 1/8W Carbon AA
R638 VRD-RA2BE181JY X 180 1/8W Carbon AA
R639 VRD-RM2HD271JY X 270 1/2W Carbon AA
R642 VRN-RL3DB2R2J+ X 2.2 2W M-Film AB
R661 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R662 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R701 VRW-KQ3NC1R5K X 1.5 7W Cement AC
R702 VRD-RM2HD154JY X 150k 1/2W Carbon AA
R704 VRD-RA2BE101JY X 100 1/8W Carbon AA

U R705 VRN-RL3DBR47J+ X 0.47 2W M-Film AB
U R706 VRN-RL3DBR39J+ X 0.39 2W M-Film AB

R710 VRD-RM2HD220JY X 22 1/2W Carbon AA
R711 VRD-RA2EE122JY X 1.2k 1/4W Carbon AA
R712 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R713 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R725 VRD-RM2HD821JY X 820 1/2W Carbon AA

28

21FL84

Ref. No. Part No. « Description Code

PWB-A: DUNTKC522WEA2

MAIN UNIT

RESISTORS

[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]

R726 VRN-RL2HCR47J+ X 0.47 1/2W M-Film AB
R753 VRD-RM2HD124JY X 120k 1/2W Carbon AA
R754 VRN-RL3AB8R2J+ X 8.2 1W M-Film AB
R756 VRS-RG3DB121J+ X 120 2W M-Ox. AB
R801 VRS-CY1JF561JY X 560 1/16W M-Ox. AA
R802 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R803 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R804 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R805 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R806 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R807 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R808 VRD-RA2BE273JY X 27k 1/8W Carbon AA
R812 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R814 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R815 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R816 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R817 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R823 VRD-RA2BE101JY X 100 1/8W Carbon AA
R824 VRD-RA2BE101JY X 100 1/8W Carbon AA
R825 VRD-RA2BE101JY X 100 1/8W Carbon AA
R827 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R828 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R829 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
R830 VRS-CY1JF393JY X 39k 1/16W M-Ox. AA
R831 VRS-CY1JF271JY X 270 1/16W M-Ox. AA
R832 VRS-CY1JF822JY X 8.2k 1/16W M-Ox. AA
R833 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R835 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R836 VRD-RA2BE470JY X 47 1/8W Carbon AA
R838 VRD-RA2BE105JY X 1 M 1/8W Carbon AA
R839 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R840 VRS-CY1JF124JY X 120k 1/16W M-Ox. AA
R841 VRD-RA2BE821JY X 820 1/8W Carbon AA
R842 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R843 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R847 VRS-CY1JF475JY X 4.7M 1/16W M-Ox. AA
R1002 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R1003 VRS-CY1JF822JY X 8.2k 1/16W M-Ox. AA
R1006 VRS-CY1JF822JY X 8.2k 1/16W M-Ox. AA
R1007 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1008 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R1009 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1011 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1012 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1013 QJUM-0001AJFWY X Jumper Wire AA
R1023 VRD-RA2BE271JY X 270 1/8W Carbon AA
R1024 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R1027 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R1031 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1032 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1034 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1036 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1040 VRD-RA2BE273JY X 27k 1/8W Carbon AA
R1041 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1042 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1043 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R1044 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R1045 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1046 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R1047 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R1048 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R1049 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA

Ref. No. Part No. « Description Code

R1051 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R1054 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1055 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R1056 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R1059 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1061 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1062 VRS-CY1JF105JY X 1M 1/16W M-Ox. AA
R1063 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1064 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1065 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1066 VRS-CY1JF561JY X 560 1/16W M-Ox. AA
R1072 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R1073 VRD-RA2BE101JY X 100 1/8W Carbon AA
R1074 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1076 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R1081 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1087 VRS-CY1JF391JY X 390 1/16W M-Ox. AA
R1096 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1097 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R1098 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R1801 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
R1802 VRS-CY1JF124JY X 120k 1/16W M-Ox. AA
R1849 VRS-CY1JF152JY X 1.5k 1/16W M-Ox. AA
R1850 VRS-CY1JF472JY X 4.7k 1/16W M-Ox. AA
R1851 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R1852 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R1853 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R1854 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R1855 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R1894 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R1895 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R1896 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R3006 VRS-CY1JF101JY X 100 1/16W M-Ox. AA

FERRITE BEAD

FB601 RBLN-0091GEZZY X Ferrite Bead AA

SWITCHES

S1001 QSW-K0202PEZZ+ X Switch, AB
S1002 QSW-K0202PEZZ+ X Switch, AB
S1003 QSW-K0202PEZZ+ X Switch, AB
S1004 QSW-K0202PEZZ+ X Switch, AB
S1005 QSW-K0202PEZZ+ X Switch, AB
S1006 QSW-K0114CEZZ X Switch, AE

MISCELLANEOUS PARTS

U F701 QFS-C3229CEZZ X Fuse,T3.14AL AC
U FH701 QFSHD1013CEZZ+ X FUSE CLIP AB
U FH702 QFSHD1014CEZZ+ X FUSE CLIP AB

J402 QJAKE0108CEZZ X Jack,3Pin AD
J403 QJAKE0183CEZZ X Jack,3Pin AD
J405 QJAKF0074CEZZ X Jack, Rear AV-In AE
P302 QPLGN0461CEZZA X plug, 4pin(S1-4) AB
P601 QPLGN0660CEZZ X plug (6 PINS) AC
P602 QPLGN0461CEZZA X plug, 4pin(S1-4) AB
P603 QPLGN0361CEZZA X plug,3p (TP651-3) AB
P701 QPLGN0260CEZZ X plug,2p (M1-2) AB
P702 QPLGN0269GEZZ X plug,2p (P1-2) AB
P1001 QPLGN0561CEZZA X plug 5Pin(KA) AB
P1002 QPLGN0561CEZZ X plug (5 PINS) AB
RDA301 PRDARA121WJFW X Heat Sink AC
RDA501 PRDARA120WJFW X Heat Sink AD
RDA601 PRDARA131WJFW X Heat Sink AD
RDA602 PRDAR0337PEFW X Heat Sink AC
RDA701 PRDARA119WJFW X Heat Sink AE
RMC1001 RRMCUA009WJZZ X R/C Receiver AE

U RY701 RRLYJA006WJZZ X Relay AE

LHLDP1066PE00 X LED HOLDER AB

29

21FL84

Ref. No. Part No. « Description Code

PWB-B: DUNTKA599WED5

CRT UNIT

TRANSISTORS

Q854 VS2SC3789//2E X 2SC3789 AD
Q855 VS2SC3789//2E X 2SC3789 AD
Q894 VS2SA1015Y/1E+ X 2SA1015Y AB

DIODES

D859 VHD1SS119//-1Y X Diode AA
D898 VHD1SS119//-1Y X Diode AA

FILTERS

L851 VP-MK820K0000+ X Peaking,82mH AB

CAPACITORS

[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]

C851 VCKYPA1HB221K+ X 220p 50V Ceramic AA
C852 VCKYPA1HB221K+ X 220p 50V Ceramic AA
C853 VCKYPA1HB221K+ X 220p 50V Ceramic AA
C880 RC-KZ0153CEZZ X 1000p 3kV Ceramic AC
C893 VCEA0A1CW336M+ X 33 16V EL. AA

RESISTORS

[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]

R849 VRD-RA2BE221JY X 220 1/8W Carbon AA
R850 VRD-RA2BE470JY X 47 1/8W Carbon AA
R851 VRD-RA2BE470JY X 47 1/8W Carbon AA
R852 VRD-RA2BE470JY X 47 1/8W Carbon AA
R854 VRD-RA2BE271JY X 270 1/8W Carbon AA
R855 VRD-RA2BE271JY X 270 1/8W Carbon AA
R859 VRS-VV3DB123J X 12k 2W M-Ox. AA
R861 VRS-VV3DB123J X 12k 2W M-Ox. AA
R863 VRS-VV3DB123J X 12k 2W M-Ox. AA
R864 VRD-RA2BE470JY X 47 1/8W Carbon AA
R876 VRD-RA2BE121JY X 120 1/8W Carbon AA
R877 VRD-RA2BE121JY X 120 1/8W Carbon AA
R878 VRD-RA2BE121JY X 120 1/8W Carbon AA
R880 VRD-RM2HD332JY X 3.3k 1/2W Carbon AA
R881 VRD-RM2HD332JY X 3.3k 1/2W Carbon AA
R882 VRD-RM2HD332JY X 3.3k 1/2W Carbon AA
R889 VRD-RA2BE821JY X 820 1/8W Carbon AA
R891 VRD-RA2BE561JY X 560 1/8W Carbon AA
R892 VRD-RA2BE391JY X 390 1/8W Carbon AA
R894 VRD-RA2BE152JY X 1.5k 1/8W Carbon AA
R895 VRD-RA2BE561JY X 560 1/8W Carbon AA

MISCELLANEOUS PARTS

P860 QPLGN0461CEZZ X plug (4 PINS) AA
P880 QPLGN0561CEZZ X plug (5 PINS) AB
SC851 QSOCV0933CEZZ X SOCKET (CRT) AD

MISCELLANEOUS PARTS

ACC701 QACCZA020WJPZ X AC Cord AG
SP301 VSP1205PB09WA X SPEAKER AM

LHLDK0014PEZZ X AC CORD HOLDER AB
QCNW-A871WJZZ X Wire (H) 5 pin AD
QCNW-A872WJZZ X Wire (K) 4 pin AD
QCNW-A873WJZZ X Wire (speaker) AE

Ref. No. Part No. « Description Code

PACKING PARTS

SPAKCB492WJZZ X PACKING CASE AU
SPAKPA125WJZZ X LAMIN FOAM AG
SPAKXA145WJZZ X PACKING FOAM AM
SSAKA0101GJZZ X Plastic Bag AB
TLABM0005GJZZ X Model Label AC
TLABZA714WJZZ X POP LABEL AE

SUPPLIED ACCESORRIES

TINS-B272WJZZ X Operation manual AF
RRMCGA257WJSA X Infrared R-C Unit AM

CABINET PARTS

1 CCABAA659WEH1 X Front Cabinet Ass'y BF
1-1 Not Avairable — Front Cabinet —
1-2 HBDGB3155CESA X BADGE AE
1-3 HDECQA403WJSA X COVER (LED & R/C) AL
1-4 JBTN-A070WJKD X BUTTON (POWER) AE
1-5 MSPRC0005PEFW X SPRING AA
1-6 GDORFA015WJKD X DOOR (20F640) AF
1-7 MSPRPA012WJFW X SPRING (DOOR) AB
1-8 HINDPA213WJSA X INDICATION PLATE AD
1-9 GBFL-A007WJZZ X SPEAKER HOLDER AE

2 GCABBA099WJKA X REAR CABINET AZ

1-1

1

2

9

1-4 1-5

1-3

1-2

30

1-6

1-7

1-8

PACKING OF THE SET

21FL8421FL84

31

- M E M O -

21FL84

32

21FL84

COPYRIGHT © 2004 BY SHARP CORPORATION

ALL RIGHTS RESERVED.

No part of this publication may be reproduced,
stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without
prior written permission of the publisher.

QRC0008-L
June. 2004

Modify : SEMEX

Design and Production Information

Design : SEM
Production : SEMEX

J B

SHARP ELECTRONICA MEXICO S. A. DE C. V.
Quality & Reliability Control Center
Blvd. SHARP No. 3510 Parque Industrial Rosarito
Playas de Rosarito, México B. C. 22710
