Digital 6000
Instruction manual
Sennheiser electronic GmbH & Co. KG
Am Labor 1, 30900 Wedemark, Germany, www.sennheiser.com
Digital 6000 - v3.4
The Digital 6000 Series 7
Features 8
Products in the Digital 6000 series 9
EM 6000 | EM 6000 DANTE 2-channel receiver 10
Package contents 10
Product overview 11
SKM 6000 handheld transmitter 12
Package contents 12
Product overview 13
SK 6000 bodypack transmitter 14
Package contents 15
Product overview 15
SK 6212 bodypack transmitter 16
Package contents 17
Product overview 17
Modular L 6000 charger 18
Package contents 18
Product overview 19
Accessories 20
Charging modules for L 6000 charger 20
LM 6060 20
LM 6061 20
LM 6062 21
Rechargeable batteries and battery compartments 22
BA 60 rechargeable battery 23
BA 61 rechargeable battery 23
BA 62 rechargeable battery 24
B 60 battery compartment 25
B 61 battery compartment 25
L 60 charger 26
Digital 9000 series handheld transmitter and bodypack
transmitter 27
SKM 9000 product variants 27
SK 9000 product variants 27
KA 9000 COM command adapter 28
Microphones and cables 29
Microphone modules 29
Headset and Lavalier microphones 30
Line/instrument cables 30
AES3 cable for digital audio signals 30
Antennas and accessories 31
Omni-directional antennas 31
Directional antennas 31
Circularly polarized antennas 31
Antenna splitter 31
Antenna amplifiers 31
Antenna cables 31
Antennas for bodypack transmitters 31
Installing Digital 6000 series devices 32
Installing the EM 6000 34
Connectors on the rear of the device 34
1
Product overview for the rear side of the EM 6000 34
Product overview for the rear side of the EM 6000 DAN-
TE 35
Connecting/disconnecting the EM 6000 to/from the power supply system 36
Connecting the EM 6000 to a network 37
Outputting analog audio signals 38
Outputting digital audio signals 39
Outputting audio via a Dante™ network (EM 6000 DANTE
only) 40
Connecting the word clock 41
Connecting remote antennas 43
Cascading receivers 44
Connecting rod antennas 45
Installing the EM 6000 in a rack 46
Installing the SKM 6000 47
Inserting and removing the BA 60 rechargeable battery
48
Inserting and removing the B 60 battery compartment 50
Replacing the microphone module 53
Installing the SK 6000 55
Inserting and removing the BA 61 rechargeable battery
56
Inserting and removing the B 61 battery compartment 58
Mounting the antenna 60
Connecting a microphone to the SK 6000 61
Connecting an instrument or line source to the SK 6000
62
Connecting the KA 9000 COM command adapter to the
SK 6000 63
Installing the SK 6212 64
Inserting and removing the BA 62 rechargeable battery
64
Mounting the antenna 66
Connecting a microphone to the SK 6212 68
Connecting an instrument or line source to the SK 6212
70
Installing the L 6000 | LM 6060 | LM 6061 | LM 6062
71
Connecting/disconnecting the L 6000 to/from the power supply system 72
Connecting the L 6000 to a network 73
Installing the LM 6060, LM 6061 and LM 6062 charging
modules in the L 6000 74
Installing the L 6000 in a rack 76
Using Digital 6000 series devices 77
Using the EM 6000 79
Operating elements on the front of the device 79
Product overview for the front of the EM 6000 79
Switching the EM 6000 on and off 81
2
Displays on the EM 6000 display panel 82
Buttons for navigating through the menu 84
Home screen 85
Home screen 1 86
Home screen 2 88
Home screen 3 89
Home screen 4 90
Home screen 5 (audio mute) 90
Muting the audio signal 91
Setting options in the menu 92
Menu structure 94
Frequency menu item 95
Name menu item 97
Sync Settings menu item 98
Gain 101
Low Cut 102
Auto Lock 102
Display panel 103
Cable 103
Power LED Mode 104
MIC Line Mode 104
Frequency Only 105
Encryption menu item 106
Command Mode menu item 108
EXAMPLE: 109
Scan & Auto-Setup menu item 110
Performing a frequency scan and automatic frequency
setup 110
Step 1a: New Scan 112
Step 1b: Use Old Scan 114
Step 2: Editing displayed frequencies 114
Step 3: Starting the automatic frequency setup 116
Walktest menu item 118
AF Output menu item 120
Test Tone menu item 121
Bank Edit menu item 122
System menu item 124
System -> Wordclock menu item 127
System -> Network menu item 128
System -> Device ID menu item 130
System -> Dante Settings (only EM 6000 DANTE) menu
item 131
Device ID 131
Mode 132
PrimNet 133
SecNet 134
Info 134
System -> Booster Feed menu item 135
System -> Brightness menu item 136
System -> Auto Setup menu item 137
System -> Info menu item 138
System -> Hardware menu item 138
3
System -> Help menu item 139
System -> TX Update menu item 139
System -> Reset menu item 140
Using the headphone output 141
Updating the firmware of the receiver 142
Updating the firmware of the Dante™ interface 143
Status messages 144
Using the SKM 6000 147
Operating elements of the SKM 6000 handheld transmitter 147
Switching the SKM 6000 on and off 148
Displays on the SKM 6000 handheld transmitter display
panel 149
Operating the SKM 6000 menu 150
Navigating through the menu 150
Making changes in a menu item 150
Menu item overview 150
Updating the firmware of the SKM 6000 153
Using the SK 6000 154
Operating elements of the SK 6000 bodypack transmitter 155
Switching the SK 6000 on and off 156
Displays on the SK 6000 bodypack transmitter display
panel 157
Operating the SK 6000 menu 158
Navigating through the menu 158
Making changes in a menu item 158
Menu item overview 158
Operating the SK 6000 with the KA 9000 COM command
adapter 162
Updating the firmware of the SK 6000 162
Using the SK 6212 163
Operating elements of the SK 6212 bodypack transmitter
163
Switching the SK 6212 on and off 164
Switching on the SK 6212 bodypack transmitter 164
Switching on the SK 6212 bodypack transmitter and
deactivating the RF signal 164
Switching off the SK 6212 bodypack transmitter 164
Home screen 165
Home screen 1: Frequency 165
Home screen 2: Name 165
Home screen 3: Audio 166
Displays on the SK 6212 bodypack transmitter display
166
Operating the SK 6212 menu 167
Navigating through the menu 167
Making changes in a menu item 167
Menu item overview 167
Updating the firmware of the SK 6212 170
Using the L 6000 171
4
Switching the L 6000 on and off 171
Charging rechargeable batteries 172
Meaning of the LEDs on the L 6000 charger and
LM 6060, LM 6061 and LM 6062 charging modules 174
L 6000 status LEDs 174
LM 6060, LM 6061 and LM 6062 status LEDs 175
LM 6060, LM 6061 and LM 6062 status LEDs in stora-
ge mode 175
Preparing rechargeable batteries for storage (storage
mode) 176
Meaning of the status LEDs in storage mode 176
Resetting settings (factory reset) 177
Updating the firmware 178
Operating the L 6000 via a network 179
Establishing a radio link 180
Adjusting frequencies 180
Encrypting the radio link 180
Meaning of the Link Quality Indicator 180
Green range from 50% to 100%: 181
Yellow range from 20% to 49%: 181
Orange range from 1% to 19%: 181
Red range 0%: 181
Synchronizing devices 182
Overview 183
Recommendations for using antennas 184
Rod antennas (included in the delivery) 184
Remote antennas 184
Active vs passive antennas 184
General recommendation 184
Types of remote antenna 185
Losses due to cable properties and length 185
Equidistant frequency grid 186
Word clock scenarios for digital audio (AES3 and
Dante™) 187
Word clock with analog audio 187
Word clock with digital audio 187
Defining the master and slave 188
Overview 189
Product variants 189
EM 6000 | EM 6000 DANTE product variants 189
SKM 6000 product variants 190
SK 6000 product variants 190
SK 6212 product variants 191
L 6000 product variants 191
LM 6060, LM 6061 and LM 6062 product variants 191
Specifications 192
System 192
EM 6000 192
EM 6000 DANTE 193
SKM 6000 195
5
SK 6000 196
SK 6212 197
L 6000 198
LM 6060 | LM 6061 | LM 6062 199
BA 60 | BA 61 | BA 62 199
Cleaning and maintenance 200
Cleaning the sound inlet basket of the microphone mo-
dule 200
Cleaning the SK 6000 bodypack transmitter contacts.
201
Cleaning the L 6000 charger 201
6
The Digital 6000 Series
PRODUCT INFORMATION
The Digital 6000 Series
For more information about the individual products in the Digital 6000 series, see „Products in the Digital 6000 series“.
For information about the available accessories, see „Accessories“.
►
When perfection is required there can be no compromises. The Digital
6000 system combines experience, high standards and excellent instincts
for day-to-day work in the modern live event industry into one simple
promise: no compromises in RF robustness, sound or workflow.
The 2-channel system delivers quality, reliability and efficiency in a compact 19-inch/1 RU format. The series incorporates the renowned Long
Range mode with the proprietary audio codec (SeDAC) of the wireless
masterpiece, Digital 9000.
True bit diversity evaluates the quality of each individual bit and combines
the bits from the two parallel reception streams. In combination with a
switching bandwidth of 244 MHz and equidistant frequency grid, it provides the greatest possible transmission reliability even in demanding RF
environments. Digital 6000 is compatible with many other Sennheiser antennas and capsules and has an easy-to-follow user interface on clear
OLED displays, digital and analog outputs and AES 256 encryption. The
Dante Version with an Audinate Brooklyn II Card offers an additional RJ-45
connector.
The series is ideal for touring and rental companies, theater and musical
productions, broadcasting, large places of worship and corporate applications.
7
The Digital 6000 Series
The 6000 series includes a 2-channel receiver, a bodypack transmitter, a
handheld transmitter and a modular 19-inch rack-mounted charger.
Digital 6000 combines the benefits of modern audio technology with an intelligent operating concept. The frequency range can be scanned directly
with the receiver, which then distributes free frequencies within the network. The equipment can also be monitored and configured via Wireless
System Manager (WSM) software. The high-quality OLED display provides
an overview with a multitude of operating data. Intelligent home screens
lead you directly to important contextual information with no need for timeconsuming navigation. In addition to the popular RF graphs, the link quality
display (LQI) allows a real-time evaluation of the wireless link quality. That
allows you to identify and eliminate risks immediately.
Digital 6000 integrates seamlessly into existing digital and analog infrastructures. The EM 6000 receiver has a digital AES3 output with word
clock inputs and outputs, high-quality transformer-balanced analog XLR-3
outputs, 6.3 mm (1/4") jack outputs and a 6.3 mm (1/4") headphone output.
The Dante version with an Audinate Brooklyn II card offers an additional
Amphenol RJ-45 jack plug for integrating the receiver into a Dante network.
The Digital 6000 series includes a 2-channel receiver available in 2 versions, a bodypack transmitter, a handheld transmitter and a modular 19inch rack-mounted charger.
Features
• A 2-channel receiver in a compact 19-inch/1 RU format combines performance, efficiency and clarity
• The wireless transmission uses the legendary Long Range mode with
SeDAC codec from the masterpiece, Digital 9000 – for maximum transmission quality
• True bit diversity, error correction and masking protect the transmission channels even in demanding RF environments
• Future-proof and usable worldwide thanks to the large 244 MHz switching bandwidth
• The equidistant frequency grid guarantees the highest possible number
of channels and simplest configuration, even in the most congested frequency bandwidths.
• Sophisticated transmitter electronics prevent disruptive intermodulation even with multiple transmitters in confined spaces
• Low system latency of just 3 ms
• Multiple outputs for analog and digital systems (XLR, jack socket, AES,
Dante (EM 6000 Dante only))
• AES 256 encryption for maximum data security
• Simple setup of multi-channel solutions: With the integrated antenna
splitters, you can cascade up to 8 receivers without any additional hardware
• Compatible with a huge number of Sennheiser and Neumann capsules,
Lavalier microphones (clip-on microphones), headsets and antenna
systems
• High-resolution white OLED display with four easy access home
screens
• Simple, intuitive user concept for setup and monitoring
•WSM-compatible
• Transmitter equipped with lithium-ion rechargeable batteries
• Modular 19 inch/1 RU charger
8
Products in the Digital 6000 series
Products in the Digital 6000 series
►
You can also find more information here:
▷ A variety of frequency variants are available for the SKM 6000,
SK 6000 and SK 6212 transmitters. You can find more information under „Product variants“.
▷ You can find technical specifications about the individual products un-
der „Specifications“.
▷ You can find information about installing the products under „Install-
ing Digital 6000 series devices“.
▷ You can find information about operating the products under „Using
Digital 6000 series devices“.
9
Products in the Digital 6000 series
EM 6000 | EM 6000 DANTE 2-channel receiver
►
The digital 2-channel receiver works with a switching bandwidth of
244 MHz (470 to 714 MHz), which is covered by three transmitter versions.
For larger 4-channel systems, you can cascade up to EM 6000s without using additional antenna splitters and you then require only one pair of antennas.
The 2-channel receiver is available in 2 variants:
• EM 6000
• EM 6000 DANTE
The EM 6000 DANTE variant is identical in construction to the EM 6000.
The only difference is that it also has an integrated Dante™ interface (Audinate Brooklyn II) for connecting the device to a Dante™ network. Two
modes are supported for the two Dante™ sockets: Redundant and Through.
▷ See „EM 6000 | EM 6000 DANTE product variants“
You can find more detailed information about the EM 6000 in the following sections:
▷ Installation: „Installing the EM 6000“
▷ Operation: „Using the EM 6000“
▷ Specifications: „EM 6000“ or „EM 6000 DANTE“
Package contents
• 1 EM 6000 or EM 6000 DANTE 2-channel receiver
• 1 mains cables (EU, UK, or US variant)
•2 antennas
• 2 antenna cables (BNC, 50 Ω)
• 4 rubber feet
•1 quick guide
• 1 manual with safety instructions
• 1 manual with technical data and manufacturer declarations
10
Product overview
View of the front side:
►
Rear view of the EM 6000:
►
Products in the Digital 6000 series
Rear view of the EM 6000 DANTE:
►
11
Products in the Digital 6000 series
SKM 6000 handheld transmitter
►
You can find more detailed information about the SKM 6000 in the following sections:
▷ Installation: „Installing the SKM 6000“
▷ Operation: „Using the SKM 6000“
▷ Frequency variants: „SKM 6000 product variants“
▷ Specifications: „SKM 6000“
Package contents
• 1 SKM 6000 handheld transmitter
• 1 MZQ 9000 microphone clamp
•1 quick guide
• 1 manual with safety instructions
• 1 manual with technical data and manufacturer declarations
12
Product overview
View of the front side:
►
Products in the Digital 6000 series
View of the rear side with the display:
►
13
Products in the Digital 6000 series
SK 6000 bodypack transmitter
►
You can find more detailed information about the SK 6000 in the following sections:
▷ Installation: „Installing the SK 6000“
▷ Operation: „Using the SK 6000“
▷ Frequency variants: „SK 6000 product variants“
▷ Specifications: „SK 6000“
14
Products in the Digital 6000 series
Package contents
• 1 SK 6000 bodypack transmitter
• 1 antenna
•1 belt clip
•1 quick guide
• 1 manual with safety instructions
• 1 manual with technical data and manufacturer declarations
Product overview
View of the front side:
►
View without rechargeable battery:
►
15
Products in the Digital 6000 series
SK 6212 bodypack transmitter
►
You can find more detailed information about the SK 6212 in the following sections:
▷ Installation: „Installing the SK 6212“
▷ Operation: „Using the SK 6212“
▷ Frequency variants: „SKM 6000 product variants“
▷ Specifications: „SK 6212“
16
Products in the Digital 6000 series
Package contents
• 1 SK 6212 bodypack transmitter
• 1 antenna
•1 belt clip
•1 quick guide
• 1 supplement sheet with safety instructions
• 1 supplement sheet with specifications and manufacturer declarations
Product overview
View of the front side:
►
View of the rear side:
►
View from above:
►
17
Products in the Digital 6000 series
Modular L 6000 charger
►
The L 6000 charger is used to charge the BA 60, BA 61 and BA 62 rechargeable batteries. The charging modules LM 6060 (for the BA 60),
LM 6061 (for the BA 61) or LM 6062 (for the BA 62) are required to do so.
The rechargeable batteries and charging modules are available separately.
You can find more detailed information about the L 6000 charger and
the LM 6060, LM 6061 and LM 6062 charging modules in the following
sections:
▷ Information about the rechargeable batteries and charging mod-
ules: „Rechargeable batteries and battery compartments“ and
„Charging modules for L 6000 charger“
▷ Installation: „Installing the L 6000 | LM 6060 | LM 6061 | LM 6062“
▷ Operation: „Using the L 6000“
▷ Specifications: „L 6000“ or „LM 6060 | LM 6061 | LM 6062“
Package contents
• 1 L 6000 charger
• 1 mains cables (EU, UK, or US variant)
• 4 dummy caps including screws (preassembled)
• 4 rubber feet
•1 quick guide
• 1 manual with safety instructions
• 1 manual with technical data and manufacturer declarations
18
Products in the Digital 6000 series
Product overview
View with the charging modules and rechargeable batteries inserted:
►
View with the LM 6060 charging modules without rechargeable batteries inserted:
►
View with the LM 6061 charging modules without rechargeable batteries inserted:
►
19
Accessories
Accessories
Various accessory parts are available for the Digital 6000 series.
Charging modules for L 6000 charger
LM 6060
The LM 6060 charging module is installed in the L 6000 charger to charge
the BA 60 rechargeable battery.
4 Torx 10 screws for mounting in the L 6000 are included in the delivery.
►
Sennheiser article number 507198
LM 6061
The LM 6061 charging module is installed in the L 6000 charger to charge
the BA 61 rechargeable battery.
4 Torx 10 screws for mounting in the L 6000 are included in the delivery.
►
Sennheiser article number 507199
20
Accessories
LM 6062
The LM 6062 charging module is installed in the L 6000 charger to charge
the BA 62 rechargeable battery.
4 Torx 10 screws for mounting in the L 6000 are included in the delivery.
►
Sennheiser article number 508516
21
Accessories
Rechargeable batteries and battery compartments
Rechargeable batteries:
To operate the transmitters, we recommend using the rechargeable batteries BA 60 (for the SKM 6000 handheld transmitter), BA 61 (for the
SK 6000 bodypack transmitter) or BA 62 (for the SK 6212 bodypack transmitter). The rechargeable batteries are available as accessories. These
lithium-ion rechargeable batteries have been especially developed to
achieve the optimum service life and operational reliability for the transmitters.
Lithium-ion rechargeable batteries do not have a memory effect and have
a greater power density than primary batteries and NiMh rechargeable
batteries. In addition, the remaining battery life of the transmitters can be
read to the exact minute on the transmitter and receiver.
These rechargeable batteries must be charged only with Sennheiser
L 6000 (BA 60, BA 61 and BA 62) and L60 (BA 60 and BA 61) chargers.
Battery compartments:
With the B60 battery compartment (for the SKM 6000 handheld transmit-
ter) and B61 battery compartment (for the SK 6000 bodypack transmitter)
that are also available as accessories, you can use AA batteries and rechargeable AA batteries. However, the battery life of the transmitters is
shorter than the BA 60 and BA 61 rechargeable battery life and depends
heavily on the quality, capacitance and age of the batteries or rechargeable
batteries used.
The remaining battery life can only be roughly estimated from the battery
icon and a specific battery life cannot be displayed. At the end of the battery life, the transmitters may also experience oscillating on-off switching
behavior.
The use of battery compartments may be a solution for rehearsals or to
avoid disasters, but should generally not be considered as part of an event.
22
Accessories
BA 60 rechargeable battery
The BA 60 rechargeable battery is intended to operate the SKM 6000
handheld transmitter.
►
Sennheiser article number 504702
BA 61 rechargeable battery
The BA 61 rechargeable battery is intended to operate the SK 6000
bodypack transmitter.
►
Sennheiser article number 504703
23
Accessories
BA 62 rechargeable battery
The BA 62 rechargeable battery is intended to operate the SK 6212
bodypack transmitter.
►
Sennheiser article number 508517
24
Accessories
B 60 battery compartment
The B 60 battery compartment is intended to operate the SKM 6000 handheld transmitter.
►
Sennheiser article number 504700
B 61 battery compartment
The B 61 battery compartment is intended to operate the SK 6000
bodypack transmitter.
►
Sennheiser article number 504701
25
Accessories
L60 charger
As an alternative to the L 6000 charger, the L 60 charger from the
Digital 9000 series can be used to charge the BA 60 and BA 61 rechargeable batteries.
►
Features:
• Simultaneous charging of up to 2 rechargeable batteries of type BA 60/
BA 61
• Cascade up to 4 chargers
Sennheiser article no. 504704
You can find more information about the L 60 charger in the
Digital 9000 series instruction manual in the Sennheiser Documentation app, or on the L 60 charger product page at the following ad-
dress:
www.sennheiser.com/l-60
26
Accessories
Digital 9000 series handheld transmitter and bodypack transmitter
The Sennheiser Digital 9000 series SK 9000 bodypack transmitter and
SKM 9000 handheld transmitter are compatible with the Digital 6000 se-
ries if operated in LR mode.
The SKM 9000 COM variant of the handheld transmitter has a Command
button for use in command mode (see „Command Mode menu item“).
SKM 9000 product variants
►
Product Frequency range Article
no.
SKM 9000 A1-A4, black 470 to 558 MHz 504718
SKM 9000 A5-A8, black 550 to 638 MHz 504719
SKM 9000 B1-B4, black 630 to 718 MHz 504720
SKM 9000 COM A1-A4, black 470 to 558 MHz 504714
SKM 9000 COM A5-A8, black 550 to 638 MHz 504715
SKM 9000 COM B1-B4, black 630 to 718 MHz 504716
SKM 9000 A1-A4, nickel 470 to 558 MHz 504726
SKM 9000 A5-A8, nickel 550 to 638 MHz 504727
SKM 9000 B1-B4, nickel 630 to 718 MHz 504728
SKM 9000 COM A1-A4, nickel 470 to 558 MHz 504722
SKM 9000 COM A5-A8, nickel 550 to 638 MHz 504723
SKM 9000 COM B1-B4, nickel 630 to 718 MHz 504724
SK 9000 product variants
►
Product Frequency range Article
no.
SK 9000 A1-A4 470 to 558 MHz 504730
SK 9000 A5-A8 550 to 638 MHz 504731
SK 9000 B1-B4 630 to 718 MHz 504732
27
Accessories
KA 9000 COM command adapter
Command adapter for the SK 6000 bodypack transmitter. You can use the
KA 9000 COM command adapter to switch the audio channel on the EM
6000 receiver via remote control (for example, to provide directional instructions).
Article no. 504735
You can find more detailed information about the KA 9000 COM command adapter in the following sections:
• Installation: „Connecting the KA 9000 COM command adapter to the SK
6000“
• Operation: „Operating the SK 6000 with the KA 9000 COM command
adapter“
►
28
Accessories
Microphones and cables
Microphone modules
We recommend using the following microphone modules with the
SKM 6000 handheld transmitter.
►
Module Features Article no.
MMD 835-1 BK Dynamic, cardioid, black 502575
MMD 845-1 BK Dynamic, super-cardioid, black 502576
MME 865-1 BK Capacitor, super-cardioid, black 502581
MMD 935-1 BK Dynamic, cardioid, black 502577
MMD 945-1 BK Dynamic, super-cardioid, black 502579
MMK 965-1 BK Capacitor, switchable, black 502582
MMK 965-1 NI Capacitor, switchable, nickel 502584
MD 9235 BK Dynamic, super-cardioid, black 502585
MD 9235 NI Dynamic, super-cardioid, nickel 502586
MD 9235 NI/BK Dynamic, super-cardioid, nickel-black 502591
ME 9002 Electret, omni-directional, black 502587
ME 9004 Electret, cardioid, black 502588
ME 9005 Electret, super-cardioid, black 502589
Neumann
Capacitor, cardioid, nickel 008651
KK 204
Neumann
Capacitor, cardioid, black 008652
KK 204 BK
Neumann
Capacitor, super-cardioid, nickel 008653
KK 205
Neumann
Capacitor, super-cardioid, black 008654
KK 205 BK
You can also use microphone modules from the G3/G4 evolution
wireless and 2000 series with the SKM 6000 handheld transmitter.
You can find more information about the individual microphone modules on
their respective product pages at www.sennheiser.com or www.neumann.com.
29
Accessories
Headset and Lavalier microphones
We recommend using the following Lavalier microphones and headset microphones with the SK 6000 and SK 6212 bodypack transmitters.
►
Microphone Features Article no.
MKE 1-4 Lavalier microphone, omni-directional 502167
MKE 2-4 Lavalier microphone, omni-directional 004736
MKE 40-4 Lavalier microphone, cardioid 003579
HSP 2 Headset microphone, omni-directional 009862
HSP 4 Headset microphone, cardioid 009864
SL Headmic 1-4 Headset microphone, omni-directional 506905
HSP Essential
Omni Black
Headset microphone, omni-directional,
black
508247
3-pin
HSP Essential
Omni Beige
Headset microphone, omni-directional,
beige
508248
3-pin
MKE Essential
Omni Black
Lavalier microphone, omni-directional,
black
508251
3-pin
MKE Essential
Omni Beige
Lavalier microphone, omni-directional,
beige
508252
3-pin
You can find more information about the individual microphones on
their respective product pages at www.sennheiser.com.
Line/instrument cables
The following cable is available to connect instruments and line sources to
the SK 6000 bodypack transmitter:
•Sennheiser CI 1-4
6.3 mm (1/4") jack plug (silent plug) to 3-pin audio connector (Sennheiser special connector), article no. 503163
The following cable is available to connect instruments and line sources to
the SK 6212 bodypack transmitter:
•Sennheiser CI R-4A-NRS
6.3 mm (1/4") jack plug (silent plug) to 3-pin audio connector (Sennheiser special connector), article no. 390027
AES3 cable for digital audio signals
To connect the digital audio output of the EM 6000 to a digital mixing console.
• GZL AES 10, AES3 cable, 10 m (32 ft), 110 Ω, double-shielded, article no.
502432
30
Accessories
Antennas and accessories
The following antenna components are available as accessory parts.
Omni-directional antennas
• A 1031-U, passive omni-directional antenna, article no. 004645
• A 3700, active omni-directional antenna, article no. 502195
Directional antennas
• A 2003 UHF, passive directional antenna, article no. 003658
• AD 3700, active directional antenna, article no. 502197
Circularly polarized antennas
• A 5000 CP, passive circularly polarized helical antenna, article no.
500887
Antenna splitter
• ASA 3000, active antenna splitter 2×1:8
• ASA 3000-EU variant, article no. 009423
• ASA 3000-UK variant, article no. 009408
• ASA 3000-US variant, article no. 009407
Antenna amplifiers
• AB 3700, broadband antenna amplifier, article no. 502196
• AB 9000, antenna amplifier
• AB 9000 A1-A8 variant, article no. 504708
• AB 9000 B1-B8 variant, article no. 504709
Antenna cables
• GZL 1019, BNC/BNC coaxial cable, antenna cable with 50 Ω characteristic (wave) impedance
• GZL 1019-A1 variant, 1 m (3 ft), article no. 002324
• GZL 1019-A5 variant, 5 m (16 ft), article no. 002325
• GZL 1019-A10 variant, 10 m (32 ft), article no. 002326
• RF cable, BNC cable for daisy chaining the antenna signal, 50 Ω, 0.25 m
(9 27/32"), article no. 087969
• RF cable, BNC cable for daisy chaining the word clock signal, 75 Ω,
0.25 m (9 27/32"), article no. 087972
Antennas for bodypack transmitters
• Antenna A1-A4, antenna for SK 6212, article no. 508572
• Antenna A4-A8, antenna for SK 6212, article no. 508573
• Antenna B1-B4, antenna for SK 6212, article no. 508574
31
Installing Digital 6000 series devices
INSTALLATION
Installing Digital 6000 series devices
You can find information about installing and connecting Digital 6000 series devices in the following sections.
• EM 6000 2-channel receiver >> „Installing the EM 6000“
• SKM 6000 handheld transmitter >> „Installing the SKM 6000“
• SK 6000 bodypack transmitter >> „Installing the SK 6000“
• SK 6212 bodypack transmitter >> „Installing the SK 6212“
32
Installing Digital 6000 series devices
• L 6000 charger and LM 6060, LM 6061, LM 6062 charging modules >>
„Installing the L 6000 | LM 6060 | LM 6061 | LM 6062“
You can find information about operating the products under „Using
Digital 6000 series devices“.
33
Installing the EM 6000
Installing the EM 6000
These sections contain detailed information about installing the EM 6000.
You can find information about operating the EM 6000 under „Using the
EM 6000“.
Connectors on the rear of the device
Product overview for the rear side of the EM 6000
►
1 Power socket
• See „Connecting/disconnecting the EM 6000 to/from the power
supply system“
2 Ethernet socket for controlling the device via the network and Sennhe-
iser WSM
• See „Connecting the EM 6000 to a network“
3 Digital Audio AES 3 digital audio output
• See „Outputting digital audio signals“
4 Word clock BNC sockets
• See „Connecting the word clock“
5 Bal AF out analog audio outputs for the CH 1 and CH 2 channels
• One XLR and 6.3 mm (1/4") jack per channel, transformer-balanced,
parallel
• See „Outputting analog audio signals“
6 BNC antenna inputs and BNC antenna outputs for cascading
• See „Connecting remote antennas“
• See „Connecting rod antennas“
• See „Recommendations for using antennas“
34
Installing the EM 6000
Product overview for the rear side of the EM 6000 DANTE
►
1 Power socket
• See „Connecting/disconnecting the EM 6000 to/from the power
supply system“
2 Dante™ interface with two RJ-45 sockets, Primary and Secondary
• See „Outputting audio via a Dante™ network (EM 6000 DANTE only)“
3 Ethernet socket for controlling the device via the network and Sennhe-
iser WSM
• See „Connecting the EM 6000 to a network“
4 Digital Audio AES 3 digital audio output
• See „Outputting digital audio signals“
5 Word clock BNC sockets
• See „Connecting the word clock“
6 Bal AF out analog audio outputs for the CH 1 and CH 2 channels
• One XLR and 6.3 mm (1/4") jack per channel, transformer-balanced,
parallel
• See „Outputting analog audio signals“
7 BNC antenna inputs and BNC antenna outputs for cascading
• See „Connecting remote antennas“
• See „Connecting rod antennas“
• See „Recommendations for using antennas“
35
Installing the EM 6000
Connecting/disconnecting the EM 6000 to/from the power supply system
To connect the EM 6000 to the power supply system:
▷ Connect the mains cable IEC connector to the power socket on the rear
side of the EM 6000.
▷ Connect the mains cable plug into a suitable wall socket.
►
Once the EM 6000 is connected to the power supply, the On/Off button lights up dimmed. If the booster voltage for antennas is activated
in the menu (see „System -> Booster Feed menu item“), it is active al-
ready before you switch on and after you switch off the EM 6000.
To completely disconnect the EM 6000 from the power supply system:
▷ Unplug the mains cable plug from the wall socket.
▷ Unplug the mains cable IEC connector from the power socket on the
rear side of the EM 6000.
36
Installing the EM 6000
Connecting the EM 6000 to a network
You can monitor and control one or more EM 6000s via a network connection using Sennheiser Wireless Systems Manager (WSM) software.
The network does not have to be a homogeneous network including
only receivers. You can integrate the EM 6000 into your existing network infrastructure with any other types of devices.
►
To connect the EM 6000 to a network:
▷ Connect a network cable with an RJ-45 connector (Cat5 at minimum)
to the Ethernet socket on the rear side of the EM 6000.
►
For more information about controlling devices via the Sennheiser
Wireless Systems Manager (WSM) software, refer to the instruction
manual for the software. You can download the software here:
www.sennheiser.com/wsm
37
Installing the EM 6000
Outputting analog audio signals
Each of the two channels CH 1 and CH 2 on the EM 6000 have both a symmetrical XLR-3M output socket and a symmetrical 6.3 mm (1/4") jack output socket.
▷ Always use only one of the two Bal AF out output sockets for each
channel.
The two output sockets of a channel are connected in parallel.
To connect an XLR cable:
►
To connect a jack cable:
►
38
Installing the EM 6000
Outputting digital audio signals
The EM 6000 can also output digital audio.
To do so, use the Digital Audio AES 3 output on the rear side of the
EM 6000.
The Digital Audio AES 3 output socket is designed as an XLR-3M
socket. Use an XLR cable with a resistance of 110 ohm. Conventional
XLR audio cables may not transfer the digital audio signal correctly.
►
39
Installing the EM 6000
Outputting audio via a Dante™ network (EM 6000 DANTE only)
The EM 6000 DANTE has a Dante interface (Audinate Brooklyn II) for outputting digital audio signals via a Dante™ network.
▷ Connect a Dante-enabled network cable to the Dante socket on the
rear side of the EM 6000 DANTE.
►
We recommend using an Ethernet connector as shown in the figure.
You can find more information about Dante™ here:
• „Word clock scenarios for digital audio (AES3 and Dante™)“
• „System -> Dante Settings (only EM 6000 DANTE) menu item“
40
Installing the EM 6000
Connecting the word clock
You can use the internal word clock on the EM 6000 or connect an external
word clock.
You can also output the external word clock and cascade it up to 16 receivers.
The word clock output transmits only the external word clock that is connected via the word clock input. The internal word clock is not output via
the word clock output.
For more information about the word clock, see „Word clock scenarios for digital audio (AES3 and Dante™)“.
To connect an external word clock:
►
▷ Use a coaxial BNC cable (75 Ω) to connect the external word clock to
the Wordclock In input.
A suitable cable is available as an accessory part. See „Antenna cables“.
41
Installing the EM 6000
To cascade the word clock:
▷ Connect the Wordclock In input of the next EM 6000 to the Wordclock
Out output of the previous EM 6000.
►
42
Installing the EM 6000
Connecting remote antennas
We recommend using remote antennas. You can also find useful information about using antennas under „Recommendations for using antennas“.
To connect remote antennas:
▷ Connect the first antenna to the RF in socket for Antenna A on the rear
side of the EM 6000.
▷ Connect the second antenna to the RF in socket for Antenna B on the
rear side of the EM 6000.
►
Note the following information when setting up antennas:
▷ Maintain a distance of at least 1 m (3 ft) between the antennas.
▷ Maintain a distance of at least 0.5 m (1.5 ft) between the antennas and
the nearest wall.
▷ Position the antennas so that there is a direct line of sight between the
transmitters and the antennas.
▷ Refer to the more detailed information under „Remote antennas“.
▷ Activate the booster feed in the EM 6000 menu if you are using active
antennas. See „System -> Booster Feed menu item“ in the chapter
„System menu item“. Alternatively, use an external antenna amplifier.
43
Installing the EM 6000
Cascading receivers
For larger 4-channel systems, you can cascade up to 8 receivers without
using additional antenna splitters and you then require only one pair of antennas.
►
44
Installing the EM 6000
Connecting rod antennas
We recommend using remote antennas. You can also find useful information about using antennas under „Recommendations for using antennas“.
To connect the supplied rod antennas:
▷ Connect the first rod antenna to the RF in socket for Antenna A on the
rear side of the EM 6000.
▷ Connect the second rod antenna to the RF in socket for Antenna B on
the rear side of the EM 6000.
▷ Gently angle the rod antennas to the left and right as shown in the fig-
ure.
►
45
Installing the EM 6000
Installing the EM 6000 in a rack
You can install the EM 6000 2-channel receiver in any conventional 19"
rack. The rack mounting angles are already attached to the device.
Always observe the following information during rack mounting.
▷ Support the EM 6000 after installation in the rack.
Due to the weight and depth of the device, there is a risk that it may
break off in the rack and become damaged as a result.
►
Version A:
▷ Use special rack mounting rails.
▷ The design of the rack used must be suitable for the installation of
these mounting rails.
Version B:
▷ Use a suitable object to support the device on the rear side.
▷ Ensure that this object cannot become loose.
ATTENTION
Material damages caused by devices overheating
When there is insufficient ventilation, the devices mounted in the rack may
overheat.
▷ Ensure that there is sufficient ventilation in the rack, particularly if sev-
eral devices are installed. If necessary, install a fan in the rack.
►
46
Installing the SKM 6000
Installing the SKM 6000
These sections contain detailed information about installing the
SKM 6000.
You can find information about operating the SKM 6000 under „Using the
SKM 6000“.
47
Installing the SKM 6000
Inserting and removing the BA 60 rechargeable battery
We recommend using the BA 60 rechargeable battery instead of the
B 60 battery compartment. You can find more information about this
subject under „Rechargeable batteries and battery compartments“.
▷ Charge the BA 60 rechargeable battery before using it for the first time.
For information about charging, see „Charging rechargeable batteries“.
►
To insert the BA 60 rechargeable battery into the SKM 6000 handheld
transmitter:
▷ Insert the BA 60 rechargeable battery into the SKM 6000 handheld
transmitter as shown in the figure until it audibly clicks into place.
►
48
Installing the SKM 6000
To remove the BA 60 rechargeable battery from the SKM 6000 handheld
transmitter:
▷ Press the two catches as shown in the figure and pull the BA 60 re-
chargeable battery out of the SKM 6000 handheld transmitter.
►
CAUTION
Damage to the handheld transmitter and/or rechargeable battery/battery compartment
If you touch the following contacts, they may become dirty or bent.
• BA 60 rechargeable battery charging and data contacts
• B 60 battery compartment contacts
▷ Do not touch the BA 60 rechargeable battery contacts or the B 60 bat-
tery compartment contacts.
►
49
Installing the SKM 6000
Inserting and removing the B 60 battery compartment
We recommend using the BA 60 rechargeable battery instead of the
B 60 battery compartment. You can find more information about this
subject under „Rechargeable batteries and battery compartments“.
Before using the battery compartment, you must insert the batteries as
shown in the figure.
▷ Please observe correct polarity when inserting the batteries.
▷ Use only high-quality AA batteries (e.g. lithium or alkaline manganese
batteries) or high-quality NiMH rechargeable batteries in the B 60 battery compartment.
►
To insert the B 60 battery compartment into the SKM 6000 handheld
transmitter:
▷ Insert the B 60 battery compartment into the SKM 6000 handheld
transmitter as shown in the figure until it audibly clicks into place.
50
Installing the SKM 6000
►
To remove the B 60 battery compartment from the SKM 6000 handheld
transmitter:
▷ Press the two catches as shown in the figure and pull the B 60 battery
compartment out of the SKM 6000 handheld transmitter.
51
Installing the SKM 6000
►
CAUTION
Damage to the handheld transmitter and/or rechargeable battery/battery compartment
If you touch the following contacts, they may become dirty or bent.
• BA 60 rechargeable battery charging and data contacts
• B 60 battery compartment contacts
▷ Do not touch the BA 60 rechargeable battery contacts or the B 60 bat-
tery compartment contacts.
►
52
Installing the SKM 6000
Replacing the microphone module
We recommend using the following microphone modules with the
SKM 6000 handheld transmitter.
►
Module Features Article no.
MMD 835-1 BK Dynamic, cardioid, black 502575
MMD 845-1 BK Dynamic, super-cardioid, black 502576
MME 865-1 BK Capacitor, super-cardioid, black 502581
MMD 935-1 BK Dynamic, cardioid, black 502577
MMD 945-1 BK Dynamic, super-cardioid, black 502579
MMK 965-1 BK Capacitor, switchable, black 502582
MMK 965-1 NI Capacitor, switchable, nickel 502584
MD 9235 BK Dynamic, super-cardioid, black 502585
MD 9235 NI Dynamic, super-cardioid, nickel 502586
MD 9235 NI/BK Dynamic, super-cardioid, nickel-black 502591
ME 9002 Electret, omni-directional, black 502587
ME 9004 Electret, cardioid, black 502588
ME 9005 Electret, super-cardioid, black 502589
Neumann
Capacitor, cardioid, nickel 008651
KK 204
Neumann
Capacitor, cardioid, black 008652
KK 204 BK
Neumann
Capacitor, super-cardioid, nickel 008653
KK 205
Neumann
Capacitor, super-cardioid, black 008654
KK 205 BK
You can also use microphone modules from the evolution wireless
G3 and 2000 series with the SKM 6000 handheld transmitter.
53
Installing the SKM 6000
To change the microphone module:
▷ Screw or unscrew the microphone module onto or from the handheld
transmitter as shown in the figure.
►
With some microphone modules, the upper part of the microphone
basket can be screwed off. Ensure that you always completely unscrew the microphone module.
CAUTION
Damage to the microphone module
If you touch the contacts, they may become dirty or bent.
▷ Do not touch the handheld transmitter contacts or the microphone
module contacts.
►
54
Installing the SK 6000
Installing the SK 6000
These sections contain detailed information about installing the SK 6000.
You can find information about operating the SK 6000 under „Using the
SK 6000“.
55
Installing the SK 6000
Inserting and removing the BA 61 rechargeable battery
We recommend using the BA 61 rechargeable battery instead of the
B 61 battery compartment. You can find more information about this
subject under „Rechargeable batteries and battery compartments“.
▷ Charge the BA 61 rechargeable battery before using it for the first time.
For information about charging, see „Charging rechargeable batteries“.
►
To insert the BA 61 rechargeable battery into the SK 6000 bodypack transmitter:
▷ Insert the BA 61 rechargeable battery into the SK 6000 bodypack trans-
mitter as shown in the figure until it audibly clicks into place.
►
56
Installing the SK 6000
To remove the BA 61 rechargeable battery from the SK 6000 bodypack
transmitter:
▷ Press the two catches as shown in the figure and pull the BA 61 re-
chargeable battery out of the SK 6000 bodypack transmitter.
►
CAUTION
Damage to the bodypack transmitter and/or rechargeable battery/
battery compartment
If you touch the following contacts, they may become dirty or bent.
• Supply voltage contacts and bodypack transmitter contacts
• BA 61 rechargeable battery charging and data contacts
• B 61 battery compartment contacts
▷ Do not touch the BA 61 rechargeable battery contacts or the B 61 bat-
tery compartment contacts.
►
57
Installing the SK 6000
Inserting and removing the B 61 battery compartment
We recommend using the BA 61 rechargeable battery instead of the
B 61 battery compartment. You can find more information about this
subject under „Rechargeable batteries and battery compartments“.
Before using the battery compartment, you must insert the batteries as
shown in the figure.
▷ Please observe correct polarity when inserting the batteries.
▷ Use only high-quality AA batteries (e.g. lithium or alkaline manganese
batteries) or high-quality NiMH rechargeable batteries in the B 61 battery compartment.
►
To insert the B 61 battery compartment into the SK 6000 bodypack transmitter:
▷ Insert the B 61 battery compartment into the SK 6000 bodypack trans-
mitter as shown in the figure until it audibly clicks into place.
►
58
Installing the SK 6000
To remove the B 61 battery compartment from the SK 6000 bodypack
transmitter:
▷ Press the two catches as shown in the figure and pull the B 61 battery
compartment out of the SK 6000 bodypack transmitter.
►
CAUTION
Damage to the bodypack transmitter and/or rechargeable battery/
battery compartment
If you touch the following contacts, they may become dirty or bent.
• Supply voltage contacts and bodypack transmitter contacts
• BA 61 rechargeable battery charging and data contacts
• B 61 battery compartment contacts
▷ Do not touch the BA 61 rechargeable battery contacts or the B 61 bat-
tery compartment contacts.
►
59
Installing the SK 6000
Mounting the antenna
To mount the supplied antenna:
▷ Connect the antenna to the SK 6000 bodypack transmitter antenna
socket as shown in the figure.
▷ Tightly screw on the antenna coupling ring on the SK 6000 bodypack
transmitter antenna socket.
►
The antenna can be connected to the antenna socket very gently in
only one direction. Do not use force to connect the antenna to the
bodypack transmitter antenna socket.
60
Installing the SK 6000
Connecting a microphone to the SK 6000
We recommend using the following Lavalier microphones and headset microphones with the SK 6000 and SK 6212 bodypack transmitters.
►
Microphone Features Article no.
MKE 1-4 Lavalier microphone, omni-directional 502167
MKE 2-4 Lavalier microphone, omni-directional 004736
MKE 40-4 Lavalier microphone, cardioid 003579
HSP 2 Headset microphone, omni-directional 009862
HSP 4 Headset microphone, cardioid 009864
SL Headmic 1-4 Headset microphone, omni-directional 506905
HSP Essential
Omni Black
Headset microphone, omni-directional,
black
508247
3-pin
HSP Essential
Omni Beige
Headset microphone, omni-directional,
beige
508248
3-pin
MKE Essential
Omni Black
Lavalier microphone, omni-directional,
black
508251
3-pin
MKE Essential
Omni Beige
Lavalier microphone, omni-directional,
beige
508252
3-pin
To connect a microphone to the bodypack transmitter:
▷ Use a 3-pin audio connector to connect the microphone cable to the
SK 6000 bodypack transmitter audio socket as shown in the figure.
▷ Tightly screw on the microphone cable coupling ring on the audio sock-
et thread of the SK 6000 bodypack transmitter.
►
For more information about using the particular microphone, see the
corresponding instruction manual for the microphone. You can find
this instruction manual in the download section of the Sennheiser
website under www.sennheiser.com/download.
61
Installing the SK 6000
Connecting an instrument or line source to the SK 6000
You can connect instruments or audio sources with a line level to the
SK 6000 bodypack transmitter.
To do so, you require the Sennheiser CI 1-4 cable (6.3 mm (1/4") jack plug
to 3-pin audio connector)
To connect an instrument or line source to bodypack transmitter:
▷ Connect the 3-pin audio connector of the CI 1-4 cable to the SK 6000
bodypack transmitter audio socket as shown in the figure.
▷ Tightly screw on the audio cable coupling ring on the audio socket
thread of the SK 6000 bodypack transmitter.
►
62
Installing the SK 6000
Connecting the KA 9000 COM command adapter to the SK 6000
You can use the KA 9000 COM command adapter to switch the audio channel on the EM 6000 receiver via remote control (for example, to provide directional instructions).
To connect the KA 9000 COM command adapter to the bodypack transmitter:
▷ Connect the 3-pin audio connector of the KA 9000 COM to the SK 6000
bodypack transmitter audio socket as shown in the figure.
▷ Connect the 3-pin audio connector of the Sennheiser microphone or
Sennheiser CI 1-4 line/instrument cable to the KA 9000 COM audio
socket.
►
63
Installing the SK 6212
Installing the SK 6212
These sections contain detailed information about installing the SK 6212.
You can find information about operating the SK 6212 under „Using the
SK 6212“.
Inserting and removing the BA 62 rechargeable battery
▷ Charge the BA 62 rechargeable battery before using it for the first time.
For information about charging, see „Charging rechargeable batteries“.
It is possible that new rechargeable batteries cannot be fully charged
to 100 % in the first few charging cycles.
The remaining operating time may still be unclear after the first few
charging cycles. This will improve over time after more charging cycles
because the rechargeable battery calibrates itself.
To insert the BA 62 rechargeable battery into the SK 6212 bodypack transmitter:
▷ Open the battery compartment on the SK 6212 bodypack transmitter as
shown in the figure.
▷ Insert the BA 62 rechargeable battery into the SK 6212 bodypack trans-
mitter as shown in the figure.
▷ Close the battery compartment cover until it clicks into place.
►
64
Installing the SK 6212
To remove the BA 62 rechargeable battery from the SK 6212 bodypack
transmitter:
▷ Open the battery compartment on the SK 6212 bodypack transmitter as
shown in the figure.
▷ Remove the BA 62 rechargeable battery from the SK 6212 bodypack
transmitter.
CAUTION
Damage to the bodypack transmitter and/or rechargeable battery/
battery compartment
If you touch the following contacts, they may become dirty or bent.
• Supply voltage contacts and bodypack transmitter contacts
• BA 62 rechargeable battery charging and data contacts
▷ Do not touch the contacts on the BA 62 rechargeable battery or the
SK 6212 bodypack transmitter.
►
65
Installing the SK 6212
Mounting the antenna
To mount the supplied antenna:
▷ Connect the antenna to the SK 6212 bodypack transmitter antenna
socket as shown in the figure.
▷ Tightly screw the antenna coupling ring onto the SK 6212 bodypack
transmitter antenna socket.
►
The antenna can be connected to the antenna socket very gently in
only one direction. Do not use force to connect the antenna to the
bodypack transmitter antenna socket.
66
Installing the SK 6212
The antenna bends very easily.
▷ Make sure that the antenna does not touch the housing of the bodypack
transmitter.
►
67
Installing the SK 6212
Connecting a microphone to the SK 6212
We recommend using the following Lavalier microphones and headset microphones with the SK 6000 and SK 6212 bodypack transmitters.
►
Microphone Features Article no.
MKE 1-4 Lavalier microphone, omni-directional 502167
MKE 2-4 Lavalier microphone, omni-directional 004736
MKE 40-4 Lavalier microphone, cardioid 003579
HSP 2 Headset microphone, omni-directional 009862
HSP 4 Headset microphone, cardioid 009864
SL Headmic 1-4 Headset microphone, omni-directional 506905
HSP Essential
Omni Black
3-pin
HSP Essential
Omni Beige
3-pin
MKE Essential
Omni Black
3-pin
MKE Essential
Omni Beige
3-pin
Headset microphone, omni-directional,
black
Headset microphone, omni-directional,
beige
Lavalier microphone, omni-directional,
black
Lavalier microphone, omni-directional,
beige
508247
508248
508251
508252
68
Installing the SK 6212
To connect a microphone to the bodypack transmitter:
▷ Use a 3-pin audio connector to connect the microphone cable to the
SK 6212 bodypack transmitter audio socket as shown in the figure.
▷ Tightly screw the microphone cable coupling ring onto the audio socket
thread of the SK 6212 bodypack transmitter.
►
For more information about using the particular microphone, see the
corresponding instruction manual for the microphone. You can find
this instruction manual in the download section of the Sennheiser
website under www.sennheiser.com/download.
69
Installing the SK 6212
Connecting an instrument or line source to the SK 6212
You can connect instruments or audio sources with a line level to the
SK 6212 bodypack transmitter.
To do so, you require the Sennheiser CI R-4A-NRS cable (6.3 mm (1/4")
jack plug to 3-pin audio connector)
To connect an instrument or line source to bodypack transmitter:
▷ Connect the 3-pin audio connector of the CI R-4A-NRS cable to the
SK 6212 bodypack transmitter audio socket as shown in the figure.
▷ Tightly screw on the audio cable coupling ring on the audio socket
thread of the SK 6212 bodypack transmitter.
►
70
Installing the L 6000 | LM 6060 | LM 6061 | LM 6062
Installing the L 6000 | LM 6060 |
LM 6061 | LM 6062
These sections contain detailed information about installing the L 6000.
You can find information about operating the L 6000 under „Using the
L6000“.
71
Installing the L 6000 | LM 6060 | LM 6061 | LM 6062
Connecting/disconnecting the L 6000 to/from the power supply system
To connect the L 6000 to the power supply system:
▷ Connect the mains cable IEC connector to the power socket on the rear
side of the L 6000.
▷ Connect the mains cable plug into a suitable wall socket.
►
To completely disconnect the L 6000 from the power supply system:
▷ Unplug the mains cable plug from the wall socket.
▷ Unplug the mains cable IEC connector from the power socket on the
rear side of the L 6000.
72
Installing the L 6000 | LM 6060 | LM 6061 | LM 6062
Connecting the L 6000 to a network
You can monitor and control one or more L 6000s via a network connection
using Sennheiser Wireless Systems Manager (WSM) software.
The network does not have to be a homogeneous network including only
chargers. You can integrate the L 6000 into your existing network infrastructure with any other types of devices.
►
To connect the L 6000 to a network:
▷ Connect a network cable with an RJ-45 connector (Cat5 at minimum)
to the Ethernet socket on the rear side of the L 6000.
►
For more information about controlling devices via the Sennheiser
Wireless Systems Manager (WSM) software, refer to the instruction
manual for the software. You can download the software here:
www.sennheiser.com/wsm
73
Installing the L 6000 | LM 6060 | LM 6061 | LM 6062
Installing the LM 6060, LM 6061 and LM 6062 charging modules in the L 6000
The following charging modules are available for the L 6000 charger:
• LM 6060 -> for charging the BA 60 rechargeable battery
►
• LM 6061 -> for charging the BA 61 rechargeable battery
►
• LM 6062 -> for charging the BA 62 rechargeable battery
►
You can combine the LM 6060, LM 6061 and LM 6062 in any way in the
L 6000 charger.
74
Installing the L 6000 | LM 6060 | LM 6061 | LM 6062
To install a charging module in the L 6000 charger:
▷ Completely disconnect the L 6000 charger from the power supply sys-
tem. See „Connecting/disconnecting the L 6000 to/from the power
supply system“.
▷ Unscrew one of the dummy caps on the L 6000.
To do so, you require a Torx 10 screwdriver.
►
▷ Fully slide the charging module into the open charging slot as shown in
the figure.
The charging module can be inserted into the L 6000 housing only in
one direction. The Sennheiser lettering on the charging module must
face upward.
►
▷ Tightly screw on the charging module.
Always use the latest firmware for the L 6000 charger (version 2.0 or later)
to ensure you have access to the full range of functions. You can download
the latest firmware from the following address:
http://www.sennheiser.com/l-6000
For more detailed information about charging the BA 60, BA 61 and
BA 62 rechargeable batteries, see „Charging rechargeable batteries“.
75
Installing the L 6000 | LM 6060 | LM 6061 | LM 6062
Installing the L 6000 in a rack
You can install the L 6000 charger in any conventional 19" rack. The rack
mounting angles are already attached to the device.
Always observe the following information during rack mounting.
▷ Support the L 6000 charger after installation in the rack.
Due to the weight and depth of the device, there is a risk that it may
break off in the rack and become damaged as a result.
►
Version A:
▷ Use special rack mounting rails.
▷ The design of the rack used must be suitable for the installation of
these mounting rails.
Version B:
▷ Use a suitable object to support the device on the rear side.
▷ Ensure that this object cannot become loose.
ATTENTION
Material damages caused by devices overheating
When there is insufficient ventilation, the devices mounted in the rack may
overheat.
▷ Ensure that there is sufficient ventilation in the rack, particularly if sev-
eral devices are installed. If necessary, install a fan in the rack.
►
76
Using Digital 6000 series devices
OPERATION
Using Digital 6000 series devices
You can find information about using Digital 6000 series devices in the
following sections.
• EM 6000 2-channel receiver >> „Using the EM 6000“
• SKM 6000 handheld transmitter >> „Using the SKM 6000“
• SK 6000 bodypack transmitter >> „Using the SK 6000“
• SK 6212 bodypack transmitter >> „Using the SK 6212“
77
Using Digital 6000 series devices
• L 6000 charger and LM 6060, LM 6061, LM 6062 charging modules >>
„Using the L 6000“
You can find information about installing the products under „Installing Digital 6000 series devices“.
In the sections below, you can find important information about specific
use cases.
• Establishing a radio link between the transmitter and receiver >> „Establishing a radio link“
• Synchronizing the receiver settings to the transmitter >> „Synchronizing devices“
•Using the operating menu of the receiver >> „Displays on the EM 6000
display panel“
• Information about status messages and error messages on the display >> „Status messages“
78
Using the EM 6000
Using the EM 6000
These sections contain detailed information about operating the EM 6000.
You can find information about installing the EM 6000 under „Installing the
EM 6000“.
Operating elements on the front of the device
Product overview for the front of the EM 6000
►
1 Displaying and using channel 1 (CH 1)
• See „Displays on the EM 6000 display panel“
• See „Buttons for navigating through the menu“
2 Displaying and using channel 2 (CH 2)
• See „Displays on the EM 6000 display panel“
• See „Buttons for navigating through the menu“
3 On/Off button
• See „Switching the EM 6000 on and off“
4 SAVE button for saving settings in the menu (separate for CH 1 and CH
2)
• See „Buttons for navigating through the menu“
5 ESC button for canceling an action in the menu (separate for CH 1 and
CH 2)
• See „Buttons for navigating through the menu“
79
Using the EM 6000
6 Headphone button for listening in the particular channel via the HEAD-
PHONES socket (13) (separate for CH 1 and CH 2)
• See „Using the headphone output“
7 SYNC button for synchronizing the channel settings to a transmitter
(separate for CH 1 and CH 2)
• See „Synchronizing devices“
8 Jog dial for navigating through the menu (separate for CH 1 and CH 2)
• See „Buttons for navigating through the menu“
9 Warning indicator for error messages (separate for CH 1 and CH 2)
• See „Status messages“
10Display (separate for CH 1 and CH 2)
• See „Displays on the EM 6000 display panel“
11Infra-red interface for the SYNC function
• See „Synchronizing devices“
12Volume control for the HEADPHONES headphone socket (13)
• See „Using the headphone output“
13HEADPHONES headphone socket
• See „Using the headphone output“
80
Using the EM 6000
Switching the EM 6000 on and off
To switch on the EM 6000:
▷ Connect the EM 6000 to the power supply system.
See „Connecting/disconnecting the EM 6000 to/from the power supply system“.
▷ Short-press the On/Off button.
The Sennheiser logo is temporarily displayed on the two displays. The
two displays then show the home screen for the relevant channel.
To switch off the EM 6000:
▷ Hold down the On/Off button until the device switches off.
►
Once the EM 6000 is connected to the power supply, the On/Off button lights up dimmed. If the booster voltage for antennas is activated
in the menu, it is active already before you switch on the EM 6000.
81
Using the EM 6000
Displays on the EM 6000 display panel
The EM 6000 has a separate display for each of the two channels CH 1 and
CH 2.
Channel-specific status information (CH 1 and CH 2)
• In the displays, the home screens for both channels display the channel-specific status information such as the reception quality, battery
life, audio level, and so on. See „Home screen“.
Operating menu (CH 1 and CH 2)
• The display also shows the operating menu for the two channels CH 1
and CH 2, in which you can configure channel-specific settings. See
„Setting options in the menu“.
82
Using the EM 6000
System settings (CH 1 only)
• On the display for the channel CH 1, the system settings for the whole
device are also displayed in the operating menu. See „System menu
item“.
83
Using the EM 6000
Buttons for navigating through the menu
To navigate through the EM 6000 operating menu, you require the following buttons.
►
Turn the jog dial to the right: NEXT
• Display the next home screen
• Scroll down in the menu
Turn the jog dial to the left: PREVIOUS
• Display the previous home screen
• Scroll up in the menu
Press the jog dial: SELECT
• On the home screen: open the menu
• In the menu: open a menu item
• Within a menu item: go to the next selection
SAVE button
• Save a selection
ESC button
• Navigate back one level without saving
These buttons are located next to the two displays for the two CH 1 and CH
2 channels.
84
Using the EM 6000
Home screen
After you switch on the receiver, the two displays initially show the Sennheiser logo. After a short time, the home screen is then displayed.
►
The home screen has 4 different views in total, which display different status information.
▷ Turn the jog dial to the right or left to switch between the individual
home screens.
85
Using the EM 6000
Home screen 1
►
The first home screen that is displayed as the initial view after the device
switches on contains the following status information.
►
Display on the display
Meaning
panel
RF = Radio Frequency
Display of the radio link RF level for antenna
A and antenna B.
This display is shown on each home
screen
LQI = Link Quality Indicator
Shows the quality of the radio link. You can
find more information under „Meaning of the
Link Quality Indicator“.
This display is shown on each home
screen
AF = Audio Frequency
Shows the transmitter audio input level.
This level is separate from the audio level
that is output from the receiver.
This display is shown on each home
screen
Name of the radio link
You can assign the radio link name yourself
in the menu. See „Name menu item“.
Frequency
You can adjust the frequency in the menu.
See „Frequency menu item“.
86
Using the EM 6000
Remaining battery life
Shows the remaining battery life and the
transmitter operating time.
The time is displayed only if the BA 60 and
BA 61 rechargeable batteries are used.
For normal batteries, only the charge level of
the batteries is displayed without time information.
For more information about rechargeable batteries and batteries, see „Rechargeable batteries and battery
compartments“.
AES 256 encryption
The AES icon is displayed if encryption has
been activated for the channel. See „Encryption menu item“.
Command mode
The COM icon is displayed when command
mode is activated. See „Command Mode
menu item“.
87
Using the EM 6000
Home screen 2
►
The second home screen contains the following status information about
the receiver settings.
►
Display on the display
Meaning
panel
Bank/Channel
Shows which channel is set in which frequency bank. See „Frequency menu item“.
AF Out
Shows the receiver audio output level that is
output via the audio outputs. See „AF Output
menu item“.
Wordclock
Shows which wordclock setting is selected.
See „System -> Wordclock menu item“ under „System menu item“.
Booster Feed
Shows whether the booster feed for active
antennas is activated. See „System -> Booster Feed menu item“ under „System menu
item“.
88
Using the EM 6000
Home screen 3
►
The third home screen contains the following status information about the
transmitter settings.
►
Display on the display
Meaning
panel
Capsule
Shows the microphone module with which
the handheld transmitter is equipped
Recommended microphone modules for the
handheld transmitter: „Microphone modules“
Gain
Displays the gain setting for the transmitter.
This setting can be configured in the transmitter menu. See „Operating the SKM 6000
menu“ or „Operating the SK 6000 menu“.
Alternatively, the gain setting can also be
configured in the receiver and synchronized
with the transmitter. See „Sync Settings
menu item“.
Low Cut
Shows the low cut filter setting for the transmitter.
This setting can be configured in the transmitter menu. See „Operating the SKM 6000
menu“ or „Operating the SK 6000 menu“.
Alternatively, the low cut setting can also be
configured in the receiver and synchronized
with the transmitter. See „Sync Settings
menu item“.
Model
Shows the transmitter product variant. See
„SKM 6000 product variants“ or „SK 6000
product variants“.
89
Using the EM 6000
Home screen 4
►
The fourth home screen contains the following status information about
the receiver network settings.
►
Display on the display
Meaning
panel
IP Mode
Shows whether the IP address is assigned
automatically or manually. See „System ->
Network menu item“ under „System menu
item“.
IP Address
Shows the IP address of the receiver. See
„System -> Network menu item“ under „System menu item“.
Netmask
Shows the netmask of the receiver. See
„System -> Network menu item“ under „System menu item“.
Gateway
Shows the gateway of the receiver. See
„System -> Network menu item“ under „System menu item“.
Home screen 5 (audio mute)
▷ See „Muting the audio signal“
90
Using the EM 6000
Muting the audio signal
To mute the audio signal on a channel:
▷ On the home screen, turn the jog dial to the right until the following
view is displayed.
►
▷ Press the jog dial to activate the check box.
►
▷ Press the SAVE button to save the setting.
The audio output on the channel is now muted.
On the home screen, the following indicator flashes while the audio signal
is muted.
►
To cancel the muting:
▷ On the home screen, press the ESC button.
The channel muting is canceled.
91
Using the EM 6000
Setting options in the menu
In the EM 6000 menu, you can configure the following settings.
Muting the receiver audio output
▷ See „Muting the audio signal“
Adjusting frequencies
▷ See „Frequency menu item“
Setting up user-defined frequency banks
▷ See „Bank Edit menu item“
Changing link names
▷ See „Name menu item“
Configuring settings that are transferred to the transmitter during a
sync
▷ See „Sync Settings menu item“
Activating and deactivating encryption
▷ See „Encryption menu item“
Performing a frequency scan and automatic frequency setup
▷ See „Scan & Auto-Setup menu item“
Performing a walk test
▷ See „Walktest menu item“
Adjusting the output level of the receiver audio signal
▷ See „AF Output menu item“
92
Using the EM 6000
Playing back a test tone
▷ See „Test Tone menu item“
Configuring different system settings
• Configuring wordclock
• Configuring network settings
• Changing device names
• Configuring Dante settings (only EM 6000 DANTE)
• Activating the power supply for an external antenna amplifier
• Changing the brightness of the display panel
• Activating the auto-setup function
• Displaying information about software and hardware
• Updating the firmware for the transmitters
• Resetting settings
▷ See „System menu item“
You can find an overview of the entire menu structure under „Menu
structure“.
93
Using the EM 6000
Menu structure
The figure shows the complete EM 6000 menu structure in an overview.
Version: Firmware Version 2.1.9
►
94
Using the EM 6000
Frequency menu item
In the Frequency menu item, you can adjust the frequency for the channel
in question.
You can select a frequency from the predefined frequency banks B1 to B6
(up to 65 channels per bank) or manually adjust the frequency.
You can also select frequencies from the user-defined frequency banks U1
to U6. You can adjust these frequency banks in the Bank Edit menu item.
See „Bank Edit menu item“.
To open the Frequency menu item:
▷ On the home screen, press the jog dial to open the operating menu.
▷ Turn the jog dial until the Frequency menu item appears in the selec-
tion frame:
►
▷ Press the jog dial to open the menu.
The following view is displayed:
►
▷ Turn the jog dial to select a different frequency bank.
▷ Press the jog dial to go to the channel selection:
95
Using the EM 6000
►
▷ Turn the jog dial to set a different channel.
▷ Press the SAVE button to confirm the selection of the bank and chan-
nel.
or
▷ Press the jog dial to go to the manual frequency setting:
►
▷ Turn the jog dial to set the desired frequency.
▷ Press the SAVE button to save the set frequency.
96
Using the EM 6000
Name menu item
In the Name menu item, you can define the name of the link for the channel
in question.
This name is the name of the radio link between the transmitter and
receiver. In the network settings, you can enter the receiver name as
it is displayed in a network: see „System -> Device ID menu item“ un-
der „System menu item“.
To open the Name menu item:
▷ On the home screen, press the jog dial to open the operating menu.
▷ Turn the jog dial until the Name menu item appears in the selection
frame:
►
▷ Press the jog dial to open the menu.
The following view is displayed:
►
To enter the desired link name:
▷ Turn the jog dial to select the desired character.
▷ Press the jog dial to go to the next position.
▷ Press the SAVE button to save the set name.
97
Using the EM 6000
Sync Settings menu item
In the Sync Settings menu item, you can choose which settings for the
transmitter you want to transfer from the receiver to the transmitter during
the synchronization.
All of the settings can also be set separately in the menu on the transmitter.
However, you can simply use the Sync function to configure these settings
via the receiver.
For more information about the Sync function, see „Synchronizing
devices“.
The following settings can be transferred:
Gain
Gain setting for the transmitter, from -6 to 60 dB
Low Cut
Low cut filter, from 30 Hz to 120 Hz
Auto Lock
Activate or deactivate the lock-off on the transmitter
Display panel
Display on the home screen of the transmitter display panel
• Name of the link
•Frequency
•Preset
Cable
Cable emulator in 4 steps
•Line
•Type 1
•Type 2
•Type 3
98
Using the EM 6000
Power LED Mode
Setting the lighting behavior on the blue transmitter LED
•On
•Lock Off
MIC Line Mode
Only for SK 6000: Switching between the mic signal, line signal or automatic detection.
•AUTO
•MIC
•LINE
Frequency Only
Only the frequency is transmitted. No other settings are transferred to the
transmitter.
If you do not want to transfer all of these values to the transmitter,
you can also set the no sync value for each option. The option in
question is then not included in the synchronization.
99
Loading...
