Electronic Security
Hardware
HES | Securitron Product Catalog
138
Securitron MCL Cabinet Lock
Dimensions Specifications
Electrical
Cabinet Locks
4-5/8"
[117m m]
• 84mA at 24 VDC
Holding Force
• Static Strength 170 lbs
1-1/8"
[29mm]
3/4"
[19mm]
1/4 "
[6mm]
3-1/8"
[79mm]
Swinging Door Sliding Door
Environmental
• Operating Temperature: 40° to 140°F [-40° to 60°C]
• Indoor or outdoor use
Shipping Weight
• 6 lbs [2.72kg]
1-1/8"
[29mm]
US assaabloyesh.com | 800.626.7590 | customerservice.esh@assaabloy.com
Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com
Copyr ight © 2019, Hanche tt Entr y System s, Inc., a n ASSA ABLOY Gro up company. A ll right s reserv ed. Repro duction
in whol e or in part w ithout th e express w ritten p ermissio n of Hanchet t Entry Sy stems, I nc. is prohib ited.
Updated 6/7/19 Patent pending and/or patent www.assaabloydss.com/patents
Securitron®
M32-SS Split Strike
®
Magnalock
Double-door cabinet control
139
Cabinet Locks
Now you can add asset
control to your existing
access control system
with the durable,
power-efficient
Securitron M32-SS.
Each strike plate of the Securitron M32-SS
delivers 300 lbs of holding force (600 lbs total).
Ideal for securing large two-door cabinets,
retail cases or double-door, indoor/outdoor
storage applications with out-swinging
doors that share a center latching point.
Features
Standard Features
• Direct mount with common tools
for strength and reliability
• For 5/8" to 7/8" [15.875mm to
22.225mm] thick cabinet doors
• Ef ficient, low power usage
• Noise suppression with included MOV
• Instant release circuit
— no residual magnetism
• Fully sealed and for
weather-proof operations
• Rust resistant — all ferrous metal
surfaces plated for durability
• 10 ft. [3.05m] of jacketed,
stranded conductor cable
• MagnaCare
no-fault, no questions asked warranty
®
lifetime replacement,
Optional Features
• B BondSTAT
sensor — Patented (MBS)
• Use with CWB-32 bracket
for mounting option on
wood or concrete
®
magnetic bond
