PC 1001
Electric Air Compressor
Operating Instructions
Document #FN1001 Issued 5/30/A
Warnings for the safe use of this compressor are included in this manual.
Code 181517022
1
TABLE OF CONTENTS
INTRODUCTION ...................................................................3
SAFETY ALERT.....................................................................3
INSPECTION ......................................................................... 3
SAFETY WARNINGS ............................................................4
ELECTRICAL................................................................ 4
EXPLOSION OR FIRE.................................................. 5
BURSTING ...................................................................5
BREA THING.................................................................6
BURNS .........................................................................6
FL YING OBJECTS........................................................6
MOVING P ARTS........................................................... 7
NEGLIGENCE ..............................................................7
AIR COMPRESSOR DAMAGE..................................... 7
COMPRESSOR FEA TURES .................................................8
PREPARATION.................................................................... 10
INITIAL SET-UP ......................................................... 10
LOCATION.................................................................. 1 0
ELECTRICAL.............................................................. 10
OPERA TION........................................................................ 11
PRE-START CHECKLIST........................................... 11
START-UP .................................................................. 11
SHUTDOWN .............................................................. 11
MAINTENANCE................................................................... 11
TROUBLESHOOTING ...................................................12-14
SPECIFICATIONS ............................................................... 15
WARRANTY ........................................................................ 16
P ARTS REFERENCE GUIDE..............................................17
2
INTRODUCTION
Congratulations on the purchase of your new SENCO ® Air Compressor! You can be assured your SENCO Air
Compressor was constructed with the highest level of precision and accuracy . Each component has been rigorously
tested by technicians to ensure the quality , endurance and performance of this air compressor.
This operator’s manual was compiled for your benefit. By reading and following the simple safety , installation and
operation, maintenance and troubleshooting steps described in this manual, you will receive years of troublefree
operation from your new SENCO ® Air Compressor. The contents of this manual are based on the latest product
information available at the time of publication. The manufacturer reserves the right to make changes in price,
color, materials equipment, specifications or models at any time without notice.
SAFETY ALERT!
A ”
DANGER, WARNING or CAUTION
This box is used to designate and emphasize Safety Warnings that must be followed when operating this
air compressor. Accompanying the safety warnings are “Signal Words” which designate the degree or
level of hazard seriousness. The “Signal Words” used in this manual are as follows:
” safety warning will be surrounded by a ”SAFETY ALERT BOX”.
DANGER:
WARNING:
CAUTION:
ALWAYS PROVIDE A COPY OF THIS MANUAL TO ANYONE USING THIS EQUIPMENT. READ ALL
INSTRUCTIONS IN THIS MANUAL AND ANY INSTRUCTIONS SUPPLIED BY MANUFACTURERS OF
SUPPORTING EQUIPMENT BEFORE OPERA TING THIS AIR COMPRESSOR AND ESPECIALL Y POINT OUT
THE “SAFETY WARNINGS” T O PREVENT THE POSSIBILITY OF PERSONAL INJURY TO THE OPERA T OR.
Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury .
Indicates a potentially hazardous situation which, if not avoided
MAY result in minor or moderate injury or damage to the air
compressor.
The symbols set to the left of this paragraph are “Safety Alert Symbols”.
These symbols are used to call attention to items or procedures that could
be dangerous to you or other persons using this equipment.
INSPECTION
Unbox the air compressor and write in the serial number in the space provided below. Inspect for signs of obvious
or concealed freight damage. Be sure that all damaged parts are replaced and any mechanical problems are
corrected prior to the operation of the air compressor.
SERIAL NUMBER__________________________________________
If you have Questions or Comments call SENCO’s toll-free Action-line: 1-800-543-4596 or, e-mail:
toolprof@Senco.com
Please have the following information available for all service calls:
1. Model Number
2. Serial Number
3. Date and Place of Purchase
Senco® Corporation 8485 Broadwell Road, Cincinnati, OH 45244
3
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE USING AIR COMPRESSOR
HAZARD
RISK OF
ELECTRIC SHOCK
OR
ELECTROCUTION
POTENTIAL CONSEQUENCE
Serious injury or death could occur if
the air compressor is not properly
grounded. Your air compressor is
powered by electricity and may cause
electric shock or electrocution if not
used properly .
Electrical shock may occur from
electrical cord.
Electrical shock may occur if air
compressor is not operated properly .
PREVENTION
Make sure the air compressor is
plugged into a properly grounded
outlet which provides correct
voltage and adequate fuse
protection.
Check power cord for signs of
crushing, cutting or heat damage.
Replace faulty cord before use.
Keep all connections dry and off the
ground. Do not allow electrical
cords to lay in water or in such a
position where water could come in
contact with them. Do not touch
plug with wet hands.
Do not pull on the electrical cord to
disconnect from the outlet.
Never operate air compressor in
wet conditions or outdoors when it
is raining.
Serious injury or death may occur if
electrical repairs are attempted by
unqualified persons.
Never operate air compressor with
safety guards/covers removed or
damaged.
Any electrical wiring or repairs
performed on this air compressor
should be done by Authorized
Service Personnel in accordance
with National and Local electrical
codes.
Before opening any electrical
enclosure, always shut off the air
compressor, relieve pressure and
unplug the air compressor from the
power source. Allow air compressor
to cool down. Never assume the air
compressor is safe to work on just
because it is not operating. It could
restart at any time!
4
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE USING AIR COMPRESSOR
HAZARD
RISK OF
EXPLOSION OR FIRE
POTENTIAL CONSEQUENCE
Serious injury or death may occur from
normal electrical sparks in motor and
pressure switch.
Serious injury may occur if any air
compressor ventilation openings are
restricted, causing the air compressor
to overheat and start on fire.
PREVENTION
Always operate air compressor in a
well ventilated area free of
flammable vapors, combustible
dust, gases or other combustible
materials.
If spraying flammable material,
locate the air compressor at least
20 feet away from the spray area.
(An additional hose may be
required.)
Never place objects against or on
top of air compressor. Operate air
compressor at least 12 inches away
from any wall or obstruction that
would restrict proper ventilation.
RISK OF
BURSTING
Serious injury or death may occur from
an air tank explosion if air tanks are
not properly maintained.
Serious injury may occur from an air
compressor malfunction or exploding
accessories if incorrect system
components, attachments or
accessories are used.
Drain air tank daily or after each use
to prevent moisture buildup in the
air tank.
If air tank develops a leak, replace
the air tank immediately. Never
repair, weld or make modifications
to the air tank or its attachments.
Use only genuine SENCO® repair
parts for your air compressor.
Never make adjustments to the
factory set pressures.
Never exceed manufacturers
maximum allowable pressure rating
of attachments.
Because of extreme heat, do not
use plastic pipe or lead tin soldered
joints for a discharge line.
Never use air compressor to inflate
small, low pressure objects such as
toys.
5
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE USING AIR COMPRESSOR
HAZARD
RISK TO
BREATHING
RISK OF
BURNS
POTENTIAL CONSEQUENCE
Serious injury or death could occur
from inhaling compressed air. The air
stream may contain carbon monoxide,
toxic vapors or solid particles.
Sprayed materials such as paint, paint
solvents, paint remover, insecticides,
weed killers, etc. contain harmful
vapors and poisons.
Serious injury could occur from
touching exposed metal parts.
These areas can remain hot for some
time after the air compressor is
shutdown.
PREVENTION
Never inhale air from the air
compressor either directly or from a
breathing device connected to the air
compressor.
Operate air compressor only in a well
ventilated area. Follow all safety
instructions provided with the
materials you are spraying. Use of a
respirator may be required when
working with some materials.
Never allow any part of your body or
other materials to make contact with
any exposed metal parts on the air
compressor.
RISK
OF FLYING
OBJECTS
Soft tissue damage can occur from the
compressed air stream.
Serious injury can occur from loose
debris being propelled at a high speed
from the compressed air stream.
Always wear OSHA required “287”
safety glasses to shield the eyes
from flying debris.
Never point the air stream at any part
of your body , anyone else or animals.
Never leave pressurized air
compressor unattended. Shut off air
compressor and relieve pressure
before attempting maintenance,
attaching tools or accessories.
Always maintain a safe distance from
people and animals while operating
the air compressor.
Do not move the air compressor
while air tank is under pressure. Do
not attempt to move the air
compressor by pulling on the hose.
6
SAFETY WARNINGS
READ ALL SAFETY WARNINGS BEFORE USING AIR COMPRESSOR
HAZARD
RISK FROM
MOVING PARTS
RISK FROM
NEGLIGENCE
POTENTIAL CONSEQUENCE
Risk of bodily injury from moving parts.
This air compressor cycles
automatically when the pressure
switch is in the “On/Auto” position.
Risk of injury from negligent use.
PREVENTION
Always turn off air compressor when
not in use. Bleed pressure from the
air hose and unplug from electrical
outlet before performing
maintenance. All repairs to the air
compressor should be made by an
Authorized Service person. Never
assume the air compressor is safe
to work on just because it is not
operating. It could restart at any time!
Do not operate without protective
covers/guards. Replace damaged
covers/guards before using the air
compressor.
Never allow children or adolescents
to operate this air compressor!
Stay alert-watch what you are doing.
Do not operate the air compressor
when fatigued or under the influence
of alcohol or drugs.
RISK
OF AIR COMPRESSOR
DAMAGE
Risk of major repair.
Know how to stop the air
compressor. Be thoroughly familiar
with controls.
Do not operate air compressor
without an air filter.
Do not operate air compressor in a
corrosive environment.
Do not incline the air compressor
transversely or longitudinally more
than 10°.
Ensure the oil level is above the
minimum notch and below the
maximum notch on the dipstick. If
low, add compressor pump oil.
Always operate the air compressor
in a stable, secure position to prevent
air compressor from falling.
Follow all maintenance instructions
listed in this manual.
! SAVE THESE INSTRUCTIONS !
7
COMPRESSOR FEATURES
10
3
2
4
11
79
1
6
8
12
15
14
1 Motor/Pressure Switch
2 Thermal Overload / Reset
3 Air Intake Filter
4 Air Compressor Pump
5 Safety Relief Valve
6 Air tank drain valve
7 T ank Pressure Gauge
8 Outlet Pressure Gauge
9 Pressure Regulator
10 Oil Dipstick
11 Oil Drain
12 Discharge Line
13 115 Volt Electric Power Cord
14 Ventilation Openings / Protective Shroud
15 Quick Disconnect
8
5
13
COMPRESSOR FEATURES
1) MOTOR/PRESSURE SWITCH: This switch is used to start or stop the air
compressor. Moving the switch to the “Auto” (On) position will provide automatic
power to the pressure switch which will allow the motor to start when the air tank
pressure is below the factory set “cut-in” pressure. When in the Start/ Stop Option,
the pressure switch stops the motor when the air tank pressure reaches the factor
set “cut out” pressure. For safety purposes, this switch also has a pressure release
valve located on the side of the switch designed to automatically release compressed
air from the air compressor pump head and its discharge line when the air compressor
reaches “cut-out” pressure or is shut off. This allows the motor to restart freely . Moving
the switch to the “Off” position will remove power from the pressure switch and stop
the air compressor.
2) MOTOR THERMAL OVERLOAD: The electric motor has a manual thermal
overload protector. If the motor overheats for any reason, the thermal overload will
cut off power, thus preventing the motor from being damaged. Wait until the motor is
cool before pressing the thermal overload button to reset and begin working again.
3) AIR INT AKE FILTER: This filter is designed to clean air coming into the pump. To
ensure the pump continually receives a clean, cool, dry air supply this filter must
always be clean and ventilation opening free from obstructions. The filter can be
removed for cleaning by using warm, soapy water. Rinse the filter and air dry . Replace
filter when necessary.
4) AIR COMPRESSOR PUMP: To compress air, the pistons move up and down in
the cylinders. On the downstroke, air is drawn in through the air intake valves while
the exhaust valves remain closed. On the upstroke, air is compressed, the intake
valves close and compressed air is forced out through the exhaust valves, into the
discharge line, through the check valve and into the air tank.
1
ON
OFF
2
3
5) SAFETY RELIEF VALVE: This valve is designed to prevent system failures by
relieving pressure from the system when the compressed air reaches a predetermined
level. The valve is preset by the manufacturer and must not be modified in any way.
To verify the valve is working properly, pull on the ring. Air pressure should escape.
When the ring is released, it will reseat.
6) AIR T ANK DRAIN V AL VE: The drain valve is used to remove moisture from the air
tank(s) after the air compressor is shut off.
NEVER attempt to open the drain valve
when more than 10 PSI of air pressure is in the air tank! T o open the drain valve,
turn the knob counterclockwise.
7) AIR TANK PRESSURE GAUGE: The air tank pressure gauge indicates the
reserve air pressure in the air tank (s).
8) OUTLET PRESSURE GAUGE: The outlet pressure gauge indicates the air
pressure available at the outlet side of the regulator. This pressure is controlled
by the regulator and is always less or equal to the air tank pressure.
9) PRESSURE REGULATOR: The air pressure coming from the air tank is
controlled by the regulator knob. Turn the pressure regulation knob clockwise to
increase discharge pressure, and counterclockwise to decrease discharge
pressure.
5
6
8
7
9
10
10) OIL DIPSTICK: The dipstick will register the amount of oil in the pump. Oil level
should be checked on a daily basis to ensure it does not exceed the maximum
notch or fall below the minimum notch on the dipstick
9
PREPARATION
INITIAL SET-UP:
1. Read safety warnings before setting-up air compressor.
2. Ensure the oil level is above the minimum notch and below the maximum notch on the dipstick. If low, add
compressor pump oil.
LOCA TION:
CAUTION
In order to avoid damaging the air compressor, do not incline the air compressor
transversely or longitudinally more than 10°.
1. Place air compressor at least 12 inches away from obstacles that may prevent proper ventilation.
Do not place air compressor in an area:
-where there is evidence of oil or gas leaks.
-where flammable gas vapors or materials may be present.
WARNING
Serious injury or death may occur if electrical sparks from motor and pressure switch
come in contact with flammable vapors, combustible dust, gases or other
combustible materials. When using the air compressor for spray painting, place the
air compressor as far away I from the work area as possible, using extra air hoses instead of
extension cords.
-where air temperatures fall below 32°F or exceed 104°F.
-where extremely dirty air or water could be drawn into the air compressor.
ELECTRICAL:
DANGER
Improper connection of the equipment-grounding conductor can result in a risk
of shock or electrocution. Check with a qualified electrician or service personnel
if you are in doubt as to whether the outlet is properly grounded. Do not use any type of
adapter with this product. If repair or replacement of the cord or plug is necessary , do not
connect the grounding wire to either flat blade terminal. The wire with insulation having
an outer surface that is green with or without yellow stripes is the grounding wire.
WARNING
This product must be grounded. If there should be a malfunction or breakdown,
grounding provides a path of least resistance for electric current to reduce the
risk of electric shock. This product is equipped with a cord having an equipmentgrounding conductor and a grounding type plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
1. SENCO® DOES NOT RECOMMEND THE USE OF EXTENSION CORDS as this can create power loss and
overheating of the motor. Use of an additional air hose is recommended rather than an extension cord. If use of an
extension cord is unavoidable, it should be plugged into a GFCI found in circuit boxes or protected receptacles.
When using an extension cord, observe the following:
Cable Length Wire Gauge
Up to 25 feet 12 AWG
Up to 100 feet 10 AWG
Up to 150 feet 8 AWG
Up to 250 feet 6 AWG
Use only 3-blade extension cords that have 3-blade grounding-type plugs and 3-slot cord connectors that will
accept the plug from the product. Use only extension cords having an electrical rating not less than the rating of
the product. Do not use damaged extension cords. Examine extension cord before using and replace if damaged.
Do not abuse extension cord and do not yank on any cord to disconnect. Keep cord away from heat and sharp
edges. Always shut off the air compressor switch before removing the plug from the receptacle.
10
OPERATION
PRE-ST ART CHECKLIST:
1. Check oil level. Add if necessary .
2. Remove any moisture in the air compressor air tank. Remove excessive pressure with an air tool, then open
the air tank drain valve in the bottom of the air tank. Close tightly when drained.
WARNING: Risk of bodily injury . NEVER attempt to open the drain valve when
more than 10 PSI of air pressure is in the air tank!
3. Make sure the air compressor Motor Switch is in the “OFF” position.
4. Make sure all safety valves are working correctly .
5. Make sure all guards and covers are in place and securely mounted.
ST ART-UP:
1. Ensure the lever on the pressure switch box is in the “OFF” position.
2. Plug the power cord into a grounded outlet.
3. Move the lever on the pressure switch box to the “AUTO” position.
4. START/ST OP OPTION: Turn it completely clockwise to the fully closed position. This will allow the air compressor
to “ST ART” building up pressure in the air tanks and “STOP” when correct pressure is achieved. When pressure
drops with usage, the air compressor will “ST AR T” building up pressure again.
CONSTANT RUN OPTION: Locate the adjustment knob at the top of the pilot valve. Turn it completely
counterclockwise to the fully open position. The air compressor is now set up to “CONSTANTLY” build up
pressure. When pressure reaches the preset level in the air tank, pressure will bleed through the pilot valve.
5. Set pressure by adjusting the pressure regulator knob counterclockwise for less pressure and clockwise for
more pressure.
6. If you notice any unusual noise or vibration, stop the air compressor and refer to “Troubleshooting”.
SHUTDOWN:
1. To stop the air compressor , move the lever on the pressure switch box to the “OFF” position. NEVER stop the
air compressor by unplugging it from the power source. This could result in risk of electrocution.
2. Drain air from the air tanks by releasing air with an attached air tool or by pulling on the safety relief valve rings.
3. Once pressure in the air tanks register under 10 pounds, open the drain valve under each air tank to drain any
moisture.
4. Allow the air compressor to cool down.
5. Wipe air compressor clean and store in a safe, non-freezing area.
MAINTENANCE
Read the instruction manual before performing maintenance. The following procedures must be performed when
stopping the air compressor for maintenance or service.
1. Turn off air compressor.
WARNING: Never assume the air compressor is safe to work on just because it is not
operating. It could restart at any time!
2. Disconnect cord from main power supply .
3. Open all drains.
4. Wait for the air compressor to cool before starting service.
MAINTENANCE CHART
PROCEDURE DAILY WEEKLY MONTHLY 200 HOURS
Check pump oil level X
Oil leak inspection X
Drain condensation in air tank(s) X
Check for unusual noise/vibration X
Check for air leaks X
Inspect air filter X
Clean exterior of compressor X
Check safety relief valve X
Change pump oil* X
Replace air filter X
*The pump oil must be changed after the first 50 hours of operation and every 200 hours or 3 months, whichever
comes first. Recommended non-detergent straight weights.
11
TROUBLESHOOTING
Symptom 1. Motor will not run or restart.
Power cord not plugged in.
Motor/Pressure switch in “OFF” position.
Motor thermal overload switch has
tripped.
Fuse blown or circuit breaker has tripped.
Wrong gauge wire or length of extension
cord.
Air tank pressure exceeds motor/
pressure switch “cut-in” pressure.
Pressure release valve on motor/
pressure switch has not unloaded pump
head pressure.
Plug cord into grounded outlet.
Move switch to “AUTO” position.
Turn air compressor off, wait until motor is cool, then press
motor thermal overload (red) button firmly until click is heard.
Replace fuse or reset circuit breaker.
Check for proper fuse amperage.
Check for low voltage conditions.
Disconnect any other electrical appliances from circuit or
operate air compressor on its own branch circuit.
Check chart on page #9 for proper gauge wire and cord length.
Motor will start automatically when air tank pressure drops
below “cut-in” pressure of motor/pressure switch.
Bleed the line by moving the switch to the “Off” position.
Defective motor, motor capacitor , motor/
pressure switch, or check valve.
Symptom 2. Noisy operation.
Loose motor pulley or pump flywheel.
Lack of oil in the pump.
Carbon deposits on pistons or valves.
Bearing, piston or connecting rod failure.
Contact Senco Customer Service.
Tighten pulley and or flywheel.
Add correct amount of oil. Check for bearing damage.
Remove cylinder head and inspect. Clean or replace.
STOP THE COMPRESSOR! Contact Senco Customer
Service.
12
TROUBLESHOOTING
Symptom 3. When in the Start/Stop option, motor runs continuously .
PROBABLE CAUSE
Motor/Pressure switch does not shut off motor when
air compressor reaches “cut-out” pressure and safety
relief valve activates.
Air compressor is incorrectly sized.
Symptom 4. Air continues to leak at motor/pressure switch release valve after motor stops.
PROBABLE CAUSE
Defective pilot valve, the check valve is stuck open.
Symptom 5. Air continues to leak at motor/pressure switch release valve while motor is running.
PROBABLE CAUSE
Defective motor/pressure switch.
Symptom 6. Air leaks from safety relief valve.
PROBABLE CAUSE
Possible defective safety relief valve.
REMEDY
Move the motor/pressure switch to the “Off” position. If
the motor doesn’t shut off, unplug the air compressor . If
the electrical contacts are welded together, replace the
pressure switch.
Limit the air pressure to the capacity of the air
compressor. Either use a smaller tool or a larger air
compressor.
REMEDY
Remove, clean or replace.
REMEDY
Replace.
REMEDY
Operate safety relief valve manually by pulling on ring.
If it still leaks, it should be replaced.
Excessive air tank pressure.
Symptom 7. Air leaks at pump.
PROBABLE CAUSE
Defective gaskets.
Symptom 8. Air leaks at fittings.
PROBABLE CAUSE
Fittings are not tight enough.
Symptom 9. Air leak in air tank.
PROBABLE CAUSE
Defective or rusted air tank.
Symptom 10. Air blowing from inlet filter.
PROBABLE CAUSE
Damaged inlet (reed) valve.
Defective motor/pressure switch. Replace.
REMEDY
Replace and torque head bolts to 20 ft./lbs.
REMEDY
Tighten fittings where air can be heard escaping. Check
fittings with soapy water solution. Do not overtighten.
REMEDY
Air tank must be replaced. Do not attempt to repair
air tank!
REMEDY
Contact SENCO Customer Service 888-222-8144.
13
TROUBLESHOOTING
Symptom 11. Insufficient pressure at air tool or accessory.
PROBABLE CAUSE
Pressure regulator knob not turned to high enough
pressure or defective pressure regulator.
Restricted air intake filter.
Air leaks.
Hose or hose connections are too small or long.
Air compressor is not large enough for air
requirement.
Symptom 12. Air compressor not making enough air.
PROBABLE CAUSE
Restricted air intake filter.
Defective (reed) valve.
Restriction in pilot valve.
REMEDY
Adjust pressure regulator knob to proper setting or
replace.
Clean or replace.
Check for leaks and repair.
Replace with larger hose or connectors.
Check the accessory air requirement. If it is higher than
the CFM or pressure supply of the air compressor, you
need a larger air compressor.
REMEDY
Clean or replace.
Drain air tank and measure pump up time. Compare to
specifications. If lower, remove pump head and inspect
valve plate, clean or replace.
Clean or replace.
Symptom 13. Excessive oil consumption in pump.
PROBABLE CAUSE
Restricted air intake filter.
Air compressor on unlevel surface.
Crankcase overfilled with oil.
Plugged oil dipstick vent.
Oil leaks.
Worn piston rings or scored cylinder .
Symptom 14. Oil has milky appearance.
PROBABLE CAUSE
Water in oil due to condensation.
Symptom 15. Moisture in discharge air.
PROBABLE CAUSE
Condensation in air tank caused by high level
of atmospheric humidity or air compressor is
not run long enough.
REMEDY
Clean or replace.
Do not incline the air compressor more than 10° in any
direction while running.
Drain oil. Refill to proper level with oil.
Clean.
Repair.
Contact Senco Customer Service.
REMEDY
Change oil and move air compressor to a less humid
environment.
REMEDY
Drain air tank after every use. Drain air tank more often
in humid weather and use an air line filter.
14
SPECIFICATIONS
Model # PC 1001
Motor
Horsepower 2 Equivalent
Voltage 1 15
Amperage 15
Hz. 60
Phase Single
RPM 3400
Compressor Pump
Number of Cylinders 1
Compression Stage 1
Lubrication Splash
Oil Type Non-detergent
Crankcase Aluminum
Bearings Ball
Cylinder Steel sleeve inserts
V alves Reed-Single
Head Aluminum
Filter Canister
Motor/Pressure Switch Setting
Cut-out 1 16 PSI
Cut-in 87 PSI
Controls Start/stop
Air tank
Capacity 4.3 gallons
Performance
CFM Air Displacement 7.7
CFM @ 40 PSI 5.3
CFM @ 90 PSI 4.0
CFM @ 1 16 PSI 3.6
Maximum Pressure 116 PSI
Pump-up Time: 0-116 PSI 1 min., 10 sec.
Recovery Time: 90-116 PSI 15 seconds
Weight
Net 54 Ibs.
Shipping 56 Ibs.
Dimensions
Basic LxWxH 20"x14"x16"
Cubic Feet 2.6'
15
SENCO COMPRESSOR AND PARTS W ARRANTY
This compressor has been designed and constructed using the highest standards of material and workmanship.
COMPRESSOR WARRANTY:
The length of this guarantee is one year from date of purchase by the original retail purchaser. During this period,
Senco Products, Inc., will repair or replace at Senco’s option, any original part or parts for the original retail purchaser. This will
be done free of charge, provided the parts are determined defective in materials or workmanship upon examination by a Senco
Authorized Warranty Service Center, with the exceptions and exclusions described below. Any replacement part provided will
carry a warranty for the balance of the period of warranty applicable to the part it replaces. When repair or replacement of parts
or compressor is necessary, the original retail purchaser returns the complete compressor or part, with transportation prepaid,
to the nearest Senco Authorized Warranty Service Center , with purchase receipt or other positive proof that the part or compressor
is within the warranty period.
Senco warrants all parts (except those listed below) of your Senco air compressor to be free from defects in materials and
workmanship during the following periods:
1. For 1 year from date of original purchase:
2. For 90 days from date of original purchase:
Defective parts not subject to normal wear and tear will be repaired or replaced, at our (Senco’s) option, during warranty period.
In any event, reimbursement is limited to the purchase price paid.
EXCLUSIONS:
1. Engine/Motor is covered under separate warranty by its respective manufacturer and is subject to the terms set forth
therein.
2. Normal wear parts not covered under warranty:
3. This warranty does not cover parts damaged due to normal wear, misapplication, misuse, accidents, operation at other
than recommended speeds or voltage (electric units only), improper storage, or damages resulting during shipping.
4. Deviation from operating instructions, specifications, and maintenance schedules.
5. Labor charges, loss or damage resulting from improper operation, maintenance or repairs made by person(s) other than
a Senco Authorized Warranty Service Center.
6. The use of other than genuine Senco Repair Parts will void warranty.
Compressor Pump Pilot Valve
Tank Assembly Plumbing
Flywheel Throttle Control
Power Cord
Pressure Gauge Pressure Relief
Valve Draincocks
Isolators Drive Belt
Air Filter
This warranty is contingent upon proper use of the compressor by purchaser and does not cover:
THIS WARRANTY IS THE ONLY WARRANTY ON THIS COMPRESSOR, AND ALL OTHER WARRANTIES, WHETHER
ORAL, WRITTEN, EXPRESS, OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED. BUYER’S OR USER’S REMEDIES
ARE SOLELY AND EXCLUSIVELY AS STATED ABOVE. SENCO PRODUCTS, INC. SHALL IN NO EVENT BE LIABLE FOR
INCIDENTAL, CONSEQUENTIAL, INDIRECT, OR SPECIAL DAMAGES. IN NO EVENT, WHETHER AS A RESULT OF A
BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING NEGLIGENCE) OR OTHERWISE, SHALL SENCO’S LIABILITY
EXCEED THE PRICE OF THE COMPRESSOR WHICH HAS GIVEN RISE TO THE CLAIM OR LIABILITY. ANY LIABILITY
CONNECTED WITH THE USE OF THIS COMPRESSOR SHALL TERMINA TE UPON THE EXPIRA TION OF THE WARRANTY
PERIOD SPECIFIED ABOVE.
Senco will also replace any compressor destroyed by an Act of God such as flood, earthquake, hurricane or other disaster
resulting only from the forces of nature. Such a claim will be honored provided that such original retail purchaser had previously
submitted a completed warranty registration card, and then submits proof of ownership and an acceptable statement describing
such Act of God documented by an insurance carrier, police department, or other official governmental source. To obtain
instructions for filing a claim call 1-800-543-4596.
(A) Abnormal conditions, accident, neglect, misuse or improper storage of the unit.
(B) Deviation from operating or maintenance instructions.
(C) Modifications not authorized by Senco.
(D) Repairs or maintenance (other than routine air tank draining and oil filter changes required by your operating
and maintenance manual) made by persons other than Senco or its authorized agents.
(E) Freight damage.
Replacement of Compressor Due to Natural Disaster
SENCO PRODUCTS, INC.
CINCINNA TI, OHIO 45244-1611 USA
16
Loading...
