Sennheiser EM 100 G4 User Manual

LIVE PERFORMANCES / BROADCAST & FILM / BUSINESS & EDUCATION
evolution wireless G4
Evolving with you.
Evolving with you.
“Whether you’re in the corporate world, live entertain­ment, theater or broadcast, I really think it helps when you know your gear – evolution wireless G4 does that for you. Only when you know your gear you know what is possible. And with the right gear – anything is possible."
Raphael Williams, Sound Engineer
Stop dreaming about fl exibility, stop wishing for a higher bandwidth, for more power. G4 has it. G4 takes you wherever you want to go. G4 is a wireless system that simply evolves with your passion, with your audi­ence, with you.
Evolution wireless users have come to expect an ever­evolving feature set with each new generation, and evolution wireless G4 is no exception.
With a sleek new user interface, a generously expanded switching bandwidth and higher RF output power for the 300 and 500 series, new multi-channel functionality for the 100 series and brand-new on-camera systems, G4 delivers high-quality, reliable audio for musical perfor­mances, houses of worship, theaters, business settings and camera work.
evolution wireless G4 – Evolving with you.
4 more flexibility.
More flexibility.
Versatility is key. G4 offers
Versatility is key. G4 offers the highest amount of flex-
the highest amount of flex­ibility for all possible appli-
ibility for all possible appli­cations. Live Sound, In-Ear
cations. Live Sound, In-Ear Monitoring, portable solu-
Monitoring, portable solu­tions for ENG and profes-
tions for ENG and profes­sional film productions. It is
sional film productions. It is your partner on every con-
your partner on every con­gress, meeting or university
gress, meeting or university lecture. G4 is mobile. G4 is
lecture. G4 is mobile. always on air.
G4 is always on air.
Mobility.
When it comes to hospitali­ty, education and events, G4 is your mobile solution that fits easily into every room and workflow. When on the road, docu­mentarists and film-makers know that G4 fits into every pocket and provides power­ful speech intelligibility dur­ing the whole interview.
Integration.
The LSP 500 Pro is your mo­bile wireless speaker join­ing you on every job, a broad range of accessories com­pletes the system, and integra­tors adore its versatility when it comes to workflow and con­trol software such as WSM (Wireless Systems Manager) and the Sennheiser Control Cockpit on mobile devices.
evolution wireless - The story continues.
G4 addresses the broad base of the wireless market that relies on analogue transmission in the professional UHF band. G4 benefits from sixty years of expertise in analogue wire­less design, bringing its users a maximum of features, reliability and user-friendliness.
G4 is fully compatible with all G1, G2 and G3 systems, ensuring investments continue to be viable and pay off well into the future. With many user-driven improvements and new features, G4 will continue this legacy.
04 / 05
More power.
More bandwidth.
Stop dreaming about power. G4 has it. The IEM, 300 and 500 series offer up to 50 mW RF output power (adjustable in 3 steps: 10/30/50). Por­table Broadcast & Film sets benefit from 8 hours battery power. G4 is a reliable part­ner on every set.
G4 is beyond expectations on its price point. A switching bandwidth of up to 88 MHz (300 and 500 series) literally enables you to go everywhere your job takes you.
Quicker setup.
G4’s 100 Series enables you to link up to 12 receiv­ers for simultaneous easy­setup, saving valuable time. G4’s intuitive LCD and OLED (IEM, 300 and 500 Series) displays make lives easier in every environment.
Content.
Live Performances 100 Series, 500 Series and IEM Series pages 06–11
Broadcast & Film 100P Series, 500P Series pages 14–19
Business & Education 300 Series pages 20–23
For all additional system components, accessories, and software solutions, please visit us at
www. sennheiser.com/g4
06 / 07
Live Performances G4 is where the magic is.
On a live stage in your favorite venue or at major festivals. In houses of worship, and in the theater.
Sound engineers and avid users love its flexibility and ver­satility – whereas more casual users will adore how easy it is to setup, allowing them to fully concentrate on their major goal; connecting with their audience.
> 100 Series (Easy to operate pro wireless) > IEM Series (InEar Monitoring) > 500 Series (Multi-Channel Setups)
100 Series
evolution wireless G4 - 100 Series
Evolving with you: Flexibility, Safety, Power.
Evolution wireless G4 100 Series is a versatile wireless systems for those who sing, speak or play instruments with up to 42 MHz tuning bandwidth in a stable UHF range and fast, simultaneous setup of up to 12 linked systems.
> True diversity half-rack receiver in a full-metal housing with intuitive LCD display for full control > Easy and fl exible wireless synchronization between transmitter and receiver via infrared > Fast frequency allocation for up to 12 receivers via new linking functionality > Up to 20 compatible channels > Up to 42 MHz bandwidth with 1680 selectable frequencies, fully tunable in a stable UHF range > Transmission Range: up to 100 meters / 330 feet > High RF output power (up to 30 mW) depending on country regulations > All sets now come with GA 3 rackmount kit included
08 / 09
